Ontology-based Automation of Penetration Testing

Ge Chu and Alexei Lisitsa

Department of Computer Science, University of Liverpool, Liverpool, U.K.

Keywords:

Automated Penetration Testing, Information Security, Ontology, Protege, SWRL, BDI Agent.

Abstract:

Ontology is a widely used knowledge representation formalism in artiﬁcial intelligence area in recent years. In

this paper, we propose an ontology-based automated penetration testing approach. We use protege to create the

ontology, which is constructed based on attack taxonomy. SWRL rules are used to create penetration testing

knowledge base and reasoning. We use agent-based(BDI) framework to achieve the process of automated

penetration testing.

1 INTRODUCTION

Penetration testing is a popular method used to eval-

uate system security from the perspective of an at-

tacker. According to PTES (penetration testing ex-

ecution standard) (Nickerson et al., 2014), the pro-

cess of penetration testing includes seven stages:

Pre-Engagement Interaction, Information Gathering,

Threat Modelling, Vulnerability Analysis, Exploita-

tion, Post Exploitation and Reporting. In general, the

success of penetration testing highly relies on the ex-

pertise, technology and experience of the executive

team. With this in mind, it is worth pointing out that

only a minority of people possess knowledge about

penetration testing and the knowledge of penetration

testing is challenging to share and reuse (Shah and

Mehtre, 2015). Due to these reasons, the efﬁciency of

penetration testing has been adversely affected. Sim-

ilarly, establishing and subsequent-managing of the

knowledge base also poses a challenge in the research

on automated penetration testing.

Ontology (Guarino, 1995) is a concept from the

ﬁeld of philosophy, which has been widely used for

knowledge representation in the ﬁeld of artiﬁcial in-

telligence in recent years. It can be used to de-

scribe concepts and their relationships in a certain

domain. With the assistance of domain experts, re-

searchers have currently established ontology in many

areas. For example: SENSUS ontology (Knight et al.,

1995) provided a conceptual structure for machine

translation, UMLS ontology (Bodenreider, 2004) is

a medical language systems , CYC ontology (Lenat

and Guha, 1989) is used to establish human common

sense, and an English dictionary is based on cognitive

linguistics Word-Net ontology (Miller, 1995).

Ontology not only allows the domain knowledge

to be shared and reused through formalisation, but it

also has an excellent conceptual hierarchy and sup-

port for logical reasoning. In this paper, we ﬁrstly

build a penetration testing ontology according to at-

tack taxonomy and secondly we use SWRL (Horrocks

et al., 2004) which is a semantic web rule language

combining OWL and RuleML, to create a knowledge

base and reasoning in our automated penetration test-

ing approach. Finally, we use the BDI agent structure

(Rao et al., 1995) to implement an automated pene-

tration testing attack process.

The remainder of this paper is organised as fol-

lows: Section 2 presents related work regarding on-

tology in the information security ﬁeld. Section 3

outlines our proposed ontology-based on attack tax-

onomy. Section 4 concerns the knowledge base by

SWRL and reasoning. Section 5 describes the process

of automated penetration testing using a BDI agent

structure. Section 6 illustrates a case study of an at-

tack scenario. Finally, we summarise this paper in

section 7.

2 RELATED WORK

There have been some research investigating tax-

onomy and ontology in the security ﬁeld and re-

lated to automated penetration testing. Pinkstion et

al.(Pinkston et al., 2004) produced an ontology spec-

ifying a model of computer attacks, based on over

4,000 classes of computer attacks for intrusion detec-

tion. It is categorized according to the system compo-

Chu, G. and Lisitsa, A.

Ontology-based Automation of Penetration Testing.

DOI: 10.5220/0009171007130720

In Proceedings of the 6th International Conference on Information Systems Security and Privacy (ICISSP 2020), pages 713-720

ISBN: 978-989-758-399-5; ISSN: 2184-4356

713

nent targeted, means of attack, a consequence of the

attack and location of the attacker.

Similarly, Herzog et al.(Herzog et al., 2007) put

forward an ontology of information security which

models assets, threats, vulnerabilities, countermea-

sures and their relations. This ontology covered gen-

eral knowledge and can be used as the vocabulary,

roadmap, and an extensible dictionary of the domain

of information security.

In addition to the ontology built for attack or infor-

mation security concepts, some ontologies have been

based on vulnerabilities. For example, Wang et al.

