Garment Detection in Catwalk Videos

Qi Dang

1 a

, Heydar Maboudi Afkham

2 b

and Oskar Juhlin

1 c

Department of Computer and Systems Sciences, Stockholm University, Stockholm, Sweden

Sarvai, Stockholm, Sweden

Keywords:

Garment Detection, Fashion, Video Analysis, Computer Vision, Application.

Abstract:

Most computer vision applications in the commercial scene lack a large scale and properly annotated dataset.

The solution to these applications relies on already published code and knowledge transfer from existing

computer vision datasets. In most cases, these applications sacriﬁce proper benchmarking of the solution

and rely on the performance of used methods from their respective papers. In this paper, we are focusing

on how we can use the existing code base and the datasets in computer vision to address a hypothetical

application of detecting garments in the catwalk videos. We proposed a combination of methods that allows

us to localize garments in complex scenery by only training models on public datasets. To understand which

method performs best for our application, we have designed a relative-benchmark framework that requires

very little manual annotation to work.

1 INTRODUCTION

The methodology of Computer Vision (CV) appli-

cations is usually inspired by methodologies created

in state-of-the-art research, which usually revolves

around introducing new methodologies to solve tasks

represented by different datasets (Lin et al., 2014;

Zheng et al., 2018; Ge et al., 2019). As we have ob-

served, a majority of CV applications tend to use the

code-base from research with little to none modiﬁca-

tions. A popular example of such a practice is us-

ing a version of YOLO object detector (Redmon and

Farhadi, 2018) with unmodiﬁed weights as a part of

a CV application. In most cases, these applications

are at a much smaller scale compared to current CV

research tasks and come with far less supporting data

and annotations. In this paper, we have investigated

how the existing code-base and publicly available

datasets for CV research can be used for addressing

more custom applications that can not be necessarily

formulated similar to the research problems. Such ap-

plications usually arise in non-academic settings and

their key characteristics are lack of a large dataset

and proper annotations. Addressing such applications

may require different training strategies compared to

what is normally done for similar problems in the re-

https://orcid.org/0000-0002-3442-6910

https://orcid.org/0000-0001-5118-2172

https://orcid.org/0000-0002-5308-0150

search context. We have also investigated a bench-

marking framework to compare the performance of

different models on the target dataset, without signif-

icant annotation requirements.

As a hypothetical application, we have chosen to

extract garment information from fashion models in

catwalk videos. We have chosen this problem because

to solve it, we need to investigate both object and gar-

ment detection methodologies and determine if their

assumptions are correct for our application. For ex-

ample, when focusing on the task of garment detec-

tion, the frames from the video used in this work tend

to look very different from the images found in re-

search datasets (Zheng et al., 2018; Liu et al., 2016b).

Because of these differences, as shown in Fig. 1, we

require a different approach to train the models.

For this problem, we have used a 10 minutes cat-

walk video as the benchmarking dataset and only used

COCO2014 (Lin et al., 2014) and Modanet (Zheng

et al., 2018) datasets for the training of the models.

We utilized a multi-staged strategy (Fig. 2) by (a)

splitting the video into camera shots, (b) detecting

the people that are present in the video, (c) tracking

all the people in each shot and generating a track for

each person, (d) ﬁltering these tracks to obtain a se-

ries of candidates for the fashion model in the scene,

and (e) generating garment proposals for the ﬁltered

tracks. With this strategy, we are able to use a va-

riety of different methods to address the problem in

Dang, Q., Afkham, H. and Juhlin, O.

Garment Detection in Catwalk Videos.

DOI: 10.5220/0010192804710479

In Proceedings of the 10th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2021), pages 471-479

ISBN: 978-989-758-486-2

471

(a) (b) (c) (d) (e)

Figure 1: Fashion datasets comparison. (a) and (b) originate from a fashion catwalk video. Such videos have two typical

patterns. First, the fashion models are usually in the center, although they vary in size. Second, there are usually audiences

along the side. (c) is from Modanet dataset. In images from Modanet dataset, there is always one person in the center, and

most people are of similar size. (d) and (e) are from DeepFashion dataset (Liu et al., 2016b). There is either a person or a

single garment in each image from the DeepFashion dataset.

each stage. To compare the accuracy of these methods

with respect to the catwalk video, we also developed

a benchmarking framework on this data, without the

need for detailed annotations.

The contributions of this paper are, (a) a frame-

work for combining the existing code base to solve

the problem of garment detection in catwalk videos,

and (b) a relative-benchmarking framework to com-

pare the performance of different method combina-

tions without the need for detailed annotations.

