Towards Web Application Security by Automated Code Correction

Ricardo Morgado, Ib

eria Medeiros and Nuno Neves

LASIGE, Faculty of Sciences, University of Lisboa, Portugal

Keywords:

Web Application Vulnerabilities, Static Analysis, Code Correction, Software Security.

Abstract:

Web applications are commonly used to provide access to the services and resources offered by companies.

However, they are known to contain vulnerabilities in their source code, which, when exploited, can cause se-

rious damage to organizations, such as the theft of millions of user credentials. For this reason, it is crucial to

protect critical services, such as health care and ﬁnancial services, with safe web applications. Often, vulnera-

bilities are left in the source code unintentionally by programmers because they have insufﬁcient knowledge on

how to write secure code. For example, developers many times employ sanitization functions of the program-

ming language, believing that they will defend their applications. However, some of those functions do not

invalidate all attacks, leaving applications still vulnerable. This paper presents an approach and a tool capable

of automatically correcting web applications from relevant classes of vulnerabilities (XSS and SQL Injection).

The tool was evaluated with both benchmark test cases and real code, and the results are very encouraging.

They show that the tool can insert safe and right corrections while maintaining the original behavior of the

web applications in the vast majority of the cases.

1 INTRODUCTION

In recent years, web applications have become in-

creasingly popular and an essential part of our lives.

Often, web applications require users to provide per-

sonal details, such as our home address and credit

card number. This data is stored on the application’s

database and may be exposed if someone with mali-

cious intentions can successfully perform an attack.

Therefore, web applications are an appealing target

for attackers because, if they succeed, they can poten-

tially compromise the personal details of up to mil-

lions of users. Injection vulnerabilities, such as SQL

Injection (SQLi) and Cross-Site Scripting (XSS), rank

high in the list of web application security risks ac-

cording to the OWASP Top 10 (van der Stock et al.,

2017) and are the most prevalent and preferred of at-

tackers.

Vulnerabilities are usually caused by misinformed

developers who make mistakes when writing the code

and do not possess sufﬁcient knowledge on software

security. Simultaneously, there are also the limi-

tations of time and budget for testing within orga-

nizations, which contribute to exacerbate the prob-

lem. Lastly, the sources for programming information

available to developers can sometimes have confus-

ing recommendations, which can also inﬂuence the

security of the code (Acar et al., 2016) (Fischer et al.,

2017). The consequence is a growing number of vul-

nerabilities being reported every year, with a particu-

lar incidence on web applications.

In our context, PHP is particularly relevant, as it

is the most used server-side language of web appli-

cations, powering around 79% of the websites

. The

fact that PHP is a ”weakly-typed” language makes it

easier to introduce mistakes in some situations, es-

pecially when dealing with badly-documented code.

All programming languages, including PHP, contain a

wide range of functions (and other methods) that can

be used to invalidate attacks. However, most develop-

ers do not master when and how to use them, conse-

quently leaving applications with vulnerabilities.

There are several tools available to analyze PHP

source code and to ﬁnd potential bugs. Such tools are

often hard to use, do not provide the information de-

velopers need, and report vulnerabilities that do not

exist (i.e., false positives). Some tools are based on

taint analysis, while others employ techniques like

dynamic analysis (Schwartz et al., 2010) and sym-

bolic execution (Zheng et al., 2013) (Huang et al.,

2019). They provide reports in various formats and al-

most all of them leave the burden of ﬁxing the bugs to

developers. Given that most developers are unaware

of the right way to remove a bug, this process many

https://w3techs.com/technologies/details/pl-php/all/all

Morgado, R., Medeiros, I. and Neves, N.

Towards Web Application Security by Automated Code Correction.

DOI: 10.5220/0009369900860096

In Proceedings of the 15th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2020), pages 86-96

ISBN: 978-989-758-421-3

times does not completely eliminate the vulnerability.

To alleviate this problem, tools could detect and

correct such bugs. However, the small number of

tools that perform automatic correction of the source

code, often have limitations in the sense that they

insert unsound ﬁxes, producing syntactically invalid

new programs that can not be executed (Medeiros

et al., 2014).

This work presents an approach to automatically

repair web applications by employing a mixture of

taint tracking and instruction simulation of PHP pro-

grams. The solution focuses on two prevalent types

of web application vulnerabilities, namely XSS and

SQLi. Our tool called PHPCORRECTOR, determines

where and what correction is most appropriate for a

particular bug, and is able to deal with existing forms

of sanitization. An experimental evaluation was per-

formed with benchmark test cases from the NIST

SARD dataset and six large web applications. The

results demonstrate that PHPCORRECTOR can repair

appropriately the great majority of the identiﬁed bugs,

leaving a few cases where the applications became

only partially protected. We believe that these results

are highly encouraging, giving evidence that our ap-

proach is an useful step towards automatic correction

of web applications.

The main contributions of the paper are: 1) a study

of the different sanitization methods of PHP and their

pitfalls; 2) an approach to automatically develop a ﬁx

for XSS and SQLi in web applications; 3) a tool capa-

ble of correcting automatically PHP web applications

while maintaining their original functionality; and 4)

an evaluation with both benchmark test cases and real

web applications, demonstrating beneﬁts of our ap-

proach.

2 BACKGROUND

This section gives a brief overview of injection vul-

nerabilities – SQLi and XSS – and afterwards it ex-

plains the most relevant PHP sanitization methods for

these bugs and their pitfalls.

2.1 Injection Vulnerabilities

SQL Injection vulnerabilities (SQLi) occur when a

crafted input of an attacker can reach a SQL inter-

preter as part of a query, tricking the database into

executing unintended commands. This often allows

the bypass of authentication mechanisms, the access

to conﬁdential information, or the shut down of the

database server. SQLi ﬂaws are usually introduced

in web applications who fail to properly validate in-

put data before inserting it into a query. Listing

1 shows a classic example of a SQLi vulnerability,

where the user input, received through $ GET [

is placed in the SQL statement that is forwarded by

mysqli query to the database. This type of vulner-

ability can be prevented, for example, by applying

proper sanitization to the input and by using param-

eterized queries to interact with the database.

