IRENE: Interference and High Availability Aware Microservice-based

Applications Placement for Edge Computing

Paulo Souza

1 a

, Jo

ao Nascimento

1 b

, Conrado Boeira

1 c

Angelo Vieira

1 d

, Felipe Rubin

1 e

omulo Reis

1 f

, F

abio Rossi

2 g

and Tiago Ferreto

1 h

Pontiﬁcal Catholic University of Rio Grande do Sul, Porto Alegre, Brazil

Federal Institute of Education, Science and Technology Farroupilha, Alegrete, Brazil

Keywords:

Edge Computing, Microservices, Genetic Algorithm, Applications Placement.

Abstract:

The adoption of microservice-based applications in Edge Computing is increasing, as a result of the improved

maintainability and scalability delivered by these highly-distributed and decoupled applications. On the other

hand, Edge Computing operators must be aware of availability and resource contention issues when placing

microservices on the edge infrastructure to avoid applications’ performance degradation. In this paper, we

present IRENE, a genetic algorithm designed to improve the performance of microservice-based applications

in Edge Computing by preventing performance degradation caused by resource contention and increasing the

application’s availability as a means for avoiding SLA violations. Experiments were carried, and the results

showed IRENE effectiveness over different existing strategies in different scenarios. In future investigations,

we intend to extend IRENE’s interference awareness to the network level.

1 INTRODUCTION

Edge Computing is gaining attention by delivering

processing power to mobile applications with reduced

latency compared to cloud solutions (Satyanarayanan,

2017). For this goal, small-sized data centers, also re-

ferred to as cloudlets, are positioned at strategic po-

sitions to provide fast feedback while avoiding core

network saturation. While the proximity between

cloudlets and end-users allows for reduced response

times, edge infrastructure operators still have resource

management concerns regarding the placement of ap-

plications. These concerns are even more challeng-

ing for applications built upon the microservices ar-

chitecture, which are designed with a particular set of

technologies to get the best-of-breed out of modern

computing infrastructure.

https://orcid.org/0000-0003-4945-3329

https://orcid.org/0000-0002-2261-2791

https://orcid.org/0000-0002-6519-9001

https://orcid.org/0000-0002-1806-7241

https://orcid.org/0000-0003-1612-078X

https://orcid.org/0000-0001-9949-3797

https://orcid.org/0000-0002-2450-1024

https://orcid.org/0000-0001-8485-529X

Microservice-Based applications usually priori-

tize smaller footprint, reduced storage requirements,

and the faster boot time of lightweight virtualization

over reinforced isolation provided by traditional vir-

tual machines (Gannon et al., 2017). As a conse-

quence, the co-location of multiple microservices into

the same server may result in performance-degrading

events due to resource contention.

Unlike most of cloud data centers, cloudlets may

count on heterogeneous servers to host applications,

which may provide different performance and avail-

ability assurances. Therefore, choosing host servers

for accomodating microservices also involves con-

sidering applications’ availability requirements as a

means to avoid Service Level Agreements (SLAs) vi-

olations.

Several studies have been focusing on optimiz-

ing the placement of applications (Wang et al., 2012;

Romero and Delimitrou, 2018). Whereas some of

them provided solutions for ensuring high availabil-

ity, others have focused on avoiding performance in-

terference. However, providing both minimal perfor-

mance interference and high availability for applica-

tions’ placement remains an open problem.

Therefore, in this paper, we present IRENE, a ge-

netic algorithm designed for ensuring minimal inter-

490

Souza, P., Nascimento, J., Boeira, C., Vieira, Â., Rubin, F., Reis, R., Rossi, F. and Ferreto, T.

IRENE: Interference and High Availability Aware Microservice-based Applications Placement for Edge Computing.

DOI: 10.5220/0009581604900497

In Proceedings of the 10th International Conference on Cloud Computing and Services Science (CLOSER 2020), pages 490-497

ISBN: 978-989-758-424-4

 2020 by SCITEPRESS – Science and Technology Publications, Lda. All rights reser ved

ference to avoid performance degradation and high

availability as a means for minimizing SLA violations

during the placement of microservice-based applica-

tions. We performed a set of experiments that showed

that IRENE could overcome several existing strate-

gies.

