CAMP-IRL Agents: Extracting Multiple Behavior Proﬁles

for Pedestrian Simulation

Nahum Alvarez

1 a

and Itsuki Noda

2 b

Airbus Central Research & Technology, Munich, Germany

National Institute of Advanced Industrial Science and Technology, Japan

Keywords:

Pedestrian Simulators, Agent Behavior, Inverse Reinforcement Learning.

Abstract:

Crowd simulation has been subject of study due to its applications in the ﬁelds of evacuation management,

smart town planning and business strategic placing. Simulations of human behavior have many useful ap-

plications but are limited in their ﬂexibility. A possible solution to that issue is to use semi-supervised ma-

chine learning techniques to extract action patterns for the simulation. In this paper, we present a model for

agent-based crowd simulation that generates agents capable of navigating efﬁciently across a map attending

to different goal driven behaviors. We designed an agent model capable of using the different behavior pat-

terns obtained from training data, imitating the behavior of the real pedestrians and we compared it with other

models attending to behavioral metrics.

1 INTRODUCTION

Crowd behavior simulation has a large number of ap-

plications in diverse domains. However, experiment-

ing with real crowd presents a number of logistic dif-

ﬁculties and it is usually not practical, or even infea-

sible in certain instances. Therefore, a way to solve

this issue is to use a simulator in order to replicate

the desired scenario. Agent based models are com-

monly used to perform those simulations, due to their

ﬂexibility and scalability, and allow to produce com-

plex crowd interactions using models composed of

simple actions, given that we understand its behavior

rules. However, modeling human behavior is a com-

plex problem due to be subject to hidden rules; the re-

sulting behavior appears to follow sub-optimal plans

that are difﬁcult to understand. A way to approach

this problem is to use machine learning techniques on

available data in order to give the agents a way to react

to new but similar situations.

In this paper, we present an agent model that

works with a novel variant of Inverse Reinforcement

Learning (IRL from here on), able to capture hidden

pedestrian behavior rules training with observed data.

The model then applies those rules to agents simu-

lating pedestrians, giving them decision making ca-

https://orcid.org/0000-0003-1717-2506

https://orcid.org/0000-0003-1987-5336

pabilities. Our technique allows to evaluate different

sets of actions depending on the location of the agent,

extracting different behavior patterns, called policies,

from the data. Hence, we called this method ”Con-

textual Action Multiple Policy Inverse Reinforcement

Learning”, or CAMP-IRL. Our objective is to repro-

duce more realistic pedestrian behavior, and by ana-

lyzing how this behavior is inﬂuenced by the features

in the environment, we would be able to decide which

spot is best for certain type of feature and how would

change pedestrian afﬂuence if we add new features or

modify the existent ones.

The rest of the present document is organized as

follows: Section 2 consists on a survey of related

work about IRL in agent behavior and pedestrian sim-

ulators. Our crowd simulator and its architecture are

described in Section 3, and the CAMP-IRL technique

and the behavioral model of the agents are detailed

in Section 4. Section 5 contains our behavior com-

parison experiment and its results. Finally section 6

presents our conclusions.

2 IRL IN CROWD SIMULATORS

Pedestrian and trafﬁc simulations have been the object

of interest because it can deal with a number of real-

life problems in our society. For example, it can be

216

Alvarez, N. and Noda, I.

CAMP-IRL Agents: Extracting Multiple Behavior Proﬁles for Pedestrian Simulation.

DOI: 10.5220/0010209602160223

In Proceedings of the 13th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2021) - Volume 1, pages 216-223

ISBN: 978-989-758-484-8

used to improve transportation systems and networks

and in obtaining solutions to lower car pollution (Fac-

cin et al., 2017), or to assist in the design of evac-

uation strategies in concrete scenarios like natural or

disasters (Yamashita et al., 2009) or terrorist incidents

ammel et al., 2010).

There is a wide spectrum of works in pedestrian

simulation with agents, using different techniques.

Systems based in video analysis give good results,

like the one found in (Zhong et al., 2016), but in

order to remain practical they narrow their domain,

using tile location and pre-generated trajectories for

the agents. Another common strategy is to model the

agents with a dual behavior system controlling two

types of movement: micro and macro movement. The

ﬁrst deals with collision avoiding in the near space

and adjusting the agent’s velocity in the crowd’s ﬂow,

and the second is the one in charge of driving the

agent towards its goal, creating and updating its route

and taking care of the decision making process (Tor-

rens et al., 2012). Our pedestrian simulator, uses as

well a multi-agent approach to represent pedestrians.

