A Layered Quality Framework for Machine Learning-driven Data and

Information Models

Shelernaz Azimi and Claus Pahl

Free University of Bozen - Bolzano, Bolzano, Italy

Keywords:

Data Quality, Information Value, Machine Learning, Big Data, Data Quality Improvement, Data Analysis.

Abstract:

Data quality is an important factor that determines the value of information in organisations. Data, when given

meaning, results in information. This then creates ﬁnancial value that can be monetised or provides value by

supporting strategic and operational decision processes in organisations. In recent times, data is not directly

accessed by the consumers, but is provided ’as-a-service’. Moreover, machine-learning techniques are now

widely applied to data, helping to convert raw, monitored source data into valuable information. In this con-

text, we introduce a framework that presents a range of quality factors for data and resulting machine-learning

generated information models. Our speciﬁc aim is to link the quality of these machine-learned information

models to the quality of the underlying source data. This takes into account the different types of machine

learning information models as well as the value types that these model provide. We will look at this speciﬁ-

cally in the context of numeric data, where we use an IoT application that exhibits a range of typical machine

learning functions to validate our framework.

1 INTRODUCTION

Large volumes of continuously produced data are

now omnipresent in many contexts. The Internet-of-

Things (IoT) is a typical example where high volumes

of a variety of data types are produced with high ve-

locity (speed), often subject to veracity (uncertainty)

concerns. We also refer to this type of data as big data

(Saha and Srivastava, 2014).

In order to make sense out of this raw data orig-

inating from various sources, data needs to be struc-

tured and organised to provide information ready for

consumption. More and more, Machine Learning

(ML) is used to aggregate and derive non-obvious in-

formation from the data, thus enhancing the value of

that information. Enhanced information can help to

monetise data in the form of products or services pro-

vided. It can also aid an organisation in order to im-

prove operational and strategic decision making. Ma-

chine learning makes this possible in a situation where

manual processing and creation of functions on data

is not possible due to time and space needs.

The problem in this context is, however, the im-

pact of volume, variety, velocity and veracity of data

on the quality and value of the information that is

derived through a machine learning approach. Data

quality plays a central role in creating value out of

data (Heine et al., 2019). In order to conceptualise the

problem, we need to extend a data quality framework

to an ML function level (Azimi and Pahl, 2020b).

Thus, our contribution is a layered data architec-

ture for data and ML function layers with associated

quality aspects, consisting of

• a data quality model for raw data collected from

different sources,

• a categorisation of machine learning functions,

• a quality model for machine-learning generated

information models.

The problem of assessing quality of machine

learning-generated information has been recognised

(Ehrlinger et al., 2019), but a systematic categorisa-

tion is lacking. The novelty of the approach lies in,

ﬁrstly, the layering of data and ML model quality

based on dedicated ML function types and, secondly,

when data quality might not be directly observable,

we provide a new way of inferring quality.

This would enable to understand better the impact

of data quality on enhanced information models for

direct user access. Ultimately, this would also allow

us to infer data quality deﬁciencies by only consider-

ing the machine-learned information models, thus al-

lowing to remedy problems at data level and increase

the overall value.

Azimi, S. and Pahl, C.

A Layered Quality Framework for Machine Learning-driven Data and Information Models.

DOI: 10.5220/0009472305790587

In Proceedings of the 22nd International Conference on Enterprise Information Systems (ICEIS 2020) - Volume 1, pages 579-587

ISBN: 978-989-758-423-7

579

We focus here on numeric data that would for exam-

ple be collected in technical or economic applications,

neglecting text and image data here. We use IoT here

as the application context in order to make qualities

and impacting factors more concrete though an appli-

cation context impacted by the big data factors vol-

ume, variety, velocity and veracity.

The remainder of the paper is structured as fol-

lows. In Section 2, we introduce essential background

technologies. In Section 3, we review related work.

Our quality framework is presented in Section 4. In

Section 5, we motivate and validate the framework by

referring to some use cases. Section 6 summarises the

evaluation results, before we conclude in Section 7.

2 BACKGROUND

We look at the quality of information that is derived

from data through a machine learning approach. Data

quality and machine learning shall be introduced.

