A/B Testing Adaptations based on Possibilistic Reward Methods for

Checkout Processes: A Numerical Analysis

Miguel Mart

ın, Antonio Jim

enez-Mart

ın

and Alfonso Mateos

Decision Analysis and Statistics Group, Universidad Polit

ecnica de Madrid, Campus de Montegancedo S/N,

Boadilla del Monte, 28660, Madrid, Spain

Keywords:

Multi-Armed Bandit, Possibilistic Reward, A/B Testing, Checkout Process, Numerical Analyses.

Abstract:

A/B Testing can be used in digital contexts to optimize the e-commerce purchasing process so as to reduce

customer effort during online purchasing and assure that the largest possible number of customers place their

order. In this paper we focus on the checkout process. Most of the companies are very interested in agilice

this process in order to reduce the customer abandon rate during the purchase sequence and to increase the

customer satisfaction. In this paper, we use an adaptation of A/B testing based on multi-armed bandit algo-

rithms, which also includes the deﬁnition of alternative stopping criteria. In real contexts, where the family to

which the reward distribution belongs is unknown, the possibilistic reward (PR) methods become a powerful

alternative. In PR methods, the probability distribution of the expected rewards is approximately modeled and

only the minimum and maximum reward bounds have to be known. A comparative numerical analysis based

on the simulation of real checkout process scenarios is used to analyze the performance of the proposed A/B

testing adaptations in non-Bernoulli environments. The conclusion is that the PR3 method can be efﬁciently

used in such environments in combination with the PR3-based stopping criteria.

1 INTRODUCTION

In the current market of digital services an content

(retail, media, news, e-commerce) there is a continue

necessity in offering the best user experience by pro-

viding the customer with the right content that they

most likely to use and by offering and effortless ac-

cess to any task, transaction and process required to

complete a service.

The most used approach for this and other types

of service or user interface optimization solutions is

to continuously make changes to the offered services

or interfaces and use a speciﬁc indicator to measure

which change produces the best expected indicator

value. This type of experimentation is commonly

known as A/B testing.

In recent years, some companies and solutions

(for instance, Google Analytics) have addressed

this experimentation process as a multi-armed ban-

dit (MAB) problem (Audibert and Bubeck, 2010;

Baransi et al., 2014; Chapelle and Li, 2011; Gariv-

ier and Capp

e, 2011; Kaufmann et al., 2012; Mart

ın

https://orcid.org/0000-0002-4947-8430

https://orcid.org/0000-0003-4764-6047

et al., 2018), using algorithms existing in the litera-

ture designed to optimize the conﬂict between explor-

ing all the variations and exploiting the best variation.

This drastically reduces the number of unnecessary

experiments. This is known in the A/B testing market

as dynamic trafﬁc distribution.

The most used MAB algorithm is Thompson sam-

pling (Chapelle and Li, 2011), since it performs well

under delayed rewards conditions typical of A/B test-

ing. However, Thompson sampling can only be used

if the type of distribution associated with the rewards

or the indicator to be optimized is known a priori.

Bernoulli distributions often used to measure the suc-

cess or failure of an action (whether or not the cus-

tomer makes the purchase or views a content). In

other cases, however, the distribution type may be un-

known and depend on factors such as purchase price,

navigation time or number of pages visited before

purchase.

A complementary technique used to optimize the

performance of the A/B Testing is to improve the ex-

periment stopping criterion. To do this, some solu-

tions perform the hypothesis tests using a Bayesian

approach to ascertain the statistical signiﬁcance. As

in Thompson sampling, however, the distribution

278

Martín, M., Jiménez-Martín, A. and Mateos, A.

A/B Testing Adaptations based on Possibilistic Reward Methods for Checkout Processes: A Numerical Analysis.

DOI: 10.5220/0009356902780285

In Proceedings of the 9th International Conference on Operations Research and Enterprise Systems (ICORES 2020), pages 278-285

ISBN: 978-989-758-396-4; ISSN: 2184-4372

family to which the rewards belong has to be known a

priori in order to perform this type of Bayesian anal-

ysis.