1 $qu er y = " S ELE CT * F ROM E mp lo ye e W HER E i d = " .

$_ GET [" id " ];

2 $r esu lt = my s ql i_ qu er y ( $ conn , $ qu er y ) ;

Listing 1: Example of a SQLi vulnerability.

Cross-Site Scripting Vlnerabilities (XSS) occur when

an application includes untrusted user data as part

of a web page without proper validation or encod-

ing (van der Stock et al., 2017). XSS lets an attacker

trick the victim’s web browser into executing his ma-

licious code. For instance, a traditional PHP XSS ﬂaw

exists when a user input is inserted in a web page

with the echo function. There are several forms of

XSS, with new variants continuing to appear period-

ically (Steffens et al., 2019), and therefore, they are

one of the most prevalent vulnerabilities in the web

today (WhiteHat Security, 2019). XSS can be averted

by properly encoding potentially malicious input be-

fore adding it to a web page.

2.2 PHP Sanitization Methods

2.2.1 Generic

There are few sanitization methods that can help with

both kinds of vulnerabilities. For numeric inputs,

PHP contains the intval and floatval functions

that preclude many of the SQLi and XSS attacks.

Both functions receive a string as argument and re-

turn the result of converting that string to an integer

or a ﬂoat, respectively. If they are unable to do the

transformation, they return zero, thus making any ma-

licious input innocuous while leaving benign string

inputs untouched (i.e., containing just numbers). Al-

ternatively, the conversion can be achieved with casts

to numeric types. The casts will execute in a similar

way as the previously described functions, thus mak-

ing inputs harmless.

For string inputs that have a well-known format,

such as a date or zip code, there is the possibility of

using the preg match function to compare them with

a regular expression. In order for this technique to be

safe, the developer has to use a correct regular expres-

sion.

Towards Web Application Security by Automated Code Correction

Lastly, if the input can only assume one of a lim-

ited number of values, developers can use white lists

for these values. To do so, it is created an array of

valid values and used the in array function to verify

if the input is part of the array.

2.2.2 Cross-Site Scripting

Sanitization. Protection from XSS can be attained

with functions that encode special characters like <

or >, making them inoffensive when rendered in the

browser.

HTML-encoding functions convert all HTML’s

special characters to their respective representation as

HTML entities, thus preventing attacks that abuse un-

intended utilization of these values. For example, the

< character is converted to <, thus being properly

displayed on the browser. There are two functions in

this group: htmlspecialchars and htmlentities.

They receive the same arguments (a string to be san-

itized and a set of ﬂags), but differ in the number of

characters they convert. The former converts the fol-

lowing characters: &, ", ’, <, >, whereas the latter

converts not only these characters but also more than

two hundred additional ones, such as

A and C¸. The

ﬂags inﬂuence safety because they specify the way

the function encodes quotes and the way it deals with

the HTML itself (whether it considers the HTML as

HTML 4.01 or HTML 5, for example).

URL-encoding functions encode all non-

alphanumeric characters to make them harmless

when rendered in the browser. As an example, the <

character is converted to %3C, thus being shown on the

screen as %3C and not being mistakenly understood

as the beginning of a tag. There are three functions

in this group: http build query, urlencode, and

rawurlencode. The ﬁrst one receives an array

and returns a URL-encoded query string with all

key-value pairs contained in the array. The other two

functions get a single string as an argument and differ

only in the way they encode spaces. urlencode

substitutes spaces by + while rawurlencode encodes

spaces as %20. All these functions will make their

inputs safe, but they may cause usability problems

because an URL is shown on the screen in it’s

URL-encoded form. For this reason, they should only

be used in some special situations.

Pitfalls. HTML-encoding functions can stop some

variants of XSS when the result is included inside the

content of any HTML tag, except the <script> and

<style>

tags. However, they will allow attacks to go

Note that the execution of Javascript inside this tag is only

possible in older versions of browsers.

through when the result is placed in an unquoted part

of any HTML tag’s deﬁnition. They will also fail if

they are called without the ENT QUOTES ﬂag and their

result is included inside of a string quoted with single

quotes. The most widely recommended way to call

these functions safely is to use solely the ENT QUOTES

ﬂag.

The URL-encoding functions can prevent XSS

in all situations because they encode all non-

alphanumeric characters. This means that an attacker

is unable to write meaningful Javascript if the input

goes through one of these functions. However, the use

of HTML-encoding is usually preferred by developers

in most situations, as the output of URL-encoding is

less appealing when exhibited to the users.

2.2.3 SQL Injection Sanitization

Sanitization. SQLi attacks can be addressed with

functions of the family * escape string. These

functions escape SQL’s metacharacters to make

them safe to be included inside a SQL state-

ment. For the MySQL database, the appropri-

ate functions are mysql real escape string and

mysqli real escape string. Both functions es-

cape the same characters in a similar manner. The

difference lies in the PHP extension they use — the

former uses the MySQL extension

while the latter

resorts to the MySQL Improved extension.

Often, the recommended way to block SQLi is

to employ prepared statements. Prepared statements

consist of two phases: (i) in the preparation phase, the

statement is sent to the database, which then performs

a syntax check and initializes resources for later use;

(ii) in the execution phase, the client binds parameter

values and sends them to the database. Afterwards,

the database executes the statement with the bound

values using the previously initialized resources. This

ensures that user-supplied values are never treated as

SQL commands. For the ﬁrst task, PHP has func-

tion mysqli

prepare while for the second phase

there are functions mysqli stmt bind param and

mysqli stmt execute.