Furthermore, we explain the role of IoT as a repre-

sentative domain.

2.1 Data and Information Quality

Data represents a valuable asset in any enterprise con-

text as a source for extracting information. Thus,

quality is a critical requirement for any data commu-

nication and consumption, as be easily be motivated

in IoT data services and their users. In IoT, things

such as sensors produce volumes of data that are the

basis in order to provide services for consumers. If

data are inaccurate, extracted information and actions

based on this will probably be unsound and erroneous.

Sensors and other data collectors generally monitor

a variable of interest (e.g., temperature, trafﬁc, re-

source consumption, etc.) in the physical world (Az-

imi and Pahl, 2020a). The environments in which

the collection of data takes place is often changeable

and volatile in nature. Consequently, data is often

uncertain, erroneous, noisy, distributed and volumi-

nous. Some characteristics can depend on the context

and the monitored phenomena, such as smoothness of

variations, continuity and periodicity of production,

correlation with other factors and statefulness (e.g.,

Markovian behavior).

Data quality refers to how well data meets the

requirements of its consumers. The relevant as-

pects data quality are known as data quality dimen-

sions (e.g., Accuracy, Timeliness, Precision, Com-

pleteness, Reliability and Error recovery). Based on

this broader conceptualization, four main categories

have been identiﬁed (Intrinsic, Contextual, Represen-

tational, Accessibility) based on 159 individual di-

mensions (Karkouch et al., 2016), see Table 1.

Data and information quality frameworks have

been proposed (O’Brien et al., 2013), which we will

review in the Related Work section. There is also

a commonly accepted classiﬁcation of (big) data as-

pects that can help in organising and managing the

quality concerns (Saha and Srivastava, 2014): volume

(scale, size), velocity (change rate/streaming/real-

time), variety (form/format) and veracity (uncertainty,

accuracy, applicability). All of these do, to a different

extent, impact on our solutions.

2.2 Machine Learning

Machine learning (ML) is the study of algorithms

and statistical models that computer systems use to

perform a particular task, relying on patterns and

inference and without being given precise instruc-

tions. Machine learning algorithms build a mathe-

matical model based on sample data, known as "train-

ing data", in order to make predictions or decisions

without being explicitly programmed to perform the

task. Machine learning tasks are classiﬁed into sev-

eral broad categories. Supervised Learning, Unsuper-

vised Learning and Reinforcement Learning are the

most common ones (Mahdavinejad et al., 2018):

• In supervised learning, the algorithm builds a

model from data that contains both inputs and de-

sired outputs. Classiﬁcation and regression algo-

rithms are types of supervised learning. Classiﬁ-

cation is used when the output is a discrete num-

ber and regression when the output is continuous.

• In unsupervised learning, the algorithm builds a

mathematical model from data that contains only

inputs and no desired output labels. Unsupervised

learning algorithms are used to ﬁnd structure in

the data, like grouping or clustering of data points.

• Reinforcement learning algorithms are given

feedback in the form of positive or negative re-

inforcement (rewards) in a dynamic environment.

The quality of ML and the models that it produces

through the different mechanisms has been an impor-

tant concern for a long time ago (Cortes et al., 1995).

Accuracy of the model in terms of the reality reﬂected

for example is a central quality property.

2.3 Internet-of-Things

The Internet-of-Things (IoT) is the application frame-

work that we consider here, where data that could be

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

580

Table 1: Categories of Data Quality Categories.

Data Quality Categories Deﬁnition Examples

Intrinsic Categories that describe quality that is innate in or

that inherently exists within data.

Accuracy, Reputation

Contextual Categories describing the quality with respect to

the context of tasks using data.

Timeliness, Complete-

ness, Data volume

Representational Categories describing how well data formats are

representative and understandable.

Interpretability, Ease of

understanding

Accessibility Categories that describe how accessible (and in the

same time secured) data are for data consumers.

Accessibility, Access

security

high in volume, velocity and variety and is under ve-

racity concerns (Saha and Srivastava, 2014) could be

produced and processed by sensors and actuators.