The remaining parts are structured as follows. We

discuss related works of person detection and garment

detection in §2. In §3, the details of the method-

ology are discussed . In §4, we propose a relative-

benchmarking framework for the application and dis-

cuss the results. In §5, we conclude the paper and

discuss the novelty and the limitations of our work.

2 RELATED WORK

Because of the nature of our application, we divide the

study of the related work in two sections. In §2.1, we

list some of the more recent object detection methods

and their properties with respect to our application. In

§2.2, we look into existing research on garment detec-

tion and discuss what needs to be changed to enable

them in our application.

2.1 Person/Object Detection

Modern object detectors consist of two parts i.e. fea-

ture extraction networks and detection head. In this

context, the detection head usually determines the

type of detector. In one-stage detectors, the head di-

rectly detects the objects by using the output of the

feature map. In two-stage detectors, the head ﬁrst

creates several proposals for the objects and then ver-

iﬁes them individually. This veriﬁcation step usu-

ally makes two-stage detectors slower than one-stage

detectors, but it enables them to have better perfor-

mance.

The recent and most inﬂuential one-stage detec-

tors are YOLO (Redmon et al., 2016), SSD (Liu et al.,

2016a), CenterNet (Zhou et al., 2019). The recent and

most inﬂuential two-stage detectors are Faster RCNN

(Ren et al., 2015) and Mask RCNN (He et al., 2017).

Since all these detectors can produce decent per-

son detections in images and videos, we used them

in our experiments without any modiﬁcations. Here,

we focus on their performance in the task of person

detection in catwalk videos.

2.2 Garment Detection

During the past ﬁve years, a small number of large

scale datasets with garment annotations have been re-

leased, i.e., DeepFahion (Liu et al., 2016b), Deep-

Fashion2 (Ge et al., 2019) and Modanet. We focus on

the Modanet dataset since its content is more similar

to our target dataset, than the other datasets. How-

ever, a drawback in Modanet is that each image only

contains one person, who is posing to show the outﬁt.

The person is mostly shown in full-body in the mid-

dle of the image. Furthermore, it has little variation in

size and pose of the fashion models and the garments.

To enable garment detection, most researchers

have applied different object detectors to these

datasets. Kucer and Murray (Kucer and Murray,

2019) trained Mask R-CNN (He et al., 2017) detector

on the Modanet dataset and used it for street to shop

image retrieval. Cychnerski et al. (Cychnerski et al.,

2017) trained and tested SSD detector (Liu et al.,

2016a) on the DeepFashion dataset and built an at-

tribute detector conditioned on garments detector. Ge

et al. (Ge et al., 2019) built the DeepFashion2 bench-

mark and applied Mask R-CNN (He et al., 2017) on

the benchmark. Sidnev et al. (Sidnev et al., 2019)

ICPRAM 2021 - 10th International Conference on Pattern Recognition Applications and Methods

472

applied CenterNet (Zhou et al., 2019) on DeepFash-

ion2 benchmark. Zheng et al. created the Modanet

dataset and applied Faster R-CNN, SSD, and Yolo as

the benchmark.

However, previous research does not address how

these methods can be modiﬁed to overcome the draw-

backs of the Modanet dataset to detect garments in a

dataset with much higher visual complexity, such as

catwalk videos. Such videos raise several challenges:

(a) the garments in catwalk videos have a greater scale

variation compared to available fashion datasets(Fig.

1), (b) there are usually more people in each frame,

and the scenes have a much higher visual complex-

ity, (c) the application should both detect the garments

and link them to person detections, (d) only the gar-

ments detected on fashion models are desired in the

application.

In the next section, we discuss how by condition-

ing the garment detector on person detection, we can

overcome these challenges.

3 METHODOLOGY

To successfully extract garment information from

fashion models in catwalk videos, we utilized a

methodology that has several steps. Its pipeline is

shown in Fig. 2.

Step 1, Shot Boundary Detection. Catwalk videos

usually consist of several different camera shots such

as close up garment shots and view of the runway as

a whole, in order to emphasize garments worn by the

fashion model (see Fig. 2). Transition between these

shots can severely affect the behavior of the tracking

algorithms. To avoid this, we used the shot boundary

detector TransNet (Sou

cek et al., 2019), which can

produce boundary conﬁdence scores for each frame.

The score predicts if a frame is a boundary of a video

shot. If the boundary conﬁdence score of a frame is

higher than a threshold, the frame is considered as

the boundary between two shots. If several frames

score above the threshold in a window of 25 frames,

we choose the frame with the highest score.

