Helper-in-the-Middle: Supporting Web Application Scanners Targeting

Industrial Control Systems

Anne Borcherding

1 a

, Steffen Pfrang

1 b

, Christian Haas

, Albrecht Weiche

and J

urgen Beyerer

1,2

Fraunhofer IOSB, Karlsruhe, Germany

Vision and Fusion Laboratory (IES), Karlsruhe Institute of Technology (KIT), Karlsruhe, Germany

Keywords:

Industrial Control Systems, Black Box Security Testing, Web Application Scanners, Proxy, Usability.

Abstract:

Web applications on industrial control systems (ICS) provide functionality such as obtaining status information

or updating conﬁgurations. However, a web application possibly adds additional attack vectors to the ICS. In

order to ﬁnd existing vulnerabilities of web applications, automated black box web application scanners (WAS)

can be used. Evaluations of existing scanners show similar limitations in their applicability. For example, ICS

often crash during a scan. If the used scanner does not recognize and handle this issue, it is not able to

ﬁnish the test. We present HelpMeICS which makes improvements available for different scanners without

the need to adapt the speciﬁc scanner. It is implemented as a proxy-based solution which is transparent for the

scanners and handles different aspects such as error-handling, authentication, and replacement of contents. Our

evaluation with ﬁve different ICS shows an improvement of applicability as well as a reduction of additional

limitations of WAS. As an example, our improvements increased the URL coverage from 8% to 100%. For

one of the ICS, a complete scan was only made possible by HelpMeICS since the ICS crashed irrecoverably

during the scans without HelpMeICS.

1 INTRODUCTION

ICS play an elementary role in making production

faster, more reliable and more ﬂexible. Correspond-

ing device classes are, amongst others, programmable

logic controllers (PLC), bus couplers, gateways, and

industrial ﬁrewalls. Most ICS include a communica-

tion interface over Ethernet to transfer process data

or status information, either to a local communica-

tion partner or even to a communication partner in the

cloud. Due to a high priority on improving the fea-

tures of ICS, security often gets neglected during the

development process.

The lack of security is critical since ICS pose an

interesting target for attackers. With their two com-

munication channels, ICS possibly build a bridge for

an attacker trying to attack the production process

from the Internet. In a simple case – as discovered

during this work – a single HTTP packet sufﬁces

to stop a production process from anywhere in the

world. A more advanced case is pivoting in the au-

tomation network which may also lead to data leak-

age, disruption of safety systems, damage to facilities

https://orcid.org/0000-0002-8144-2382

https://orcid.org/0000-0001-7768-7259

Automation Network

ICS

...

ICS

Attacker

HTTP(S)

Figure 1: An attacker uses the web application (WA) of

ICS

as an entry point to the automation network.

or even human harm. This situation is presented in

Figure 1: The attacker uses the web application of an

ICS as an entry point. Based on this, the attacker can

start pivoting using, for example, unsecured industrial

communication protocols such as PROFINET.

Security testing is a major measure to improve the

security of software in general and of ICS in partic-

ular. It aims at revealing vulnerabilities in an early

stage of the development life cycle as well as ﬁnd-

ing vulnerabilities in a later stage. There exist differ-

ent security testing approaches, ranging from model

based tests of the architecture to penetration tests of

the already published product (Felderer et al., 2016).

The requirement to perform security testing is also

postulated in the IEC 62443 standard (IEC62443,

Borcherding, A., Pfrang, S., Haas, C., Weiche, A. and Beyerer, J.

Helper-in-the-Middle: Supporting Web Application Scanners Targeting Industrial Control Systems.

DOI: 10.5220/0009517800270038

In Proceedings of the 17th International Joint Conference on e-Business and Telecommunications (ICETE 2020) - SECRYPT, pages 27-38

ISBN: 978-989-758-446-6

2019) which targets security for industrial automation

and control systems.

The aim of this work is to detect vulnerabilities in

ICS using automated black box WAS. WAS provide

a cost-efﬁcient approach on ﬁnding vulnerabilities of

a web application. Since they run automatically, they

can be used to conduct tests on a regular basis (Bau

et al., 2010). However, literature shows various simi-

lar limitations of WAS, many of them concerning the

methodology and applicability of WAS.

This work presents a comprehensive solution ap-

proaching many of these limitations. Note that we

are not presenting a new WAS since we are con-

vinced that there are plenty sophisticated WAS out

there. Instead, we are presenting a framework to im-

prove the methodology and applicability of existing

WAS: HelpMeICS. With HelpMeICS, it is possible

to make improvements transparently available for ar-

bitrary WAS. It consists of a proxy, which is located

between the WAS and the device under test (DUT),

containers in which the WAS run, and an integration

into the industrial security testing framework ISuTest

(Pfrang et al., 2017).

In summary, the main contributions of this paper

are the following:

• Review of limitations identiﬁed and improve-

ments achieved by existing evaluations of WAS.

• HelpMeICS: A system to make improvements of

methodology and applicability available for exist-

ing WAS.

• Extensive evaluation of HelpMeICS using real

ICS as targets that shows reduced limitations, in-

creased number of true positive reports as well as

a higher URL coverage.

• Publication of the source code of the developed

add-ons for the open source proxy mitmproxy,

which also can be run as a stand-alone system

1,2

Following this introduction, Section 2 provides more

information on ICS and security testing. In Section 3,

we present a review to show limitations identiﬁed and

improvements achieved by literature. Building upon

this background, we present the design of HelpMeICS

in Section 4. A qualitative and quantitative evaluation

is shown in Section 5. Finally, our conclusions are

presented in Section 6.

https://github.com/mitmproxy/mitmproxy/pull/3961

https://github.com/mitmproxy/mitmproxy/pull/3962

2 BACKGROUND

Automated black box security testing of all commu-

nication interfaces plays an important role in improv-

ing ICS security. This includes web security testing

if the DUT provides a web interface. The following

provides some context on ICS and security testing as

well as on ISuTest, a security testing framework that

serves as a building block for HelpMeICS.

2.1 Industrial Control Systems

The main task of ICS is to control and monitor pro-

cesses in industrial environments. In order to achieve

this task or to provide additional services, ICS need

to communicate to other nodes in the industrial net-

work. In former times, industrial networks have been

set up using proprietary communication protocols and

corresponding wiring. Nowadays, the communica-

tion is performed using Ethernet wiring and Ethernet-

based protocols. By using these Ethernet-based proto-

cols such as PROFINET or EtherCat, requirements of

industrial communication such as real-time commu-

nication can be fulﬁlled using standardized Ethernet

hardware (Galloway and Hancke, 2012).

