A Novel Anonymous Authentication and Key Agreement Scheme for

Smart Grid

Hamza Hammami

, Mohammad S. Obaidat

2,3,4,∗

and Sadok Ben Yahia

5,6

University of Tunis El Manar, Faculty of Sciences of Tunis, LIPAH-LR11ES14, 2092 Tunis, Tunisia

College of Computing & Informatics, University of Sharjah, U.A.E.

King Abdullah II School of Information Technology, Universality of Jordan, Jordan

University of Science and Technology Beijing, China

University of Tunis El Manar, Faculty of Sciences of Tunis, LIPAH-LR11ES14, 2092 Tunis, Tunisia

Tallinn University of Technology, Department of Software Science, Akadeemia tee 15a, Tallinn 12618, Estonia

Keywords:

Smart Grid, Consumption, Attacks, Security, Costs.

Abstract:

The smart grid is a new technology that is revolutionizing the services and uses of the electric power sector. It

is a solution that integrates the new information and the communication technology into its operation in order

to modernize the electrical system and optimize the transport of electrical energy from production points to

distribution ones. Indeed, the smart grid represents a future solution mainly based on two participants: the

distribution and calculation center and the smart meter installed at the end customer. This smart meter sends

the information carrying the energy consumption data of its customer to the distribution and calculation center.

The latter processes the received consumption data and returns the result of its calculation to the end customer

in the form of an invoice containing the amount of its consumption. This communication can be susceptible to

several types of attacks due to its sending in a network, which is not always secure. These types of attacks can

modify data and can subsequently generate a falsiﬁed consumption invoice. Our work therefore focuses on

this issue. It particularly concerns the development of a solution that has the capacity to stem attacks targeting

the smart grid with a lower computation and communication costs than its competitors.

1 INTRODUCTION

The smart grid represents an electrical network that

has used the new information and the communication

technology to modernize this network and make it in-

telligent (Raza et al. 2019). This is a recent tech-

nology that responds to the current trend in the ﬁeld

of electrical energy (Bagdadee et al. 2019). This

technology takes the form of the power distribution

server and the smart meter. The latter represents the

ﬁrst brick that plays an important role in the transfor-

mation of the conventional electrical network into an

intelligent electrical network (the smart grid) (Wang

et al. 2018). It consists of transmitting the commu-

nication data from the end customer to the energy

distribution server and receiving the invoice for its

counted electricity consumption by the energy distri-

bution server (Nguyen et al. 2019).

We cannot deny that the smart grid solution of-

∗

Fellow of IEEE

fers a wide range of advantages to its customers by

enabling them to follow its consumption in real time,

not to request the reading of its meter, to subscribe

an offer adapted to its consumption and to better con-

trol its electricity consumption (Avancini et al. 2019).

However, this advanced technology has highlighted

a fundamental security problem due to the migration

of data exchanged between the energy distribution

server and its smart meter through a network which

is not always secure, hence making these data vul-

nerable to multiple types of attacks that can cause

real damage (Romdhane et al. 2019). This security

problem is therefore a major obstacle to the expan-

sion of this solution, which highlights the implemen-

tation of solutions to contain these types of attacks in

order to ensure the security of the smart grid technol-

ogy (Romdhane et al. 2019). Our proposed solution

can face attacks targeting connection parameters and

consumption data exchanged between the energy dis-

tribution server and its smart meter and can respond

Hammami, H., Obaidat, M. and Ben Yahia, S.

A Novel Anonymous Authentication and Key Agreement Scheme for Smart Grid.

DOI: 10.5220/0009824203570362

In Proceedings of the 17th International Joint Conference on e-Business and Telecommunications (ICETE 2020) - SECRYPT, pages 357-362

ISBN: 978-989-758-446-6

357

comprehensively and efﬁciently to all security needs

with lower communication and calculation costs.

The paper is organized as follows: In section 2,

we describe the work that has appeared recently to en-

sure the security of the smart grid technology. Then,

in section 3, we detail our solution with its different

steps. After that, in section 4, we analyze the per-

formance and reliability of the solution we have pro-

posed with other competing solutions. Finally, this

paper ends with a general conclusion and some per-

spectives.

2 RELATED WORK

The problem of the security of the smart grid tech-

nology has prompted several researchers to take an

interest in this delicate subject. For this, several ap-

proaches have been devoted to the search for solu-

tions to face this problem. For example, in (Garg

et al. 2019), the authors suggested an authenti-

cation scheme, which took advantage of the op-

portunities offered by elliptic curve cryptography,

the one-way hash functions and the beneﬁts pro-

vided by the Menezes-Qu-Vanstone key exchange so-

lution. Indeed, this authentication scheme desig-

nated a lightweight solution ensuring the security and

anonymity of communications in the smart grid with

lower communication and calculation costs. How-

ever, this solution was vulnerable to the insider attack

and the password guessing attacks.