The following steps are done independently for

each shot. Here a video is decomposed into several

shots {S

,...,S

} with |S

| being the number of

frames in the shot S

Step 2, Person Detection. Our object of interest in

the catwalk videos is the fashion model which usually

has standing or walking pose, with no occlusion. In

most scenarios, this can be easily detected by off-the-

shelf object/person detectors.

Step 3, Person Tracking. Once the person detec-

tion boxes are generated for each frame in the shot,

we use an IoU (Intersection over Union) score based

tracker to generate tracklets across the shot. A track-

let is the trace of the bounding boxes of a speciﬁc

detected object across the frames of the shot. In

this setup, if the IoU score between two boxes from

two different frames is larger than a threshold (set to

0.5), they are considered to belong to the same track-

let. Since there might be missed detections, we al-

low gaps between the frames which is capped at a

maximum frames gap (25 frames). The missing de-

tections, inbetween the frames, are then interpolated

based on the boxes in the tracklet. Moreover, if a box

has a big IoU score with more than one box in the

next frame, only the one with the highest IoU score

is considered in the tracklet. Here, we formally de-

ﬁne a tracklet as the sequence T = (B

,...,B

where B

= {x

,i} with x

being

the coordinates of the box in the frame and i being the

frame index in the shot. With this deﬁnition we have,

m+1

[i] = B

[i] + 1 and |T | is the number of frames

in which the tracklet expands.

Step 4, Tracklet Classiﬁcation. Correctly identi-

fying fashion models from the audiences in catwalk

videos is not straight forward. Our methodology to

address this problem is based on the following ob-

servations: (i) in a catwalk video, the camera usu-

ally moves with the fashion models and keep them in

the center with no occlusion, (ii) the fashion models

walk on the runway and their pose is usually stand-

ing or walking, (iii) the fashion models are visually

similar to the persons appearing in Modanet dataset

in terms of pose and style, and (iv) the detections on

fashion models usually have a bigger overlap across

frames compared to the audience which results in

longer tracklets in each shot.

We categorise a tracklet T in shot S based on three

criteria: position in the frame, length (with respect to

the length of the shot), and visual assessment.

To deﬁne the position score, for each bounding

box B

in T , we ﬁrst deﬁne the normalized coordi-

nates of the bounding box in the frame as

norm

] + B

]

, (1)

with W

being the width of the frame. The position

score is then calculated as

(T,S)

|T |

∑

m=1

exp(

−(x

norm

− 0.5)

), (2)

with σ

being the scaling factor (set to 0.3). This

score gives a higher conﬁdence to the tracklets, with

most of their bounding boxes centered in the frame.

The length score is simply calculated as

(T,S)

|T |

|S|

, (3)

Garment Detection in Catwalk Videos

473

Figure 2: The ﬁgure describes our pipeline. Step 1 The video is split to shots by using TransNet(Sou

cek et al., 2019). Step 2

All individuals are detected in every frame of each shot. Step 3 A tracking algorithm is used to connect the person boxes and

generate tracks for all the detected persons. Step 4 The individuals in the tracks are classiﬁed as a fashion model or audience.

Step 5 Garment proposals are generated for the regions detected as fashion models.

and allows us to give higher conﬁdence to the track-

lets that span the longest within the shot.

We then introduce a custom CNN for their vi-

sual assessment. It is designed based on the obser-

vation (iii) regarding tracklets. We observed that the

fashion models in catwalk videos are more similar to

the people in the Modanet dataset and the audience

is more similar to the people in the COCO dataset.

Based on this, we have trained a CNN model to dis-

tinguish between the person detections found in the

two datasets. To train this classiﬁer, the person detec-

tions from both datasets were cropped, resized, and

labeled accordingly. Using this classiﬁer the visual

assessment score of the each tracklet is calculated as

(T,S)

= [

∑

B∈T

Φ(B)]/|T |, where Φ(B) is the visual

assessment score given to the bounding box B in the

tracklet T. Finally, the score given to the tracklet T in

the shot S is calculated as

Score

(T,S)

= P

(T,S)

× L

(T,S)

×V

(T,S)

. (4)

This score is then thresholded to select the tracklets

that correspond to fashion models. We have set this

threshold to be 0.1.

