An Elasticity Description Language for Task-parallel Cloud Applications

Jens Haussmann

1 a

, Wolfgang Blochinger

1 b

and Wolfgang Kuechlin

2 c

Parallel and Distributed Computing Group, Reutlingen University, Germany

Symbolic Computation Group, University of Tuebingen, Germany

Keywords:

Cloud Computing, High Performance Computing, Parallel Application, Elasticity.

Abstract:

In recent years, the cloud has become an attractive execution environment for parallel applications, which in-

troduces novel opportunities for versatile optimizations. Particularly promising in this context is the elasticity

characteristic of cloud environments. While elasticity is well established for client-server applications, it is a

fundamentally new concept for parallel applications. However, existing elasticity mechanisms for client-server

applications can be applied to parallel applications only to a limited extent. Efﬁcient exploitation of elasticity

for parallel applications requires novel mechanisms that take into account the particular runtime characteristics

and resource requirements of this application type. To tackle this issue, we propose an elasticity description

language. This language facilitates users to deﬁne elasticity policies, which specify the elasticity behavior at

both cloud infrastructure level and application level. Elasticity at the application level is supported by an ade-

quate programming and execution model, as well as abstractions that comply with the dynamic availability of

resources. We present the underlying concepts and mechanisms, as well as the architecture and a prototypical

implementation. Furthermore, we illustrate the capabilities of our approach through real-world scenarios.

1 INTRODUCTION

Cloud computing evolved into a mature computing

paradigm that has turned out to be a promising tech-

nological path heading the utility computing vision.

Employing cloud environments for executing paral-

lel applications is particularly promising since prop-

erties like pay-per-use, on-demand access, and elas-

ticity open up new opportunities. For instance, one

can explicitly control and optimize monetary costs on

the level of individual parallel application runs. How-

ever, existing parallel applications have almost never

been designed for execution in cloud environments.

It is still not completely known in which ways and to

what extent they can proﬁt from the opportunities that

have been emerged from cloud computing. This issue

motivated an increasing activity in a wide-ranging re-

search domain concerning the exploitation of cloud

characteristics for parallel applications.

In principle, several classes of parallel applica-

tions can exploit cloud characteristics with no or few

modiﬁcations, like some HPC applications, such as

e.g., in the following scenario: By employing a sim-

https://orcid.org/0000-0003-0986-7594

https://orcid.org/0000-0002-5946-7225

https://orcid.org/0000-0002-5469-5544

ple ”copy and paste” approach, users can substitute

their HPC infrastructure by virtual hardware, harness-

ing the on-demand self-service and pay-per-use char-

acteristics of the cloud model. This approach provides

several beneﬁts: First, the user only pays for actu-

ally used resources. This characteristic is well suited

for institutions that otherwise would have to deal with

underutilized resources or a restricted budget that pre-

vents an investment for on-site clusters. Second, the

on-demand self-service characteristic of cloud offer-

ings allows additional execution scenarios. For exam-

ple, jobs submitted to grids or clusters are typically

handled by a scheduling system, stored in a queue

and executed later when resources become available.

In contrast, unlimited and immediately available re-

sources in cloud environments allow the execution of

all jobs in parallel, avoiding waiting times.

In this work, we focus on a cloud characteristic

of fundamental signiﬁcance for parallel applications:

Elasticity. For parallel applications elasticity is a new

concept, to which our research contributes towards

its understanding and utilization. Elasticity is com-

monly deﬁned as the degree to which a system can

adapt to workload changes by provisioning and de-

provisioning resources in an autonomic manner, such

that at each point in time, the available resources

match the current demand as closely as possible. To

Haussmann, J., Blochinger, W. and Kuechlin, W.

An Elasticity Description Language for Task-parallel Cloud Applications.

DOI: 10.5220/0009579004730481

In Proceedings of the 10th International Conference on Cloud Computing and Services Science (CLOSER 2020), pages 473-481

ISBN: 978-989-758-424-4

 2020 by SCITEPRESS – Science and Technology Publications, Lda. All rights reser ved

473

date, there exists a substantial body of research that

addresses various aspects of elasticity in cloud com-

puting. However, previous studies mostly focused on

elasticity regarding traditional client-server cloud ap-

plications, like web-, mail-, and database servers. De-

spite its promising potential, implications and oppor-

tunities of elasticity on parallel applications have not

been studied in depth. To beneﬁt from elasticity, it is

not sufﬁcient to focus solely on the elasticity of the in-

frastructure. Instead, parallel applications are also re-

quired to consider the application’s internal structure

and runtime behavior. To this end, it is mandatory

to support elasticity at the application level by pro-

viding adequate programming and execution models

as well as abstractions that take into account the dy-

namic availability of resources.