Instead of scripting the agents by hand, having

low ﬂexibility and escalating badly, we can take ad-

vantage of machine learning techniques to learn their

behavior. Concretely, apprenticeship learning meth-

ods have been widely used in intelligent agents’ sys-

tems to train them to perform tasks in dynamic envi-

ronments like (Svetlik et al., 2016) or observe strate-

gies to emulate predeﬁned driving behaviors in (Fac-

cin et al., 2017). There are also works where agents

are given a behavior cognitive model for pedestrians

like in (Luo et al., 2008), (Martinez-Gil et al., 2017)

or (Crociani et al., 2016). However, we see that in all

of those works the behavior model (i.e. the policies

ruling the agents) is predeﬁned by a designer, but in

the case of pedestrians, the rules and goals directing

their actions are not visible, so learning those behav-

ior patterns is a difﬁcult problem.

To overcome this problem, an useful technique is

Inverse Reinforcement Learning, being appropriate to

model behavior because it tackles the problem of not

knowing the reward function that drives the behav-

ior, needing a set of expert demonstrations (Ng et al.,

2000). IRL techniques work on domains that can be

modeled by a Markov Decision Process (MDP, from

here on after) and are used to learn its hidden reward

function. Works using IRL to control agent behav-

ior are sparse but effective (Herman et al., 2016), as

it is shown in (Abbeel and Ng, 2004) where driving

styles are learned by an agent, or (Natarajan et al.,

2010) where different agents work together for rout-

ing trafﬁc. Other IRL methods perform even better,

like (Dvijotham and Todorov, 2010), which works on

a subset of MDPs, but it does not match well with our

domain, or (Levine et al., 2011) which works with

non-linear reward functions.

As different pedestrians have different goals that

drive different types of behavior, we should learn each

one separately instead of merging all of them in one.

Obtaining multiple policies from observed behavior

has already been tackled by a number of works. We

can consider plan recognition techniques, like the one

contained in (Ram

ırez and Geffner, 2009), used to

identify the objective of the agent in an observed state,

selecting it from a list of deﬁned goals. These kinds

of techniques work well and have good performance

when compared with IRL basic approaches, like max-

imum entropy IRL, as seen in (Lelerre et al., 2017)

or (Le Guillarme et al., 2016). However, our pedes-

trian behavior domain has a number of desired re-

quirements that would be very limited if we use these

techniques: they assume that the agent’s decisions

should be optimal, with deterministic state transitions,

but real pedestrians do not have those characteristics.

Also, they select the goals from a predeﬁned set, but

we may not have that information in the training data.

Finally, they consider the goals as mutually exclusive,

whilst actual pedestrians behavior is a product of the

combination of goals.

With this requirements in mind, we preferred to

explore unsupervised learning techniques to segment

the data into different behavior proﬁles, and looked

to approaches that mix well with our IRL behavior

model. In (Surana and Srivastava, 2014), we can ﬁnd

a method to switch between different MDPs to ob-

tain their related policy functions that works reason-

ably well extracting different behaviors. (Michini and

How, 2012) show how to divide the data in smaller

sub-goals in order to obtain simple reward functions,

and (Krishnan et al., 2016) describe a hierarchical

method for selecting MDP partitions with different

policies for each sub-MDP, which can be interest-

ing for domains where the agent has a number of se-

quential small sub-goals. In our case, we decided to

based our method on the one found in (Choi and Kim,

2012), which is able to infer different policies from

the data by clustering the trajectories in the training.

3 PEDESTRIAN SIMULATOR

Our simulator, called CrowdWalk (Alvarez and Noda,

2018), is a pedestrian simulator designed for generic

uses, where each pedestrian is represented by an

agent. CrowdWalk allows the generation of complex

behavior and escalates well, being suitable for large

scenarios with high numbers of agents; it can simulate

CAMP-IRL Agents: Extracting Multiple Behavior Proﬁles for Pedestrian Simulation

217

movements of more than 1 million agents in a diverse

array of locations, like multi-storied buildings or large

city areas. Maps can be created by hand or obtained

from open source formats, and pedestrian behaviors

are conﬁgurable so that we can conduct simulations

with various situations. Internally, CrowdWalk uses

a Network-based model; the map is described in the

form of a network where nodes represent intersections

and links represent paths. A link has length and width

attributes, inﬂuencing how long the agents need to

walk from an end to another and how many agents

can walk in parallel, and can be two-way or one-way.