The remaining of this paper is organized as fol-

lows. In Section 2, we discuss the emergence of

Edge Computing, the popularization of microservice-

based applications, and challenges faced by edge in-

frastructure operators during the placement of these

applications, especially regarding performance inter-

ference and high availability. We also complement the

background section with an overview of current in-

vestigations in Section 3, which also discusses the re-

search gap tackled by our study. After describing the

problem we aim to solve in Section 4, we introduce

IRENE, our proposed genetic algorithm. Finally, Sec-

tions 6 and 7 are reserved for the evaluation of IRENE

versus three baseline heuristic placement strategies,

as well as for ﬁnal remarks and directions for future

investigations.

2 BACKGROUND

The increasing amount of sensors integrated on mul-

tiple devices allowed the rise of various Internet of

Things (IoT) applications, such as Smart Homes and

Smart Cities (Shi et al., 2016). Due to the intrin-

sic limitation of embedded devices used in IoT ap-

plications in terms of resources, it becomes infeasible

to perform some computational tasks locally (Satya-

narayanan et al., 2009). A solution would be to send

the data collected to the cloud. Nonetheless, trans-

porting data to the cloud introduces new challenges,

such as network latency and security. There are also

connectivity restrictions that make the task of send-

ing the data from IoT and mobile applications to the

cloud even more challenging.

The concept of Edge Computing was proposed

as a solution to this problem. Edge Computing

performs computations at the edge of the network,

closer to the devices that are producing/consuming

the data (Shi et al., 2016). It results in a reduction

of network latency, as the data does not need to travel

long distances to reach the cloud. Satyanarayanan et

al. (Satyanarayanan et al., 2009) proposed the concept

of cloudlets as simpler and smaller data centers that

can be responsible for the computation in the Edge

Computing.

Microservices architecture is a recommendation

for getting the maximum beneﬁts from the Cloud

Computing (Gannon et al., 2017), and this recom-

mendation also ﬁts well for Edge Computing. The

microservices architecture proposes an opposing view

to the monolithic architecture by segmenting the dif-

ferent application functionalities into multiple com-

ponents. Each microservice can be managed indepen-

dently from others and has limited responsibilities and

dependencies (Gannon et al., 2017). They can also be

accommodated in cloudlets within the Edge Comput-

ing paradigm as a means for allowing improved use of

resources. Two of the main factors that edge infras-

tructure operators must keep in mind during the de-

cision of where to deploy the microservices are high

availability and interference.

When deploying an application on cloudlets, we

want the system to be highly available; that means,

to keep working properly, even when one or more

servers are not responding. Depending on how avail-

able an application is, the operator can provide Ser-

vice Level Agreements (SLAs) to the users. These

are explicit or implicit contracts that deﬁne service

levels promised in the form of a metric of interest like

availability, for example. SLAs also provide speciﬁc

remedies in case of any unexpected event.

Another factor that needs to be considered when

deciding the applications’ placement is how differ-

ent microservices in the same host interfere with

each other. At this point, understanding the core

technologies such as virtualization, which responsi-

ble for hosting applications inside servers, is nec-

essary. Virtualization allows microservices to ob-

tain access to shared resources from the same host

while still keeping a certain degree of isolation during

their execution. There are two types of virtualization:

hypervisor-based and container-based.

In the hypervisor-based virtualization, each appli-

cation has its own virtual machine with a guest operat-

ing system. The container-based virtualization lever-

ages OS-level features to provide isolation among ap-

plications that share the host kernel as a means for

improved performance (Soltesz et al., 2007). The

container-based virtualization has the advantage of

being lightweight (Gannon et al., 2017), which makes

it more suitable for Edge Computing, where hosts

present resource constraints. However, containers

have the downside that they grant less isolation for

the applications, compared to hypervisor-based virtu-

alization.

