Addressing Industrial Needs with the Fulib Modeling Library

Albert Zündorf, Adrian Kunz and Christoph Eickhoff

Kassel University, Germany

Keywords:

Models, Model Transformations, Modeling Tools.

Abstract:

Fulib is a new lightweight modeling tool providing code generation and model transformations. Code generated

by Fulib does not need a Fulib runtime library. Fulib has been designed to be integrated into agile software

development processes. Fulib collaborates with versioning tools like Git. These features address practical

problems with modeling tools that frequently prevent their usage in industry.

1 INTRODUCTION

The International Conference on Model Transforma-

tion (ICMT) October 2019 in Eindhoven had a panel

discussion on “Is there a future for Model Transforma-

tion Languages?”. Basically, they answered this ques-

tion with “No!” and terminated the ICMT conference

series. The main argument was that model transforma-

tions were not able to gain industrial relevance. The

main reasons given by the panel were: 1) proprietary

libraries, 2) licence issues, 3) vendor lock-in to (im-

mature) university prototypes, 4) poor integration with

iterative software development approaches. There is

also the paper of Paige and Varro (Paige and Varró,

2012) that discusses similar insights.

Following that panel and reading (Paige and Varró,

2012), we recognized: “Well, these are exactly the

issues that forced us to stop working on Fujaba (Nickel

et al., 2000) and SDMLib (Zündorf et al., 2013) and

to come up with Fulib”. Actually, we have started to

work on Fulib in August 2018 and the ﬁrst ofﬁcial

release was in October 2019. Thus, this paper outlines

how our new lightweight modeling FUjaba Library

Fulib addresses the typical industrial concerns with

modeling tools.

2 NO FULIB RUNTIME LIBRARY

Within the model transformation community, the

Eclipse Modeling Framework (EMF) (Steinberg et al.,

2008) has become the de-facto standard for the im-

plementation of models. Besides being a common

standard for many modern modeling tools, EMF does

a great job in generating model implementations and

providing model management functionality like seri-

alization to XML, generic model viewers and editors,

etc. However, if your model e.g. has a class Order or

Product, then the generated Java classes will inherit

from the basic library class (interface) EObject. If

your model uses to-many associations, these will be

implemented using the library class EList. Thus, your

model code relies heavily on an EMF runtime library.

In order to use the generated model code within your

ﬁnal product you have to include the EMF runtime

library and thus you have to deal with the according

licence. Generally, the EMF tooling and especially the

EMF runtime library are pretty mature and ready for

industrial use and the Eclipse Public Licence is pretty

general. Still this triggers the industrial concerns raised

by the ICMT panel discussed in our introduction.

To avoid these industrial concerns, the Java classes

generated by Fulib do not require any runtime li-

brary. Fulib does not use a common superclass or

interface like EObject and our associations are im-

plemented with standard Java container classes (de-

fault ArrayList). Additional model functionalities like

bidirectional associations are generated into the Java

classes. Instead of runtime libraries, Fulib relies on

generated code and on generic reﬂection functionality

. Thus, you may use Fulib to generate (parts of) your

model and when you ship your product, you do not

ship any Fulib libraries or parts and there are no Fulib

licences involved.

Zündorf, A., Kunz, A. and Eickhoff, C.

Addressing Industrial Needs with the Fulib Modeling Library.

DOI: 10.5220/0010203501550162

In Proceedings of the 9th International Conference on Model-Driven Engineering and Software Development (MODELSWARD 2021), pages 155-162

ISBN: 978-989-758-487-9

155

1 p u b l i c c l a s s GenModel implem ents Cla s s M o d e l D e c o r a t o r {

2 @Ov erride

3 p u b l i c v o i d d e c o r a t e ( Cl a s s Model M a n a g er mm) {

4 C l a z z sh o p = mm. h a v e C l a s s ( " Shop " , c −> {

5 c . a t t r i b u t e ( " name " , STRING ) ;

6 } ) ;

7 C l a z z c u s t o m e r = mm. h a v e C l a s s ( " Cu s tom e r " , c −> {

8 c . a t t r i b u t e ( " c u s t o m e r I d " , STRING ) ;

