Introducing a Verified Authenticated Key Exchange Protocol
over Voice Channels for Secure Voice Communication
Piotr Krasnowski
1,2
, Jerome Lebrun
1
and Bruno Martin
1
1
Univ. C
ˆ
ote d’Azur, I3S-CNRS, Sophia Antipolis, France
2
BlackBoxS
´
ecu, Sophia Antipolis, France
Keywords:
Authenticated Key Exchange, Secure Voice Communications, Data over Voice, Vocal Verification, Crypto
Phone, Tamarin Prover, Formal Protocol Verification.
Abstract:
Increasing need for secure voice communication is leading to new ideas for securing voice transmission. This
work relates to a relatively new concept of sending encrypted speech as pseudo-speech in audio domain over
existing civilian voice communication infrastructure, like 2G-4G networks and VoIP. Such a setting is more
universal compared to military “Crypto Phones” and can be opened for public evaluation. Nevertheless, secure
communication requires a prior exchange of cryptographic keys over voice channels, without reliance on any
Public Key Infrastructure (PKI).
This work presents the first formally verified and authenticated key exchange (AKE) over voice channels
for secure military-grade voice communications. It describes the operational principles of the novel com-
munication system and enlists its security requirements. The voice channel characteristics in the context of
AKE protocol execution is thoroughly explained, with a strong emphasis on differences to classical store-
and-forward data channels. Namely a robust protocol has been designed specifically for voice channels with
double authentication based on signatures and Short Authentication Strings (SAS). The protocol is detailed
and analyzed in terms of fundamental security properties and successfuly verified in a symbolic model using
Tamarin Prover.
1 INTRODUCTION
An increasing concern of privacy violation in voice
communications has motivated the development of
secure voice over IP (VoIP) communicators, with
Telegram and Signal being the iconic examples
12
.
However, these applications are inherently insecure
against spying malware installed on the smart-phone
(Scott-Railton et al., 2017). Parallely, military-grade
applications requiring higher protection rely on ded-
icated hardware, most commonly in the form of
Crypto Phones. These closed and unverifiable solu-
tions suffer from high costs and low flexibility, as typ-
ically encrypted phones allow communications exclu-
sively over one kind of a voice channel, like GSM.
The mentioned limitations encourage the search
for open solutions complementary to Crypto Phones,
combining flexibility and high protection provided by
specialized hardware. A new idea, depicted on Fig.1,
is based on voice encryption in the audio domain. The
1
https://signal.org
2
https://core.telegram.org
Figure 1: Encrypted voice over voice channel scheme.
speech is recorded by (a) the headset’s microphone
and then forwarded to (b) the encryption device (here
called the Crypto Box). The Crypto Box processes
the speech and enciphers vocal parameters of the sig-
nal. The encrypted speech in the form of data stream
shaped into pseudo-speech audio signal is transmit-
ted by (c) the audio link to the audio input of (d) the
phone and sent through 2G-4G networks or VoIP. Fi-
nally, the received pseudo-speech is deciphered by the
paired Crypto Box on the other side of the channel.
In such a setting, voice encryption is performed
Krasnowski, P., Lebrun, J. and Martin, B.
Introducing a Verified Authenticated Key Exchange Protocol over Voice Channels for Secure Voice Communication.
DOI: 10.5220/0009156506830690
In Proceedings of the 6th International Conference on Information Systems Security and Privacy (ICISSP 2020), pages 683-690
ISBN: 978-989-758-399-5; ISSN: 2184-4356
Copyright
c
 2022 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved
683

outside of the phone, hence protecting against audio-
recording malware. To limit the risk of a system cor-
ruption, the Crypto Box has only analog input/output
interfaces to the headset and to the phone. However,
for security reasons, it is necessary that other analog
inputs of the phone (particularly the built-in micro-
phone) are blocked by a special case or removed.
From the system perspective, two Crypto Boxes
are the end-points of a secured voice domain. Every-
thing in between, including mobile phones itself, are
elements of a communication infrastructure that en-
ables voice transmission. The framework adds a new
layer of security, protecting against spying malware
installed on the phone. Since all communications be-
tween encrypting devices is done purely in the ana-
log domain, the selection of the specific voice com-
munication technology is therefore a secondary issue.
Compatibility with most of the vocal communication
methods, like VoIP applications or 2G-4G networks,
significantly widens the range of usability scenarios.
The described setting, which is not intended for a
daily-usage, is of great interest for business, diplo-
matic and military services, who require secure com-
munications in an unreliable environment and without
the access to a confidential communication infrastruc-
ture.