Applications tend to require more intensively a

speciﬁc computational resource (e.g., CPU, memory,

etc.) (Qiao et al., 2017). Microservices on the same

host using the same resources may end up degrading

each other performance. In an ideal scenario, where

applications could run on dedicated servers, there

would be no interference. However, this scenario is

IRENE: Interference and High Availability Aware Microservice-based Applications Placement for Edge Computing

491

usually not real due to the virtualization, which allows

a server to share its computational resources among

several microservices, which must compete for the

shared resources. This competition can be avoided

during the choice of where to accommodate applica-

tions. A remedy to avoid performance interference

would be considering the placement of microservices

with non-conﬂicting resource bounds (Qiao et al.,

2017).

3 RELATED WORK

3.1 High Availability

Bin et al. (Bin et al., 2011) propose a heuristic algo-

rithm that monitors the infrastructure to detect failures

beforehand and tries to reallocate applications from

hosts before they fail, thus enhancing applications’

availability.

Zhu and Huang (Zhu and Huang, 2017) formulate

a stochastic model for adaptive placement of Edge ap-

plications to achieve lower costs, while still consider-

ing high availability. As the problem scales, to cir-

cumvent the complexity of computations, a heuristic

algorithm is also presented for real-world scenarios.

Wang et al. (Wang et al., 2012) propose a high

availability scheme for virtual machines in cloud data

centers. The authors take advantage of both verti-

cal and horizontal scalability to improve applications’

availability. To this end, the number of instances per

application is increased, enabling their placement in

other hosts, thus improving availability.

3.2 Performance Interference

Kim et al. (Kim et al., 2018) propose a manage-

ment mechanism to reduce the memory interference

latency. The proposed approach differentiates the ex-

ecution of tasks by separating them into critical and

normal control groups. When a critical task is run-

ning, a prediction about excessive memory consump-

tion is made. If deemed necessary, the CPUFreq gov-

ernor is activated to throttle memory requests made

by applications of the normal control group.

Ren et al. (Ren et al., 2019) present a machine

learning-based prediction framework that enables the

classiﬁcation of each task as repetitive or new. In con-

trast to new tasks, repetitive ones can provide histor-

ical information regarding their behavior, which can

be used to improve their scheduling to achieve perfor-

mance gains.

Romero and Delimitrou (Romero and Delimitrou,

2018) present a way to optimize performance and ef-

ﬁciency in systems with intra-server and inter-server

heterogeneity, with a solution called Mage. Mage

continuously monitors the performance of active ap-

plications and minimizes resource contention in cloud

systems. Using data mining, it explores the space

of application placements and determines those that

minimize interference between co-located applica-

tions.

3.3 Our Contributions

Several studies have been focused on optimiz-

ing availability or performance interference require-

ments. However, none of them considered both objec-

tives during the placement of applications in edge sce-

narios. Therefore, in this paper, we propose IRENE,

a genetic algorithm for improving the placement of

microservice-based applications regarding both high

availability requirements as means for minimizing the

number of SLA violations and interference that leads

to superior applications’ performance.

4 PROBLEM FORMULATION

In this study, we consider an Edge Computing sce-

nario where applications containing one or more mi-

croservices need to be placed inside physical servers

on a cloudlet. Our goal is to design a satisfactory

placement for applications considering a twofold ob-

jective:

1. Minimizing performance interference by avoid-

ing the co-location of microservices with similar

resource bounds (e.g., CPU-bound) in the same

host.

2. Minimizing the number of SLA violations by dis-

tributing applications’ microservices on hosts that

satisfy its availability requirements.

Table 1 presents the list of terminology adopted in

this study. We demonstrate both the capacity of

physical servers and the demand of microservices as

a resource vector containing: (i) CPU (number of

cores); (ii) memory (Gigabytes); and (iii) storage (Gi-

gabytes). The set of g physical servers is denoted by

P = {P

, P

, ..., P

}. Each physical server P

provides

an availability denoted by α(P

) and has a binary vari-

able u(P

), which represents whether the server is be-

ing used or not (0 = inactive, 1 = active).

We deﬁne the set of h applications as A =

, A

, ..., A

}, where each microservice A

∈ A has

a placement requirement β(A

) that represents the

minimum availability ratio expected by A

. In this

scenario, each application A

∈ A is composed of

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

492

Table 1: List of terminology used in this paper.