9 c . a t t r i b u t e ( " name " , STRING ) ;

10 c . a t t r i b u t e ( " a d d r e s s " , STRING ) ;

11 } ) ;

12 C l a z z p r o d u c t = mm. h a v e C l a s s ( " P r o d u c t " , c −> {

13 c . a t t r i b u t e ( " p r o d u c t I d " , STRING ) ;

14 c . a t t r i b u t e ( " d e s c r i p t i o n " , STRING ) ;

15 c . a t t r i b u t e ( " p r i c e " , DOUBLE ) ;

16 } ) ;

17 C l a z z o r d e r = mm. h a v e C l a s s ( " O r d e r " , c −> {

18 c . a t t r i b u t e ( " o r d e r I d " , STRING ) ;

19 c . a t t r i b u t e ( " d a t e " , STRING ) ;

20 } ) ;

21 mm. a s s o c i a t e ( shop , " c u s t o m e r s " , MANY, c u s t o m e r , " sh o p " , ONE ) ;

22 mm. a s s o c i a t e ( shop , " p r o d u c t s " , MANY, p r o d u c t , " sh o p " , ONE ) ;

23 mm. a s s o c i a t e ( cu s t om e r , " o r d e r s " , MANY, o r d e r , " c u s t o m e r " , ONE ) ;

24 mm. a s s o c i a t e ( o r d e r , " p r o d u c t s " , MANY, p r o d u c t , " o r d e r s " , MANY) ;

25 }

26 }

Listing 1: Fulib class model e.g. in src/gen/java/theModelPackage/GenModel.java.

1 p l u g i n s {

2 i d ’ j a v a ’

3 i d ’ o r g . F u l i b . F u l i b G r a d l e ’

4 v e r s i o n ’ 0 . 2 . 0 ’

5 }

Listing 2: Including the Fulib Gradle Plugin into

build.gradle.

3 FULIB LIGHTWEIGHT

TOOLING

A major problem with many modeling tools is, that

you have to learn some complex diagram tool, e.g.

MagicDraw (mag, 2020) or Microsoft Visio or Enter-

prise Architect (ent, 2020) or UML-Lab (UML, 2020)

or others. Recently, many textual modeling languages

have popped up e.g. based on xCore (xCo, 2020) or

(Rumpe and Hölldobler, 2017). These textual model-

ing languages still require you to use some complex

tool and to learn some new language. To avoid this,

Fulib encodes your class model in Java using a small

API, cf. Listing 1. Fulib then renders your class model

as UML diagram for you, cf. Figure 1. To be hon-

est, to use Fulib, you still have to learn the Fulib API.

However, you may stick with your favorite Integrated

Development Environment (IDE) and your IDE will

provide you with comfortable editing support like com-

pletion and compile time checks.

To use Fulib you may download the Fulib libraries

and add them to your classpath. However, we also

provide a Gradle plugin that does this job for you (a

Maven plugin is current work), cf. Listing 2.

The FulibGradle plugin provides a generateSce-

narioSource task. This task looks for ClassMod-

elDecorators within a dedicated src/gen/java/... sub-

directory and compiles and runs these classes. This

generates source code within your src/main/java/... di-

rectory. The generateScenarioSource task runs before

your usual compile and test tasks.

4 FULIB INTEGRATION WITH

ITERATIVE SOFTWARE

DEVELOPMENT

As discussed, our FulibGradle plugins keeps your

model and your source code in sync, on each gra-

dle build. This addresses the next main problem with

modeling tools in industrial projects: their poor inte-

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

156

1 p u b l i c c l a s s M o d e l s w a r d S t o r y T e s t {

2 @Test

3 p u b l i c v o i d t e s t P a y P a l ( ) {

4 Shop uks Sh op = new Shop ( ) . setName ( " UKSShop " ) ;

5 Cus t omer a l i c e = new Cu s t ome r ( ) . s e t C u s t o m e r I d ( " a l i c e 1 " )

6 . setName ( " A l i c e " ) . s e t A d d r e s s ( " W ond er land 1 " ) . s e t S h o p ( uksShop ) ;