Step 5, Garment Detection. In our dataset, the size

of the bounding boxes appearing in a tracklet vary

signiﬁcantly. This results in the garments appearing

in a large variety of scales. To train a scale-invariant

garment detector, we conditioned the garment detec-

tion based on cropped bounding boxes in the track-

lets. To ensure that the bounding boxes cover as many

garments as possible, before cropping, the bounding

boxes were expanded by twenty percent and their as-

pect ratio was ﬁt to a pre-deﬁned ratio. The expanded

bounding boxes were then cropped and resized to a

ﬁxed size. A similar procedure was applied to the

Modanet dataset during the training of the garment

detection models.

4 EXPERIMENT SETUP AND

BENCHMARK

We have divided the experiment setup and the bench-

marks of this paper into three sections. In §4.1, we

describe the details and the setup of the modules used

in different sections of our application. In §4.2, we

describe the reference bounding boxes that are used

for the relative-benchmarking framework. In §4.3, we

focus on benchmarking the application on our target

catwalk video dataset.

4.1 Experiment Setup

The experiments focus on three aspects of our method

i.e. person detection, fashion model detection and

garment detection. In all experiments, we used the

PyTorch (Paszke et al., 2019) deep learning plat-

form. As mentioned in §3, we used TransNet (Sou

cek

et al., 2019) to divide the video into shots using

the pre-trained models from that study. For per-

son and garments detection we are considering Faster

RCNN

, YOLOv3

(Redmon and Farhadi, 2018),

SSD

(Liu et al., 2016a) and CenterNet

(Zhou et al.,

2019). We made small modiﬁcations in the pre-

processing section of these codes to allow image in-

puts with different sizes. The backbones of the Faster

RCNN, YOLOv3, SSD and CenterNet are Resnet-

101, Darknet-53, VGG-16 and DLA-34.

For person detection, we trained all mentioned

methods on the person class of the training set of

COCO 2014 dataset. Since the input image size can

highly affect the accuracy and computation time of

Implemented in torchvision

https://github.com/eriklindernoren/PyTorch-YOLOv3

https://github.com/amdegroot/ssd.pytorch

https://github.com/xingyizhou/CenterNet

ICPRAM 2021 - 10th International Conference on Pattern Recognition Applications and Methods

474

Table 1: (Left) A Comparison between performance of the trained person detectors on COCO2014 test set. In this experiment,

CenterNet showed the best accuracy for all resolutions. We were not able to make YOLOv3 and SSD converge when the

maximum image side was 1216 pixels. (Right) This table shows how the model trained on patches extracted using the

detectors trained in Left can robustly identify if a patch was extracted from the COCO2014 dataset or Modanet dataset. This

shows that there is a signiﬁcant difference between how people are visually presented in the two datasets.

Person detection AP

0.5

on COCO2014 (Test)

Max side resolution

Detectors 416 800 1216

Faster RCNN 0.701 0.791 0.812

YOLOv3 0.641 0.630 -

SSD 0.666 0.670 -

CenterNet 0.749 0.804 0.818

Visual Assessment Model

Max side resolution

Detectors 416 800 1216

Faster RCNN 0.976 0.98 0.985

YOLOv3 0.979 0.978 -

SSD 0.978 0.984 -

CenterNet 0.981 0.984 0.985

Table 2: Evaluation of garment detection models on the Modanet test data set. In this data set, all the detectors conditioned

on the person detection patches are outperformed by the detectors trained on the whole images.

Garment detection AP

0.5

on Modanet (Test)

Resolution 128:64, patch 256:128, patch 512:256, patch 800, whole

Faster RCNN 0.429 0.59 0.663 0.745

YOLOv3 0.299 0.435 0.524 0.651

SSD 0.534 0.658 0.7 0.778

CenterNet 0.543 0.641 0.706 0.824

each method, the images were resized to have the

maximum side of 416, 800, and 1216 pixels. With

this setup, we were able to train ten different person

detectors. In Table 1 (Left), we can see a compari-

son between the accuracy of these models based on

the AP@0.5 metric (0.5 IoU criteria). To utilize these

detectors in our application, we have used the COCO

2014 validation set to determine a threshold for each

detector. This threshold is set to allow the detector to

have a 90% recall of the person bounding boxes.

To correctly identify tracklets associated with the

fashion models, we trained a model to distinguish be-

tween person patches coming from COCO 2014 and

from Modanet datasets. For this experiment, since

Modanet does not have an annotated validation set,

we have randomly partitioned its training set into a

training set and a validation set (4:1 ratio), which were

placed alongside COCO 2014’s training and valida-

tion sets. We applied the trained person detectors to

all images. From COCO 2014, we considered detec-

tions that have an IoU of at least 0.8 with a ground

truth box and from Modanet, the biggest detection in

each image is considered. The selected detections are

then padded to ﬁt a 1:1 aspect ratio, cropped, and re-

sized to ﬁt 160×160 pixel patches. These patches are

then labeled according to their original dataset. To

distinguish between the patches, we trained a CNN

with ResNet50 backbone which is pre-trained on Im-

ageNet (Deng et al., 2009) and a 2-layer full convo-

lution head. Table 1 (Right) shows how this detector

can successfully distinguish between patches coming

from the two datasets. This indicates that there is a

signiﬁcant visual difference between how people are

presented in the two datasets.