(Wang and Guo, 2009) built an ontology for vulnera-

bility management (OVM), and it has been populated

with all vulnerabilities in NVD such as CVE, CWE,

CVSS, CAPEC and the relationships among them.

In order to evaluate the security of a system,

(Stepanova et al., 2015) proposed a novel penetration

testing ontology to achieve semi-automatic knowl-

edge extraction from vast amounts of data, which

would yield a holistic view on security analysis. (Gao

et al., 2013) proposed a taxonomy which consists of

ﬁve dimensions including attack impact, attack vec-

tor, attack target, vulnerability and defence. They also

provided an ontology-based model to assess the secu-

rity of the system from an attacker’s of view.

Most other research models the penetration test-

ing as a planning problem expressed in terms of an

attack tree (Ning et al., 2008), attack graph (Kotenko

and Doynikova, 2014) or other forms of planning such

as PDDL (Planning Domain Deﬁnition Language)

(Obes et al., 2013).The major problem with this ap-

proach is that it is computationally expensive, and

this approach faces challenges in decision-making

environments where an agent must plan and act in

real-time (Bordini et al., 2007). Some research at-

tempted to achieve automated penetration testing by

using Markov Decision Processes (MDP) or Partially

Observable Markov Decision Processes (POMDP).

However, scalability has been reported in (Sarraute

et al., 2013) as a primary issue limiting applications

of POMDP. To solve these problems, (Moga et al.,

2015) presented two patterns of massive type attacks

applicable in cyberspace using BDI (belief-desire-

intention) agents. Furthermore, (Chu and Lisitsa,

2018) proposed an automated penetration testing ap-

proach based on BDI agents model.

Our approach is based on these previous research

and builds an ontology from the perspective of pen-

etration testing in practice. Our approach also has

the reasoning ability to achieve automation using BDI

agent-based architecture.

3 ONTOLOGY DESIGN

An ontology is a formal, explicit speciﬁcation of a

shared conceptualisation (Studer et al., 1998). The

main components of ontology are classes, relations,

functions, axioms and instances. We can build ontol-

ogy based on taxonomy in the domain.

3.1 Taxonomy for Penetration Testing

Based on taxonomies of attack in previous work and

ATT&CK knowledge base (Strom et al., 2018), we

establish an attack taxonomy from the perspective of

penetration testing. By penetration testing in practice

(Broad and Bindner, 2013), we summarise the attacks

into the following categories: information gathering

attack, conﬁguration attack, buffer overﬂow attack,

password attack, web attack, sniffer attack, social en-

gineering attack, and denial of service attack.

3.1.1 Information Gathering Attack

Information gathering is the most critical step in pen-

etration testing. Typically, we need to collect infor-

mation about the target including IP address, opened

port, application information, OS information, human

or organisation information, network information, de-

fence mechanism, conﬁguration information, vulner-

ability information, physical environment informa-

tion and so on. The collection of the above informa-

tion determines whether the penetration test is suc-

cessful or not.

3.1.2 Conﬁguration Attack

Such attacks are usually based on an administrator’s

misconﬁguration of the system. For example, the

robot.txt ﬁle usually exposes the structure informa-

tion of the website, or the directory that allows users

to upload ﬁles has executable permission so that at-

tackers can upload a malicious ﬁle and execute it.

3.1.3 Buffer Overﬂow Attack

A buffer overﬂow is a typical software coding mis-

take that an attacker could exploit to gain access to the

target system. When a program, while writing data

to a buffer, overruns the buffer’s boundary and over-

writes adjacent memory locations. It allows attackers

to change the program ﬂow and execute their com-

mands or programs. Buffer overﬂow is a widespread

and very dangerous vulnerability, which widely ap-

pears in various operating systems and application

software. It is a famous attack in penetration testing.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

714

3.1.4 Password Attack

Password attack is an essential part of penetration

testing. Usually, an attacker can gain some speciﬁc

permission from the target system if a password at-

tack is successful. The most commonly used pass-

word attack is based on a dictionary, which consists

of all possible passwords.

3.1.5 Web Attack

WEB attack is an attack against web applications.

The most common attacks include Injection, Cross-

Site Scripting (XSS) and Cross-Site Request Forgery

(CSRF). The Open Web Application Security Project

(OWASP) (Pandya and Patel, 2016) publishes the

TOP 10 vulnerabilities every year to raise awareness

amongst developers and managers, which becomes

the application security standard. However, these vul-

nerabilities tend to be exploited by attackers.