We make here some assumptions. Firstly, that all

data is numerical in nature, i.e., we do not consider

text or image data and corresponding quality concerns

regarding formatting and syntax here. We also as-

sume that data can be stateful and also stateless. In

that way, IoT is not the only application domain for

our investigation and our results are transferable to

other contexts such numeric data, but we focus on IoT

here for motivation and evaluation (Li et al., 2018).

3 RELATED WORK

The related work shall be discussed in terms of three

aspects: the data level, machine learning process per-

spective and machine learning model layer.

The data level was broadly discussed in (O’Brien

et al., 2013) as a discussion paper. The data quality

problems where classiﬁed into 2 groups of context-

independent and context-dependant from data and

user’s perspective. These problems are both text and

non-text based. Furthermore, in (Casado-Vara et al.,

2018), a new architecture based on Blockchain tech-

nology was proposed as a concrete example in which

an edge layer and a new algorithm were introduced to

improve data quality and false data detection, which

connected to our use of IoT as a sample context here.

Another similar work has been presented in

(Sicari et al., 2016). In this paper, a lightweight

and cross-domain prototype of a distributed architec-

ture for IoT was presented, providing minimum data

caching functionality and in-memory data processing.

A number of supporting algorithms for the assessment

of data quality and security were presented and dis-

cussed. In the presented system, users could request

services on the basis of a publish/subscribe mecha-

nism, with data from IoT devices being ﬁltered ac-

cording to user requirements in terms of security and

quality. The prototype was validated in an experi-

mental setting characterized by the usage of real-time

open data feeds presenting different levels of reliabil-

ity, quality and security.

The process perspective was presented in (Amer-

shi et al., 2019). Nine stages were speciﬁed for an ML

workﬂow in which some of the stages were data ori-

ented. ML workﬂows are highly non-linear and con-

tain several feedback loops which may loop back to

any previous stage. This workﬂow can become even

more complex if the system is integrative, containing

multiple ML components which interact together.

Finally, the machine learning model layer has

been studied in (Plewczynski et al., 2006), (Caru-

ana and Niculescu-Mizil, 2006) and (Caruana and

Niculescu-Mizil, 2005). Different algorithms and ap-

proaches were introduced and used in these papers

which were mostly building on supervised learning

algorithms. They observed that different methods can

have different applications. They also examined the

effect that calibrating the models via Platt scaling and

isotonic regression has on their performances.

For concrete ML techniques, there are also spe-

ciﬁc quality metrics applied. For instance, (Kleiman

and Page, 2019) discuss the area under the receiver

operating characteristic curve (AUC) as an example

for classiﬁcation models. We respond to that by as-

sociating primary quality concerns to the identiﬁed

model types here later on.

A different direction has been described in (Srid-

har et al., 2018). In this paper, the authors motivate

the need for, deﬁne the problem of, and propose a so-

lution for model governance in production ML. They

showed that through their approach, one can mean-

ingfully track and understand the who, where, what,

when, and how an ML prediction came to be.

The quality of data in a machine learning approach

has been investigated in (Ehrlinger et al., 2019),

where an application use case is presented. A sys-

tematic coverage of quality aspects, is however not

attempted. However, to summarise, no joint discus-

sion of quality concerns across the layers exist yet,

which we aim to address here. (Ehrlinger et al., 2019)

A Layered Quality Framework for Machine Learning-driven Data and Information Models

581

is the most relevant paper to our work but, they did

their research on just 1 use case and we intend to do a

broader research.

4 DATA AND INFORMATION

QUALITY FRAMEWORK

Information is the result of organising and structuring

raw data coming from data-producing sources such as

sensors in IoT environments.

4.1 Information Value

Information is based on data that can be put to a use.

Firstly, information has direct ﬁnancial value, i.e., the

information can be monetised in the form of exter-

nally provided products or services. Secondly, the in-

formation can be used internally to support decision

making at different levels, such as strategic or various

forms of operational decisions. We can illustrate the

value aspect in different application cases. We choose

weather and mobility here as sample domains:

• Weather: paid weather forecasting services that

aggregate and predict weather are common exam-

ples, i.e., direct monetization of the data and in-

formation takes place by the provider.

• Mobility: long-term strategic decisions, e.g., city

planning, can be based on extracted and learned

road mobility volume and patterns.