For garment detection, our methodology signiﬁ-

cantly diverges from the state-of-the-art methods. To

adapt to the scale variations in the data, our methodol-

ogy focuses on conditioning the garment detection on

normalized person detection patches rather than de-

tecting them independently in the whole image. To

train this model, we have ﬁrst applied Faster RCNN

800 person detection model to the Modanet dataset.

From each image, we have selected the largest detec-

tion and padded it to have an aspect ratio of 2:1, ex-

panded by 20% (to make sure most of the garments

are included in the patch), and resized it to the de-

tector’s input size. Table 2 shows how this strategy

compares to whole image detection used in state-of-

the-art methods on Modanet’s test set. As can be seen,

with the current training setup, all these detectors are

outperformed by the whole image on this dataset.

With this setup, we have 10 different person detec-

tion models and 16 different garment detection mod-

els to engage the problem of garment detection in cat-

walk videos. It provides us with 160 different method

combinations. For the sake of being concise, we have

only focused on combining models with the same

model types and only focused on garment detection

trained on 512:256 patches and the whole image. We

have provided a comparison of all 160 conﬁgurations

in Fig. 4.

4.2 Reference Bounding Boxes

A proper benchmarking of detections in a catwalk

videos is challenging, without full annotation. At the

same time, full annotation is something that is usu-

ally missing from such applications. In our applica-

Garment Detection in Catwalk Videos

475

Table 3: (Left) The table shows the percentage of the bounding boxes from the reference tracklets, detected by each detector.

Here, we can see that SSD is signiﬁcantly under-performing compared to the other detectors. (Right) This table shows the

average precision of tracklet classiﬁcation with the visual assessment model trained for each person detector.

Person detection Recall Catwalk Video

Max side resolution

Detectors 416 800 1216

Faster RCNN 0.819 0.914 0.902

YOLOv3 0.794 0.843 -

SSD 0.772 0.647 -

CenterNet 0.871 0.849 0.799

Tracklet Classiﬁcation AP

Max side resolution

Detectors 416 800 1216

Faster RCNN 0.848 0.854 0.88

YOLOv3 0.853 0.858 -

SSD 0.816 0.819 -

CenterNet 0.832 0.837 0.842

Table 4: Evaluation of garment detection models on the fashion model tracklets in the catwalk videos. In this evaluation, we

have looked at both localization and categorization. The localization benchmark was formulated as a single class detection

problem, and categorization benchmark was formulated as a multi-class detection problem. The AP

.5 of the category bench-

mark is much lower than the localization benchmark. It indicates that it is much easier to locate the garments than to both

locate and to classify them correctly.

Garment detection AP

0.5

on Fashion Model Reference Bounding Boxes

Resolution 128:64, patch 256:128, patch 512:256, patch 800, whole

Localization (Single Class Detection)

Faster RCNN 0.72 0.846 0.842 0.641

YOLOv3 0.421 0.57 0.678 0.525

SSD 0.783 0.784 0.747 0.238

CenterNet 0.723 0.743 0.776 0.647

Categorization (Multi Class Detection)

Faster RCNN 0.242 0.391 0.376 0.27

YOLOv3 0.149 0.231 0.255 0.15

SSD 0.36 0.354 0.318 0.125

CenterNet 0.284 0.326 0.353 0.234

Figure 3: This ﬁgure describes the process of reference bounding box generation. Step 1 The detection boxes from different

detectors are gathered together. Step 2 The boxes are clustered to several groups using spectrum clustering. Step 3 The boxes

from the same cluster are averaged to generate the reference bounding boxes. The category of the reference bounding boxes

is set by voting.

tion, we are only interested in establishing a method

that allows us to examine which conﬁguration works

better, instead of building an absolute accuracy target.

We refer to this framework as a relative-benchmark.