7 Cus t omer bob = new Cus t o mer ( ) . s e t C u s t o m e r I d ( " bob2 " ) . setName ( " Bob " )

8 . s e t A d d r e s s ( " W ond er land 1 " ) . s e t S h o p ( uksShop ) ;

9 P r o d u c t t s h i r t = new P r o d u c t ( ) . s e t P r o d u c t I d ( " t 4 2 " ) . s e t P r i c e ( 1 3 . 3 7 )

10 . s e t D e s c r i p t i o n ( "UKS T s h i r t " ) . s e t S h o p ( uks Sh op ) ;

11 P r o d u c t mug = new P r o d u c t ( ) . s e t P r o d u c t I d ( "m43 " ) . s e t P r i c e ( 4 . 2 0 )

12 . s e t D e s c r i p t i o n ( "UKS C o f f e e Mug" ) . s e t S h o p ( uksShop ) ;

13 Or de r o44 = new O r de r ( ) . s e t O r d e r I d ( " o44 " ) . s e t C u s t o m e r ( a l i c e )

14 . s e t D a t e ( " 2 0 2 0 . 0 9 . 0 2 " ) . w i t h P r o d u c t s ( t s h i r t , mug ) ;

16 u ksShop . p r o c e s s ( o44 ) ;

18 F u l i b T o o l s . o b j e c t D i a g r a m s ( )

19 . dumpSVG ( " p a p e r / p a y p a l O b j e c t s . s vg " , uksShop ) ;

20 a s s e r t T h a t ( o44 . g e t S t a t e ( ) , i s ( " pa y ed " ) ) ;

21 }

22 }

Listing 3: Test Driven Development.

Shop

name :String

Customer

customerId :String

name :String

address :String

shop

customers *

Product

productId :String

description :String

price :double

shop

products *

Order

orderId :String

date :String

customer

orders *

products *

orders *

Figure 1: Example Class Diagram.

gration into iterative software development processes.

Frequently, modelling tools are used only in initial

project phases and as soon as you start to add your

business logic, code generation is detached and your

code develops independent from the model.

If you use an agile or iterative software develop-

ment approach you may follow the ideas of Test Driven

Design. Therefore, you start writing a test that sets up

a scenario for a certain functionality and then invokes

the corresponding operation and validates that the de-

sired effects have been achieved. We call such a test

a scenario test, cf. (Zündorf et al., 1999). Such sce-

nario tests may also be related to use cases. A typical

scenario test will set up some example object model

and then invoke some business logic operation and

than validate the results. Fulib has no generic model

editor to set up an example object model. Actually, we

have a simple textual scenario language you could use

(cf. www.fulib.org). This textual scenario language

may e.g. be used to discuss examples with customers

or users during requirements engineering. However,

this paper focuses on the design and implementation

phase. Thus during design and implementation, you

may just code the creation of example object models

based on the class model implementation generated by

Fulib, cf. Listing 3. Building a model via Java code

leverages code completion and editing support from

your integrated development environment. Note also

that our set-methods return the underlying object and

thus they may be used in a ‘ﬂuid’ code style.

To visualize the created object model you may

use the FulibTools library, e.g. Line 19 of Listing 3

dumps an object diagram of our model, cf. Figure 2.

As you use this within your tests only, it will not ship

with your product, thus still no licence issues. We use

these object diagram dumps a lot during debugging,

too.

Note, our test already contains a business logic

method (Shop.process(order)), cf. Line 16 of Listing 3

and see Listing 4. Following the test driven develop-

Addressing Industrial Needs with the Fulib Modeling Library

157

uKSShop :Shop

name = "UKSShop"

alice :Customer

address = "Wonderland 1"

customerId = "alice1"

name = "Alice"

customers

shop

bob :Customer

address = "Wonderland 1"

customerId = "bob2"

name = "Bob"

customers

shop

p :Product

description = "Great UKS Tshirt"

price = 13.37

productId = "t42"

products

shop

p1 :Product

description = "UKS Coffee Mug"

price = 4.2

productId = "m43"

products

shop

o :Order

date = "2020.09.02"

orderId = "o44"

state = "initial"

orders

customer

orders

products

orders

products

Figure 2: Example Object Diagram.