Pitfalls. Functions of the * escape string family

can only prevent SQLi if their output is placed in a

SQL string. This happens because they only sanitize

characters that can inﬂuence a string’s limits, such as

quotes and line breaks. If their result is, for example,

included in a comparison with an integer, the attack

will be able to proceed.

MySQL extension was deprecated in PHP 5.5 and removed

in PHP 7.

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

It is also important to note that prepared state-

ments do not work in all situations. They do not allow

the binding of parameters to table or column identi-

ﬁers or SQL keywords, meaning that, in this situa-

tion, developers should resort to white lists to check

the inputs against a set of valid values (however, the

study in (Anderson and Hills, 2017) suggests that this

situation is uncommon, which means that bugs may

remain). Also, prepared statements can be utilized

unsafely, which is likely to occur given that they are

more complex than simple sanitization functions.

2.2.4 Filters

PHP ﬁlters can be employed as a sanitization method

by calling the filter var function, and by provid-

ing as constant that identiﬁes the ﬁlter to be used.

This sanitization method can operate both as a generic

approach or as a XSS speciﬁc solution, depending

on the selected ﬁlter. Default sanitization ﬁlters

are all named FILTER SANITIZE *, and they range

from number sanitization (like intval) to HTML-

encoding (similar to htmlspecialchars).

3 AUTOMATED CODE

CORRECTION

This section describes our approach in detail, includ-

ing a discussion of the main challenges and the deci-

sions that we took to deal with them.

3.1 Code Correction Challenges

A Static Analysis Tool (SAT) must solve three main

challenges to be able to correct a web application au-

tomatically:

Where to Insert the Correction? As stated in Sec-

tion 2.2, some variants of XSS and SQLi bugs can be

ﬁxed by inserting a properly conﬁgured sanitization

function. However, there are usually various locations

where to place the call, but some of them might end

up breaking the application logic. For example, ap-

plying the correction always on the entry point is in-

appropriate if the application uses that (attacker) input

in multiple sensitive sinks, which suffer from differ-

ent classes of vulnerability (e.g., this would result in

multiple amendments put in for the same entry point).

However, adding the correction closer to the sensitive

sink may also be difﬁcult because there are no guaran-

tees that the code that receives the input will be easy

to analyze by the tool (e.g., a SQL query can be quite

complex and span over multiple lines).

In order to resolve this challenge, we decided that

all corrections should consist solely of adding new

lines of code, instead of modifying existing ones. This

will help to minimize the chances of causing a pro-

gram to become syntactically invalid. In addition, if

possible, the sanitization of a variable is to be located

in a line of code immediately before the sensitive sink

where the variable is used. When a tainted variable

var can not be rectiﬁed in this manner, we will sani-

tize the variable(s) that caused var to become tainted,

in the line(s) of code immediately before that hap-

pened. To do so, we simulate statically the execution

of operations that act on the variable. This allows us

to know the approximate value of a variable when it

reaches a sensitive sink, thus revealing whether the

variable can be entirely amended.

What Correction to Insert? The kind of correction

to build is very closely related to the class of vulnera-

bility and the context in which the input is used. Car-

rying this task thus requires the tool to be capable of

reasoning about where the input data is inserted and

what is it’s expected type. This asks for an under-

standing on how a SQL query is setup or the HTML

is constructed.

To solve this challenge, we select the patch to ap-

ply based ﬁrstly on the class of vulnerability that was

identiﬁed. If it is SQLi, the tool inserts a string es-

caping function accordingly with the sensitive sink.

If it is XSS, the tool adds URL-encoding functions

whenever possible and HTML-encoding functions in

all other cases.

How to Deal with Existing Sanitization? Existing

sanitizations in the code pose another challenge be-

cause they might be insufﬁcient to prevent all attacks.

In such cases an automated tool has to decide between

making some modiﬁcations to the existing sanitiza-

tion or adding it’s own ﬁx to the program.

To tackle this difﬁculty, we decided that our ap-

proach would need to have the capability of reason-

ing about diverse sanitization methods. If the saniti-

zation method in use is safe, the variable is marked as

untainted, meaning that no correction is introduced.

Otherwise, the remedy will be applied following the

ideas presented for the ﬁrst challenge. Note how-

ever that the problem we are tackling is undecidable

in general. Therefore, in some cases, the application

might contain a safe sanitization method that is re-

garded as unsafe by our solution. Here, the repair

principles explained for the ﬁrst challenge should help

us prevent our correction from breaking the applica-

tion’s logic.

Towards Web Application Security by Automated Code Correction

PHP slice

Type of

Vulnerability

Corrected

code

Path

Processor

Sensitive

Sink

Identifier

Correction

Processor

Knowledge

Base

Figure 1: Automated Code Correction Approach Architec-

ture.

3.2 Overview of the Solution

Our approach aims to correct PHP web applications

by inserting new lines of code that sanitize or validate

inputs arriving at the entry points, which are later used

in sensitive sinks in an unsafe manner. It is our inten-

tion to avoid possible syntactic errors or breaking the

application logic, but it is out of scope to patch the

functional behaviour of the application.

The tool starts by receiving as input a slice of

code, containing a data ﬂow beginning at an (or more)

entry point and ending at a sensitive sink, and infor-

mation about the class of vulnerability that the slice

may suffer. The slice is then analysed by a solution

inspired on taint tracking to discover which variables

have to be sanitized or validated, and where rectify

the slice. The outcome of the tool is a safe slice. No-

tice, however, that the analysis may deem a slice as

non-vulnerable, and in this case no changes are made.

Figure 1 provides an overview of the architecture of

the tool. Next, we detail each component.

PHP Slice. It is a PHP ﬁle containing a potentially

vulnerable slice of code (typically produced by a vul-

nerability detection tool). The slice contains the in-

structions of a program corresponding to a data ﬂow

path that takes some input from an entry point and

carries it to a sensitive sink. The slice can include

more instructions than the strictly relevant for the vul-

nerability exploitation as long as it contains a single

control ﬂow path. Also, it can have multiple vulnera-

bilities if they are all of the same class.