Next to these specialized protocols, ICS commu-

nicate using standard Internet protocols such as UDP

or TCP. For an attacker, the barrier to attack these

protocol stacks is especially small, since well known

techniques and tools exist. In addition, the possible

outcome of an successful attack is enormous. An suc-

cessful attack can lead to an interruption of produc-

tion, data leakage as well as physical damage to the

production or humans (BSI, 2019).

Awareness for security issues in the industrial do-

main is rising steadily. One of the triggers for this

surely was Stuxnet (Langner, 2011). By now, the

International Electrotechnical Commission (IEC) has

published several standards concerning the security

for ICS (IEC62443, 2019). But still, the implemen-

tation and integration of security in industrial net-

works and systems is an ongoing process that just has

started. To keep this process going, practicable solu-

tions to ﬁnd vulnerabilities need to be offered. Our

work contributes to the fulﬁlment of this need.

2.2 Security Testing

Security testing can be categorized and arranged us-

ing various metrics and dimensions. A full descrip-

tion of these categories is beyond the scope of this

work which is focussed on automated black box

web application scanning of ICS. Nevertheless, the

speciﬁcs of our point of view on security testing for

SECRYPT 2020 - 17th International Conference on Security and Cryptography

ICS are to be elaborated. Felderer et al. give a

good overview on the categorization of security test-

ing (Felderer et al., 2016).

Automated: This keyword refers to the meaning of

automated as opposed to manual. Automated security

testing is easier to integrate into a development life

cycle, since tests can be run on a regular basis and the

security status of the DUT can be monitored easily.

Black Box: For black box testing, only the ex-

ternal inputs and outputs of the DUT are considered.

With this, no internal information of the DUT needs

to be disclosed. Simpliﬁed, input is sent to the DUT

and the following reaction of the DUT is monitored

based on its output. In the case of ICS testing, the in-

puts are network packets and the output may be any

external interface of the DUT. This includes digital or

analog I/O as well as various network protocol stacks.

Web Application Scanning: Each additional fea-

ture of an ICS poses an additional attack vector. This

also holds for the web applications many ICS are

running for maintenance purposes. Web applications

simplify maintenance tasks such as obtaining status

information or updating the ﬁrmware. Additionally,

they often simplify attacking the ICS. Many hacking

tools are available for the web domain since web ap-

plication hackers have existed almost as long as the

web exists. This makes hacking web applications eas-

ier than hacking an industrial protocol for which an

attacker needs special domain knowledge. It follows

that the existence of web applications on ICS makes

hacking ICS much easier.

2.3 ISuTest

ISuTest is a security testing framework for ICS

(Pfrang et al., 2017). We use its different features for

black box testing of ICS for HelpMeICS. One fea-

ture of ISuTest is to conﬁgure and start so called test

scripts which deﬁne the parameters and speciﬁcations

of test sequences. For example, a test sequence might

be a fuzzing test for UDP or a test sequence probing

the DUT for a speciﬁc vulnerability in its PROFINET

protocol stack. During a test, the DUT is monitored

continuously using different outputs such as digital or

analog I/O as well as network protocols such as ICMP,

TCP, HTTP, and PROFINET. In addition, ISuTest is

able to restart a DUT by switching the power off and

on. With this, ISuTest is able to reset the DUT before

each test and is also able to restart the DUT after a

crash. We are using these features of ISuTest as one

building block for HelpMeICS.

3 REVIEW

This work addresses the following requirements: (I)

reducing the limitations of existing WAS regarding

their applicability, while (II) not restricting this re-

duction to some WAS, but by making improvements

available independently of the speciﬁc WAS, and (III)

making the code publicly available. To the best of our

knowledge, no existing open source tool fulﬁlls all of

the formulated requirements. For the usage against

web applications on industrial hardware, DUT spe-

ciﬁc changes are often necessary. Because of this,

public availability of the code is a fundamental re-

quirement. As a result, we do not include commercial

solutions but focus on results from literature.

Literature includes various evaluations of WAS

which show limitations as well as improvements. The

following review is based on 15 papers aiming at

comparing different black box WAS (Bau et al., 2010;

Pfrang et al., 2019; Makino and Klyuev, 2015; Idrissi

et al., 2017; Vega et al., 2017; Doup

e et al., 2010; Fer-

reira and Kleppe, 2011; Suteva et al., 2013; Alassmi

et al., 2012; Fonseca et al., 2007; Khoury et al., 2011;

McAllister et al., 2008; Doup

e et al., 2012; Deepa

et al., 2018; Esposito et al., 2018). In total, these pa-

pers evaluated 25 WAS using 25 targets.

In summary, it shows (I) that there are many dif-

ferent WAS relevant enough to be considered, (II) that

none of the WAS clearly stands out, and (III) that a

combination of WAS leads to better results. From

these insights, we derived the necessity of a system

which improves and orchestrates existing WAS.

Next to the comparisons of WAS, literature shows

various limitations that are similar for many WAS, as

well as work to reduce these limitations. In the fol-

lowing, we present a classiﬁcation of the limitations

identiﬁed and improvements made (see Sections 3.1

and 3.2). It shows that a signiﬁcant part of limitations

concerns the applicability of WAS, but that there has

been only little effort to reduce these limitations. Nev-

ertheless, applicability of WAS is an important factor

in their usefulness and, consequently, for their spread-

ing. Based upon this insight, we focus on reducing the

limitations of WAS regarding their applicability.

3.1 Limitations Identiﬁed

In order to give a better understanding of the limita-

tions of WAS revealed by literature, we collected and

classiﬁed them. We identiﬁed the following clusters:

target, vulnerability classes, methodology and appli-

cability. In fact, the cluster target includes limitations

of the targets used for the evaluation instead of lim-

itations of the WAS itself. This cluster includes the

Helper-in-the-Middle: Supporting Web Application Scanners Targeting Industrial Control Systems

limitations that targets exhibit unintended vulnerabil-

ities (Makino and Klyuev, 2015) and that the exhib-

ited vulnerabilities are outdated (Suteva et al., 2013).

For the sake of completeness we included them in our

classiﬁcation but we will not go into it any further in

the following since they are not concerned with the

WAS itself.

The clusters as well as the classiﬁed limitations

and the corresponding papers are shown in Table 1.

The cluster vulnerability classes includes types of

vulnerabilities WAS have shown to struggle with es-

Table 1: Limitations of WAS as shown by literature.