The major motivation in our approach is to secure
voice communication even with untrusted phones, as
these should not be actively involved in the setup of a
secure connection or store sensitive data. Instead, the
trust is given to Crypto Box manufacturers, respon-
sible for software implementation or update policy.
Though, the open framework enables various hard-
ware solutions, including combining the phone and
the Crypto Box into one device.
Producing encrypted speech in real-time appears
to be quite technically challenging. Firstly, the
recorded speech is encoded into the vocal parame-
ters in a similar manner as during speech compres-
sion. Later, the speech parameters are encrypted and
mapped onto the audio waveform. This technique,
called Data over Voice (DoV), proved its feasibil-
ity in practical scenarios (Katugampala et al., 2004;
Shahbazi et al., 2009; Dhananjay et al., 2010; Bian-
cucci et al., 2013). However, since voice channels are
designed to carry voice signal without much loss of
perceptual quality, which is a different goal than the
transmission of data, the achievable bitrate for DoV
typically is at most 2 kbps. Even in case of mod-
ern digital VoIP applications, the received voice is
much distorted compared to the input signal, mak-
ing the transmission resembling a communication
over highly distortive analog channel. Sending en-
crypted voice with such constraints is possible thanks
to strong error correction and voice compression by
coders like MELP or Codec2.
Secure speech enciphering requires a prior ex-
change of session keys between the Crypto Boxes.
Due to system requirements, the key exchange can
only be made through the same point-to-point voice
channel, which gives no practical possibility of
adding an online trusted third party (TTP) or a certifi-
cate authority (CA). Such a limitation is a big concern
for users’ authentication.
Research on secure key exchange between two
honest parties without any TTP led to the creation
of standards suitable for VoIP applications, as an ex-
tension of the Real-Time Transport Protocol, called
ZRTP (Callas et al., 2011), and Multimedia Inter-
net KEYing (MIKEY) protocol (Arkko et al., 2004).
Especially ZRTP is interesting in the context of this
work, because it provides authentication mechanism
in the absence of any Public Key Infrastructure (PKI)
or a pre-shared secret. In these situations, authenti-
cation is based on vocally comparing Short Authen-
tication Strings (SAS). Unfortunately, having three
modes of operation and extensive negotiation signal-
ing, even ZRTP seems to be overly complex for com-
munication over voice channels. Moreover, none of
the protocols put a sufficient emphasis on resistance
to strong message distortion or desynchronization in
low-bandwidth environment.
To the best of authors’ knowledge, this is the first
paper focusing on authenticated key exchange (AKE)
protocols over voice channels. The work aims at
giving the understanding of the very specific chan-
nel constraints, leading to a protocol highly adapted
to voice channel characteristics and system require-
ments. The protocol provides double authentication
in a single mode of operation, by signatures and vo-
cal comparison of SAS. In addition, it is flexible
enough to support authentication of user who did not
yet share the signing public keys between each other,
with SAS-only authentication or unilateral signature
authentication. Finally, the same protocol can be used
to authenticate the exchange of signing public keys.
2 SYSTEM REQUIREMENTS
The need for hardware-based voice encryption is a re-
sponse to an increased risk of being intercepted. Thus,
a cryptographic scheme should reflect higher require-
ments for secrecy and authentication. The first con-
cern is recording and analyzing the network traffic
by omnipresent passive eavesdroppers. Active adver-
saries controlling the network are more likely to block
or distort communication, which is technically very
ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy
684

simple. However, a powerful and knowledgeable ad-
versary who is able to analyze and synthesize a com-
patible pseudo-speech may try to modify a message or
insert his own. Finally, in critical situations, the en-
crypting device could be hijacked in order to extract
long-term keys. On the other hand, in our work we
assume that the encryption device does not allow any
intrusion into its internal memory during the opera-
tion, so all ephemeral data stored on the device (and
deleted after each protocol run) is considered secure.
A design process of the protocol is motivated by
an anticipated user experience. However, due to se-
vere constraints of the voice channel characteristics,
the biggest challenges are related to protocol com-
plexity, synchronization and robustness. A major bot-
tleneck is a large message round-trip time, around 2
seconds long, which causes the whole protocol run-
time prohibitively long even in case of simple proto-
cols. Another limitation is a very small bandwidth
implying a reduction of the message size. More-
over, the protocol has to be robust against fading
and signal distortion, requiring a significant simpli-
fication of signalization and strong error correction
mechanisms. Finally, in order to decrease battery
power consumption, cryptographic operations should
be rather lightweight and optimized. When imple-
menting, relying on popular and verified network se-
curity libraries, like OpenSSL or NaCL, could be a
strong practical advantage.