To relative-benchmark, we focused on the ability

of each detector to identify the box around the fash-

ion model. To achieve this, we have created a ref-

erence annotation for each frame of the video. The

reference annotation is an aggregation of all detec-

tions, made over each frame, using all trained mod-

els. To achieve this, we have mapped the thresholds

detections of all 10 detectors to a scale-free space (by

dividing the bounding boxes by the height and width

of the frame) and grouped them using spectral clus-

tering with the IoU as the metric. Since the size of

the afﬁnity matrices is rather small in our problem,

we used a heuristic measure to determine the number

of clusters in each frame. Here, the number of clus-

ters is equal to the number of singular values of the

afﬁnity matrix that are greater than the largest singu-

lar value times 0.2. We have averaged the bounding

boxes assigned to each cluster to produce the refer-

ence bounding box. We used spectral clustering, as

oppose to Non-Maximum Suppression, to avoid hav-

ing to normalize the scoring produced by each detec-

ICPRAM 2021 - 10th International Conference on Pattern Recognition Applications and Methods

476

Table 5: Evaluation of garments detection regarding our application. We are evaluating localization, categorization, and

timing of garments detection. We ignored the garments’ category labels for the localization and benchmark it as a single class

detection problem. For categorization, we benchmark it as a regular multi-class detection problem. The timing is produced

by running the method described in §3 on a 9 shots, 43 seconds video clip (1081 frames). By comparing the different settings

for the application, we can see that the garment detectors conditioned on person detectors generally perform better and faster

than the whole image garment detectors. However, almost all detectors fail to predict the category of the boxes.

System benchmark AP

0.5

and Timing

Person Detector Garment Detector Localization Categorization Timing (seconds)

Garment detections conditioned on person detections

Faster RCNN 416 Faster RCNN 512 0.757 0.337 102.52

Faster RCNN 800 Faster RCNN 512 0.775 0.333 122.78

Faster RCNN 1216 Faster RCNN 512 0.765 0.343 151.17

YOLOv3 416 YOLOv3 512 0.523 0.175 87.25

YOLOv3 800 YOLOv3 512 0.548 0.182 124.51

SSD 416 SSD 512 0.586 0.238 246.59

SSD 800 SSD 512 0.514 0.193 306.69

CenterNet 416 CenterNet 512 0.699 0.311 71.58

CenterNet 800 CenterNet 512 0.682 0.305 88.15

CenterNet 1216 CenterNet 512 0.650 0.293 110.35

Whole image garment detection

Faster RCNN 416 Faster RCNN 800 0.604 0.261 117.27

Faster RCNN 800 Faster RCNN 800 0.624 0.261 137.94

Faster RCNN 1216 Faster RCNN 800 0.608 0.252 166.26

YOLOv3 416 YOLOv3 800 0.479 0.132 97.99

YOLOv3 800 YOLOv3 800 0.453 0.136 136.79

SSD 416 SSD 800 0.167 0.093 381.29

SSD 800 SSD 800 0.148 0.076 419.9

CenterNet 416 CenterNet 800 0.637 0.226 85.45

CenterNet 800 CenterNet 800 0.637 0.226 100.4

CenterNet 1216 CenterNet 800 0.608 0.217 122.38

(a) (b)

Figure 4: This ﬁgure shows the application benchmark using different person detectors and garment detectors. (a) shows

the AP@0.5 for localization, and (b) shows the AP@0.5 for categorization. The Faster RCNN person detectors and garment

detectors perform the best in our application. The behavior of different detectors are similar to our discussion in Table 5.

tor

. The process of creating these reference bound-

ing boxes for both people and garments is shown in

Fig. 3.

We observed that when using NMS, the reference an-

notation would be dominated by the person detectors, which

tend to produce higher scores. Building a method to nor-

malize the scoring produced by all the detectors is out of

the scope of this paper.

Each reference bounding box has the property that

several methods have voted on its importance in each

frame. We refer to the tracklets that are built based on

reference bounding boxes as reference tracklets. We

provided manual annotation for the reference track-

lets to determine if they are associated with a fashion

model or not.

Garment Detection in Catwalk Videos

477

With these references, it is now possible to com-

pare the performance of different model conﬁgura-

tions on the catwalk video. We should emphasize

that in these experiments, no training was done on the

video, and it was only used for benchmarking.

4.3 Benchmark

In this section, we investigate the benchmarking of

our application from two different perspectives. First,

we benchmark every module of the application inde-

pendently using the reference tracklets. Second, we

benchmark the application as a whole.

