Comparison of Search Servers for Use with Digital Repositories

Aluísio Augusto Silva Gonçalves

and Marcos Sfair Sunye

Department of Informatics, Federal University of Paraná, Curitiba, Brazil

Keywords:

Digital Libraries, Information Retrieval, Benchmark, Lucene.

Abstract:

Search is a fundamental operation of storage systems, such as digital repositories, and their performance and

quality directly impact the user’s opinion of a system. This paper evaluates two different search engines,

Apache Solr and Elasticsearch, for the same repository and reports the pros and cons of each for that speciﬁc

use case. In particular, we identify that although Elasticsearch consumes less resources and responds to most

queries more quickly, it may also take longer to respond in some scenarios.

1 INTRODUCTION

Search is an essential use case of databases and doc-

ument storage systems, and is the focus of an entire

discipline of computer science: information retrieval,

deﬁned by Manning et al. (2009) as the act of locat-

ing materials (usually documents) of an unstructured

nature (such as plain text) present in large collections

(usually computers) that satisfy an information need,

in opposition to traditional mechanisms of data re-

trieval that rely on an unique identiﬁer associated with

a particular datum.

One kind of document storage system is the digital

repository (or digital library), an specialized system

that manages preservation and access to digital ﬁles,

and which is publicly used mostly by universities and

research institutes as a tool for the dissemination of

scientiﬁc knowledge (Ferreira and Sunye, 2017).

To Schatz (1997), one of the fundamental aspects

of digital repositories is the ability to search and ﬁl-

ter their contents according to the user’s needs. Par-

ticularly for user-facing operations, the performance

of searches, as measured both in response time and

quality of the results, inﬂuences the perception of the

system as a whole (Joseph et al., 1989). Thus, it is

in the interest of digital repository operators to evalu-

ate different search engines in the context of a single

system, so as to select the most user-friendly option.

Per the Directory of Open Access Reposito-

ries (Jisc, 2019) and the Registry of Open Access

Repositories (University of Southampton, 2019), the

https://orcid.org/0000-0002-1844-6540

https://orcid.org/0000-0002-2568-5697

DSpace

platform is the one used by the majority of

public digital repositories. DSpace uses the Apache

Solr

search server for its document search and or-

ganization needs, and Solr in turn wraps the Lucene

search library, which does much of the heavy lifting

involved in a search.

A similar project in the same space as Solr is Elas-

ticsearch

, that works with new paradigms and tech-

nologies and takes advantage of today’s distributed

computing environments (Banon, 2010; Gospodneti

2015). By virtue of sharing the Lucene core library

with Solr, Elasticsearch can be used, with some adap-

tation, in lieu of the Apache project’s search server.

This makes both projects candidates for the kind of

comparison previously considered in this work.

With this context, the aim of this work is to eval-

uate the quality of results returned by these two tex-

tual information retrieval systems, Apache Solr and

Elasticsearch, when operating in conjunction with a

DSpace document repository. To do so, we will re-

view basic concepts of information retrieval and ex-

amine the software to be tested, then present the eval-

uation methodology and test setup, then conclude

with a discussion of the results and of future works

stemming from them.

https://duraspace.org/dspace/

https://lucene.apache.org/solr/

https://lucene.apache.org/core/

https://www.elastic.co/elasticsearch

256

Gonçalves, A. and Sunye, M.

Comparison of Search Servers for Use with Digital Repositories.

DOI: 10.5220/0009577102560260

In Proceedings of the 22nd International Conference on Enterprise Information Systems (ICEIS 2020) - Volume 1, pages 256-260

ISBN: 978-989-758-423-7

2 CONCEPTS FROM

INFORMATION RETRIEVAL

Current information retrieval systems work with col-

lections of arbitrary documents that can be auto-

matically or manually associated with the informa-

tion present in each document represented as terms

(Baeza-Yates and Ribeiro-Neto, 1999). This associa-

tion is usually maintained in an inverted index, a cor-

respondence between terms and documents.