Notation Description

P Set of g servers within the cloudlet

A Set of h applications

M Set of p microservices to be hosted

α(P

)

Variable that represents the availability level

assured by a server P

β(A

)

Variable that represents the minimum availability

ratio expected by an application A

σ(P

)

Variable that represents the number of colliding

microservices inside a server P

u(P

)

Binary variable that receives 1 if a server P

is active or or receives 0 otherwise

i,k

Binary variable that receives 1 if a server P

hosts a microservice k, or receives 0 otherwise

one or more microservices. The set of all p mi-

croservices within the cloudlet is deﬁned as M =

, M

, ..., M

Each microservice may be distributed across the

hardware components differently. For simplicity

reasons, we consider microservices as CPU-bound,

memory-bound, or IO-bound. We also deﬁne which

microservices belong to which applications with the

k, j

variable, that receives 1 if a microservice M

part of an application A

, and receives 0 otherwise.

5 PROPOSAL

The problem we aim to solve in this work can be

considered a variant of the vector bin-packing prob-

lem. It can be brieﬂy formulated as packing n vec-

tors into k sets (or bins) without surpassing their limit.

This problem is acknowledged to be an NP-hard prob-

lem (Zhang et al., 2010), and hence, no optimal so-

lution in polynomial time is known. Therefore, this

work proposes a solution that uses a Genetic Algo-

rithm, as it offers a near-optimal solution in con-

strained time.

Genetic Algorithms (GA) are a class of algorithms

that are based on Darwin’s ideas of natural selection

and evolution. It encodes possible solutions for a

problem into the chromosome-like structure and then

applies recombination methods. The idea is that a GA

starts with a population of potential solutions charac-

terized as individuals. Then, it evaluates each one of

them accordingly to a deﬁned set of mathematically

expressed goals, which ones are better and worse so-

lutions. The collection of mathematical equations

used to evaluate solutions is called ﬁtness function.

The individuals deemed ”ﬁtter” have attributed to

them a higher chance of ”reproducing”, as in passing

some of its characteristics to a new individual (Whit-

ley, 1994). Therefore, GA can reach a satisfactory

solution by repeating this process multiple times.

5.1 Chromosome Representation

In the genetic algorithm presented in this work, the

genes of an individual represent which server will

host each microservice. In other words, if bit i has

value x, it means the microservice with id i will be

hosted in server number x. Therefore, each individual

represents a possible placement conﬁguration.

5.2 Fitness Function

IRENE assesses solutions based on the trade-off

between cloudlet’s consolidation rate, applications’

availability, and microservices interference. To

achieve this goal, IRENE utilizes the following ﬁtness

function to evaluate each solution z on the population:

f(z) ← (c + s + h)

(1)

The c variable represents the colliding microservices

ratio resulted from the solution. To calculate this ra-

tio, IRENE applies a ”rule of three” equation to mea-

sure the representativeness of the number of colliding

microservices gathered by the σ function concerning

the number of p microservices within the cloudlet.

This process is depicted next:

c ← 100 −



∑

σ(p

)



× 100

(2)

The s variable gets the number of applications whose

SLA requirements were violated with the proposed

placement. This process involves checking the ϑ

function, that veriﬁes if the SLA of an application

was violated. To accomplish this, the ϑ function com-

pares the guaranteed availability ratio provided by

each server through the α function against the appli-

cation’s availability requirements:

s ← 100 −



∑

ϑ(a

)



× 100

(3)

The h represents the cloudlet’s consolidation rate.

This variable utilizes a ”rule of three” equation to

calculate how many servers stay inactive within the

cloudlet after the suggested placement is applied.

This process is described in the following equation:

h ← 100 −



∑

u(p

)



× 100

(4)

To evaluate the generated solutions, IRENE sums

c, s, and h variables, and the result of this sum is

raised to the power of 2. We perform this exponen-

tiation to aid the genetic algorithm to understand that

even a slightly better solution may refer to signiﬁcant

progress in overall.

IRENE: Interference and High Availability Aware Microservice-based Applications Placement for Edge Computing

493

5.3 Genetic Operators

In this section, we present IRENE’s genetic operators.