Nodes and links can contain features, usually describ-

ing what facilities are on that location.

CrowdWalk contains an agent factory that gen-

erates one agent per pedestrian. Each agent has its

own decision model, composed by the micro and

macro behavior modules. The micro behavior mod-

ule in each agent takes care of micro movements au-

tomatically, calculating when an agent has to stop,

walk slower or deciding when it is unable to continue

through the current path. The speed of an agent is

given in relation with the density of the link it is cur-

rently in, being slower as the link is more crowded,

until a maximum capacity limit where it is not possi-

ble to continue advancing. The macro behavior mod-

ule is the one in charge of planning the agent’s route

to its goal, and updating it if necessary. Our CAMP-

IRL module controls directly this module when it is

used.

4 AGENT MODEL

Our CAMP-IRL module contains two separated parts:

one part is executed before the simulation, which con-

tains the CAMP-IRL method itself, and the other con-

trols the agents’ macro behavior during the simula-

tion, being the CAMP-IRL agents’ controller. The

next subsections describe in depth each one of those.

4.1 The CAMP-IRL Learning Process

The CAMP-IRL method consists in a non-parametric

Bayesian approach to IRL, that works with an adap-

tation of the MDP to our domain.

We deﬁne Contextual Action Multiple Policy

MDP(CAMP-MDP) as an MDP {S,A,T ,γ,R } us-

ing the deﬁnition of S as the set of states, the transi-

tion function T (s, a, s’ ) from one state to another by

executing an action, and γ as the discount factor.

We also deﬁne the super set A(s) of actions as a

function of a state s, and a set of Reward functions R .

Each reward function can be deﬁned as R(s) where s ∈

S and can be used to generate a policy π that contains

a list of consecutive pairs of states and actions in the

form s,a where a ∈ A(s). This allows for each state

to have a different set of actions.

In our domain, where each map node has a dif-

ferent number of possible links to take, we can iden-

tify each node with a state and the links available to

them to their set of actions. To reduce the size of

the solution space, those actions are contextual, so

they have different meaning depending on the current

state, keeping the total number of actions small. Also,

the map features contained on each node, are assigned

to the correspondent states, and will be used in the

training process

The CAMP-IRL algorithm is based on the Dirich-

let process mixture model Bayesian IRL, adapting it

to be able to work with a CAMP-MDP, considering

that each state will have a different action set. The

Dirichlet process (Neal, 2000) is used to classify the

trajectories into different clusters, and then the reward

is calculated for each cluster using a Bayesian ap-

proach to the IRL method using the next algorithm

and formulas:

1. Initialize the cluster set C containing K elements

and the reward set {r}

k=1

(i) The initial clusters and their reward function

are randomized. The reward function consists

in a weight vector containing the weights of all

the map features.

(ii) An initial policy is generated randomly from

each reward. This policy consists in a vector

containing the optimal action to perform for

each node, and it is obtained by calculating the

value of performing the most optimal action a

from the available actions in the state s follow-

ing the next function:

∗

(s) = max

a∈A(s)

R (s,a) + γ

∑

∈S

T (s,a,s

∗

)

2. For each element m in the trajectory set, select

a new cluster candidate c

∗

using the following

rules:

(i) If the trajectory has no assigned cluster, gener-

ate a new one and a reward function for it

(ii) If it has one, obtain the most populated cluster

(iii) Assign the trajectory to the new cluster with

probability:

P(X

∗

)

P(X

)

3. For each cluster k:

(i) Create a weight vector candidate

∗

= r

∇log(P(X

)P(r

)) +τα

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

218

where τ is a scaling factor and α is a random

number sampled from a multinomial distribu-

tion (0,1).

(ii) Update the weight vectors with probability

P(X

∗

)P(r

∗

)g(r

∗

)

P(X

)P(r

)g(r

∗

)

being the function g() the gradient from the

Langevin algorithm calculated as follows:

g(x,y) =

exp



−1

2 τ



x − y −

∇log(P(X

|x)P(x))





(2πτ

)

D/2

where τ is a scaling factor.

4. Repeat the process from (2) until convergence.

Once ﬁnished, it is possible to use the obtained

set of optimal policies for each cluster to calcu-

late the value vector as follows:

(s) = R (s,π) + γ

∑

∈S

T (s,π,s

)

This value represents the expected reward of exe-

cuting the policy π on a node s.

