Retrieving Similar Software from Large-scale Open-source Repository

by Constructing Representation of Project Description

Chuanyi Li

1,3 a

, Jidong Ge

1 b

, Victor Chang

2 c

and Bin Luo

State Key Laboratory for Novel Software Technology, Software Institute, Nanjing University, Nanjing, China

School of Computing and Digital Technologies, Teesside University, Middlesbrough, U.K.

State key Laboratory of Networking and Switching Technology,

Beijing University of Posts and Telecommunications, Beijing, China

Keywords:

Information Retrieval, Project Similarity, Big Text Data, Learn to Rank.

Abstract:

The rise of open source community has greatly promoted the development of software resource reuse in all

phases of software process, such as requirements engineering, designing, coding, and testing. However, how

to efﬁciently and accurately locate reusable resources on large-scale open source website remains to be solved.

Presently, most open source websites provide text-matching-based searching mechanism while ignoring the

semantic of project description. For enabling requirements engineers to ﬁnd software that are similar to the

one to be developed quickly at the very beginning of the project, we propose a searching framework based on

constructing semantic embedding for software project with machine learning technique. In the proposed ap-

proach, both Type Distribution and Document Vector learnt through different neural network language models

are used as project representations. Besides, we integrate searching results of different representations with

a Ranking model. For evaluating our approach, we compare search results of different searching strategies

manually using an evaluating system. Experimental results on a data set consisting of 24,896 projects show

that the proposed searching framework, i.e., combining results derived from Inverted Index, Type Distribution

and Document Vector, signiﬁcantly superior to the text-matching-based one.

1 INTRODUCTION

The large number of open source software products

brings great opportunities and challenges to software

reuse. No matter at which level of reuse, e.g., require-

ments reuse, design reuse, code reuse and module

reuse and product reuse, the most important thing is

to locate reusable artifacts in the massive open source

software repository. For reusing, the earlier the stage

is, the more beneﬁts there are. So, how to ﬁnd appro-

priate open source projects of similar requirements to

the one to be developed at the very beginning of soft-

ware process has always been an important topic to

be studied these days.

However, at the very beginning of a project, only

the simple description of the product is available.

Many existing software similarity measurement ap-

proaches relying on other software artifacts cannot be

https://orcid.org/0000-0003-4956-8142

https://orcid.org/0000-0003-1773-0942

https://orcid.org/0000-0002-8012-5852

applied. Existing open source software repositories

support keywords based similar project searching ap-

proaches but ignore the deep semantic of text as well

as the concept of software domain knowledge. Upon

deriving query results in this way, users still need to

review many of the retrieved project description with

their idea one by one to check if they are what they

want. Besides, for users without software engineer-

ing background, it is hard for them to pick up exact

keywords for searching.

In this paper, we propose a similar software

searching framework according to software descrip-

tion. Figure 1 shows the main steps of our approach.

First, we construct inverted index, train Doc2Vec

model and train software type predictor for the repos-

itory. Then, apply clustering algorithms on docu-

ment vectors and type distribution vectors respec-

tively to all products to generate clusters for fasten-

ing the searching efﬁciency. While a query is made,

three different result sets will be given. Next, we

train a ranking model for re-rank the fetched results

in the three sets. For training the type predictor,

296

Li, C., Ge, J., Chang, V. and Luo, B.

Retrieving Similar Software from Large-scale Open-source Repository by Constructing Representation of Project Description.

DOI: 10.5220/0009400002960303

In Proceedings of the 5th International Conference on Internet of Things, Big Data and Security (IoTBDS 2020), pages 296-303

ISBN: 978-989-758-426-8

Software

Projects

Repository

Word Matching

(Inversed Index)

Doc2Vec

Clusters

Type

Predictor

Clusters

Preprocessing

Query: input software product description

Feedback

Ranking

Model

Projects Data with

Manually

Evaluating Results

Feedback

Results

Query

Preparation

Ranking

Construct

Train

Figure 1: Framework of the proposed Software Project Searching Approach.

we try different machine learning algorithms includ-

ing Support Vector Machine (i.e., SVM)(Cortes and

Vapnik, 1995), full connected Neural Network (i.e.,

FNN)(Epelbaum, 2017), Convolutional Neural Net-

work (i.e., CNN)(Kim, 2014) and Long Short-Term

Memory neural network (i.e., LSTM)(Hochreiter and

Schmidhuber, 1997). The experimental results show

that our approach improves the similar software prod-

uct searching results signiﬁcantly.

