Emerging Design Patterns for Blockchain Applications

Vijay Rajasekar

, Shiv Sondhi

, Sherif Saad

and Shady Mohammed

School of Computer Science, University of Windsor, Canada

Faculty of Computer Science & IT, Ahram Canadian University, Egypt

Keywords:

Software Engineering, Software Patterns, Empirical Analysis, Anti-patterns, Blockchain.

Abstract:

Blockchain or Distributed Ledger Technology (DLT) introduces a new computing paradigm that is viewed by

experts as a disruptive and revolutionary technology. While bitcoin is the most well-known successful appli-

cation of blockchain technology, many other applications and sectors could successfully utilize the power of

blockchain. The potential applications of blockchain beyond ﬁnance and banking encouraged many organiza-

tions to integrate and adopt blockchain into existing or new software systems. Integrating and using any new

computing paradigm is expected to affect the best practice and design principles of building software systems.

This paper summarizes our ongoing research on collecting, categorizing and understanding, existing software

design patterns when building blockchain-based software systems. It collects and categorizes the existing

software (design and architectural) patterns that are commonly linked to blockchain and distributed ledger

technology. We provide an informal analysis of the identiﬁed patterns to highlight their maturity. Finally,

we discuss the current research gap in software engineering for blockchain-based applications and propose

potential research directions.

1 INTRODUCTION

A blockchain is a distributed store or ledger of records

that is usually used to store transactional data. How-

ever, there is no restriction on the type of data that can

be stored health records for health applications, own-

ership records for property management and even ex-

ecutable code in the form of smart-contracts. This in-

dicates how ﬂexible blockchains can be. Blockchain

technology came into existence when a white paper

titled Bitcoin: A peer-to-peer electronic cash system

was announced by Satoshi Nakamoto in 2008. How-

ever, the word blockchain was never used in the paper

speciﬁcally. The paper discusses a peer-to-peer ver-

sion of electronic cash that overcome a well-known

limitation in electronic cash (cryptocurrency) known

as double-spending.

One of the major milestones in blockchain tech-

nology was the introduction of a blockchain frame-

work named Ethereum (Buterin, 2014). It pro-

vides a powerful application stack embedded within

each node of the Ethereum network, known as the

Ethereum Virtual Machine. It also provides Solidity,

a programming language for writing smart contracts,

inspired by many object-oriented programming lan-

guages, to simplify and standardize the development

of Decentralized Applications or DApps. The devel-

opment of DApps in Ethereum is achieved through

writing smart contracts using Solidity and implement-

ing other parts of the DApp using Web3 (Buterin,

2014).

Today, there are many blockchain/distributed

ledger platforms that enable the development

of blockchain-based applications or integrating

blockchain into existing software systems. For

instance, we have Hyperledger Fabric, Quorum,

Corda, Ripple, Tezos, Sawtooth, BigChainDB,

OpenChain, etc. All of these platforms provide

technology stacks that enable the developers to build

and blockchain-based applications. The recent devel-

opments of blockchain platforms and the widespread

of blockchain-based applications introduced new

challenges to the software development commu-

nityblockchain developers encountering several

challenges when working with blockchain. To solve

these challenges, blockchain developers introduced

new software design patterns or adapted existing

patterns.

Software design patterns played a signiﬁcant role

in software engineering practice and education since

the term was coined (Gamma et al., 1993). De-

sign patterns are generally considered as the accepted

242

Rajasekar, V., Sondhi, S., Saad, S. and Mohammed, S.

Emerging Design Patterns for Blockchain Applications.

DOI: 10.5220/0009892702420249

In Proceedings of the 15th International Conference on Software Technologies (ICSOFT 2020), pages 242-249

ISBN: 978-989-758-443-5

practices applied to software system design, which

help in making the system portable, clean and efﬁ-

cient. It is not entirely clear how design patterns af-

fect the performance of a system; although a few tra-

ditional patterns do optimize memory consumption

(Flyweight Pattern) and speed optimization (Proxy

Pattern).