The inputs of the CAMP-IRL method are the map

used by CrowdWalk, which is converted into a

CAMP-MDP, and a ﬁle containing the trajectories we

want to train. Once the training process ﬁnishes, we

obtain two ﬁles: one containing the weight vectors of

the features of each discovered cluster, and another

containing the value of each map node (as deﬁned in

the step 4 of the algorithm) for each cluster. We group

both weight vector and node’s values by the cluster

they belong to, deﬁning these groups as ”behavior

proﬁles” and storing them in a ﬁle format. Thus, those

ﬁles will be used in the simulation by the CAMP-IRL

agents to select the behavior proﬁle they should have

and which path to take.

Finally, this process can be iterated by simulating

agents with the obtained behavior proﬁles and train-

ing the system again with their resulting trajectories,

generating a new set of behavior proﬁles. We con-

sider this new set as a reﬁnement of the original pro-

ﬁles, and in our experimental observations the new

ones performed always better than the originals; we

will extend more on this topic in the experiments sec-

tion.

4.2 The CAMP-IRL Agents

Once the simulation starts, CrowdWalk’s Agent Han-

dler creates the agents using our CAMP-IRL Agent

Controller. The CAMP-IRL agents use three input

ﬁles directing their behavior; the ﬁrst two ﬁles are the

Weight and value ﬁles from the CAMP-IRL process,

and the third one consists in a database containing

their goals. Those can be generic features, like “visit-

ing a restaurant”, or concrete nodes from the map, like

“visiting the node labeled as nd00465”. Also, this ﬁle

contains an evacuation point to go after completing

the goals.

The decision making process of the CAMP-IRL

agent is shown in Figure 1. First, the agent selects the

proﬁle that has the highest weight for the features as-

sociated to its goals. As the agent may have multiple

goals and also the weights may be similar, the agent

selects a set composed of the proﬁles that are within a

threshold from the one with the highest weight. From

the experience of our tests, we concluded that a 10%

of threshold gives the best results. The set of selected

proﬁles from the agent’s proﬁle list. Once completed

this step, the agent chooses from this list the proﬁle

with the highest value in its current node according to

the value ﬁle.

Whenever an agent enters in a node, it checks if

that is a goal in its list or not. In case it is not a

goal, the agent compares the value of the nodes con-

nected to the current one and selects randomly one

node within the set of best valued ones. This set is

created also using a threshold range from the highest

valued node, and again a threshold of a 10% gave us

the best results. The selection of the best valued nodes

ignores the node the agent is coming from, under the

rationale of the agent coming from a node with an al-

ready high value and having to conform with lower

values after that. Once the best node to go is selected,

the agent moves to it.

If the agent entered in a node containing a goal,

then the agent enters in an state of waiting, represent-

ing the agent satisfying its goal. The goal satisfaction

time is given by the training process, which in paral-

lel with the CAMP-IRL algorithm, performed a linear

regression to learn from the waiting times present in

the trajectories, using the node features to estimate

such time. When the goal is satisﬁed, the agent ver-

iﬁes if it has remaining goals. If all the goals have

been satisﬁed, the agent evacuates by going directly

to the evacuation point (this movement is no more be-

havioral, and is performed by calculating the shortest

route to the evacuation node).

If there are still goals unsatisﬁed, the agent pro-

ceeds to select a new proﬁle. However, before select-

ing one it updates its proﬁle’s list, as it has fewer goals

now, so some proﬁles are not useful anymore. After

deleting those proﬁles related with the satisﬁed goals,

the agent chooses a proﬁle from its list in the same

way that it did initially.

Finally, the agent has a timeout in case it spends

too much time wandering across the map without

CAMP-IRL Agents: Extracting Multiple Behavior Proﬁles for Pedestrian Simulation

219

Figure 1: The CAMP-IRL agents’ algorithm. Once they reach a map node, they use the proﬁle correspondent to its current

goal to choose the next one. If they satisfy a goal, they search for another one selecting the proﬁle that suits it best.

reaching any goal. If the timeout ﬁnishes, the agent

will select a new proﬁle, but this time the method it

uses is different. Instead of selecting a proﬁle from

its proﬁle’s list, the agent selects randomly another

proﬁle from the whole set, with the only condition

that it has to be different than the previous one. This

represents the agent deciding that its previous actions

where not advancing it to the goal, and it has to “ex-

plore” the map.