Vulnerability Classes

Stored XSS (Bau et al., 2010; Doup

e et al., 2010;

Alassmi et al., 2012)

Stored SQL (Bau et al., 2010; Doup

e et al., 2010;

Khoury et al., 2011)

Remote File Inclusion (Makino and Klyuev, 2015;

Doup

e et al., 2010)

Local File Inclusion (Idrissi et al., 2017)

Path Disclosure (Doup

e et al., 2010)

Methodology

Crawling (Esposito et al., 2018; Doup

e et al.,

2010; Idrissi et al., 2017; Ferreira and Kleppe,

2011; Khoury et al., 2011)

Fuzzing (Idrissi et al., 2017)

Periodically Changing Content (Pfrang et al.,

2019)

Attack Code Selection (Ferreira and Kleppe, 2011;

Khoury et al., 2011)

User Login (Pfrang et al., 2019; Doup

e et al.,

2010; Khoury et al., 2011)

Second Order Vulnerabilities (Bau et al., 2010;

Doup

e et al., 2010)

Application Logic (Doup

e et al., 2010)

JavaScript / Flash / HTML5 (Doup

e et al., 2010;

Idrissi et al., 2017; Doup

e et al., 2012)

Categorization of Findings (Khoury et al., 2011)

Applicability

Parameter Understandability (Esposito et al.,

2018)

Reproducibility (Pfrang et al., 2019)

Conduction of Single Tests (Pfrang et al., 2019)

Load Reduction (Pfrang et al., 2019)

Pause and Resume a Scan (Pfrang et al., 2019)

Behavior in Case of an Error (Pfrang et al., 2019)

Different Scanners Necessary (Esposito et al.,

2018; Pfrang et al., 2019; Idrissi et al., 2017)

Runtime (Pfrang et al., 2019; Doup

e et al., 2010;

Suteva et al., 2013)

pecially. In the cluster methodology, limitations of

general approaches of WAS are collected. For exam-

ple, this includes Crawling and Fuzzing capabilities,

handling of Periodically Changing Content, and Ap-

plication Logic limitations. The limitation of Peri-

odically Changing Content refers to web applications

that include regularly changing content such as the

current time. This content can pose a problem for

WAS while they are probing the DUT for injection

vulnerabilities. To ﬁnd out if injections are possible,

WAS ﬁrst try to inject code to a web application. Sec-

ond, they check if the content of the web application

is different to what it had been before the injection.

If the web application contains content that changes

regularly, WAS assume they were able to change the

content and they reason that they were able to inject

code. However, in reality only the regularly changing

content such as the current time has changed. Ap-

plication Logic limitations include the checking and

detection of application speciﬁc vulnerabilities.

The cluster applicability refers to limitations of

WAS concerning the practical handling of WAS. Load

Reduction refers to limitations in specifying the load

to be sent to the DUT. Especially when using ICS, a

crash of the DUT because of a high load is probable.

Behavior in Case of an Error is connected to this. If

the DUT crashes and the WAS does not recognize the

problem, the WAS will send its probes into the empti-

ness. Literature has shown that different scanners are

necessary to generate a good coverage. Another im-

portant point is the Runtime of a WAS. It has a high

impact on how often a test of the DUT is conducted.

Note that the presented limitations are not spe-

ciﬁc to the domain of ICS. However, some of the

limitations become more prominent while using WAS

against ICS.

3.2 Improvements Achieved

Building upon the revealed limitations, researchers

have worked on reducing these limitations. The fol-

lowing describes works in this domain and correlates

them to the limitations described in Section 3.1.

McAllister et al. built a WAS enhanced by tech-

niques to detect more entry points for the scan. This

includes the recording and replaying of use cases,

fuzzing various forms at the same time to increase

testing breadth, and stateful fuzzing. Note that the

stateful fuzzing is only possible if the WAS is able to

control the web application. They ﬁnd that their solu-

tion is able to identify more entry points and bugs than

the other evaluated WAS (McAllister et al., 2008).

Doup

e et al. present a state-aware WAS. Through

sending packets to the DUT and interpreting the re-

SECRYPT 2020 - 17th International Conference on Security and Cryptography

sponses, it builds a model of the internal states of the

web application. Using this model, new entry points

are derived and tested. Additionally, the model is used

to build new payloads for the included fuzzer. Their

evaluation shows that the code coverage as well as

the effectiveness of vulnerability tests are improved

by their system (Doup

e et al., 2012).

Deepa et al. present a WAS that is using the data

and control ﬂow of a web application to build a model

of its behavior. With this model, logic vulnerabilities

like parameter manipulation, access control and work

ﬂow bypass vulnerabilities are targeted. The authors

show that their system results in a high precision and

a high true positive rate (Deepa et al., 2018).

In contrast to the solutions above, Esposito et al.

present a proxy to improve the capabilities of WAS

instead of building a new WAS. The proxy is used to

improve the crawling capabilities as well as the au-

thentication of the WAS against the target. Crawling

is improved by injecting known URLs into places the

WAS will look into for crawling information. Addi-

tionally, the proxy is able to authenticate the origi-

nally unauthenticated requests sent by the WAS. The

authors show in their evaluation that the presented

proxy increases the number of detected vulnerabilities

without having a signiﬁcant impact on the reported

false positives (Esposito et al., 2018).

In summary, literature has improved WAS in their

limitations of Crawling (McAllister et al., 2008; Es-

posito et al., 2018; Doup

e et al., 2012), Fuzzing

(McAllister et al., 2008; Doup

e et al., 2012), Applica-

tion Logic (Deepa et al., 2018), and User Login (Es-

posito et al., 2018; McAllister et al., 2008). All these

improvements focus on the methodology of the WAS

and not on their applicability. As we have learned

from our practical work with WAS, the applicability

of WAS is an important factor in their usefulness and

spreading. That is why there should be improvements

in this cluster as well.

4 OUR APPROACH

Our approach is to support and improve arbitrary

WAS through a transparent helper-in-the-middle. The

following presents the concept of HelpMeICS as well

as the extensions we designed and implemented. The

goal of HelpMeICS is to improve the following ap-

plicability limitations of WAS: Crawling, Periodically

Changing Content, User Login, Reproducibility, Con-

duction of Single Tests, Load Reduction, Pause and

Resume a Scan, Behavior in Case of an Error, and

Different Scanners Necessary.

WAS

Proxy

DuT

ISuTest

alert

interrupt /

resume

monitor

Figure 2: Overview over HelpMeICS. At a given time, one

WAS running in a container can communicate with the DUT

using the proxy. When ISuTest receives an alert by the

watchdog of the proxy, it interrupts the currently running

WAS and monitors the DUT. All components except the

DUT run on one computer.