This drawback is the main reason why most of

the AB Testing using MAB algorithms and new stop-

ing criteria are limited most of the case to Bernoulli

experiments, however, the numerical analyses carried

out recently in (Mart

ın et al., 2019) and (Mart

ın et al.,

2020) show that the possibilistic reward (PR) meth-

ods (Mart

ın et al., 2018) outperform other MAB al-

gorithms in scenarios with delayed rewards and also

where the associated reward distribution does not

have to be known: Test A/B in digital content web

when the reward is continue and increase if customer

read the content and campaign management in digi-

tal marketing recommendation systems. PR methods

approximate a distribution function for rewards that

can also be used to perform classic A/B testing, al-

beit with a stopping condition based on Bayesian and

non-frequentist hypothesis tests.

One of the most common business cases where is

continue optimizing scenarios where the reward dis-

tribution is unknown are those related with the pur-

chasing process so as to reduce customer effort to

complete the online purchasing process and assure

that the largest possible number of customers place

their order in e-commerce companies

In this paper we extend experiments carried out

(Mart

ın et al., 2020) (using the adaptation A/B test-

ing to account for PR methods, together with the def-

inition of a new stopping criterion also based on PR

methods to be used for both classical A/B testing and

A/B testing based on MAB algorithms) with a com-

mon scenarios of optimize purchasing process in e-

commerce companies.

The paper is structured as follows. Section 2

brieﬂy reviews possibilistic reward (PR) methods.

Section 3 gives a brief description of A/B testing and

improvements aimed at optimizing how tests are car-

ried out (dynamic trafﬁc distribution and stopping cri-

terion) and the use of PR methods in A/B testing. Sec-

tion 4 describes the numerical analysis carried out for

checkout process scenarios and the results. Finally,

some conclusions and future research work are out-

lined in Section 5.

2 POSSIBILISTIC REWARD

METHOD

Possibilistic reward methods (PR1,PR2 and PR3)

(Mart

ın et al., 2017; Mart

ın et al., 2018) have recently

been proposed as an alternative to MAB algorithms in

the literature. A review of the most important alloca-

tion strategies can be found in (Mart

ın et al., 2017).

The basic idea of the PR1 method is as follows:

the uncertainty about the arm expected rewards are

ﬁrst modelled by means of possibilistic reward dis-

tributions derived from a set of inﬁnite nested conﬁ-

dence intervals around the expected value on the ba-

sis of the Chernoff-Hoeffding inequality (Hoeffding,

1963).

Then, the method follows the pignistic probability

transformation from decision theory and the transfer-

able belief model (Smets, 2000). The pignistic prob-

ability transformation establishes that when we have

a plausibility function, such as a possibility function,

and any further decision-making information, we can

convert this function into an probability distribution

following the insufﬁcient reason principle.

Once we have a probability distribution for the re-

ward of each arm, then a simulation experiment is car-

ried out by sampling from each arm according to their

probability distributions to ﬁnd out which one has the

highest expected reward. Finally, the selected arm is

played and a real reward is output.

As mentioned above, the PR1 method starting

point is the Chernoff-Hoeffding inequality (Hoeffd-

ing, 1963). This inequality establishes an upper

bound on the probability that the sum of random vari-

ables deviates from its expected value for [0,1], which

can be used to build an inﬁnite set of nested conﬁ-

dence intervals.

The difference between PR1, PR2 and PR3 lies in

the type of concentration applied and subsequent ap-

proximations. PR1 and PR2 are based on the Hoeffd-

ing concentration, whereas PR3 is based on a combi-

nation of the Chernoff and Bernstein concentrations.

A numerical study based on of ﬁve complex and

representative scenarios was performed in (Mart

ın

et al., 2018) to compare the performance of PR meth-

ods against other MAB methods in the literature. PR2

and PR3 methods perform well in all representative

scenarios under consideration, and are the best alloca-

tion strategies if truncated Poisson or exponential dis-

tributions in [0,10] are considered for the arms. Be-

sides, Thompson sampling (TS), PR2 and PR3 per-

form equally with a Bernoulli distribution for the arm

rewards. PR2 is exactly the same as the generalization

of the TS method proposed in (Agrawal and Goyal,

2012) (see Algorithm 2).

Moreover, the numerical analyses conducted re-

cently in (Mart

ın et al., 2019) show that possibilistic

reward (PR) methods outperform other MAB algo-

rithms in digital marketing content recommendation

systems for campaign management, another scenario

with delayed rewards.