5 EXPERIMENTAL RESULTS

We performed an experiment in order to evaluate two

aspects: ﬁrst, the performance of the CAMP-IRL

agents, and second, their behavior similarity with the

trained data. For the ﬁrst aspect, we measured the

time the agents took in satisfying goals belonging to

different pedestrian proﬁles whose trajectories were

previously trained. We compared our agents with

other types of agents: one agent using a different IRL

method that extracts only a unique policy and reward

function from the whole set of trajectories and does

not use contextual actions (this means it has a ﬁx set

of actions and only one proﬁle) called “Single IRL

Agent” and ﬁnally one agent that extracts multiple

proﬁles but with no contextual actions called “Multi

IRL Agent”. The Single IRL Agent used the max-

imum entropy algorithm from (Ziebart et al., 2008),

chosen because it works well when the agents do not

have much information about the layout of the map,

and the Multi IRL agent used the method shown in

(Choi and Kim, 2012). We also compared each type’s

coverage of the map.

The training set consisted in 150 trajectories that

could be divided into ﬁve hypothetical behavior pro-

ﬁles: “restaurant” for pedestrians that are going look-

ing for a place to eat; “books” for pedestrians that are

going to buy books, magazines or other paper ware;

“cinema” for pedestrians going to the cinema or simi-

lar entertainment places (theater, games, etc.); “shop-

ping” for pedestrians that want to buy clothes; and

ﬁnally “supermarket” that covers pedestrians going

to supermarkets or convenience stores. The trajecto-

ries were created by artiﬁcial methods due to the lack

of real data in this domain, but they were designed

to be as realistic as possible. The trajectories were

slightly noisy, with the pedestrians making small de-

tours and wandering a bit while they were going to

their goals. The map we used was a portion of Tokyo

from the Toshima ward area, containing commercial

areas, entertainment spots, a train station, and resi-

dential zones.

After we trained the system with the original train-

ing set, we obtained a total of 7 proﬁles for feeding

the agents, which will be called “CAMP-IRL A” from

here on. We observed that from these 7 proﬁles, three

of them were strongly related one-to-one to three of

the original behavior proﬁles we intended to train, and

the other four were a combination of some of the orig-

inal proﬁles. Then, after we trained again the system

with the trajectories obtained from a simulation using

these agents, we obtained a set of eight proﬁles for

a second agent, which we will call “CAMP-IRL B”.

Each training process took between 6 and 7 hours to

complete.

We observed that CAMP-IRL agents A and B had

three identical proﬁles, and other two proﬁles that

were moderately similar. Our explanation for this is

that some proﬁles are strongly tied to certain features,

like restaurants, or cinemas, but other are the prod-

uct of a combination of proﬁles, that represent more

generic activities like shopping. In the case of those

proﬁles moderately similar to others, it is because the

combination is similar with slight variations of the

features’ weight.

In the future will be interesting to isolate the pro-

ﬁle extraction from the IRL method, and comparing

it with other methods like the inverse planning tech-

niques we described in Section 2. Even with the re-

striction of having a predeﬁned set of exclusive goals,

we could use it as a trade-off comparison. Also, inter-

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

220

esting improvements to those methods have been pro-

posed, like in (Ram

ırez and Geffner, 2011), allowing

them to work with POMDP models, so we could use

them to work with no deterministic environments.

We prepared simulations for all the agent types.

The simulator was set under the same conﬁguration

for each type: 150 agents, each one with ﬁve goals,

one for each one of the original proﬁles. Each simu-

lation was executed 20 times in order to average the

results; we considered this number enough to have

conﬁdence in our validation as we did not observe a

signiﬁcant deviation in the ﬁnal results. Also, in or-

der to avoid adding noise to the results, we set all the

agents to not taking any time in satisfying the goals

and keep walking immediately; the training trajecto-

ries were also created without such delays.

Table 1: Average clear times by agent type.

Agents Individual Whole set

CAMP-IRL A 53:09 5:24:05

CAMP-IRL B 41:43 3:00:42

Multi IRL 1:30:13 10:16:31

Single IRL 2:22:06 12:33:04

Table1 shows the average times for an individual

agent to satisfy the goals and the average clear time

for the whole set of 150 agents of each simulation.

By seeing the results, we conﬁrmed that CAMP-IRL

B agents obtain substantially better times than the oth-

ers, taking only three hours to complete the simula-

tion.

Table 2: Average trajectory length in number of nodes.