In conclusion, we make the following contribu-

tions in this paper:

(1) Organizing a dataset consisting of 24,896 soft-

ware projects for conducting similar software

product searching research. 2000 projects are

used as testing data and the others are used as the

searching database.

(2) Designing and implementing an integrated sim-

ilar software product/project searching approach

by adopting learning to rank techniques.

(3) Developing a reusable manual annotating system

for evaluating different searching methods.

The rest of this article is organized as follows.

Section 2 introduces some related work. Section 3 de-

scribes the dataset. Details of the proposed approach

are illustrated in Section 4. Experiments and evalua-

tions are presented in Section 5. Section 6 concludes

the paper.

2 RELATED WORK

Most existing related work mainly measure project

similarity based on software code or other artifacts.

Lannan Luo et al. (Luo et al., 2017) proposed a binary

code similarity comparison method using the longest

common subsequence to judge the similarity degree

of items according to the code. Naohiro Kawamitsu

et al. (Kawamitsu et al., 2014) proposed a technique

to automatically identify the source code reuse rela-

tionship between two code bases. Shuai Wang et al.

(Wang and Wu, 2017) proposed a new method for

binary code similarity analysis using memory fuzzi-

ness. The main difference between our work and

these is that we measure the natural language simi-

larity but not the code similarity. For non-software

engineering domain text similarity measuring, there

are many existing works based on machine learning

techniques. Lin Yao et al. (Yao et al., 2018) propose

a new LSTM encoder for the existing similarity mea-

surement algorithm of short text. Chenghao Liu et

al. (Liu et al., 2017) proposed an online bayesian in-

ference algorithm for collaborative subject regression

(CTR) model to act on the recommendation system.

Naresh Kumar Nagwani et al. (Nagwani, 2015) pro-

posed a similarity measure of text processing (SMTP)

for knowledge discovery of text collection. Yuhua

Li et al. (Li et al., 2006) proposed an algorithm

that takes into account the semantic information and

word order information implied in sentences. Dif-

ferent from these works, we aim at solving the soft-

ware project description similarity problem by con-

sidering the software engineering domain knowledge

while adopting the machine learning techniques.

3 CONSTRUCTED DATA SET

We prepare the data set according to the large open-

source and business software platform SourceForge

(i.e., https://sourceforge.net). We downloaded the Top

24,896 open-source software projects from Source-

Retrieving Similar Software from Large-scale Open-source Repository by Constructing Representation of Project Description

297

Forge by setting the searching ﬁlter of Operating

System to Windows in January of 2018. All these

projects are belonging to 17 categories. The number

of projects of each category is as shown in Table 1.

For the projects in the prepared data set, there are their

names, categories, and descriptions.

For approach evaluation, we randomly choose

2000 projects from each category at a same ratio for

comparing different approaches. The left projects are

used in constructing the searching database. In the

remain parts of this paper, we use Evaluating Set re-

ferring to 2000 selected projects and Database for the

other projects. For training and testing the ranking

strategy, the evaluating set is utilized.

4 APPROACH

4.1 Database Preparation

There are three concrete searching methods in our

approach, namely, words matching, text semantic

matching and software category matching. For each

method, we need to prepare searching index based on

database.

Words Matching. For implementing efﬁcient words

matching searching, we generate Inverted Index for

descriptions of software projects in our searching data

base. Inverted indexing technology for text character

matching is widely used in all kinds of search engines.

It represents the connection among texts to some ex-

tents, especially the Top-K searching results performs

well in most application scenario. We utilize inverted

indexing for modeling the text similarity from the

words matching perspective and provide similar soft-

ware projects as part of the integrated searching ap-

proach. We only retrieve keywords in the description

for generating the inverted index. The keywords are

those have top-25 TF-IDF (Term Frequency-Inverse

Document Frequency) values in each project descrip-

tion. We do not take stopwords into account in build-

ing the inverted index and the stopwords are those

in Default English stopwords list

. We adopt the

open-source search library Lucene

for implementing

words matching.

Semantic Matching. In order to modeling deep se-

mantics in measuring software product similarity, we

adopt Doc2Vec (Le and Mikolov, 2014) for generat-

ing representation of software description. For cal-

culating similarities among a large number of texts,

a general method for transforming each text into a

Deﬁned here: https://www.ranks.nl/stopwords/

Found here: http://lucene.apache.org/

ﬁxed-length feature vector is needed. Doc2Vec is an

unsupervised algorithm that learns ﬁxed-length fea-

ture representations from variable-length pieces of

texts, such as sentences, paragraphs, and documents.

In our approach, we apply the Doc2Vec tools pro-

vided by gensim

to transform each software project

description into a dense vector. All projects in the

data set are used in training the Doc2Vec model. Val-

ues of core parameters for training are vector size =

150, window = 5, min count = 3. These values are

most frequently used in applying Doc2Vec tools. An-

other consideration is that the smaller the vector size

is, the higher the querying response efﬁciency is.

Clustering. In order to fasten the searching efﬁ-

ciency, we apply k-Means(MacQueen et al., 1967)

clustering algorithm on derived document vectors of

projects in the database. Since clustering can cluster

the sample data with similar semantics, it can effec-

tively reduce the range of candidate sets and reduce

the time cost and noise impact caused by excessive

data. The vector similarity algorithm used in k-Means

is cosine similarity(Gomaa and Fahmy, 2013). The

number of clusters is set to 34, i.e., twice of the cat-

egory number. While the searching is requested, the

input project description will be ﬁrstly turn to a doc-

ument vector and then ﬁnd the nearest cluster center.

The Top-K nearest projects in the same cluster will be

retrieved as similar projects. Details of querying will

be described in next subsection.

Category Matching. The ﬁrst two parts of match-

ing have little relation of software engineering domain

knowledge. Software project taxonomy is one kind

of software engineering domain speciﬁc knowledge.

The category names are usually software property re-

lated words, such as Windows, Desktop Application,

Mobile Application, and Security. We could use soft-

ware category information of a project to represent

the project for searching similar ones. Inspired by

the neural network language model, we utilize ma-

chine learning methods to learn vectors of software

project’s category distribution from project descrip-

tion. We model this as a multiclass classiﬁcation

problem. We try different machine learning algo-

rithms and different input feature representing meth-

ods. Combinations of learning algorithms and fea-

tures are as following:

(1) SVM + TF-IDF. We adopt the multiclass SVM

method which casts the multiclass classiﬁcation prob-

lem into a single optimization problem. The tool we

use is libsvm

developed by Chih-Chung Chang and

Found here: https://radimrehurek.com/gensim/models/

doc2vec.html

Found here: https://www.csie.ntu.edu.tw/

∼

cjlin/

libsvm/

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

298

Table 1: Statistics on software projects in the prepared data set.

Category # of projects Examples Category # of projects Examples

Development 4321 Hibernate, TortoiseSVN Security & Utilities 690 Tor Browser, ophcrack

System Administration 2554 ScpToolkit, Rufus Home & Education 596 Logisim, FMSLogo

Science & Engineering 2020 OpenCV, Octave Forge Desktop 574 3D Desktop, Adobe Flash Updater

Games 1626 Amidst, Antimicro Terminals 133 Alarm, BBSSH

Internet 1480 4chan Downloader, 51Degrees-PHP Multimedia 91 BlackBox ISO Burner, Joystick To Mouse

Business & Enterprise 1238 KeePass, GnuWin Mobile-apps 47 KeePass for J2ME, LineageOS on LeEco

Audio & Video 1105 Equalizer APO, ffdshow Formats and protocols 43 MoodleRest Java Library, Podcast Generator

Communications 1244 Moodle, Scrollout F1 Nonlisted Topics 6244 Pokemon Online, Pokemon–Dark Rift

Graphics 890 Sweet Home 3D, gnuplot Total Number of projects 24,896

Chih-Jen Lin. We use TF-IDF vectors to represent

each project’s description. The size of vocabulary is

50,000 because we choose to keep words with top-

50000 document frequency for representing each doc-

ument. For tuning the parameter of SVM algorithm,

i.e., Cost, we apply ﬁve-fold cross-validation on the

data set consisting of all projects in the database.

We choose the value for parameter –c that derives

the highest average predicting performance in cross-

validation. Details of evaluation metrics are described

in the experiment section.

(2) FNN + TF-IDF. Different from SVM’s construct-

ing separating gap, neural network is to build a map-

ping function between input data instance and its la-

bels. We ﬁrstly try simple full connected neural net-

work to learn a project category predictor. Each de-

scription of project is represented by the TF-IDF vec-

tor which is the same as used in SVM. We adopt sim-

ple settings for the fully connected neural network.

There are three hidden layers and they have 1,500,

750 and 17 neurons separately. The activation func-

tion is Tanh. The input and output layers have 50,000

and 17 neurons respectively. The output layer is also

a so f tmax layer applied on the third hidden layer.

(3) CNN + Word2Vec. Word2Vec (Mikolov et al.,

2013) is a novel model architecture for computing

continuous vector representations of words from very

large data sets. In our approach, we adopt Word2Vec

to train embedding for words. In our experiments, we

length of vectors for words is set to 150 which is the

same as that of vectors for the entire document.

Convolutional neural network uses convolution

kernel to extract local features, and integrates and an-

alyzes features in the way of multi-layer convolution,

which shows great advantages in image processing

(LeCun et al., 1998). We also try CNN with simple

settings in training project category predictor. The

number of input words of each project description is

equal to the average length of all descriptions in the

database, i.e., 46. For documents whose length is

more than 46, we use the middle 46 words to rep-

resent the document. Each word is represented by a

150-dimension vector derived from Word2Vec model.

We use three kernels of different sizes, namely 3, 4

and 5. There is only one convolution-pooling layer

for each kernel and eventually they are concatenated

together to predict the project categories. Like that in

fully connected neural network, the output layer is a

softmax layer.

(4) LSTM + Word2Vec. LSTM is an artiﬁcial recur-

rent neural network (RNN) architecture(Hochreiter

and Schmidhuber, 1997). Both CNN and LSTM can

be utilized as feature extracting approaches in pro-

cessing natural language texts. CNN extract effec-

tive features from the entire text while LSTM extract

effective semantic features speciﬁcally. In our ap-

proach, we only want to explore which one is better

in encoding project category distribution for search-

ing similar software projects among SVM, NN, CNN

and LSTM. So, we also adopt simple LSTM in train-

ing project category predictor.

There are some common settings for NN, CNN

and LSTM: (1) using tanh activation function, (2)

using Mean Squared Error loss function, (3) use

Stochastic Gradient Descent (SGD) loss optimizer,

and (4) softmax layer as output layer.

Upon the category distribution vectors of projects

in the database are derived, the clustering algorithm is

also applied for indexing projects.

4.2 Query

The querying process is intuitively described in Fig-

ure 1. The details of each modules’ work are illus-

trated as following:

Words Matching. Only non-stopwords are retrieved

in searching similar projects using inverted index.

The remained words in the description are trans-

ferred to the Lucene API to searching similar projects.

Eventually, top-10 projects returned by Lucene would

be used as the words matching similar projects.

Semantic Matching. The description of the input

project is ﬁrstly transformed into a 150-dimensional

document vector by the pre-trained Doc2Vec model.

Then the cosine similarity between the document vec-

tor and each cluster center are calculated. Upon the

nearest cluster is detected, top-10 nearest projects in

the cluster measured by cosine similarity algorithm

would be retrieved as ultimate similar projects of se-

mantic matching.

Category Matching. This process is the same as that

of the semantic matching searching. Firstly, the de-

Retrieving Similar Software from Large-scale Open-source Repository by Constructing Representation of Project Description

299

scription of the input project is given to the pre-trained

category predictor to generate a category distribution

vector for the project. Then this vector is used to de-

tect the nearest cluster and retrieve the top-10 near-

est projects in that cluster with cosine similarity algo-

rithm.

As shown in Figure 1, for each input project, the

querying process would return three different lists of

similar projects retrieved by different approaches. We

would also manually evaluate the quality of different

lists of projects. Since different approaches has dif-

ferent similarity aspects consideration and each gives

some good feedbacks, we want to integrate their re-

sults by re-ranking the three lists of projects. Details

are illustrated in next subsection.

4.3 Ranking

Ranking approach is to conduct a secondary sort on

the three different tok-10 project lists returned by dif-

ferent searching strategies.

For each project in the evaluating set, its corre-

sponding thirty similar projects are retrieved through

three different matching approaches. Then, for each

project, each of their similar projects is manually an-

notated a score. Eventually, the similar projects can

be re-ranked according to the scores. The ranker to be

trained should predict the ultimate order of projects

as similar to manually ordering as possible. The input

project description is called a query and each result

is called a document. The task is to rank documents

belonging to a same query.

In this paper, we adopt pair-wise ranking al-

gorithm for re-ranking similar projects. It formu-

lates ranking task as a two-class classiﬁcation prob-

lem(Clariana and Wallace, 2009) and focuses on rel-

ative preference between two items of a same query.

Let (x

, y

) and (x

, y

) be two result documents of a

same query, where x is the feature vector of the re-

sult and y is the score of the result, then a new data

instance (x

, y

)=(x

−x

, y

−y

) would be generated

for training the pair-wise ranker. The tool we use is

SVM Rank

. The following commonly used features

are adopted:

• TF-IDF vector of the document, i.e., descriptions

of result projects.

• Latent Dirichlet Allocation (i.e., LDA) topic

model vector of the document.

• Length of the document.

• The number of words that appear in both the query

and the document.

Found here: http://www.cs.cornell.edu/people/tj/svm\

light/svm\ rank.html

• The one hot vector of unigram pairs in the (query,

document) pairs.

• The string edit distance between the query and the

document.

• The cosine similarity of doc2vecs and category

vectors between the query and the document.

• The searching approach, 0, 1 and 2 for Words, Se-

mantic and Category Matching respectively.

All features are calculated based on the keywords

extracted from each project’s description. We con-

duct ﬁve-fold cross-validation for evaluating using the

evaluating set.

5 EXPERIMENTS

In this section, we introduce the manual annotating

process and evaluation metrics.

5.1 Annotation

The annotators for annotating similarity between soft-

ware projects are second-year graduate students in

software engineering. Each group of projects are

annotated by ﬁve students. The average scores are

adopted as the ultimate scores for each project. The

annotators are asked to assign scores to the result

projects according to the input project. Six different

similarity aspects are considered in manually mea-

suring the similarity. If two projects have no com-

mon properties among the six aspects, then the score

is 0. If they match one more aspect, more scores

they should be assigned. Descriptions of these as-

pects and an example is shown in Table 2. We set

different scores for different aspects, i.e., Platform

and Architecture are 1 score while the others are 2

scores. Through manual annotating, projects in dif-

ferent searching result lists of all projects in the eval-

uating set would get manual scores representing their

similarities with the input projects.

5.2 Evaluation Metrics

For evaluating the classiﬁcation performances of cat-

egory predictors, we use the precision, recall, and ac-

curacy values. Since the numbers of projects of dif-

ferent categories are imbalanced, the macro precision,

recall and F1 are also used in evaluation.

For comparing the performances of different ap-

proaches in searching similar software projects, we

compare the average manually annotated scores of

each project in the result list, i.e., Average Score. Be-

sides, we merge result lists of different approaches

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

300

Table 2: Descriptions of scoring aspects and the annotating example.

Scoring Aspects Description Example

√

/×

Platform

Products are used in the same platform, such as

mobile phones, laptops, servers, clusters, cloud,

etc.

This is a map

internet web

service based on

a huge raster

maps or satellite

images for

tracking and

monitoring the

mobile objects

(cars etc) using

GPS.

QLandkarte GT is the

ultimate outdoor

aﬁcionado’s tool. It

supports GPS maps in

GeoTiff format as well

as Garmin’s img vector

map format. Additional

it is the PC side front

end to QLandkarte M, a

moving map application

for mobile devices.

√

Architecture

Client, Server, Client/Server, Browser/Server,

etc.

Users

No speciﬁc user group, developers, ﬁnanciers,

designers, etc.

Domain

Financial, Words, Painting, Game, Education, etc.

√

Tools

Products are related the same third party

tools, libraries or other type of resources.

√

Function

The products are to satisfy the same functional

requirements.

and re-rank projects according to their manually an-

notated scores. Then the Average Hit of Top-10

projects in the ranked list of different approaches are

calculated. The higher average score and average hit

are, the better the searching approach is.

For evaluating the ranking approach, we adopt the

commonly used evaluation metric Mean Average Pre-

cision (i.e., MAP) for algorithms that do information

retrieval.

5.3 Answering Research Questions

RQ1. Which machine learning method works best for

software type encoding in the searching scenario?

Results and Discussion: According to classiﬁcation

performances showing in Table 3, the full connected

neural network using TF-IDF as input works best in

transforming project description into category distri-

bution vector. We also check the accuracy of top-k

categories predicted by classiﬁers in Table 3. It proves

that FNN with TF-IDF has better predicting capabil-

ity than others taking top-k categories into account.

The average manual annotated score shows the over-

all performance of each method. For further describ-

ing that the recommending performance of FNN is

better than others, we plot the average score curves

of Top-K recommended projects for each method. In

Figure 2(a), we calculate the average score of k-th

recommended project in the initial order. It shows

that FNN has the highest scores for all k-th projects.

In Figure 2(b), we ﬁrstly rank all recommended list

of each method for each evaluating project accord-

ing to the manual annotated scores, then calculate the

average scores of the ranked k-th projects on all the

evaluating projects and plot the score curves. Al-

though CNN achieves higher average scores for top-5

projects, the last 5 projects derives much lower scores

than FNN. The average scores of ranked list derived

by FNN is also higher than the other two methods. All

these details prove that FNN with TF-IDF as text fea-

tures is the best simple method for encoding software

project category distribution in the similar project re-

trieving scenario. In the following parts, FNN would

be used as the representative of Category Matching

approach.

RQ2. What are the performances of different search-

ing methods based on words matching, pure semantic

similarity and type semantic respectively?

Results and Discussion: According to average man-

ual scores shown in Table 4, the category matching

method achieves the best performance among all the

three approaches. However, there are no big dif-

ferences between the words matching and category

matching. The average hits at position 1 to 3 of

words matching is even much higher than twice of

that of the category matching, implying the most sim-

ilar projects could be derived by matching words. But

matching category distribution does better in retriev-

ing other similar projects. The average hits at other

top-k ranges of category matching are higher than

those of the other two methods. Note that there are

many projects derived by different methods tied for

tenth. It could be seen that category matching also

derives the most number of tied tenth. The MAP val-

ues represent the consistencies between manual or-

dering and searching ordering. So, category match-

ing can best represent people’s point of view in sort-

ing projects. We plot average scores and average hits

at each top-k position of different approaches in Fig-

ure 3. It shows that words matching does the best

in searching the most similar projects while category

matching does best on average. Since each approach

has some high quality feedbacks, using any one singly

as ultimate searching strategy is not a good strategy.

So we design the Ranking step.

RQ3. To what extent would the ranking strategy im-

proves searching performance while combining the

results of different searching methods?

Results and Discussion: Before ranking, there are six

different strategies for combining result lists of the

three searching approaches. All MAP values of these

strategies are shown in the ﬁrst six columns of Table

Retrieving Similar Software from Large-scale Open-source Repository by Constructing Representation of Project Description

301

Table 3: Evaluating results of different Category Predictors.

Method

Macro Accuracy

Average Score

precision recall F1 Top-1 Top-2 Top-3 Top-4 Top-5

SVM 0.475 0.230 0.445 0.475 0.593 0.642 0.685 0.716 4.246

FNN 0.641 0.507 0.566 0.581 0.717 0.786 0.837 0.863 5.258

CNN 0.553 0.317 0.403 0.428 0.602 0.687 0.743 0.797 4.996

LSTM 0.612 0.371 0.462 0.489 0.648 0.733 0.793 0.837 4.644

3.5

4.5

5.5

6.5

top1 top2 top3 top4 top5 top6 top7 top8 top9 top10

Score

Index of result project

Average Scores of k-th Project after Ranking

CNN

FNN

LSTM

SVM

3.5

4.5

5.5

top1 top2 top3 top4 top5 top6 top7 top8 top9 top10

Score

Index of result project

Average Scores of k-th Project

CNN

FNN

LSTM

SVM

(a) (b)

Figure 2: Average scores of k-th projects in the result list of different category predictors.

top1 top2 top3 top4 top5 top6 top7 top8 top9 top10

Score

Index of result project

Average Scores of k-th Project

Semantic

Words