We used the Roulette Wheel Selection method as the

selection algorithm for our approach. In this proce-

dure, the probability of an individual being chosen as

a parent is directly proportional to its ﬁtness score.

The highest the ﬁtness rate, the highest the likelihood

of a chromosome being selected for the list of parents

used in the selection phase (Sivaraj and Ravichandran,

2011).

The next step, after the parents’ selection, the ge-

netic algorithm framework proceeds to the crossover

operation. This stage consists of generating the off-

spring by combining parts of the genes from the se-

lected parents. There are multiple methods to per-

form the crossover operation, but the one chosen was

a uniform crossover. The uniform crossover consists

of randomly choosing from which parent the genes

are copied from (Umbarkar and Sheth, 2015). During

this step, a random mutation is also performed. Any

offspring has a speciﬁc probability of being mutated

and having one of its bits randomly chosen to be mu-

tated. This means that when a solution is mutated, one

of the microservices is assigned to a random cloudlet

server.

6 NUMERICAL EVALUATION

6.1 Workloads Description

For the evaluation, we consider a data set with a ﬁxed

number of 18 applications, grouped according to their

SLA requirements and number of microservices (also

called as application size for brevity purposes).

Regarding the SLA requirements, we divide appli-

cations in three groups according to the minimum ac-

ceptable availability rate: (a) Low SLA Requirement:

80%; (b) Medium SLA Requirement: 85%; and (c)

High SLA Requirement: 90%. Regarding the number

of microservices, we also divide applications in three

groups: (i) Small: 3 microservices; (ii) Medium: 6

microservices; and (iii) Large: 9 microservices.

Given the heterogeneous nature of edge environ-

ments, where a multitude of applications with differ-

ent behaviors must be allocated, in this study, we con-

centrate on assessing the implications of having to ac-

commodate applications with different sizes (Table 4

and SLA requirements (Table 5). To aid the analysis,

we also consider a baseline scenario (Table 6) wherein

applications are divided equally regarding number of

microservices and SLA requirements.

During the evaluation, we considered microservices

that may have different behaviors, based on the re-

source bounds (e.g., CPU-Bound, Memory-Bound,

and IO-Bound). The resource demands of microser-

vices may also be different, as can be seen in Table 2.

Table 2: Different microservice resource demands consid-

ered during the evaluation.

Size CPU (# of Cores) Memory (GB) Disk (GB)

Small 1 1 8

Medium 2 2 16

Large 4 4 32

We consider a ﬁxed number of 60 homogeneous edge

servers with the following conﬁguration: CPU: 16

cores, RAM: 16GB, Disk: 128GB. The servers are di-

vided according to different levels of availability they

can assure, as described in Table 3.

Table 3: Availability levels of edge servers.

Type Availability Number of servers

Low 90% 30

Medium 95% 20

High 99.9% 10

We compare our proposal against the following algo-

rithms:

• Best-Fit (BF): Prioritizes server consolidation,

reducing the total number of servers used to host

applications.

• Worst-Fit (WF): Focuses on balancing work-

loads between servers.

• IntHA: focuses on accommodating applications

in a minimal number of servers given interfer-

ence and high availability goals. To accomplish

this, IntHA takes into account both the assured

availability (depicted by α(P

)) and the number of

colliding microservices (represented by σ(P

)) for

each host. Algorithm 1 shows the pseudocode for

this heuristic.

All solutions considered during the evaluation were

developed and executed using the Ruby language

v2.7.0p0 (2019-12-25 revision 647ee6f091). For the

execution of the solutions, we used a Linux host ma-

chine with speciﬁcations contained in Table 7. Dur-

ing the experiments, we conﬁgured IRENE to look

for placement solutions during 25000 generations us-

ing a population of 500 chromosomes, with mutation

rate set to 35% and 100 parents being used for mating.

All experimentation assets can be found at our GitHub

repository (https://github.com/paulosevero/IRENE).

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

494

Table 4: Application size scenarios.

Small-Size Applications Medium-Size Applications Large-Size Applications

Scenario 1

Low SLA Requirement 1 1 4

Medium SLA Requirement 1 1 4

High SLA Requirement 1 1 4

TOTAL 3 3 12

Scenario 2

Low SLA Requirement 4 1 1

Medium SLA Requirement 4 1 1

High SLA Requirement 4 1 1

TOTAL 12 3 3

Table 5: SLA requirements scenarios.