• Mobility: short-term operational planning, e.g.,

event management in a city or region can be based

on common and extraordinary mobility behaviour

derived from raw monitored data for past events.

• Mobility: immediate operation, e.g., self-adaptive

trafﬁc management systems such as situation-

dependent trafﬁc lights where the behaviour of

adaptive trafﬁc light controllers can be learned.

These examples demonstrate the different value as-

pects for speciﬁcally some use case domains.

4.2 Data and Information Quality

Layers

Our central hypothesis is that information, as op-

posed to just data, is increasingly provided through

functions created using a machine learning (ML) ap-

proach. IoT is a sample context were typically histori-

cal data is available that allows functions to be derived

in the form of machine learning models.

We distinguish here three ML function types: pre-

dictor, estimator and adaptor, see Table 2. These re-

ﬂect different usage context of ML techniques. The

predictor addresses future events; the estimator deals

with calculations or estimations irrespective of a state

notion; and the adaptor calculates adjustments to a

system in order to achieve a goal.

Based on this initial assumption, we present as the

core of our framework a layered data architecture, see

Figure 1, that captures qualities of the data and the

information function layer.

• Source Data Layer: The base layer is the source

layer consisting of raw, i.e., unstructured and un-

organised data from IoT sources in our context.

We can distinguish here context-dependent and

context-independent quality properties. We fol-

low here the frameworks presented in (O’Brien

et al., 2013) and (Thatipamula, 2013), but ad-

just this to numerically-oriented data (i.e., exclude

text-based and multimedia-based data sources).

– context-independent data quality: e.g., miss-

ing/incomplete, duplicate, incorrect/inaccurate

value, incorrect format, outdated, inconsis-

tent/violation of generic constraint.

– context-dependent data quality: e.g., the viola-

tion of domain constraints.

Data quality needs to take into account data that

are missing, incorrect or invalid in some way. In

order to ensure data are trustworthy, it is important

to understand the key dimensions of data quality

to assess the cause of low quality data.

• Information Model Layer: The upper layer is an

enhanced information model.

– In order to deﬁne a quality framework for

the information function, we considered as in-

put for function quality the following struc-

tural model quality: completeness, correctness,

consistency, accuracy and optimality that can

be found in the literature (Plewczynski et al.,

2006), (Caruana and Niculescu-Mizil, 2006).

– Based on these we deﬁne a function quality no-

tion for each of the function types

, see Table

4. Note, that is essential here to assess the qual-

ity of the function provided by the ML models,

which emerge in different types, such as predic-

tors, estimators or adaptors.

In Figure 1, the source data is grouped into reality and

rules aspects (intrinsic data quality category, see Table

In the literature, also ethical model or function quali-

ties such as fairness, sustainability or privacy-preservation

can be found. Since there is some uncertainty about their

deﬁnition, we will exclude these here.

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

582

Figure 1: Layered Data Architecture.

Table 2: ML Function Types.

Function Type Deﬁnition

predictor a predictor predicts a future event in a state-based context were historical data is available.

estimator an estimator or calculator is a function that aims to calculate a value for a given question,

which is an estimation rather than a calculation if accuracy cannot be guaranteed.

adaptor an adaptor is a function that calculates setting or conﬁguration values in a state-based

context where a system is present that can be reconﬁgured to produce different data.

Table 3: Data Quality Deﬁnitions.

Quality Aspect Quality Deﬁnition

Completeness Space Completeness is deﬁned as expected comprehensiveness. Data can be com-

plete even if optional data is missing. As long as the data meets the expecta-

tions then the data is considered complete.

Consistency Reality Consistency is the degree to which labeller annotations agree with one an-

other. In other word, how often the labeling was correct.

Conformity Rules Conformity means the data is following the set of standard data deﬁnitions

like data type, size and format.

Accuracy Reality Accuracy is the degree to which data correctly reﬂects the real world object

or an event being described, i.e., how close a label is to the real world.

Integrity Rules Integrity means validity of data across the relationships and ensures that all

data in a database can be traced and connected to other data.

Timeliness Time Timeliness references whether information is available when it is expected

and needed. The timeliness depends on user expectations.