The main contributions of this paper are:

• We describe an approach of elasticity mechanisms

that control the logical parallelism of the applica-

tion and the physical parallelism of the cloud in-

frastructure.

• We show how to efﬁciently leverage elasticity for

task-parallel applications in cloud environments.

• We develop an elasticity description language for

parallel applications in the cloud with a corre-

sponding programming model and report on the

experimental evaluation.

The remainder of the paper is organized as fol-

lows: In Section 2, we motivate our study by dis-

cussing in more detail the speciﬁc problem we are ad-

dressing. Section 3 describes in detail our approach

for comprehensive elasticity management of parallel

cloud applications. Later, in Section 4, we discuss

several use-cases to substantiate the capabilities of our

proposed elasticity mechanisms. In Section 5, we re-

port on our experimental evaluation. Next, Section 6

gives an overview of related work. Section 7 con-

cludes the paper and outlines directions for future re-

search.

2 PROBLEM STATEMENT

Among all characteristics that paved the way for the

success of cloud computing, elasticity is widely con-

sidered to be the most fundamental of all. It is a

novel characteristic in resource management that dis-

tinguishes the cloud from other computing paradigms.

Elasticity offers the ability to allocate computing re-

sources dynamically, according to the current de-

mand. This introduces a wide range of new oppor-

tunities to optimize individual executions of an appli-

cation with changing resource requirements.

Generally, elasticity can be proﬁtable for appli-

cations with dynamic resource demand during exe-

cution. However, while many applications possess

this property, previous work has mostly been lim-

ited to client-server applications. Typically, these are

client-server applications such as web servers, e-mail

servers, and database servers whose workload is de-

ﬁned by external and independent user requests. The

rate at which these requests arrive constitutes the ap-

plication’s resource demand. Since the arrival rate

can change over time, static resource capacity can

lead to over-/under-provision of resources. In such

situations, these applications proﬁt from the elastic-

ity of cloud infrastructures by dynamically matching

resource allocation to the current resource demand.

For parallel applications, however, elasticity is a

new concept to which our research contributes to-

wards understanding and utilization. Unlike client-

server applications, the workload of parallel appli-

cations is deﬁned by a set of input parameters, in-

cluding a description of the problem to be processed.

The left part of Figure 1 summarizes the most im-

portant factors that necessitate leveraging elasticity

mechanisms for parallel applications. Parallel appli-

cations also differ from client-server applications in

certain other aspects. Typically, they are executed on

dedicated HPC clusters consisting of a static number

of processing elements. In addition, they are often

dependent on a particular type of hardware and uti-

lize optimized runtime systems, programming mod-

els, middleware, and software libraries (Blochinger

et al., 1999; Blochinger et al., 1998). However, these

instruments do not sufﬁciently support the elasticity

mechanisms present in cloud environments. Such

limitations prevent the exploitation of elasticity with-

out a major redesign of the existing parallel applica-

tion.

In order to exploit elasticity, mechanisms are

needed at both the infrastructure and the application

level. Cloud providers offer APIs at the infrastructure

level to control the number of processing elements,

which we refer to as physical parallelism. To leverage

these processing elements, the application must pro-

vide a sufﬁcient number of tasks, which we call log-

ical parallelism. For efﬁcient parallel computations,

the degree of logical parallelism must match the de-

gree of physical parallelism. Controlling both levels

is a complex task that can be considerably simpliﬁed

with elasticity policies, Elasticity policies express the

requirements on both parallelism levels and their en-

forcement in a descriptive way.

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

474

Optimize

costs

Optimize

quality of

results

Optimize

computation

time

Environment parameters

• Problem description

• Result quality

• Deadline

Runtime behavior

• Communication quantity

• Computation granularity

• Degree of parallelism

Changes of resource

costs

• Communication

• Processing

Changes of availability

of virtual resources

• Failure

• Volatile resources

Changes of performance

of virtual resources

• Migration

• Multi tenancy

Reasons for Adaptations

Actions

Goals

Scale

Physical

Parallelism

Scale

Logical

Parallelism

Figure 1: Elasticity of parallel applications.

3 ENABLING ELASTICITY FOR

TASK-PARALLEL

COMPUTATIONS

In this section, we present our solution that enables ef-

ﬁcient exploitation of elasticity for task-parallel appli-

cations. Particularly, we focus on the discussion of the

essential components and their interaction. One im-

portant aspect is the programming model, which has

to offer mechanisms for taking into account elasticity

at the program structure level, along with an appro-

priate model of the parallel execution. Additionally,

we present the elasticity description language (EDL)

that enables users to deﬁne the elasticity behavior of

the parallel system.

3.1 Programming and Execution Model

In this work, we employ the task pool execution

model for task management and load balancing. A

task pool consists of a set of processing elements,

each of which maintains a queue for storing tasks.

