Security Analysis of ElGamal Implementations

Mohamad El Laz, Benjamin Gr

egoire and Tamara Rezk

Inria Sophia-Antipolis M

editerran

ee, France

Keywords:

ElGamal, DDH Assumption, Quadratic Residues, Voting Systems, Message Encoding.

Abstract:

The ElGamal encryption scheme is not only the most extensively used alternative to RSA, but is also almost

exclusively used in voting systems as an effective homomorphic encryption scheme. Being easily adaptable to

a wide range of cryptographic groups, the ElGamal encryption scheme enjoys homomorphic properties while

remaining semantically secure. This is subject to the upholding of the Decisional Difﬁe-Hellman (DDH)

assumption on the chosen group. We analyze 26 libraries that implement the ElGamal encryption scheme

and discover that 20 of them are semantically insecure as they do not respect the Decisional Difﬁe-Hellman

(DDH) assumption. From the ﬁve libraries that do satisfy the DDH assumption, we identify and compare four

different message encoding and decoding techniques.

1 INTRODUCTION

Throughout the last century, especially with the be-

ginning of public key cryptography due to Difﬁe-

Hellman (Difﬁe and Hellman, 1976), many crypto-

graphic schemes have been proposed. Their security

depends on mathematically complex problems such

as integer factorization and discrete logarithm. In

fact, it is thought that a cryptographic scheme is se-

cure if it resists cryptographic attacks over a long pe-

riod of time. On one hand, since certain schemes

may take several years before being widely studied in

depth, they become vulnerable as time passes. On the

other hand, a cryptographic scheme is a provable one,

if it resists cryptographic attacks relying on mathe-

matical hypothesis. Being easily adaptable to many

kinds of cryptographic groups, the ElGamal encryp-

tion scheme enjoys homomorphic properties while re-

maining semantically secure (Goldwasser and Micali,

1982), provided that the Decisional Difﬁe-Hellman

(DDH) assumption holds on the chosen group. While

the homomorphic property forbids resistance against

chosen ciphertext attacks, it is very convenient for

voting systems (Cortier et al., 2015).

The ElGamal encryption scheme (ElGamal, 1985)

is the most extensively used homomorphic encryption

scheme for voting systems (see also Paillier (Paillier,

1999)). Moreover, ElGamal is the only homomorphic

encryption scheme implemented by default in many

hardware security modules (Volkamer, 2009; Orr and

Liam, 2016). In order to be provably secure, the El-

Gamal encryption needs to be implemented on top

of a group verifying the Decisional Difﬁe-Hellman

(DDH) assumption. Since this assumption does not

hold for all groups, one may have to wrap an encod-

ing and a decoding phase to ElGamal to be able to

have a generic encryption scheme. In this paper, our

main goal is to study ElGamal encryption scheme li-

braries to identify which implementations respect the

DDH assumption.

We manually analyze the source code of 26

libraries that implement the ElGamal encryption

scheme in the wild. We focus our analysis on under-

standing whether the DDH assumption is respected

in these implementations, ensuring a secure scheme

in which no information about the original message

could be leaked. The DDH assumption is crucial

for the security of ElGamal because it ensures indis-

tinguishability under chosen-plaintext attacks (IND-

CPA). Without a group satisfying the DDH assump-

tion, encryption mechanisms may leak one bit of in-

formation about the plaintext and endanger the secu-

rity of the electoral system, thus threatening the pri-

vacy in an election. For instance, when considering an

approval ballot with a yes or no vote, leaking one bit

of information signiﬁes a full leakage of the vote. One

way to comply with the DDH assumption is by using

groups of prime order. In particular, when adopting

safe primes, one can ensure the existence of a large

prime order subgroup (Milne, 2011) and restrict mes-

sages to belong to this subgroup. Mapping plaintexts

into subgroups is called message encoding. Such en-

coding necessitates to be efﬁcient and precisely in-

vertible to allow decoding after the decryption.

310

El Laz, M., Grégoire, B. and Rezk, T.

Security Analysis of ElGamal Implementations.

DOI: 10.5220/0009817103100321

In Proceedings of the 17th International Joint Conference on e-Business and Telecommunications (ICETE 2020) - SECRYPT, pages 310-321

ISBN: 978-989-758-446-6

In Table 1, we give an overview of our results : out

of 26 analyzed libraries, 20 are wrongly implemented

because they do not respect the conditions to achieve

IND-CPA security under the DDH assumption. This

means that encryptions using ElGamal from any of

these 20 libraries leak one bit of information (see Sec-

tion 4).

From the 6 libraries which respect the DDH as-

sumption, we also study and compare various encod-

ing and decoding techniques. We identify four differ-

ent message encoding and decoding techniques sum-

marized in Table 2. Finally, we discuss the different

designs and conclude which implementation is more

efﬁcient for voting systems.

2 RELATED WORK

The ElGamal Scheme. The ElGamal encryption

scheme was introduced in 1985 by Taher ElGamal

(ElGamal, 1985). It relies on Difﬁe-Hellman key ex-

change and is known to be semantically secure un-

der the Decisional Difﬁe-Hellman (DDH) assumption

where the discrete logarithm problem is hard to solve.

In 2009, Barthe et al. (Barthe et al., 2009) proved

that the ElGamal encryption scheme is secure against

chosen-plaintext attacks (CPA) in the standard model

assuming that the DDH problem is hard in the under-

lying group family by using the proof assistant Coq.

The Cramer-Shoup cryptosystem (CS) (Cramer and

Shoup, 1998) was developed by Ronald Cramer and

Victor Shoup in 1998. It is a generalization of ElGa-

mal’s protocol and is provably secure against adap-

tive chosen ciphertext attacks (CCA), under the DDH

assumption. Even though it is a modiﬁed version

of ElGamal, the Cramer-Shoup cryptosystem cannot

be used however as a substitute of ElGamal in vot-

ing systems. In fact, being resistant to CCA results

in losing the homomorphic property of the scheme,

which is fundamental for voting systems. In 2006,

Beno

ıt Chevallier-Mames et al. (Chevallier-Mames

et al., 2006) proposed an ElGamal encryption alter-

native, using a new encoding-free technique. Their

approach holds better performance than plain ElGa-

mal without the necessity to map the message into

a subgroup. The authors introduce the notion of the

class function based on the difﬁculty of the Deci-

sional Class Difﬁe-Hellman (DCDH) assumption. An

essential improvement of the Encoding-Free version

scheme is to avoid message conversion, providing a

wider message space. ElGamal encoding-free is IND-

CPA. However, to date, it is not known how to iden-

tify whether a group satisﬁes the DCDH assumption

or not.