3.1.6 Sniffer Attack

If there is no vulnerability or the target system is well-

protected, a human experienced penetration tester

would typically attempt to perform a sniffer attack.

Firstly, they break into other systems which are un-

der the same sub-network as the original target, and

the tester can monitor and analyse all network ﬂow to

gain sensitive information such as a password.

3.1.7 Social Engineer Attack

Social engineer attacks are against humans, such as

administrators who have weak security awareness.

Social engineering is the term used for a broad range

of malicious activities accomplished through human

interactions. In remote penetration testing, usually

perform Spear-Phishing Attack by email or link, Web-

site forge Attack or Spooﬁng Attack.

3.1.8 Denial of Service Attack

A denial-of-service (DoS) is an attack where the at-

tackers (hackers) attempt to prevent legitimate users

from accessing the service. In a DoS attack, the at-

tacker usually sends excessive data ﬂow to the net-

work or server to exhaust target resources. In pene-

tration testing, a DoS attack is not typical and usu-

ally leads to the reboot of the target system for some

purposes. These kinds of attacks include SYN ﬂood,

TCP/UDP attack, SMTP attack, ICMP attack, and so

on. If the attack source comes from a different device,

we call it a distributed denial-of-service attack(DDoS

attack).

3.2 Our Ontology

According to our proposed taxonomy above, we build

an ontology for penetration testing by Protege (Musen

et al., 2015) which is a widely-used open-source on-

tology editor and a knowledge management system.

Classes describe concepts in a domain. Object prop-

erties represent the relations between instances, data

properties represent a property of the instance, restric-

tions represent axioms, and individuals represent in-

stances of a class. Figure 1 illustrates our ontology

for penetration testing.

In the ontology, we build attackers, targets and at-

tack methods classes as top level concepts. Attackers

class includes a set of attacker instances, such as at-

tacker1.

The targets class includes a set of target instances,

and for the presentation purposes we create target1

and target2. These target instances are described by

data properties such as IP address, port, OS, applica-

tion , conﬁguration , vulnerability and current permis-

sion. Due to the limited space in this paper, we only

present two target instances and indicate their same

subnet relation. Through the ontology, we can easily

understand the network topology of the target.

The attack methods class consists of multiple lev-

els of attack methods, based on our proposed pene-

tration testing taxonomy, such as buffer overﬂow at-

tack or password attack. Under the class of the at-

tack method, the speciﬁc attack actions are deﬁned as

instances which include data properties such as ac-

tion, precondition and postcondition. Similarly, due

to the limited space in this paper, we only present

one instance which indicates to perform a buffer over-

ﬂow attack with CVE number MS08-067. Property

characteristics and descriptions are used to represent

axioms and restrictions in our ontology. For exam-

ple, the object property isSameSubnet is transitive

and symmetric. That is, if target1 and target2 are in

the same subnet, target2 and target3 are in the same

subnet. Then we can know that target1 and target3

are also in the same subnet. This knowledge usually

comes from insights gained during penetration test-

ing.

To describe the relations between instances, we

deﬁne ﬁve object properties below:

• hasPermission: represents the attacker has spe-

ciﬁc current permission in a target.

• isConnected: represents the attacker instance can

be connected to target instance.

• isNotConnected represents the attacker instance

cannot be connected to target instance.

Ontology-based Automation of Penetration Testing

715

Figure 1: Ontology for penetration testing.

• isSameSubnet: represents the target instances

which in the same subnet.

• exploitBy: represents attacker can perform spe-

ciﬁc attack.

All attack methods are pre-deﬁned and extensible in

our ontology; in other words, the ontology will con-

tinue to expand.

4 SWRL AND REASONING

After creating the ontology for penetration testing, we

add SWRL rules to implement the inference func-

tion. SWRL is regarded not only as a combination

of rules and ontology but also as being able to use

relationships and vocabulary in an ontology directly.

SWRL rules include two parts, body part and head

part, which represent precondition and postcondition.

The body and head consist of a set of atoms. Infor-

mally, a rule can be read as meaning that if the body

part is true, then the head part must also be true.

SWRL rules are used to determine the attack ac-

tions when certain preconditions are satisﬁed as well

as obtain new knowledge. Therefore, the SWRL rule

base is a vital part of making decisions in the automa-

tion of penetration testing. We take the buffer over-

ﬂow vulnerability MS08-067 as an example:

Rule1:

attacker(?attacker)

isConnected(?attacker, target1)

vulnerability(target1,”MS08-067”)

→ exploitBy(?attacker,MS08-067)

Rule1 presents the process of an attack on vulnerabil-

ity MS08-067: when the attacker can connect to the

target2, and it has MS08-067 vulnerability, it then per-

forms the actions of an MS08-067 attack. After rea-

soning by Inference Engine in Protege, a new relation

occurs between the attacker instance and the MS08-

067 instance, which is represented by object property

exploitBy. Figure 2 shows how the attacker1 will per-

form the MS08-067 attack.