Task decomposition and processing is performed by

each processing element individually. Generated

tasks are stored in the local queue, and any processing

element may fetch them for processing through work-

stealing. The resulting dynamic mapping of tasks to

processing elements decouples problem decomposi-

tion and processing.

Programming models for parallel applications can

be classiﬁed according to their abstraction level in

terms of parallelism. According to (Skillicorn and

Talia, 1998), there are six different abstraction lev-

els, ranging from models that completely abstract par-

allelism (level 1) to models in which parallelism is

completely explicit (level 6). In this work, we em-

ploy a modiﬁed version of the fork-join program-

ming model, being at abstraction level 2. This model

is also used by Cilk (Blumofe et al., 1995) and

OpenMP (Galante and Bona, 2014). At this abstrac-

tion level, the parallelism in the program is marked

explicitly, while task generation, mapping, and com-

munication is implicit. Thus, developers are aware

that the application is running in parallel, while they

only need to express that part of the code that might

run in parallel. The fork-join statements allow de-

velopers to specify potential parallelism at the pro-

gram level, which can be transformed into logical

parallelism in the form of tasks. In the basic fork-

join model, the degree of logical parallelism increases

whenever a fork statement is encountered. Com-

monly, there is a ﬁxed relationship between calling

the fork statement and instantiating new tasks, with

each fork typically instantiating a single task. In the

following, we will refer to this relationship as fork

policy. An accurate formulation of the fork policy

is essential, as creating new tasks results in overhead

in the form of excess computation and communica-

tion. A ﬁxed fork policy is well suited for executions

with a static number of processing elements, since the

policy for fork statements and thus the granularity of

the tasks can be speciﬁed prior to execution. How-

ever, cloud infrastructures feature a dynamic resource

capacity and therefore require a dynamic policy for

efﬁcient parallel execution, and will be discussed in

the next section. The parallelism levels which have

to be aligned are therefore: 1) Parallelism at the pro-

gram level, speciﬁed with the fork-join programming

model. 2) Logical parallelism through the tasks cre-

An Elasticity Description Language for Task-parallel Cloud Applications

475

ated by the task pool. 3) Physical parallelism through

the processing elements of the cloud infrastructure.

3.2 Elasticity Description Language

From a cloud user’s perspective, elasticity require-

ments of a cloud system are often speciﬁed in a tem-

plate ﬁle written in a markup language such as YAML.

This speciﬁcation contains a set of conditions that the

system must fulﬁll together with appropriated scal-

ing operations to be carried out in the case of viola-

tion. A fundamental advantage of this method lies in

its straightforward usability. The speciﬁcation ﬁle is

read, interpreted, and automatically enforced by ser-

vices from the cloud provider (e.g., heat), shielding

the user from details of the implementation. Hence,

elasticity is enabled in a transparent manner, i.e., users

do not have to deal with burdens like modiﬁcations of

the applications’ source code, monitoring tools, and

APIs for interaction with the cloud infrastructure.

Although there exist several languages for the

speciﬁcation of elasticity requirements, most of them

focus on elasticity for client-server applications with

elasticity mechanisms operating at the infrastructure

level. Hitherto, there are only a few languages capable

of deﬁning elasticity requirements on multiple levels

of cloud systems, like SYBL (Copil et al., 2015) The

SYBL language deﬁnes several constructs that enable

the speciﬁcation of multi-level elasticity requirements

for cloud services. While several implementations of

these constructs have been developed to date, none

of them has yet addressed the elasticity speciﬁcation

at the parallel programming model and infrastructure

level.

We remedy this limitation and propose our elas-

ticity description language (EDL) that provides elas-

ticity support for fork-join applications. The language

facilitates detailed elasticity speciﬁcations of the par-

allel system with logical and physical parallelism be-

ing the control levers. A template ﬁle written in the

EDL is called an elasticity policy. This policy de-

scribes the scope of states within which it should be

operating and the elastic mechanisms through which

this is achieved. The structure of our language is pri-

marily based on the languages of YAML, YAQL, and

HOT. To control elasticity beyond the hardware level,

we use the same level of abstraction for our compo-

nents as in SYBL. We provide three core components

for the construction of elasticity policies, which are

described in more detail below: Monitor, constraint,

and strategy. The basic structure of a policy is shown

in Listing 1. Both, constraints and strategies have

conﬁgurable properties and are grouped into two sep-

arate lists within a policy. In contrast to constraints

1 constraints:

2 - [Constraint 1]

3 - [Constraint 2]

4 ...

5 - [Constraint n]

6 ,→

7 ,→

8 strategies:

9 - [Strategy 1]

10 - [Strategy 2]

11 ...