To evaluate the person detectors, we only focus

on the reference tracklets associated with the fashion

models. We aimed to establish a metric that demon-

strates how often a given detector misses the bounding

boxes, which are present in the tracklets. To achieve

this, we have used the IoU 0.5 metric to verify if a

detection bounding box has some overlap with a ref-

erence bounding box and calculated the percentage of

the reference bounding boxes that were detected. Ta-

ble 3 (Left) shows the recall of reference bounding

boxes for different detectors. As expected, almost all

detectors perform reasonably well in this test.

To evaluate the tracklet classiﬁcation, we applied

the visual assessment model, trained based on each

detector, to the reference tracklets and measured how

often the tracklets are classiﬁed correctly (§3 Step 4).

Table 3 (Right) shows the average precision of these

classiﬁers for different detectors. As can be seen, al-

most all detectors perform similarly with respect to

this metric. The experiment conﬁrms our hypothe-

sis that we can identify the fashion models by under-

standing the visual differences between the people ap-

pearing in COCO 2014 and Modanet datasets.

To evaluate the garment detection, we created ref-

erence bounding boxes for the garments with two dis-

tinctions. (a) For better consistency, we decided to re-

move the clusters with a single bounding box, and (b)

we determined the category of the reference bounding

boxes based on majority voting. For this benchmark,

we have only focused on the garment detections on

the reference bounding boxes that are associated with

the annotated fashion models tracklets. For the whole

image detections, we considered the detections that

overlap at least 80% with a reference bounding box.

In this benchmark, we focused on how well the gar-

ments are located and identiﬁed. Since a garment can

be correctly located but incorrectly identiﬁed, we di-

vided this benchmark into two parts, (a) localization

in which we benchmark the garments as a single class

detection problem, with all the garments belonging to

one class, and (b) categorization in which we bench-

mark the garments as a multi-class detection problem.

These benchmarks are set up as standard object detec-

tion benchmarks and are done using the COCO eval-

uation tools. The results can be seen in table 4. The

experiment shows that it is much easier to localize

the garments in these videos than to correctly classify

them. It is interesting that whole image garment de-

tection performs signiﬁcantly worse in all cases based

on this benchmark. This conﬁrms our hypothesis that

the experimental setup presented for different fashion

datasets is not suitable for real-world applications.

Finally, to benchmark the application as a whole,

we applied our method on the target video and pro-

duced garment proposals for each frame. This pro-

cess includes (a) running the person detection for each

frame, (b) forming the tracklets, (c) classifying the

tracklets, and (d) producing garment proposals for

bounding boxes in tracklets that are classiﬁed as fash-

ion models. The target for this benchmarking is the

reference garment bounding boxes, which are created

based on the fashion model reference tracklets. In this

scenario, if our method makes an error and classiﬁes a

non-fashion model tracklet as a fashion model track-

let, the garment detections based on this tracklet are

considered as false positives. Similar to the previous

benchmark, this problem is also formulated as a stan-

dard object detection benchmark using COCO evalu-

ation tools. The results of this experiment can be seen

in Table 5. We observe that most garment detectors

that are conditioned on person detections do a decent

job of localizing the garments. Further, it is noticeable

that almost all methods are failing at correctly classi-

fying the garments. This might be due to the fact that

there is a large visual disparity between the garments

in the Modanet dataset and the garments appearing in

the catwalk videos. this disparity is resulting in dif-

ferent methods identifying different categories for a

given garment. To our understanding, improving this

part of our application requires the building of cus-

tom models that are not in the scope of this paper. It

should be noticed that whole image garment detec-

tors tend to perform worse and run slower than the

garment detectors based on person detection patches.

This is true for both garment localization and catego-

rization. By comparing the data in Table 5, we can

observe that Faster RCNN 800 person detector com-

bined with Faster RCNN 512 patch garment detector

has the highest accuracy for our application.

5 CONCLUSION

We investigated how to utilize off-the-shelf code-

bases and datasets to solve computer vision appli-

ICPRAM 2021 - 10th International Conference on Pattern Recognition Applications and Methods

478

cations as complex as garment detection in catwalk

videos. We showed how some of the assumptions

made in existing available datasets, such as Modanet,

are not suitable for real-world applications. We ar-

gued that to use the models trained on these datasets

in real-world applications, we might need to introduce

new assumptions to the training procedure that might

not improve the results on the original dataset but in-

crease the accuracy of the application. Finally, we

have presented a relative-benchmarking framework to

compare the accuracy of different methods for our ap-

plication without the need for extensive annotations.

As discussed, we were not able to solve all the chal-

lenges of this problem using off-the-shelf methods

(Robust garment classiﬁcation) and we believe that

addressing these problems can only be done by build-

ing custom and sophisticated models.