Vulnerability Type. It is a ﬁle with information

about the class of vulnerability that the slice may

have. Currently, only XSS and SQLi are supported.

Our solution requires this as input because it allows

the taint analysis to be more efﬁcient and narrows

down the sanitization functions that should be con-

sidered.

Knowledge Base. Contains the names of all PHP

entry points, sensitive sinks and sanitization methods

to be considered by our approach for each class of

vulnerability. It is used by the Path Processor to get

the entry points and sanitization methods, and by the

Sensitive Sink Identiﬁer to collect the sensitive sinks.

Sensitive Sink Identiﬁer. Discovers the sensitive

sinks in the PHP slice for all classes of vulnerability

supported by our approach. Its output is used by the

Path Processor and the Correction Processor to check

whether a given slice instruction is a sensitive sink.

Path Processor. Performs the taint analysis and

simulates the execution of operations with the vari-

able. It tracks the slice’s input as it is processed and

passed along the instructions, from the entry points

to the sensitive sinks, and maintains the taint status

of the program’s variables. To perform these tasks, it

consumes information from the Knowledge Base and

the Sensitive Sink Identiﬁer.

Correction Processor. Determines which vari-

able(s) need to be sanitized, what corrections they re-

quire and the line(s) of code where those ﬁxes should

be applied. This is done using the information pro-

duced by the Sensitive Sink Identiﬁer and Path Pro-

cessor. The component is also responsible for gener-

ating the actual instructions to be inserted in the out-

put ﬁle, including the appropriate parameters.

Corrected Code. Consists of a PHP ﬁle containing

the patched version of the slice of code provided as

input. No ﬁle is returned if no repair is necessary, as

the original slice was not changed.

Algorithm 1: Approach Algorithm.

Input: PHP slice; Type of vulnerability

Output: Corrected PHP slice

1 Function Main(slice, vulnerability):

2 ast ← GenerateAST (slice);

3 state ← ProcessPath (ast, vulnerability);

4 corrections ← ProcessCorrections (ast, state,

vulnerability);

5 for cor in corrections do

6 InsertLine (slice, cor.code, cor.line);

7 End Function

Algorithm 1 presents the high level steps of our ap-

proach. It starts by generating an Abstract Syntax

Tree (AST) of the PHP slice. Then, it calls the Path

Processor to perform the taint analysis and simulate

the variable operations. This is done to conﬁrm the

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

vulnerabilities in the code and to compute the state

of the program’s variables. Next, it calls the Correc-

tion Processor to analyze the sensitive sinks, deter-

mine the required corrections and where they should

be applied. Lastly, it inserts all corrections in the slice

to generate the output ﬁle.

3.3 Variable Operation Simulation

Our approach simulates statically the operations in-

volving PHP variables. This is done while the taint

analysis is being performed and consists of simulating

the execution instructions, like string concatenations

and arithmetic operations with numbers. When an in-

put value is involved in one of these operations, a spe-

cial marker is put in it’s place, thus indicating that part

of the result might be inﬂuence by an attacker. Such

approach allows for example to keep track where a

user input might be inside of a string. This is useful

to ascertain if a string might contain HTML tags, in

the case of XSS, or to determine if the input is being

included in a query, in the case of SQLi. However,

it is important to note that this simulation might not

always obtain the exact value of a variable, such as

with function calls and arrays. In any case, the result

is still useful for the majority of situations, as an ap-

proximate value for a variable is normally sufﬁcient

to make the right selection of the remedy.

1 $i n = $ _GE T [ "a " ];

2 $ ht ml = " I npu t us er da ta -" . $ i n ;

3 $i = 1 0;

4 $j = $i + 1 ;

5 e cho $ ht ml ;

Listing 2: PHP program vulnerable to XSS.

Listing 2 shows an example of a simple program with

operations involving strings and integers. The simula-

tion of variable operations assigns the ::input spe-

cial marker to $in in line 1, to state that it contains

some external value. Next, in line 2, it concatenates

the string "Input user data -" with the value of

variable $in to form the simulated value of $html. In

line 3, the integer 10 is assigned to $i, and then, in

line 4, the value of $i is summed with the integer 1

to obtain the simulated value of $j. Lastly, in line 5,

the value of $html is used in the sensitive sink echo.

Note that the simulation takes place statically, without

ever executing the code. The result of the simulation

is a list of < key : value > pairs, in which the keys

are the names of the variables and the values are their

respective simulated values. An example of such list

is shown in Listing 3, taking the code of Listing 2. In

this list, the string ::input corresponds to the spe-

cial marker inserted in the place where the input was

added.

1 $i n : ’ :: i npu t ’

2 $ ht ml : ’ I npu t us er da ta -:: in put ’

3 $i : 10

4 $j : 11

Listing 3: Result of simulating the variable operations for

the program in Listing 2.

3.4 Code Correction

The Correction Processor uses the results from the

simulations and taint tracking, plus the line num-

bers of relevant sensitive sinks for the speciﬁc class

of vulnerability, to prescribe a correction and where

it should be applied. Taking as example the pro-

gram in Listing 2 and the simulation of Listing 3,

the Correction Processor is activated when the Path

Processor identiﬁes that the tainted variable $html

reaches the echo function. It observes that the vari-

able contains the special marker ::input and back-

tracks the variable until its last assignment. Next,

it uses the data provided by taint analysis to get the

name of the variable that carries the special marker.

In addition, based on the sensitive sink, it decides on

the most appropriate sanitization function that should

be added. This way, the Correction Processor gen-

erates the instruction $in = htmlentities($in,

ENT QUOTES); and places it right before the line

where the assignment to $html was done, i.e., before

line 2 on Listing 2.