12 - [Strategy n]

Listing 1: Basic structure of an elasticity policy.

and strategies, monitors are implicitly available and

do not need to be explicitly deﬁned in a policy be-

fore use. We will now move on to a more detailed

discussion of the use and concepts of the introduced

components from our EDL.

A monitor is applied to check the current state of a

particular component within the parallel system. Tra-

ditionally, monitors gather information related to the

employed cloud resources at the infrastructure level

like CPU-utilization, network bandwidth, or disk I/O.

However, since our EDL addresses both physical

and logical parallelism, application-level monitoring

is also required for efﬁcient elasticity management.

Monitors at the infrastructure level, such as processor

utilization, are not further elaborated here as the cloud

provider usually provides them. In the following, we

discuss in more detail the information gathered by the

monitors at the application level. At the application

level, there are several categories within the task pool

execution model where monitor implementations en-

able insights of signiﬁcant relevance:

• Load Balancing: No. of task stealing attempts,

no. of received tasks, response time, consumed

CPU-time, etc.

• Local Task Queue: Size, no. of accesses, details

of most recent access (time, type, initiator), etc.

• Task Processing: No. of completed tasks, con-

sumed CPU-time, status, up-time, no. of basic op-

erations, etc.

• Current Task: Elapsed processing time, no. of

child tasks, occupied memory, etc.

• Task Decomposition: No. of decompositions

(tasks created), no. of failed decompositions, con-

sumed CPU-time, etc.

• Overall Task Pool: No. of active workers, arrival

rate of tasks, up-time, etc.

As part of the prototypical runtime system that

leverages our EDL (cf. Section 5), we provide a set of

monitors that are implicitly accessible without a prior

declaration.

Constraints deﬁne the conditions that the system

must fulﬁll and trigger the execution of strategies

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

476

1 constraints:

2 - name: <string>

3 properties:

4 value_L: <number|monitor name>

5 #left hand value of

comparison,→

6 value_R: <number|monitor name>

7 #right hand value of

comparison,→

8 comparison_operator:

9 <le|ge|eq|lt|gt|ne>

10 #operator to compare

right/left,→

11 time_constraint: <number>

12 #constraint validity in sec

Listing 2: Constraints section within an elasticity policy.

when they are not fulﬁlled. The structure of a con-

straint is shown in Listing 2. Based on the three prop-

erties (value_L, value_R, comparison_operator),

conditional expressions can be speciﬁed. An expres-

sion deﬁnes threshold values for a particular aspect

of the parallel system within it is supposed to oper-

ate. Furthermore, the constraints reﬂect individual

trade-offs that exist between several conﬂicting op-

timization goals at runtime, obliging the user to de-

ﬁne a suitable solution. For parallel computations

in cloud environments, for example, these conﬂict-

ing goals are usually fast processing and low mon-

etary costs. The properties value_L and value_R

can be assigned with constant numeric values or

real-time data retrieved from monitors. Finally,

the time_constraint property deﬁnes the operation

time in seconds, i.e., the period for which the con-

straint is active and gets evaluated.

Strategies are used to specify the steps that need to

be taken if a constraint gets violated. Listing 3 shows

the basic structure of a strategy. The condition

property deﬁnes the constraint whose violation trig-

gers the execution of the strategy’s actions. The em-

ployed set of actions is in accordance with the pre-

viously discussed levels of parallelism. Hence, there

exist actions for controlling the physical parallelism

(e.g., adapting the number of processors) and for con-

trolling the logical parallelism (e.g., adapting the fork

policy for task decomposition).

4 USE-CASES

In this section, we present two exemplary use-cases to

substantiate the capabilities of our proposed elasticity

mechanisms.

1 strategies:

2 - name: <string>

3 properties:

4 condition: <constraint>

5 #Triggering constraint

6 actions: <list of actions>

7 #Actions carried out

Listing 3: Strategies section within an elasticity policy.

In general, parallel applications that rely on dy-

namic problem decomposition (e.g. Boolean satisﬁ-

ability or discrete optimization) share a set of com-

mon runtime characteristics. For example, a reason-

able assumption is that the ongoing decomposition

during computation continuously reduces the granu-

larity of newly generated tasks. The task granular-

ity is deﬁned by the amount of essential computations

in ratio to the amount of communication overhead.

As parallel computation progresses, the overhead for

decomposition and load balancing increases, which

in turn continually reduces parallel efﬁciency. Ul-

timately, decomposition of tasks reaches a granular-

ity where the overhead outweighs the gains achieved

by parallel execution. Particularly at the end of the

computation, when remaining work becomes scarce

and processors begin to compete, decomposition gen-

erates ﬁne-grained tasks, and parallel execution be-

comes inefﬁcient. Since computing resources can no

longer be utilized efﬁciently, users would pay for par-

allel overhead rather than for essential computations.

Whether this is the case can be assessed by moni-

toring the mean time required for the execution of in-

dividual tasks. Falling below a certain threshold, efﬁ-

ciency can be optimized by decreasing the number of

processors. In this way, the degree of physical paral-

lelism is adapted to the degree of logical parallelism.

The speciﬁcation of the threshold enables users to opt

for a trade-off between cost and speedup. Listing 4

shows the elasticity policy containing the speciﬁca-

tion for this use-case.

The policy can be created with minimal effort, as

it requires only a few lines of code. In particular, we

can formulate the previously stated elasticity require-

ments by employing only two elements: One con-

straint and one strategy. Constraint c granularity (cf.

Line 2) deﬁnes the granularity limit of generated tasks

that must be maintained during execution. The ﬁrst

three properties of the constraint are constituents of

a logical expression, specifying that the mean execu-

tion time of tasks must be at least 1000 milliseconds.

The current mean task execution time is obtained by

the monitor m taskProcessingTime. Finally, the last

property speciﬁes that the evaluation of the constraint

An Elasticity Description Language for Task-parallel Cloud Applications

477

1 constraints:

2 - name: c_granularity

3 properties:

4 value_L: m_taskProcessingTime

5 value_R: 1000

6 comparison_operator: ge

7 time_constraint: infinity

9 strategies:

10 - name: s_scaleInPhysicalParallelism

11 properties:

12 conditions: c_granularity

13 actions:

14 physicalParallelism: 0.75

Listing 4: Elasticity speciﬁcation of ﬁrst use-case.

is not limited to a given point in time or period. Com-

plementary to the constraint c granularity, strategy

s scaleInPhysicalParallelism (cf. Line 10) is respon-

sible for its enforcement. According to its properties,

violations of c granularity lead to a decrease in phys-

ical parallelism, i.e., fewer processors will be utilized

during parallel execution. Each violation triggers a

scale-in action, reducing the number of processors to

75% of the currently utilized number.

In the following use case we will deal with an-

other source of parallel overhead in the context of

dynamic problem decomposition, namely processor

idling. Minimizing processor idling is of particular

importance in cloud environments due to the pay-per-

use billing model. Since compute resources are billed

per time unit, without regard to their actual utilization,

idle resources can be an excessive cost driver. In par-

allel applications, a major source of idling overhead

is the lack of logical parallelism, i.e., the number of

available tasks is too low. However, the EDL can be

employed to control the problem decomposition pro-

cess at runtime and thus the number of task instanti-

ations. By monitoring the idling time of processing

units in the task pool, one can assess whether there

is a lack of logical parallelism. If the idle time falls

below a certain threshold, the ratio of called and per-

formed fork statements is adjusted so that the calls re-

sult more often in task instantiations. Listing 5 shows

the elasticity policy for this use-case.

5 EXPERIMENTAL EVALUATION

In this section, we present an experimental evaluation

of the proposed elasticity description language. First,

the methodology and setup of the experimental plat-

form are described in Section 5.1. In Section 5.2, we

1 constraints:

2 - name: c_lowIdleOverhead

3 properties:

4 value_L: m_idle

5 value_R: 0.25

6 comparison_operator: lt

7 time_constraint: infinity

9 strategies:

10 - name: s_scaleOutLogicalParallelism

11 properties:

12 conditions: c_lowIdleOverhead

13 actions:

14 logicalParallelism: 1.25

Listing 5: Elasticity speciﬁcation of second use-case.

then report on a detailed analysis of the correlation be-

tween the elasticity requirements speciﬁed in a policy

and the runtime behavior of a parallel computation.

5.1 Methodology and Platform

To put our work into practice, we have implemented a

prototype of a runtime system that manages the elas-

ticity of a parallel system based on EDL policies. This

prototype employs the distributed task pool execution

model, with each worker being hosted on a separate

virtual machine equipped with 1 vCPU and 2 GB

RAM. The experiments were conducted on our pri-

vate cloud running OpenStack during regular multi-

tenant operation. The hardware underlying this cloud

consists of a cluster of identically conﬁgured servers,

each equipped with two Intel Xeon E5-2650v2 CPUs

and 128 GB RAM.

To demonstrate broad applicability and improve

the reliability of our results, we require an applica-

tion whose parallel execution shows differing runtime

characteristics depending on the input data. This par-

ticularly holds for the class of state space search prob-

lems, which we employ for evaluation purposes. Al-

gorithms that deal with this class of problems implic-

itly construct a search tree in which each node rep-

resents a state, edges constrain state properties, and

paths represent results. As the computation proceeds,

these algorithms explore the state space tree by ex-

panding tree nodes, aiming to ﬁnd proﬁtable paths.

For parallel search algorithms, where the exploration

of individual subtrees takes place simultaneously, the

different and unpredictable sizes of the subtrees can

lead to an imbalance of the load, which in turn signif-

icantly affects scalability. Due to this dynamic pro-

cess, the shape and size of the tree highly depend on

the input data and cannot be estimated in advance by

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

478

a (semi-)static analysis. Since this behavior corre-

sponds to our requirements for the runtime character-

istics, state space search problems are well suited for

our evaluation. However, standard implementations

of representative state space search problems, such

as Boolean satisﬁability or discrete optimization ex-

hibit randomization, resulting in highly varying paral-

lel runtimes for the same input. Furthermore, we can-

not directly control the runtime characteristics, which

renders a systematic investigation of elasticity control

mechanisms unfeasible. Therefore, we employ for

evaluation purposes the Generic State Space Search

Application (GSSSA) presented in (Haussmann et al.,

2018). This application exhibits all relevant charac-

teristics of state space search applications, particu-

larly w.r.t. parallel execution, and allows to explicitly

control runtime characteristics through a small set of

parameters. The total workload is represented by ran-

dom SHA-1 hash calculations and deﬁned by the pa-

rameters w

and w

, each representing a fraction of

the search tree of different structure. The parame-

ter w

deﬁnes the regular fraction where expansions

lead to two subtrees of equal workload. On the other

hand, w

deﬁnes the irregular fraction where the bal-

ancing parameter b speciﬁes the partitioning of the

workload between the expanded subtrees. Finally, the

parameter g speciﬁes the smallest permissible work-

load of expansions. For our evaluation we applied the

parameters w

= 2,500,000,000, w

= 7,500,000,000,

b = 0.001, and g = 1.

5.2 Experimental Analysis of Use-case

In the following, we investigate whether the elasticity

requirements speciﬁed in a policy are adequately ful-

ﬁlled during execution. There are several aspects that

determine the efﬁciency of our approach, such as the

responsiveness of corrective elasticity actions taken

and their impact on the runtime behaviour. In this

evaluation we will employ the elasticity policy of the

ﬁrst use-case, presented in Section 4 (cf. Listing 4).

In particular, we analyze the parallel computations for

four different parameterizations of this policy, which

are shown in Table 1. In the following we refer to

the parameterizations by their IDs (#1-#4). Addition-

ally, we will examine the same parallel computation

utilizing a constant number of processors. This refer-

ence values enables us to draw a comparison between

computations with and without employing elasticity

policies. We performed each computation on a clus-

ter with a capacity of 32 virtual machines.

In the following, we evaluate the performance and

cost aspects of parallel computations employing elas-

ticity policies. Of particular interest for our evaluation

Table 1: Policy parameterizations used for evaluation.

Parameterization

#1 #2 #3 #4

constraints

name c granularity

properties

value L [ms] m taskTime

value R [ms] 500 100 50 10

operator gt

strategies

name s scaleInPhysicalParallelism

properties

conditions not: c granularity

actions physicalParallelism: 0.75

are the parallel runtime T

par

, speedup S, efﬁciency E,

and the costs stemming from the total consumption

of processing time C. Due to the pay-per-use billing

model of the cloud, the consumed processing time di-

rectly translates into monetary costs (thus we can as-

sume w.l.o.g. costs of 1$ per processing time unit).

Without using an elasticity policy, computation gener-

ally would be performed utilizing a constant number

of processors that is selected by the user. As compara-

tive data for our evaluation, we employ two scenarios:

A sequential computation (i.e. number of processors

p = 1) and a parallel computation utilizing a number

of processors p = 32, which will be denoted as #seq

and #par, respectively. This, in turn, allows to de-

termine the overhead that results from the performed

elasticity operations. All computations were carried

out ﬁve times and the results shown in Figure 2 are

based on the arithmetic mean.

The sequential computation #seq has a runtime of

seq

= 5,163 sec, and thus costs of C = 5,163 $. On

the other hand, the parallel computation #par that uti-

lizes a constant number of processors p = 32, has a

parallel runtime of T

par

= 295 sec, resulting in costs

of C = 9,424 $, a speedup of S = 17.53 and an efﬁ-

ciency of E = 0.55. Concerning the parallel runtime

par

of computations that employ elasticity policies,

one can observe that T

par

decreases for smaller lim-

its of the task granularity. This effect occurs since

the number of processors is reduced at earlier stages

of the computation when using large granularity lim-

its. Ordered by decreasing granularity limit, the par-

allel runtime T

par

is 3,333 sec, 1,205 sec, 620 sec, and

296 sec. The corresponding speedups are 1.55, 4.29,

8.32, 17.44 and the efﬁciencies are 0.92, 0.87, 0.83,

and 0.65 accordingly. Compared to the parallel com-

putation #par that utilizes a constant number of pro-

cessors p = 32, policy #4 has the best cost-speedup

trade-off as the runtime is only increased by 0.3%,

but the costs are reduced by 15.5%. Depending on

An Elasticity Description Language for Task-parallel Cloud Applications

479

#par #1 #2 #3 #4

Speedup

0,00

0,20

0,40

0,60

0,80

1,00

#par #1 #2 #3 #4

Efficiency

2000

4000

6000

8000

10000

#seq #par #1 #2 #3 #4

Costs

1000

2000

3000

4000

5000

6000

#seq #par #1 #2 #3 #4

Runtime

[sec]

[$]

Figure 2: Results of parallel computations with and without employing elasticity policies.

whether speedup or cost-savings are considered to be

more relevant, the other policies are preferable. Com-

pared to the most cost-efﬁcient computation, which

in this case is the sequential computation #seq, policy

#1 decreases the runtime by 35.4%, but increases the

costs only by 8.8%.

6 RELATED WORK

As of today, it has been recognized that the utilization

of cloud resources is by no means limited to client-

server applications but also includes parallel applica-

tions. Major cloud providers, like Amazon and Mi-

crosoft, already offer several products that are speciﬁ-

cally designed for parallel applications (Aljamal et al.,

2018). Unlike standard virtual resources, which often

possess heterogeneous processing speeds and high-

latency network-links (Jackson and Ramakrishnan,

2010), these are performance-optimized virtual re-

sources with a high-speed interconnect such as Inﬁni-

Band (Zhang et al., 2017) (Mauch and Kunze, 2013).

From the perspective of cloud consumers, there

exists also a growing trend to migrate parallel ap-

plications into the cloud and render them cloud-

aware (Gupta and Faraboschi, 2016).Recent research

has indicated that several classes of parallel applica-

tions are well suited for migration, while some oth-

ers can only be migrated with limitations (Kehrer

and Blochinger, 2019c). How this migration takes

place depends on the requirements of the respective

application. The survey conducted in (Kehrer and

Blochinger, 2019a) has found that there exist three

prevalent cloud migration strategies of varying com-

plexity in existing research: Copy and paste, cloud-

aware refactoring, and cloud-aware refactoring, in-

cluding elasticity control. For parallel applications,

on the one hand, these strategies aim to mitigate the

adverse effects of characteristics inherent in cloud

environments. For example, heterogeneous capaci-

ties of virtual resources such as processors and net-

works, degrade the performance of parallel appli-

cations, especially when synchronous communica-

tion is required. On the other hand, more sophis-

ticated strategies aim to enable parallel applications

to take advantage of cloud characteristics such as

on-demand resource access, elasticity, and pay-per-

use billing (Netto et al., 2018), (Rajan and Thain,

2017), (Haussmann et al., 2019).

Elasticity, in particular, is a cloud characteris-

tic that holds great potential for parallel applica-

tions. Previous research such as (Galante et al.,

2016) and (Kehrer and Blochinger, 2019b) high-

lighted the need for elasticity support at the appli-

cation level and emphasized the relevance of novel

frameworks for constructing elastic parallel cloud ap-

plications. Our work validates these results and pro-

vides a better insight into the underlying elasticity

mechanisms for parallel cloud applications.

Rule-based control of cloud systems has become

an increasingly important topic in the domain of cloud

computing. On the one hand, most cloud providers

have such offers directly available to consumers on

their platforms, such as OpenStack or AWS, which

leverage the formats HOT and CFN. Meanwhile, an

increasing number of studies on this issue indicates

a growing interest in research. In (Copil et al.,

2015), the authors introduce a language that enables

the speciﬁcation of multi-level elasticity requirements

for cloud services. These elasticity requirements are

high-level demands, formulated by the user, concern-

ing a cloud service. Furthermore, they proposed a

model that considers elasticity as a multidimensional

space in which the system can oscillate. An architec-

ture for controlling the behavior of cloud services is

presented in (Jennings and Stadler, 2014). By lever-

aging the introduced abstractions and rules engine,

applications can exploit virtual resources from differ-

ent cloud providers simultaneously to control appli-

cation behavior. In contrast to our work, their ap-

proach focus on elasticity for client-server applica-

tions, while elasticity mechanisms mainly act at the

infrastructure level. Our work focuses on parallel ap-

plications and enables elastic task parallelism in cloud

environments, by applying elasticity on both the logi-

cal and the physical level of a parallel system.

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

480

7 CONCLUSION

In this paper, we introduced an elasticity description

language that enables the speciﬁcation and utiliza-

tion of elasticity policies at both the cloud infrastruc-

ture and application level. Concepts and mechanisms

of this language are speciﬁcally designed for parallel

applications that rely on the fork-join programming

model. Our work deals with aspects of elasticity that

go beyond the traditional context, which usually con-

siders virtual infrastructures solely. The use cases pre-

sented and the evaluation performed have proven the

viability of our work and demonstrate that elasticity

is an issue beyond the infrastructure level.