Two main metrics are used to assess the quality

of results returned by a query to an information re-

trieval system: precision, deﬁned as the proportion of

the results that are considered relevant to that query,

i.e. those that are correctly present in the results; and

recall, that considers how many relevant documents

have been returned as search results, and is computed

as the ratio between the number of relevant docu-

ments returned and the total number of relevant docu-

ments in the base. These metrics are used as building

blocks for many others, and are henceforth denomi-

nated primitive metrics for the rest of this article.

Mandl (2008) notes that these metrics alone, as

well as combinations such as measure-F, work bet-

ter when results are collected in an unordered set;

when the results are presented in an ordered fash-

ion, it is possible to take this new information into

account during the evaluation. Jones et al. (1995);

Latha (2016) discuss two measures of particular inter-

est to digital repositories: precision-at-k, which limits

the set of results to those appearing on the ﬁrst page

shown to the user (i.e. the ﬁrst k results); and mean

precision, given by the arithmetic mean of the pre-

cision calculated for each relevant document as it is

found in the list of results.

A limitation of these metrics is their dependence

on the correct and complete identiﬁcation of relevant

and non-relevant documents, in particular those de-

rived from the recall primitive. When it is not possible

to evaluate all the documents in the collection from

this perspective, it is advantageous to use the binary

preference metric, or bpref (Buckley and Voorhees,

2004), deﬁned simply as the number of times docu-

ments deemed non-relevant are retrieved before doc-

uments assumed relevant by the system.

Metrics such as precision-at-k and bpref are used,

among others, as one of the metrics for benchmarks

in the Text Retrieval Conference (Hersh et al., 2006),

an event whose publications center on the develop-

ment and evaluation of both generic and task-speciﬁc

information retrieval systems (Stokes, 2006).

3 TESTED SOFTWARE

Jantz and Giarlo (2005) deﬁnes a digital repository as

a platform to catalogue, preserve, and access digital

ﬁles, whether they are digitized (e.g. books or news-

paper issues) or native digital objects (such as spread-

sheets, e-books, and multimedia ﬁles).

From the multiple digital repository systems avail-

able presently, the DSpace software originally devel-

oped by the Massachusetts Institute of Technology

and Hewlett-Packard (Smith et al., 2003) can be con-

sidered the leading solution in use for publicly avail-

able repositories (Jisc, 2019; University of Southamp-

ton, 2019). That makes it a prime candidate for which

to analyze the quality of information retrieval.

Underlying DSpace’s search capabilities is the

Apache Solr enterprise search server, which receives

commands and queries over the HTTP protocol and

can operate over multiple distinct document bases

called cores (Veenhof, 2012).

Actual interaction with the cores, including in-

sertions and queries, is done through the Apache

Lucene library. Lucene indexes documents composed

of key-value pairs (termed ﬁelds) into an inverted in-

dex structure. When responding to a query, results are

sorted with the BM25 function described by Robert-

son et al. (1995), and relevant parts can be indicated

for highlighting by the client application (Gospod-

neti

c and Hatcher, 2005).

For DSpace, the indexed ﬁelds include ﬁle meta-

data such as title, author, subject, among others; the

transcribed textual content of the ﬁle, when available;

and the location of the ﬁle within the repository.

Despite operating in a client-server model, Solr

did not originally have any support for multiple

servers, which would enable features such as load bal-

ancing, database replication, and fail-over. The Elas-

ticsearch server was created to ﬁll these shortcomings

while taking advantage of new paradigms developed

after Solr’s origin (Gospodneti

c, 2015).

4 RELATED WORKS

Because Elasticsearch too uses Lucene as its underly-

ing search engine, multiple comparisons can be found

between it and Solr. Few of them, however, explore

the performance and search result quality differences

between both systems.

Coviaux (2019) presents a detailed framework

for optimization of Elasticsearch search results after

choosing it over Solr due to developer friendliness;

however, no discussion is had about the runtime per-

formance and requirements of either search servers,

Comparison of Search Servers for Use with Digital Repositories

257

nor there is a comparison of their search results.

Correia (2016), while developing a clinical

database system, ranks Solr higher due to superior

documentation of its query language. Once again, the

comparison does not reach a stage in which the search

servers are tested in a live environment.

Kılıç and Karabey (2016) compare the replication

and security aspects of Elasticsearch and Solr, favour-

ing the former due to its greater ﬂexibility in regards

to distributed conﬁgurations.

Luburi

c and Ivanovi

c (2016) perform a direct

comparative analysis of both search servers directly

and conclude that they perform similarly for plain

text indexing, while Elasticsearch outperforms Solr

on analytical queries such as those present on big data

workloads.

Akca et al. (2016) provide a direct and extensive

performance study of Elasticsearch and Solr, outside

of any particular usage or workload, that ﬁnds that

Elasticsearch has a pronounced advantage over Solr in

response time with more than 100 concurrent queries,

particularly when the underlying document set is still

being indexed. We have found that, in the context of

digital repositories and our particular document set,

the actual difference is half of what was reported.

5 METHODOLOGY

Inspired by the methodology used at the Text Re-

trieval Conference, we designed a full benchmark for

evaluating the search servers, as outlined by Dekhtyar

and Hayes (2006).

The document set upon which the searches were

performed is based on the contents of the Digital

Archive of the Federal University of Paraná

(UFPR)

on February 21, 2019. The document set upon which

the searches were performed is based on the contents

of the Digital Archive [REDACTED] on February 21,

2019.

To select the queries to be made part of the bench-

mark, we analysed all searches made in the Digital

Archive between 2015 and August 2019. 30 queries

were used, that cover the composition of over 99 % of

searches. The ﬁelds queried in each of the selected

search patterns are listed on Table 1.

The quality of the results was measured using

the precision-at-10 and binary preference metrics.

Precision-at-10 reﬂects the relevancy of the docu-

ments presented in the ﬁrst page of search results

seen by a user, and thus is a proxy measure for the

perceived quality of those results. Binary preference

https://acervodigital.ufpr.br

was designed to measure the average relevancy of the

search results while being resistant to incomplete rel-

evancy judgements of the document set (Allan et al.,

2005), thus being well suited for benchmarks com-

posed of thousands of documents. These metrics are

the same ones used, along with others, by the Text

Retrieval Conference (Hersh et al., 2006), an event

whose publications center on the development and

evaluation of both generic and task-speciﬁc informa-

tion retrieval systems (Stokes, 2006).

Tests were run on a DSpace instance hosted on a

virtual machine with dedicated hardware, including 8

virtual cores and 19 GiB of RAM with no disk swap

conﬁgured, mirroring the production setup of UFPR’s

Digital Archive. Tests were run on a DSpace instance

hosted on a virtual machine with dedicated hardware,

including 8 virtual cores and 19 GiB of RAM with

no disk swap conﬁgured, mirroring the production

setup of the Digital Archive. The instance could be

switched to use either the built-in Solr server or a

standalone Elasticsearch server for resolving search

queries. Memory and resource usage during search

index creation were tracked using the pidstat tool

and information available through Linux’s /proc ﬁle

system. Resource usage during searches proved dif-

ﬁcult to isolate from other tasks being done concur-

rently, and thus was not included.

6 RESULTS

Table 2 presents the overall resource consumption

of the indexing process. It can be noted that Elas-

ticsearch’s resource consumption is 1.5 to 4 times

smaller than Solr, for the same dataset. The fact that

Solr runs in the same process as DSpace itself ac-

counts for the increased memory usage, but not for

the extra time spent (since DSpace was idle during

this phase of the tests) nor for the disk space used

by the search cores (which are wholly within Solr’s

purview).

Table 3 summarizes the metrics calculated for the

search queries executed against both Solr and Elas-

ticsearch through DSpace. When averaged over all

search queries, the difference in search result quality

is less than 5 %.

The response time for queries shows a less com-

promising story, however. While Solr starts respond-

ing to queries after about a second, Elasticsearch re-

sponses are sent back in under 500 ms. However,

when many documents are returned from a query, as

when one navigates the repository from DSpace’s in-

terface, Solr takes up to 5 seconds to ﬁnish its re-

sponse, with Elasticsearch concluding after almost 15

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

258

Table 1: Fields included in each search query class.

no. all Has ﬁles? Author Date Subject Type

1 X X X X

2 X X X

3 X

4 X X

5 X X

6 X X

7 X X X

8 X

9 X X X

10 X X

11 X X X

12 X X

13 X X X X

14 X X X

15 X X X

16 X

17 X X X X

18 X X

19 X X X X

20 X

21 X X X X X

22 X X

23 X

24 X X

25 X X X

26 X X X

27 X

28 X X

29 X X X

30 X X X X

Table 2: Comparison of resource usage during indexing by

the Solr and Elasticsearch search servers.

Resource Solr Elasticsearch

Total time 224 min 53 min

Maximum RAM usage 20 978 MiB 11 201 MiB

Index disk space 11 513 MiB 7 152 MiB

Table 3: Median precision-at-10 and binary preference met-

rics over all search queries, when using Solr or Elastic-

search as search server.

Metric Solr Elasticsearch

Precision at 10 0.3469 0.3315

b-pref 0.2148 0.2243

seconds. The 3x difference in the worst-case scenario

must be carefully observed by repository operators, as

it’s directly noticeable by end users.

7 CONCLUSIONS

Searches in document storage systems are one of the

facets through which users interact and ultimately

perceive these systems, and the quality of search re-

sults has an impact on this perception. By comparing

two similar search servers as part of the functioning

of the same large application, this work aims to iden-

tify their strengths, weaknesses, and suitability for the

domain of digital repositories.

We used the DSpace repository software as a plat-

form for comparisons between the Solr and Elastic-

search search servers, both of which use the Lucene

library as their search engine while offering different

features and performance proﬁles.

Overall, even as it use the same underlying search

engine as Solr, Elasticsearch offers signiﬁcant sav-

ings in resource usage while keeping a similar level

of quality in its results, but at the cost of occasional

high latency while navigating the stored documents.

This trade-off must be carefully observed by reposi-

tory operators that might wish to switch their systems’

search servers.

8 FUTURE WORKS

We intend to continue development of the benchmark

used in this work and to release it publicly so that it

can be applied to other repository software and search

engines. We also plan to increase its scope to cover

search engines not based on inverted indexes, such as

Treap

and WT1RMQ

(Gog et al., 2017).

ACKNOWLEDGEMENTS

This study was ﬁnanced in part by the Coordenação

de Aperfeiçoamento de Pessoal de Nível Superior –

Brasil (CAPES) – Finance Code 001.

REFERENCES

Akca, M. A., Aydo

gan, T., and

Ilkuçar, M. (2016). An anal-

ysis on the comparison of the performance and con-

ﬁguration features of big data tools Solr and Elastic-

search. International Journal of Intelligent Systems

and Applications in Engineering, 6(special issue):8–

12.

Allan, J., Carterette, B., and Lewis, J. (2005). When will

information retrieval be “good enough”? In Proceed-

ings of the 28th annual international ACM conference

on research and development in information retrieval,

pages 433–440. ACM.

Comparison of Search Servers for Use with Digital Repositories

259

Baeza-Yates, R. and Ribeiro-Neto, B. (1999). Modern In-

formation Retrieval. Addison-Wesley.

Banon, S. (2010). ElasticSearch, Sphinx, Lucene, Solr,

Xapian. Which ﬁts for which usage? Response from

kimchy.

Buckley, C. and Voorhees, E. M. (2004). Retrieval eval-

uation with incomplete information. In Proceedings

of the 27th Annual International ACM SIGIR Con-

ference on Research and Development in Information

Retrieval, pages 25–32. ACM.

Correia, J. d. S. B. C. (2016). Indexação de documentos

clínicos. Master’s thesis, Faculdade de Engenharia,

Universidade do Porto.

Coviaux, Q. (2019). Optimization of the search engine Elas-

ticSearch. Master’s thesis, Facultat d’Informàtica de

Barcelona, Universitat Politècnica de Catalunya.

Dekhtyar, A. and Hayes, J. H. (2006). Good benchmarks

are hard to ﬁnd: Toward the benchmark for informa-

tion retrieval applications in software engineering. In

Proceedings of the 22nd International Conference on

Software Maintenance. IEEE.

Ferreira, E. and Sunye, M. S. (2017). A method for gather-

ing and classiﬁcation of scientiﬁc production metadata

in digital libraries. In Proceedings of the 19th Interna-

tional Conference on Enterprise Information System,

volume 1, pages 357–364. SCITEPRESS.

Gog, S., Konow, R., and Navarro, G. (2017). Practical com-

pact indexes for top-k document retrieval. Journal of

Experimental Algorithmics, 22.

Gospodneti

c, O. (2015). Solr vs. Elasticsearch — how to

decide?

Gospodneti

c, O. and Hatcher, E. (2005). Lucene in Action.

Manning.

Hersh, W., Cohen, A., Yang, J., Bhupatiraju, R. T., Roberts,

P., and Hearst, M. (2006). TREC 2005 genomics track

overview. In NIST Special Publication 500-266: 14th

Text Retrieval Conference. NIST.

Jantz, R. and Giarlo, M. J. (2005). Digital preservation:

Architecture and technology for trusted digital reposi-

tories. Microform & Imaging Review, 34(3):135–147.

Jisc (2019). Directory of Open Access Repositories. Statis-

tics.

Jones, G. J. F., Foote, J. T., Jones, K. S., and J., Y. S. (1995).

Video mail retrieval: the effect of word spotting accu-

racy on precision. In Proceedings of the 1st Interna-

tional Conference on Acoustics, Speech, and Signal

Processing, pages 309–312. IEEE.

Joseph, B., Steinberg, E. R., and Jones, A. R. (1989). User

perceptions and expectations of an information re-

trieval system. Behaviour & Information Technology,

8(2):77–88.

Kılıç, U. and Karabey, I. (2016). Comparison of Solr and

Elasticsearch among popular full text search engines

and their security analysis.

Latha, K. (2016). Experiment and Evaluation in Informa-

tion Retrieval Models. CRC Press.

Luburi

c, N. and Ivanovi

c, D. (2016). Comparing apache

solr and elasticsearch search servers. In Proceedings

of the Sixth International Conference on Information

Society and Technology, volume 2, pages 287–291.

Society for Information Systems and Computer Net-

works.

Mandl, T. (2008). Recent developments in the evaluation of

information retrieval systems: Moving towards diver-

sity and practical relevance. Informatica, 32(1):27–

38.

Manning, C. D., Raghavan, P., and Schütze, H. (2009). An

Introduction to Information Retrieval. Cambridge UP.

Robertson, S. E., Walker, S., Jones, S., Hancock-Beaulieu,

M. M., and Gatford, M. (1995). Okapi at TREC-3. In

NIST Special Publication 500-225, volume 3, pages

109–126. NIST.

Schatz, B. R. (1997). Information retrieval in digi-

tal libraries: Bringing search to the net. Science,

275(5298):327–334.

Smith, M., Barton, M., Bass, M., Branschofsky, M., Mc-

Clellan, G., Stuve, D., Tansley, R., and Walker, J. H.

(2003). Dspace: An open source dynamic digital

repository. D-Lib Magazine, 9(1).

Stokes, N. (2006). Trec: Experiment and evaluation

in information retrieval. Computational Linguistics,

32(4):563–567.

University of Southampton (2019). Registry of Open Ac-

cess Repositories. Browse by repository software.

Veenhof, N. (2012). Improving Acquia search and the

Apache Solr module. Master’s thesis, Facultat

d’Informàtica de Barcelona, Universitat Politècnica

de Catalunya.

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

260