A/B Testing Adaptations based on Possibilistic Reward Methods for Checkout Processes: A Numerical Analysis

279

Finally, PR methods have one big advantage over

other MAB algorithms, including TS: all they need

to know is the interval to which the reward belongs

rather than the total reward distribution. PR methods

approximate a distribution function for rewards that

can also be used to perform a classic A/B test, albeit

with a stopping condition based on Bayesian and non-

frequentist hypothesis tests. In this way, experimenta-

tion can be efﬁciently carried out with these methods

in contexts where the objective is not conﬁned merely

to action success or failure (Bernoulli distribution) but

also to the minimization of the total number of page

views or the duration of a session, or the maximiza-

tion of the total income from web e-commerce.

3 A/B TESTING IN DIGITAL

SERVICES

It is common practice in companies that offer services

and products through online channels (web and mo-

bile apps) to continuously optimize their user inter-

faces with the aim of improving one or more of their

key business indicators, such as customer satisfaction,

online sales, content consumption times, or advertis-

ing conversion rates.

These experiments are known in the industry as

A/B testing, randomized control trials (RCT) where

different variations are tested until there is statistical

signiﬁcance.

Two options are currently used to implement A/B

testing:

• Ad hoc developments, mainly using proprietary

software (primarily large content managers, such

as Google, Facebook, Netﬂix, Amazon...), or li-

braries, such as Facebook Planout, and plug-ins

by e-commerce platforms, such as Magento or

Pentashop.

• Specialized experimentation software, where

there is a wide variety of vendors, notably Google

Optimizer, Optimizely, AB Tasty and VWO.

The most advanced experimentation or A/B testing

solutions have incorporated improvements aimed at

optimizing how the tests are carried out. This opti-

mization consists of achieving statistical signiﬁcance

with the lowest opportunity cost, that is, experiment

with the worst variations as few times as possible,

since they result in worse performance than the best

variation. To do this, two optimization processes ac-

count for dynamic trafﬁc distribution and the stopping

criterion, respectively.

3.1 Dynamic Trafﬁc Allocation

In A/B testing, trafﬁc is originally distributed equally

for each of the variations to provide the same number

of experiments. However, it is more efﬁcient to re-

distribute trafﬁc dynamically, sending more or fewer

experiments to variations perform better or worse,

respectively, provided that statistical signiﬁcance is

achieved.

Trafﬁc can be distributed dynamically using

multi-armed-bandit (MAB) methods. In this con-

text, the decisions have to be taken each time

a user/customer accesses the web page by select-

ing the variation (arm) that will be shown to that

user/customer. Then, a delayed stochastic reward will

be received depending on the scenario under consid-

eration (Bernoulli or other reward distributions). The

aim is then to select a strategy (a sequence of variation

selections) that optimizes the expected reward value,

i.e. minimizing the expected regret or the opportunity

cost.

The three advanced solutions for optimizing the

dynamic trafﬁc distribution using MAB methods for

an objective with a Bernoulli distribution (success or

failure), such as conversion ratios, click ratios, are:

1. A Thompson sampling variation for Bernoulli re-

wards. In this case, the original version is proba-

bility matching, where a weight consisting of the

probability of its expected value being better than

the rest is computed for each variation. The vari-

ation to be executed is then chosen based on a

random sample where the probability of select-

ing each variation corresponds to the previously

computed weight. In this way, the variations that

are more likely to be the best will be chosen more

times.

This is the dynamic trafﬁc distribution technique

based on MAB methods most used by vendors,

since it performs very well, even under delayed

rewards conditions (Mart

ın et al., 2019), where

there is a time delay between a variation and its

feedback, as in commercial A/B testing systems.

2. A variation of e-greedy algorithms. Some vendors

opt for this simpler algorithm, although conver-

gence is linear rather than logarithmic. According

to this approach, the best variations are calculated

periodically or after a series of N iterations. Then

80% of the trafﬁc is uniformly distributed to the

best variations in order to optimize the expected

value and the other 20% is distributed uniformly

to all variations in order to perform exploration

tasks until the next iteration.

The companies adopting this approach include

Adobe, with Adobe Target.

ICORES 2020 - 9th International Conference on Operations Research and Enterprise Systems

280

3. It is quite plausible, although it has not, as far as

we know, been published, that some large com-

panies developing their own ad hoc experimental

software, use Thompson sampling in its most ef-

ﬁcient form in this context, where the algorithm

is dynamically updated at each decision and not

every N decisions.

In experiments where the objective follows a non-

Bernoulli distribution, measuring browsing time,

number of pages visited, total revenue, Thompson

sampling cannot be used since it is not possible to

parameterize the reward distribution. Therefore, the

main companies, such as Adobe and ABTasty, use

other alternatives, mainly a variation on e-greedy al-

gorithms. Other vendors such as Google, with Google

Analytics, and ABTasty, do not provide information

on whether or not and how they perform dynamic

trafﬁc distribution with objectives not following a

Bernoulli distribution.

As cited before, the type of distribution associated

with the rewards or the indicator to be optimized does

not have to be known a priori in the possibilistic re-

ward (PR) methods. Thus, they constitute an alterna-

tive for dynamic trafﬁc distribution for non-Bernoulli

reward distributions.

In (Mart

ın et al., 2020) a variation for dynamic

trafﬁc distribution in A/B testing accounting for PR

methods for non-Bernoulli reward distributions is

proposed.

3.2 Stopping Criterion

The stopping criterion plays a key role in the execu-

tion of A/B testing experiments. It is used to decide

when a variation is considered to be the best.

The de facto method used to deﬁne the stopping

criterion in most approaches is based on a classical

hypothesis test. However, classic stopping criteria are

not very efﬁcient, since they are unable to dynami-

cally stop the test when there is enough evidence to

suggest that one variation is better than the others

(Scott, 2015).

Recently, the most innovative companies are in-

troducing more dynamic stopping criteria to reduce

testing costs, leading to the same statistical signif-

icance in a similar way. These new methods, al-

though perfectly applicable to classical A/B testing,

come hand in hand with the new methods for dy-

namic trafﬁc distribution. The multi-armed bandit

paradigm is the most popular, since the number of

samples that have to be executed for each variation

is determined dynamically rather than using classical

hypothesis tests to identify the number of samples re-

quired to achieve statistical signiﬁcance.

These new criteria are based on different ap-

proaches (Bayesian, inequalities bounds...). In

(Mart

ın et al., 2020) a review of the most important

approaches is provided, including Google Analytics,

which uses a stopping criterion based on a Bayesian

approach (Scott, 2015; Google, ), and Adobe Target

(Adobe, ), in which a stopping method based on con-

ﬁdence intervals computed by the Bernstein inequal-

ity (Bernstein, 1946) is used. Google Analytics and

Adobe Target are the the stopping criteria most used

by the main vendors.

The stopping method based on the value remain-

ing used by Google Analytics (Scott, 2015) is very

efﬁcient in environments with rewards following a

Bernoulli distribution, since it has to know the exact

distribution of the expected rewards in order to carry

out the simulations. The distribution of the expected

rewards is inferred with a Bayesian approach.

This approach, however, has a drawback: the

shape of the reward distribution has to be known or

modeled by a family of parameterizable distributions

on which priors can be applied. In addition, it should

be tractable or at least computationally efﬁcient to up-

date the a posteriori distributions and the expected

value. This is not very often the case in many real

contexts, where the family to which the reward dis-

tribution belongs (normal, Poisson, Bernoulli) is un-

known. Besides, if the distribution is known or can

be modeled, it is very difﬁcult to make an efﬁcient

inference using, for example, conjugate priors.

To overcome this problem, a new approach was

proposed in (Mart

ın et al., 2020), in which the prob-

ability distribution of the expected rewards efﬁciently

is approximately modeled by applying the possibilis-

tic rewards methods (PR2 and PR3) for the reward

in each variation. To do this, only the minimum and

maximum reward bounds have to be known rather

than the distribution of each reward. This information

is commonly available in real contexts.

Once the density function of the expected reward

(Step 3 in PR2 and PR3) is derived, the simulation and

stopping condition techniques used in (Scott, 2015)

are applied. In the Section 5, reporting a numerical

analysis of these methods on checkout process scenar-

ios, these approaches will be denoted as PR2 ValRem

and PR3 ValRem.

Besides, a stopping criterion computed from ap-

proximations to the probability distributions of the ex-

pected reward derived from PR2 and PR3 methods is

also proposed in (Mart

ın et al., 2020) for emulating

conﬁdence level-based stopping criteria, such as em-

pirical Bernstein in Adobe Target.

To do this, function that outputs the percentile

value is needed, which will be used as a conﬁdence

A/B Testing Adaptations based on Possibilistic Reward Methods for Checkout Processes: A Numerical Analysis

281

level, from distributions PR2 or PR3. As PR2 and

PR3 are Beta distributions, we can use the quantile

function, also called ppf (percentile point function),

to compute these dimensions. This function can be

analytically obtained and is available in any statistical

software library.

Once these dimensions have been derived, we

have practically the same stopping criterion as the one

used by Adobe Target.

In the Section 5, these approaches will be denoted

as PR2 bounds and PR3 bounds.

4 NUMERICAL EXPERIMENTS

AND RESULTS

In most e-commerce companies the purchase process,

also called checkout process in business argot, starts

when a customer after searching and evaluating some

service products he/she is interested in, decides to buy

one or several. This process usually start by clicking

the buy button associated to the product in the web-

site, or by clicking the checkout button and go to buy

the products previously added to the cart.

The checkout process in most cases consists of the

following tasks:

• Conﬁrming from the cart the products and quanti-

ties the customer wants to purchase.

• Selecting a pay method (card, PayPal, etc.) and

providing the payment data (credit card number,

expiration date, etc.)

• Logistic information regarding transport duration

and fees is displayed, and the address information

is entered by the customer.

• The customer is sometimes asked to sign-in or

sign-up and/or offered a coupon, some cross-

selling or up-selling products.

• Finally, the customer is requested to conﬁrm all

the entered information to process the purchase,

and the corresponding recipe order is displayed.

The different variations of the process usually consist

of grouping or splitting the different tasks in different

steps, adding and/or removing steps, in order to check

what variations and designs are more efﬁcient.

In this optimization process, reducing the number

of abandons becomes crucial but also the time the cus-

tomer spends in the purchase. Therefore, the objetive

or reward will be a time function, in which the reward

is 0 if the customer abandons the process and, other-

wise the reward is higher the less time is spent in the

purchase.

The checkout process consists on 1 to n steps, cor-

responding to pages necessary to read or enter some

information. In any step, we will simulate an aban-

don rate by means of a Bernoulli distribution. If the

customer abandons the process then we have a reward

0, otherwise the user has spent some time in this step

and go to next step. A gamma distribution is used

to generate the times spent in the different steps and

the total time of customer purchase process will be

the sum of the times spent in the steps throughout the

checkout process.

We have simulated two different scenarios with

only one and with more than one variations.

4.1 Checkout Process Scenario with

Only One Variation

In this scenario the current state compared against

only one variation. The current process consists of

a purchase process with two steps: A step to enter

all the information (pay methods, pay data, name, ad-

dress, etc.) and a second step to review information

and conﬁrm the purchase.

The ﬁrst step has an abandon rate of 10% and the

time spent in this step follows a Gamma distribution

with parameter α = 540 and β = 0.16, what leads to

a mean time of 85 seconds. The abandon rate in the

second step is 1% and the time spent in this step fol-

lows a Gamma distribution with parameter α = 140

and β = 0.16, with a mean time of 21 seconds.

Finally, the maximum timeout to complete the

purchase is 300 seconds.

The challenger checkout process we will have the

next conﬁguration. It consists of three steps: A step to

enter all the payment information (pay methods, pay

data, name), a second one to enter logistic information

and a third step to review information and conﬁrm the

purchase.

The ﬁrst step has an abandon rate of 5% and the

time spent in this step follows a Gamma distribution

with parameter α = 340 and β = 0.16, with a mean

time of 55 seconds. The abandon rate in the sec-

ond step is 5% and the time spent in this step fol-

lows a Gamma distribution with parameter α = 240

and β = 0.16, with a mean time of 39 seconds. Fi-

nally, in the third the gamma parameters are α = 140

and β = 0.16, with a mean time of 21 seconds.

The maximum timeout to complete the purchase

also is 300 seconds.

The reward distributions for the variations are un-

known for the tested algorithms and the aim is to

analyse throughout the simulation their reinforcement

learning capacity on the basis of the accumulated re-

grets together with the number of samples necessary

ICORES 2020 - 9th International Conference on Operations Research and Enterprise Systems

282

for the corresponding stopping criterion.

Table 1 shows the Scenario 1 results for all the

combinations of methods and stopping criteria un-

der consideration. Mean values are provided in all

columns derived from 500 simulations, and the meth-

ods are ordered from lowest to highest mean accumu-

lated regret. Besides, the accumulated regret density

for the best 10 combinations are shown in Fig. 1.

Table 1: Results in Scenario 1 with only one variation.

method stopping crit. accum. regret std. dev. samples

PR3 PR3 ValRem 11.394 7.952 2604.25

PR2 PR3 ValRem 12.366 7.610 2014.75

PR3 PR3 bounds 16.284 9.574 6655.90

A/B test PR3 ValRem 16.398 9.318 1917.25

e-Greedy PR3 ValRem 19.298 3.954 2252.75

PR2 PR3 bounds 20.694 10.031 4387.10

PR3 PR2 ValRem 21.407 11.237 19912.50

PR2 PR2 ValRem 26.623 13.537 6727.75

e-Greedy PR3 bounds 28.746 12.341 3358.80

A/B test PR3 bounds 31.501 13.803 3691.80

PR3 PR2 bounds 33.708 11.698 309003.85

e-Greedy PR2 ValRem 38.334 18.029 4482.25

A/B test PR2 ValRem 43.608 18.840 5107.25

PR2 PR2 bounds 51.540 19.331 30505.50

e-Greedy PR2 bounds 117.740 34.735 13778.80

A/B test PR2 bounds 117.756 33.241 13781.40

Figure 1: Ripple graph of Scenario 1.

First is important to point out that the mean ac-

cumulated regret derived from the classical A/B test-

ing with also the classical stopping criterion is 248.41,

whereas the number of samples needed is 28228, be-

ing both measures clearly outperformed by the com-

binations analysed in the numerical study.

In this scenario, PR3 + PR3 ValRem is the best

combination, followed by PR2 + PR3 ValRem and

PR3 + PR3 bounds in terms of mean accumulated re-

grets. Moreover, the three best-ranked combinations

in terms of mean accumulated regrets also good val-

ues with respect to standard deviations (dispersion of

accumulated regrets). They are only outperformed by

the combination e-Greedy +R3 ValRem, but with a

worst mean accumulated regret. However, PR2 + PR3

ValRem slightly outperforms the other two combina-

tions in terms of maximum accumulated regret (see

Fig. 1).

We can also ﬁnd that for the same stopping cri-

terion, PR3 is always better than the rest of the al-

gorithms: The accumulated mean regret and stan-

dard deviation (except for the combination e-Greedy

+ PR3 ValRem with a lower std. deviations) are lower.

Regarding the stopping criteria, we ﬁnd, looking

at the mean samples column, that the values for com-

binations with the PR3 value remaining (PR3 Val-

Rem) stopping criterion are the lowest, followed by

PR2 ValRem and PR3 bounds (depending on the com-

bination) and PR2 bounds. The two best-ranked com-

binations in terms of mean accumulated regrets are

among the best with respect to the number of mean

required samples.

We can conclude that the combinations PR3 +

PR3 ValRem and PR2 + PR3 ValRem outperforms

the other combinations in this Scenario 1 with good

performances regarding the mean samples.

4.2 Checkout Process Scenario with 7

Variations

In this scenario 7 possible variations are consider to

test the behaviour of algorithms under consideration.

First, we have considered 5 variation types as follows:

Variation types 1, 2 and 3 consist of a purchase

process with two steps: A step to enter all the infor-

mation (pay methods, pay data, name, address, etc.)

and a second step to review information and conﬁrm

the purchase. Variation types 4 and 5 consist of three

steps: A step to enter all the payment information

(pay methods, pay data, name), a second one to enter

logistic information and a third step to review infor-

mation and conﬁrm the purchase.

The times spent in each of the different steps in

the 5 variations under consideration follow a Gamma

distribution with parameter β = 0.16 and the values

for parameter α shown in Table 2, which also includes

the corresponding mean time spent and abandon rate

for each step and variation.

Fig. 2 shows the reward distribution for the ﬁve

variation types under consideration. Note the differ-

ent heights in the vertical bar for the reward 0 cor-

responding to 5 variation types under consideration,

which match up with the corresponding abandon rates

for each variation type in Table 2. We can see that the

A/B Testing Adaptations based on Possibilistic Reward Methods for Checkout Processes: A Numerical Analysis

283

best variation types are the 1 and 4, which also match

up with the mean times included in Table 2 since al-

though the mean accumulated time spent in their steps

are lower than in the other variations, the accumulated

abandon rates are lower (see the vertical lines associ-

ated to the zero reward value in the ﬁgure).

The above reward distributions for the variations

are unknown for the tested algorithms and the aim is

to analyse throughout the simulation their reinforce-

ment learning capacity on the basis of the accumu-

lated regrets together with the number of samples nec-

essary on the basis of the stopping criteria.

Finally, in the ﬁve variations the maximum time-

out to complete the purchase also is 300 seconds.

In the simulation process carried out we consider a

variation of types 1 and 2 and two variations of types

3, 4 and 5 each.

Table 2: Variation parameters (β = 0.16) in Scenario 2.

Variation Step α mean time abandon rate

Variation type 1 step1 540 85 sec. 10%

step2 140 21 sec. 1%

Variation type 2 step1 440 70 sec. 20%

step2 100 15 sec. 2%

Variation type 3 step1 640 110 sec. 0.2%

step2 200 30 sec. 0.02%

Variation type 4 step1 340 55 sec. 5%

step2 240 39 sec. 5%

step3 140 21 sec. 1%

Variation type 5 step1 240 39 sec. 10%

step2 200 30 sec. 10%

step3 100 15 sec. 2%

Figure 2: Reward distribution in Scenario 2.

Table 3 shows the Scenario 2 results for all the

combinations of methods and stopping criteria un-

der consideration. Mean values are provided in all

columns derived from 500 simulations, and the meth-

ods are ordered from lowest to highest mean accumu-

lated regret. Besides, the accumulated regret density

for the combinations are shown in Fig. 3.

Is important to point out again that the mean accu-

mulated regret derived from the classical A/B testing

with also the classical stopping criterion is 2819.334,

whereas the number of samples needed is 211980, be-

ing both measures clearly outperformed by most of

the combinations analysed in the numerical study.

In this scenario, PR3 + PR3 bounds is the best

combination, followed by PR3 + PR3 ValRem and

PR2 + PR3 ValRem in terms of mean accumulated re-

grets. Moreover, the three best-ranked combinations

in terms of mean accumulated regrets also the best

values with respect to standard deviations (dispersion

of accumulated regrets) and in terms of maximum ac-

cumulated regret (see Fig. 3).

Regarding the stopping criteria, ﬁrst we can see

that the mean number of samples for the combina-

tions in this Scenario 2 are much higher than in Sce-

nario 1 since a more variations are considered in Sce-

nario 2. We ﬁnd, looking at the mean samples column

(last column), that the values for combinations with

a PR3-based stopping criterion are the lowest. The

three best-ranked combinations in terms of mean ac-

cumulated regrets are among the best with respect to

the number of mean required samples.

We can conclude that the combinations PR3 +

PR3 ValRem and PR2 + PR3 ValRem outperforms

the other combinations in this Scenario 1 with good

performances regarding the mean samples.

Table 3: Results in scenario 2 with seven variations.

method stopping crit. acc. regret std. dev. samples

PR3 PR3 bounds 227.55 64.05 5.179e+04

PR3 PR3 ValRem 243.51 70.22 5.718e+04

PR2 PR3 ValRem 259.64 78.12 3.714e+04

PR2 PR3 bounds 364.11 124.84 5.830e+04

A/B test PR3 ValRem 599.94 267.34 5.522e+04

e-Greedy PR3 ValRem 609.77 223.52 6.317e+04

PR2 PR2 ValRem 609.92 142.70 1.209e+05

PR2 PR2 bounds 849.74 212.81 2.052e+05

e-Greedy PR3 bounds 853.88 356.47 8.947e+04

PR3 PR2 ValRem 1182.72 341.18 4.978e+06

PR3 PR2 bounds 1183.33 340.75 4.999e+06

A/B test PR3 bounds 1190.37 571.33 1.095e+05

e-Greedy PR2 ValRem 1654.84 528.65 1.760e+05

A/B test PR2 ValRem 2051.88 781.56 1.888e+05

e-Greedy PR2 bounds 3182.26 985.21 3.426e+05

A/B test PR2 bounds 5101.73 1456.92 4.696e+05

5 CONCLUSIONS

In this paper we analyze the use of the A/B Testing to

optimize the e-commerce purchasing process, speciﬁ-

cally the checkout process, aimed at reducing the cus-

tomer abandon rate during the purchase sequence and

to increase the customer satisfaction reducing the time

ICORES 2020 - 9th International Conference on Operations Research and Enterprise Systems

284

Figure 3: Ripple graph of Scenario 2.

required to end it.