In addition, the authors in (P. Kumar et al. 2019)

put forward an authentication solution with a key

agreement based on hybrid cryptography. This so-

lution provided bidirectional authentication between

a remote smart meter and the server in order to ob-

tain a session key agreement to ensure the security

of the data communications exchanged. In addition,

it checked anonymity and the dynamic session key.

However, it did not provide security against the in-

sider attack and the password guessing attacks.

Moreover, the authors in (Tsai et al. 2015) used

an identity-based signature scheme, as well as another

identity-based encryption scheme, in order to achieve

a new anonymous key distribution scheme ensuring

the technology security of the smart grid. In the sug-

gested solution, a smart meter could anonymously ac-

cess the services offered by service providers using

a private key and without the use of a trusted anchor

during authentication. However, this solution did not

verify perfect forward secrecy and did not provide se-

curity against the man-in-the-middle and session-key-

discloser attacks.

Furthermore, the authors in (Odelu et al. 2016)

proposed a security scheme ensuring secure authenti-

cation in the smart grid. The authentication scheme

reinforced the security of the solution propounded in

(Tsai et al. 2015), but this authentication scheme was

vulnerable to the man-in-the-middle attacks.

Besides, the authors in (He et al. 2016) suggested

an anonymous authentication scheme ensuring the se-

curity of the smart grid. This proposed scheme took

advantage of the opportunities offered by elliptical

curves to provide the anonymity of the smart me-

ter and authentication between the power distribution

server and its smart meters without the help of any

trusted anchor. However, this solution did not ver-

ify anonymity and did not provide security against in-

sider and password guessing attacks.

3 PROPOSED SOLUTION

In our work, and in order to offer a more satisfactory

level of security in the intelligent electrical network,

more particularly in the security of all communica-

tions exchanged between the smart meter and the data

center, we have developed a solution of strong and

light authentication allowing mixing several authenti-

cation parameters, in order to properly authenticate a

smart meter with its energy distribution server, to pro-

tect and verify that the energy consumption data sent

by the smart meter are correct and come from a legit-

imate smart meter. In fact, in our authentication so-

lution we take advantage of the opportunities offered

by cryptography based on elliptic curves in combi-

nation with light cryptographic functions, i.e. hash

functions and concatenation functions, to use them in

the account of our security solution. Indeed, our au-

thentication solution is presented in three phases: (i)

setup, (ii) identiﬁcation and (iii) authentication and

key agreement.

3.1 Setup Phase

During this ﬁrst step, the energy distribution server

performs a process of generating a set of parameters.

These parameters enable the other stages to execute

safely. The details of this generation process are as

follow:

• At the start, the energy distribution server ran-

domly generates two large prime integers a and

b. Subsequently, it calculates z = (a - 1)(b - 1) and

r = a · b. Then, it randomly generates two integers

x and y so that PGCD(x, z) = 1 and (y · x) mod z

= 1.

• After completing the generation, the energy dis-

tribution server chooses a hash function h

(.): {

SECRYPT 2020 - 17th International Conference on Security and Cryptography

358

0, 1 }

∗

→ {0, 1}

where k denotes the size of the

hashed chain and subsequently publishes its pub-

lic key (x, r) and keeps its private key y secret.

3.2 Identiﬁcation Phase

Once the setup step is complete, the energy distribu-

tion server publishes its parameters. In this step, any

smart meter can easily register with its server. Just

enter its login (pseudo) and its password (passwd).

Subsequently, it arbitrarily generates a number λ and

calculates β = h

(passwd k λ) . After completing this

calculation, it sends <pseudo ; β > to the power dis-

tribution server.

As soon as the energy distribution server receives

<pseudo ; β >, it will perform the following calcu-

lation: E= h

(pseudo k y) ; K= h

(E k β k pseudo) ;

N= E ⊕ h

(β k pseudo). Once it has completed the

calculation, the energy distribution server saves these

results and then sends <N ; K> to the smart meter.

3.3 Authentication and Key Agreement

Phase

In this phase, the smart meter provides its login

(pseudo’) and its password (passwd’). Subsequently,

it calculates β’= h

(passwd’ k λ) and extracts E’= N

⊕ h

(β’ k pseudo’). Then it calculates K’ = h

(E’ k β’

k pseudo’). As soon as it completes the calculation, it

checks result K’ found with previously recorded K. If

the two results are equal, this means that pseudo’=

pseudo and passwd’ = passwd. Thereafter, it per-

forms the following calculations µ = h

(E’ k h

(β k

pseudo’) k S k ε ) ; ν = (pseudo’ k µ k ε)

mod r. We

note here that S is a current timestamp and ε denotes

an arbitrarily generated number. As soon as the smart

meter completes the calculation, it sends < N ; S ; ν

> to the power distribution server.