4.1 Basic Idea

The basic idea of HelpMeICS is to combine the ad-

vantages of a proxy, ISuTest, and containers to sup-

port WAS during their testing. Our concept for this

combination is presented in Figure 2. The three com-

ponents proxy, WAS, and ISuTest run on one com-

puter which is called test device (TD).

The proxy is located in between the WAS and the

DUT. With this, it is able to read, interpret and change

the packets sent between the WAS and the DUT. The

extensions of the proxy are implemented as add-ons

which are presented in detail later in this section.

The WAS run in containers which results in the

following two main advantages: First, it is now possi-

ble to pause and resume the WAS. Second, if the con-

tainer is not updated, scans can be run in a more repro-

ducible way since the WAS can be reset to a known

state. The third component of HelpMeICS is ISuTest.

We use ISuTest to orchestrate the WAS and to

monitor the DUT. In order to orchestrate the WAS, we

added the possibility to integrate external tools into

ISuTest. This is not restricted to WAS. In addition,

we use the monitoring of ISuTest. The monitoring

is supported by the so-called watchdog add-on of the

proxy which alerts ISuTest if the DUT gives the im-

pression of no longer reacting properly to HTTP re-

quests. When the watchdog of the proxy detects a

possible error of the DUT, it alerts ISuTest. ISuTest

then performs a monitoring cycle and checks if the

DUT indeed has an error. Refer to the description of

the watchdog later in this section for more informa-

tion on the monitoring.

Our solution can be used by proxy-aware WAS

as well as by WAS that are not proxy-aware. For

those WAS that are not proxy-aware, we implemented

a transparent proxy mode. The challenge for the

transparent proxy mode is to differentiate between the

packets to be routed to the proxy and the ones that

should not be routed to the proxy. This is made possi-

Helper-in-the-Middle: Supporting Web Application Scanners Targeting Industrial Control Systems

ble by HelpMeICS because of the containers the WAS

run in. We added a virtual network bridge to the TD

which redirects all trafﬁc from and to the containers

to the proxy. With this, HelpMeICS can be used even

with WAS that are not proxy-aware. Note that Help-

MeICS can also be used if it is not possible to run

the WAS in a container. However, this reduces the

impact of HelpMeICS (see Section 5) and the trans-

parent proxy mode is not possible.

Esposito et al. present a proxy-based solution to

improve WAS as well (Esposito et al., 2018). The

authors show that their approach is able to improve

Crawling and User Login. HelpMeICS goes beyond

this approach and addresses more limitations of WAS.

We present a full integration of the WAS into a secu-

rity testing system without the need to adapt the WAS.

This includes ISuTest, running the WAS in a container

and additional add-ons for the proxy. In addition, we

publish the add-ons to make them available for further

research. Note that the proxy can also be used stand-

alone. As a result, many of our improvements can be

used just by installing and conﬁguring the proxy.

4.2 Extensions

We built the containers for the WAS using LXD

. Our

decision was mainly based on the fact that LXD pro-

vides an easy conﬁguration and manipulation of the

forwarding for virtual network bridges. This is neces-

sary for the transparent proxy mode.

As a basis for the proxy included in HelpMeICS,

mitmproxy

is used. We chose this proxy since it is

easily extensible and its code is open source under the

MIT license. In addition, it supports HTTP as well as

HTTPS. With this, it builds a good base for this work.

In the following, we present the additional features

for mitmproxy we designed and implemented.

Watchdog. The watchdog add-on addresses the

limitation of crashing DUTs during a test (Behavior

in Case of an Error). For this, it monitors whether

the DUT shows errors in the communication with the

WAS using the error method provided by mitmproxy.

This method is called if an error occurs during the

transmission or reception of an HTTP packet. Serv-

ing as a connection between mitmproxy and ISuTest,

the watchdog alerts ISuTest and such informs about

the error. In Figure 2 this process is presented through

dashed arrows. When receiving an alert, ISuTest in-

terrupts the WAS. This interruption is made possible

because of the container the WAS runs in. The next

step for ISuTest is to conduct a monitoring cycle. A

https://linuxcontainers.org/

https://mitmproxy.org/

monitoring cycle consists of a check if the DUT re-

sponds to requests of different protocols. If the check

shows that the DUT is indeed not responding, ISuTest

restarts the DUT and checks it again. Then, the WAS

is resumed and the test is continued. Note that this

process is completely transparent for the WAS.

Mapping. The mapping add-on aims at reducing

the false positives resulting from changing content

(Periodically Changing Content). It provides the pos-

sibility to replace or delete content of a web page, for

example regularly changing content such as the cur-

rent time. Content referred to by a CSS selector is

replaced by a given HTML code.

User Login. We present two different approaches

to address the limitation concerning user login or au-

thentication (User Login). The ﬁrst approach imple-

ments different authentication schemes and executes

the authentication if necessary. With this, the re-

quests of the WAS are being authenticated transpar-

ently. One limitation of this approach is that it does

not have access to a browser instance. With this, it

is not possible to fully retrieve and execute the web

page. The second approach addresses this limitation

of the ﬁrst approach by using selenium

. Selenium in-

cludes a browser instance with which we can simulate

a login by a user. Afterwards, the login information

such as cookies or session IDs need to be transferred

to the requests of the WAS. Both approaches share

the need to detect if a request is authenticated or not.

This check is performed during a request of the WAS

as well as during a response of the DUT.

URL Injection. In order to improve the Crawling

capabilities of the WAS, we present an URL injec-

tion add-on. With this add-on, URLs are injected into

the responses sent by the DUT. As has been shown

by Esposito et al., this improves the crawling perfor-

mance of the WAS since the WAS are able to ﬁnd

more links and pages. We implemented the four dif-

ferent approaches suggested by the authors: inject-

ing the URLs using (I) robots.txt, (II) sitemap.xml,

(III) a landing page, and (IV) an index page (Esposito

et al., 2018). The difference between their approach

and our approach is the extraction of URLs used for

the injection (URL index). Esposito et al. created the

URL index for their evaluation using endpoint extrac-

tion of URLs. Since our work is placed in an au-

tomated black-box setting, this is not realistic. We

performed the generation of the URL index automati-

cally using HelpMeICS. We ﬁrst automatically run all

https://selenium.dev/

SECRYPT 2020 - 17th International Conference on Security and Cryptography

WAS against a target and recorded all requests and re-

sponses made. Afterwards, we extracted all requests

to which the DUT responded with a non-error code

which then built the URL index. For an evaluation,

please refer to Sections 5.2 and 5.3.