1) and space and time aspects (contextual data quality

category), into which we organised the six individ-

ual qualities. At the ML model layer, the three func-

tion types predictor, estimator and adaptor are shown,

which each of them having their primary quality con-

cern attached. Across the layer, we have shown cross-

layer dependencies. Here we can see a mesh of de-

pendencies, with only adaptors not strictly requiring

space qualities (i.e., allow systems to work in the case

of incompleteness by not taking an action) and esti-

mators not essentially based on a state/time notion.

Machine learning connects the two layers by map-

ping data into information models. We expect the

mapping by the ML approach to have some proper-

ties. Critical here is conformance, i.e., the result-

ing functions must accurately represent the lower data

layer. In some situations, we need to reﬁne the quality

classiﬁcation. For the adaptor function, effectiveness

A Layered Quality Framework for Machine Learning-driven Data and Information Models

583

Table 4: ML Model Quality Deﬁnitions.

Quality Function Quality Deﬁnition

Correctness Predictor Correctness is a Boolean value that indicates whether a prediction was suc-

cessful

Accuracy Predictor Accuracy is the degree to which a prediction was successful

Completeness Estimator Completeness is the degree to which a estimator covers the whole input space

Effectiveness Estimator

/ Adaptor

Effectiveness is a Boolean value that indicates the correctness of a calculation

Optimality Adaptor Optimality is a Boolean value indicating whether the optimal solution has

been reached

and optimality are criteria that often involved multiple

goals. For example, for the primary goal ’effective’

for one aspect (which could be a performance thresh-

old in a technical system), we could have as secondary

goal ’optimality’ for another aspect (which could be

energy or amount of resources sent to maintain perfor-

mance). In order to see how these function qualities

are calculated, see Table 5.

Table 5: ML Functions, Qualities and ML Techniques.

Function Sample

Quality

ML technique

predictor accuracy regression

correctness classiﬁcation

estimator effectiveness clustering

completeness clustering (if there is

no cluster)

adaptor effective classiﬁcation

optimal (e.g.

minimal)

regression, reinforce-

ment

We can relate ML function quality to ML techniques.

We look at the different function types individually.

In practical terms, the complexity of the quality cal-

culation is of importance, since in an implementation,

the ML function assessment would need to be auto-

mated. Here, (i) complexity is a concern and (ii) there

is also need to wait for actual observable result event

(adaptor) as an example.

5 ILLUSTRATED USE CASE

We already illustrated the information value aspect

for the Mobility and Weather domains, indicating

that ML functions provide value for monetization

through services/products and for decision support

for strategic (long-term), operational (mid-term/short-

term) and adaptive (short-term/immediate) needs.

We now investigate the Mobility case further,

which will actually also involve weather data in or-

Table 6: Data Quality Observations for Mobility Use Case.

Quality Observation

incomplete can arise as a consequence of prob-

lems with sensor connectivity and

late arrival of data (causing incom-

pleteness until the arrival)

integrity

(duplicate)

sensors might be sending data

twice (e.g., if there is no acknowl-

edgement)

inaccurate as a consequence of sensor faults

integrity

(format

failure)

if temperature data is sent in

Fahrenheit instead of Celsius as ex-

pected

timely

(outdated)

if either the observed object has

changed since data collected (road

capacity has changed) or data that

has arrived late

inconsistent where generic consistency con-

straints such as ’not null’ in data

records are violated

der to combine different varieties of data. This serves

here as an illustration, but helps also with the valida-

tion of the concepts we introduced in our framework.

This is based on a real case study we are working on

with a provider of ICT services for public administra-

tion in a regional context. The raw data sets from the

sensor sources are of the two different domains:

• road trafﬁc data: number of vehicles (categorised)

[every hour, accumulated]

• meteorological data: temperature and precipita-

tion [every 5 minutes]

From this, a joined data set emerges that links trafﬁc

data with the meteorological data. Since we cannot

assume the weather and trafﬁc data collection points

to be co-located, for each trafﬁc data collection point,

we associate the nearest weather data collection point.

The ﬁrst component of our framework is raw data

and its associated qualities. Quality of the raw data

can be a problem, as shown in the following cases

presented in Table 6.