Semantic Security. The mental poker (Rivest et al.,

1979) is the ﬁrst protocol known to be vulnerable to

attacks because its encryption scheme does not re-

spect the DDH assumption. The game of mental

poker is an ordinary poker game and communications

between players are done via messages since it is a

game without physical cards. Being exposed to at-

tacks, the mental poker game can leak one bit of in-

formation about the cards by observing whether the

encryption scheme preserves the quadratic residuosity

of a number (Lipton, 1981). Consequently, in 1982,

Goldwasser and Micali introduced the ﬁrst probabilis-

tic public-key encryption scheme (Goldwasser and

Micali, 1982) which is provably secure under stan-

dard cryptographic assumptions. It is based on the

intractability of Quadratic Residuosity Assumption

modulo a composite n. Considering that the distribu-

tion of quadratic residues and quadratic non-residues

is not the same, one restricts oneself to a subset where

the number of quadratic residues is equal to the num-

ber of quadratic non-residues, and takes only the mes-

sages that are quadratic residues to prevent an attacker

from gaining any information about the original mes-

sage.

Encoding Mechanisms. What we call message encod-

ing refers to the mechanism that maps a message into

a speciﬁc group. An approach to encode a message is

the hash-ElGamal encoding. This scheme consists of

including a hash function during the encryption pro-

cess. Let h : G → {0, 1}

,w → h(w) be a hash func-

tion mapping elements to l-bit strings. The encryption

of a message m ∈ M where the message space is de-

ﬁned as M = {0,1}

is then given by (g

,m ⊕ h(y

)).

This encoding mechanism solves the problem of leak-

ing information about the original message but un-

fortunately, it cannot be used for voting systems as

it loses its homomorphic property. Another option

to encode messages is exponent-ElGamal encoding

(Cramer et al., 1997). This technique takes advantage

of a property where any element w ∈ G =< g > is

uniquely represented as w = g

for some z ∈ Z/qZ.

For any message m ∈ Z/qZ, the resulting encod-

ing is g

. The corresponding ciphertext is given by

) = (g

). In this case, the problem is in

the decryption process: to retrieve the original mes-

sage, the computation of the discrete logarithm in G

is needed. Considering that the discrete logarithms

are hard to solve in G, this leads to limit the message

space to a small set where the discrete logarithm prob-

lem is easy to solve by using brute force or Pollard’s

rho algorithm (Pollard, 1978).

Elliptic curve ElGamal is a different variant where

a message m is represented as a point on an elliptic

curve, more accurately, as a point on a prime order

Security Analysis of ElGamal Implementations

311

subgroup. Elliptic curve cryptography (Koblitz et al.,

2000; Miller, 1985) offers smaller key sizes resulting

in gains in speed and memory, and beneﬁts of the ab-

sence of sub-exponential algorithms that solve the el-

liptic curve discrete logarithm problem. However, en-

codings (Farashahi, 2014; Fadavi et al., 2018; Bern-

stein et al., 2013) mostly do not handle prime-order

elliptic curves as there is no known polynomial time

algorithm for ﬁnding a large number of points on an

arbitrary curve. Furthermore, several encodings are

hash-to-curve that are not invertible and therefore not

compatible with group operation which destroys the

homomorphic property (Faz-Hernandez et al., 2019).

Application to E-voting. We brieﬂy discuss elec-

tronic voting systems that use ElGamal encryption.

To get familiar with voting systems, we refer the in-

terested reader to (Ne Oo and Aung, 2014; Cortier

et al., 2016; Volkamer, 2009). E-voting systems are

important as they expand the participation of voters

and offer an efﬁcient way to count votes. However,

without employing secure systems, the use of voting

systems would be meaningless. E-voting uses public-

key cryptography: ElGamal is the most common used

encryption algorithm as it enjoys multiplicative ho-

momorphic properties that allows the addition on the

ciphertexts in order to count ballots without reveal-

ing the identity of the voters. Additionally, ElGamal

enables re-encryption which results in a different ci-

phertext containing the same information. (Paillier

encryption scheme (Paillier, 1999) is a possible op-

tion as well, relying on the DCR assumption). Vari-

ous studies demonstrated the importance of ElGamal

as an encryption scheme for electronic voting sys-

tems (Haines et al., 2019; Adida, 2008). Addition-

ally, several countries (e.g. Estonia (Kubjas et al.,

2017), Norway (Puigalli and Guasch, 2012) and Rus-

sia (Babenko et al., 2017)) are using e-voting systems

as a main mechanism for elections and are employing

ElGamal to count and verify votes. Moreover, in a

note of 15 November 2019, Pierrick Gaudry (Gaudry,

2019) reveals an attack about the Moscow voting sys-

tem because it does not comply with the DDH as-

sumption.

3 BACKGROUND

3.1 Notions and Preliminaries

The ElGamal encryption scheme is known to be IND-

CPA secure under the decisional Difﬁe-Hellman as-

sumption. In this section we recall some basic deﬁni-

tions and notations that will be used throughout this

paper.

Deﬁnition 3.1 (Decisional Difﬁe-Hellman)

Given two distributions DDH

= (g

)

and DDH

= (g

) where x,y,z are randomly

distributed in Z

, a cyclic group with generator g. It

is hard to distinguish between DDH

and DDH

An encryption scheme is said to be IND-CPA se-

cure if a polynomial time adversary choosing two

plaintexts cannot distinguish between the resulting ci-

phertexts. If the adversary can distinguish between

the ciphertexts better than guessing blindly, we say

that the adversary achieves an advantage. The advan-

tage of any efﬁcient adversary is expressed as a negli-

gible function of the security parameter in the formal

deﬁnition of IND-CPA . For ElGamal, the security pa-

rameter is the key length.

To satisfy IND-CPA, an encryption scheme must

necessarily be probabilistic, otherwise an adversary

could trivially detect which message corresponds to

the challenge ciphertext by simply encrypting one of

the messages it has chosen and compare the resulting

ciphertext with the challenge ciphertext.

3.2 The ElGamal Encryption Scheme

ElGamal (ElGamal, 1985) is an asymmetric encryp-

tion scheme, it enjoys homomorphic properties that

are fundamental for the electronic voting systems. El-

Gamal scheme (see Algorithm 1) consists of three al-

gorithms: key generation(η), η being a security pa-

rameter, encryption E(m, pk) with m being a plaintext

and pk a public key, and decryption D(c,sk) where c

is a ciphertext and sk is a private key.

Algorithm 1: ElGamal Scheme.

K G: Pick randomly a secret key x ∈ Z

, then

compute y = g

to obtain the public key.

E(m): Let m ∈ G and r ∈ Z

randomly selected.