Logging. To be able to narrow down a vulnerabil-

ity, it is necessary to know which requests and re-

sponses have been sent between the WAS and the

DUT. The logging add-on addresses this by logging

each response and request seen by the proxy.

5 EVALUATION

To evaluate HelpMeICS, we conducted a qualita-

tive evaluation as well as a quantitative evaluation.

This section describes our evaluation setting (Sec-

tion 5.1), presents the results of the quantitative evalu-

ation (Section 5.2), and shows the results of the qual-

itative evaluation (Section 5.3). Our qualitative eval-

uation shows that HelpMeICS reduces the following

limitations of WAS: Crawling, Periodically Chang-

ing Content, User Login, Reproducibility, Pause and

Resume a Scan, Conduction of Single Tests, Load Re-

duction, Behavior in Case of an Error, and Differ-

ent Scanners Necessary. The quantitative evaluation

shows an increase of true positive reports as well as a

higher URL coverage. For one of the used DUTs, a

security test was only possible using HelpMeICS be-

cause it crashes irrecoverably during web application

scans without HelpMeICS.

5.1 Evaluation Setting

For our evaluation we selected six WAS to be run

against ﬁve real ICS. The aim of the evaluation is to

evaluate HelpMeICS and not to evaluate the ICS used.

That is why we decided not to reveal the manufactur-

ers and versions of the ICS. Instead, we describe the

device class as well as the properties of the ICS which

are relevant for the evaluation. In the following, we

Table 2: WAS used for the evaluation.

Scanner Version

Arachni 1.5.1

Nikto 2.1

Skipﬁsh 2.10

Subgraph Vega 1.0

Wapiti commit

0bf7g7

ZAP 2.8.0

[1] https://git.code.sf.net/p/wapiti/git

describe the ICS, WAS, and conﬁgurations of Help-

MeICS used for the evaluation.

Web Application Scanners. In order to evaluate

the impact of HelpMeICS, we used HelpMeICS with

six WAS against ﬁve ICS. In Table 2 the WAS we

used are shown. We selected six open source WAS

which have already been used for many evaluations

by literature. To be able to integrate the GUI-based

WAS Vega, we created a customized version which

allows controlling the conducted tests via a python

API. We made this customized version of Vega pub-

licly available

. Arachni differs from the other WAS

since it includes a browser engine. With this, it is able

to investigate web applications which include tech-

nologies like JavaScript, HTML5, DOM manipula-

tion and AJAX. Nikto also shows a special behavior.

For its tests, Nikto uses a ﬁxed database of URLs and

checks. With this, Nikto is the only one of the consid-

ered WAS which conducts highly reproducible tests.

Devices Under Test. We selected ﬁve ICS with dif-

ferent functions and properties as realistic targets.

The ﬁrst DUT, DUT1, is a PROFINET bus cou-

pler. Bus couplers translate communication between

different bus systems and architectures. For exam-

ple, bus couplers can serve as a provider of addi-

tional input and output interfaces for a PLC. DUT1

provides a web application that uses HTTP-Basic-

Authentication. One characteristic of this web appli-

cation is that it includes a vulnerability which can be

used to crash DUT1. The DUT needs to be restarted

by switching the power off and on to be functional

again. This poses a problem for WAS, since each

WAS detecting this vulnerability will crash DUT1.

The WAS are not able to detect and recover from this

issue since they are not able to restart DUT1.

The second ICS, DUT2, is a gateway for OPC

UA, a machine-to-machine communication protocol

for industrial automation. DUT2 connects different

communication protocols to OPC UA in order to com-

bine the data from different sources. Its web applica-

tion uses a form based user login. The identiﬁers of

the input ﬁelds used for login are changed on a regu-

lar basis. WAS which are able to perform form based

authentication are not able to login to the web applica-

tion without help since they assume ﬁxed identiﬁers.

DUT3 is a ﬁrewall which connects two networks

and restricts the trafﬁc in between. In contrast to the

other DUTs, the web application of DUT3 only al-

lows HTTPS. To login to the web application, the user

needs to provide only a password but no user name.

https://github.com/subgraph/Vega/pull/184

Helper-in-the-Middle: Supporting Web Application Scanners Targeting Industrial Control Systems

Since the WAS which are able to perform form based

authentication expect a password ﬁeld as well as a

ﬁeld for the user name, they are not able to login.

Similar to DUT1, DUT4 is a PROFINET bus cou-

pler. The web application of DUT4 shows the special

feature that it ﬁrst delivers a JavaScript program to

a user. Afterwards, this program loads the actual user

interface. This makes it more complicated for a proxy

to interpret and manipulate the packets.

DUT5 is a thermometer which distributes its mea-

surements over different communication protocols

such as MQTT, SNMP, FTP, and Mail. In addition,

the measurements are presented on a web application

as a dynamically updated graph as well as a XML-

Feed. This data is of that kind of Periodically Chang-

ing Content that can mislead WAS (see Section 3.1).

Conﬁgurations. In order to be able to compare the

performance of the add-ons (see Section 4), we de-

ﬁned different conﬁgurations of our system for the

evaluation. An overview of these conﬁgurations is

given in Table 3. The conﬁguration bare names

the execution of the WAS without HelpMeICS. The

conﬁguration using our system without the proxy is

called virtualised. That means that the WAS are run

in a container and are conﬁgured by ISuTest. All other

conﬁgurations refer to the usage of all components of

the system with different add-ons used by the proxy.

5.2 Qualitative Evaluation

HelpMeICS reduces the limitations of WAS by three

means: proxy add-ons, containers, and ISuTest. In

the following, we present our solutions for improved

limitations, including potential restrictions.

Table 3: Conﬁgurations used for the evaluation. bare corre-

sponds to an execution without HelpMeICS, virtualised to

WAS running in a container, and all other conﬁgurations to

an execution using a different subset of proxy add-ons.

conﬁguration

container

proxy

logging

watchdog

user login

URL injection

bare - - - - - -

virtualised X - - - - -

proxy X X X - - -

proxy W X X X X - -

proxy WL X X X X X -

proxy WI X X X X - X

proxy WLI X X X X X X

Crawling. The crawling capabilities by a WAS are

improved by the URL injection add-on (see also Sec-

tion 5.3). Recall that the used URL index is crafted

automatically based on the requests from all WAS.