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

584

Machine learning shall be utilised to create ML infor-

mation models and derive different types of informa-

tion through the ML function types :

• prediction: predicted number of vehicles for the

next 5 days at a certain location,

• prediction: predicted level of trafﬁc (in 4 cate-

gories light, moderate, high, very high) for the

next 5 days at a certain location

• estimation: estimation of average number of vehi-

cles in a particular period (which needs to be ab-

stracted from concrete weather-dependent num-

bers in the data).

• estimation: estimation of the type of the vehicle

such as car or motorbike.

• adaptation: determination of suitable speed limits

to control (reduce) accidents or emissions.

The ML model creation process can use different

techniques, including decision trees, random forests,

KNN, neural networks etc. This is largely driven by

a need for accuracy. In practice, a model will be cre-

ated for each trafﬁc location. For example, a neural

network can be used to create a model for trafﬁc level

predication. ML model creation (training) takes into

account historical data, which in our case is a full year

of meteorological and trafﬁc data for all locations.

The purpose is to create information models to

support the following objectives across several value

types presented in Table 7.

Table 7: Value Types for the Mobility Use Case.

Value type Objective ML function

strategic road con-

struction

prediction/

estimation

operational holiday man-

agement

prediction

adaptive speed limits adaptation

Four functions across three function types shall now

be described in more detail in terms of functionality

and quality. The quality analysis of these functions is

presented in Table 8.

What this information model and function analy-

sis shows is that in our mobility application we cover

the following cases: (i) all information value types

(strategic, operational, adaptive) are covered, (ii) all

ML function types (predictor, estimator, adaptor) are

covered, (iii) all ML function qualities are relevant

and applicable. Thus, this serves as a demonstration

of the suitability of the quality framework we pre-

sented for common data collection, processing and

analysis applications with numeric data. In addition

to this case study, we evaluate central properties of

our solution further in general terms below.

6 DISCUSSION

The evaluation aims at validating the proposed quality

framework. Partly, the trafﬁc use case in the previous

section serves as a proof-of-concept validation of the

concepts. However, here we cover the criteria more

systematically and comprehensively. The evaluation

criteria for our quality framework are:

• completeness of the selected qualities at both data

and ML model levels,

• necessity of all selected qualities: required for the

chosen use case domains,

• transferability across different domains beyond

IoT and speciﬁcally mobility.

6.1 Observations

The above criteria shall be addressed individually.

6.1.1 Completeness and Necessity

In order to achieve a high degree of completeness, we

consulted the literature on data quality and ML model

quality and took respective frameworks on board.

Some additional ones that are less structural in nature

exist. These are sometimes referred to a ethical prop-

erties such as fairness, privacy-preserving, sustainable

and address personal or societal concerns (Rajkomar

et al., 2018). As there is no agreed deﬁnition for them

in the community, we left them out here.

We report on transferability between domains be-

low. There, we observed that all quality factors were

applicable at least once, thus conﬁrming the overall

necessity of all factors.

The use case above has demonstrated complete-

ness and necessity for the given application case, as

we remarked at the end of that section.

6.1.2 Transferability

In order to address transferability, we considered data

sets from a range of selected domains:

• weather: a range of different meteorological at-

tributes,

• buildings: looking at an air-condition and heat-

ing system as a self-adaptive system that reacts to

temperature and usage.

• people: has been considered as part of the build-

ings domain,

A Layered Quality Framework for Machine Learning-driven Data and Information Models

585

Table 8: Use Case ML Function Analysis.

Value Function

Type

Function Construction Quality

strategic estimator The long-term strategic aspect is

based on trafﬁc, but not weather.