Agents Trajectory Length

Trained routes 41

CAMP-IRL A 75

CAMP-IRL B 56

Multi IRL 142

Single IRL 206

Table 2 shows the average trajectory length of each

type of agent, including training trajectories infor-

mation for reference reasons; CAMP-IRL agents not

only beat the others in the time to clear all the goals

but also their paths are more efﬁcient, wandering less

than the others. The trajectories of CAMP-IRL B

agents were the closest to the trained routes.

Evaluating the second aspect, behavior, is more

difﬁcult; we decided to compare agent’s behavior us-

ing as our metric the popularity of the map features

and goals, i.e. how often the agents traverse those

spots or go directly to there. It is important to note

that we do not want to replicate the trajectories, so us-

ing path comparison is not enough to give insight to

how similar the behavior is, and also images of the

trajectories generated by the different agents are ap-

parently similar. However, we can compare the most

popular nodes in the map for each feature and how the

agents distribute across them.

The rationale of this idea is the following: we can

identify popular nodes in the original training routes,

and future pedestrians should also consider them pop-

ular; however, as the training routes did not cover all

the possible routes and goal combinations, if we want

to imitate behavior instead of trajectory planning, the

pedestrian distribution on the test map should be dif-

ferent compared to the trained ones, but also the popu-

lar nodes should be still consistent. In sort, we search

for high similarity in the list of top ten popular nodes

and low similarity in the distribution of the agents

over that list. This effect also would allow to obtain

the expected popularity of areas with little or no data

by simulating the agents on them.

Table 3 shows the similarity degree between the

agents and the trained routes on node popularity and

on distribution of the agents when looking actively

for a goal node. We can see that in general all the

agents have high similarity in top node popularity,

with CAMP-IRL B agents having slightly higher val-

ues. This is due to IRL being a good method in gen-

eral to extract hidden rewards assigned to the nodes,

identifying which ones are the best to get goals. How-

ever, when we observe the distribution of the agents

across the map, we see that CAMP-IRL agents have

the lowest values, meaning that these agents choose

more diverse options while maintaining knowledge of

the rewards; on the other hand, agents with high val-

ues in the similarity of the distribution are inclined to

just imitate the trained routes. This follows the line

of our hypothesis: having high values in the top node

similarity, but low values in the distribution. We ob-

served a particular case with the cinema goal features;

as there are only 4 in the map, the top ten only con-

tained 4 nodes, and all the agents have maximum sim-

ilarity in that aspect. However, the distribution still

gets its lowest value with CAMP-IRL B agents.

A potential use of this analysis is to obtain the

list of nodes that are popular because they are sought

actively to satisfy a goal, or which ones are popular

because a high number of pedestrians are passing by

them. This information can be very useful to get busi-

ness insight of future facilities by simulating them on

the map with the CAMP-IRL agents. Also, by seeing

the results we can afﬁrm that popular locations are

different if we use pedestrian afﬂuence or goal driven

behavior as the metric to obtain, being both useful for

CAMP-IRL Agents: Extracting Multiple Behavior Proﬁles for Pedestrian Simulation

221

Table 3: Similarity with the training routes in goal popularity and similarity of the agent distribution across the top nodes.

Feature CAMP-IRL A CAMP-IRL B Multi IRL Single IRL

Distrib. Top Nodes Distrib. Top Nodes Distrib. Top Nodes Distrib. Top Nodes

Shop 63.47% 60% 59.36% 70% 82.01% 70% 71.96% 70%

Supermarket 51.72% 70% 48.16% 70% 60.91% 70% 71.81% 70%

Books 74.08% 90% 57.7% 90% 52.15% 80% 67.08% 90%

Cinema 74.68% 100% 60.73% 100% 65.85% 100% 87.42% 100%

Restaurant 47.46% 70% 53.01% 80% 68.72% 80% 63.08% 70%

Total 62.28% 78% 55.79% 82% 65.92% 80% 72.27% 80%

management reasons as we may be just looking for a

spot with high afﬂuence in order to sell to casual cus-

tomers, or aim for more specialized customers that go

on purpose to certain locations.

We also noted space to improvement, as we ob-

served that some useful information from the map and

the routes is not being reﬂected in the learning pro-

cess: in the experiments, cinemas were a scarce fea-

ture that only was present in four nodes of the map;

the agents were able to ﬁnd it, but the wandered exces-

sively before doing it. After analyzing why this was

happening, we found this situation was due to the co-

incidence of two factors: scarcity of the goal feature

and few and indirect ways to reach it. In our example

to reach one of those features, the agents had to cross

a large avenue which could only be crossed on cer-

tain points of the map, but those points were not very

remarkable in terms of value for the proﬁle selected

to reach that feature. Thus, agents near that feature

were conducted by their proﬁles to go towards it, but

when reaching the large avenue they could not ﬁnd the

crossing point which was far away. We plan to solve

this issue by enriching the map information, estab-

lishing semantic relations between nodes like those

crossing points and the featured nodes.