4 EXPERIMENTAL EVALUATION

The approach was implemented in a tool that we

call PHPCORRECTOR

. The tool was developed in

Python and uses as parser a modiﬁed version of the

PHPly

, which supports both PHP 5 and PHP 7. The

taint analysis, simulations, and corrections were im-

plemented from scratch.

PHPCORRECTOR is evaluated by correcting

SQLi and XSS vulnerabilities in two sets of web ap-

plications. The ﬁrst set is based on the programs of

the NIST benchmark SARD - Software Assurance

Reference Dataset

(Section 4.1), and the other test

set utilizes real vulnerable applications that were se-

lected from Exploit-DB

(Section 4.2). The research

questions that are answered by the experiments are:

PHPCorrector is available at: https://phpcorrector.

sourceforge.io

https://github.com/viraptor/phply

https://samate.nist.gov/SRD/

https://www.exploit-db.com/

Towards Web Application Security by Automated Code Correction

(1) Is PHPCORRECTOR able to validate the vulner-

abilities in SARD and real web applications? (2) Is

PHPCORRECTOR able to ﬁx XSS / SQLi vulnerabil-

ities? (3) Are the corrections done appropriately?

4.1 SARD Test Cases

4.1.1 Dataset Characterization

We gathered a total of 1864 test cases from SARD,

namely 1764 XSS and 100 SQLi. All of these test

cases contain a single data ﬂow path, meaning that

they ﬁt our deﬁnition of a slice of code. They have

different types of entry points (e.g., $ GET, $ POST),

vary from no sanitization, type casts or distinct forms

of sanitization, and hold a single kind of sensitive

sink, either mysql query (for SQLi) or echo (for

XSS).

While analyzing slices manually, we discovered

that some of SARD’s test cases are mislabelled. There

are safe (not-vulnerable) test cases that are considered

as unsafe (vulnerable) and vice-versa. For this reason,

we ran a more thorough analysis to determine the ac-

tual label that the test cases should have. Our dataset

contains 1494 test cases that kept their original SARD

labels and 370 test cases whose labels had to be ad-

justed. Summarizing, the dataset is composed of 420

unsafe XSS, 1344 safe XSS, 13 unsafe SQLi, and 87

safe SQLi.

4.1.2 XSS and SQLi Evaluation

PHPCORRECTOR was able to process all test cases.

It is important to note that each unsafe test case con-

tains a single vulnerability that requires one correc-

tion. This means that the number of vulnerabilities

detected by our tool is equal to the number of patches

it applied. For XSS, the tool always chose one of

two sanitizations: i) a call to the htmlentities func-

tion with the ENT QUOTES ﬂag, or ii) a call to the

rawurlencode function. For SQLi, the tool also

always applied the same correction: a call to the

mysql real escape string function.

Table 1: Summary of Results for XSS.

Observed XSS

Total

Vul N-Vul

Tool XSS

Vul 308 172 480

N-Vul

112 1172 1284

Total 420 1344 1764

A summary of the results is presented in Tables 1 and

2, respectively for XSS and SQLi. Out of the 1764

XSS test cases, 1480 were correctly identiﬁed by

the tool as being vulnerable (308) and not-vulnerable

(1172). The remaining 284 test cases, there were

cases where unnecessarily amendments were made

(172 false positives, FP) and where no ﬁx was done

because the slice was deemed secure (112 false neg-

atives, FN). For SQLi, out of the 100 test cases, the

tool only undetected 3 vulnerabilities and generated

13 FP, while the remaining 74 cases were correctly

processed. We investigated the key reasons that could

explain the FN and FP. The main conclusions are dis-

cussed next and presented in Tables 3 and 4. Although

we think our results are very promising, we intend

in the future propose complementary solutions to ad-

dress the mislabeling causes.

XSS FN and FP. XSS FN were always observed in

test cases that resort to improper sanitization methods

while encoding HTML’s special characters, which

were regarded as safe by our tool. Their detailed

causes are described in lines 2–6 of Table 3 (identiﬁed

as XSS-FNRex) and the number instances is showed

in column 3. We believe that FNs related with XSS-

FNRe2 and XSS-FNRe3 could be avoided if the tool’s

taint analysis was able to track the type of sanitization

function that was being applied to a variable. This

would allow the tool to reason that, for example, a

variable is unsafe to be include in a <script> tag if

it was sanitized by a HTML-encoding function. As

for the remaining XSS-FNRes, averting them would

require a detailed analysis of the context in which a

tainted variable is added to the output. The XSS FP

appeared in test cases that employ unsafe sanitization

methods but that fortunately are used in a secure con-

text, and in test cases that utilize a sanitization method

involving a regular expression. Lines 7–8 elaborate

on these reasons (identiﬁed by XSS-FPRex).

SQLi FN and FP. Regarding the SQLi FN, all 3

cases are explained by the same reason – sanitization

of numeric data (line 2 of Table 4). The test cases

had an unsafe usage of this operation, as explained in

Section 2.2. Avoiding these FN would require knowl-

edge about the data types of the database tables and

a more detailed analysis of the query’s structure. We

believe that the FP associated to reasons SQLi-FPRe1

and SQLi-FPRe2 can not be avoided because these

two methods of sanitization should not be considered

Table 2: Summary of Results for SQLi.

Observed SQLi

Total

Vul N-Vul

Tool SQLi

Vul 10 13 23

N-Vul

3 74 77

Total 13 87 100

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

Table 3: FN and FP Explanations and Numbers for XSS.

Reason

Test

Total

Cases

XSS-FNRe1

Inclusion of input inside unquoted attributes: These false negatives occurred for

test cases that include the input inside of an unquoted HTML attribute. This makes

the test cases vulnerable because it is possible to write nonexistent Javascript event

handlers without using HTML’s special characters.

XSS-FNRe2

Inclusion of input inside CSS: These false negatives occurred for test cases that

include their input inside of a <style> tag. This makes them vulnerable because

certain versions of some browsers allow the execution of some Javascript statements

inside of CSS.