Upon the receipt of < N ; S ; ν > by the energy

distribution server, this latter will ﬁrst check the time

stamp (S - S*) <= ∆T, where ∆T represents the maxi-

mum transmission delay and S* is the timestamp dur-

ing which the connection message is received by the

power distribution server. If the timestamp is veriﬁed

to be correct, the energy distribution server will per-

form the following calculations: v

mod r in order to

get (pseudo’ k µ’ k ε’ ) ; E* = h

(pseudo’ k y) and

then extract h

(passwd’ k pseudo’) = N ⊕ E*. There-

fore, it calculates µ* = h

(E* k h

(β’ k pseudo’)k S

k ε). Once the distribution server ﬁnishes the calcula-

tion, it then checks whether µ* = µ’. If it is not, the

power distribution server rejects the session. Other-

wise, this means that it is a legitimate smart meter. In

this case, the energy distribution server will perform

the following calculation: U= h

(E’ k D) ; W= D ⊕

ε’. After completing the calculation, the energy distri-

bution server sends <U ;W ;S”> to the smart meter.

We note here that S” denotes a timestamp and D rep-

resents an arbitrarily generated number.

As soon as the smart meter receives <U ;W ;S”>,

it will ﬁrst check the timestamp (S”- S*)<= ∆T. If

the timestamp is veriﬁed to be correct, in this case the

smart meter will calculate D’ = ε ⊕ W ; U’ = h

(D’

k E*) and will then check whether U = U’. If so, this

means that the authentication step is completed suc-

cessfully. In this case, the smart meter and the energy

distribution server agree on a shared Key Agreement =

(ε k E’ k D’) = h

(ε’ k E* k D). This key is intended

for encryption and decryption of all data exchanged

between the smart meter and the energy distribution

server.

4 PERFORMANCE ANALYSIS

In this section, we analyze the security of our solution

while showing its performance and robustness during

resistance against various attacks targeting the smart

grid. Then, we present the reliability and efﬁciency

of our solution compared to the solutions presented in

the literature in terms of cost of communication and

computation.

4.1 Security Analysis

In this subsection, we analyze attacks targeting the

smart grid, and try to show the advantages and re-

liability of our solution concerning the ﬁght against

these types of attacks.

4.1.1 Replay Attack

This is an attack in which a malicious participant in-

tercepts and then replays a valid data transmission

over a network (Das et al. 2019). Due to the valid-

ity of the original data, which generally comes from

an authorized participant, network security solutions

treat this type of attack as if it were a legitimate data

transmission. We remedy this type of attacks in our

solution by using randomly generated numbers (ε, D)

and time stamps (S, S *, S”),which are different for

each communication. In this case, our solution will

detect any replay of a data transmission, so a mali-

cious participant has no way to execute this type of

attacks.

A Novel Anonymous Authentication and Key Agreement Scheme for Smart Grid

359

4.1.2 Perfect Forward Secrecy

This is a key agreement property which ensures that

session keys cannot be compromised if the private key

of the power distribution server is compromised. In

our security scheme, we generate a unique session key

Key Agreement = h

(ε k E’ k D’) = h

(ε’ k E* k D) for

each communication session between the smart meter

and the energy distribution server. Here, the compro-

mise of a single session key will only affect the data

exchanged during the session encrypted by the key in

question.

4.1.3 Ensuring Smart Meter Anonymity

This is a property that allows a smart meter to prove

its identity without revealing any sensitive data that

can identify it (McDonald et al. 2019). We verify

this property in our scheme by protecting the login

(pseudo) of the smart meter with an irreversible hash

function h

(.) and encapsulating it in the following

parameters: E =h

(pseudo k y) ; N= E ⊕ h1(β k

pseudo) and K= h

(E k β k pseudo). In this way, a

malicious participant has no way of having y and β in

order to obtain information about the login (pseudo)

of the smart meter.

4.1.4 Insider Attack

This is a malicious attack that perpetrates on a net-

work by a participant with authorized access to the

system (Gusrialdi et al. 2019). In our solution, we

ﬁght against this type of attacks through the calcula-

tion of β = h

(passwd k λ). We note here that we

apply the hash function h

() on the concatenation of

the smart meter password (passwd) with a randomly

generated number λ. In this case, a malicious partic-

ipant has no way to calculate the reciprocal function

()

−1

to successfully apply this type of attacks.

4.1.5 Man in the Middle

This is an attack by which a malicious participant

gains access to communications between the smart

meter and the power distribution server, without either

of these parties being aware of it (Fritz et al. 2019).

We contain this type of attack in our security scheme

by using randomly generated numbers ε and D and

by the secret key y of the energy distribution server.

In this case a malicious participant will not be able to

generate whatsoever falsiﬁed communications when

sending < ν = (pseudo’ k µ k ε)

mod r ; N= E ⊕

(β k pseudo); S > to the energy distribution server

during the identiﬁcation phase or when sending < U=

(E’ k D) ; W= D ⊕ ε’ > during the authentication

phase.

4.1.6 Password Guessing Attack

In this type of attacks a malicious participant seeks to

ﬁnd a way to recover the password (passwd) of the

smart meter when sending parameters < N ; S ; ν >

and < U ;W ;S”> during the identiﬁcation and au-

thentication phases. In our scheme, we ﬁght against

this type of attacks by using the following parameters:

β = h

(passwd k λ) ; E =h

(pseudo k y) ; K= h

(E k β

k pseudo). In this case, a malicious participant has no

way to ﬁnd (passwd) because he should have both (λ

; pseudo ; y) to be able to calculate the hash function

4.1.7 Session Key Discloser Attack

In our scheme, we remedy this type of attacks by us-

ing Key Agreement = h

(ε k E’ k D’) = h

(ε’ k E* k D)

generated to ensure the security of all exchanged com-

munications between the smart meter and the power

distribution server. We note that this key agreement

is variable for each session; thanks to the arbitrarily

generated numbers. This key agreement is therefore

robust because it is generated from (pseudo) where it

is transmitted encrypted in the network ν = (pseudo

k µ k ε)

mod r. Thus, a malicious participant has no

way to ﬁnd the key agreement because he must have

both the decryption key y, the pseudo of the smart me-

ter as well as the randomly generated numbers.

Table 1 illustrates the security analysis of our ap-

proach with other approaches presented in the litera-

ture.

4.2 Performance Evaluation of Our

Proposed Scheme

In this last sub-section, we carry out various experi-

ments in order to illustrate the performance and effec-

tiveness of our solution compared to other approaches

in the same context as ours in terms of communication

and computation costs. In what follows, we describe

the details of the experiments that we perform as well

as their results.

After completing our experiments, we obtain the

following two ﬁgures Figure 1.a and Figure 1.b.

These latter present the number of bits used by our

scheme and the other schemes presented in the litera-

ture while sending and receiving data. From these two

ﬁgures, we can say that our approach surpasses all its

competing approaches in terms of cost and number of

bits used during communications (sent / received).

SECRYPT 2020 - 17th International Conference on Security and Cryptography

360

Table 1: Security analysis.

Security Properties [8] [9] [10] [11] [12] Ours

Secure against replay attack X X X X X X

Ensures perfect forward secrecy X X × X X X

Ensures anonymity of smart meter X X X X × X

Secure against insider attack × × X X × X

Secure against man-in-the-middle attack X X × × X X

Secure against password guessing attack × × X X × X

Secure against session key discloser attack X X × X X X

(a) The number of bits used during communications sent (b) The number of bits used during communications received

Figure 1: The number of bits used during communications (sent / received) between the smart meter and the power distribution

server.

Table 2 shows the calculation cost used by our so-

lution compared with the other competing solutions

presented in the literature. We note that in Table 2,

(Tm) indicates the execution time used to ensure the

multiplication operations, (Ted) denotes the execution

time used to ensure encryption and decryption steps,

(Th) designates the execution time used for the hash

function, (Tbp) represents the execution time used for

the bilinear pairing funtion, (Tadd) denotes the exe-

cution time used to ensure the the addition operations

and (Texp) indicates the execution time used to en-

sure the exponentiation operations. This table clearly

demonstrates that our security scheme is better than

its competitors in terms of cost of calculation.

Table 2: Total computational cost of our solution compared

to the solutions presented in the literature.

Schemes Total Computational Cost

[8] 4Tm + 8Th

[9] 6Tm+ 4Ted + 4Tmac + 9Th

[10] 7Tm + 2Tadd + 2Tbp + 2Texp + 10Th

[11] 5Tm + 6Tadd + 2Tbp + 2Texp +12Th

[12] 10Tm + 3Tadd + 11Th

Ours 2Texp + 8Th

In this last section, we can conclude that our proposed

security scheme outperforms all of its competitors in

terms of communication and computation costs and

can be easily checked against all the different attacks

targeting the smart grid.

5 CONCLUSION

In this paper, we have devised an approach with the

capacity to ensure the security of the smart grid tech-

nology against any attack aimed at their deployment.

In fact, by the presentation of the different experimen-

tal results, we can say that the solution we have pro-

posed surpasses all its competing solutions in terms of

ﬁght against the different attack scenarios presented

previously and in terms of computation and commu-

nication costs. This is due to the fact that our solution

has resorted to the use of light cryptographic func-

tions in order to ensure a strong security of all the data

exchanged between the energy distribution server and

the smart meter with a lower cost.

REFERENCES

Raza, N., Akbar, M. Q., Sooﬁ, A. A., & Akbar, S. (2019).

Study of smart grid communication network archi-

tectures and technologies. Journal of Computer and

Communications, 7(3), 19-29.

A Novel Anonymous Authentication and Key Agreement Scheme for Smart Grid

361

Bagdadee, A. H., & Zhang, L. (2019). Smart Grid: A Brief

Assessment of the Smart Grid Technologies for Mod-

ern Power System. Journal of Engineering Technol-

ogy, 8(1), 122-142.

Wang, Y., Chen, Q., Hong, T., & Kang, C. (2018). Review

of smart meter data analytics: Applications, method-

ologies, and challenges. IEEE Transactions on Smart

Grid, 10(3), 3125-3148.

Nguyen, D. H., Tran, H. N., Narikiyo, T., & Kawanishi,

M. (2019). A distributed optimization method for op-

timal energy management in smart grid. In Energy Ef-

ﬁciency in Smart Grids. IntechOpen.

Avancini, D. B., Rodrigues, J. J., Martins, S. G., Rab

elo, R.

A., Al-Muhtadi, J., & Solic, P. (2019). Energy meters

evolution in smart grids: A review. Journal of cleaner

production, 217, 702-715.

Romdhane, R. B., Hammami, H., Hamdi, M., & Kim, T. H.

(2019, June). A novel approach for privacy-preserving

data aggregation in smart grid. In 2019 15th Interna-

tional Wireless Communications & Mobile Comput-

ing Conference (IWCMC) (pp. 1060-1066). IEEE.

Romdhane, R. B., Hammami, H., Hamdi, M., & Kim, T.

H. (2019, June). At the cross roads of lattice-based

and homomorphic encryption to secure data aggrega-

tion in smart grid. In 2019 15th International Wire-

less Communications & Mobile Computing Confer-

ence (IWCMC) (pp. 1067-1072). IEEE.

Garg, S., Kaur, K., Kaddoum, G., Rodrigues, J. J., &

Guizani, M. (2019). Secure and Lightweight Authen-

tication Scheme for Smart Metering Infrastructure in

Smart Grid. IEEE Transactions on Industrial Infor-

matics.

P. Kumar, A. Gurtov, M. Sain, A. Martin, and P. H. Ha,

“Lightweight Authentication and Key Agreement for

Smart Metering in Smart Energy Networks,” IEEE

Transactions on Smart Grid, vol. 10, no. 4, pp.

4349–4359, 2019.

Tsai, J. L., & Lo, N. W. (2015). Secure anonymous key dis-

tribution scheme for smart grid. IEEE transactions on

smart grid, 7(2), 906-914.

Odelu, V., Das, A. K., Wazid, M., & Conti, M. (2016). Prov-

ably secure authenticated key agreement scheme for

smart grid. IEEE Transactions on Smart Grid, 9(3),

1900-1910.

He, D., Wang, H., Khan, M. K., & Wang, L. (2016).

Lightweight anonymous key distribution scheme for

smart grid using elliptic curve cryptography. IET

Communications, 10(14), 1795-1802.

Das, A. K., & Zeadally, S. (2019). Data Security in the

Smart Grid Environment. In Pathways to a Smarter

Power System (pp. 371-395). Academic Press.

McDonald, N., Hill, B. M., Greenstadt, R., & Forte, A.

(2019, May). Privacy, anonymity, and perceived risk

in open collaboration: A study of service providers. In

Proceedings of the 2019 CHI Conference on Human

Factors in Computing Systems (pp. 1-12).

Gusrialdi, A., & Qu, Z. (2019). Smart grid security: At-

tacks and defenses. In Smart grid control (pp. 199-

223). Springer, Cham.

Fritz, J. J., Sagisi, J., James, J., St Leger, A., King, K., &

Duncan, K. (2019). Simulation of Man in the Middle

Attack On Smart Grid Testbed. Proceeding of 2019

IEEE SoutheastCon.

SECRYPT 2020 - 17th International Conference on Security and Cryptography

362