Finally, we observed consistently in our exper-

iments that the act of retraining the system with

CAMP-IRL agents as the source of data improved

greatly its performance, and after analyzing their be-

havior proﬁles, we noted that some of the proﬁles are

kept across the training steps, but other are combi-

nations of some sort. That may be the reason of the

improvement in the results, as those combined pro-

ﬁles are reﬁned in subsequent training stages. Hence,

we want to analyze more in depth how this effect is

produced.

6 CONCLUSIONS

This paper presents a behavioral model for pedes-

trian agents using a technique called CAMP-IRL. The

CAMP-IRL method works with contextual actions,

different depending on the location of the agent, and

generates multiple policy functions for them, creat-

ing a proﬁle per policy. Our model converts a city

map into a CAMP-MDP and trains with the trajec-

tories database, generating a set of behavior proﬁles.

These proﬁles are used to navigate across the map by

the agents, choosing the proﬁle that ﬁts best to their

goal. The generated agent behavior can be analyzed

then in order to obtain insight on what are the most

popular features in the map, and predict how would

be the performance of new ones.

We performed an experiment in order evaluate our

agents’ performance and how much similar are their

generated behaviors to the trained data. Our CAMP-

IRL agents perform better than others trained using

different methods and get the best clear times in the

simulator. They also have more optimal routes, with

results similar to the trained ones with the difference

of having no knowledge of the map. When looking

at behavior similarity, we observed that our agents

consider similar nodes for goal seeking as the train-

ing data, but their actual decisions are based on the

current surroundings and behavior proﬁle, resulting

in a more different agent distribution. We also noted

in our experiments that re-training the system using

data obtained from a previously trained agents yielded

even better results, with CAMP-IRL B agents obtain-

ing consistently the best results in our tests.

We think the results of our experiment opened in-

teresting research paths, and we plan to add a pre-

processing step to the CAMP-IRL process to enrich

the map information, in order to improve more the

agents’ navigation around difﬁcult areas. Also, we

observed that it is possible to extract knowledge of

the popularity of the map locations, either due to be-

ing an actively sought goal or due to be in spots very

transited or complementary to other goals, and pre-

dict the popularity of other areas, not only analyz-

ing pedestrian afﬂuence but also goal driven behav-

ior, giving different results depending on which one

of those metrics is used. We plan to analyze how

re-training affects the proﬁles and how they are com-

bined in subsequent training cycles as the improve-

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

222

ment in performance was very evident but still the

concrete reason being unclear.

ACKNOWLEDGEMENTS

This work was partially supported by JSPS KAK-

ENHI Grant Number 18H03301.

REFERENCES

Abbeel, P. and Ng, A. Y. (2004). Apprenticeship learning

via inverse reinforcement learning. In Proceedings of

the twenty-ﬁrst international conference on Machine

learning, page 1. ACM.

Alvarez, N. and Noda, I. (2018). Inverse reinforcement

learning for agents behavior in a crowd simulator. In

International Workshop on Massively Multiagent Sys-

tems, pages 81–95. Springer.

Choi, J. and Kim, K.-E. (2012). Nonparametric bayesian in-

verse reinforcement learning for multiple reward func-

tions. In Advances in Neural Information Processing

Systems, pages 305–313.

Crociani, L., Vizzari, G., Yanagisawa, D., Nishinari, K., and

Bandini, S. (2016). Route choice in pedestrian sim-

ulation: Design and evaluation of a model based on

empirical observations. Intelligenza Artiﬁciale, 10(2).

Dvijotham, K. and Todorov, E. (2010). Inverse optimal con-

trol with linearly-solvable mdps. In Proceedings of the

27th International Conference on Machine Learning.

Faccin, J., Nunes, I., and Bazzan, A. (2017). Understand-

ing the Behaviour of Learning-Based BDI Agents in

the Braess’ Paradox, pages 187–204. Springer Inter-

national Publishing.

Herman, M., Gindele, T., Wagner, J., Schmitt, F., Quignon,

C., and Burgard, W. (2016). Learning high-level nav-

igation strategies via inverse reinforcement learning:

A comparative analysis. In Australasian Joint Confer-

ence on Artiﬁcial Intelligence. Springer.