A numerical study has been carried out to com-

pare different adaptations of the A/B Testing based

on multi-armed bandit algorithms, also including al-

ternative stopping criteria.

First, we can conclude the the different adapta-

tions of the A/B Testing on the basic of possibility re-

ward (PR) methods together with the alternative stop-

ping criteria outperform the classical A/B Testing in

terms of both the mean accumulated regret and the

number of samples necessary.

The PR3-based adaptation is the best one in the

two scenarios under consideration, together with the

PR3-based stopping criteria (PR3 ValRem and PR3

bounds). PR3-based adaptation outperforms the PR2-

based adaptation because it better takes advantage of

the sample variance to limit the distribution function

of the regret expected value, then becoming much bet-

ter than the PR2-based adaptation the lower is the re-

ward variance.

These conclusions match up with those reached in

(Mart

ın et al., 2020), in which a comparative numer-

ical analysis based on the simulation of real scenar-

ios is used to analyze the performance of the same

A/B Testing adaptations in both Bernoulli and non-

Bernoulli environments.

ACKNOWLEDGEMENTS

The paper was supported by Spanish Ministry of

Economy and Competitiveness project MTM2017-

86875-C3-3R.

REFERENCES

Adobe. Adobe target automatic trafﬁc allocation.

https://docs.adobe.com/content/help/en/target/using/

activities/auto-allocate/automated-trafﬁc-

allocation.html.

Agrawal, S. and Goyal, N. (2012). Analysis of thompson

sampling for the multi-armed bandit problem. In Pro-

ceedings of the 25th Anual Conference on Learning

Theory, pages 39.1– 39.26.

Audibert, J.-Y. and Bubeck, S. (2010). Regret bounds and

minimax policies under partial monitoring. Journal of

Machine Learning Research, 11:2785–2836.

Baransi, A., Maillard, O., and Mannor, S. (2014). Sub-

sampling for multi-armed bandits. In Proceedings

of the European Conference on Machine Learning,

page 13.

Bernstein, S. (1946). Probability Theory. GTTI, Moscow-

Leningrad.

Chapelle, O. and Li, L. (2011). An empirical evaluation of

thompson sampling. Advances in Neural Information

Processing Systems, 17:2249–2257.

Garivier, A. and Capp

e, O. (2011). The kl-ucb algorithm

for bounded stochastic bandits and beyond. arXiv.

Google. Google analytics help.

https://support.google.com/analytics/answer/2846882/.

Hoeffding, W. (1963). Probability inequalities for sums of

bounded random variables. Advances Applied Mathe-

matics, 58:13–30.

Kaufmann, E., Capp

e, O., and Garivier, A. (2012). On

bayesian upper conﬁdence bounds for bandit prob-

lems. In Proceedings of the International Conference

on Artiﬁcial Intelligence and Statistics, pages 592–

600.

Mart

ın, M., Jim

enez-Mart

ın, A., and Mateos, A. (2017).

Possibilistic reward method for the multi-armed ban-

dit problem. In Proccedings of the 6th International

Conference on Operations Research and Enterprise

Systems, pages 75–84.

Mart

ın, M., Jim

enez-Mart

ın, A., and Mateos, A. (2018).

Possibilistic reward methods for the multi-armed ban-

dit problem. Neurocomputing, 310:201–212.

Mart

ın, M., Jim

enez-Mart

ın, A., and Mateos, A. (2019).

A numerical analysis of allocation strategies for the

multi armed bandit problem under delayed rewards

conditions in digital campaign management. Neuro-

computing, 363:99–113.

Mart

ın, M., Jim

enez-Mart

ın, A., and Mateos, A. (2020).

Improving a/b testing on the basis of possibilistic re-

ward methods: a numerical analysis. Journal of Ma-

chine Learning Research, under review.

Scott, S. L. (2015). Multi-armed bandit experiments in the

online service economy. Applied Stochastic Models in

Business and Industry, 31(1):37–45.

Smets, P. (2000). Data fusion in the transferable belief

model. In Proceedings of the 3rd International Con-

ference on Information Fusion, pages 21–33.

A/B Testing Adaptations based on Possibilistic Reward Methods for Checkout Processes: A Numerical Analysis

285