ment idea, we ﬁrst wrote the method call in Line 16

of Listing 3 and the assert statement in Line20. Then

we used auto repair features and code completion of

our IDE to create method Shop.process(order) and the

state attribute within our Order class. Then we used

gradle to compile and run our test. This gradle build

did another code generation. During this code genera-

tion, the Fulib code generator recognized the manual

extensions of our model classes and merged them with

the generated parts, seamlessly.

While you could / should add things like the state

attribute to the model, sometimes you do not consider

such helper elements as relevant for the model or you

are focusing on your algorithms and do not want to

bother with the modeling level. Or you just follow

the test driven development approach and want to start

with the usage of a feature before adding it to your

system (or model). Actually, we might add the state

attribute to our model after introducing it to our code

via IDE. Then, the Fulib code generator will identify

the manually added implementation and replace it with

the (similar) generated implementation. To achieve

this, Fulib uses a Java parser to identify attribute and

method declarations and then these declarations are

related to model elements via their names. After all,

code and model would by in sync and the manually

added attribute becomes part of the model, too.

As manual code extension is frequently required,

there are many sophisticated techniques that allow

developers to protect their code modiﬁcations and ex-

tensions from being overridden by some code gener-

ator, e.g. special code regions marked with pseudo

comments or adaption of generated code via sub and

super classes (e.g. in (Rumpe and Hölldobler, 2017)

or generation gap pattern by Fowler (Fowler, 2010)).

To make this even simpler and more seamless, Fulib

identiﬁes which code elements (attributes / methods,

etc.) stem from or correspond to a model element (Ful,

2020b). Such code fragments will be overwritten on

each project build. Manual changes to such code frag-

ments will be lost. (You may protect such elements

with a “// no Fulib” comment.) Any code fragment

that has been added manually, e.g. a helper (state)

attribute or business logic method (process()) remains

untouched and is preserved during each project build.

Thus, if developers extend the generated code with at-

tributes or methods, they do not need to bother with the

Fulib model or code generation. In other approaches,

the extra effort for code preservation frequently causes

developers to detach the model from the code i.e. re-

move the automatic code generation from the build

process or just never run the code generation again.

With Fulib, the code generation is such seamless that

you may keep the Fulib Gradle plugin included.

When breaking down our example

Shop.process(order) method, cf. Listing 4, we

recognized that we need an email address for our

customers. This time we just extend the class model

code from Listing 1 and run gradle build. This adds

the email attribute to our model and to the generated

code, still well integrated with the manual extensions.

A great functionality of integrated development

environments are refactorings, e.g. renaming a class

or an attribute together with all its usages. Most code

generators have difﬁculties when you do e.g. such a

renaming on generated code. As an example let us

rename our Shop class into a Store. Using your IDE

this will also update your test code and other usages

of the old Shop class. If we run a gradle build after

renaming Shop to Store, the Fulib code generator will

regenerate the Shop class. This will also regenerate

the association between Shop and e.g. Product. This

results in numerous compile errors e.g. between the

regenerated method Product.setShop(Shop) and the old

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

158

1 p u b l i c c l a s s Shop {

2 p u b l i c v o i d p r o c e s s ( Or d e r o r d e r ) {

3 i f ( o r d e r . g e t S t a t e ( ) . e q u a l s ( " i n i t i a l " ) ) {

4 r e q u e s t P a y m e n t ( o r d e r ) ;

5 }

6 e l s e i f ( o r d e r . g e t S t a t e ( ) . e q u a l s ( " pa y ed " ) ) {

7 d e l i v e r ( o r d e r ) ;

8 }

9 }

11 p r i v a t e vo id r e q u e s t P a y m e n t ( O r d e r o r d e r ) {

12 . . .

13 }

15 p r i v a t e vo id d e l i v e r ( O r d er o r d e r ) {

16 . . .

17 }

18 . . .