These patterns however, are not a one-size-ﬁts-all

utility. Different systems beneﬁt from different pat-

terns; so selecting the correct ones for your appli-

cation is important. Similarly, when new technolo-

gies crop up, they create the need for new design pat-

terns. Examples include technologies like cloud com-

puting, the internet of things and blockchain. Since

these technologies differ signiﬁcantly from traditional

software systems, they require design patterns that are

suited to their unique attributes. Here, we attempt to

ﬁnd and validate the effect of design patterns on the

efﬁciency, security and reusability of blockchain ap-

plications.

This short paper is organized as follows. In sec-

tion 2, we identity and discuss common blockchain

design patterns. In section 3 we provide brief empir-

ical analysis and discuss how the patterns have ma-

tured with time. Finally, in section 4 we provide the

conclusion for our ﬁndings and our stance on the mat-

ter.

2 BLOCKCHAIN DESIGN

PATTERNS

Several studies have been proposed in the literature to

introduce some new patterns or to extend existing pat-

terns to ﬁt blockchain-application requirements. This

section compiles the patterns found and presents each

one with a description, the need for the pattern and

the consequences of using it. Wherever applicable,

real-world context is also provided.

Checks-Effects-Interactions Description - The con-

tract ﬁrst checks whether the necessary conditions are

met, then makes necessary changes to the contract

state (effects) and ﬁnally passes control to another

contract (interactions) (Wohrer and Zdun, 2018).

Need - If the ”interactions” occur before the ”ef-

fects” are recorded and the invoked contract makes

a callback to the original one, the system state can

be exploited. And it was, in the hack of The DAO

(Atzei et al., 2017). The attacker made a recursive

call to a function in such a way that the contract’s

funds were transferred (interaction) before the pro-

gram could ever record the transfer of funds (effects).

Consequences - The advantage of this software pat-

tern is that it ensures all debits and credits are

recorded before any further transactions can be made.

A disadvantage is that the pattern is counter-intuitive

in the sense that it is generally good practice to wait

for a function to execute successfully, before making

any state changes.

Secure Ether Transfer Description - This is in-

fact an anti-pattern. The low-level Solidity function,

address.call() should not be used to invoke a con-

tract. Instead, the high-level address.send() or ad-

dress.transfer() should be preferred because they set

a limit on the amount of gas

the contract can forward

to any invoked contract. (Wohrer and Zdun, 2018;

Whrer and Zdun, 2018)

Need - Since the low-level function will forward all

remaining gas to the invoked contract, using it allows

further invocations to be made, provided the gas sent

in the original call is sufﬁciently larger than the re-

quired minimum.

Consequences - The advantage is that if the amount

of gas transferred is capped, the extra invocations will

end eventually due to insufﬁcient funds.

Oracle Description - A contract or blockchain-based

application may sometimes need to access informa-

tion from the external world. The oracle pattern uses

a third-party veriﬁer to verify that information stored

off-chain is valid, before it can be relayed to the

blockchain. (Xu et al., 2018; Whrer and Zdun, 2018;

Zhang et al., 2018)

Need - There are several scenarios where a blockchain

may need to access external data. This depends on

the application’s use-case but a few examples are:

stock market data, weather-related data and bank ac-

count information. Since such information is stored

off-chain, it’s validity may be compromised and the

trust generated by the blockchain can be compro-

mised without even attacking it directly.

Consequences - Some considerations when using an

oracle are to be sure you can trust the third-party.

It can also be argued that this introduces an element

of centralisation in the blockchain-based application.

But that is something that can be controlled while de-

veloping the oracle, as shown by (Grifﬁth, 2017) and

(Costa, 2019).

Off-chain Datastore Description - If the raw data to

be stored on the blockchain takes too much memory,

calculate a hash for the entire raw data and store this

on the blockchain instead.(Lu et al., 2018)

Need - Since the blockchain is a distributed store of

data, many nodes in the network must store the en-

tire blockchain, which becomes infeasible if too much

data is stored in every block. Additionally, on public

blockchains, storing data requires money and can get

Gas is a monetary token or the ”cost” for any transac-

tion in Ethereum

Emerging Design Patterns for Blockchain Applications

243

expensive quickly.

Consequences - The hash will let you know if the data

has been tampered with or not. This is called hash in-

tegrity. However, tampering cannot be reversed and if

the data is deleted or lost, only its hash remains per-

manently.

State Channel Description - Micro-transactions

should not be stored on the blockchain; they should

be stored off-chain and only the ﬁnal settled amounts

should be stored on-chain (Xu et al., 2018). There

are some use-cases of this pattern, the most common

being the Lightning Network in Bitcoin (Poon and

Dryja, 2015) and Plasma in Ethereum.

Need - As mentioned, storing large amounts of data

on the blockchain is not sustainable for scalability

and sometimes cost issues. In the case of micro-

transactions, the amount being transacted is signiﬁ-

cantly lesser than the processing fees and will take up

as much space as any other transaction on the chain.

Consequences - Using the state channel pattern can

thus save storage space and costs. A drawback could

be the trustworthiness of the state-channel protocol

which is different from the blockchain’s.

Contract Registry Description - Every contract and

its address are stored off-chain as key-value pairs.

This mapping is mutable since it is off-chain, which

means that the address of a contract can be updated in

the registry. Since calls to any contract will now go

through the registry, this leaves all dependencies in-

tact. (Xu et al., 2018; Whrer and Zdun, 2018)

Need - Code on a smart contract may need to be mod-

iﬁed or updated to deal with bugs and changing re-

quirements. Since data on a blockchain cannot be

modiﬁed, the registry pattern offers an abstraction

over contract names and their code.

Consequences - The advantage is that this allows us

to update our contract logic and can be used to rectify

bugs and errors. The registry being stored off-chain

seems like a drawback but Ethereum itself stores a lot

of important data off-chain as we’ll see in Section 3.

Data Contract Description - Store data and code on

separate contracts to decouple them.(Xu et al., 2018;

Whrer and Zdun, 2018)

Need - If a contract stores its data within itself, mod-

ifying the contract using the registry or proxy pat-

tern will mean rewriting all of the data to the up-

dated version as well. Since the outdated contracts

still remain on the blockchain, and are only indirectly

replaced by the updated versions, the data will be

stored redundantly with every new version of the con-

tract (Volland, 2018). Conversely, storing the data on

a data contract would reduce redundant data storage

and save space as well as money.

Consequences - The consequences of this separation

are the obvious cost and storage efﬁciency. Some

negative consequences would be that the separation

of logic from data increases complexity of code due

to external calls. Moreover, external calls increase

chances of unintended behaviour.

Embedded Permission Description - Contracts must

have an embedded permission ﬁeld for certain critical

functions, which allows only authorized users to run

them. This is comparable to an end-user not having

access to all the back-end code.(Xu et al., 2018; Lu

et al., 2018)

Need - A good example of a critical or sensitive func-

tion is self destruct() in Solidity

. The absence of em-

bedded permission to execute this particular function

was leveraged in the Parity Wallet hack (Destefanis

et al., 2018).

Consequences - To use this design pattern one must

ﬁrst decide on the method to check for permissions.

For instance, you could perform authorization using

the user’s private key, although this may pose prob-

lems when permissions change or a private key is lost.

Factory Contract Description - This pattern is simi-

lar to the idea of a class in programming languages. It

entails storing a template contract on the blockchain

to instantiate other contracts having a similar struc-

ture and ﬂow.(Xu et al., 2018; Zhang et al., 2018)

Need - Using a factory contract helps make a DApp’s

code modular and reduces the amount of updates re-

quired when new functionality is added to the DApp.

It also ensures that certain design principles are con-

sistent throughout the application.

Consequences - The factory contract makes it easier

for beginners to create contracts which follow prede-

ﬁned best-practices. It can reduce the use of inefﬁ-

cient design but may however, imply extra costs. This

is speciﬁcally applicable if the application is running

on a public blockchain as it most likely will be.

Emergency Stop Description - Include the ability for

an authorized party to stop the execution of a con-

tract.(Wohrer and Zdun, 2018)

Need - If a contract is executing malicious functions

recursively or for several iterations, without the abil-

ity to interrupt, the malicious function can run in-

deﬁnitely and the nodes can do nothing till execu-

tion completes. While the attacker hacked The DAO,

the participants on the Ethereum network could only

watch as their money was slowly siphoned out of their

contracts and into the attacker’s.

Consequences - Having an authorized emergency stop

functionality will allow an authorized party to prevent

further damage in cases of malicious or erroneous ex-

ecutions. Choice of the authorized party is an impor-

It is technically an opcode for the EVM - like the ones

in low-level assembly languages

ICSOFT 2020 - 15th International Conference on Software Technologies

244

Table 1: Design Patterns Discussed.

Name Domain Usefulness Similar Traditional Patterns

Checks-Effects-Interactions Security Avoid unexpected errors Chain of Responsibility

Secure Ether Transfer Security Minimize risk —

Oracle Data Maintain integrity —

Off-chain Datastore Data Storage and Integrity —

State Channel Structural Storage —

Contract Registry Structural Flexibility Proxy Pattern

Data Contract Structural Avoid unexpected errors —

Embedded Permission Security Authentication and authorization Facade

Factory Contract Creational Convenience Factory

Emergency Stop Security Minimize Risk Memento

Mutex Security Synchronisation Mutex

Create Balance Limit Security Minimize Risk —

Reverse Veriﬁer Data Availability and Authentication Observer

Incentive Execution Behavioral Good practice Composite

Commit and Reveal Security Authentication and Authorization Iterator

Proxy Contract Structural Flexibility Proxy Pattern

Dynamic Binding Structural Authentication and Authorization Chain of Responsibility

Flyweight Structural Storage Flyweight

Tight Variable Packing Behavioral Storage —

tant consideration. Moreover, having a single author-

ity may lead to centralisation - to tackle this multi-

party authorization can also be used.

Mutex Description - This patern is similar to mu-

texes in traditional programming. It prevents a con-

tract from executing code in its parent contract, un-

til the parent has executed completely. (Wohrer and

Zdun, 2018) The parent contract here is the contract

that invokes another contract.

Need - Having a recursive call (or a callback) that

modiﬁes the state of the parent, before it has ﬁnished

its execution, can cause serious issues as described

several times above. Using a mutex is just another

way to assure that such attacks (like re-entrancy) can-

not occur.

Consequences - There aren’t many negative conse-

quences of using a mutex - generally if you ﬁnd the

mutex hindering your task, there’s probably a better

way to accomplish the task.

Contract Balance-limit Description - This pattern

states that a contract should not hold any more funds

than a predeﬁned balance-limit. It must reject any

further transactions made to it except for forced pay-

ments

. (Wohrer and Zdun, 2018)

Need - This design pattern will reduce the risk if any

individual contract is compromised. Having a con-

tract with too much capital reduces the target area for

a potential attack to take place.

Consequences - The consequences of this design pat-

tern are that once the balance-limit has been reached,

the contract will not accept any more gas, therefore

Functions like self destruct() and also mining rewards

sent to a contract, cannot be declined. Therefore they are

”forced” payments

nobody can invoke the contract again unless there is

some provision to send the funds elsewhere.

Reverse Veriﬁer Description - Sometimes an appli-

cation may need to access data from the blockchain.

Like the oracle pattern, reverse veriﬁer is used to ver-

ify data being sent to an external source from the

blockchain.(Xu et al., 2018)

Need - It is common to have application data in a

traditional database and store only a hash on the

blockchain. One shortcoming of this is that we cannot

prevent tampering of data in the database. The tam-

pering will be detected however, thanks to the hash

value. The reverse veriﬁer checks for hash integrity

when blockchain data is requested by external com-

ponents.

Consequences - One possible consequence of using

a reverse veriﬁer is that communication between ex-

ternal components and the blockchain may take some

time. Additionally, the reverse veriﬁer must also be a

trusted party.

Incentive Execution Description - Make seldom-run

utility functions piggyback onto contracts that execute

more often.

Need - Some functions perform tasks like cleaning

up expired records, making dividend payouts and de-

stroying deprecated contracts. These utility functions

also require gas to be executed, and the payout is usu-

ally not enough to offset the execution cost. Therefore

reimbursing callers or adding these functions to other

contracts are possible solutions. (Xu et al., 2018)

Consequences - There are some things to consider if

this pattern is used. For starters, the type of contract

that the utilities are appended to; if it contains sensi-

tive functions, experiences a lot of trafﬁc or is called

Emerging Design Patterns for Blockchain Applications

245

more often than the utilities must be, it is not a good

ﬁt. Also, the amount of gas required to invoke the

contract may increase due to the utility functions.

Commit and Reveal Description - This pattern

works by hiding certain secret variables in a contract’s

function, and only displaying the ﬁnal values. Autho-

rized users may have access to the secret.(Whrer and

Zdun, 2018)

Need - If a contract’s internal state is visible to the

network, it is possible for a malicious user to take ad-

vantage, and invoke the contract with deliberately se-

lected variables that change the state to one they de-

sire. So, this pattern hides some variables from the

network, reducing the probability of such injection at-

tacks.

Consequences - Implementing this pattern requires

overhead in terms of code. Deciding access roles will

also need consideration to prevent centralisation of

the system.

Proxy Contract Description - Create a proxy for

each contract, which will accept, and then forward

the parameters to the current version of the con-

tract.(Whrer and Zdun, 2018)

Need - This pattern is similar in purpose to the con-

tract registry. They both help in modiﬁcation and up-

dating of contracts.

Consequences - A contract registry has two obvious

advantages over a proxy contract: there is only one

contract registry but there are several proxies, and us-

ing a proxy contract does not allow anything to be re-

turned to the invoking contract. One advantage, is that

the proxy contracts unlike the registry, will be stored

on-chain.

Dynamic Binding Description Create a dynamic as-

sociation between a contract and its authorized users’

addresses, in such a way that the addresses are not de-

ﬁned in the contract. Instead, the users send a secret

key to another, designated contract, which forwards

the request to the the main one if the key is valid.(Lu

et al., 2018)

Need - This pattern can be used in cases where an ex-

tra layer of security is required. Since the authorized

user’s address is not listed on the contract, it is not

visible to the public.

Consequences - This design pattern ensures privacy

and also respects the authorization and authentication

protocols of the network. It may however, increase

gas overhead due to the extra contract invocations and

can raise problems if the secret key is lost or compro-

mised.

Flyweight Description - Inspired in part by the data

contract design pattern, the ﬂyweight contract stores

data that is shared by a group of clients in one com-

mon place.(Zhang et al., 2018)

Need - Since this pattern is essentially a data contract

itself, the need is the same - to decouple data from

programmatic logic. It also helps conserve space by

storing a single copy of data that is shared between a

group of contracts.

Consequences - The consequences of using the ﬂy-

weight are that lots of storage space is saved, which

translates to money saved. It also means that updating

a contract will not affect the shared data. Some con-

siderations while using this pattern are: accessing the

data may require extra gas and, some provisions are

required for when the data needs to be updated.

Tight Variable Packing Description - Store static

variables in smart contracts as the smallest possible

data type that they can ﬁt in. For example don’t store

a value as an int if it could be stored as a byte. (Vol-

land, 2018)

Need - This is because storage costs money on

Ethereum and other public blockchains.

Consequences - There are no negative consequences

of using the pattern - it should be followed in tradi-

tional programming as well, but has greater conse-

quences in blockchain-oriented software.

In Table 1 each design pattern is assigned a do-

main that describes what aspect of the blockchain the

pattern affects. The domains are listed below with a

brief note on each.

• Security - Includes design patterns that increase

security of the system.

• Data - Includes design patterns that deal with data

on and off the blockchain.

• Creational - Include design patterns that deal

with creation of contracts on the blockchain.

• Structural - Include design patterns that deﬁne

structural properties that lead to new functionality.

• Behavioral - Include design patterns dealing

mainly with good practices and speciﬁc behaviors

of contracts on the blockchain.

3 PATTERNS MATURITY

We have discussed common design patterns in

blockchain-oriented software and how they may be

useful to developers. Some of these patterns emerged

as a means to tackle malicious users on the pub-

lic internet and others to make an application more

cost-effective or scalable. In this section, we discuss

how the design patterns have matured over years and

whether they hold any value in blockchain-oriented

software engineering at all.

The oracle or external data veriﬁer, has emerged

as one of the most prominent design patterns in the

ICSOFT 2020 - 15th International Conference on Software Technologies

246

industry today. Part of its popularity lies in the fact

that companies and individuals began implementing

oracles as a distributed application i.e. the oracle

itself was built on a blockchain. This enables ora-

cles to be used in other industries for data validation

as well. ChainLink is one such company that has

quickly risen to fame (Ellis et al., 2017). It offers a

distributed solution to the external data access prob-

lem. The great thing about ChainLink is that it works

as an oracle veriﬁer, as well as a reverse veriﬁer, i.e.

it can validate data coming from a blockchain appli-

cation too. There are many projects like ChainLink

that create distributed oracles and such services are

used by other popular DApps. Chainlink itself, con-

nects DApps to external APIs and also provides sup-

port for blockchain transactions. It has partnered with

the likes of Google, Binance and other major players

in the DLT/Blockchain industry.

One DApp that uses Chainlink’s oracle services is

Loopring - an open protocol for building decentral-

ized exchanges. Despite the P2P and decentralized

nature of blockchains, most cryptographic assets to-

day are exchanged at centralised exchanges (like Bi-

nance, Bitmex, etc). When trading through these cen-

tralised exchanges, traders must transfer their assets

to a wallet provided by the exchange, and then the ex-

change will facilitate the trade. One problem here is

that after transferring your assets, you are no longer

in control of them - the exchange does not provide the

wallet’s private key to traders. During this interme-

diary period, you can’t control what happens to your

assets and Loopring identiﬁes this as a single point

of failure. Their website lists around 40 hacks of ex-

changes and online marketplaces since 2013, each re-

sulting in a loss of tens of millions of dollars on av-

erage. All of this money ultimately belongs to traders

using the exchange. Loopring’s aim is to create non-

custodial, decentralised exchanges. To do this, they

use zero-knowledge proofs (ZKP). ZKP aims to allow

a user to prove they know a secret value, without dis-

closing the secret itself. In other words, a trader can

prove that he knows his private key without actually

disclosing it. This is an application of the commit-

and-reveal design pattern, where secret values are

hidden from unauthorized users and only the ﬁnal so-

lutions are visible. Using this pattern, Loopring is try-

ing to make blockchains scalable and increase trans-

action throughput. Apart from commit-and-reveal,

Loopring uses an off-chain data storage in addition

to the Ethereum blockchain.

Another pattern that receives some attention

is the ﬂyweight pattern. The DApp for Smart

Health (DASH) is a distributed application that

uses blockchain technology in the healthcare sector

(Zhang et al., 2018). Patient records and information

are stored on the blockchain. However, storing insur-

ance policies, coverage details and other patient infor-

mation requires a lot of storage which causes scalabil-

ity issues. Using the ﬂyweight pattern, DASH stores

all policies separately and creates references to appro-

priate policies for each patient. Since the number of

insurance policies is a much smaller subset compared

to the number of patients, the ﬂyweight pattern helps

to save a lot of storage space.

Coming to the giants in the blockchain space; the

Bitcoin community has been working hard on the

lightning network since 2016 with the ﬁrst version

going live in early 2018. The Lightning Network is

deﬁned as a Layer 2 protocol that functions on top

of a blockchain-enabled cryptocurrency like Bitcoin

(Poon and Dryja, 2015). The protocol is in its early

stages and is only available for public tests now. It

uses the state channel design pattern by enabling

micro-transaction networks to work at a higher layer

of abstraction than the payment protocol. Once a cer-

tain number of micro-transactions have been recorded

and settlement occurs, the ﬁnal amounts are added

onto the blockchain. However, recent research sug-

gests that the micro-transaction network is highly

centralised (Lin et al., 2020). It has found ”hubs”

on the network that handle a majority of the micro-

transactions. Further, taking out one of these hubs

results in the network collapsing into several compo-

nents. This is undesirable as it can lead to splits in

the network, where two or more groups of validators

(validating micro-transactions) start working on sepa-

rate chains, leading to two or more competing chains.

This could destroy the network since each group is

likely playing by its own rules. It is worth noting here

that the main Bitcoin network too is controlled ma-

jorly by only 5 mining pools (companies).

Ethereum, on the other hand, quite successfully

uses some of the discussed patterns. Ethereum’s en-

vironment is designed as a state machine. The state

of the network includes the current state of each con-

tract as well as the amount of funds available at each

address. The state of a contract is deﬁned by its inter-

nal variables and the funds available to it. This state

information is stored on an external database (Lev-

elDB and RocksDB) as a trie data structure

. The

root is hashed and stored with every new block on the

blockchain for hash integrity. Additionally, the exter-

nal database stores current as well as past state-tries of

the network, which enables the network to roll-back

the state if needed.

The off-chain data storage design pattern is wo-

A trie is like a binary tree except that each tree node

may have upto n child nodes

Emerging Design Patterns for Blockchain Applications

247

ven right into Ethereum. The external database

is stored at all validator nodes (called full-nodes).

Ethereum also allows ownership of contracts which

gives owners certain privileges, deﬁned by the own-

ers themselves. These privileges usually translate to

permissions to run certain functions in the contract

(like contract termination), thus creating a sort of em-

bedded permission. Additionally, patterns like tight

variable packing are genenrally good practice, es-

pecially when dealing with public blockchains where

storage costs money and may cause scalability issues.

After a few hacks on Ethereum’s platform, the de-

velopers started working to prevent further malicious

activity on the network. Checks-effects-interactions

and mutexes are two design patterns that were sug-

gested to safeguard against future attacks. They were

mostly relevant to hacks like The DAO’s which was

a re-entrancy attack. Re-entrancy is an attack where

contract execution passes recursively from an invoked

contract to itself in such a way that the ”effects”

of the calling contract occur after its ”interactions”.

This means that the state is never updated since the

recursive call occurs beforehand and continues in-

deﬁnitely. Using mutexes and the checks-effects-

interactions ﬂow-control can help against such attacks

but suppose that a hacker does succeed somehow, the

emergency stop pattern and balance limits can min-

imize the risk associated with the malicious activity.

Similar to how the above design patterns emerged,

the secure ether transfer anti-pattern also came

about for a similar purpose. The high-level transfer()

and send() functions were created in Solidity to help

against re-entrancy attacks. These functions add a cap

of 2300 units of gas to be passed to a contract on

invocation; limiting the number of times a recursive

call can continue (any interaction with a contract in

Ethereum requires gas). However, after the Istanbul

hard fork

, the secure ether transfer anti-pattern was

scrapped. These changes directly affected the trans-

fer() and send() functions. Now gas amounts required

for different contract invocations increased in many

cases. Therefore limiting the gas was now detrimen-

tal, as the limit was not enough to see the desired

number of invocations through. In other words, the

high-level transfer and send functions now constrain

the ability to execute necessary functions in Ethereum

- leading the developer community to advise against

the use of these two functions (Marx, 2019). In ret-

rospect, they called it a quick-ﬁx for the issues re-

vealed by the hacks. The advise now is to use the low-

level call() function along with the checks-effects-

interactions and mutex patterns.

Istanbul hard fork was an update to Ethereum that made

fundamental changes to the existing protocols

4 CONCLUSION

In this paper, we identiﬁed common software design

patterns and investigated their maturity using an em-

pirical analysis approach. We only consider a pro-

posed pattern (design solution) as a mature pattern

if it has been adapted/used by either a blockchain

platform or was applied in a well-known blockchain-

based application. In general, the identiﬁed patterns

could be categorized into ﬁve main categories. These

categories are patterns for data management, pat-

terns for security assurance, patterns for smart con-

tracts, patterns for communication with external enti-

ties, and ﬁnally patterns to reduce computational cost.

Moreover, some patterns are designed for speciﬁc

blockchain platforms or commonly used in public or

private blockchain networks. In the literature, we did

not ﬁnd any quantitative or qualitative assessments for

the proposed patterns. Therefore, for some patterns, it

is not clear exactly how they affect the quality of the

produced system or application. Moreover, extracting

or identifying the patterns is a time consuming and

intensive task, that could only be achieved using code

review and white-box analysis. These are some of the

limitations that we plan to address in our future re-

search.

ACKNOWLEDGEMENT

This research was supported by the Scotiabank

Global Trade Transactions Initiative administered

by the University of Windsor’s Cross-Border Insti-

tute and Mitacs. We thank our colleagues from Sco-

tiabank and Cross-Border Institute, who provided in-

sight and expertise that greatly assisted the research.

However, they may not agree with all of the interpre-

tations/conclusions of this paper.

We are also immensely grateful to Dr.William An-

derson from the University of Windsors Cross-Border

Institute for his comments on an earlier version of

the manuscript, although any errors are our own and

should not tarnish the reputations of any other person.

REFERENCES

Atzei, N., Bartoletti, M., and Cimoli, T. (2017). A survey

of attacks on ethereum smart contracts (sok). pages

164–186.

Buterin, V. (2014). Ethereum: A next-generation smart

contract and decentralized application platform. Ac-

cessed: 2016-08-22.

Costa, P. (2019). Github repository: Blockchain oracle.

ICSOFT 2020 - 15th International Conference on Software Technologies

248

Destefanis, G., Marchesi, M., Ortu, M., Tonelli, R., Brac-

ciali, A., and Hierons, R. (2018). Smart contracts vul-

nerabilities: a call for blockchain software engineer-

ing? In 2018 International Workshop on Blockchain

Oriented Software Engineering, pages 19–25.

Ellis, S., Juels, A., and Nazarov, S. (2017). Chainlink: A

decentralized oracle network.

Gamma, E., Helm, R., Johnson, R., and Vlissides, J. (1993).

Design patterns: Abstraction and reuse of object-

oriented design. In Proceedings of 7th European Con-

ference on Object Oriented Programming, pages 406–

431.

Grifﬁth, A. (2017). Github repository: Concurrence.io.

Lin, J.-H., Primicerio, K., Squartini, T., Decker, C., and Tes-

sone, C. J. (2020). Lightning network: a second path

towards centralisation of the bitcoin economy.

Lu, Q., Xu, X., Liu, Y., and Zhang, W. (2018). Design

pattern as a service for blockchain applications. pages

128–135.

Marx, S. (2019). Blog: Stop using solidity’s transfer() now.

Poon, J. and Dryja, T. (2015). The bitcoin lightning net-

work: Scalable off-chain instant payments.

Volland, F. (2018). Github blog: Solidity patterns.

Whrer, M. and Zdun, U. (2018). Design patterns for

smart contracts in the ethereum ecosystem. In 2018

IEEE International Conference on Internet of Things

(iThings) and IEEE Cyber, Physical and Social Com-

puting (CPSCom) and IEEE Smart Data (SmartData),

pages 1513–1520.

Wohrer, M. and Zdun, U. (2018). Smart contracts: security

patterns in the ethereum ecosystem and solidity. In

2018 International Workshop on Blockchain Oriented

Software Engineering (IWBOSE), pages 2–8.

Xu, X., Pautasso, C., Zhu, L., Lu, Q., and Weber, I.

(2018). A pattern collection for blockchain-based ap-

plications.

Zhang, P., Schmidt, D., White, J., and Lenz, G. (2018).

Blockchain Technology Use Cases in Healthcare.

Emerging Design Patterns for Blockchain Applications

249