Krishnan, S., Garg, A., Liaw, R., Miller, L., Pokorny, F. T.,

and Goldberg, K. (2016). Hirl: Hierarchical inverse

reinforcement learning for long-horizon tasks with de-

layed rewards. arXiv preprint arXiv:1604.06508.

ammel, G., Grether, D., and Nagel, K. (2010). The rep-

resentation and implementation of time-dependent in-

undation in large-scale microscopic evacuation simu-

lations. Transportation Research Part C: Emerging

Technologies, 18(1):84–98.

Le Guillarme, N., Mouaddib, A.-i., Gatepaille, S., and Bel-

lenger, A. (2016). Adversarial intention recognition as

inverse game-theoretic planning for threat assessment.

Lelerre, M., Mouaddib, A.-i., and Jeanpierre, L. (2017). Ro-

bust inverse planning approaches for policy estimation

of semi-autonomous agents. pages 951–958.

Levine, S., Popovic, Z., and Koltun, V. (2011). Nonlin-

ear inverse reinforcement learning with gaussian pro-

cesses. In Advances in Neural Information Processing

Systems, pages 19–27.

Luo, L., Zhou, S., Cai, W., Low, M. Y. H., Tian, F., Wang,

Y., Xiao, X., and Chen, D. (2008). Agent-based hu-

man behavior modeling for crowd simulation. Com-

puter Animation and Virtual Worlds, 19(3-4).

Martinez-Gil, F., Lozano, M., and Fern

andez, F. (2017).

Emergent behaviors and scalability for multi-agent re-

inforcement learning-based pedestrian models. Simu-

lation Modelling Practice and Theory, 74:117–133.

Michini, B. and How, J. P. (2012). Bayesian nonparamet-

ric inverse reinforcement learning. In Joint European

Conference on Machine Learning and Knowledge

Discovery in Databases, pages 148–163. Springer.

Natarajan, S., Kunapuli, G., Judah, K., Tadepalli, P., Ker-

sting, K., and Shavlik, J. (2010). Multi-agent inverse

reinforcement learning. In Ninth International Con-

ference on Machine Learning and Applications. IEEE.

Neal, R. M. (2000). Markov chain sampling methods for

dirichlet process mixture models. Journal of compu-

tational and graphical statistics, 9(2):249–265.

Ng, A. Y., Russell, S. J., et al. (2000). Algorithms for in-

verse reinforcement learning. In Icml, pages 663–670.

Ram

ırez, M. and Geffner, H. (2009). Plan recognition as

planning. In Proceedings of the 21st International

Joint Conference on Artiﬁcal Intelligence, San Fran-

cisco, CA, USA. Morgan Kaufmann Publishers Inc.

Ram

ırez, M. and Geffner, H. (2011). Goal recognition over

pomdps: Inferring the intention of a pomdp agent. In

Proceedings of the 22nd International Joint Confer-

ence on Artiﬁcial Intelligence, IJCAI’11. AAAI Press.

Surana, A. and Srivastava, K. (2014). Bayesian nonpara-

metric inverse reinforcement learning for switched

markov decision processes. In Machine Learning and

Applications (ICMLA), 2014 13th International Con-

ference on, pages 47–54. IEEE.

Svetlik, M., Leonetti, M., Sinapov, J., Shah, R., Walker,

N., and Stone, P. (2016). Automatic curriculum graph

generation for reinforcement learning agents.

Torrens, P. M., Nara, A., Li, X., Zhu, H., Grifﬁn, W. A., and

Brown, S. B. (2012). An extensible simulation en-

vironment and movement metrics for testing walking

behavior in agent-based models. Computers, Environ-

ment and Urban Systems, 36(1):1–17.

Yamashita, T., Soeda, S., and Noda, I. (2009). Evacua-

tion planning assist system with network model-based

pedestrian simulator. In PRIMA. Springer.

Zhong, J., Cai, W., Luo, L., and Zhao, M. (2016). Learning

behavior patterns from video for agent-based crowd

modeling and simulation. Autonomous Agents and

Multi-Agent Systems, 30(5):990–1019.

Ziebart, B. D., Maas, A. L., Bagnell, J. A., and Dey,

A. K. (2008). Maximum entropy inverse reinforce-

ment learning. In AAAI, volume 8, pages 1433–1438.

Chicago, IL, USA.

CAMP-IRL Agents: Extracting Multiple Behavior Proﬁles for Pedestrian Simulation

223