Small-Size Applications Medium-Size Applications Large-Size Applications

Scenario 1

Low SLA Requirement 1 1 1

Medium SLA Requirement 1 1 1

High SLA Requirement 4 4 4

TOTAL 6 6 6

Scenario 2

Low SLA Requirement 4 4 4

Medium SLA Requirement 1 1 1

High SLA Requirement 1 1 1

TOTAL 6 6 6

Table 6: Baseline scenario.

Small-Size Applications Medium-Size Applications Large-Size Applications

Baseline

Low SLA Requirement 2 2 2

Medium SLA Requirement 2 2 2

High SLA Requirement 2 2 2

TOTAL 6 6 6

Algorithm 1: IntHA heuristic.

1 A ← {A

, A

, ..., A

}

2 P ← {P

, P

, ..., P

}

3 M ← {M

, M

, ..., M

}

4 foreach application A ∈ A do

5 foreach microservice M ∈ M do

6 if M ∈ A

then

7 µ ← null

8 foreach server P ∈ P do

9 if P has cap. to host M then

10 s ←

usage

+α(P)

1 + σ(P)

11 end

12 if s ≥ µ

score

then

13 µ ← P

14 end

15 end

16 µ

← µ

∪ M

17 end

18 end

19 end

6.2 Results and Analysis

6.2.1 Application Size

The goal of this analysis is to understand how much

the average size of applications impact the evaluated

solutions behavior regarding interference, SLA viola-

tions, and consolidation rate. The results of this anal-

ysis are depicted in Figure 1.

Table 7: Testbed speciﬁcations.

Component Speciﬁcation

Processor Intel(R) Core(TM) i7-4790 4(8) @ 3.60GHz

Memory 16GB DDR3 @ 1333MHz

Storage 1TB HDD SATA @ 7200RPM

Operation System

elementary OS 5.1.2 Hera

Achieving high levels of availability becomes harder

when applications have more microservices. There-

fore, facing a scenario with larger applications leads

to more SLA violations. Consolidating applications

inside hosts that provide higher availability guaran-

tees avoid SLA violations, but with the cost of caus-

ing the collision of more microservices. This ex-

plains why the Best-Fit approach surpasses Worst-Fit

and IntHA when handling SLA violations, but loses

in terms of interference. IRENE, on the other hand,

follows a different path for avoiding SLA violations

without hurting too much the other metrics. It fo-

cuses on not wasting the resources of servers that

provide higher availability with applications that have

low SLA requirements.

In the evaluated scenarios, we can notice that there

is a trade-off between delivering high levels of avail-

ability and avoiding collision of microservices with

similar resource bounds. If we focus on providing the

highest availability possible for all applications, we

will be forced to consolidate all the workload inside

a limited number of servers that offer higher guaran-

tees. However, this decision would lead to several mi-

croservices with similar bound being hosted by the

same server, which raises concerns with interference.

As a consequence, considering just one of these

IRENE: Interference and High Availability Aware Microservice-based Applications Placement for Edge Computing

495

1 4

1 6

1 3

1 1

1 0 5

3 3

3 9

1 2 9

5 9

6 4

7 5

1 2

B e s t - F i t W o r s t - F i t I n t H A I R E N E B e s t - F i t W o r s t - F i t I n t H A I R E N E B e s t - F i t W o r s t - F i t I n t H A I R E N E

B a s e l i n e

A p p l i c a t i o n S i z e S c e n a r i o 1

A p p l i c a t i o n S i z e S c e n a r i o 2

1 2

1 5

1 8

S L A V i o l a t i o n s C o l l i d i n g M i c r o s e r v i c e s

S t r a t e g y

S L A V i o l a t i o n s

5 0

1 0 0

1 5 0

C o l l i d i n g M i c r o s e r v i c e s

Figure 1: Heuristic results in edge scenarios with variable application sizes.