Adaptation to hardware and channel constraints
should not lead to significant relaxation of the security
level. It will be detailed that the key exchange proto-
col provides strong mutual agreement on the parame-
ters used for the derivation of the session key, putting
a special emphasis on preventing Man-In-The-Middle
(MITM) attacks and achieving Perfect Forward Se-
crecy (PFS). The crucial property of the protocol is to
enable the authentication of peers, no matter if they
share a common secret or not.
A successful and fast key exchange is an indicator
of sufficiently good channel conditions, that provide a
comfortable communication. Each received message
can be used to effectively estimate channel character-
istics and to improve decoding capabilities.
3 PROTOCOL DESCRIPTION
This section presents the symbolic model of the au-
thenticated key exchange protocol over voice chan-
nels and provides a brief explanation.
3.1 Preliminaries
Let us describe the key exchange between honest
users Alice and Bob who know each other, without
any legitimate trusted third party participating. The
operational framework requires that Alice and Bob
first need to establish a non-encrypted voice connec-
tion with a preferred voice application. Then, they can
initiate a secure communication. The system model
assumes that identity information used to make a call
(phone number, user account, credentials etc.) is inde-
pendent from the authentic user identity and from the
identification number of the voice encryption hard-
ware. Only one running session at a time is possi-
ble since each device cannot process more than one
message simultaneously. Therefore, several kinds of
Denial-of-Service (DoS) attacks, when the adversary
tries to send multiple messages to a recipient, are not
effectively different than distorting or blocking the
channel.
In highly unreliable channels like voice channels,
Alice and Bob are never sure of message delivery.
Thus, several synchronization techniques are needed,
i.e. repeat requests, retransmissions and time-outs.
For simplicity and space limitations, most details on
synchronization will be omitted here. Additionally,
thanks to strong error-detection coding, users are able
to detect random channel errors and differentiate them
from intentional malicious manipulations.
3.2 Symbolic Model of the Protocol
The proposed protocol, that is presented on Fig-
ure 2 next page, relies on Ephemeral (Elliptic-
Curve) Diffie-Hellman (EC)DHE exchange (Hanker-
son et al., 2005), authenticated by signatures (existen-
tially unforgeable and deterministic) or Short Authen-
tication Strings. Before the protocol starts, Alice and
Bob agree on the elliptic curve and the lengths of keys
and nonces. Public verification keys should be pro-
vided to the recipients in an authenticated way before
the communication starts and are stored in the Crypto
Box address book. However, in many real scenarios
it is not possible to properly provide such a verifica-
tion key. If the signature cannot be verified by the
recipient, the protocol offers vocal verification as an
alternative, which authenticates the speakers and the
parameters used to derive the current session key.
The protocol interaction consists of several steps:
the setup, the key exchange and authentication, the
protocol acknowledgement and the optional vocal
verification. Table 1 contains the glossary of terms
used in the protocol specification, along with their bit-
lengths.
Introducing a Verified Authenticated Key Exchange Protocol over Voice Channels for Secure Voice Communication
685

Table 1: Glossary.
Acronyms Definitions Bits
ID
U
fixed user identifier 32
N
U
random and unique
nonce
32
K
S
Session Key 256
SAS
Short Authentication
String
32
(R
A
, R
B
)
Short Authentication
String seeds
(128, 32)
(d
U
, Q
U
)
secret/public ECDHE
key pair
(256, 256)
(S
U
, V
U
)
signing/verification
key pair
(256, 256)
Sign
S
U
(·)
signature (signed
with S
U
)
256
h
X
(·) hash function X
Setup: The negotiation stage has been considerably
simplified. Participants have to mutually agree
on starting the key exchange procedure, therefore
the actual key exchange protocol is preceded only
by fast and automatic role negotiation in order to
prevent mutual interference or logjams. Then, both
Alice and Bob choose a random private integer d, a
random and unique nonce N, a random value R and
compute a public key Q. Unique nonce guarantees
the uniqueness of the triple (ID, Q, N).
Key Exchange and Authentication: In this stage
Alice and Bob exchange values that are used to
derive the Session Key (K
S
) and the SAS. Alice sends
her public ID, the nonce, the ephemeral public key
and the hash, with R
A
included. Bob responds with
his values, appends R
B
, and additionally sends his
signature over all sent parameters required for K
S
calculation. Alice answers with her signature over
the same data and finally reveals R
A
. It is worth
noting that the protocol permits a situation when the
signature cannot be verified. If any of the recipients
did not obtain a verification key corresponding to the
sender’s ID, the signature is checked against channel
errors but not processed further.
Protocol Acknowledgment: When all cryptographic
parameters are exchanged, voice encryption can be
started. Encryption is initiated after a reception of
Bob’s acknowledgment by Alice. The acknowl-
edgment is a confirmation of error-less message
reception, so can be non-encrypted.
Short Authentication String Comparison: Each
participant can request for vocally challenging SAS
equality with the peer. SAS comparison is obligatory
. . . . . . . . . . . . . . . Unsecured call initiation . . . . . . . . . . . . . . .
Alice
vocal agreement on
←−−−−−−−−−−−−−→
protocol initialization
Bob
. . . . . . . . . . . . . . . . . . . . . . . . Setup . . . . . . . . . . . . . . . . . . . . . . . .
1 : N
A
←$ Z
∗
32
A/B role
←−−−−−−−−−−−−−→
negotiation
N
B
←$ Z
∗
32
2 : d
A
←$ Z
∗
256
d
B
←$ Z
∗
256
3 : Q
A
= d
A
G Q
B
= d
B
G
4 : R
A
←$ Z
∗
128
R
B
←$ Z
∗
32
. . . . . . . . . . . Key exchange and authentication . . . . . . . . . . .
5 :
ID
A
, N
A
, Q
A
−−−−−−−−−−−−−−−→
h
128
(ID
A
kN
A
kQ
A
kR
A
)
6 :
ID
B
, N
B
, Q
B
, R
B
←−−−−−−−−−−−−−−−
Sign
S
B
(N)
7 : Z = d
A
Q
B
R
A
, Sign
S
A
(H)
−−−−−−−−−−−−−−−→ Z = d
B
Q
A
8 : K
S
= h
256
(Zk•) K
S
= h
256
(Zk•)
. . . . . . . . . . . . . . . . . . Acknowledgment . . . . . . . . . . . . . . . . . .
9 :
ACK
←−−−−−−−−−−−−−−−
. . . . . . . SAS comparison over Encrypted Channel . . . . . . .
10 : SAS = h
32
()
SAS vocal
←−−−−−−−−−−−−−→
comparison
SAS = h
32
()
Symbols:
N ≡ ’B’kID
A
kN
A
kQ
A
kID
B
kN
B
kQ
B
H ≡ ’A’kID
B
kN
B
kQ
B
kID
A
kN
A
kQ
A
• ≡ ID
A
kN
A
kID
B
kN
B
 ≡ R
A
kR
B
kID
B
kQ
B
kN
B
Figure 2: Key exchange protocol over voice channels.
if any of the users was not able to verify the signature.
It is assumed that the comparison process is authen-
ticated - users are able to recognize voice character-
istics of the peer (timbre, tempo, etc.). The SAS is
displayed on the Crypto Box as a short string of digits
or words to be vocally uttered by the users.
4 FORMAL VERIFICATION
Verification of the protocol is performed in a sym-
bolic model, where all cryptographic primitives are
assumed perfect and give the adversary no advantage
(Dolev and Yao, 1983). In the analyzed scenario, it
means that all parties generate truly random numbers,
signatures are unforgeable and ECDH parameters do
not reveal any secret information. Formal symbolic
verification can be considered as a first step of a proto-
col analysis, paving the way to computational model
verification (Goldwasser and Micali, 1984; Blanchet,
ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy
686

2012), in which the adversary gets the power to attack
cryptographic algorithms.
A formal analysis in a symbolic model of the
proposed protocol was done with Tamarin Prover
(Schmidt, 2012; Meier, 2013; Meier et al., 2013), a
powerful and increasingly popular automatic verifica-
tion tool designed at ETH Z
¨
urich. Tamarin is based
on multiset rewriting (MSR) language and supports
generic Diffie-Hellman group operations. In addi-
tion, Tamarin can model many cryptographic prim-
itives like signatures or hashes and offers an impres-
sive database of examples, that makes the tool suitable
for the protocol evaluation.
4.1 Protocol Modeling
Verification by Tamarin implies providing an abstract
protocol model, which tries to faithfully express rel-
evant information from the security perspective, but
still being within the scope of feasibility of the analy-
sis. The protocol model code can be found in (Kras-
nowski, 2019). Several protocol restrictions were re-
laxed, allowing users to run multiple protocol instan-
tiations at the same time and to “forget” the verifica-
tion key of the peer. SAS verification is performed by
a separate protocol rule which is not obligatory, sim-
ulating a realistic case when users simply ignore it.
Vocal challenging is modeled as communicating over
an authenticated (not secret) channel, that is a chan-
nel which the adversary can intercept but not modify.
Last ACK message is skipped.
4.2 Security Properties and Verification
Results
The protocol model was checked against the Dolev-
Yao adversary (Dolev and Yao, 1983), having a full
control over the network and with the power to reveal
the long-term secret key of any user (ephemeral data
is considered secure). Evaluation was done in four au-
thentication configurations: mutual signature authen-
tication between two honest users, unilateral signature
authentication (when only one user can verify the sig-
nature of the peer), vocal verification or no authenti-
cation.
Verification focused on most critical security
properties: (perfect forward) secrecy and a mutual in-
jective agreement (Lowe, 1997) on the Session Key.
The protocol was also verified for resilience to reflec-
tion attacks (a user cannot accept her own identity as a
peer) and for signing key compromise impersonation
(adversary can impersonate only corrupted users).
Results of protocol verification can be found in
Table 2. Protocol configurations involving signature
Table 2: Security properties verified by Tamarin in four au-
thentication scenarios: (a) mutual signature authentication,
(b) unilateral signature authentication, (c) SAS vocal verifi-
cation and (d) no authentication.
Authentication
scenario:
(a) (b) (c) (d)
Session Key secrecy 3 3 3 7
forward secrecy 3 3 3 7
injective agreement 3 3 3 7
reflection attack 3 3 7 7
key compromise
impersonation
3 3 - -
authentication or authenticated SAS comparison are
proven to provide perfect forward secrecy and injec-
tive agreement. Unilateral signature authentication
between two honest users who know each other guar-
antees the same level of security as mutual signature
authentication. Surprisingly, vocal verification does
not protect against reflection attack, because the user
can trivially compare SAS with herself. Table results
indicate the importance of authentication - none of the
properties were verified if no authentication was per-
formed.
5 SECURITY CONSIDERATIONS
The following sections explain in more detail the
protocol characteristics, providing several justifica-
tions and practical recommendations. It starts from
the overview of fundamental protocol elements: the
choice of public-based cryptography, the role of sig-
natures and of Short Authentication Strings. Next sec-
tion enlists potential protocol weaknesses and possi-
ble fixes.
5.1 Discussion
Public Key Agreement versus Symmetric Cryp-
tography: In exceptionally constrained resource
devices, such as IoT sensors or RFID cards, a pursue
for ultra-lightweight key exchange protocols led to
the shift from the public key encryption towards
symmetric encryption techniques (Echevarria et al.,
2016; Lee et al., 2014; Baashirah and Abuzneid,
2018). Even the ZRTP protocol offers a possibility of
a key exchange in a lightweight preshared mode. In
this configuration, two entities share a secret which
is used to encrypt or refresh the keying material for
the new session. In order to achieve Perfect Forward
Secrecy, the long-term secret should be regularly
updated, desirably after each successful key exchange
run. The update decision has to be mutual, otherwise
Introducing a Verified Authenticated Key Exchange Protocol over Voice Channels for Secure Voice Communication
687

risking one-side update and user desynchronization.
Unfortunately, in voice channels such a risk cannot
be eliminated, because the last update confirmation
message may not be delivered. Decreasing the chance
of desynchronization by sending more confirma-
tion messages would negatively affect the protocol
run-time. Another solution, based on on-the-fly
resynchronization mechanisms requires an online
server keeping the track of all key updates or a costly
and potentially unsecure “guessing” the long-term
parameters until decryption is successful (Baashirah
and Abuzneid, 2018). Finally, as was emphasized
before, in some scenarios the exchange of long-term
secret is not possible, limiting the usability of sym-
metric cryptography. In the light of above-mentioned
reasons and relatively smaller hardware restrictions
compared to IoT sensors, public-based key exchange
scheme seems more adequate.
Role of Short Authentication Strings: If the key ex-
change is not interfered by a third party, both partic-
ipants obtain the same Short Authentication String.
Challenging SAS vocally between honest users has a
twofold role. Firstly, it enables authentication of users
based on voice identification. Secondly, the inequality
of codes may indicate the presence of an active MITM
adversary. However, MITM manipulations would be
undetected if the adversary is somehow able to influ-
ence or precompute the SAS value before the users.
Computation of the code depends on seed values
R
A
and R
B
chosen randomly by honest users. Impor-
tantly, Alice and Bob are forced to select seeds before
knowing the value of the peer - Alice by sending the
hash of R
A
in the first message and Bob by revealing
R
B
before R
A
. Such construction, inspired by (Pasini
and Vaudenay, 2006), prevents adaptive selection of
seeds by each party. The same rule applies to the ad-
versary, who cannot predict the SAS value until it is
too late. The only hope for him is a random guess with
a low probability of a success, or an extraction of R
A
from the hash sent in the first message by brute force
search. For this last reason, the length of R
A
should
be considerably larger than R
B
. On the other hand, the
difference of lengths is partially compensated by tak-
ing Q
B
kN
B
as an additional input of the hash function.
It is worth noting, that SAS value does not have to be
confidential, since it plays only the authentication role
and cannot be modified without detection.
In practice, the security of vocal verification
depends also on how users abide to it. The SAS
could be represented by a smaller number of simple
pictographs or easily pronounceable words, the same
way as in the ZRTP which has the PGP Word List
incorporated into its framework (Callas et al., 2011;
Zimmermann, 1996). The device should encourage
the mutual SAS comparison by indicating a part of
the SAS to pronounce and a part to hear from the peer.
Signature-based Authentication: Signatures pro-
vide device authentication and message integrity, sim-
ilarly to message authentication codes (MAC), which
are simpler and easier to compute. Indeed, in some
scenarios choosing hash-based MAC instead of sig-
natures would be sufficient. However, signatures give
wider flexibility, justifying higher computational cost.
A natural advantage of signatures is that they do not
require mutual agreement and secure exchange of a
long-term secret between two parties. Moreover, each
user keeps in memory only one private signing key,
used regardless of the receiver’s identity. In conse-
quence, if the user is corrupted, the adversary should
be able to impersonate only that person.
When one user cannot obtain a verification key
due to insecure environment, it is still possible to
achieve unilateral authentication (Boyd and Mathuria,
2003; Maurer et al., 2013; Dodis and Fiore, 2017).
One-side authentication prevents MITM attacks, leav-
ing only two possibilities: both honest users securely
exchange a secret or the adversary is an authenticator
(Maurer et al., 2013). It naturally implies that if the
users want to communicate and they know they can
perform unilateral authentication, the adversary can-
not interfere undetected in another way than prevent-
ing the successful exchange. However, the user who
failed to authenticate the peer is still complied to chal-
lenge the SAS, because from her perspective it is the
only formal way to verify the absence of the MITM
manipulations.
A signature key management policy, due to a lack
of any PKI infrastructure, has a crucial impact on
the system security and usability. This work points
out two possible schemes, decentralized and fully
centralized, which can be chosen depending on the
needs. In a centralized system, keys are managed by
an offline central authority, keeping the track of all
records and being responsible for key distribution
and update. In a decentralized case, each user is
entitled to generate her own key pair and distribute
public keys to specific users in authenticated way.
Following the PGP model, sharing the key can be
performed remotely based on speaker identification
and vocal authentication of the channel. Thus, the
proposed protocol with SAS comparison gives the
possibility to authenticate the exchange of signature
verification keys.
Identity Protection: In many situations protecting
the identity of the user is as important as securing the
ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy
688

content of the speech. However, calling anybody with
a civilian communication networks is always associ-
ated with revealing user metadata (i.e. phone num-
ber, user credentials, location). Even if the metadata
is publicly known, it may be advantageous to at least
hide the identity of the encrypting device from passive
eavesdroppers.
It is possible to redesign the proposed protocol to
attain identity anonymity without the change of any
other substantial protocol property. The ID and the
signatures of Alice and Bob can be sent encrypted
with the key derived from DH secret exchanged dur-
ing first message round-trip, in a similar manner as
in the Initial Exchange of IKEv2 standard (Kaufman
et al., 2010). The complexity of a protocol providing
anonymity would increase, since it will require addi-
tional data encryption. It is also important to care-
fully evaluate the way the encryption key is derived
and how it is related to the the session key, in order to
give no foothold for cryptanalysis.
5.2 Possible Attacks and Threats
Many protocol vulnerabilities are focusing on the se-
lection of specific cryptographic algorithms, its im-
plementation and finally on compliance to protocol
rules. The biggest threat is posed by not respecting
the obligation of SAS comparison by real users, open-
ing a space for MITM attacks.
The capabilities of modern speech synthesizers
which exploit AI techniques to impersonate speaker’s
voice (Gao et al., 2018) question the level of authen-
tication provided by voice recognition. Instead of
breaking the SAS security, the adversary may simply
simulate or replay the speaker pronouncing the code
(Shirvanian et al., 2018). The risk is amplified by the
fact that the voice sent is highly compressed and thus
significantly differs from its real characteristics. For
this reason, it is recommended to extend sequence
comparison by contextual questions, like describing
the last watched movie, or to share personal informa-
tion known only by the peer but not by the adversary.
If honest users are capable to verify signatures of
each other and of achieving strong authentication, the
adversary may try a downgrade-attack. It can be done
simply by modifying users’ ID and imposing vocal
verification. The problem may be partially solved by
displaying the IDs along the SAS. However, the real
solution would be to force signature verification dur-
ing each protocol by default.
Finally, the proposed protocol cannot protect
against the consequences of a device being stolen or
misused, giving the responsibility to the manufacturer
to provide strong enough password or biometric pro-
tection. To minimize the negative consequences of a
theft, the device should be protected against physical
tampering, making reverse engineering very difficult.
6 CONCLUSIONS
Our work is the first attempt to resolve the problem of
cryptographic key exchange over voice channels for
military-grade secure voice communications. It also
introduces challenges related to secure communica-
tions over voice channels like extremely small band-
width, no guarantee of message delivery and the is-
sue of battery consumption. The paper lists the secu-
rity requirements posed to the system, like protecting
against interception and MITM attacks, emphasizing
the importance of user authentication in absence of a
trusted server. All these concerns and limitations jus-
tify the need of a dedicated protocol instead of relying
fully on standardized solutions.
We proposed a simplified key exchange protocol
between two honest parties which is based on the
ephemeral elliptic curve Diffie-Hellman (ECDHE)
protocol. The protocol offers two ways of authen-
tication - by signatures and by vocally challenging
the equality of the Short Authentication Strings. A
symbolic model of the protocol was analyzed using
Tamarin Prover in order to verify the crucial secu-
rity properties as Perfect Forward Secrecy and mutual
agreement on the Session Key. The process of the ver-
ification was explained, pointing out the limitations
of a symbolic analysis, particularly model simplifica-
tions and perfect cryptography assumption.
Formal verification was followed by the discus-
sion of the protocol properties, like unilateral authen-
tication provided by one-side signature verification or
the role of vocal comparison in preventing MITM at-
tacks. The analysis led to the observation that all ana-
lyzed techniques in themselves do not provide perfect
authentication, thus informal identity authentication
methods has to be introduced.
Potential vulnerabilities and attacks on the sys-
tem were also covered in this work. Several propo-
sitions and practical solutions regarding key manage-
ment, proper SAS comparison or identity protection
can serve as a guide for engineers working on the im-
plementations of exchange protocols over voice chan-
nels or in similar scenarios.
ACKNOWLEDGEMENTS
This work is supported by grant DGA Cifre-Defense
program No 01D17022178 DGA/DS/MRIS.
Introducing a Verified Authenticated Key Exchange Protocol over Voice Channels for Secure Voice Communication
689

REFERENCES
Arkko, J., Carrara, E., Lindholm, F., Norrman, K.,
and Naslund, M. (2004). Mikey: Multimedia
Internet KEYing (Proposed standard RFC3830).
Network Working Group. Retrieved from
https://tools.ietf.org/html/rfc3830.
Baashirah, R. and Abuzneid, A. (2018). Survey on promi-
nent RFID authentication protocols for passive tags.
Sensors, 18(10):3584.
Biancucci, G., Claudi, A., and Dragoni, A. F. (2013). Se-
cure data and voice transmission over GSM voice
channel: Applications for secure communications.
In 2013 4th International Conference on Intelligent
Systems, Modelling and Simulation, pages 230–233.
IEEE.
Blanchet, B. (2012). Security protocol verification: Sym-
bolic and computational models. In Proceedings of
the First international conference on Principles of Se-
curity and Trust, pages 3–29. Springer-Verlag.
Boyd, C. and Mathuria, A. (2003). Protocols for authenti-
cation and key establishment, volume 1. Springer.
Callas, J., Johnston, A., and Zimmermann, P. (2011).
ZRTP: Media path key agreement for unicast se-
cure RTP (RFC6189). IETF. Retrieved from
https://tools.ietf.org/html/rfc6189.
Dhananjay, A., Sharma, A., Paik, M., Chen, J., Kuppusamy,
T. K., Li, J., and Subramanian, L. (2010). Hermes:
data transmission over unknown voice channels. In
Proceedings of the sixteenth annual international con-
ference on Mobile computing and networking, pages
113–124. ACM.
Dodis, Y. and Fiore, D. (2017). Unilaterally-authenticated
key exchange. In International Conference on Finan-
cial Cryptography and Data Security, pages 542–560.
Springer.
Dolev, D. and Yao, A. (1983). On the security of public key
protocols. IEEE Transactions on information theory,
29(2):198–208.
Echevarria, J. J., Legarda, J., Larra
˜
naga, J., and Ruiz-
de Garibay, J. (2016). lwAKE: A lightweight Au-
thenticated Key Exchange for class 0 devices. In-
ternational Journal of Distributed Sensor Networks,
12(5):6236494.
Gao, Y., Singh, R., and Raj, B. (2018). Voice imperson-
ation using generative adversarial networks. In 2018
IEEE International Conference on Acoustics, Speech
and Signal Processing (ICASSP), pages 2506–2510.
IEEE.
Goldwasser, S. and Micali, S. (1984). Probabilistic en-
cryption. Journal of computer and system sciences,
28(2):270–299.
Hankerson, D., Menezes, A. J., and Vanstone, S. (2005).
Guide to elliptic curve cryptography. Computing Re-
views, 46(1):13.
Katugampala, N., Al-Naimi, K., Villette, S., and Kondoz,
A. (2004). Real time data transmission over GSM
voice channel for secure voice & data applications.
In 2nd IEE Secure Mobile Commmunications Forum:
Exploring the Technical Challenges in Secure GSM
and WLAN. IET.
Kaufman, C., Hoffman, P., Nir, Y., and Eronen, P. (2010).
Internet Key Exchange Protocol Version 2 (IKEv2)
(RFC7296). IETF.
Krasnowski, P. (2019). Tamarin code of the key
exchange over voice channels. Available at
https://github.com/PiotrKrasnowski/AKE over Voice.
Lee, J.-Y., Lin, W.-C., and Huang, Y.-H. (2014). A
lightweight authentication protocol for internet of
things. In 2014 International Symposium on Next-
Generation Electronics (ISNE), pages 1–2. IEEE.
Lowe, G. (1997). A hierarchy of authentication specifica-
tions. In Proceedings 10th Computer Security Foun-
dations Workshop, pages 31–43. IEEE.
Maurer, U., Tackmann, B., and Coretti, S. (2013). Key Ex-
change with Unilateral Authentication: Composable
security definition and modular protocol design. IACR
Cryptology ePrint Archive, 2013:555.
Meier, S. (2013). Advancing automated security protocol
verification. PhD thesis, ETH Zurich.
Meier, S., Schmidt, B., Cremers, C., and Basin, D.
(2013). The TAMARIN prover for the symbolic anal-
ysis of security protocols. In International Confer-
ence on Computer Aided Verification, pages 696–701.
Springer.
Pasini, S. and Vaudenay, S. (2006). SAS-based authenti-
cated key agreement. In Public Key Cryptography -
PKC 2006, pages 395–409. Springer Berlin Heidel-
berg.
Schmidt, B. (2012). Formal analysis of key exchange proto-
cols and physical protocols. PhD thesis, ETH Zurich.
Scott-Railton, J., Marczak, B., Razzak, B. A., Crete-
Nishihata, M., and Deibert, R. (2017). Reckless ex-
ploit: Mexican journalists, lawyers, and a child tar-
geted with NSO spyware. Technical report.
Shahbazi, A., Rezaie, A. H., Sayadiyan, A., and
Mosayyebpour, S. (2009). A novel speech-like sym-
bol design for data transmission through GSM voice
channel. In 2009 IEEE International Symposium on
Signal Processing and Information Technology (IS-
SPIT), pages 478–483. IEEE.
Shirvanian, M., Saxena, N., and Mukhopadhyay, D. (2018).
Short voice imitation man-in-the-middle attacks on
Crypto Phones: Defeating humans and machines.
Journal of Computer Security, 26(3):311–333.
Zimmermann, P. (1996). PGPfone Owner’s Man-
ual. Pretty Good Privacy. Retrieved from
http://web.mit.edu/network/pgpfone/manual/.
ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy
690