19 }

Listing 4: Business Logic Development.

refactored method Product.setShop(Store) that both

access the Product.shop attribute which the Fulib code

generator has changed back to type Shop.

Luckily, the Fulib code generator is able to repair

this mess, easily. We just rename Shop to Store in our

class model code (Listing 1) and run the gradle build

again. The Fulib code generator keeps a copy of the

class model that has been used during the last code

generation. On each new code generation, the Fulib

code generator compares the old class model and the

new class model. Thus Fulib recognizes that the Shop

class is gone and that the corresponding associations

are now referencing the new Store class. Thus, Fulib

removes all code generated for the old Shop and the old

associations. Then, the new elements are generated.

During the generation of new elements, Fulib merges

the new code with existing code (from the refactoring).

Thus, once we have completed the renaming of Shop to

Store in our model, Fulib repairs all code and the code

compiles and works, again. A disciplined developer

might do the renaming in code and model directly and

no problem occurs. If you forget about the model, you

will recognize the problem on the next gradle build,

repair the model, and you are good, too.

In the best of all worlds, such a renaming would

work on code and model, simultaneously. As far as

we know, UML-Lab (UML, 2020) is the only mod-

eling tool that supports this. To achieve this, your

modeling tool needs to be tightly integrated with your

IDE (which provides the code refactoring function-

ality including manually created code that is not ad-

dressed by your modeling tool.) However, Fulib is just

a lightweight tool that is integrated into your develop-

ment workﬂow via gradle and that works with any IDE.

Thus, you have to do both renamings, manually. At

least Fulib deals with the problem that you may forget

to adapt the model, directly. This works not only for

the renaming of classes but also for the renaming of

attributes and associations. We have used Fulib in a

Bachelor course on object oriented modeling in winter

term 2019/2020 at Kassel University with about 80

students with great success and no student removed

the FulibGradle plugin from his or her project. We

use it a lot in our research projects, again with very

good experiences. Code generation and manual code

extension works great with Fulib.

5 FULIB GIT INTEGRATION

Another frequent reason for decoupling the model

from your code is when the model is not under Git

or version control together with your code. EMF class

models are usually stored in ECore ﬁles using XML

format. XML based ﬁles have serious problems when

e.g. a Git version control tool is used and merge con-

ﬂicts occur. Fulib uses a Java based API to create a

class model and to generate the implementation code,

cf. Listing 1. This class model description (code) is

compiled and executed by the FulibGradle plugin dur-

ing the code generation phase and code is generated

within the src/main/java/... directory of your project.

As developers may extend the generated code man-

ually, we recommend to put the whole src directory

(including the generated code) under Git version con-

trol. As the class model description (code) is now

Addressing Industrial Needs with the Fulib Modeling Library

159

1 . . .

2 Cu s t o m e r T a b l e c u s t o m e r T a b l e = new C u s t o m e r T a b l e ( a l i c e ) ;

3 O r d e r T a b l e o r d e r T a b l e = c u s t o m e r T a b l e . e x p a n d O r d e r s ( " O rd e r " ) ;

4 o r d e r T a b l e . f i l t e r ( o r d e r −> o r d e r . g e t S t a t e ( ) . e q u a l s ( " i n i t i a l " ) ) ;

5 P r o d u c t T a b l e p r o d u c t T a b l e = o r d e r T a b l e . e x p a n d P r o d u c t s ( " P r o d u c t " ) ;

6 d o u b l e T a b l e p r i c e T a b l e = p r o d u c t T a b l e . e x p a n d P r i c e ( " P r i c e " ) ;

7 Syste m . o u t . p r i n t l n ( p r o d u c t T a b l e ) ;

8 Syste m . o u t . p r i n t l n ( " T o t a l : " + p r i c e T a b l e . sum ( ) ) ;

9 /

p r i n t s :

11 | −−− | −−− | −−− | −−− |

12 | a l i c e 1 A l i c e Wo nd erl an d 1 | o44 2 0 2 0 . 0 9 . 0 2 | t 4 2 UKS T s h i r t | 1 3 . 3 7 |

13 | a l i c e 1 A l i c e Wo nd erl an d 1 | o44 2 0 2 0 . 0 9 . 0 2 | m43 UKS C o f f e e Mug | 4 . 2 |

14 T o t a l : 1 7 . 5 7

16 p r o d u c t T a b l e . t o S e t ( ) . f o r E a c h ( p r o d u c t −> uksSh op . r e t r i e v e ( p r o d u c t ) ) ;

17 . . .

Listing 5: Fulib generated query API.

versioned together with all other code of your project,

you may use all Git features for collaborative software

development on your model and your code together.

You may e.g. use multiple feature branches to develop

different features independently. For each feature you

may extend and adapt the model description code and

the other code parts of your system and then you merge

the feature into your main development branch. Your

model description code will merge similar to all other

code.

6 MODEL QUERIES AND

TRANSFORMATIONS

In addition to code generation for class models, sup-

port for model queries and transformations is another

major contribution of modeling tools and frameworks.

Again, 1) proprietary libraries, 2) licence issues, 3)

vendor lock-in to (immature) university prototypes,

and 4) poor integration with iterative software devel-

opment are major concerns. In addition, a proprietary

query and transformation language adds to the com-

plexity of the overall development process.

Fulib provides different approaches in order to

deal with these problems. First, on demand, the

Fulib.tablesGenerator generates model speciﬁc query

operations. Listing 5 shows the usage of such gen-

erated tables based on the object structure created in

Listing 3.

For each model class like Customer, Fulib gen-

erates a corresponding table class, in this case Cus-

tomerTable. These table classes provide expand opera-

tions for each attached association e.g. expandOrders,

cf. Line 3 of Listing 5. Operation expandOrders cre-

ates a new wrapper object of type OrderTable that

refers to the original underlying table data. Operation

expandOrders takes each row of the original table (in

our case one row with one column with content alice1)

and computes the set of all objects reachable via an

orders link (in our case e.g. order o44). For each

combination of source and target object a new row is

added to the underlying table data. (The old rows are

removed.) The ﬁlter operation in line 4 of Listing 5

iterates through all rows of the underlying table and

applies the passed lambda expression on the element

of the current column (in our case on the order ele-

ment). In our example this evaluates to true and we

keep our single row. Now line 5 expands the current

order(s) via its (their) products link. This results in two

rows consisting of a copy of the old row extended by

one of the two ordered products. Line 6 adds a price

column for each product. Line 7 prints the resulting

table. This has been added to Listing 5 as comment in

lines 10 to 13. Line 8 calls sum on the price column

of our table and prints the result, cf. Line 14. If you

want to do not only a model query but also a model

transformation you may e.g run a lambda expression

on each element of a certain column, cf. line 16 of

Listing 5. Alternatively, you might iterate through all

rows of the underlying table. This allows you to access

e.g. customer, order, and product together.

The code generated for these table operations is

again self contained and does not need any runtime

library. The code only relies on the typical get opera-

tions. Thus, the generated table code works not only

with model classes generated by Fulib, but also with

model classes from other frameworks (e.g. EMF) or

manually crafted model classes.

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

160

1 . . .

2 P a t h T a b l e t a b l e = new P a t h T a b l e ( " Cu s tom e r " , a l i c e ) ;

3 t a b l e . e x p and ( " C u stom e r " , Cu s tom e r . PROPERTY_orders , " O r d e r " ) ;

4 t a b l e . f i l t e r ( " O rd e r " , o r d e r − >(( O rd e r ) o r d e r ) . g e t S t a t e ( ) . e q u a l s ( " i n i t i a l " ) ) ;

5 t a b l e = t a b l e . e x pand ( " Ord e r " , Or d e r . PROPERTY_products , " P r o d u c t " ) ;

6 t a b l e . e x p and ( " P r o d u c t " , P r o d u c t . PROPERTY_price , " P r i c e " ) ;

7 Syste m . o u t . p r i n t l n ( t a b l e ) ;

8 Syste m . o u t . p r i n t l n ( " T o t a l : " + t a b l e . sum ( " P r i c e " ) ) ;

9 /

p r i n t s :