What we discussed in this paper can be applied

to almost any computer vision application with sim-

ilar properties. In any application, one should inves-

tigate if the assumption made in the research datasets

and code-bases are relevant to the application. At the

same time, the relative-benchmark proposed in this

paper can be a valuable tool for examining these as-

sumptions and ﬁnding a correct solution to the prob-

lem.

REFERENCES

Cychnerski, J., Brzeski, A., Boguszewski, A., Mar-

molowski, M., and Trojanowicz, M. (2017). Clothes

detection and classiﬁcation using convolutional neural

networks. In 2017 22nd IEEE International Confer-

ence on Emerging Technologies and Factory Automa-

tion (ETFA), pages 1–8.

Deng, J., Dong, W., Socher, R., Li, L.-J., Li, K., and Fei-

Fei, L. (2009). Imagenet: A large-scale hierarchical

image database. In 2009 IEEE conference on com-

puter vision and pattern recognition, pages 248–255.

Ieee.

Ge, Y., Zhang, R., Wu, L., Wang, X., Tang, X., and Luo, P.

(2019). A versatile benchmark for detection, pose esti-

mation, segmentation and re-identiﬁcation of clothing

images. CVPR.

He, K., Gkioxari, G., Doll

ar, P., and Girshick, R. (2017).

Mask r-cnn. In Proceedings of the IEEE international

conference on computer vision, pages 2961–2969.

Kucer, M. and Murray, N. (2019). A detect-then-retrieve

model for multi-domain fashion item retrieval. In Pro-

ceedings of the IEEE Conference on Computer Vision

and Pattern Recognition Workshops, pages 0–0.

Lin, T., Maire, M., Belongie, S. J., Bourdev, L. D., Girshick,

R. B., Hays, J., Perona, P., Ramanan, D., Doll

ar, P.,

and Zitnick, C. L. (2014). Microsoft COCO: common

objects in context. CoRR, abs/1405.0312.

Liu, W., Anguelov, D., Erhan, D., Szegedy, C., Reed, S.,

Fu, C.-Y., and Berg, A. C. (2016a). Ssd: Single shot

multibox detector. In European conference on com-

puter vision, pages 21–37. Springer.

Liu, Z., Luo, P., Qiu, S., Wang, X., and Tang, X. (2016b).

Deepfashion: Powering robust clothes recognition and

retrieval with rich annotations. In Proceedings of

IEEE Conference on Computer Vision and Pattern

Recognition (CVPR).

Paszke, A., Gross, S., Massa, F., Lerer, A., Bradbury, J.,

Chanan, G., Killeen, T., Lin, Z., Gimelshein, N.,

Antiga, L., Desmaison, A., Kopf, A., Yang, E., De-

Vito, Z., Raison, M., Tejani, A., Chilamkurthy, S.,

Steiner, B., Fang, L., Bai, J., and Chintala, S. (2019).

Pytorch: An imperative style, high-performance deep

learning library. In Wallach, H., Larochelle, H.,

Beygelzimer, A., d'Alch

e-Buc, F., Fox, E., and Gar-

nett, R., editors, Advances in Neural Information Pro-

cessing Systems 32, pages 8024–8035. Curran Asso-

ciates, Inc.

Redmon, J., Divvala, S., Girshick, R., and Farhadi, A.

(2016). You only look once: Uniﬁed, real-time object

detection. In Proceedings of the IEEE conference on

computer vision and pattern recognition, pages 779–

788.

Redmon, J. and Farhadi, A. (2018). Yolov3: An incremental

improvement. CoRR, abs/1804.02767.

Ren, S., He, K., Girshick, R., and Sun, J. (2015). Faster R-

CNN: Towards real-time object detection with region

proposal networks. In Advances in Neural Informa-

tion Processing Systems (NIPS).

Sidnev, A., Trushkov, A., Kazakov, M., Korolev, I., and

Sorokin, V. (2019). Deepmark: One-shot clothing

detection. In The IEEE International Conference on

Computer Vision (ICCV) Workshops.

Sou

cek, T., Moravec, J., and Loko

c, J. (2019). Transnet: A

deep network for fast detection of common shot tran-

sitions. arXiv preprint arXiv:1906.03363.

Zheng, S., Yang, F., Kiapour, M. H., and Piramuthu, R.

(2018). Modanet: A large-scale street fashion dataset

with polygon annotations. In ACM Multimedia.

Zhou, X., Wang, D., and Kr

ahenb

uhl, P. (2019). Objects as

points. CoRR, abs/1904.07850.

Garment Detection in Catwalk Videos

479