In a special case, this automatic approach increases

the number of indexed URLs unnecessarily. Given a

WAS that randomly changes a parameter in the URL

and a web application that does not care about this

parameter but delivers always a positive response, it

follows that each of these URLs are indexed. An

automatic reduction of URLs is difﬁcult since other

web applications might react to changing parameters.

Nevertheless, the injection of crawled URLs increases

the coverage tremendously (see Section 5.3).

Periodically Changing Content. The mapping

add-on allows for replacing or removing periodically

changing contents that might mislead WAS. A user

needs to specify the content to be replaced using a

CSS selector. The positive impact of this add-on

has been conﬁrmed by the evaluation of ZAP against

DUT5. As has already been stated, the web appli-

cation of DUT5 provides a XML-feed of the mea-

sured temperatures. Since this feed is updated once a

minute, ZAP is convinced that its tests for SQL injec-

tion have been successful. Using the mapping add-on,

the feed can be set to a ﬁxed value. With this, ZAP no

longer reports the false positive SQL injection.

User Login. On some DUTs, logged-in users can

access more websites than unauthenticated users.

Even though most WAS provide different authenti-

cation mechanisms, they still struggle to authenti-

cate against some of the ICS as has been described

in Section 5.1. In order to support the WAS during

their scan, login add-ons have been implemented and

tested. Using the selenium add-on, the WAS are now

able to scan web applications only asking for a pass-

word and no user name (DUT5) as well as web appli-

cations with changing session IDs (DUT3). The user

needs to record the login process only once using a

selenium recorder and is able to reuse it for all WAS

afterwards. Nevertheless, the add-on fails on DUTs

whose websites contain logic to answer a speciﬁc call

regularly in the background (DUT2 and DUT4). In

order to overcome this issue, one would have to im-

plement a DUT-speciﬁc solution.

Reproducibility. The reproducibility of tests is

reached by running the WAS in containers and taking

snapshots on a regular basis. However, some WAS

generate their random data used for fuzzing on the

ﬂy. In this case, two test runs from the same snap-

SECRYPT 2020 - 17th International Conference on Security and Cryptography

shot can produce two different testing processes. This

issue can only be solved by the speciﬁc WAS.

Pause and Resume a Scan. Especially when using

WAS against ICS, pausing a scan might be necessary,

for example to restart the DUT. The use of contain-

ers with snapshots allows for stopping the scan and

resuming the scan afterwards.

Conduction of Single Tests. Using only a subset of

security tests is partly supported by the use of con-

tainers. With the granularity of snapshots, only some

tests can be conducted. This improves WAS which do

not support the feature to run single tests.

Load Reduction. High loads of network trafﬁc can

overstrain some DUTs. The container solution allows

for stopping and resuming a security test by stopping

and resuming the container. For example, this helps in

the case of limited TCP connections. If the proxy de-

tects too many concurrent TCP requests, it can pause

the WAS. Due to this pause, the DUT is able to handle

the remaining TCP requests and is able to free enough

sources to handle new requests by the WAS.

Behavior in Case of an Error. In case of a crash of

the DUT which requires a restart of the device, WAS

get stuck. This means that they discovered one vul-

nerability but cannot test for more. HelpMeICS em-

ploys the combination of ISuTest and the containers

which improves this situation enormously. At ﬁrst,

the WAS gets stopped for the regular monitoring. If

ISuTest detects that the DUT does not respond any-

more, it executes a restart by switching the power off

and on. Then, the container of the WAS can be re-

sumed and thus the test can be continued. In the con-

crete example of DUT1, testing with HelpMeICS has

two advantages: The ﬁrst one is that DUT1 will be

restarted after the crash and the test can be continued

until it ﬁnishes. With this, only possibly a few tests in

the time period between the crash and the monitoring

are lost. The second advantage is that HelpMeICS

logs the information about the packages sent during

the test as well as generating a report about the crash.

With this information, a security tester is able to com-

prehend the vulnerability reported.

Different Scanners Necessary. The need to con-

duct security tests with many different WAS is ad-

dressed by ISuTest. Once integrated in HelpMeICS,

many scans with different WAS can be scheduled one

after another.

DUT1 DUT2 DUT3

200

400

600

800

1,000

143

133

143

177

928

743

Devices under test

Number of true positive reports

bare

proxy W proxy WLI

Figure 3: Number of true positive reports summarized over

the WAS for the different conﬁgurations, excluding false

positives but including duplicates. Using more add-ons of

the proxy leads to more true positive reports.

DUT1 DUT2 DUT3

20%

40%

60%

80%

100%

0.7

14.7

5.4

1.4

3.8

27.2

1.6

63.5

Devices under test

False positive rate of reports

bare

proxy W proxy WLI

Figure 4: False positive rate of reports summarized over the

WAS. Depending on the DUT, using more add-ons of the

proxy decreases or increased the rate.

5.3 Quantitative Evaluation

The quantitative evaluation includes an analysis of the

true positive reports given by the WAS, the URL cov-

erage, the performance of the watchdog, as well as the

impact on the runtime of the tests. For the evaluation,

we executed each of the presented WAS against each

ICS using each of the conﬁgurations (see Section 5.1).

Reported Vulnerabilities. The ﬁrst evaluation

analyses the number of true positive reports given

by the WAS. Note that this number excludes false

positives but includes duplicates. Since our work is

Helper-in-the-Middle: Supporting Web Application Scanners Targeting Industrial Control Systems

DUT1 DUT2 DUT3

20%

40%

60%

80%

100%

100100

100

Devices under test

URL coverage

bare

proxy W proxy WLI

Figure 5: Percentage of existing URLs on a DUT that have

been visited by at least one WAS. Using more add-ons of

the proxy leads to a higher percentage of vistited URLs.

situated in a black-box setting, it is not possible to

identify the number of concrete vulnerabilities the re-

ports correspond to. This would be necessary in or-

der to eliminate duplicates. In Figure 3, the num-

ber of true positive reports given by all WAS together

is depicted for each DUT. The conﬁgurations shown

are bare (execution of the WAS without HelpMeICS),

proxy W (usage of HelpMeICS including the logging

and watchdog add-on), and proxy WLI (additional us-

age of the login and the URL injection add-on). For

DUT2 and DUT3, the number of reports rises steadily

with the number of add-ons. For DUT1, the number

of reports stays the same for the conﬁgurations bare

and proxy W but rises as well for proxy WLI. Even

tough the number of true positive reports does not di-

rectly correspond to the number of vulnerabilities, it

gives an evidence for the effectiveness of HelpMeICS.