11 | −−− | −−− | −−− | −−− |

12 | a l i c e 1 A l i c e Wo nd erl an d 1 | o44 2 0 2 0 . 0 9 . 0 2 | t 4 2 UKS T s h i r t | 1 3 . 3 7 |

13 | a l i c e 1 A l i c e Wo nd erl an d 1 | o44 2 0 2 0 . 0 9 . 0 2 | m43 UKS C o f f e e Mug | 4 . 2 |

14 T o t a l : 1 7 . 5 7

16 t a b l e . t o S e t ( " P r o d u c t " ) . f o r E a c h ( p −> uksSho p . r e t r i e v e ( ( P r o d u c t ) p ) ) ;

17 . . .

Listing 6: FulibTables runtime library query API.

1 . . .

2 P a t t e r n B u i l d e r pb = F u l i b T a b l e s . p a t t e r n B u i l d e r ( ) ;

3 P a t t e r n O b j e c t c u s t o m e r = pb . b u i l d P a t t e r n O b j e c t ( " c u s t o m e r " ) ;

4 P a t t e r n O b j e c t o r d e r = pb . b u i l d P a t t e r n O b j e c t ( " o r d e r " ) ;

5 P a t t e r n O b j e c t s t a t e = pb . b u i l d P a t t e r n O b j e c t ( " s t a t e " ) ;

6 P a t t e r n O b j e c t p r o d u c t = pb . b u i l d P a t t e r n O b j e c t ( " p r o d u c t " ) ;

7 P a t t e r n O b j e c t p r i c e = pb . b u i l d P a t t e r n O b j e c t ( " p r i c e " ) ;

8 pb . b u i l d P a t t e r n L i n k ( c u s t o m er , O r d e r . PROPERTY_customer ,

9 Cus t omer . PROPERTY_orders , o r d e r ) ;

10 pb . b u i l d P a t t e r n L i n k ( o r d e r , n u l l , " s t a t e " , s t a t e ) ;

11 pb . b u i l d A t t r i b u t e C o n s t r a i n t ( s t a t e , s t r −> s t r . e q u a l s ( " i n i t i a l " ) ) ;

12 pb . b u i l d P a t t e r n L i n k ( o r d e r , P r o d u c t . PROPERTY_orders ,

13 Or de r . PROPERTY_products , p r o d u c t ) ;

14 pb . b u i l d P a t t e r n L i n k ( p r o d u c t , " p r i c e " , p r i c e ) ;

15 P a t t e r n M a t c h e r m a t c h e r = F u l i b T a b l e s . m a t c h e r ( pb . g e t P a t t e r n ( ) ) ;

16 O b j e c t T a b l e t a b l e = m a t c h e r . match ( " c u s t o m e r " , a l i c e ) ;

17 Syste m . o u t . p r i n t l n ( t a b l e ) ;

18 /

20 | −−− | −−− | −−− | −−− | −−− |

21 | a l i c e 1 A l i c e | o44 2 0 2 0 . 0 9 . 0 2 | i n i t i a l | t 4 2 UKS T s h i r t | 1 3 . 3 7

22 | a l i c e 1 A l i c e | o44 2 0 2 0 . 0 9 . 0 2 | i n i t i a l | m43 UKS C o f f e e Mug | 4 . 2

Listing 7: FulibTables query pattern.

However, code generation for this model speciﬁc table

code relies on the existence of a Fulib class model (as

created e.g. in Listing 1). If you have created your

model (code) in a different way, you could reverse

engineer the class model for Fulib and then use only

the table generator. If you do not want to generate the

table code, Fulib also provides a generic PathTable

within a small runtime library (i.e. FulibTables).

Listing 6 shows the same query as Listing 5, but

this time using our generic PathTable. Thus, in List-

ing 6 we need to provide the names of table columns

and associations and attributes as string parameters.