Figure 2: Example for SWRL rule-based reasoning.

SWRL rules can not only make a decision but are

also able to produce new knowledge. For example,

ontology can discover potential attack paths through a

combination of SWRL rules, property characteristics

and descriptions. The rule2 presents a penetration

testing scenario into the internal network. That is, if

the attacker can connect to target2 and successfully

gains root permission, then target2 becomes an

internal attacker. In this way, we can get the path to

reach its ﬁnal target.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

716

Rule2:

attacker(?attacker)

isConnected(?attacker, target2)

exploitBy(?attacker, target2)

currentPermission(target2,”root”)

→ attacker(target2)

5 AUTOMATION

Based on our ontology and SWRL rules, we make use

of the BDI agent framework to achieve the process

of automated penetration testing. In general, ontol-

ogy is used to store knowledge of targets and attacks,

while the BDI agent is used to perform speciﬁc attack

actions. Owlready2 (Lamy, 2017) is a module for

ontology-oriented programming in Python, which is

used to interact between ontology and the BDI agent

by performing actions such as load, query, create, up-

date classes, instances, properties and perform rea-

soning. In addition, BDIPython is used to implement

the BDI mechanism, which is a Python library used

to support BDI-style Programming (Bremner et al.,

2019). Our approach includes two knowledge bases,

which SWRL rules and BDI plans. The SWRL rules

are used to make decisions about an attack by in-

ference in ontology, while plans are used to perform

multiple steps of attack in the BDI agent. In fact, only

the result of an attack will be updated to the ontology

rather than the information generated by the interme-

diate process of an attack. The advantage of using

an SWRL-based ontology knowledge base is that the

agent can infer new knowledge rather than relying on

pre-deﬁned plans.

5.1 BDI Agent-based Interaction

The BDI agent is one of the classical models of cog-

nitive architecture, which include three essential logic

components: belief, desire and intention. The BDI

agent is deﬁned as a tuple <Ag, B, D, I, P>,where:

• Ag: is an agent name.

• B: is a belief set which represents the informa-

tional state of the agent. Usually, they refer to

environmental information.

• D is a desire set which represents the motivational

state of the agent. They represent objectives or

situations that the agent would like to accomplish

or bring about.

• I: is an intention set which represents the deliber-

ative state of the agent. They show what the agent

has chosen to do.

• P: is a plan set which consists of available actions.

Plans may include other plans that an agent can

perform to achieve one or more of its intentions.

The structure of a plan is shown below:

Trigger Event: context <- body.

The interaction between the BDI agent and the ontol-

ogy can be illustrated by the following pseudocode.

In this example, we ﬁrst call a Nmap port scanner as a

function to get port information from the target. Sec-

ondly, the updateontology function assigns the result

of the port scan into the ontology and performs rea-

soning to obtain new knowledge. Finally, the sshat-

tack function updates the result of ssh attack into the

ontology data property if there is an exploitBy relation

between the instance of the attacker and sshAttack.

Algorithm 1: Interaction between agent and ontology.

1: function PORTSCAN(ip)

2: result ← Nmap(ip)

3: return result

4: end function

5: function UPDATEONTOLOGY(portscan)

6: onto ← ontology.load

7: onto.target1.port ← portscan

8: syncReasoner

9: end function

10: function SSHATTACK(ip, port)

11: if onto.attacker.exploitBy = onto.sshAttack

then

12: result ← sshAttackRule(ip, port)

13: end if

14: onto.target1.ssh ← result

15: end function

5.2 Automation Process

(Chu and Lisitsa, 2018) proposed an approach for the

automation of penetration testing based on the BDI

agent. They proposed using a belief set and plan

set to store target information and penetration test-

ing knowledge, respectively. Our approach is based

on their BDI agent framework. However, the differ-

ence is that target information, and penetration test-

ing knowledge is stored in the ontology. In our ap-

proach, target information is stored as instances un-

der target classes with data properties such as IP ad-

dress, port, OS, application, conﬁguration, vulnera-

bility and current permission. The object property is-

SameSubnet represents the relation between targets.