The estimated average number of

vehicles over different periods is

here relevant.

supervised

learning –

classiﬁcation

effective: allows use-

ful interpretation, i.e.,

effective road planning

complete: available for

all stations

operational predictor The operational aspect needs to pre-

dict based on past weather and past

trafﬁc, taking into account a future

event (holiday period here). Con-

crete predictions are trafﬁc level and

trafﬁc volume (number of cars)

supervised

learning –

classiﬁcation

correct: right traf-

ﬁc level is predicted

accurate: number of cars

predicted is reasonable

close to the later real

value

predictor A second operational function could

determine the type of car, e.g., if

trucks or buses should be treated dif-

ferently

unsupervised

learning –

clustering

correct: right ve-

hicle is determined

accurate: categories

determined are correct

for correct input data

adaptive adaptor a self-adaptive function that changes

speed limit settings autonomously,

guided by an objective (such as re-

ducing accidents or lowering emis-

sions).

unsupervised

learning – re-

inforcement

learning

effective: speed re-

duction is effective.

optimal: achieves overall

objects with the proposed

action

• technical system: as an autonomous system, cloud

computing environments have been evaluated as

self-adaptive resource management systems that

rely to some degree on prediction.

We found most of the concepts of our quality frame-

work applicable in all domains, but all relevant in at

least one domain. This overall conﬁrms the transfer-

ability of the concepts. Due to space limitations, the

results are not presented here.

6.2 Threats to Validity

Machine learning comprises various learning mecha-

nisms suitable for processing numeric data, text and

other multi-media formats such as images. In order

to make qualiﬁed statements about data and informa-

tion qualities, we restricted ourselves to numeric data

with the respective qualities and ML processing types.

Not all data quality concerns from the literature were

included here. For instance, fairness, sustainability or

privacy-preservation are relevant from a more societal

than technical perspective. However, since there is no

agreement in the community and these are still under

investigation, these were excluded.

We choose IoT as the application domain, which

might be too speciﬁc, but we aligned the discussion

with the 4V model of big data (volume, variety, veloc-

ity, veracity) showing that these characteristics apply.

Some frameworks also add ’Value’ as a ﬁfth concern

to the big data characteristics (Nguyen, 2018). We

also discussed this value aspect.

The use case discussion covers the selected ML

function types, but also considers the different ML

techniques such as supervised and unsupervised

learning with classiﬁcation, regression, clustering and

reinforcement learning being applied.

7 CONCLUSIONS

Raw data is without additional processing of little

value. More and more, machine learning can help

with this processing. A critical observation in this

context is the need to address quality across the two

layers that emerge – the raw source data and the ML-

supported information models.

We presented a quality framework that combines

quality aspects of the raw source data as well as the

quality of the machine-learned models derived from

the data, We provided a ﬁne-granular model covering

a range of quality concerns organised around some

common types of machine learning function types.

Machine learning is still expanding into differ-

ent application areas. More complex information and

knowledge models can be expected in the future. Dig-

ital twins is such an advanced concept that refers

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

586

to a digital replica of physical assets such as pro-

cesses, locations, systems and devices, in which ML-

generated models based on measured and monitored

data from the real world form the basis for further

analysis. These are often based on IoT-generated data

with enhances models and function provided through

machine learning. We plan to investigate deeper the

complexity of these digital twins and the respective

quality concerns that would apply.

As other future work, our ultimate goal is to close

the loop mapping functional problems back to their

origins by identifying the symptoms of low quality

precisely and map these to the root causes of these

deﬁciencies.

REFERENCES

Amershi, S., Begel, A., Bird, C., DeLine, R., Gall, H., Ka-

mar, E., Nagappan, N., Nushi, B., and Zimmermann,

T. (2019). Software engineering for machine learning:

A case study. In International Conference on Software

Engineering (ICSE 2019) - Software Engineering in

Practice track. IEEE Computer Society.

Azimi, S. and Pahl, C. (2020a). Particle swarm optimiza-

tion for performance management in multi-cluster

iot edge architectures. In International Conference

on Cloud Computing and Services Science CLOSER.

SciTePress.

Azimi, S. and Pahl, C. (2020b). Root cause analysis and

remediation for quality and value improvement in ma-

chine learning driven information models. In 22nd

International Conference on Enterprise Information

Systems - ICEIS 2020. SciTePress.

Caruana, R. and Niculescu-Mizil, A. (2005). An empirical

comparison of supervised learning algorithms using

different performance metrics.

Caruana, R. and Niculescu-Mizil, A. (2006). An empirical

comparison of supervised learning algorithms. In Pro-

ceedings of the 23rd International Conference on Ma-

chine Learning, ICML ’06, page 161–168, New York,

NY, USA. Association for Computing Machinery.