This has three drawbacks: ﬁrst, we loose static type

checking, you may accidentally ask a Customer ob-

ject to expand via link "xy" which is not possible as

the class Customer does not have such an associa-

tion. Correlated with missing type information is the

lack of auto completion support in your IDE. Finally,

PathTables rely on Java reﬂection. This is a little bit

slower than the generated solution. Again PathTable

Addressing Industrial Needs with the Fulib Modeling Library

161

works with Fulib models, EMF models, manually

crafted models, etc.

In addition to PathTables our FulibTables runtime

library also provides more general model queries via

object patterns, cf. Listing 7. These patterns are in-

spired by graph transformations, cf. (Zündorf et al.,

2017). Note, patterns are still compatible to all mod-

els that stick to the Java Beans conventions. Thus,

you may e.g. use our patterns on EMF models or on

manually crafted models.

In (Eickhoff et al., 2019) we also provide EMFeR

a generic model checking tool based on model queries

and model transformations. EMFeR works perfectly

well with Fulib queries and transformations, too.

7 SUMMARY

The Fulib modeling library tries to address typical

concerns and requirements of industrial software de-

velopers. You get a lot of Fulib functionality without

the need of a runtime library. Code generation is in-

tegrated into your Gradle build. Fulib supports itera-

tive software development as good as we can. Fulib

deals with Git version management reasonably well.

Model speciﬁc query functionality may be generated

which again avoids runtime libraries and licence is-

sues. Generic query functionality is provided within

a small runtime library (MIT licence). The generic

query functionality is agnostic to different model im-

plementations. It works not only for Fulib generated

code but also for code generated by other tools or for

manually crafted code. We have evaluated the Fulib

library within a modeling course with about 80 partici-

pants at Kassel University in winter term 2019/2020

and within several research projects at our department.

We are now ready to approach industrial partners to get

their feedback. We have already demonstrated Fulib

within a talk to local industry at the Java User Group

Hessia, Germany, in August 2020 (Ful, 2020a).

REFERENCES

(2020). Enterprise architect. https://www.sparxsystems.de/

uml/neweditions/. Accessed: 2020-09-02.

(2020a). Fulib - macht java code aus klassendi-

agrammen. https://www.youtube.com/watch?v=

eamdeXCxysk. Accessed: 2020-09-02.

(2020b). Fulib class org.fulib.generator. https://github.com/

fujaba/fulib. Accessed: 2020-02-12.

(2020). Magic draw. https://www.nomagic.com/products/

magicdraw. Accessed: 2020-09-02.

(2020). Uml-lab, yatta solutions gmbh. https://www.uml-lab.

com/de/uml-lab/. Accessed: 2020-09-02.

(2020). xcore. https://wiki.eclipse.org/Xcore. Accessed:

2020-09-02.

Eickhoff, C., Lange, M., Raesch, S.-L., and Zündorf, A.

(2019). Emfer: Model checking for object oriented

(emf) models. In MODELSWARD, pages 511–518.

Fowler, M. (2010). Domain-speciﬁc languages. Pearson

Education.

Nickel, U., Niere, J., and Zündorf, A. (2000). The fujaba

environment. In Proceedings of the 22nd international

conference on Software engineering, pages 742–745.

Paige, R. F. and Varró, D. (2012). Lessons learned from

building model-driven development tools. Software &

Systems Modeling, 11(4):527–539.

Rumpe, B. and Hölldobler, K. (2017). Monticore 5 language

workbench. edition 2017.

Steinberg, D., Budinsky, F., Merks, E., and Paternostro, M.

(2008). EMF: eclipse modeling framework. Pearson

Education.

Zündorf, A., Gebauer, D., and Reichmann, C. (2017). Table

graphs. In International Conference on Graph Trans-

formation, pages 221–230. Springer.

Zündorf, A., George, T., Lindel, S., and Norbisrath, U.

(2013). Story driven modeling libary (sdmlib): an

inline dsl for modeling and model transformations, the

petrinet-statechart case. Sixth Transformation Tool

Contest (TTC 2013), ser. EPTCS.

Zündorf, A., Schürr, A., and Winter, A. J. (1999). Story

driven modeling. Univ.-Gesamthochsch. Paderborn,

Fachbereich Mathematik-Informatik.

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

162