1 4

1 5

1 1

1 3

1 0 5

3 3

3 9

1 0 5

3 3

5 5

1 0 5

3 3

3 2

B e s t - F i t W o r s t - F i t I n t H A I R E N E B e s t - F i t W o r s t - F i t I n t H A I R E N E B e s t - F i t W o r s t - F i t I n t H A I R E N E

B a s e l i n e

S L A S c e n a r i o 1

S L A S c e n a r i o 2

1 0

1 5

S L A V i o l a t i o n s C o l l i d i n g M i c r o s e r v i c e s

S t r a t e g y

S L A V i o l a t i o n s

5 0

1 0 0

1 5 0

C o l l i d i n g M i c r o s e r v i c e s

Figure 2: Heuristic results in edge scenarios with variable application SLA requirements.

two metrics may result in placements that hurt the

other. For example, Best-Fit and Worst-Fit only take

into account the number of hosts used for accommo-

dating applications. Best-Fit tries to consolidate ap-

plications the most and ends up by causing high in-

terference levels. On the other hand, Worst-Fit that

tries to balance the workload the most ends up by pro-

viding poor availability ratios which result in several

SLA violations.

Bearing in mind this trade-off, IRENE chooses to

sacriﬁce the consolidation rate a little to achieve more

signiﬁcant gains regarding interference and SLA vio-

lations. Compared to Best-Fit, it sacriﬁces the consol-

idation rate in 16% for the sake of reducing the num-

ber of colliding microservices in 45.74% and mini-

mizing the SLA violations by half.

6.2.2 SLA Requirements

This analysis aims at examining the implications of

decisions made by placement strategies regarding in-

terference, consolidation rate, and SLA violations in

edge scenarios containing applications with variable

SLA requirements. The results of this analysis is de-

picted in Figure 2.

When most of applications have high availability

requirements, placement strategies may have to stack

as many microservices as possible into servers that

provide higher availability in order to avoid SLA vio-

lations. As a consequence, Best-Fit suits well in this

scenario, being able to achieve the second-best re-

sult regarding SLA violation while utilizing only 16

servers. However, due to the order of placement of

applications being crescent in availability need, the

Best-Fit heuristic guarantees a higher SLA for the low

availability applications and a lower one for the appli-

cations that demand a higher availability.

In contrast, IRENE is able to minimize the

percentage of applications with SLA violations in

27.77% compared to Best-Fit in the ﬁrst scenario.

Furthermore, IRENE manages to have 0 SLA viola-

tions in scenario 2. However, this gain is achieved at

the cost of reducing the consolidation rate in 16.66%

and 20.0% for scenarios 1 and 2 respectively.

Another aspect where IRENE differ from Best-

Fit is the SLA guarantees for each type of applica-

tions. Our algorithm ensures higher SLAs for applica-

tions that need higher availability and lower SLAs for

the ones with lower availability needs. This decision

of stacking as many microservices from applications

with high SLA requirements as possible into the sub-

set of servers that provide higher availability guaran-

tees also allows IRENE to accommodate, in scenario

1, all microservices in only 26 servers, 2 less than in

the baseline scenario. Nonetheless, it also generates

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

496

an increase of 14.81% on the number of co-located

microservices with similar bound compared to the re-

sult it achieved in the baseline scenario.

7 CONCLUSIONS

Edge Computing is gaining signiﬁcant popularity

with the idea of using small-sized data centers (often

called as cloudlets) to bring data processing closer to

end-users. Even though cloudlets provide faster re-

sponse time, performance-degrading events such as

resource contention may affect applications’ perfor-

mance and, consequently, negatively inﬂuence the

end-user experience. This performance interference

can be even more dangerous considering an existing

trend in modern application development of prioritiz-

ing ﬂexibility provided by microservices running on

containers over the improved isolation offered by the

classical approach that uses virtual machines. On sce-

narios such as those, high availability requirements

present in SLAs also come into the scene. When plac-

ing all microservices of a given application on a single

host, it becomes a single point of failure.