Casado-Vara, R., de la Prieta, F., Prieto, J., and Corchado,

J. M. (2018). Blockchain framework for iot data qual-

ity via edge computing. In Proceedings of the 1st

Workshop on Blockchain-Enabled Networked Sensor

Systems, BlockSys’18, page 19–24, New York, NY,

USA. Association for Computing Machinery.

Cortes, C., Jackel, L. D., and Chiang, W.-P. (1995). Limits

on learning machine accuracy imposed by data qual-

ity. In Tesauro, G., Touretzky, D. S., and Leen, T. K.,

editors, Advances in Neural Information Processing

Systems 7, pages 239–246. MIT Press.

Ehrlinger, L., Haunschmid, V., Palazzini, D., and Lettner,

C. (2019). A daql to monitor data quality in ma-

chine learning applications. In Hartmann, S., Küng,

J., Chakravarthy, S., Anderst-Kotsis, G., Tjoa, A. M.,

and Khalil, I., editors, Database and Expert Systems

Applications, pages 227–237, Cham. Springer Inter-

national Publishing.

Heine, F., Kleiner, C., and Oelsner, T. (2019). Automated

detection and monitoring of advanced data quality

rules. In Hartmann, S., Küng, J., Chakravarthy,

S., Anderst-Kotsis, G., Tjoa, A. M., and Khalil, I.,

editors, Database and Expert Systems Applications,

pages 238–247, Cham. Springer International Pub-

lishing.

Karkouch, A., Mousannif, H., Moatassime, H. A., and

Noel, T. (2016). Data quality in internet of things: A

state-of-the-art survey. Journal of Network and Com-

puter Applications, 73:57 – 81.

Kleiman, R. and Page, D. (2019). Aucµ: A performance

metric for multi-class machine learning models. In In-

ternational Conference on Machine Learning, pages

3439–3447.

Li, H., Ota, K., and Dong, M. (2018). Learning iot in

edge: Deep learning for the internet of things with

edge computing. IEEE Network, 32:96–101.

Mahdavinejad, M. S., Rezvan, M., Barekatain, M., Adibi,

P., Barnaghi, P., and Sheth, A. P. (2018). Machine

learning for internet of things data analysis: a sur-

vey. Digital Communications and Networks, 4(3):161

– 175.

Nguyen, T. L. (2018). A framework for ﬁve big v’s of big

data and organizational culture in ﬁrms. In 2018 IEEE

International Conference on Big Data (Big Data),

pages 5411–5413. IEEE.

O’Brien, T., Helfert, M., and Sukumar, A. (2013). The value

of good data- a quality perspective a framework and

discussion. In ICEIS 2013 - Proceedings of the 15th

International Conference on Enterprise Information

Systems, volume 2.

Plewczynski, D., Spieser, S. A. H., and Koch, U. (2006).

Assessing different classiﬁcation methods for virtual

screening. Journal of Chemical Information and Mod-

eling, 46(3):1098–1106. PMID: 16711730.

Rajkomar, A., Hardt, M., Howell, M. D., Corrado, G., and

Chin, M. H. (2018). Ensuring fairness in machine

learning to advance health equity. Annals of internal

medicine, 169(12):866–872.

Saha, B. and Srivastava, D. (2014). Data quality: The other

face of big data. In 2014 IEEE 30th International

Conference on Data Engineering, pages 1294–1297.

IEEE.

Sicari, S., Rizzardi, A., Miorandi, D., Cappiello, C., and

Coen-Porisini, A. (2016). A secure and quality-aware

prototypical architecture for the internet of things. In-

formation Systems, 58:43 – 55.

Sridhar, V., Subramanian, S., Arteaga, D., Sundararaman,

S., Roselli, D. S., and Talagala, N. (2018). Model

governance: Reducing the anarchy of production ml.

In USENIX Annual Technical Conference.

Thatipamula, S. (2013). Data done right: 6 di-

mensions of data quality. https://smartbridge.com/

data-done-right-6-dimensions-of-data-qua\-lity/. Ac-

cessed on 2020-01-16.

A Layered Quality Framework for Machine Learning-driven Data and Information Models

587