From the prospects of attackers, attack actions are

stored as instances under the attacker methods class

with data properties such as action, precondition and

post-condition. SWRL rules are used to determine the

Ontology-based Automation of Penetration Testing

717

attack actions and their preference according to target

information, in the meantime, updating the informa-

tion or relations in the ontology. After the ontology

determines the speciﬁc attack action, the BDI plan

will perform the attack. At this point, the belief set in

the BDI agent is used to store new information gen-

erated during the attack. Finally, the ontology will be

updated, including the object property exploitBy and

the data property current property after the attack is

ﬁnished in the BDI agent by Owlready2. The process

of our ontology-based automation of penetration test-

ing is presented in Figure 3:

Figure 3: Process of automation of penetration testing.

6 ATTACK SCENARIO

To validate our approach, we present an attack sce-

nario in a virtual environment. Our demo runs on the

Kali Linux virtual machine, while the target runs on a

WindowsXPSP3 virtual machine. We use Metasploit,

a popular penetration testing framework (Kennedy

et al., 2011) as the attack action space. In BDIPython,

we use functions to deﬁne attack actions and plan

rules to active the BDI reasoning cycle. The target

information is shown below :

- Ip address: 192.168.1.162

- Ports: 135, 139, 445, 3389

- Operating system: WindowsXP SP3

- Vulnerabilities: MS08067,Weak password

- Current permission: None

In our demo, we pre-deﬁne MS08-067 buffer over-

ﬂow attack and ssh password attack. We can see from

Figure 4: ﬁrstly, after we input the target IP address

and the attacker’s IP address, our demo start to probe

the target port.

Figure 4: Probe target’s port.

Then, according to the port results, there is no ssh

port running on the target. Thus, our demo performs

MS08-067 attack.

Figure 5: MS08-067 attack.

Figure 6: System permission.

Finally, the MS08-067 attack is successful (see

Figure 5), and we obtain the highest permission in the

target system. Figure 6 shows a connection has been

created between the attacker and target machine with

system privilege through 4444 port.

We can see the update of data properties in target1

instance and the relation between attacker instance

and MS08-067 instance in our ontology(see Figure

7). In target1 data properties, current permission is

changed to system.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

718

Figure 7: Properties update in ontology.

7 CONCLUSION

In this paper, we proposed an ontology-based auto-

mated penetration testing approach. According to

our proposed penetration testing attack taxonomy, we

built an ontology by Protege. To help make decisions

and produce new knowledge, we make use of SWRL

rules to create a penetration testing knowledge base

as well as to achieve reasoning functions. Finally, we

use agent-based(BDI) framework and Owlready2 to

achieve the process of automated penetration testing.

To validate our approach, we used BDIPython library

to implement an attack scenario in a virtual environ-

ment. The ontology and BDI agent are extendable,

while we are going to ﬁnd ways to extend it automat-

ically in the future.

REFERENCES

Bodenreider, O. (2004). The uniﬁed medical language sys-

tem (umls): integrating biomedical terminology. Nu-

cleic acids research, 32(suppl 1):D267–D270.

Bordini, R. H., H

ubner, J. F., and Wooldridge, M. (2007).

Programming multi-agent systems in AgentSpeak us-

ing Jason, volume 8. John Wiley & Sons.

Bremner, P., Dennis, L. A., Fisher, M., and Winﬁeld, A. F.

(2019). On proactive, transparent, and veriﬁable eth-

ical reasoning for robots. Proceedings of the IEEE,

107(3):541–561.

Broad, J. and Bindner, A. (2013). Hacking with Kali: prac-

tical penetration testing techniques. Newnes.

Chu, G. and Lisitsa, A. (2018). Poster: Agent-based (bdi)

modeling for automation of penetration testing. In

2018 16th Annual Conference on Privacy, Security

and Trust (PST), pages 1–2. IEEE.

Gao, J.-b., Zhang, B.-w., Chen, X.-h., and Luo, Z. (2013).

Ontology-based model of network and computer at-

tacks for security assessment. Journal of Shanghai

Jiaotong University (Science), 18(5):554–562.

Guarino, N. (1995). Formal ontology, conceptual analysis

and knowledge representation. International journal

of human-computer studies, 43(5-6):625–640.

Herzog, A., Shahmehri, N., and Duma, C. (2007). An ontol-

ogy of information security. International Journal of

Information Security and Privacy (IJISP), 1(4):1–23.

