On a Metasemantic Protocol for Modeling Language Extension

Ed Seidewitz

Model Driven Solutions, 235A E. Church St., Frederick, MD, U.S.A.

Keywords: Modeling Language Extension, Modeling Language Semantics, Metamodeling, SysML.

Abstract: A metaobject protocol is an object-oriented interface that allows a programming language to be efficiently

extended by users of that language from within the language itself. A metasemantic protocol is a

generalization of that idea, providing a mechanism to allow users of a formally defined modeling language to

syntactically and semantically extend that language from within the language. Such an approach is

fundamental to the language architecture being developed for the proposed second version of the Systems

Modeling Language (SysML). SysML v2 is being effectively defined as an extension to a foundational Kernel

Modeling Language (KerML), and then users can define domain-specific languages in the same way as

extensions of SysML. This approach is already being worked out in the ongoing pilot implementation of

SysML v2, but there is still much to do before the vision of a true metasemantic protocol is fully realized.

1 INTRODUCTION

Almost thirty years ago, Gregor Kiczales and his

colleagues proposed the idea of a metaobject protocol

for programming languages (Kiczales, 1991). They

defined metaobject protocols as “interfaces to the

language that give users the ability to incrementally

modify the languages behavior and implementation”.

With this approach, “users are encouraged to

participate in the language design process”, but

without compromising “program portability or

implementation efficiency”.

For better or for worse, few languages in the

ensuing years provided metaobject protocols for their

users. As Kiczales et al. admit in their original work,

developing such protocols is hard, and they did not

claim to have entirely solved the problem. Further,

the implementation they provided was embedded

within the Common LISP Object System (CLOS).

CLOS provides powerful metalinguistic tools for

such an implementation, but it has a LISP syntax that

is daunting to many and a dwindling user community

that has limited the understanding of the proposed

meta-object protocol approach.

https://orcid.org/0000-0002-7647-4769

See http://xtext.org

See https://www.jetbrains.com/mps/

See https://www.ruby-lang.org/

See, for example, https://thoughtbot.com/blog/writing-a-domain-specific-language-in-ruby

All indicated trademarks are of the Object Management Group.

Nevertheless, the need for user-specialized

languages did not go away. Today we see much work

on domain-specific programming languages (DSLs),

sometimes created from scratch using language

workbench technology (such as Xtext

JetBrains/MPS

). However, some level of domain-

specificity can be provided in any programming

language using specialized libraries. And some

general purpose languages (such as Ruby

) are

particularly well-suited to being tailored in this way

to provide so-called “internal DSLs”, somewhat in

the spirit of the original metaobject protocol concept.

The tension between general-purpose and

domain-specific languages also exists in the modeling

world. Well-known general-purpose modeling

languages include the Unified Modeling Language™

(UML

2017), the Systems Modeling Language™

(SysML

2018) and the Business Processing Model

and Notation™ (BPMN, 2014), all standardized by

the Object Management Group (OMG).

On the other

hand, DSL workbenches can also be used to create

very targeted domain-specific modeling languages

(e.g., see Voelter, 2018).

Further, the profile mechanism in UML is

essentially intended as an internal DSL capability.

Seidewitz, E.

On a Metasemantic Protocol for Modeling Language Extension.

DOI: 10.5220/0009181604650472

In Proceedings of the 8th International Conference on Model-Driven Engineering and Software Development (MODELSWARD 2020), pages 465-472

ISBN: 978-989-758-400-8; ISSN: 2184-4348

465

Indeed, SysML is currently defined as a standard

profile of UML, tailoring the more general language

for use within the more specific systems engineering

community. User-defined profiles are also often used

within organizations and teams to succinctly capture

modeling patterns and domain-specific concepts

commonly used within those groups.

Unfortunately, profiles in UML do not actually

provide a full language extension mechanism. In

particular, the lack of a formal semantic definition for

UML means that profiles cannot provide any precise

way to extend the semantics of the language. (While

Foundational UML and succeeding standards based

on it do provide precise execution semantics for a

subset of UML, this subset does not yet include a

precise semantics for profiling.) At best, profiles

provide a formal means for syntactic extension UML.

However, most UML modeling tools provide only

limited support for even syntactic tailoring of UML

using profiles, often with little more support of user

profiles in UML 2 than the basic stereotyping and

tagging capabilities of UML 1.

However, in 2017 OMG issued a request for

proposals (RFP) for version 2 of SysML that no

longer requires the language to be a profile of UML

(SysMLv2, 2017). But the RFP includes

requirements calling for the language to have a formal

semantic basis that could be truly extended by users.

In addition, even though SysML v2 no longer needs

to be based on UML, it would be desirable to continue

to have interoperability between software and

systems modeling in the context of today’s many

software-intensive cyber-physical systems.

In response, the cross-industry team currently

working on a submission to the RFP

has proposed a

language architecture in which the desired SysML v2

is based on a Kernel Modeling Language (KerML)

that acts as a general foundation for building

modeling languages. KerML moves a step beyond the

current OMG Meta Object Facility (MOF)

technology, which formalizes only the definition of

the abstract syntax of a modeling language, by also

providing a formal grounding for the definition of the

semantics of modeling languages built on it. And, as

with the metaobject protocol, the idea is that, just as

SysML v2 is based on KerML, users can, in the same

way, build their own more tailored domain-specific

language extensions, syntactically and semantically,

on SysML v2. However, in contrast to the inherently

object-oriented programming mechanism proposed

by Kitczales et al., this approach can be more

For public incremental pre-submission releases of

SysML v2 from the submission team, go to

http://openmbee.org/sysml-v2-release.

generally termed a metasemantic protocol for

modeling language extension.

This protocol can be summarized by the following

steps:

1. Define a model library that specifies the formal

semantic concepts needed in a language

extension.

2. Define the abstract syntax for the language

extension in terms of patterns of usage of the

model library that can be mapped back to the

abstract syntax of the language being extended.

3. Define a user-friendly surface syntax for the

language extension that maps to the extended

language abstract syntax.

The first two steps of the protocol have been

applied to UML and SysML in (Bock 2011) and

(Bock 2019). This paper gives an outline of how the

protocol is being further developed in the ongoing

work on SysML v2, and, in particular, examples of

the application of the third step. While the full SysML

v2 definition includes a complete abstract syntax as

well as both graphical and textual concrete surface

syntaxes, the presentation in this paper will focus on

the textual surface syntax, due to space limitations.

Section 2 presents an overview of basic structural

modeling in KerML and its model-library-based

approach to language extension. Section 3 describes

how the metasemantic protocol is used to build

SysML v2 on KerML, and Section 4 then discusses

how the same protocol can be used to build domain-

specific language extensions to SysML v2.

2 KERNEL MODELING

LANGUAGE

KerML provides a basic set of modeling capabilities

based on a formally defined semantic core. For the

purposes of this paper, we will discuss only some

simple structure modeling capabilities and only

describe the underlying core semantics informally.

The focus, in subsequent sections, will then be on

how successive layers of user-focused modeling

languages can be built, syntactically and

semantically, on this foundation.

UML and SysML are primarily graphical

languages, and SysML v2 will also define graphical

views of models, as SysML v1 does. However, unlike

UML and SysML v1, KerML and SysML v2 will also

MODELSWARD 2020 - 8th International Conference on Model-Driven Engineering and Software Development

466

both provide standard textual modeling notations. For

the purposes of this paper, and for general discussions

of language extensibility, it is easier to focus on just

this textual notation.

So, to begin, consider a very simple model of a car

that has an engine and four wheels, and which may

have a driver. Using the KerML textual notation, this

model may be represented as follows:

class Car {

feature driver: Person[0..1];

composite feature engine: Engine[1];

composite feature wheels: Wheel[4];

}

As in UML, a class specifies a type whose

instances are objects that have various features. A

feature defines a mapping from instances of the

featuring class to instances of the type of the feature,

with some multiplicity. A composite feature is

considered to be an integral part of the featuring

object, while a non-composite feature is simply

referential.

Next, define an association between an engine

and the wheels driven by that engine:

assoc DriveTrain {

end engine: Engine[0..1];

end wheel: Wheel[*];

}

Again, as in UML, an association is a type whose

instances are links between objects of the types of the

end features of the association. The basic difference

between an end feature and a regular feature is that

the multiplicity of an end is for navigation across the

association. That is, the above association specifies

that one engine can be linked to multiple wheels, but

a wheel can only be linked to (at most) a single

engine. Nevertheless, each instance of the association

will link exactly one engine to exactly one wheel.

Given the

DriveTrain association, we can now

extend our earlier Car model to reflect the fact that (in

this simple model) exactly two of the wheels of a car

are driven by the car's engine:

class Car {

feature driver: Person[0..1];

composite feature engine: Engine[1];

composite feature wheels: Wheel[4];

connector drive: DriveTrain

from engine[1] to wheels[2];

}

A connector is a feature whose instances are links

specifically between values of features of the

containing class of the connector. Thus, the connector

drive specifies that the single engine of the car has

links to two of the wheels of the car. It is fundamental

to the semantics of the connector that the linked

engine and wheels are parts of the same car.

Now, some of the semantic statements made in the

description of the example above are actually

captured more formally in terms of elements of a

Kernel Model Library that is integral to the

specification of KerML. For instance, this model

library includes the following elements (this is a

simplification of the actual library, adequate for our

present purposes):

class Object specializes Anything;

class BinaryLink specializes Object {

end source: Anything[*];

end target: Anything[*];

}

The type Anything is at the root of the KerML

type specialization hierarchy. The class

Object is

then the base type of all classes of things with identity

and properties that may change over time (as distinct

from data values, not considered in detail in this

paper, which are immutable things with value

semantics). The class

BinaryLink is the base type of

all binary associations, whose instances are objects

that link a source thing to a target thing.

The notation previously used for the association

DriveTrain is actually a shorthand for the more

explicit class model shown below:

class DriveTrain specializes BinaryLink

{

end engine: Engine[1]

redefines BinaryLink::source;

end wheels: Wheel[*]

redefines BinaryLink::target;

}

That is, DriveTrain is a class that specializes

BinaryLink, redefining its source and target ends to

have more restrictive types and multiplicities. In this

way, the semantics of associations are reduced to the

semantics of classes with end features (and the only

difference between end features and the fundamental

semantics of regular features is in how multiplicity is

interpreted).

The earlier model of a car, as extended with a

connector, is then itself a shorthand for:

class Car specializes Object {

feature driver: Person;

composite feature engine: Engine;

composite feature wheels: Wheel[4];

On a Metasemantic Protocol for Modeling Language Extension

467

composite feature drive:

DriveTrain[*] {

end engine: Engine[1]

redefines DriveTrain::engine

subsets Car::engine;

end wheel: Wheel[2]

redefines DriveTrain::wheel

subsets Car::wheels;

}

That is, the connector drive is actually just a

composite feature whose type is the association

DriveTrain. But, further, the actual connection

between the

engine and wheels features of Car is

modeled using local redefinitions of the end features

DriveTrain. For example, the redefinition of

wheel specifies that, in the context of a car, the

engine is linked to exactly two wheels and the linked

wheels must be a subset of the overall set of wheels

that are part of the car.

Allowing a feature to have nested features is a

critical capability in KerML that is not found in UML

or most other modeling language (nor even in

ontological languages like OWL). One can think of

nested features as being part of a local specialization

of the base type of the containing feature, but with a

specifically contextual semantics. This contextuality

is what ensures, for example, that the feature

drive

in the class model above fundamentally has the

desired connector semantics in which the engine and

wheels linked by the feature must be part of the same

car.

As we will see, this ability to define features

contextually nested in other features is especially

important for achieving semantic extensibility.

3 SYSTEMS MODELING

LANGUAGE

The current proposal for SysML v2 is to define it as

an extension to KerML. Semantically, this extension

is captured in the Systems Model Library for SysML,

which extends KerML's Kernel Model Library. The

elements of the Systems Model Library capture the

key systems modeling concepts that are important for

the systems engineering user community of SysML.

For example, a central idea in the structural

modeling of systems is that a system can be

decomposed into parts, and that these parts can have

ports, which define specific points through which the

parts can be interconnected. This conception is

captured as follows in the model library (again, this is

a simplification of the actual SysML model library):

class Part specializes Object {

composite feature ports: Port[*];

}

class Port specializes Part {

feature inputs: Anything[*];

feature outputs: Anything[*];

}

Given the concepts of parts and ports, we can then

provide the ability to specify the interfaces between

parts in terms of how their ports may be

interconnected. Unlike the way the term “interface”

is used in software engineering, to a systems

engineer, an interface generally specifies not just the

externally visible face of a single part, but both ends

of an allowed connection between two parts. Thus,

we define an interface as an association that connects

two ports:

class Connection specializes

BinaryLink, Part {

end source: Part[*]

redefines BinaryLink::source;

end target: Part[*]

redefines BinaryLink::target;

}

class Interface specializes Connection

{

end source: Port[*]

redefines Connection::source;

end target: Port[*]

redefines Connection::target;

}

Given just the above systems engineering

concepts, we can now improve our earlier model of a

drive train into a (slightly) better systems engineering

interface model:

class DrivePort specializes Port {

feature torque: Torque

subsets outputs;

}

class DrivenPort specializes Port {

feature torque: Torque

subsets inputs;

}

MODELSWARD 2020 - 8th International Conference on Model-Driven Engineering and Software Development

468

assoc DriveTrain specializes Interface

{

end drive: DrivePort

redefines Interface::source;

end driven: DrivenPort[*]

redefines Interface::target;

}

Unlike the model given in the previous section, the

interface model for DriveTrain is no longer specific

to the

Engine and Wheel types, but can be used to

specify the interface between any two parts that have

DrivePort and DrivenPort connection points.

Note that the

DrivePort class defines a torque

output and that the

DrivenPort class has a

corresponding torque input. This means that the two

port definitions are compatible for specifying the

opposite ends of an interface. In general, two ports are

compatible if, for any input of one of the ports, there

is a corresponding output of the other port.

Next, we can use the above interface definition for

DriveTrain in our Car model (presuming that

Engine and Wheel are also redefined as parts):

class Car specializes Part {

feature driver: Person;

composite feature engine: Engine {

composite feature enginePort:

DrivePort subsets ports;

}

composite feature wheels: Wheel[4];

composite feature driveWheels:

Wheel[2] subsets wheels {

composite feature wheelPort:

DrivenPort subsets ports;

}

connector drive: DriveTrain

from engine::enginePort[1]

to driveWheels::wheelPort[2];

}

Now, rather than the drive connector being directly

between the engine and the wheels, it is a connection

between the corresponding ports on those parts. Note

that we have added the ports locally to the

engine

and

driveWheels features of Car, rather than to the

Engine and Wheel classes themselves, to emphasize

that these are localized connection points to the

engine and wheels in a specific car. Further, this

allows us to more specifically model that only two of

the wheels of a car are drive wheels and that only

these wheels have the ability to be interfaced to the

engine.

The Systems Model Library provides the

additional semantic concepts necessary to use KerML

in a more specialized domain like systems

engineering. However, syntactically, the resulting

system engineering models are rather cumbersome

and inconsistent with the kind of structural modeling

terminology familiar to system engineers. This may

be remedied by providing a specialized surface syntax

for SysML, in just the way that the notation for

associations and connectors in KerML was really just

syntactic sugar for specific patterns of usage of

classes and features.

Thus, using the specialized SysML textual

notation, the interface definition given above for

DriveTrain is written as follows:

port def DrivePort {

out torque: Torque;

}

interface def DriveTrain {

end drive: DrivePort;

end driven: ~DrivePort[*];

}

In this syntax, special keywords like port and

interface are used as markers for corresponding

linkages to the semantic library. Further, the notation

~DrivePort specifies a conjugation of the port

definition

DrivePort. The conjugate of a port

definition is a port definition with similar features, but

with inputs and outputs reversed. In this way, a

conjugated port definition is conveniently always

compatible as the type of the opposite end in an

interface definition to a port typed by the original port

definition.

In SysML terminology, the class of a part is called

a block. Therefore, the model of a

Car is given in

SysML by the following block definition:

block Car {

ref driver: Person;

part engine: Engine {

port enginePort: DrivePort;

}

part wheels: Wheel[4];

part driveWheels: Wheel[2]

subsets wheels {

port wheelPort: ~DrivePort;

}

interface drive: DriveTrain

connect engine::enginePort[1]

to driveWheels::wheelPort[2];

}

This provides a more succinct structural model of a

car, using more familiar systems engineering

terminology. However, the underlying semantics is

still formally specified by mapping this notation back

On a Metasemantic Protocol for Modeling Language Extension

469

to KerML and expanding to the required patterns of

usage of the Systems Model Library.

4 USER DOMAIN-SPECIFIC

LANGUAGES

SysML v1 is defined as a standard profile of UML v2.

However, it also allows the profile capability of UML

to be leveraged so that users can define profiles that

further specialize SysML. Indeed, this capability is

widely used by major SysML-using organizations,

which often define corporate and even project-

specific profiles of SysML.

Unfortunately, as discussed previously, the UML

profile mechanism falls far short of a full domain-

specific language extension capability. While SysML

tools are well-tailored to the modeling and

diagrammatic specializations of the standard SysML

profile, they rarely allow the same level of tailoring

for a user-defined profile. It is thus often frustrating

and cumbersome to use a SysML profile, which does

not allow true syntactic or semantic extensibility.

An important requirement for SysML v2 is to

improve the ability for users to extend the language.

The proposal is to do this by leveraging the same

approach to linguistic extension used to build SysML

v2 on KerML in order to build user domain-specific

languages on SysML. This is quite similar in concept

to the intent of further leveraging the UML profile

mechanism in SysML v1, but using a much more

powerful mechanism for linguistic extensibility than

what is possible with the UML profile mechanism.

As an example of this, consider a simple language

for failure mode and effects analysis (FMEA) that is

actually being developed as an example within the

SysML v2 submission team. Using the same

approach as was used for defining SysML in the

previous section, we first define a model library that

captures the basic concepts of FMEA (once again,

this is a gross simplification of what would be needed

for a real FMEA model library):

block FMEAItem {

part situations: Situation[*];

part causation: Causes[*];

}

block Situation {

ref referent: Part;

}

block Cause specializes Situation {

value occurrence: Real[0..1];

}

block Effect specializes Situation {

value severity: String[0..1];

}

block FailureMode

specializes Cause, Effect {

value detectability: Real[0..1];

}

assoc block Causes {

end cause: Cause[*];

end effect: Effect[*];

}

In this model, an item of an FMEA involves a set of

situations, each of which pertains to some part of the

system under analysis. Situations are divided into

causes and effects, with a failure mode being both an

effect and a possible cause of other effects. Finally,

an FMEA item may also contain a model of the causal

links between the situations it is covering.

For instance, suppose we are analyzing the

possible failure modes of a glucose meter, which

monitors the glucose level of a patient and applies

therapy as necessary by pumping glucose from a

reservoir to the patient:

block GlucoseMeter {

ref patient: Patient;

part battery: Battery;

part pump: Pump;

part reservoir: Reservoir;

}

This analysis includes the following model of the

effect of the possible failure of the battery of the meter

to recharge:

block GlucoseMeterBatteryFMEAItem

specializes FMEAItem {

ref meter: GlucoseMeter;

part 'battery depleted': Cause

subsets situations {

ref redefines referent =

meter::battery;

value redefines occurrence =

0.005;

}

part 'battery cannot be charged':

FailureMode subsets situations {

ref redefines referent =

meter::battery;

value redefines detectability =

0.013;

}

part 'glucose level undetected':

FailureMode subsets situations {

redefines ref referent = meter;

}

MODELSWARD 2020 - 8th International Conference on Model-Driven Engineering and Software Development

470

part 'therapy delayed': Effect

subsets situations {

ref redefines referent =

meter::patient;

value redefines severity =

"High";

}

link :Causes subsets causation

connect 'battery depleted'

to 'battery cannot be charged';

link :Causes subsets causation

connect

'battery cannot be charged'

to 'glucose level undetected';

link :Causes subsets causation

connect

'glucose level undetected'

to 'therapy delayed';

}

As we saw when defining SysML earlier, the

resulting model here may be semantically correct, but

it is syntactically cumbersome and unfriendly. And,

once again, this can be remedied by providing an

appropriate surface syntax:

item GlucoseMeterBatteryFMEAItem {

ref meter: GlucoseMeter;

cause 'battery depleted'

on meter::battery

occurs 0.005;

causes failure

'battery cannot be charged'

on meter::battery

detected 0.013;

causes failure

'glucose level undetected'

on meter;

causes effect 'therapy delayed'

on meter::patient

severity "High";

}

This notation is much clearer to a human reader, but

its semantics are still given formally by mapping it

back to the earlier SysML model, which is, in turn,

formally defined by mapping it back to KerML and

its core semantics.

5 CONCLUSION

Ongoing work on a pilot implementation for KerML

and SysML has already demonstrated the feasibility

of each of the three steps of the metasemantic

protocol. Unfortunately, the current prototype

approach uses different technologies for each of the

steps:

1. Model libraries are written in KerML or SysML

(or, potentially, in any further domain-specific

extension of SysML).

2. Abstract syntax is modeled using current OMG

MOF technology and implemented using the

Eclipse Modeling Framework.

3. Concrete syntax for textual notation is

implemented using the Xtext DSL framework.

For a true metasemantic protocol, however, all of

the above steps need to be achievable within a single

linguistic framework that is accessible to end users.

That is, all the steps need to be achievable using

KerML or SysML. This is already the case for the first

step, and it will not be conceptually difficult to

achieve for the second step, since the modeling

capabilities already available in KerML are sufficient

to cover the metamodeling capabilities of MOF.

However, providing a robust linguistic capability for

the third step is more difficult, especially when one

includes requirements for both textual and graphical

surface notations.

That said, the SysML v2 RFP already has

requirements for the language to include a robust

capability for defining user views and viewpoints of

a model, well beyond the simple capability found in

SysML v1. Our plan is to leverage this required

capability in order to fill out the final part of the

language extension mechanism for SysML v2. The

hope is to realize as much of the full vision of a full

metasemantic protocol by the time final submissions

are due for the SysML v2 RFP in June 2021.

ACKNOWLEDGEMENTS

I would like to thank Andrius Armonas, No Magic

Europe/Dassault Systemes, for allowing me to adapt

his work on the FMEA example language extension

of SysML v2.

REFERENCES

Bock, C., Odell, J., 2011. Ontological Behavior Modeling.

Journal of Object Technology 10 (3): 1–36,

https://doi.org/10.5381/jot.2011.10.1.a3.

Bock, C., Galey, C., 2019 Integrating four-dimensional

ontology and systems requirements modelling. Journal

of Engineering Design 30 (10–12): 477–522,

https://doi.org/10.1080/09544828.2019.1642461.

On a Metasemantic Protocol for Modeling Language Extension

471

BPMN, 2014. Business Process Model and Notation

(BPMN), Version 2.0.2, Object Management Group,

https://www.omg.org/spec/BPMN/2.0.2.

Kiczales, G., des Rivières, J., Bobrow, D. G., 1991. The Art

of the Metaobject Protocol, The MIT Press, Cambridge.

SysML, 2018. OMG Systems Modeling Language (OMG

SysML), Version 1.6, Object Management Group,

https://www.omg.org/spec/SysML/1.6/.

SysML v2, 2017. Systems Modeling Language (SysML) v2

RFP, Object Management Group,

https://www.omg.org/cgi-bin/doc.cgi?ad/2017-12-2.

UML, 2017. OMG Unified Modeling Language (OMG

UML), Version 2.5.1, Object Management Group,

https://www.omg.org/spec/UML/2.5.1.

Voelter, M., 2018. Fusing Modeling and Programming into

Language-Oriented Programming. In Leveraging

Applications of Formal Methods, Verification and

Validation. Modeling. 8th International Symposium,

ISoLA 2018, Limassol, Cyprus, November 5-9, 2018,

Proceedings, Part I, LNCS 11244, Springer Nature,

Switzerland, https://doi.org/10.1007/978-3-030-03418-

4_19.

MODELSWARD 2020 - 8th International Conference on Model-Driven Engineering and Software Development

472