Previous investigations proposed solutions for

high availability issues or performance interference

demands over cloud-based applications. However,

none of them focused on providing a solution for

both objectives in edge scenarios. Therefore, in this

paper, we present IRENE, a genetic algorithm ap-

proach designed to acquire the best of breed out of

edge servers regarding high availability (as means

for avoiding SLA violation) and performance inter-

ference (to achieve superior application performance)

during the placement of microservice-based applica-

tions. We validated IRENE through a set of experi-

ments, and the results showed that it could overcome

several existing approaches with minimal overhead.

As future work, we intend to minimize performance

interference issues at the network level by reducing

packets collision and network saturation.

ACKNOWLEDGEMENTS

This work was supported by the PDTI Program,

funded by Dell Computadores do Brasil Ltda (Law

8.248 / 91).

REFERENCES

Bin, E., Biran, O., Boni, O., Hadad, E., Kolodner, E. K.,

Moatti, Y., and Lorenz, D. H. (2011). Guaranteeing

high availability goals for virtual machine placement.

In 2011 31st International Conference on Distributed

Computing Systems, pages 700–709. IEEE.

Gannon, D., Barga, R., and Sundaresan, N. (2017). Cloud-

native applications. IEEE Cloud Computing, 4(5):16–

21.

Kim, J., Shin, P., Noh, S., Ham, D., and Hong, S.

(2018). Reducing memory interference latency of

safety-critical applications via memory request throt-

tling and linux cgroup. In 2018 31st IEEE Inter-

national System-on-Chip Conference (SOCC), pages

215–220. IEEE.

Qiao, S., Zhang, B., and Liu, W. (2017). Application clas-

siﬁcation based on preference for resource require-

ments in virtualization environment. In 2017 18th

International Conference on Parallel and Distributed

Computing, Applications and Technologies (PDCAT),

pages 176–182. IEEE.

Ren, S., He, L., Li, J., Chen, Z., Jiang, P., and Li, C.-

T. (2019). Contention-aware prediction for perfor-

mance impact of task co-running in multicore com-

puters. Wireless Networks, pages 1–8.

Romero, F. and Delimitrou, C. (2018). Mage: Online

interference-aware scheduling in multi-scale hetero-

geneous systems. arXiv preprint arXiv:1804.06462.

Satyanarayanan, M. (2017). The emergence of edge com-

puting. Computer, 50(1):30–39.

Satyanarayanan, M., Bahl, V., Caceres, R., and Davies, N.

(2009). The case for vm-based cloudlets in mobile

computing. IEEE pervasive Computing.

Shi, W., Cao, J., Zhang, Q., Li, Y., and Xu, L. (2016). Edge

computing: Vision and challenges. IEEE Internet of

Things Journal, 3(5):637–646.

Sivaraj, R. and Ravichandran, T. (2011). A review of selec-

tion methods in genetic algorithm. International jour-

nal of engineering science and technology, 3(5):3792–

3797.

Soltesz, S., P

otzl, H., Fiuczynski, M. E., Bavier, A., and

Peterson, L. (2007). Container-based operating sys-

tem virtualization: a scalable, high-performance al-

ternative to hypervisors. In ACM SIGOPS Operating

Systems Review, volume 41, pages 275–287. ACM.

Umbarkar, A. and Sheth, P. (2015). Crossover operators in

genetic algorithms: a review. ICTACT journal on soft

computing, 6(1).

Wang, W., Chen, H., and Chen, X. (2012). An availability-

aware virtual machine placement approach for dy-

namic scaling of cloud applications. In 2012 9th Inter-

national Conference on Ubiquitous Intelligence and

Computing and 9th International Conference on Auto-

nomic and Trusted Computing, pages 509–516. IEEE.

Whitley, D. (1994). A genetic algorithm tutorial. Statistics

and computing, 4(2):65–85.

Zhang, Q., Cheng, L., and Boutaba, R. (2010). Cloud com-

puting: state-of-the-art and research challenges. Jour-

nal of internet services and applications, 1(1):7–18.

Zhu, H. and Huang, C. (2017). Availability-aware mo-

bile edge application placement in 5g networks. In

GLOBECOM 2017-2017 IEEE Global Communica-

tions Conference, pages 1–6. IEEE.

IRENE: Interference and High Availability Aware Microservice-based Applications Placement for Edge Computing

497
