Performance Evaluation of Container Runtimes

Lennart Espe, Anshul Jindal

, Vladimir Podolskiy

and Michael Gerndt

Chair of Computer Architecture and Parallel Systems, TU Munich, Garching, Germany

Keywords:

Container Runtime, OCI Runtime, Performance Evaluation, Benchmarking for Container Runtimes,

Containers, Resource Management, Cloud Computing.

Abstract:

The co-location of containers on the same host leads to signiﬁcant performance concerns in the multi-tenant

environment such as the cloud. These concerns are raised due to an attempt to maximize host resource utiliza-

tion by increasing the number of containers running on the same host. The selection of a container runtime

becomes critical in the case of strict performance requirements. In the scope of the study, two commonly used

runtimes were evaluated: containerd (industry standard) and CRI-O (reference implementation of the CRI)

on two different Open Container Initiative (OCI) runtimes: runc (default for most container runtimes) and

gVisor (highly secure alternative to runc). Evaluation aspects of container runtimes include the performance

of running containers, the performance of container runtime operations, and scalability. A tool called Touch-

Stone was developed to address these evaluation aspects. The tool uses the CRI standard and is pluggable

into any Kubernetes-compatible container runtime. Performance results demonstrate the better performance

of containerd in terms of CPU usage, memory latency and scalability aspects, whereas ﬁle system operations

(in particular, write operations) are performed more efﬁciently by CRI-O.

1 INTRODUCTION

Cloud computing as an infrastructure model has be-

come an industry standard. Container technology

plays a leading role in this change allowing to efﬁ-

ciently share host resources among multiple tenants.

Hence, the demand for the performance evaluation

of container workloads has risen. The widely-used

container orchestrator Kubernetes supports every con-

tainer runtime that implements the standardized Con-

tainer Runtime Interface (CRI) (Hong, 2019). Al-

though the cluster administrator can choose any CRI

implementation, a guiding evaluation of runtime per-

formance is missing.

Resource management is the most important task

in multi-tenant environments such as the cloud. It

aims at resource efﬁciency in dense deployment mod-

els like FaaS (Functions-as-a-Service, a service that

abstracts away any underlying infrastructure of an

application deployment) and other serverless archi-

tectures. As new deployment models are being in-

troduced to the market, more requirements on spe-

ciﬁc facets of container runtime performance pop up.

For example, Function-as-a-Service infrastructure de-

https://orcid.org/0000-0002-7773-5342

https://orcid.org/0000-0002-2775-3630

mands for low start-up times of the underlying con-

tainer runtime. Past studies have shown that the

performance overhead of wide-spread container run-

times is low and they are more resource-efﬁcient than

traditional virtual machines (Kozhirbayev and Sin-

nott, 2017). Combined with the ability to co-locate

containers, this resource-efﬁciency leads to container

runtimes being the main driver behind energy and

cost reduction in the container-based computing en-

vironments. Still, though virtual machines are more

resource-intensive, they offer a higher degree of secu-

rity and performance isolation (Bui, 2015).

In this study, two commonly used runtimes are

evaluated: containerd and CRI-O on two differ-

ent Open Container Initiative (OCI) runtimes: runc

(default for most container runtimes) and gVisor

(highly secure alternative to runc). The evaluation

tool TouchStone is developed to evaluate various per-

formance aspects of resource management in con-

tainer runtimes in a reliable manner. TouchStone

measures how well the runtime’s performance scales

with the increase in the number of containers, how

resource overuse is coped with as well as general run-

time performance.

Section 2 provides the basic background knowl-

edge for the paper. Section 3 delves into the imple-

Espe, L., Jindal, A., Podolskiy, V. and Gerndt, M.

Performance Evaluation of Container Runtimes.

DOI: 10.5220/0009340402730281

In Proceedings of the 10th International Conference on Cloud Computing and Services Science (CLOSER 2020), pages 273-281

ISBN: 978-989-758-424-4

273

mentation details of the container runtimes studies.