Horrocks, I., Patel-Schneider, P. F., Boley, H., Tabet, S.,

Grosof, B., Dean, M., et al. (2004). Swrl: A semantic

web rule language combining owl and ruleml. W3C

Member submission, 21(79):1–31.

Kennedy, D., O’gorman, J., Kearns, D., and Aharoni, M.

(2011). Metasploit: the penetration tester’s guide. No

Starch Press.

Knight, K., Chander, I., Haines, M., Hatzivassiloglou, V.,

Hovy, E., Iida, M., Luk, S. K., Whitney, R., and Ya-

mada, K. (1995). Filling knowledge gaps in a broad-

coverage machine translation system. arXiv preprint

cmp-lg/9506009.

Kotenko, I. and Doynikova, E. (2014). Security assess-

ment of computer networks based on attack graphs

and security events. In Information and Communica-

tion Technology-EurAsia Conference, pages 462–471.

Springer.

Lamy, J.-B. (2017). Owlready: Ontology-oriented pro-

gramming in python with automatic classiﬁcation and

high level constructs for biomedical ontologies. Arti-

ﬁcial intelligence in medicine, 80:11–28.

Lenat, D. B. and Guha, R. V. (1989). Building large

knowledge-based systems; representation and infer-

ence in the Cyc project. Addison-Wesley Longman

Publishing Co., Inc.

Miller, G. A. (1995). Wordnet: a lexical database for en-

glish. Communications of the ACM, 38(11):39–41.

Moga, H., Boscoianu, M., Ungureanu, D., Lile, R., and

Erginoz, N. (2015). Massive cyber-attacks patterns

implemented with bdi agents. In Applied Mechan-

ics and Materials, volume 811, pages 383–389. Trans

Tech Publ.

Musen, M. A. et al. (2015). The prot

e project: a look

back and a look forward. AI matters, 1(4):4.

Nickerson, C., Kennedy, D., Smith, E., Rabie, A., Friedli,

S., Searle, J., Knight, B., Gates, C., and McCray, J.

(2014). Penetration testing execution standard.

Ning, Z., Xin-yuan, C., Yong-fu, Z., and Si-yuan, X.

(2008). Design and application of penetration at-

tack tree model oriented to attack resistance test. In

2008 International Conference on Computer Science

and Software Engineering, volume 3, pages 622–626.

IEEE.

Obes, J. L., Sarraute, C., and Richarte, G. (2013). At-

tack planning in the real world. arXiv preprint

arXiv:1306.4044.

Pandya, D. and Patel, N. (2016). Owasp top 10 vulnerability

analyses in government websites. International Jour-

nal of Enterprise Computing and Business Systems,

6(1).

Pinkston, J., Undercoffer, J., Joshi, A., and Finin, T. (2004).

A target-centric ontology for intrusion detection. In

In proceeding of the IJCAI-03 Workshop on Ontolo-

gies and Distributed Systems. Acapulco, August 9 th.

Citeseer.

Ontology-based Automation of Penetration Testing

719

Rao, A. S., Georgeff, M. P., et al. (1995). Bdi agents: from

theory to practice. In ICMAS, volume 95, pages 312–

319.

Sarraute, C., Buffet, O., and Hoffmann, J. (2013). Pen-

etration testing== pomdp solving? arXiv preprint

arXiv:1306.4714.

Shah, S. and Mehtre, B. M. (2015). An overview of

vulnerability assessment and penetration testing tech-

niques. Journal of Computer Virology and Hacking

Techniques, 11(1):27–49.

Stepanova, T., Pechenkin, A., and Lavrova, D. (2015).

Ontology-based big data approach to automated pene-

tration testing of large-scale heterogeneous systems.

In Proceedings of the 8th International Conference

on Security of Information and Networks, pages 142–

149. ACM.

Strom, B. E., Applebaum, A., Miller, D. P., Nickels, K. C.,

Pennington, A. G., and Thomas, C. B. (2018). Mitre

att&ck: Design and philosophy. MITRE Product MP,

pages 18–0944.

Studer, R., Benjamins, V. R., and Fensel, D. (1998). Knowl-

edge engineering: principles and methods. Data &

knowledge engineering, 25(1-2):161–197.

Wang, J. A. and Guo, M. (2009). Ovm: an ontology for

vulnerability management. In Proceedings of the 5th

Annual Workshop on Cyber Security and Information

Intelligence Research: Cyber Security and Informa-

tion Intelligence Challenges and Strategies, page 34.

ACM.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

720
