QSOR: Quantum-safe Onion Routing

Zsolt Tujner

1,2 a

, Thomas Rooijakkers

1 b

, Maran van Heesch

1 c

and Melek

Onen

2 d

TNO, The Hague, the Netherlands

EURECOM, Sophia-Antipolis, France

Keywords:

Tor, Anonymous Routing, Post-quantum Cryptography.

Abstract:

We propose a study on the use of post-quantum cryptographic primitives for the Tor network in order to make

it safe in a quantum world. With this aim, the underlying keying material has ﬁrst been analysed. We observe

that breaking the security of the algorithms/protocols that use long- and medium-term keys (usually RSA keys)

have the highest impact in security. Therefore, we investigate the cost of quantum-safe variants. Six different

post-quantum cryptographic algorithms that ensure level 1 NIST security are evaluated. We further target

the Tor circuit creation operation and evaluate the overhead of the post-quantum variant. This comparative

study is performed through a reference implementation based on SweetOnions that simulates Tor with slight

simpliﬁcations. We show that a quantum-safe Tor circuit creation is possible and suggest two versions - one

that can be used in a purely quantum-safe setting, and one that can be used in a hybrid setting.

1 INTRODUCTION

Nowadays, information available online is expanding

in an unforeseen way, a vast amount of data is up-

loaded and shared through social media, IoT, etc. This

data attracts unwanted attention and might paint a bad

image of some stakeholders. Consider the case of Ed-

ward Snowden who put the National Security Agency

(NSA) in the spotlight by shedding light on how the

American population was wiretapped

. When blow-

ing the whistle on such a large scale one would aim

to remain anonymous, as this act can negatively af-

fect the career and freedom of the individual. In

oppressive regimes, where the freedom of speech is

abused, this is even more serious, as any type of nega-

tive speech or expressing freedom of information may

be recognized as an act of treason resulting in severe

punishments.

The Onion Router (Tor) (Dingledine et al., 2004))

aims to ensure the anonymity of its users when ac-

cessing or communicating over the Internet. When

using Tor, messages or website connection requests

https://orcid.org/0000-0001-9748-0044

https://orcid.org/0000-0001-6930-0421

https://orcid.org/0000-0003-0135-3521

https://orcid.org/0000-0003-0269-9495

https://www.theguardian.com/world/interactive/

2013/nov/01/snowden-nsa-ﬁles-surveillance-revelations-

decoded#section/1, Accessed on 2019-06-14

are sent through a network of relays and after multi-

ple ’hops’ reach their destination. The cryptographic

schemes used today in Tor are based on hard mathe-

matical assumptions e.g., integer factorization (Katz

and Lindell, 2007). These schemes are assumed to be

secure against classical adversaries, as solving them

with the currently known algorithms cost exponen-

tial time. However, with a quantum computer solving

these problems becomes feasible.

Contributions. We investigate the main challenges to

build and maintain a quantum-safe Tor network. We

ﬁrst examine the keying material used in Tor and iden-

tify the impact of the compromise of each of them.

We observe that the migration towards quantum-safe

Tor should start with the update of cryptographic

algorithms that involve long-term and medium-term

keys. Such a migration naturally results in additional

cost in terms of CPU and bandwidth. To evaluate

the overhead resulting from the shift to post-quantum

(PQ) cryptographic algorithms, we have conducted an

experimental study while considering six PQ public-

key encryption algorithms that are part of NIST’s

round 2 submissions

. We observe that each scheme

comes with different advantages and limitations, and

that consequently there is no ideal solution that offers

optimal CPU and bandwidth overhead. We further fo-

cus on a particular Tor network operation, namely cir-

https://csrc.nist.gov/Projects/post-quantum-

cryptography/round-2-submissions

618

Tujner, Z., Rooijakkers, T., van Heesch, M. and Önen, M.

QSOR: Quantum-safe Onion Routing.

DOI: 10.5220/0009869206180624

In Proceedings of the 17th International Joint Conference on e-Business and Telecommunications (ICETE 2020) - SECRYPT, pages 618-624

ISBN: 978-989-758-446-6

cuit building, and evaluate the cost of its PQ variant.

This study is performed through a reference imple-

mentation based on SweetOnions

that simulates Tor

with slight modiﬁcations. We show that while the in-

crease in CPU time is acceptable and similar among

different implementations, the bandwidth overhead

remains signiﬁcant. For more details, the reader can

refer to the full version of this paper

2 BACKGROUND

The Onion Router (Tor). Tor (Dingledine et al.,

2004) is one of the most popular tools to achieve

anonymity for web browsing. When a Tor user ac-

cesses a website, the encrypted trafﬁc is routed across

multiple relays. The use of multiple nodes enroute

to the destination helps obfuscate the connection of

users and hence achieve anonymity: Each node in the

path towards the destination (named a circuit), only

has information about the previous node and the next

node. Messages are encrypted by the source in a lay-

ered fashion and each encryption layer is removed by

one relay node. The default number of relay nodes

to set up a circuit is three (entry node, middle node,

exit node)

. Each node has to communicate informa-

tion called descriptors to Directory Authorities who

maintain a state of the network. The Directory Au-

thorities vote on the network status to obtain a con-

sensus document. The user connects to one of the Di-

rectory Authorities, fetches the consensus document

and the Tor software selects a path from the available

nodes. The overall Tor framework is illustrated in Fig-

ure 1. Each Tor node receives and maintains multi-

ple cryptographic keys for different purposes. Table 1

Internet

Middle node

User

DAs

Consensus

Entry

node

Exit node

Figure 1: An overview of Tor with nine directory authori-

ties (DAs), a bridge authority, the consensus document, Tor

nodes, the symmetric keys (sk), and the message (msg).

https://github.com/LeonHeTheFirst/SweetOnions, ac-

cessed on 28/11/2019.

https://arxiv.org/abs/2001.03418

https://trac.torproject.org/projects/tor/wiki/

TorRelayGuide, accessed on 28/11/2019.

Table 1: Functionalities of keys in Tor.

Type Key lifetime Key name Function

RSA

long-term identity key Establish relay identity

medium-term onion key Decrypt cells at circuit cre-

ation. Used in ntor and

TAP for handshakes.

short-term connection key Establish TLS channels.

Curve25519 medium-term handshake key Handle handshakes ntor.

Ed25519

long-term master identity key Sign medium-term

Ed25519 key. Never

changes.

medium-term signing key Replaces RSA id key, signs

documents, certiﬁcates.

short-term link authentication key Authenticate handshakes

after circuit negotiation.

provides an overview of the asymmetric keys used in

Tor with their lifetime and functionalities. Long-term

keys are used at least for one year, medium-term keys

are used for three to twelve months, and short-term

keys have a lifespan of minutes to a maximum of one

day.

Post-quantum Cryptography. The security of the

current asymmetric encryption and digital signature

standards mostly depend on the hardness of inte-

ger factorization (RSA) or discrete logarithm (Difﬁe-

Hellman, Elliptic Curve Discrete Logarithm) (Katz

and Lindell, 2007). As described in (Shor, 1995),

such cryptographic schemes can be easily broken

in polynomial time when using quantum comput-

ers. Hence, researchers are actively developing post-

quantum cryptographic solutions to resist quantum at-

tacks (Bernstein, 2009). In 2016, the National In-

stitute of Standards and Technology (NIST) opened

a call for proposals on the topic of quantum-safe

cryptographic solutions for new quantum-safe stan-

dards (NIST, 2016). On January 30, 2019 the can-

didates for the second round were 17 asymmetric

key encryption and key-establishment algorithms and

9 digital signature algorithms. The transition to

quantum-safe cryptographic schemes is expected to

be a lengthy process. The adoption of quantum-safe

schemes results in a signiﬁcant increase in bandwidth

and computational cost. Developers adopt the hybrid

approach whereby currently used standardized cryp-

tographic schemes are combined with quantum-safe

schemes.

Related Work. At the time of writing, two papers

consider a quantum-safe Tor network: In (Ghosh and

Kate, 2015), the proposed solution named HybridOR

is a customized key exchange protocol. The so-

lution is reported to be computationally more efﬁ-

cient compared to the currently used ntor protocol.

In (Schanck et al., 2016), the focus is also on se-

curely establishing the short-term keys in a quantum-

safe fashion. The proposed protocol named Hybrid,

uses a combination of long-term keys generated by

Difﬁe-Hellman key exchange, and short-term keys

generated by a quantum-safe scheme NTRUEncrypt.

We observe that existing solutions focus on the prob-

QSOR: Quantum-safe Onion Routing

619

lem of key exchange only. Furthermore, their perfor-

mance study only focuses on the use of one particular

quantum-safe cryptographic scheme. For example,

Hybrid is evaluated using NTRUEncrypt only. There-

fore there seems to be a lack of comparative study

among different quantum-safe cryptographic primi-

tives.

3 TOWARDS QUANTUM-SAFE

TOR

In a quantum world, Tor users need to have the same

security and anonymity guarantees as they currently

have. A quantum-safe Tor network should provide

these same guarantees against both quantum and clas-

sical adversaries. Current attack scenarios on Tor do

not target the cryptography used in Tor but aim to ex-

ploit other potential weaknesses. However, powerful

enough quantum computers will pose a new threat to

Tor as cryptography becomes vulnerable for abuse by

quantum adversaries. Introducing PQ cryptography to

Tor must be done in order to keep cryptographic vul-

nerabilities off the list of attack surfaces. It is pivotal

to introduce quantum-safe cryptography to the keys

of the nodes.

Current Attack Scenarios. Current attacks on Tor

do not target the cryptography but rather focus on vul-

nerabilities in Tor-related software, hidden services,

bridge node discovery, disabling the network, and on

generic attacks like timing. Typically, adversaries in-

troduce new nodes to the Tor network. This is a

lengthy process due to the policy of the network. New

nodes are even more closely monitored than nodes al-

ready in the network for malicious patterns and if such

is recognized, they are excluded from the network.

Cryptographic Attacks. We now consider attack

scenarios on the keys of the nodes that a quantum ad-

versary possesses. There are four types of keys in Tor

(See Table 1) and all of these can be compromised:

• short-term key. By compromising a short-term

key at an entry node an adversary can follow the

entire circuit from sender to recipient, leading to

deanonymizing the user. Since such keys are re-

newed at the end of TLS connections, such attack

can be performed during the lifetime of its TLS

connection.

• medium-term key. When an adversary compro-

mises the short-term key and the medium-term

key of a node, it can impersonate this node. Since

a node can decrypt one layer of symmetric en-

cryption when the messages are passed through it,

the previous and next ‘hop’ in the circuit are dis-

covered. The attack has to be performed before

the rotation of the medium-term and short-term

keys.

• long-term key. The compromise of a long-term

key would enable the adversary to impersonate the

node and send forged descriptors to the directory

nodes. This also allows gaining indeﬁnite, full ac-

cess to the node. Moreover, the adversary sees

previous and consecutive ‘hops’ in the circuit with

the encrypted cells.

• symmetric key. Symmetric keys are used to en-

crypt the data sent between nodes. In the cur-

rent implementation of Tor, AES 128-bit is used

Compromising the symmetric keys enables an ad-

versary to decrypt layers of encryption and learn

the destination of the message; anonymity is at

risk. In case the attacker learns nothing but the

symmetric keys, the encrypted message must be

intercepted before entering the network as the

TLS connection adds an extra layer of security.

If an adversary does not learn all symmetric keys,

but only a subset, then he cannot decrypt the mes-

sage and thus, the circuit is not known, so source

and destination remain anonymous.

Current attacks on Tor are carried out with collud-

ing adversaries. If adversaries control the entry and

exit nodes in the network, they can share information

with each other and as a result deanonymize commu-

nicating parties. Colluding adversaries at the entry

and at the exit node who have the medium-term keys

will know the middle relay in a circuit. Sharing this

knowledge enables them to attempt to deanonymize

users, as the users using the common middle node

have the greatest probability to be communicating

with each other.

Migration Strategy for Quantum-safe Tor. Con-

sidering attackers’ capabilities and the lifetime of

the asymmetric keys, it is most urgent to update the

long-term keys to a quantum-safe alternative. Long-

term keys remain unchanged for a long time-period.

Hence, an adversary has more time to compromise

long-term keys. The effects of compromising long-

term keys are also greater, as an adversary can thereby

impersonate a node. The second most urgent need, is

updating the medium-term keys based on the avail-

able time period. Finally, the short-term keys must

be considered, even though the attacker has limited

time to compromise these keys due to the security

restrictions of Tor. Furthermore, short-term keys are

used with TLS, and there are works on making TLS

quantum-safe (Bos et al., 2015). We do stress that

https://gitweb.torproject.org/torspec.git/tree/tor-

spec.txt, accessed on 14/06/2019.

SECRYPT 2020 - 17th International Conference on Security and Cryptography

620

it is crucial to update every asymmetric scheme to a

quantum-safe alternative in order to enforce the secu-

rity and anonymity claims of Tor. Lastly, we note that

the symmetric keys must be updated to AES 256 bits to

prevent ‘store now, decrypt later’-attacks (Bernstein,

2009) and ensure that users of Tor maintain life-long

anonymity.

4 IMPACT OF PQ

CRYPTOGRAPHY ON TOR

In this section, we investigate the impact that PQ

cryptography might have on the Tor network, when

following the previously suggested migration strat-

egy. The impact of migrating all asymmetric cryp-

tography to a quantum-safe alternative has an impact

on the performance (both computational and network)

and reliability of Tor. We focus, in particular, on the

key exchanges as updating these has the greatest ef-

fect on the overall performance and reliability of Tor.

We benchmark the PQ cryptographic schemes that

have been implemented in the Open Quantum Safe

library (Stebila and Mosca, 2017).We only tested the

schemes that achieve level 1 NIST security (see Ta-

ble 2).

System Setup. Local and virtual environments are

both used. The technical speciﬁcation of the note-

book used for the local experiments is Dell Lati-

tude E7240, with Intel Core i5-4310U CPU @ 2.00

- 2.60GHz processor, 8 GB RAM, Samsung SSD

SM841N mSATA 128 GB for storage and Windows

10 Enterprise 64-bit operating system. Furthermore,

an Ubuntu 18.04 LTS subsystem was installed. In or-

der to emulate the Tor network, 6 virtual machines

were used with Intel Core Processor (Broadwell) @

2.4 GHz processors, 60 GB storage, a virtual network

adapter, and Linux version 4.15.0 operating system.

Benchmarking Results. We performed measure-

ments and obtained benchmarks for (i) public key, pri-

vate key and ciphertext sizes (see table 3) , (ii) RSA

key generation, encryption and decryption, and, (iii)

quantum safe key generation, encapsulation and de-

capsulation. To get an average result for the CPU cy-

cle measurements, 1 000 iterations were run with each

test. The number of CPU cycles corresponding to one

second is 2 399 753 472.

Key lengths have an effect on network load as

they are sent to the Directory Authorities who dis-

tribute them to the clients. Larger ciphertexts have

a signiﬁcant detrimental effect on the stability, re-

liability and performance of a network. From ta-

ble 2, we observe that, both Frodo-640-AES and

Frodo-640-SHAKE (Alkim et al., 2019b) have a prob-

Table 2: Key and Ciphertext sizes in Bytes.

Scheme Public key Private key Ciphertext

RSA-1024 < 128 < 128 128

RSA-2048 < 256 < 256 256

Frodo-640-AES 9 616 19 888 9 720

Frodo-640-SHAKE 9 616 19 888 9 720

Kyber512 800 1 632 736

NewHope-512-CCA 928 1 888 1 120

NTRU-HPS-2048-509 699 935 699

Sike-p503 378 434 402

lematic ciphertext size of 9 720 bytes.

From Table 3, we observe that the lattice-

based quantum-safe schemes (Kyber, NewHope,

NTRU) require less CPU cycles for generating keys

than RSA-1024. Kyber (Avanzi et al., 2017) and

NewHope (Alkim et al., 2019a) drastically outperform

the other schemes. We also note that the supersin-

gular isogeny-based quantum-safe scheme Sike (Jao

et al., 2019), even though slightly less performant

than RSA-1024, outperforms RSA-2048. Key gen-

Table 3: CPU cycles for encapsulation, decapsulation and

key generation averaged over 1 000 test runs.

Scheme Encapsulation Decapsulation Key generation

RSA-1024 410 402 2 078 161 61 568 194

RSA-2048 730 570 5 718 858 266 140 623

Kyber512 170 856 195 106 152 973

NewHope-512-CCA 228 687 247 457 193 367

NTRU-HPS-2048-509 636 263 1 609 748 27 632 969

Sike-p503 149 691 623 159 119 760 90 800 645

eration only affects the nodes who generate them.

The factor that affects both the nodes and the client

is the time/computation needed to encapsulate and

decapsulate messages. As opposed to key genera-

tion times, where all lattice-based schemes outper-

form RSA-1024, we observe that NTRU (Chen et al.,

2019) requires more CPU cycles for encapsulation.

Decapsulation for lattice-based implementations re-

quires less CPU cycles than RSA-1024. Sike requires

the most CPU cycles and is almost 48 times more

computationally heavy than RSA-2048.

Lattice-based schemes (Kyber, NewHope,

NTRU) have better performance for CPU cycles than

the RSA schemes. This suggests that these are the

most ﬁt candidates for replacing classical crypto-

graphic schemes. However, based on ciphertext sizes,

Sike is the best ﬁt as the ciphertext size ﬁts within

one Tor cell (512 bytes).

Impact. A migration of classical cryptography to

quantum-safe cryptography can have a big effect on

the overall availability, reliability, stability and per-

formance of Tor. An important factor to take into ac-

count is the network load. The number of packets

needed to transfer the ciphertexts increase with these

schemes. The factor of computation time, on the other

end, inﬂuences the response time to users. We note

QSOR: Quantum-safe Onion Routing

621

that a trade-off has to be made between network load

and computation time, when considering the schemes

that we tested.

5 CASE STUDY: CIRCUIT

CREATION IN TOR

To investigate the impact of PQ cryptography on Tor,

we propose to investigate the performance of one par-

ticular protocol, namely circuit creation. Our frame-

work uses the SweetOnions implementation

which

is a simpliﬁed version of the circuit creation protocol

used in Tor. We consider two quantum-safe versions

of this protocol: a version in which we only use post-

quantum cryptography (QSO), and a hybrid version

of the protocol (HSO) in which we combine the cur-

rently used cryptography with post-quantum cryptog-

raphy. The reference implementation (SO) that uses

standard cryptographic schemes, namely RSA, is also

evaluated. We now provide a detailed description of

each protocol. Protocol descriptions In the original

SweetOnions protocol, deﬁned in Protocol 1 for one

layer, the client who aims to send a message m to node

N, N ∈ N, encapsulates the symmetric data encryption

key using N’s public RSA key pk

. To set up a circuit

the client has to perform these steps with all the nodes

in the circuit. Once the client knows the address of

every node, each node between the client and destina-

tion sequentially decrypts one layer of encryption and

forwards the message.

Protocol 1: Sweet Onion (SO).

Client (m) Node (pk

)

AES

←

{0, 1}

256

c ← Enc

AES

, m)

← Enc

RSA

(pk

, K

AES

)

(c,c

)

−−−−→

AES

← Dec

RSA

(sk

, c

)

m ← Dec

AES

, c)

QSO corresponds to the simple quantum-safe

variant of SO: the RSA key encapsulation method

(KEM) is exchanged with a post-quantum KEM

(PQC). The public-private key pair of the node con-

sists of post-quantum keys.

In the hybrid SweetOnions (HSO) protocol (Pro-

tocol 3), the RSA KEM is combined with a post-

quantum KEM. The client randomly generates two

symmetric encryption keys. The ﬁrst key is encap-

sulated with RSA and the second key is encapsulated

https://github.com/LeonHeTheFirst/SweetOnions, ac-

cessed on 28/11/2019,

with a PQ encryption algorithm. The actual data en-

cryption key is the result of a simple XOR of these

two symmetric keys. Hence, the receiver should per-

form two decapsulation operations (one with RSA and

one with PQ decryption).

Protocol 2: Hybrid Sweet Onion (HSO).

Client (m) Node (pk

, pk

)

AES

, K

AES

←

{0, 1}

256

AES

= K

AES

⊕ K

AES

c ← Enc

AES

, m)

← Enc

RSA

(pk

, K

AES

)

← Enc

PQC

(pk

, K

AES

)

(c,c,c

)

−−−−−−→

AES

← Dec

RSA

(sk

, c

)

AES

← Dec

PQC

(sk

, c

)

AES

= K

AES

⊕ K

AES

m ← Dec

AES

, c)

Experimental Results. We evaluate the performance

of each protocol in terms of CPU and bandwidth con-

sumption. The size of one Tor packet is 512 bytes. For

the reference SO protocol, the underlying encryption

algorithms are RSA-2048 and AES-192. For the two

other protocols, the PQ cryptographic schemes stud-

ied in Section 4 are used. Experimental results are

given in Table 4. In particular, we evaluate the cost of

wrapping the layers of encryption, decapsulating one

layer of encryption, and the overall circuit creation.

The table also includes the size of one message and

the number of packets needed for this protocol.

We observe that QSO always outperforms the

original SO. On the other hand, while the integra-

tion of Sike increases the overall time signiﬁcantly,

the bandwidth overhead is very close to SO. There-

fore, a lattice-based scheme may be considered as a

potential cryptographic primitive for circuit building

since it requires less CPU cycles than Sike. Never-

theless, the use of lattice-based schemes signiﬁcantly

increases the network load compared to Sike. There-

fore, depending on the original communication cost,

one can decide to choose Sike or a lattice-based PQC.

When using the hybrid scheme, we observe that

both the computational cost and the bandwidth in-

crease signiﬁcantly. This is mainly due to the fact

that HSO uses one RSA encapsulation and one encap-

sulation with PQC. Consequently, the cost originating

from PQC for lattice-based cryptographic schemes

becomes negligible when combined with RSA. Even

though CPU consumption remains affordable in the

hybrid implementation, the bandwidth overhead is

important. The number of packets is at least doubled

when switching to the hybrid solutions.

SECRYPT 2020 - 17th International Conference on Security and Cryptography

622

Table 4: The CPU cycles needed for building a circuit (averaged over 1 000 test runs) and message sizes.

Scheme Wrap encryp- Remove Total circuit Message Packets Time

tion layers one layer build size (bytes) needed needed

Original 5 131 765 13 714 147 46 274 206 1 223 3 0.0193s

Kyber 1 371 999 917 080 4 123 240 3 248 7 0.0017s

NewHope 1 618 934 1 119 668 4 977 938 4 832 10 0.0021s

NTRU 2 803 358 4 149 134 15 250 759 3 099 7 0.0064s

Sike 452 691 951 271 667 313 1 267 693 889 1 874 4 0.5283s

Hybrid Kyber 6 188 037 15 734 659 53 392 015 5 774 12 0.0222s

Hybrid NewHope 6 953 196 13 771 785 48 268 550 7 886 16 0.0201s

Hybrid NTRU 7 517 316 18 977 229 64 449 002 5 550 11 0.0269s

Hybrid Sike 456 441 243 275 867 016 1 284 042 291 3 938 8 0.5351s

6 CONCLUSION

In this paper, we investigated the main challenges to

develop a quantum-safe Tor network and focused on

the algorithms that use long-term and medium-term

keys. Experimental studies show that among the six

post-quantum cryptographic scheme evaluated, there

is no single winning solution. Nevertheless, given the

current status of the NIST standardisation process,

Sike seems the most optimal one when it comes to

assessing the communication overhead.

For future work, it may be interesting to test other

schemes such as the code-based BIKE. Testing the re-

maining lattice and isogeny-based schemes is also an

interesting future topic as they might have better per-

formance measurements than the ones currently avail-

able in the Open Quantum Safe library. For ﬁeld ex-

periments, an implementation of Tor called TorLAB

is available and simulates Tor on a private network of

Raspberry PIs. It would be beneﬁcial to re-create the

network and extend the measurements of our research

to the network load. This would ensure a more real-

istic study for the evaluation of expected circuit build

times, since in the current setting, network latency is

omitted.

REFERENCES

Alkim, E., Avanzi, R., Bos, J., Ducas, L., de la Piedra, A.,

oppelmann, T., Schwabe, P., Stebila, D., Albrecht,

M. R., Orsini, E., Osheter, V., Paterson, K. G., Peer,

G., and Smart, N. P. (2019a). NewHope. In NIST

Round 2 Submissions for Post-Quantum Cryptogra-

phy Standardization.

Alkim, E., Bos, J. W., Ducas, L., Longa, P., Mironov,

I., Naehrig, M., Nikolaenko, V., Peikert, C., Raghu-

nathan, A., and Stebila, D. (2019b). FrodoKEM. In

https://github.com/dws-pm/TorLAB, accessed on

11/08/2019.

NIST Round 2 Submissions for Post-Quantum Cryp-

tography Standardization.

Avanzi, R., Bos, J., Ducas, L., Kiltz, E., Lepoint, T., Lyuba-

shevsky, V., Schanck, J. M., Schwabe, P., Seiler, G.,

and Stehl

e, D. (2017). CRYSTALS-KYBER. In NIST

Round 1 Submissions for Post-Quantum Cryptogra-

phy Standardization.

Bernstein, D. J. (2009). Introduction to post-quantum cryp-

tography. Springer Berlin Heidelberg.

Bos, J. W., Costello, C., Naehrig, M., and Stebila, D.

(2015). Post-Quantum Key Exchange for the TLS

Protocol from the Ring Learning with Errors Problem.

In Proceedings of the IEEE Symposium on Security

and Privacy.

Chen, C., Danba, O., Hoffstein, J., H

ulsing, A., Rijneveld,

J., Schanck, J. M., Schwabe, P., Whyte, W., and

Zhang, Z. (2019). NTRU. In NIST Round 2 Sub-

missions for Post-Quantum Cryptography Standard-

ization.

Dingledine, R., Mathewson, N., and Syverson, P. (2004).

Tor: The Second-Generation Onion Router. In Pro-

ceedings of the 13TH USENIX Security Symposium.

Ghosh, S. and Kate, A. (2015). Post-Quantum Forward-

Secure Onion Routing (Future Anonymity in Today’s

Budget). In Proceedings of the International Confer-

ence on Applied Cryptography and Network Security

(ACNS).

Jao, D., Azarderakhsh, R., Campagna, M., Costello, C.,

Feo, L. D., Hess, B., Jalali, A., Koziel, B., LaMac-

chia, B., Longa, P., Naehrig, M., Pereira, G., Renes,

J., Soukharev, V., and Urbanik, D. (2019). Super-

singular Isogeny Key Encapsulation. In NIST Round

2 Submissions for Post-Quantum Cryptography Stan-

dardization.

Katz, J. and Lindell, Y. (2007). Introduction to Modern

Cryptography. Chapman & Hall/CRC.

NIST (2016). Submission Requirements and Eval-

uation Criteria for the Post-Quantum Cryp-

tography Standardization Process. https:

//csrc.nist.gov/CSRC/media/Projects/Post-Quantum-

Cryptography/documents/call-for-proposals-ﬁnal-

dec-2016.pdf.

Schanck, J. M., Whyte, W., and Zhang, Z. (2016). Circuit-

extension handshakes for Tor achieving forwards se-

QSOR: Quantum-safe Onion Routing

623

crecy in a quantum world. In Proceedings on Privacy

Enhancing Technologies (PETS).

Shor, P. W. (1995). Polynomial-Time Algorithms for Prime

Factorization and Discrete Logarithms on a Quantum

Computer. SIAM Journal on Computing.

Stebila, D. and Mosca, M. (2017). Post-quantum Key Ex-

change for the Internet and the Open Quantum Safe

Project. In Roberto Avanzi, Howard Heys, editors,

Selected Areas in Cryptography (SAC) 2016, LNCS,

vol. 10532.

SECRYPT 2020 - 17th International Conference on Security and Cryptography

624