Section 4 discusses related works. Section 5 exam-

ines the architecture and implementation of Touch-

Stone evaluation tool. Section 6 provides evaluation

results. Section 7 summarizes and discusses the re-

sults. Section 8 concludes the work.

2 BACKGROUND

2.1 Evaluated Container Runtimes

A container runtime is a software that runs the con-

tainers and manages the container images on a de-

ployment node. Speciﬁc container runtimes are dis-

cussed in the following subsection. This subsection

explores two container runtimes: containerd and CRI-

2.1.1 Containerd

Containerd is the default runtime used by the Docker

engine (Crosby, 2017). It is often being referred to

as an industry standard because of its wide adoption.

Underneath, this runtime uses runc, the reference im-

plementation of the OCI runtime speciﬁcation. con-

tainerd stores and manages images and snapshots; it

starts and stops containers by delegating execution

tasks to the OCI runtime (The containerd authors, ).

To start a new containerized process, containerd has

to undertake the following actions: 1) create a new

Container from a given OCI image; 2) create a new

Task in the Container context; 3) start the Task (at

this point runc takes over and starts executing the OCI

bundle supplied by containerd).

Containerd provides CRI-compatible gRPC end-

point enabled by default. When using this endpoint,

abstractions speciﬁc to containerd are hidden from the

client so that the user can operate on CRI-level ab-

stractions.

2.1.2 CRI-O

Container Runtime Interface (CRI) is a standard-

ized interface for Kubernetes plugins that execute

and watch over containers. It was created as an at-

tempt to stabilize the communication interface be-

tween kubelet and the host container runtime. It is

based on gRPC, a cross-language library for remote

procedure calls using Protocol Buffers.

CRI-O is a container runtime built to provide

a bridge between OCI runtimes and the high-level

Kubernetes CRI. It is based on an older version of

the Docker architecture that was built around graph

drivers (Walli, ). It is mainly developed by RedHat,

and it serves as a default runtime for OpenShift, a

popular Kubernetes distribution for enterprise (Mc-

Carty, ). The typical life cycle of the interaction with

CRI-O is similar to containerd over the CRI endpoint.

Major differences in internal container handling to

containerd do not exist since runc is the default OCI

runtime when running CRI-O.

2.2 Evaluated OCI Runtimes

The Open Container Initiative is a Linux Founda-

tion project to design open standards for operating-

system-level virtualization, most importantly Linux

containers. The Open Containers Initiative deﬁnes

two standards – the image-spec for OCI images and

the runtime-spec for OCI runtimes

1,2

. The typical

job sequence would be that a container runtime (e.g.

containerd) downloads an OCI image, unpacks it and

prepares an OCI bundle (a container speciﬁcation in-

cluding the root ﬁlesystem) on the local disk. After

that, a OCI runtime like runc is able to create a run-

ning instance from this container speciﬁcation. OCI

images can be created using a number of tools, for

example docker build command. After the successful

build, these images are usually pushed and published

to a public or private container registry. This subsec-

tion explores two container runtimes: runc and gVisor

(runsc).

2.2.1 Runc

Runc is the lowest runtime layer of containerd that

explicitly handles containers. It was used as the refer-

ence implementation when drafting the OCI runtime

speciﬁcation (Open Container Initiative, 2019). Inter-

nally, runc uses libcontainer to interact with OS-level

components.

2.2.2 Gvisor (Runsc)

Typical OCI runtimes like runc limit system access

using different capability models integrated into the

Linux kernel like AppArmor, SELinux and SEC-

COMP. If an adversary has access to a limited set of

system calls and manages to exploit a vulnerability

in the Linux kernel, then he may be able to escape

the sandbox and gain privileged access. This is a ma-

jor risk when running untrusted code like a provider

of FaaS infrastructure does. When running a con-

tainer in a VMM-based runtime like Kata Containers,

a hypervisor will be started and it will virtualize the

github.com/opencontainers/image-spec/

github.com/opencontainers/runtime-spec/

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

274

underlying system hardware the container is running

on (kat, 2019); this approach has a signiﬁcant perfor-

mance overhead.

gVisor’s approach to container isolation is in be-

tween that of a typical container runtime and of a

fully virtualized runtime. The idea of a guest ker-

nel of VMM-based runtimes served as an inspiration

for a user-space kernel Sentry (which uses ptrace

for syscall interception) and for container ﬁle-system

access manager Gofer. Both of them are instanti-

ated once for every OCI container in a pod sandbox.

This approach is a middle ground between the default

control groups / namespaces approach and the VMM

model. To reduce overhead, it does not virtualize

system hardware and leaves scheduling and memory

management to the host kernel. This split of respon-

sibilities negatively impacts performance for applica-

tions loaded with system calls and leads to potential

incompatibilities between some workloads and gVi-

sor due to speciﬁc Linux kernel behaviour or unim-

plemented Linux system calls (LLC, 2019).

gVisor is implemented as an OCI-compatible run-

time that can be easily plugged into well-known con-

tainer tools like containerd, Docker and CRI-O. Us-

ing a containerd plugin it is also possible to switch

between the default runtime and gVisor using annota-

tions (LLC, 2019).

3 RELATED WORK

The literature on container runtime evaluation is

scarce with the most of the related research only par-

tially being devoted to the evaluation of container run-

time overhead.

Avino et al. performed the research in the context

of resource-critical mobile edge computing, and have

discovered that the CPU usage of the Docker pro-

cess is constant regardless of the CPU cycle consump-

tion of the containerized process (Avino et al., 2017).

Casalicchio et al. have benchmarked Docker Engine

for CPU- and I/O-intensive workloads with the re-

sults reporting on the reduction in overhead of Docker

Engine from 10% down to 5% when the amount

of requested CPU cycles by the container is over

80% (Casalicchio and Perciballi, 2017). Kozhirbayev

et al. compared Docker to rivaling Flockport contain-

ers (based on LXC) showing that I/O and system calls

were responsible for most performance overheads for

both container implementations with Docker memory

performance being slightly better than that of Flock-

port (Kozhirbayev and Sinnott, 2017). Morabito et

al. also identify the disk performance as the major

bottleneck both for container-based and hypervisor-

based virtualization although no signiﬁcant overheads

in other performance metrics were detected (Morabito

et al., 2015).

The study by Xavier et al. went further by dis-

covering that the near-native performance overhead

of containers (LXC, Linux-VServer, and Open VZ) is

acceptable for HPC applications (Xavier et al., 2013).

The same argument holds for Docker in data-intensive

HPC applications (Chung et al., 2016). Lee et al.

evaluated performance of containers under the hood

of production serverless computing environments by

AWS, Microsoft, Google and IBM concluding that

Amazon Lambda performs better in terms of CPU,

network bandwidth, and I/O throughput (Lee et al.,

2018). K. Kushwaha’s study on the performance of

VM-based and OS-level container runtimes such as

runc, kata-containers, also containerd and CRI-O con-

cluded that containerd performs better in compari-

son to CRI-O and Docker due to different ﬁle sys-

tem driver interface design though CRI-O has very

low container start-up latency in comparison to con-

tainerd (Kushwaha, 2017).

4 TouchStone

4.1 Overview of the Tool

This section describes the evaluation tool Touch-

Stone(the name refers to small stones that have been

used in the past to determine the quality of gold)

which was implemented to conduct tests for this

study. The tool is published under the MIT license

on GitHub. TouchStone is implemented in Go due

to available set of open-source tools that use CRI are

implemented in Go.

The main motivation for the development of the

tool is to improve container runtime evaluation by

collecting meaningful evaluation data during multi-

ple runs and exporting it. TouchStone allows to eval-

uate CPU, memory and block I/O performance as

well as container operations performance and scala-

bility of the performance under varying load. Touch-

Stone runs evaluations in a testing matrix that tests

each conﬁguration pair consisting of container run-

time (CRI runtime) and OCI runtime once. The

tests are identiﬁed by a hierarchical naming scheme

context.component.facet, for instance, perfor-

mance.cpu.total in a CPU performance bench-

mark. All of the conﬁguration listed above is done

using a YAML ﬁle. After all benchmarks have been

run, an index of the test results is generated and in-

jected together with the results into an an easily read-

able HTML report.

Performance Evaluation of Container Runtimes

275

Index map[string]IndexEntry

pkg/benchmark

pkg/benchmark/suites

pkg/cmd

+ Execute()

pkg/visual

+ Write(le, entries, index)

pkg/cong

+ Parse(le): Cong

Benchmark interface

+ Run(client, handler): Report

+ Name(): string

+ Labels(): []string

Report interface

+ Aggregate(report): Report

+ Scale(scale): Report

pkg/runtime

+ NewClient(address): Client

Client struct

Cong struct

Matrix struct

...

RuntimeServiceClient

ImageServiceClient

+ Matrix(): Matrix

CRIs: []string

OCIs: []string

Items: []Benchmark

Runs: int

+ Index(): Index

+ Run(): []MatrixEntry

MatrixEntry struct

CRI, OCI: string

Results: []MatrixResult

MatrixResult struct

Name: []string

Aggregated: Report

Reports: []Report

IndexEntry struct

Labels: []string

+ All(): []Benchmark

Performance: []Benchmark

Operations: []Benchmark

Limits: []Benchmark

Scalability: []Benchmark

CRI

generates

Figure 1: Touchstone Package Overview.

4.2 Architecture

TouchStone consists of multiple packages as shown

in the Figure 1. Following subsections provide an

overview for each of them.

4.2.1 pkg/cmd

This package implements the command line interface

(CLI). TouchStone provides four commands to the

user – version, benchmark, list and index. The

implementation of the user interface is based on the

Cobra framework used by e.g. Docker and Kuber-

netes. version command returns the version of the

tool and all CRI implementations it is able to talk to.

benchmark command runs the speciﬁed benchmark.

list command lists all benchmarking suites while

the index command generates an index to preview

the results generated by the benchmark command.

4.2.2 pkg/conﬁg

pkg/config implements YAML-parsable conﬁgura-

tion structure. Each conﬁguration deﬁnes an output

ﬁle to write the benchmark results to, a list of ﬁlters

specifying which benchmarks to run, basic bench-

mark parameters like runs per benchmark and bench-

mark scale as well as which container (CRI) and OCI

runtime to use. In case the user wants to include a new

runtime in benchmarks, the runtime has to expose this

endpoint either directly or via symbolic link.

4.2.3 pkg/benchmark

This package provides benchmarking framework and

deﬁnes types Matrix, Benchmark and Report as well

as Index and some helpers. Matrix speciﬁes a list of

targets to benchmark and has a slice of Benchmarks

that are invoked for each combination of CRI runtime

and OCI runtime. For each CRI runtime a new run-

time.Client is instantiated.

After Benchmark ﬁnishes, a report is generated.

All the reports are collected together with the report

aggregate and the benchmark name in a MatrixRe-

sult. When all CRI/OCI combinations benchmarks

are ﬁnished, the array of results is written to the des-

tination ﬁle speciﬁed in the YAML conﬁguration and

the Index of the Matrix is generated. Index stores

benchmark-report combinations and persists across

different conﬁguration runs.

4.2.4 pkg/benchmark/suites

Benchmarks implemented in this package can be

grouped into four categories:

• Limits. Suite attempts to benchmark performance

of containers with capped resources. Behaviour

of gVisor on such benchmark is especially inter-

esting due to the hypervisor being included in the

control group accounting.

• Operations. Suite tests common container run-

time operation performance including latencies

during creation and destruction as well as con-

tainer launch time.

• Performance. Suite collects conventional perfor-

mance metrics of containers running using a spe-

ciﬁc runtime with measurements provided by sys-

bench

• Scalability. Suite quantiﬁes how scalable is the

performance of a given runtime in relation to the

amount container instances.

4.2.5 pkg/runtime

This package contains a wrapper for the default CRI

gRPC client. It includes helpers to simplify creation

of containers and sandboxes as well as pulling im-

ages.

github.com/akopytov/sysbench

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

276

4.2.6 pkg/visual

It uses HTML templating from text/template,

Bootstrap and Chart.js to provide a visualization of

the collected results.

5 EXPERIMENTAL RESULTS

5.1 Test Setting

To run all the benchmarks on the same machine, a

collection of container tools is used:

• containerd (v1.2.0-621-g04e7747e);

• CRI-O (1.15.1-dev);

• runc (1.0.0-rc8+dev);

• runsc (release-20190529.1-194-

gf10862696c85);

• CNI (v0.7.5);

• crictl (1.15.0-2-g4f465cf).

All of these tools were compiled from scratch on

the testing machine to mitigate the incompatibility

risk. They were run on a linux kernel 4.19.0-5-

amd64 under Debian Buster. All benchmarks have

been executed 5 to 20 times depending on the bench-

mark workload. Due to the type of benchmarks ran

and especially their vulnerability to strong outliers,

only the median of the generated dataset is shown in

resulting graphs and tables. All tests have been exe-

cuted in a virtual machine with 2 CPU cores (2,9 GHz

Intel Core i5-6267U CPU) and 8 GiB of RAM. These

conditions are similar to a typical cloud virtual ma-

chine though server CPUs tend to have more cache,

additional instructions and other features.

5.2 General Performance

5.2.1 CPU

The CPU benchmark measures the time needed to

compute all prime numbers up to a certain maximum,

thus it should not use a lot of system calls. Figure 3

shows that containerd has a lower computational over-

head compared to CRI-O, and the same applies to

runc in comparison to runsc.

5.2.2 Memory

When looking at the total time spent in the memory

benchmark, containerd is the clear winner. A subtle

difference between runc and runsc can also be seen

with runc introducing higher performance (see Fig-

ure 2a).

However, when looking at the minimum and aver-

age latency, it can be observed that runsc introduces

an additional overhead of a factor between 1.48x and

1.72x when accessing memory. Additionally, it seems

that containerd performs on average better when ac-

cessing memory as seen in Figure 2a.

The maximum latency benchmark is in stark con-

trast to the average latency as seen in Figure 2c,

because containerd/runc has a latency spike in

comparison to containerd|runsc, crio/runc and

crio/runsc. The benchmark was repeated with a re-

ordered test execution and the same effect has been

observed. Apparently, this effect is rather a contain-

erd/runsc runtime feature than an outlier.

5.2.3 Disk I/O

Sysbench’s fileio read benchmarks reveals large

difference in performance between runc and runsc

as shown in Figure 4a. gVisor introduces massive

delays in workloads loaded with ﬁle operations like

this synthetic test. The observed performance drop is

due to an inefﬁcient implementation of the virtual ﬁle

system provided by Gofer, which has been improved

in a recent gVisor version

. The difference between

containerd and crio when using runc is negligible,

even though containerd is slightly faster in almost

all the cases.

When writing to disk, the differences between

runc and runsc stand out far less pronounced than

in the read benchmarks as shown in Figure 4b. There-

fore, the underlying hardware and operating system

are, up to a certain degree, the cause for smaller vari-

ation in write speed. In contrast to read benchmarks,

CRI-O performs slightly better than containerd in all

cases.

5.3 Container Operations

Figure 5 points at a slightly better performance of

containerd when creating a container (in compari-

son to CRI-O). This head start is diminished by the

higher run latency such that in total containerd per-

forms worse than CRI-O. It is also visible that runsc

operates almost always faster than runc.

5.4 Scalability of Runtime Performance

Scalability benchmarks test the performance of start-

ing, running and destroying an increasing amount of

long-running containers.

github.com/google/gvisor/pull/447

Performance Evaluation of Container Runtimes

277

0 5 10 15

containerd/runc

containerd/runs c

crio/r unc

crio/r unsc

(a) Total Time and Measurements Are

in Seconds.

0 0,05 0,1 0,15 0,2

containerd/runc

containerd/runs c

crio/r unc

crio/r unsc

Avg Min

(b) Minimum Avg. Latency and Mea-

surements Are in Milliseconds.

0 1 2 3 4

containerd/runc

containerd/runs c

crio/r unc

crio/r unsc

ments Are in Milliseconds.

Figure 2: performance.memory Benchmark for Different Aggregations with 10 Runs.

Table 1: Overview of the Evaluation Results.

Metric cd/runc cd/runsc crio/runc crio/runsc

CPUTime(s) 23.86 26.29 25.35 26.82

HardLimit(s) 340.33 - 354.98 403.40

ScalingLimit(s) 28.38 - 28.22 -

MemTime 10.12 10.6 13.23 14.51

MemMinLatency(ms) 0.10 0.14 0.10 0.15

MemAvgLatency(ms) 0.11 0.19 0.13 0.20

MemMaxLatency(ms) 3.55 1.98 1.14 0.95

FileRndRead(s) 0.03 0.29 0.04 0.31

FileSeqRead(s) 0.36 3.32 0.39 3.26

FileRndWrite(s) 6.39 12.74 6.03 12.03

FileSeqRewrite(s) 2.64 6.74 2.43 6.57

FileSeqWrite(s) 2.71 6.80 2.54 6.54

OpCreate(s) 0.50 0.42 0.51 0.48

OpRun(s) 0.18 0.10 0.03 0.05

OpCreateAndRun(s) 0.68 0.53 0.54 0.54

OpDestroy(s) 0.48 0.55 0.53 0.40

Scalability5(s) 3.49 2.96 4.77 7.03

Scalability10(s) 8.35 5.99 9.71 16.81

Scalability50(s) 37.69 43.36 51.66 145.77

0 5 10 15 20 25 30

containerd/runc

containerd/runsc

crio/runc

crio/runsc

Figure 3: performance.cpu.time, 20 Runs, Measurement

in Seconds.

With 5 containers there is not much of a difference

to the section 5.3; containerd/runsc performs best

overall while crio/runsc falls behind.

The observation made in 5 containers test contin-

ues and becomes more pronounced. We can see that

the required time for starting and stopping 10 contain-

ers is in a linear relation to the container count.

The linear trend discontinues with 50 contain-

ers and containerd/runc comes out ahead in this

benchmark. crio/runsc demonstrates signiﬁcant

slowdown on 50 containers, which might be due to

the larger runtime overhead.

5.5 Resource Limits and Quotas

This benchmark focused at testing containers with the

CPU Hard and Scaling limits using the same sysbench

CPU test from subsection 5.2.1, but with capped CPU

resource. Capping conﬁguration was set to cfs -

quota us = 1000 and cfs period us = 10000.

Table 1 showing the CPU Hard Limit shows

that the overhead of runsc hits the performance

much harder in this benchmark compared to perfor-

mance.cpu.time. This behaviour can be explained

by the fact that gVisor adds both Sentry and Gofer

to the control group. Since these components require

CPU time too, and are run in user space instead of ker-

nel space, they count towards the control group CPU

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

278

0 1 2 3 4

containerd/runc

containerd/runs c

crio/runc

crio/runsc

SeqRead

RndRead

(a) Read Throughput.

0 5 10 15

containerd/runc

containerd/runsc

crio/runc

crio/runsc

SeqWrite

SeqRewrite

RndWrite

(b) Write Throughput.

Figure 4: performance.disk Benchmark for Read and Write with 10 Runs and All the Measurements Are in Seconds.

0 0,2 0,4 0,6 0,8

containerd/runc

containerd/runs c

crio/r unc

crio/r unsc

Run Destr oy CreateAndR un Create

Figure 5: operations.container.lifecycle, 20 Runs,

Measurement in Seconds.

account. Due to a runsc bug, the containerd/runsc

setup ignored the control group limits and hence was

excluded from the benchmark.

The scaling benchmark shines light into how

workloads behave that are scaled from half of the allo-

catable CPU time up to full allowance over the course

of 10 seconds. Since gVisor does not support up-

dating resource limits during the execution of a con-

tainer, runsc had to be excluded from these tests. It

can be seen that the performance difference is very

small as shown in Table 1 Scaling Limit, most likely

due to the low logical overhead between CRI runtime

and OCI runtime

6 DISCUSSION

Table 1 shows the summary results of all the bench-

marks run in the scope of the study with the high-

lighted ones being the best for that particular bench-

mark. To summarize, containerd performs better

when running a container without limits due to lower

runtime overhead, although CRI-O is faster when run-

ning a container that has been created beforehand.

The lead of containerd continues in memory perfor-

mance. Disk performance gives a different picture:

although containerd takes an upper hand in read per-

formance, its superiority is broken by CRI-O in ﬁle

read performance.

When comparing runc and runsc alias gVisor, runc

comes ahead as the clear leader. This is not surpris-

ing due to Gofer virtual ﬁle system being the bottle-

neck. It should be noted that runsc may perform on

the same level as runc when running workloads that

do not perform a lot of system calls, e.g. the perfor-

mance.cpu.time benchmark. In every other bench-

mark runsc did worse than runc except the opera-

tions.container.lifecycle. It should be noted

that runsc performs worse than runc even in com-

pute bound workloads when running in a rigourously

limited environment like limits.cpu.time. The

containerd/runc setup performs best for I/O-heavy

workloads like databases and web servers, while

crio/runc is a solid starter pack in almost any case.

The usage of gVisor should be limited to systems

where security is vitally important and has to be

achieved with limited loss in raw computing power.

Running very small containers with strong resource

capping may be signiﬁcantly slower in gVisor com-

pared to runc.

Performance Evaluation of Container Runtimes

279

0 2 4 6 8

containerd/runc

containerd/runsc

crio/r unc

crio/r unsc

(a) 5 Containers.

0 5 10 15 20

containerd/runc

containerd/runsc

crio/r unc

crio/r unsc

(b) 10 Containers.

0 50 100 150 200

containerd/runc

containerd/runsc

crio/r unc

crio/r unsc

Figure 6: scalability.runtime Benchmark, 10 Runs for Different Number of Containers, All the Measurements in Sec-

onds.

7 CONCLUSION

The developed evaluation tool TouchStone has been

applied to wide-spread container and OCI runtimes

such as containerd, CRI-O and runc and gVisor to

determine performance implications of various evalu-

ated aspects such as scaling the number of containers

started in the runtime. The evaluation results high-

lighted crio/runc setup as the best starting option

almost for any use-case, whereas containerd/runc

turned out to excel at I/O-heavy workloads. Runtimes

setups including runsc might provide better security,

but their use must be carefully considered when per-

formance is important. Prospective directions of fu-

ture work include automatic deployment of a Kuber-

netes cluster with the container runtime picked specif-

ically for given types of workloads and the support

for cross-machine evaluations, i.e. running Touch-

stone on multiple machines and aggregating the re-

sults from such distributed testing environment.

ACKNOWLEDGEMENTS

This work was supported by the funding of German

Federal Ministry of Education and Research (BMBF)

in the scope of Software Campus program.

REFERENCES

(2019). Kata containers. https://katacontainers.io. Accessed

on 19.07.2019 14:05.

Avino, G., Malinverno, M., Malandrino, F., Casetti, C., and

Chiasserini, C.-F. (2017). Characterizing docker over-

head in mobile edge computing scenarios. In Proceed-

ings of the Workshop on Hot Topics in Container Net-

working and Networked Systems, pages 30–35. ACM.

Bui, T. (2015). Analysis of docker security. arXiv preprint

arXiv:1501.02967.

Casalicchio, E. and Perciballi, V. (2017). Measuring docker

performance: What a mess!!! In Proceedings of

the 8th ACM/SPEC on International Conference on

Performance Engineering Companion, pages 11–16.

ACM.

Chung, M. T., Quang-Hung, N., Nguyen, M., and Thoai, N.

(2016). Using docker in high performance computing

applications. In 2016 IEEE Sixth International Con-

ference on Communications and Electronics (ICCE),

pages 52–57.

Crosby, M. (2017). What is containerd? https://blog.docker.

com/2017/08/what-is-containerd-runtime/. Accessed

on 17.06.2019 18:57.

Hong, Y.-J. (2019). Introducing container runtime interface

in kubernetes. https://kubernetes.io/blog/2016/12/

container-runtime-interface-cri-in-kubernetes/. Ac-

cessed on 03.07.2019 17:59.

Kozhirbayev, Z. and Sinnott, R. O. (2017). A performance

comparison of container-based technologies for the

cloud. Future Generation Computer Systems, 68:175–

182.

Kushwaha, K. (2017). How container runtimes matter in

kubernetes? https://events.linuxfoundation.org/wp-

content/uploads/2017/11/How-Container-Runtime-

Matters-in-Kubernetes -OSS-Kunal-Kushwaha.pdf.

Accessed on 6.06.2019.

Lee, H., Satyam, K., and Fox, G. (2018). Evaluation of pro-

duction serverless computing environments. In 2018

IEEE 11th International Conference on Cloud Com-

puting (CLOUD), pages 442–450.

LLC, G. (2019). gvisor architecture guide. https:

//gvisor.dev/docs/architecture guide/. Accessed on

10.07.2019 20:07.

McCarty, S. Red hat openshift container platform 4

now defaults to cri-o as underlying container en-

gine. https://www.redhat.com/en/blog/red-hat-

openshift-container-platform-4-now-defaults-cri-

o-underlying-container-engine. Accessed on

22.07.2019 16:14.

Morabito, R., Kj

allman, J., and Komu, M. (2015). Hyper-

visors vs. lightweight virtualization: A performance

comparison. In 2015 IEEE International Conference

on Cloud Engineering, pages 386–393.

Open Container Initiative (2019). Oci runtime speciﬁcation.

https://github.com/opencontainers/runtime-spec/tree/

74b670efb921f9008dcdfc96145133e5b66cca5c/.

Accessed on 30.06.2019 12:54.

The containerd authors. containerd – getting started.

CLOSER 2020 - 10th International Conference on Cloud Computing and Services Science

280

https://containerd.io/docs/getting-started/. Accessed

on 22.07.2019 19:00.

Walli, S. Demystifying the open container initiative

(oci) speciﬁcations. https://blog.docker.com/2017/

07/demystifying-open-container-initiative-oci-

speciﬁcations/. Accessed on 30.06.2019 15:50.

Xavier, M. G., Neves, M. V., Rossi, F. D., Ferreto, T. C.,

Lange, T., and De Rose, C. A. F. (2013). Performance

evaluation of container-based virtualization for high

performance computing environments. In 2013 21st

Euromicro International Conference on Parallel, Dis-

tributed, and Network-Based Processing, pages 233–

240.

Performance Evaluation of Container Runtimes

281