Complementary, the false positive rate of the re-

ports is analysed. As shown by Figure 4, the false pos-

itive rate of the given reports is decreased by the us-

age of HelpMeICS in the conﬁguration proxy W for

DUT2 and DUT3. In contrast, using the conﬁguration

proxy WLI, the false positive rate increases for DUT1

and DUT3. Regarding DUT2, the false positive rate

decreases the more add-ons are used.

The analysis of the number of reports shows that

more true positive reports are given by the WAS the

more add-ons of the proxy are used. In some cases,

the trade-off for more true positives is an increased

false positive rate. Our ﬁndings coincide with the re-

sults of Esposito et al. (Esposito et al., 2018). The

authors state as well that adding URL injection and

user login leads to an increased number of reports.

URL Coverage. One indicator of an improved se-

curity test is the number of called URLs. If a WAS

does not call a URL, it is surely not able to ﬁnd vul-

nerabilities on this URL. It follows that visiting more

URLs generally means a higher probability to ﬁnd

more vulnerabilities. In the following, the percentage

of URLs of a DUT visited by at least one WAS will be

analysed. Since we are conducting black box security

tests, we are not able to monitor the internal coverage

of the web application of the DUT. This is why we

compare the URLs existing on a DUT with the URLs

visited by the WAS. We deﬁne the URLs existing on a

DUT as the URL index generated by the logging add-

on of the proxy (see Section 4). For the conﬁguration

proxy WLI it follows that we check which percentage

of injected URLs are actually tested.

The results of this evaluation are presented in Fig-

ure 5. Note that for DUT3 it shows no value for

the bare conﬁguration since DUT3 uses HTTPS. This

results in encrypted trafﬁc that can not be analysed

without using the proxy. Since our proxy supports

HTTPS, we are able to analyse the packets sent when

using the proxy. For DUT1 and DUT2, the percentage

of URLs visited increases with the number of add-

ons used. For DUT3, the percentage stays constant

at 100%. The results of DUT2 for proxy WLI show

the challenge of automatically creating URL indices

using non-reproducible WAS (see Section 4.2). The

URL index of DUT2 contains some URLs the WAS

visited during the generation of the URL index but

not during the evaluation. Nevertheless, the analysis

of the percentage of URLs visited by the WAS shows

that it is increased with the number of add-ons used.

Runtime. Since HelpMeICS adds functionality and

computations to the WAS, its impact on the runtime

needs to be analysed. For this analysis we chose Nikto

as WAS and DUT2 as target. As has already been

stated in Section 5.1, Nikto creates its tests from a

static database of URLs and checks. With this, the

runtime of Nikto is relatively stable. This allows us

to analyse the impact of HelpMeICS. To make the re-

sults even more reliable, we executed Nikto ten times

with each conﬁguration of HelpMeICS. The medium

value of these ten runs as well as the minimum and

maximum runtime is shown in Figure 6.

A ﬁrst insight from this analysis is that the virtual-

isation has no great impact on the runtime of Nikto. A

second insight is that the proxy increases the runtime

of Nikto by the factor of 9. A third insight is that the

addition of add-ons has again no great impact.

However, for some cases using other WAS and

DUTs, HelpMeICS was able to reduce the runtime.

For example, this has been the case for Arachni

SECRYPT 2020 - 17th International Conference on Security and Cryptography

bare

virtualised

proxy

proxy W

proxy WI

proxy WL

proxy WLI

500

1,000

1,500

2,000

2,500

Conﬁgurations of HelpMeICS

Runtime in seconds

Figure 6: Runtime of Nikto against DUT2 using different

conﬁgurations of HelpMeICS. Presented are medium values

of ten runs as well as minimum and maximum. The proxy

itself has a high impact on the runtime, the additional add-

ons of the proxy do have a smaller impact.

against DUT4. Arachni opens many TCP connections

and such reaches the maximum number of TCP con-

nections accepted by DUT4 after roughly 31 seconds.

During the remainder of the test, Arachni tries to es-

tablish new connections to DUT4 unavailingly until

the maximum time of the test is reached. If HelpMe-

ICS is used, the watchdog detects this problem and

alerts ISuTest. ISuTest then restarts DUT4. As a re-

sult, DUT4 is able to accept new TCP connections

again and Arachni can ﬁnish its tests successfully. In

this case, the runtime has been reduced by a factor

of 68 comparing the bare conﬁguration to proxy W.

In summary, the analysis of the runtime shows an in-

crease of runtime in most cases but also a decrease

of runtime in some cases. The proxy itself has the

most impact on the runtime, which means the runtime

might be improved by improving the used proxy.

Watchdog Performance. Depending on the behav-

ior of the DUT, the watchdog can have a high impact

on the runtime of a test. If the watchdog produces

many false positive alerts, the runtime increases un-

necessarily since ISuTest will conduct a monitoring

cycle after every alert. In the case of a true positive

alert from the watchdog, the runtime is increased even

more since the DUT is restarted. Note that this in-

crease of runtime is necessary to improve the quality

of the test, but the increase of runtime caused by false

positives is unnecessary. Because of this, the false

positive rate of the watchdog is analysed.

Our analysis shows high variance in the false pos-

itive rate of the watchdog depending on the WAS and

the DUT. For example, the combination of Nikto and

DUT1 shows a false positive rate of 8%. In contrast,

the combination of Skipﬁsh and DUT4 results in a

false positive rate of 96%. Even though the watch-

dog shows a good performance in some cases, it still

might be improved further. Note that we are currently

using the error function given by mitmproxy as trigger

for alerts. One cause of false positive alerts are mal-

formed HTTP packets sent by the WAS. These could

be excluded in a post processing step of the error trig-

ger given by mitmproxy.

In summary, the watchdog possibly increases the

runtime unnecessarily but helps to improve the tests

by detecting crashes of the DUT. For DUT1, a full

test without the watchdog is not even possible since

DUT1 crashes before the tests might be completed.

6 CONCLUSIONS

We presented HelpMeICS, a Helper-in-the-Middle

for ICS, which improves different limitations of ex-

isting WAS. HelpMeICS consists of a proxy, which

is placed between the WAS and the DUT, containers

the WAS run in, and ISuTest as an industrial security

testing framework that orchestrates all components.

Particularly, the applicability and the methodol-

ogy have been enhanced notably by HelpMeICS. Ad-

vanced crawling features, authentication and the pos-

sibility to test with many different WAS improve the

methodology. The usage of ISuTest and containers

enhance the applicability of WAS. It enhances the re-

producibility of tests and the scanner behavior in case

of DUT crashes. As signiﬁcant result, more true pos-

itive reports have been generated by the WAS and

even one severe vulnerability which crashed one DUT

completely has been found.

The evaluation showed that not every limitation

of the WAS could be solved by HelpMeICS. Script-

based authentication systems turned out to be very

DUT-speciﬁc. With this, it was not possible to create

an universal solution for every web application. The

reproducibility of security tests posed another prob-

lem after the introduction of snapshots: Some WAS

produced different test sequences even when being

started from the same snapshot. This problem cannot

be solved by HelpMeICS, it needs to be solved by the

particular WAS. Nevertheless, for most of the WAS

the snapshot feature proved to be very valuable. One

last limitation consists of a trade-off: The additional

features and improvements of the WAS increase the

runtime of the tests in most cases.

Concluding, HelpMeICS allows for conducting

automated web security tests using different existing

WAS. It improves the performance of WAS in con-

Helper-in-the-Middle: Supporting Web Application Scanners Targeting Industrial Control Systems

trast to their single use. Discovered vulnerabilities

help manufacturers and integrators of ICS to reduce

the attack vectors of their web applications and im-

proves their security in general.

Future work comprises the improvement of URL

indices in order to reduce false positives. The au-

thentication add-on for selenium needs some work to

extract session data from the used browser engine to

pass them to the WAS. More WAS can be evaluated

and integrated in HelpMeICS to improve its perfor-

mance. Finally, more DUTs can be tested to detect

and analyze even more vulnerabilities.

ACKNOWLEDGEMENTS

This work was supported by the German Federal Min-

istry of Education and Research within the frame-

work of the project KASTEL SKI in the Competence

Center for Applied Security Technology (KASTEL)

and by the Ministry of Economy, Labor and Hous-

ing, Baden-W

urttemberg, within the research project

CyberProtect.

REFERENCES

Alassmi, S., Zavarsky, P., Lindskog, D., Ruhl, R., Alasiri,

A., and Alzaidi, M. (2012). An analysis of the ef-

fectiveness of black-box web application scanners in

detection of stored xssi vulnerabilities. International

Journal of Information Technology and Computer Sci-

ence, 4(1).

Bau, J., Bursztein, E., Gupta, D., and Mitchell, J. (2010).

State of the art: Automated black-box web applica-

tion vulnerability testing. In 2010 IEEE Symposium

on Security and Privacy, pages 332–345. IEEE.

BSI (2019). Industrial control system security. Technical

report, German Federal Ofﬁce for Information Secu-

rity, Publications on Cyber-Security.

Deepa, G., Thilagam, P. S., Praseed, A., and Pais, A. R.

(2018). Detlogic: A black-box approach for detecting

logic vulnerabilities in web applications. Journal of

Network and Computer Applications, 109:89–109.

Doup

e, A., Cavedon, L., Kruegel, C., and Vigna, G. (2012).

Enemy of the state: A state-aware black-box web vul-

nerability scanner. In Presented as part of the 21st

USENIX Security Symposium (USENIX Security 12),

pages 523–538.

Doup

e, A., Cova, M., and Vigna, G. (2010). Why johnny

can’t pentest: An analysis of black-box web vulner-

ability scanners. In International Conference on De-

tection of Intrusions and Malware, and Vulnerability

Assessment, pages 111–131. Springer.

Esposito, D., Rennhard, M., Ruf, L., and Wagner, A.

(2018). Exploiting the potential of web application

vulnerability scanning. In ICIMP 2018, Spain, July

22-26, 2018, pages 22–29. IARIA.

Felderer, M., B

uchler, M., Johns, M., Brucker, A. D., Breu,

R., and Pretschner, A. (2016). Security testing: A sur-

vey. In Advances in Computers, volume 101, pages

1–51. Elsevier.

Ferreira, A. M. and Kleppe, H. (2011). Effectiveness of

automated application penetration testing tools.

Fonseca, J., Vieira, M., and Madeira, H. (2007). Testing and

comparing web vulnerability scanning tools for sql in-

jection and xss attacks. In 13th Paciﬁc Rim interna-

tional symposium on dependable computing (PRDC

2007), pages 365–372. IEEE.

Galloway, B. and Hancke, G. P. (2012). Introduction to

industrial control networks. IEEE Communications

surveys & tutorials, 15(2):860–880.

Idrissi, S., Berbiche, N., Guerouate, F., and Shibi, M.

(2017). Performance evaluation of web application se-

curity scanners for prevention and protection against

vulnerabilities. International Journal of Applied En-

gineering Research, 12(21):11068–11076.

IEC62443 (2019). IEC-62443: Security for industrial au-

tomation and control systems. Standard, International

Electrotechnical Commission.

Khoury, N., Zavarsky, P., Lindskog, D., and Ruhl, R.

(2011). An analysis of black-box web application se-

curity scanners against stored sql injection. In 2011

IEEE Third International Conference on Privacy, Se-

curity, Risk and Trust and 2011 IEEE Third Interna-

tional Conference on Social Computing, pages 1095–

1101. IEEE.

Langner, R. (2011). Stuxnet: Dissecting a cyberwarfare

weapon. IEEE Security & Privacy, 9(3):49–51.

Makino, Y. and Klyuev, V. (2015). Evaluation of web vul-

nerability scanners. In 2015 IEEE 8th International

Conference on Intelligent Data Acquisition and Ad-

vanced Computing Systems: Technology and Applica-

tions (IDAACS), volume 1, pages 399–402. IEEE.

McAllister, S., Kirda, E., and Kruegel, C. (2008). Lever-

aging user interactions for in-depth testing of web

applications. In International Workshop on Recent

Advances in Intrusion Detection, pages 191–210.

Springer.

Pfrang, S., Borcherding, A., Meier, D., and Beyerer, J.

(2019). Automated security testing for web applica-

tions on industrial automation and control systems. at-

Automatisierungstechnik, 67(5):383–401.

Pfrang, S., Meier, D., and Kautz, V. (2017). Towards a mod-

ular security testing framework for industrial automa-

tion and control systems: Isutest. 2017 22nd IEEE

International Conference on Emerging Technologies

and Factory Automation (ETFA).

Suteva, N., Zlatkovski, D., and Mileva, A. (2013). Evalu-

ation and testing of several free/open source web vul-

nerability scanners.

Vega, E. A. A., Orozco, A. L. S., and Villalba, L. J. G.

(2017). Benchmarking of pentesting tools. Inter-

national Journal of Computer and Information Engi-

neering, 11(5):602–605.

SECRYPT 2020 - 17th International Conference on Security and Cryptography