XSS-FNRe3

Inclusion of input inside of a script tag: False negatives also occurred for test

cases that include their input inside of a <script> tag. This makes them vulnerable

because it is possible to write meaningful Javascript without using HTML’s special

characters.

32 112

XSS-FNRe4

Inclusion of input in a HTML tag name: These false negatives occurred for test

cases that include their input in the place of a HTML tag name. Similarly to the ﬁrst

reason, an attacker can craft a malicious input that adds nonexistent Javascript event

handlers without using HTML’s special characters.

XSS-FNRe5

Inclusion of input in a HTML attribute name: This reason is very similar to

the previous one, except that the test case’s input is included in the place of a

HTML attribute name.

XSS-FPRe1

Unsafe sanitization used in a context that makes it safe: These false positives

occurred for test cases that sanitize quotes. The inclusion of input inside of a

Javascript string or a quoted CSS property value is safe in these cases because any

quotes present in the input are sanitized by preceding them with backslashes. This

means that an attacker can not execute meaningful code.

172

XSS-FPRe2

Use of a sanitization method involving a regular expression: All the false

positives that occurred for this reason were caused by calls to preg replace with a safe

regular expression. Our tool does not currently handle regular expressions, meaning

that any calls to preg replace are considered to return tainted data, regardless of

the regular expression used.

100

safe for SQLi. As for the remaining FP, stopping them

would require a better analysis of regular expressions

or the simulation of calls to sprintf.

4.1.3 Applied Corrections

We manually analyzed all corrections that were ap-

plied by PHPCORRECTOR to assess how many of

them actually prevent attacks. It is important to note

that none of the repaired programs became syntacti-

cally or semantically invalid. In total there were 503

test cases amended (480 XSS and 23 SQLi). To com-

plete this task, we looked at the location where the

potentially malicious input was included in the pro-

gram’s output to verify the safety of the ﬁx. Correc-

tions were organized in the following three groups: (i)

Safe: all attacks are prevented, making the programs

safe; (ii) Unsafe: some forms of attack remain active,

leaving the programs still vulnerable; (iii) Unneeded:

changes were applied to non-vulnerable test cases in-

dicating that they were unnecessary.

Table 5 shows the number of test cases in each

group. Most of the cases correspond to the Safe class

(237), and so the tool performed well. With regard

to the 185 Unneeded, the repair did not spoil the pro-

gram and therefore it is innocuous. These cases cor-

respond to the FP discussed in the previous section.

The remaining 81 Unsafe cases are part of the 318

test cases (see Tables 1 and 2) that the tool properly

detected as being vulnerable but that the correction is

not sufﬁcient to completely prevent the attacks.

4.2 Real Web Applications

We used six web applications that were vulnerable to

XSS from Exploit-DB to validate our tool with real

programs. Table 6, on the ﬁrst 5 columns, character-

izes the applications that were assessed. Each appli-

cation has a type, a vulnerable version, the number of

PHP ﬁles and the number of PHP lines of code (LoC).

Considering XSS, these applications contain a mix-

ture of sensitive sinks, such as echo, print, die and

exit. This shows that our tool is capable of detect-

ing sensitive sinks other than echo, which is the only

XSS sensitive sink in the test cases of SARD.

Among the six applications, the tool found 38

PHP ﬁles to be vulnerable with a total of 79 vari-

ables needing protection. All the identiﬁed bugs were

automatically corrected, and the resulting repaired

Towards Web Application Security by Automated Code Correction

Table 4: FN and FP Reasons and Numbers for SQLi.

Reason

Test

Total

Cases

SQLi-FPNe1

Use of a sanitization method to sanitize numeric data: These FN were caused

by the use of the mysql real escape string function to sanitize data that is later included

in a comparison with an integer.

3 3

SQLi-FPRe1

Use of a sanitization method that escapes quotes: The FP occurred due to the

use of addslashes (or an equivalent ﬁlter) to sanitize the input before it is included in

the query. This type of sanitization is regarded as unsafe by our tool but it is safe in

these test cases because any quotes present in the input are sanitized by preceding them

with backslashes.

SQLi-FPRe2

Use of a XSS sanitization method: Occured due to the use of a XSS sanitization

method to sanitize the input. This is safe in these test cases. However, it is not

considered safe by our tool because XSS sanitization functions should never be used

to prevent SQLi.

7 13

SQLi-FPRe3

Use of a sanitization method involving a regular expression: These FP occurred

due to a call to preg replace with a safe regular expression. As mentioned before, our

tool considers calls to preg replace to return tainted data.

SQLi-FPRe4

Use of a numeric format speciﬁer: The FP occurred due to the use of a numeric

format speciﬁer in a call to sprintf. This effectively consists of casting the input to a

numeric type, which was described in Section 2.2.1.

Table 5: Number of XSS and SQLi Corrections Applied by

PHPCORRECTOR.

Group XSS SQLi Total

Unneeded 172 13 185

Safe 228 9 237

Unsafe 80 1 81

Total 480 23 503

programs were all syntactically valid (see columns

6 – 8 of the table). There were 72 amendments

using HTML-encoding functions and 7 using URL-

encoding functions. On 77 occasions, the correction

was applied to the tainted variable itself and, on 2

situations, on a variable’s taint causes because the

variable itself contained HTML tags in it’s simulated

value.

As shown in the table, 75 of the 79 patches are

safe, preventing all attacks. Four ﬁxes performed on

Electricks eCommerce reduce the attack surface, par-

tially protecting the application, but leave a few at-

tacks vectors active. Therefore, they were consid-

ered unsafe. To better understand these cases, List-

ing 4 provides an example. The inserted sanitization

is the call to htmlentities in line 2. Notice that

the input is then used in the value attribute in line

3, without being surrounded by any quotes. Thus,

it allows the addition of new HTML attributes, such

as onmouseover. Therefore, an example input for

$ GET[’prod id’] that could still trigger the vulner-

ability is 1 onmouseover=alert(1).