REFERENCES

Aljamal, R., El-Mousa, A., and Jubair, F. (2018). A com-

parative review of high-performance computing major

cloud service providers. In Proc. of the 9th Int. Conf.

on Information and Communication Systems, pages

181–186.

Blochinger, W., K

uchlin, W., Ludwig, C., and Weber, A.

(1999). An object-oriented platform for distributed

high-performance symbolic computation. Mathemat-

ics and Computers in Simulation, 49(3):161–178.

Blochinger, W., Weber, A., and K

uchlin, W. (1998). The

Distributed Object-Oriented Threads System DOTS.

In Proc. of the 5th Int. Symp. on Solving Irregularly

Structured Problems in Parallel, pages 206–217.

Blumofe, R. D., Leiserson, C. E., and Joerg, C. F. (1995).

Cilk: An Efﬁcient Multithreaded Runtime System.

In Proc. of the 5th ACM SIGPLAN Symposium, vol-

ume 30, pages 207–216.

Copil, G., Moldovan, D., and Dustdar, S. (2015). On Con-

trolling Elasticity of Cloud Applications in CELAR.

In Emerging Research in Cloud Distributed Comput-

ing Systems, pages 222–252.

Galante, G. and Bona, L. C. (2014). Supporting elasticity in

OpenMP applications. In Proc. of the 22nd Int. Conf.

on Parallel, Distributed, and Network-Based Process-

ing, pages 188–195.

Galante, G., Erpen De Bona, L. C., Mury, A. R., Schulze,

B., and da Rosa Righi, R. (2016). An Analysis of

Public Clouds Elasticity in the Execution of Scientiﬁc

Applications: a Survey. Journal of Grid Computing,

14(2):193–216.

Gupta, A. and Faraboschi, P. (2016). Evaluating and Im-

proving the Performance and Scheduling of HPC Ap-

plications in Cloud. IEEE Transactions on Cloud

Computing, 4(3):307–321.

Haussmann, J., Blochinger, W., and Kuechlin, W. (2018).

Cost-efﬁcient Parallel Processing of Irregularly Struc-

tured Problems in Cloud Computing Environments.

Cluster Computing, 22(3):887–909.

Haussmann, J., Blochinger, W., and Kuechlin, W. (2019).

Cost-optimized Parallel Computations using Volatile

Cloud Resources. In Proc. of the 16th Int. Conf. on the

Economics of Grids, Clouds, Systems, and Services,

pages 45–53.

Jackson, K. and Ramakrishnan, L. (2010). Performance

Analysis of High Performance Computing Applica-

tions on the AWS Cloud. In Proc. of the 2nd Int. Conf.

on Cloud Computing Technology and Science, pages

159–168.

Jennings, B. and Stadler, R. (2014). Resource Management

in Clouds. Journal of Network and Systems Manage-

ment, 23(3):567–619.

Kehrer, S. and Blochinger, W. (2019a). A Survey on Cloud

Migration Strategies for High Performance Comput-

ing. In Proc. of the 13th Advanced Summer School

on Service-Oriented Computing. IBM Research Divi-

sion.

Kehrer, S. and Blochinger, W. (2019b). Elastic Parallel Sys-

tems for High Performance Cloud Computing: State-

of-the-Art and Future Directions. Parallel Processing

Letters, 29(2).

Kehrer, S. and Blochinger, W. (2019c). Migrating parallel

applications to the cloud: assessing cloud readiness

based on parallel design decisions. Software-Intensive

Cyber-Physical Systems, 34(2-3):73–84.

Mauch, V. and Kunze, M. (2013). High performance cloud

computing. Future Generation Computer Systems,

29(6):1408–1416.

Netto, M. A., Calheiros, R. N., Rodrigues, E. R., Cunha,

R. L., and Buyya, R. (2018). HPC cloud for scientiﬁc

and business applications. ACM Computing Surveys,

51(1).

Rajan, D. and Thain, D. (2017). Designing Self-

Tuning Split-Map-Merge Applications for High Cost-

Efﬁciency in the Cloud. IEEE Transactions on Cloud

Computing, 5(2):303–316.

Skillicorn, D. B. and Talia, D. (1998). Models and lan-

guages for parallel computation. ACM Computing

Surveys, 30(2):123–169.

Zhang, J., Lu, X., and Panda, D. K. (2017). Designing local-

ity and NUMA aware MPI runtime for nested virtual-

ization based HPC cloud with SR-IOV enabled Inﬁni-

Band. In Proc. of the 13th ACM SIGPLAN/SIGOPS,

pages 187–200.

An Elasticity Description Language for Task-parallel Cloud Applications

481