The resulting ciphertext is c = (u, v) = (g

,m.y

D(c): To recover the plaintext, one computes

m = v · u

−x

3.3 Security of ElGamal

A key point for the security of the ElGamal encryp-

tion scheme resides in the group G and its order. One

should start by generating a pair of keys (public and

private), then map the message into a group where the

Decisional Difﬁe-Hellman assumption holds. Hence,

the difﬁculty consists in ﬁnding an efﬁcient invert-

ible group encoding procedure so that one can recover

the original message when decrypting. The ElGamal

cryptosystem operates in a ﬁnite cyclic group, which

SECRYPT 2020 - 17th International Conference on Security and Cryptography

312

by convention is written multiplicatively. For the sake

of simplicity, we will restrict our discussion to the

group of integers from {1} to {p − 1} under mul-

tiplication mod p for some prime p, commonly de-

noted Z

∗

and subgroups of Z

∗

of prime order. More-

over, we will also use |g| to denote the order of an

element g in Z

∗

and < g > to denote the cyclic sub-

group of Z

∗

generated by g. Unless otherwise noted,

assume multiplications and exponentiations involving

elements of Z

∗

are done mod p. As if all subgroups

of a cyclic group are cyclic and if G =

is cyclic,

then for every divisor d of |G| there exists exactly one

subgroup of order d which may be generated (Rot-

man, 1999). One may rely on this property to form a

unique subgroup of quadratic residues elements. To

achieve this goal, the idea is to use a Sophie Ger-

main prime (Pollard, 1978): it is a safe prime p of

the form 2q + 1 where q is also prime. Safe primes

of that form are important for modulo groups as they

guarantee the existence of a subgroup of prime order.

For ElGamal, using a safe prime p, where the order

is p−1 = 2q permits to form a subgroup of prime or-

der q that forms the message space we need in order

to encrypt messages. One may take advantage of the

Lagrange theorem (Pollard, 1978) that states that in a

ﬁnite group G, the order of any subgroup H divides

the order of the group, to conclude that the prime or-

der subgroup has no subgroups being prime. Finally,

the message space must be restrained to this prime or-

der subgroup.

Quadratic Residues. To make the ElGamal cryp-

tosystem IND-CPA secure, the Decisional Difﬁe-

Hellman assumption must be respected. As a matter

of fact, one needs to ﬁnd which type of groups satis-

ﬁes the underlying assumption. A good technique is

to restrict the messages to form the subgroup of prime

order q of quadratic residues. In what follows we will

introduce further explanations and examples to better

understand the role of quadratic residues for the secu-

rity of the ElGamal encryption scheme.

Deﬁnition 3.2 (Quadratic Residue) An element a ∈

∗

is said to be a Quadratic Residue modulo n if there

exists x ∈ Z

∗

, such that x

≡ a(mod n). Every such x is

called a square root of a modulo n. If no such x exists,

then a is called a Quadratic Non-Residue modulo n.

We denote the set of all quadratic residues modulo n

by QR

and the set of all quadratic non-residues by

QNR

Quadratic residues are exactly those elements which

can be written of the form g

where i is even:

,...,g

p−1

} are distinct quadratic residues, while

{g,gg

,...,gg

p−1

} are quadratic non-residues. There

exists an efﬁcient algorithm based on Euler’s crite-

rion for deciding quadratic residuosity in Z

∗

, with p

prime:

Deﬁnition 3.3 (Euler’s Criterion) Let p be an odd

prime. Then a ∈ Z

∗

is a quadratic residue modulo p

iff a

p−1

≡ 1 (mod p).

Therefore, by restricting all the messages to be

Quadratic residues in a safe prime group, a polyno-

mial time adversary cannot distinguish between ele-

ments as all the elements are then quadratic residues.

Hereinafter, we will be using the Legendre symbol

based on Euler’s criterion for its convenient notation

that reports the quadratic residuosity of a mod p.

Deﬁnition 3.4 ( Legendre symbol) Let p be an odd

prime , a an integer, such that gcd(a, p) = 1. The

Legendre symbol (LS) is deﬁned to be





(

1 if a ∈ QR

-1 if a ∈ QNR

4 BREAKING ElGamal

Let p be a prime and g ∈ Z

∗

. Given a public key g

the ElGamal encryption scheme encrypts a message

m ∈ Z

by computing (g

,m.g

), with r chosen ran-

domly in Z

∗

. Using the private key x, decryption can

be done by ﬁrst computing (g

) and then dividing to

retrieve m. The cryptosystem is not semantically se-

cure when g is a generator of Z

∗

, as some informa-

tion about the plaintext is leaked. Speciﬁcally, the

Legendre symbol of (m.g

) uncovers the Legendre

symbolof the message m. In order to prove that ElGa-

mal is IND-CPA under the DDH assumption, one may

choose g to be the generator of the group in which

the DDH assumption holds and restrict the message

space to this group. This way, the system is seman-

tically secure as given (g

) and (g

), the secret value

) cannot be distinguished from a random element

in the group. Therefore, (m.g

) cannot be distin-

guished from a random element and an attacker can-

not learn any information about the original message.

In what follows, we will show an example on how to

break the DDH assumption and ElGamal encryption

scheme for Z

∗

groups.

Example 4.1 (Breaking the DDH Assumption)

In order to break the DDH assumption, one should

be able to distinguish between two distributions

having elements randomly distributed in a group.

Let p = 2q + 1 = 11 be the group on which we want

to perform the attack (to ease the comprehension of

the example, we consider small parameters size and

Security Analysis of ElGamal Implementations

313

not secure). Being prime, p has {p − 1} elements,

half being quadratic residues (QR) and the other

half being quadratic non-residues (QNR). Given a

tuple (g

) it is hard to decide whether c = xy

or c = z, where z is randomly generated. By LS, we

can check the quadratic residuosity of the elements

, g

and g





= 1 if x is a square (i.e., quadratic

residue), then





= 1 if x is even. Therefore, g

quadratic residue if x is a quadratic residue too. In

addition, if x or y are even, then xy is even and g

is quadratic residue. Taking advantage of all the

before-mentioned notions, we will give a detailed

example on how to break the DDH assumption. A

tuple is a valid DDH tuple if xy ≡ c mod p and can

be written as (g

Let p = 11, the challenge is to distinguish whether

(4,5,9) is DDH

or DDH

in G

. For Euler’s crite-

rion, a ∈ Z

∗

is a QR iff a

p−1

≡ 1 (mod p).

≡ 1 mod11 5

≡ 1 mod11 9

≡ 1 mod11

By testing the quadratic residuosity of the three el-

ements, one can notice that all of them are quadratic

residues. In this case, we cannot distinguish be-

tween xy and z. Since the multiplication between two

elements that are quadratic residues, results in an

quadratic residue element, it might be that the third

element of the tuple belongs to DDH

or DDH

. Con-

sequently, we are not able to break the DDH assump-

tion.

In this second example, the challenge is to distin-

guish whether (4,5,8) is (g

) or (g

) in

≡ 1 mod11 5

≡ 1 mod11 8

6≡ 1 mod11

One can notice that the third element of the tuple

is not a quadratic residue. Being both quadratic

residues, the multiplication between g

= 4 and g

= 5

must result in an quadratic residue element. However,

= 8 results being a non quadratic residue element.

In this case, we are able to distinguish between xy

and z by ensuring that (4,5, 8) is DDH

and break

the DDH assumption as a consequence. We empha-

size on the importance of choosing a safe prime group

p, to be able to work in the subgroup of prime order

q by restricting the elements to form the subgroup of

quadratic residues. This guarantees the difﬁculty of

such attacks on the DDH assumption.

Example 4.2 (Breaking the ElGamal Scheme using

a QR Generator) Being in a group in which the DDH

does not hold may leak information about the original

plaintext. An attacker able to calculate the quadratic

residuosity of an encrypted message, can learn one

bit of information about the original message. An at-

tacker can check whether the encryption of a message

is a QR or not and therefore deduce whether the orig-

inal message is a QR too. In fact, by taking g

∈ QR

and encrypting the message as E (m,k) = (g

,m.g

one can notice that if m.g

∈ QR then m ∈ QR.

Consider the group G

, let x = 4 ∈ sk, r = 2 ∈ rnd,

g = 3 ∈ QR and y = g

= 4 ∈ pk.

In the above example, the group G

has

{1,3,4,5,9} as a subgroup of quadratic residues. Ac-

tually, encrypting a message m ∈ QR with a public key

pk ∈ QR, results always in an encryption E(m,k) ∈

QR. Thus, by using G

and taking messages belong-

ing to its entire message space, one endangers the se-

curity of the scheme as he allows QR and QNR mes-

sages to be encrypted. An attacker able to calculate

the quadratic residuosity of an element could learn

one bit of information about the original message by

performing the following attack:

(a) g ∈ QR, then (g

) is QR.

(b) Check if



E(m,k)



is QR or not.



E(m,k)



∈ QR, the attacker can learn that the

message m ∈ QR, as the multiplication between

QR elements result always in a QR element.

(d) If



E(m,k)



∈ QNR, then the attacker can learn that

the message m ∈ QNR.

Let us check E (1,5) = (9,5):

(a)





= 1 ⇒ g ∈ QR,





= 1 ⇒ (g

) ∈ QR.

(b)





= 1 ⇒ E(1, 5) ∈ QR.

∈ QR leaks the quadratic residuosity

of m. In fact





= 1 ⇒ m ∈ QR.

The previous example could also be adopted for QNR

messages. In summary, the feasibility of calculating

the quadratic residuosity of an element in a modulo

prime groups, may leak information about the orig-

inal message on top of groups that do not respect

DDH.

5 STUDY OF LIBRARIES

We focus our study on manually checking whether

the underlying groups in ElGamal implementations

satisfy the Decisional Difﬁe-Hellman assumption. A

summary of our results regarding 26 analyzed li-

braries can be found in Table 1.

We split our work into three tasks to measure the

correctness of the implementations. We ﬁrst ver-

ify that the implementations use safe primes, next

we check if they adopt quadratic residue generators

SECRYPT 2020 - 17th International Conference on Security and Cryptography

314

to generate subgroups in which the DDH assump-

tion holds. Finally, we analyze the message encod-

ing techniques deployed to map the messages into the

before-mentioned subgroups. This study led us to no-

tice that a large number of the considered libraries

are not IND-CPA secure as the encryption may leak

at least one bit of information on the plaintext: 20

libraries do not respect the DDH assumption. More-

over, among these 20 libraries, 10 do not use a safe

prime. In what follows, we describe in details the

problems found in the investigated libraries using the

following classiﬁcation:

(A) Libraries that do not respect the DDH assump-

tion. There are 20 libraries in this category. In

this class we further classify the libraries that do

not respect the DDH assumption due to 3 dif-

ferent concerns: libraries that do not deploy a

safe prime, libraries that do not adopt a quadratic

residue generator, and libraries that do not use a

correct message encoding technique to map the

messages into the intended subgroup.

(B) Libraries that do respect the DDH assumption.

There are 6 libraries in this category. However,

they do not all use the same encoding technique.

Thus, we describe in detail the 4 different encod-

ing techniques, discussing their advantages and

drawbacks.

Libraries’ Relevance. This paper will provide a brief

description on the relevance of some of the chosen

libraries for analysis. Belenios (Belenios, 2016) has

been deployed on an online platform and it is used in

more than 200 elections, both in academia and in ed-

ucation. Similarly, Helios (Helios, 2008) is used for

the election of the International Association for Cryp-

tographic Research members board, the ACM general

elections, the election of UCLouvain president and for

other student elections. On the other hand, the Esto-

nian voting system (Estonia, 2017) has been used for

the European Parliament elections, local government

council elections and the election of the president of

the Republic. Swisspost (Swisspost, 2018) then offers

voting system services for cantons and municipalities

in Switzerland, while Veriﬁcatum (Veriﬁcatum, 2017)

is used in binding elections, student body elections

and intra-party elections.

5.1 Libraries That Do Not Respect

DDH

In this section, we will present the implementations

that do not respect the conditions to achieve an IND-

CPA secure ElGamal scheme. Working on groups

modulo p, a secure ElGamal scheme has to adopt safe

primes, a quadratic residue generator, and a message

encoding technique to map the messages into a sub-

group that respects the Decisional Difﬁe-Hellman as-

sumption. Twenty out of twenty six libraries violate

one or more of the before-mentioned conditions: all

the libraries in this section do not employ message

encoding techniques.

Lack of Safe Prime. In this category, 10 libraries

(Diaz, 2017; Alves, 2015; Sidorov, 2016; Lee, 2017;

Wang, 2017; Pankratiew, 2018; Pellegrini, 2017;

Musat, 2017; Libgcrypt, 2013; Moscow, 2019a) do

not use safe primes. Instead, these implementations

focus on generating large numbers and checking their

primality. This method does not guarantee the gen-

eration of a safe prime. In fact, a safe prime of the

form p = 2q + 1 where q is also a large prime, is es-

sential as it forms a large prime subgroup of order q.

Conversely, using an arbitrary large prime results in a

p − 1 group order, that can be decomposed into small

prime order subgroups. Hence, small prime order

subgroups are exposed to subgroup attacks in which

the discrete logarithm is easy to compute by using

the Pohlig-Hellman algorithm (Pohlig and Hellman,

1978) or the Pollard’s rho algorithm (Pollard, 1978).

Lack of QR Generators. In this category, we dis-

cuss the libraries that do not use quadratic residue

generators. Among the 20 libraries that do not re-

spect DDH, 5 libraries (Nasr, 2015; Ridhuan, 2016;

Elgamir, 2016; Pycrypto, 2012; Ioannou, 2014) use a

safe prime p = 2q + 1 but do not choose a quadratic

residue generator. Using a safe prime without a

quadratic residue generator does not guarantee a sub-

group of prime order q in which the DDH assumption

stands. In what follows we show an example on the

feasibility of learning information about the plaintext

when we do not employ a quadratic residue generator.

Example 5.1 (Breaking ElGamal without a QR

generator) To break ElGamal without a QR gener-

ator, it is sufﬁcient to break the underlying assump-

tion. The DDH assumption does not hold in Z

∗

if g

is a generator of Z

∗

. This is because the Legendre

symbol of g

reveals whether a is even or odd. Given

), one can compute the LS and compare the

least signiﬁcant bit of a, b and ab, which allows to

distinguish between g

and a random element group.

Having a distinguisher against DDH means having

a distinguisher against ElGamal and therefore break

ElGamal.

Lack of Encoding. We point out the relevance of

message encoding mechanisms as a crucial require-

ment in ElGamal scheme. Despite generating a safe

prime and choosing a quadratic residue generator, 5

libraries (Botan, 2018; Riddle, 2014; Norvegia, 2017;

Pycryptodome, 2018; Swisspost, 2018) do not use a

Security Analysis of ElGamal Implementations

315

Table 1: An overview on the 26 analyzed libraries (where T1, T2, T3 and T4 are listed in Table 2).

Library Safe prime QR Generator Encoding Decoding DDH

Belenios (Belenios, 2016) X X T3 T3 Yes

Botan (Botan, 2018) X X 7 7 No

Cryptology (Nasr, 2015) X 7 7 7 No

Elgamal-api (Diaz, 2017) 7 7 7 7 No

ElGamal-cipher.py (Alves, 2015) 7 7 7 7 No

ElGamalExt (Sidorov, 2016) 7 7 7 7 No

ElGamal.h (Lee, 2017) 7 7 7 7 No

ElGamal.hs (Ridhuan, 2016) X 7 T3 T3 No

Elgamal.hpp (Wang, 2017) 7 7 7 7 No

Elgamal.java (Pankratiew, 2018) 7 7 7 7 No

Elgamal-lib.c (Pellegrini, 2017) 7 7 7 7 No

Elgamal.py (Musat, 2017) 7 7 7 7 No

Elgamal.py (Riddle, 2014) X X 7 7 No

Elgamir (Elgamir, 2016) X 7 7 7 No

Estonia (Estonia, 2017) X X T1 T1 Yes

Helios (Helios, 2008) X X T2 T2 Yes

Libgcrypt (Libgcrypt, 2013) 7 7 7 7 No

Microsoft (Microsoft, 2019) X X T3 T3 Yes

Moscow 07-19 (Moscow, 2019a) 7 7 7 7 No

Moscow 09-19 (Moscow, 2019b) X X T4 T4 Yes

Norway (Norvegia, 2017) X X 7 7 No

PyCrypto (Pycrypto, 2012) X 7 7 7 No

PyCryptodome (Pycryptodome, 2018) X X 7 7 No

RSA-ElGamal (Ioannou, 2014) X 7 7 7 No

Swisspost (Swisspost, 2018) X X 7 7 No

Veriﬁcatum (Veriﬁcatum, 2017) X X T1 T1 Yes

message encoding to map the messages into a valid

subgroup. However, by adopting the standard en-

cryption scheme of ElGamal, the message space is

not restricted to the expected subgroup. This imply

that even in the presence of a safe prime and con-

sequently the presence of a subgroup of prime order

generated by a quadratic residue generator, the mes-

sage to encrypt is not mapped into the designed sub-

group. Hence, an attacker can gain knowledge about

the original message and expose the entire scheme to

total insecurity. To better understand the importance

of using a message encoding method, we display an

attack on how to break a scheme that does not map

messages into the intended subgroup (see example in

Section 4).

5.2 Libraries That Do Respect DDH

In this section, we will present the implementations

that respect the DDH assumption and therefore imple-

ment an IND-CPA secure ElGamal scheme. As men-

tioned in the previous section, a well implemented li-

brary should adopt a safe prime, a quadratic residue

generator, and a message encoding technique. Only 6

out of the 26 analyzed libraries (Belenios, 2016; Es-

tonia, 2017; Helios, 2008; Microsoft, 2019; Moscow,

2019b; Veriﬁcatum, 2017) respect all of the previ-

ously mentioned conditions. In the following para-

graphs, we will discuss in detail the message encoding

techniques implemented in these libraries. In particu-

lar, we can categorize four different techniques.

5.2.1 Limited Message Space and

q-exponentiations

The Estonian and Veriﬁcatum. In this paragraph,

we will present two libraries that implement ElGa-

mal using the same technique: the Estonian voting

system and Veriﬁcatum. The Estonian government

relies on Internet voting in a signiﬁcant way for na-

tional elections. While the Estonian voting system

(Estonia, 2017) is implemented in Java, Veriﬁcatum

(Veriﬁcatum, 2017), which implements provably se-

cure cryptography libraries for electronic voting sys-

tems, is implemented in JavaScript. To comply with

the IND-CPA security of ElGamal, these two imple-

mentations adopt a safe prime, and generate the sub-

group of prime order in which the DDH assumption

SECRYPT 2020 - 17th International Conference on Security and Cryptography

316

holds. Both implementations allow messages m to be

any integer from [1, p − 1]. Hence, before encrypting,

one checks if m is a QR by checking m

≡ 1 mod p:

Proof 1 Euler’s criterion states that a ∈ Z

∗

is a

quadratic residue modulo p iff a

p−1

≡ 1 (mod p). Be-

ing q =

p−1

, then a

p−1

= a

≡ 1 (mod p).

If the equivalence is conﬁrmed then m is encrypted

as a QR, else the message is rejected and an error is

raised (see Listing 1). In fact, these two implementa-

tions take as an input messages in Z

∗

and rejects half

of the messages that are not QR instead of encoding

them (also see Helios in Subsection 5.2.2). Besides

that, using q-exponentiations to encrypt messages can

be optimized as we will explain in Section 6.



switch ( legendre (m)) {

case 1:

return new ModPGroupElement(this, m);

case −1:

throw new IllegalArgumentException(”Can not

encode as quadratic residue ”) ;

}

// Negate if not a quadratic residue .

var value = new LargeInteger (bytesToUse);

return new ModPGroupElement(this, value);

 

Listing 1: Limited space and q-exponentiations ElGamal

encoding (Veriﬁcatum, 2017).

5.2.2 Encoding with q-exponentiations

Helios. Helios (Helios, 2008), is a known library

implemented in Python. It is used for voting sys-

tems and can be manipulated to meet the needs of

the users. Helios, is vulnerable to ballot stufﬁng as

a dishonest bulletin board could add ballots without

anyone noticing (Belenios, 2016). Being IND-CPA

secure, ElGamal in Helios is implemented by gener-

ating a safe prime p = 2q + 1 where p and q are both

large primes. It then selects a generator g of the sub-

group of prime order q. Before encrypting a message

m, a mapping to the prime order subgroup is done. As

the implementation allows the message m to be any

integer from [0, p − 1], one computes m

= m + 1 (to

avoid picking m = 0) and checks whether m

is a QR.

If m

≡ 1 mod p then it outputs m

which belongs to

the QR elements (as in Subsection 5.2.1), else, it out-

puts −m

. Please note that −m

mod p belongs also

to the QR elements. Being a safe prime p and p ≡ 3

mod 4, ensures the fact that 1 is a square element and

−1 is a non-square element. This is essential in turn-

ing a non-square element m into a square element −m.

After decryption, one obtains m and checks if m ≤ q.

If m ≤ q then m

= m otherwise m

= −m. To recover

the message, one computes m = m

− 1 (see Listing

2).

Proof 2 This is because x

≡ (−x)

mod p. So the

squares of the ﬁrst half of the nonzero numbers mod p

give a complete list of the nonzero quadratic residues

mod p. If p is an odd prime, the residue classes of

,...,(

p−1

)

} are distinct and give a complete

list of the quadratic residues modulo p. So there are

p−1

residues and

p−1

non-residues. This gives a com-

plete list as x

and (p − x)

are equivalent mod p:

≡ y

mod p ⇔ p|x

− y

⇔ p|(x − y)(x + y)

⇔ p|(x − y) or p|(x + y)

which is impossible if x and y are two different mem-

bers of the set.

As we will see in the Section 6, it is possible to re-

duce to 2 the q-exponentiations, and therefore obtain

a more efﬁcient encoding process.



if (encode m) {

var y = m.add(BigInt. ONE);

var test = y.modPow(pk.q, pk.p);

if ( test . equals ( BigInt .ONE)) {

this .m = y;

} else

this .m = y. negate () .mod(pk.p); }

 

Listing 2: ElGamal encoding with q-exponentiations

(Helios, 2008).

5.2.3 Hard Decoding

Belenios and Microsoft. Belenios (Belenios, 2016)

is a veriﬁable voting system built upon Helios. It can

be used to organize elections and perform veriﬁcation.

Contrary to Helios, Belenios provides eligibility ver-

iﬁability as anyone can check that ballots are coming

from legitimate voters: each voter receives a private

credential, while the election server receives only the

corresponding public credential. Therefore, even if

the election server is compromised, no ballot can be

added. Microsoft Election guard (Microsoft, 2019)

is a library that veriﬁes voting ballots. Concerning

ElGamal encryption scheme a message m is encoded

as g

where g is the QR generator of the prime order

subgroup: every element written in the form of g

be-

longs to the subgroup generated by g. The choice of

using the exponential version of ElGamal is to bene-

ﬁt from turning the multiplicative homomorphism of

ElGamal into an additive one. After decryption, one

should compute the discrete logarithm of g

in order

to recover the initial message m. This is possible by

using Pollard-lambda algorithm or brute force only if

m is taken from a small subset and not from the entire

interval {0,...,q − 1}. Being in a subgroup of prime

order q, where q is a large prime, it is not possible

Security Analysis of ElGamal Implementations

317

to decompose the subgroup in smaller subgroups (La-

grange Theorem (Pollard, 1978)) since the computa-

tion of the discrete logarithm is unfeasible in general

(see Listing 3).



type factor = elt partial decryption

let eg factor x {alpha; } =

let zkp = ”decrypt |” ˆ G. to string (g

˜ x) ˆ

”|” in

alpha

˜ x,

fs prove [| g; alpha |] x (hash zkp)

let check ciphertext c =

Shape. forall (fun {alpha; beta} −> G.check

alpha && G.check beta) c

 

Listing 3: Hard decoding implementation (Belenios,

2016).

5.2.4 Encoding with 2-exponentiations

Moscow Voting System. For the elections of

September 2019, the Russian government decided to

employ an electronic voting system (Moscow, 2019a)

to elect governors for local parliaments in Moscow. In

July 2019, the source code, developed by the Moscow

Department of Information Technology, was made

public to test its vulnerabilities. At that time, the

Moscow voting system was discovered to be sub-

jected to two attacks by researchers (Gaudry, 2019).

In the ﬁrst test, the researchers exploited the fact that

the keys used are small: three keys of 256 bits were

used. Discrete logarithms deﬁned by small primes

are easy to calculate in feasible time. Therefore, one

can compute the discrete logarithm and recover the

secret keys used for decryption. Moreover, one can

decrypt messages employing the same time as a legit-

imate possessor of secret keys. After reporting this

issue, the developers of Moscow voting system in-

creased the key size to 1024 bits. However, a sec-

ond test was made to verify the security of the mod-

iﬁed version. In this version, the message space was

not restricted to the subgroup of quadratic residues as

any message was allowed to be encrypted. By rely-

ing on subgroup attacks, one can get enough infor-

mation about the voter’s choice and indeed can reveal

one bit of information about the original message (see

Section 4). Therefore the Decisional Difﬁe-Hellman

assumption did not hold and the system leaked strong

information. Two days before the elections, the devel-

opers modify the source code (Moscow, 2019b) and

adopt an efﬁcient method to secure their voting sys-

tem. To map a message m into the QR subgroup, it is

sufﬁcient to square the message: m → m

(see Listing

4).

Proof 3 The quadratic residue theorem states that

a ∈ QR if ∃ x s.t. x

≡ a(p). Let m = x, then m

∈ QR

if m

≡ m

(p), which can be trivially satisﬁed.

After decryption, one obtains m by calculating its

modular square root: m = c

q+1

(Nishihara et al.,

2009). The algorithm computes the square root of c

iff p ≡ 3 mod 4, which is always the case when using

a safe prime. As a matter of fact, the underlying group

in this last version respects the DDH assumption. We

will discuss the adopted method in Section 6.



const sessionKey = trimBigInt (xoredRandomBigInt,

this . moduleP.bitLength() − 1);

const squaredData = dataAsBI.modPow(new BigInt('2

'), this .moduleP);

const a = this .generatorG.modPow(sessionKey, this

.moduleP). toString () ;

const b = this .publicKey

.modPow(sessionKey, this. moduleP)

. multiply (squaredData)

.remainder( this .moduleP)

. toString () ;

 

Listing 4: ElGamal encoding with 2-exponentiations

(Moscow, 2019b).

6 COMPARISON OF ENCODINGS

In the previous section, we have seen 4 different en-

coding techniques of ElGamal that comply with the

DDH assumption. In Table 2, we summarize the four

techniques by giving a general overview on the en-

coding and the decoding processes.

T1 The ﬁrst message encoding technique (T1)

checks whether a message m is a QR or not by

checking the following equivalence: m

≡ 1 (p).

If the equivalence holds, then the message is en-

crypted, otherwise an error is raised and the mes-

sage is rejected. The decoding operation is simple

as one outputs directly the message m.

T2 The second message encoding technique (T2)

uses the same method as the previous one, but

instead of raising an error and rejecting the mes-

sages, it maps the message as −m. For what

concerns the decoding process, one ﬁrst checks if

m < q and output m, otherwise it outputs −m.

T3 The third message encoding technique (T3) maps

a message m as g

. The decoding mechanism is

hard in general and can be only applied on a small

subset of messages in which the computation of

discrete logarithm can be solved by brute force.

T4 Concerning the fourth message encoding tech-

nique (T4), one maps a message m as m

into the

subgroup of order q. This squaring technique is

sufﬁcient to map any message as a QR element.

In addition, it is efﬁcient as it needs only 2 ex-

ponentiations for encoding any message. To de-

SECRYPT 2020 - 17th International Conference on Security and Cryptography

318

Table 2: Message Encoding Comparison.

T1: Limited msg space & q-expon. T2: q-expon. T3: m-expon. T4: 2-expon.

Encoding m

≡ 1 (p)? m : error m

≡ 1 (p)? m : −m g

Decoding m m < q ?: m : −m log

) m

q+1

code, one computes the square root by modular

exponentiation of m: m

q+1

to recover the original

message.

Whereas in T4, the encoding technique is faster

than T1 and T2 (2-exponentiations is more perfor-

mant than q-exponentiations as q is large), the de-

coding process is T1 and T2 is faster. However, for

what concerns electronic voting systems, usually sev-

eral encryptions are made and only one decryption

is needed to reveal the result of an election. We

conclude that T4 is more efﬁcient to apply to elec-

tronic voting systems. Additionally, as reported in

the note on Moscow voting systems (Gaudry, 2019),

this technique is efﬁcient since the decryption (q-

exponentiations) is usually done on high-end servers,

while the encryption (2-exponentiations) is done on

the voter’s device.

In addition, T1, T2, T3, and T4 implement a QR

generator using q-exponenentiations since they check

its quadratic residuosity by calculating g

(p). How-

ever, one can simply implement a quadratic residue

generator by using only 2-exponentiations instead of

using q-exponentiations (q-exponentiations are used

in (Belenios, 2016; Helios, 2008; Microsoft, 2019;

Moscow, 2019b; Veriﬁcatum, 2017) for the quadratic

residue generator). But clearly, a more direct and ef-

ﬁcient way to calculate the generator is by ﬁxing it in

advance. For example g = 4 if we are working in Z

∗

Note that the performance of the encoding is more

important than the performance of the generator cal-

culation, which occurs only once at the initial phase

of the voting process. Moreover, the performance of

the decoding is also less important than the encoding

in a voting process as discussed previously.

We provide a reference implementation in Ocaml

emy, 2000) (see Listing 5) in which we apply

the encoding and decoding process as in T4. In ad-

dition, in our implementation, the generation of the

quadratic residue generator differs from all the other

implementations as we use 2-exponentiations instead

of q-exponentiations.



(

Generate a safe prime of the form p = 2q + 1

)

let rec random safe prime nbits =

let q = sample ( nbits − 1) in

let q = Z.nextprime q in

let p = Z.succ (Z. shift left q 1) in

if Z.probab prime q 10 <> 0

&& Z.probab prime p 10 <> 0 then p

else random safe prime nbits

(

Generate a QR generator

)

let generator pbits p =

let q = Z. shift right p 1 in

let g = Z.succ ( sample le pbits (Z.sub p (Z.

of int 2)) ) in

Z.powm g (Z. of int 2) p

(

Deﬁne the group

)

let sample group pbits =

let p = random safe prime pbits in

let g = generator pbits p in { pbits = pbits }

(

Encode the message as a QR element

)

let encode gr m = Z.powm (Z.succ m) (Z. of int 2)

gr .p

(

Encryption

)

let encrypt gr pk m =

if (( Z.leq Z.zero m) && (Z.lt m (Z.pred (q gr))

)) then

let r = sample le (gr . pbits − 1) (q gr) in

(Z.powm gr.g r gr .p, mulm gr (Z.powm pk r gr.

p) (encode gr m))

else raise ( Invalid argument ”ElG encryption”)

(

Decryption

)

let decrypt gr sk (u,v) =

let mult = Z.mul (Z.pred (q gr) ) sk in

let modulo = Z.powm u mult gr.p in

let dec = mulm gr v modulo in

decode gr dec

(

Decoding

)

let decode gr m =

let p = gr.p in

let q = q gr in

let r = Z.powm m (Z. shift right (Z.succ q) 1) p

let m = if Z.leq r q then r else (Z.sub p r) in

(Z.pred m)

 

Listing 5: Our Ocaml implementation using a QR

Generator & 2-exponentiations for an efﬁcient message

encoding.

7 CONCLUSION

During our analysis, we have discovered a number of

ElGamal scheme implementations that are not IND-

Security Analysis of ElGamal Implementations

319

CPA secure since they do not respect the DDH as-

sumption. On one hand, some implementations do

not employ safe primes, an essential condition to form

subgroups of large prime order in which the DDH as-

sumption holds. On the other hand, other implemen-

tations do not apply message encoding mechanisms or

use Quadratic Residue Generators. As a consequence,

20 out of the 26 analyzed libraries may leak one bit of

information about the original message and therefore,

may endanger the validity of an election. Finally, af-

ter comparing four different message encoding tech-

niques that satisfy the DDH assumption, we conclude

which implementation is most convenient for voting

systems. We focused the current study on manually

analyzing the IND-CPA security of open source code

libraries of ElGamal encryption scheme. However, it

is also possible to check the IND-CPA (in-) security

when source code is not available. In fact, by applying

the technique discussed in the Example 4.2 of Section

4, one can black-box test applications. In particular,

such tests can be applied to ElGamal encryptions ob-

tained by Hardware Security Modules (HSM) (Volka-

mer, 2009; Orr and Liam, 2016), which are used

e.g. in the Estonian I-voting system (Springall et al.,

2014). We leave this as future work.

REFERENCES

Adida, B. (2008). Helios: Web-based open-audit voting. In

USENIX ’08, pages 335–348.

Alves, P. (2015). Public source code of library n.5.

https://github.com/pdroalves.

Babenko, L., Pisarev, I., and Makarevich, O. B. (2017). A

model of a secure electronic voting system based on

blind intermediaries using russian cryptographic algo-

rithms. In SIN ’17, pages 45–50.

Barthe, G., Gr

egoire, B., and B

eguelin, S. Z. (2009). Formal

certiﬁcation of code-based cryptographic proofs. In

POPL ’09, pages 90–101.

Belenios (2016). Public source code of library n.1.

https://github.com/glondu/belenios.

Bernstein, D. J., Hamburg, M., Krasnova, A., and Lange, T.

(2013). Elligator: elliptic-curve points indistinguish-

able from uniform random strings. In ACM SIGSAC

’13, pages 967–980.

Botan (2018). Public source code of library n.2.

https://github.com/randombit/botan.

Chevallier-Mames, B., Paillier, P., and Pointcheval, D.

(2006). Encoding-free elgamal encryption without

random oracles. In PKC ’06, pages 91–104.

Cortier, V., Fuchsbauer, G., and Galindo, D. (2015). Be-

leniosrf: A strongly receipt-free electronic voting

scheme. IACR, 2015.

Cortier, V., Galindo, D., K

usters, R., M

uller, J., and

Truderung, T. (2016). Sok: Veriﬁability notions for

e-voting protocols. In IEEE, SP ’16, pages 779–798.

Cramer, R., Gennaro, R., and Schoenmakers, B. (1997). A

secure and optimally efﬁcient multi-authority election

scheme. In EUROCRYPT ’97, pages 103–118.

Cramer, R. and Shoup, V. (1998). A practical public key

cryptosystem provably secure against adaptive chosen

ciphertext attack. In CRYPTO ’98, pages 13–25.

Diaz, A. (2017). Public source code of library n.4.

https://github.com/vrnvu/elgamal-ap.

Difﬁe, W. and Hellman, M. E. (1976). New directions in

cryptography. IEEE Trans. Inf. Theory ’76, pages

644–654.

ElGamal, T. (1985). A public key cryptosystem and a sig-

nature scheme based on discrete logarithms. IEEE

Trans. Inf. Theory ’85, pages 469–472.

Elgamir (2016). Public source code of library n.14.

https://github.com/d5c5ceb0/elgamir.

Estonia (2017). Public source code of library n.15.

https://github.com/vvk-ehk/ivxv.

Fadavi, M., Farashahi, R. R., and Sabbaghian, S. (2018).

Injective encodings to binary ordinary elliptic curves.

In SAC ’18, pages 434–449.

Farashahi, R. R. (2014). Hashing into hessian curves. IJACT

’14, pages 139–147.

Faz-Hernandez, A., Scott, S., Sullivan, N., Wahby, R. S.,

and Wood, C. A. (2019). Hashing to Elliptic

Curves. https://datatracker.ietf.org/doc/html/draft-irtf-

cfrg-hash-to-curve-05. Technical report.

Gaudry, P. (2019). Breaking the encryption scheme of the

moscow internet voting system. CoRR ’19.

Goldwasser, S. and Micali, S. (1982). Probabilistic encryp-

tion and how to play mental poker keeping secret all

partial information. In ACM ’82, pages 365–377.

Haines, T., Gor

e, R., and Tiwari, M. (2019). Veriﬁed ver-

iﬁers for verifying elections. In ACM SIGSAC, CCS

’19, pages 685–702.

Helios (2008). Public source code of library n.16.

https://github.com/benadida/helios-server.

Ioannou, O. (2014). Public source code of library n.24.

https://github.com/oorestisime.

Koblitz, N., Menezes, A., and Vanstone, S. A. (2000). The

state of elliptic curve cryptography. Des. Codes Cryp-

togr. ’00, pages 173–193.

Kubjas, I., Pikma, T., and Willemson, J. (2017). Estonian

voting veriﬁcation mechanism revisited again. IACR,

2017.

Lee, R. (2017). Public source code of library n.7.

https://github.com/rayli-bot/modulus-calculation.

Libgcrypt (2013). Public source code of library n.17.

https://github.com/gpg/libgcrypt.

Lipton, R. J. (1981). How to Cheat at Mental Poker. In

Proceeding of AMS short course on Cryptology ’81.

Microsoft (2019). Public source code of library n.18.

https://github.com/microsoft/electionguard-veriﬁer.

Miller, V. S. (1985). Use of elliptic curves in cryptography.

In CRYPTO ’85, pages 417–426.

Milne, J. S. (2011). Fields and galois theory (v4.22).

Moscow (July, 2019a). Public source code of library n.19.

https://github.com/moscow-technologies.

SECRYPT 2020 - 17th International Conference on Security and Cryptography

320

Moscow (September, 2019b). Public source code of library

n.20. https://github.com/moscow-technologies.

Musat, A. (2017). Public source code of library n.12.

https://github.com/andreeamusat/.

Nasr, H. (2015). Public source code of library n.3.

https://github.com/ananasr/cryptology.

Ne Oo, H. and Aung, A. (2014). A survey of different elec-

tronic voting systems. IJSER ’14.

Nishihara, N., Harasawa, R., Sueyoshi, Y., and Kudo, A.

(2009). A remark on the computation of cube roots in

ﬁnite ﬁelds. IACR ’09, page 457.

Norvegia (2017). Public source code of library n.21.

https://www.regjeringen.no/en/topics/elections-

and-democracy/den-norske-valgordningen/the-

norwegian-electoral-system/id456636.

Orr, D. and Liam, K. (2016). SAC ’15. Lecture Notes in

CS ’16.

Paillier, P. (1999). Public-key cryptosystems based on com-

posite degree residuosity classes. In EUROCRYPT

’99, pages 223–238.

Pankratiew, A. (2018). Public source code of library n.10.

https://github.com/n1ghtf1re/public-key-ciphers.

Pellegrini, J. (2017). Public source code of library n.11.

http://aleph0.info/jp/software/elgamal.

Pohlig, S. C. and Hellman, M. E. (1978). An improved

algorithm for computing logarithms over gf(p) and its

cryptographic signiﬁcance (corresp.). IEEE Trans. Inf.

Theory, 24:106–110.

Pollard, J. M. (1978). Monte carlo methods for index com-

putation $({mod} p)$.

Puigalli, J. and Guasch, S. (2012). Cast-as-intended veriﬁ-

cation in norway. In EVOTE ’12, pages 49–63.

Pycrypto (2012). Public source code of library n.22.

https://github.com/dlitz/pycrypto.

Pycryptodome (2018). Public source code of library n.23.

https://github.com/legrandin/pycryptodome.

emy, D. (2000). Using, understanding, and unraveling

the ocaml language. from practice to theory and vice

versa. In APPSEM ’00, pages 413–536.

Riddle, R. (2014). Public source code of library n.13.

https://github.com/ryanriddle/elgamal.

Ridhuan, I. (2016). Public source code of library n.8.

https://github.com/ilyasridhuan/elgamal.

Rivest, R. L., Shamir, A., and Adleman, L. M. (1979). Men-

tal poker. The Mathematical Gardner ’79, pages 120–

126.

Rotman, J. (1999). An Introduction to the Theory of Groups.

Graduate Texts in Mathematics ’99.

Sidorov, V. (2016). Public source code of library n.6.

https://github.com/bazzilic/elgamalext.

Springall, D., Finkenauer, T., Durumeric, Z., Kitcat, J.,

Hursti, H., MacAlpine, M., and Halderman, J. A.

(2014). Security analysis of the estonian internet vot-

ing system. In ACM SIGSAC ’13, pages 703–715.

Swisspost (2018). Public source code of library n.25.

https://gitlab.com/swisspost/evoting-solution.

Veriﬁcatum (2017). Public source code of library n.26.

https://github.com/veriﬁcatum.

Volkamer, M. (2009). Evaluation of Electronic Voting. Lec-

ture Notes in Business Inf. Proc. ’09.

Wang, K. (2017). Public source code of library n.9.

https://github.com/wangkepfe/cryptography.

Security Analysis of ElGamal Implementations

321