1 < div c la ss = " f orm g ro up " >

2 <? php $ _G ET [ ’ p ro d_ id ’] = ht m le nt it ie s ( $_ GE T [ ’

pr od _i d ’ ], E NT _Q UO TE S ) ; ? >

3 < in pu t t yp e =" hi dd en " cl as s = " form - co nt ro l " id = "

pr od _i d " n ame = " pr od _i d " v alu e = <? php e cho

$_ GET [ ’ pr od _i d ’ ]; ? > >

Listing 4: Correction applied to Electricks eCommerce

(simpliﬁed for readability).

5 RELATED WORK

Static analysis has the objective of analyzing the

source code of an application to ﬁnd vulnerabilities

but without executing it. SATs compare the code to

a set of patterns that indicate a vulnerability. If the

tool’s knowledge base does not contain a pattern for

a given type of vulnerability, the tool will not report

it, leading to a false negative. On the other hand, they

may report false positives, which they are a concern

to developers since they spend time looking for un-

existent problems. Most SATs still require human in-

tervention to verify that the bugs reported are in fact

vulnerabilities, and ﬁx them.

One of the forms of static analysis is taint analy-

sis. It consists in track input variables (entry points),

stating them as tainted, and verify if they are used

as arguments of functions that expect to receive un-

tainted data (sensitive sinks). Taintedness is propa-

gate along the program analysis, but if a tainted vari-

able is passed through a sanitization function, it is

stated as untainted.

Halfond et al. (Halfond et al., 2008) developed a

novel form of taint analysis that they referred to as

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

Table 6: Characterization of the Real Applications and Results of Our Evaluation over Them.

Application

Vuln. PHP PHP

Type of Application

Vuln. Correction

Version Files LoC Files Applied Safe Unsafe

Site@School 2.4.10 567 64 k

Content Management System

for Primary Schools

13 16 16 0

Integria IMS 5.0.83 974 198 k

IT Service Support

Management Tool

5 5 5 0

Electricks

eCommerce

1.0 45 7 k E-Commerce Website 5 27 23 4

userSpice 4.3 474 114 k User Management Application 1 1 1 0

AShop

Shopping Cart

6.0.2 628 113 k Shopping Cart Software 8 24 24 0

I, Librarian 4.6 114 26 k PDF File Manager 6 6 6 0

Total 2,802 522 k – 38 79 75 4

positive tainting for detection of SQLi. Their tech-

nique is based on the marking and tracking of trusted

data, instead of untrusted data.

Dashe et al. (Dahse and Holz, 2014) proposed an

approach that detects second-order vulnerabilities in

web applications, such as stored XSS and second-

order SQLi. The approach identiﬁes taintable data

stores and checks if a symbol originating from such a

data store reaches a sensitive sink without being sani-

tized.

Livshits and Lam (Livshits and Lam, 2005) devel-

oped a static analysis approach that is based on con-

text sensitive pointer alias analysis and introduced ex-

tensions to the handling of strings and containers to

improve the precision.

AMNESIA (Halfond and Orso, 2005) is a tool that

protects web applications from SQLi attacks, resort-

ing from static and dynamic analysis. In the static

phase, the tool inspects the application’s code to get a

model of all queries. In the dynamic phase, the tool

monitors the application to detect SQLi attacks based

on the extracted models.

Flynn et al. (Flynn et al., 2018) developed and

tested classiﬁcation models that predict if static anal-

ysis alerts are true or false positives, using a combi-

nation of multiple SATs. Other works study the prob-

lem of combining SATs (Nunes et al., 2017) (Algaith

et al., 2018).

In recent years, there have also been some re-

search efforts focused on applying machine learning

(ML) approaches to the detection of vulnerabilities in

source code (Grieco et al., 2016) (Shar and Tan, 2012)

(Shar et al., 2013) (Yamaguchi et al., 2011) (Medeiros

et al., 2016).

There are a few SATs that employ code correc-

tion. WebSSARI (Huang et al., 2004) is a tool that

statically ﬁnds XSS and SQLi vulnerabilities and then

remove them by inserting guards to secure it. The

authors, however, do not explain how the guards are

inserted or what they consist of. Medeiros et al.

(Medeiros et al., 2014) developed WAP, a SAT for

PHP web applications. The most novel aspects of the

tool are the use of data mining to predict false posi-

tives and automatic code correction. WAP uses taint

analysis to ﬁnd several types of vulnerabilities, and

then to be processed by data mining to classify each

one as a false positive or not. Lastly, the vulnerabili-

ties that were not classiﬁed as false positives are cor-

rected automatically.

6 CONCLUSION

In this work, we proposed an approach for automated

code correction of PHP web application, visioning re-

moving XSS and SQLi vulnerabilities from their code

and improving their security. For that, ﬁrstly, we

analyzed a multitude of sanitization methods avail-

able in PHP for both of these vulnerabilities and the

situations when they should be applied and they do

not work as expected. Also, we veriﬁed that the ex-

istent SATs do not apply code correction, and the

very few ones that apply they often produce new pro-

grams that are syntactically invalid and can not be

executed. We proposed an approach based on taint

analysis to ﬁnd and correct vulnerabilities in simpli-

ﬁed PHP programs (i.e., slices of code) by adding

new lines of code containing secure corrections, tak-

ing into account the defects of sanitization functions.

We implemented the approach in the PHPCORREC-

TOR static analysis tool, written in Python. The devel-

oped tool was evaluated using both test cases retrieved

from SARD and real web applications obtained from

Exploit-DB. The results showed that all corrected pro-

grams were syntactically valid and preserved their

original behavior for both types of vulnerabilities.

Towards Web Application Security by Automated Code Correction

ACKNOWLEDGMENTS

This work was partially supported by the na-

tional funds through FCT with reference to SEAL

project (PTDC/CCI-INF/29058/2017), and LASIGE

Research Unit (UIDB/50021/2020).

REFERENCES

Acar, Y., Backes, M., Fahl, S., Kim, D., Mazurek, M. L.,

and Stransky, C. (2016). You Get Where You’re Look-

ing for: The Impact of Information Sources on Code

Security. In Proceedings of the IEEE Symposium on

Security and Privacy.

Algaith, A., Nunes, P., Fonseca, J., Gashi, I., and Viera, M.

(2018). Finding SQL Injection and Cross Site Script-

ing Vulnerabilities with Diverse Static Analysis Tools.

In Proceedings of the European Dependable Comput-

ing Conference.

Anderson, D. and Hills, M. (2017). Query Construction Pat-

terns in PHP. In Proceedings of the International Con-

ference on Software Analysis, Evolution and Reengi-

neering.

Dahse, J. and Holz, T. (2014). Static Detection of Second-

Order Vulnerabilities in Web Applications. In Pro-

ceedings of the USENIX Security Symposium.

Fischer, F., B

ottinger, K., Xiao, H., Stransky, C., Acar,

Y., Backes, M., and Fahl, S. (2017). Stack Overﬂow

Considered Harmful? The Impact of Copy Paste on

Android Application Security. In Proceedings of the

IEEE Symposium on Security and Privacy.

Flynn, L., Snavely, W., Svoboda, D., VanHoudnos, N., Qin,

R., Burns, J., Zubrow, D., Stoddard, R., and Marce-

Santurio, G. (2018). Prioritizing Alerts from Multi-

ple Static Analysis Tools, Using Classiﬁcation Mod-

els. In Proceedings of the International Workshop on

Software Qualities and Their Dependencies.

Grieco, G., Grinblat, G. L., Uzal, L., Rawat, S., Feist, J., and

Mounier, L. (2016). Toward Large-Scale Vulnerabil-

ity Discovery Using Machine Learning. In Proceed-

ings of the ACM Conference on Data and Application

Security and Privacy.

Halfond, W. G. J. and Orso, A. (2005). AMNESIA: Anal-

ysis and Monitoring for NEutralizing SQL-injection

Attacks. In Proceedings of the IEEE/ACM Interna-

tional Conference on Automated Software Engineer-

ing.

Halfond, W. G. J., Orso, A., and Manolios, P. (2008).

WASP: Protecting Web Applications Using Positive

Tainting and Syntax-Aware Evaluation. IEEE Trans-

actions on Software Engineering.

Huang, J., Li, Y., Zhang, J., and Dai, R. (2019). UChecker:

Automatically Detecting PHP-Based Unrestricted File

Upload Vulnerabilities. In Proceedings of the IEEE/I-

FIP International Conference on Dependable Systems

and Networks.

Huang, Y.-W., Yu, F., Hang, C., Tsai, C.-H., Lee, D.-T.,

and Kuo, S.-Y. (2004). Securing Web Application

Code by Static Analysis and Runtime Protection. In

Proceedings of the International Conference on World

Wide Web.

Livshits, V. B. and Lam, M. S. (2005). Finding Security

Vulnerabilities in Java Applications with Static Anal-

ysis. In Proceedings of the USENIX Security Sympo-

sium.

Medeiros, I., Neves, N. F., and Correia, M. (2014). Au-

tomatic Detection and Correction of Web Applica-

tion Vulnerabilities using Data Mining to Predict False

Positives. In Proceedings of the International World

Wide Web Conference.

Medeiros, I., Neves, N. F., and Correia, M. (2016).

DEKANT: a static analysis tool that learns to detect

web application vulnerabilities. In Proceedings of

the 25th International Symposium on Software Testing

and Analysis.

Nunes, P., Medeiros, I., Fonseca, J., Neves, N. F., Correia,

M., and Vieira, M. (2017). On Combining Diverse

Static Analysis Tools for Web Security: An Empirical

Study. In Proceedings of the European Dependable

Computing Conference.

Schwartz, E. J., Avgerinos, T., and Brumley, D. (2010).

All You Ever Wanted to Know about Dynamic Taint

Analysis and Forward Symbolic Execution (but Might

Have Been Afraid to Ask). In Proceedings of the IEEE

Symposium on Security and Privacy.

Shar, L. K. and Tan, H. B. K. (2012). Mining Input Saniti-

zation Patterns for Predicting SQL Injection and Cross

Site Scripting Vulnerabilities. In Proceedings of the

International Conference on Software Engineering.

Shar, L. K., Tan, H. B. K., and Briand, L. C. (2013). Mining

SQL Injection and Cross Site Scripting Vulnerabilities

using Hybrid Program Analysis. In Proceedings of the

International Conference on Software Engineering.

Shirey, R. (2007). Internet Security Glossary. RFC 4949,

IETF.

Steffens, M., Rossow, C., Johns, M., and Stock, B. (2019).

Don’t trust the locals: Investigating the prevalence of

persistent client-side cross-site scripting in the wild.

In Proceedings of the Network and Distributed System

Security Symposium.

van der Stock, A., Glas, B., Smithline, N., and Gigler, T.

(2017). Owasp Top 10 2017 The Ten Most Critical

Web Application Security Risks. Technical report,

OWASP.

WhiteHat Security (2019). Technical report, WhiteHat Se-

curity.

Yamaguchi, F., Lindner, F., and Rieck, K. (2011). Vulner-

ability Extrapolation: Assisted Discovery of Vulner-

abilities Using Machine Learning. In Proceedings of

the USENIX Conference on Offensive Technologies.

Zheng, Y., Zhang, X., and Ganesh, V. (2013). Z3-str: A Z3-

based String Solver for Web Application Analysis. In

Proceedings of the Joint Meeting on Foundations of

Software Engineering.

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering
