Distributed Information Integration in Convolutional Neural Networks

Dinesh Kumar

and Dharmendra Sharma

Faculty of Science & Technology, University of Canberra, 11 Kirinari Street, Canberra, ACT 2617, Australia

Keywords:

Distributed Information Integration, Central Processor, Local Processor, Convolutional Neural Network,

Filter Pyramid, Scale-invariance.

Abstract:

A large body of physiological ﬁndings has suggested the vision system understands a scene in terms of its local

features such as lines and curves. A highly notable computer algorithm developed that models such behaviour

is the Convolutional Neural Network (CNN). Whilst recognising an object in various scales remains trivial for

the human vision system, CNNs struggle to achieve the same behaviour. Recent physiological ﬁndings are

suggesting two new paradigms. Firstly, the visual system uses both local and global features in its recognition

function. Secondly, the brain uses a distributed processing architecture to learn information from multiple

modalities. In this paper we combine these paradigms and propose a distributed information integration model

called D-Net to improve scale-invariant classiﬁcation of images. We use a CNN to extract local features and,

inspired by Google’s INCEPTION model, develop a trainable method using ﬁlter pyramids to extract global

features called Filter Pyramid Convolutions (FPC). D-Net locally processes CNN and FPC features, fuses the

outcomes and obtains a global estimate via the central processor. We test D-Net on classiﬁcation of scaled

images on benchmark datasets. Our results show D-Net’s potential effectiveness towards classiﬁcation of

scaled images.

1 INTRODUCTION

Evolution has made our vision system a state-of-the-

art biological object detector, recognition engine and

classiﬁer. This allows us to perform with ease sev-

eral vision tasks such as object detection, classiﬁca-

tion and recognition. Even if the appearance of the

object of interest in a scene has changed for exam-

ple in terms of its relative size and position our vi-

sual system still achieves a high recognition accu-

racy. Making computer vision algorithms achieve bi-

ological vision-like behaviour has resulted in various

techniques such as the Convolutional Neural Network

(CNN) (LeCun et al., 1998). Since then CNNs have

achieved great success in numerous computer vision

tasks. However, the generalisation capability of CNN

diminishes when classifying objects that are altered

by transformations such as translations, scaling, rota-

tion and reﬂection (Jaderberg et al., 2015; Kauderer-

Abrams, 2017; Lenc and Vedaldi, 2015).

Recent physiological ﬁndings are suggesting two

new paradigms. Firstly, the visual system uses both

local and global features in its recognition function

https://orcid.org/0000-0003-4693-0097

https://orcid.org/0000-0002-9856-4685

(Huang et al., 2017; Su et al., 2009). Local fea-

ture information is used where global features can-

not be determined. Here global features are not the

same as global features obtained by aggregating lo-

cal features from CNN models. Secondly instead of a

dedicated multi-sensory integration brain area, there

exists many multisensory brain areas that simultane-

ously process information from multiple modalities

(Zhang et al., 2016b). This suggests our neural sys-

tem uses a distributed information processing and in-

tegration architecture to learn information from dif-

ferent modalities. These paradigms provide the po-

tential for improving transformation invariance prob-

lems in CNNs.

In this paper we combine these paradigms and

propose a distributed information integration model

for CNNs called D-Net. D-Net allows us to test these

paradigms by locally processing local and global fea-

tures of test images and then centrally processing the

outcomes of local processors. We use a CNN to ex-

tract local features. In order to extract global fea-

tures, we apply the concept of large ﬁlters (kernels)

to spatially cover broader areas of an image (Peng

et al., 2017). We achieve this by creating a convolu-

tion layer with pyramids of stacked ﬁlters (ﬁlter pyra-

Kumar, D. and Sharma, D.

Distributed Information Integration in Convolutional Neural Networks.

DOI: 10.5220/0009150404910498

In Proceedings of the 15th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2020) - Volume 5: VISAPP, pages

491-498

ISBN: 978-989-758-402-2; ISSN: 2184-4321

491

mids) of different sizes similar to Google’s INCEP-

TION model (Szegedy et al., 2015). Through the

process of convolution these ﬁlters generate multi-

scale features maps. These feature maps are down-

sampled via pooling and used as global features. We

use max pooling as research indicates max pooling

help achieve some translation and rotation invariance

(Xu et al., 2014) in CNNs. In our work we refer to

this layer as Filter Pyramid Convolution (FPC) layer.

We test D-Net on classiﬁcation of scaled images on

benchmark datasets. Our results show D-Net outper-

forms traditional CNN on raw train and test statistics.

D-Net also shows promising results in classiﬁcation

of scaled images.

The main contributions of this paper are to im-

prove CNNs towards classiﬁcation of scaled images

by showing the effectiveness of a) using both global

and local features as different aspects of information

for an image and b) applying the distributed process-

ing architecture of the neural system in the artiﬁcial

CNN.

The rest of the paper is organised as follows: Sec-

tion 2 reviews related work while Section 3 introduces

our model. Section 4 describes our experiment design

and results are presented in Section 5. We summarise

and point to future directions in Section 6.

2 BACKGROUND

Given our research is related to topics on global fea-

ture extraction using CNNs, the distributed informa-

tion integration architecture of the biological neural

system and ﬁlter and feature pyramid based design of

CNNs, we cover review them brieﬂy in the following

sub-sections.

Global Features: Experiments on behaving mon-

keys by (Huang et al., 2017) showed detecting a dis-

tinction or change in the global feature (such as a

hole in a circle) was faster than detecting a distinc-

tion or change in a local feature (solid shapes such

as a circle). This means the visual system uses spa-

tial and semantic information present in global fea-

tures to identify objects prior to using local features

(Park and Lee, 2016). In some studies, global fea-

tures have been applied in CNNs but are limited to

using feature descriptors such as histogram of gradi-

ents (HOG) (Zhang et al., 2016a). In another work,

SIFT is combined with CNN (Zheng et al., 2017) but

we note SIFT is classiﬁed as a local feature descriptor

instead. An examination of how pre-trained Alex-Net

and VGG-19 networks process local and global fea-

tures is presented in (Zheng et al., 2018). These meth-

ods however have not been tested on how the network

handles scaled images.

Distributed Information Integration: Anatomical

evidence and experimental observations on the func-

tioning of neural systems suggest the existence of

dense clusters of neurons referred to as multisensory

brain areas (Tononi and Edelman, 1998). To process

different aspects of information about the same en-

tity, a combined effort of several multisensory brain

areas is needed (Zhang et al., 2016b; Ma and Pouget,

2008). Thus, the integration of information from

multisensory brain areas form a reliable description

of an underlying object of interest. (Zhang et al.,

2016b) describe three principle architectures namely

central, distributed and decentralised. We adopt the

distributed architecture (Figure 1) in our work where

we introduce multiple processing areas in the form of

fully connected neural networks. We also show with

some evidence the effectiveness of this design on clas-

siﬁcation of scaled images. Here our design contrasts

with designs of most CNNs which use a dedicated

multisensory integration area in the form of a single

fully connected neural network.

A notable model to handle transformation invari-

ance in CNNs is proposed by (Jaderberg et al., 2015)

called Spatial Transformer networks. This model is

built using 3 major components called a localisation

network, grid generator and sampler to spatially trans-

forms feature maps. The localisation network in the

model contains a feed-forward network which gen-

erates and learns the parameters of the spatial trans-

formation that should be applied to the input feature

map. A limitation of this technique is that it limits the

number of objects that can be modelled in the feed-

forward network. We refer to this work as another

evidence of the use of small networks embedded with

the CNN pipeline.

Filter Pyramid: Neuroscience models by (Poggio

et al., 2014; Han et al., 2017; Dicarlo et al., 2012)

essentially describe the vision system as having a

conical neuronal architecture with increasing recep-

tive ﬁeld sizes in the form of an inverted pyramid of

neurons. Visual stimuli processed by each horizontal

slice of the neuronal pyramid allows the visual system

to become robust to scale changes. Inspired by these

models the approach of using differently sized convo-

lutional ﬁlters in parallel to capture more context is in-

creasingly being explored by researchers (Gong et al.,

2014; Zagoruyko and Komodakis, 2015). Google’s

INCEPTION family of models uses this approach

(Szegedy et al., 2015; Szegedy et al., 2016; Szegedy

et al., 2017). Based on the INCEPTION model simi-

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

492

Central

processor

Local

processor

Local

processor

Local

sensor

Local

sensor

Stimulus

global estimate

(a) (b)

Figure 1: Distributed architecture adopted from (Zhang

et al., 2016b). Dedicated local processors in each pipeline

((a) and (b)) compute local estimates which are then inte-

grated by a central processor to obtain a global estimate.

lar models are proposed in (Liao and Carneiro, 2015;

Wang et al., 2019). The FPC layer in D-Net adopts a

similar approach as in the INCEPTION model. How-

ever what makes FPC different when compared to the

original INCEPTION model (Szegedy et al., 2015)

is a) FPC is uses much larger ﬁlters, b) is designed

to operate on input images directly to capture global

features and c) before ﬁlter concatenation, outputs

from large ﬁlters are selectively maxpooled to gen-

erate uniform-sized feature maps. In a similar fash-

ion, the use of maxpooling at the end of each par-

allel multi-scale pipeline makes FPC different when

compared with competitive INCEPTION model and

competitive multi-scale convolution model (Liao and

Carneiro, 2015). In addition, FPC does not use Max-

out (Goodfellow et al., 2013). Figure 2 shows the

comparison of FPC with the INCEPTION family of

models.

Image and Feature Pyramid: Pyramid based

methods used to address scale-invariance in CNNs

and can be categorised into image pyramids and fea-

ture map pyramids. For example, an image pyramid-

based method is proposed by (Kanazawa et al., 2014)

where they apply the same kernels on multi-scaled

version of the target image. In another work (Xu

et al., 2014) propose a scale-invariant CNN (SiCNN)

by applying a similar process of convolving a ﬁlter

on different image scales. (Lin et al., 2017) in their

work develop lateral connections between the feature

maps that are generated in deep convolutional net-

works through successive convolution and maxpool-

ing operations. They argue connections between fea-

ture maps establish scale-invariance in the network as

a change in an object’s scale is offset by shifting its

level in the pyramid. (Kim et al., 2018; Zhao et al.,

2019; Kong et al., 2018; Yu et al., 2018) propose

similar architectures. A commonality in these archi-

tectures is that features from different resolutions are

fused by either concatenation or summation. What

makes FPC different is that features from different

resolutions are normalised by mandatory maxpooling

operations except for the smallest-sized block of fea-

ture maps.

(a) Original inception module

1x1 convolutions 3x3 max pooling

5x5 convolutions

Filter

concatenation

Previous layer

1x1 convolutions

3x3 convolutions

1x1 convolutions 1x1 convolutions

(b) Competitive inception module

3x3 convolutions

3x3 max pooling

Batch

normalisation

Maxout

Previous layer

5x5 convolutions

Batch

normalisation

Batch

normalisation

1x1 convolutions

Batch

normalisation

3x3 convolutions

Batch

normalisation

Maxout

Previous layer

5x5 convolutions

Batch

normalisation

Batch

normalisation

1x1 convolutions

Batch

normalisation

7x7 convolutions

(d) FPC module

15x15

convolutions

2x2 max pooling

Feature

concatenatation

Input image

21x21

convolutions

3x3 max pooling

4x4 max pooling

9x9 convolutions

27x27

convolutions

Figure 2: Comparison of FPC with INCEPTION family of

models (Szegedy et al., 2015; Liao and Carneiro, 2015).

3 MODEL

In this section we propose a novel neural network

model called D-Net that combines local features from

CNN and global features from FPC. The design of D-

Net is inspired by a) (Huang et al., 2017) who show

that biological visual system utilizes global features

Distributed Information Integration in Convolutional Neural Networks

493

CNN [Convolution + ReLU + Maxpool]

(a) LOCAL FEATURE EXTRACTOR

Multisensory processor

Final

classification

Local processor

classifications

Input image

(d)

(c)

Global features vector

CNN features vector

Local processor

classifications

(b) GLOBAL FEATURE EXTRACTOR

filters

features

downsampled

features

FPC [Filter Pyramids Convolution]

(f) CENTRAL PROCESSOR

LOCAL PROCESSOR

(e)

FLATTEN

Figure 3: Architecture of D-Net which is explained in Section 3.

prior to local features in detection and recognition, b)

(Poggio et al., 2014) who show the conical architec-

ture of the visual system contains neurons packed in

groups of different sizes in the form of an inverted

pyramid of neurons and c) (Zhang et al., 2016b) who

describe the distributed information integration archi-

tecture of the neural system. The ensemble D-Net

model comprises of six main parts ((a)-(f)) as shown

in Figure 3. They are explained in the following sub-

sections.

3.1 Distributed Information Integration

Model for CNNs (D-Net)

Dual Pipeline Architecture: The hallmark of D-

Net is the dual channel pipeline in its architecture

that enables integration of local processors and merg-

ing outputs in the central processor. The parallel

pipelines are dedicated to extracting global and local

features respectively. This design makes D-Net dif-

ferent from multi-scale parallel processing channels

in CNNs such as in the INCEPTION family of models

(Figure 2). Such models use a single linear feedfor-

ward processing channel despite the multi-scale chan-

nels. D-Net allows examination of input image data in

two different aspects, in terms of its local and global

features.

Local Feature Extractor: D-Net uses standard

CNN as local feature extractor method. The operation

of the CNN processes input image through several

successive convolution, ReLU and maxpooling lay-

ers. The major advantage of CNN is the ability to pro-

cess large datasets and extract features automatically,

hence eliminating the need to manually extract fea-

tures for learning. CNN uses lower layers to extract

features such as lines and curves, while higher level

features may identify shapes relevant to the dataset

such as actual digits, faces or natural objects. As such

CNNs are widely used in image and video processing.

Global Feature Extractor (FPC): The FPC layer

in D-Net contains multiple stacks of ﬁlters of vary-

ing sizes. This forms a pyramidal structure of stacked

ﬁlters similar to the biological structure of the visual

system proposed in (Poggio et al., 2014) and the IN-

CEPTION model (Szegedy et al., 2015). The dimen-

sions ((k

, k

), (k

, k

), ...,(k

, k

)) of each ﬁlter in

the stack is manually chosen where n is the number

of ﬁlters in a stack and (k

, k

) is the largest ﬁlter. In

addition, the size of each ﬁlter in the stack is deter-

mined by the output size of its resultant feature map

(( f

, f

), ( f

, f

), ..., ( f

, f

)) and where dimensions

of feature maps ( f

, ..., f

) can be become equal to f

when pooled by an integer factor. Subsequently, sizes

of other ﬁlters are identiﬁed using a similar process.

For downscaling we use the technique of maxpooling.

Local Processor: In D-Net we use fully connected

neural networks as local processors. The goal of lo-

cal processor is to assimilate information ﬂowing into

it from each channel independently. In this way we

can decentralise the learning of local and global fea-

tures and obtain a reliable description for the underly-

ing object of interest (image) in terms of information

from the two modalities.

Global Processor: Information integration is facil-

itated by the central processor in D-Net. Here we

represent the central processor by a fully connected

neural network. Inputs in terms of local estimates

from local processors feed into the central processor

and are integrated to reach the ﬁnal global estimate.

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

494

The probabilistic outputs from the central processor

become the ﬁnal classiﬁcation results of D-Net.

3.2 D-Net Forward Propagation

Our goal is to combine extracted features from CNN

and FPC for learning in distributed local processors

and integrate the outcomes in the central processor.

To achieve the forward pass function, an input image

is processed in the local (CNN) and global feature ex-

tractor (FPC) pipelines respectively. The CNN part

of the network obtains local-global features as output.

Meanwhile in FPC, multi-scale ﬁlters produce multi-

scale outputs. They are pooled to generate a set of

uniform-sized downsampled feature maps which are

concatenated and returned as ﬁnal outputs of FPC.

Both CNN and FPC outputs are then forward propa-

gated through the respective local processors. Finally,

classiﬁcation outputs from local processors are com-

bined and reshaped into a vector form in the ﬂatten

layer (Figure 3 (e)). This vector forms the input to

fully connected neural network central processor in

D-Net (Figure 3 (f))

3.3 D-Net Backward Propagation

Model loss is calculated on the outputs of the central

processor. The backward function in the ﬂatten layer

receives gradients from the central processor. Since

there are two pipelines in D-Net, the ﬂatten layer re-

turns two sets of gradients - CNN gradients and FPC

gradients. The backward function in FPC layer takes

the FPC gradients and updates the multi-scale ﬁlter

weights in the respective ﬁlter pyramids. In a similar

fashion CNN gradient are back propagated in the lo-

cal feature extractor pipeline using chain rule deriva-

tive algorithm as well.

4 THE EXPERIMENTS

We describe the datasets, D-Net model component ar-

chitectures and our experimental design in the follow-

ing sub-sections.

4.1 Dataset Descriptions

We test D-Net on both color and grey-scale images. In

practice color images are preferred, however we wish

to ascertain the effectiveness of D-Net on both. For

color images we use the CIFAR10 dataset (described

in (Krizhevsky et al., 2009)). For grey-scale images

we use the Fashion-MNIST dataset (FMNIST) (de-

scribed in (Xiao et al., 2017)). Both datasets have 10

Table 1: Architecture of FPC in D-Net.

# of pyramids 16

# of ﬁlters in pyramid 4

On CIFAR10 dataset

Sizes of ﬁlters in pyramid

(9x9), (15x15),

(21x21), (27x27)

Final Output size (64x6x6)

On FMNIST dataset

Sizes of ﬁlters in pyramid

(5x5), (11x11),

(17x17), (23x23)

Final Output size (64x6x6)

classes and have equal distribution of samples in each

class.

4.2 CNN and FPC Architectures

CNN: For benchmarking and local feature extrac-

tor part of D-Net we used LeNet5 CNN structure as

proposed by (LeCun et al., 1998).

FPC Parameters: Table 1 describes the architec-

ture of FPC in terms of ﬁlter sizes in each ﬁlter pyra-

mid and the number of ﬁlter pyramids used. Since

the dimensions of images in CIFAR10 and FMNIST

dataset are different, ﬁlter sizes are adjusted accord-

ingly.

Local and Central Processor Networks: Table 2

describes the layers present in our distributed process-

ing modules. The fully connected neural networks

comprise of two hidden layers. This is in line with

suggestions by (Heaton, 2008) that a) two hidden lay-

ers can represent functions with any kind of shape

and b) the optimal size of the hidden layer is recom-

mended to be between the size of its input and output.

4.3 Training Process

End-to-end training was performed on all models.

For networks trained on both CIFAR10 and FMNIST

datasets we start with a warm-up strategy for 4 epochs

with a learning rate of 10

−2

, 10

−3

from epochs 5 −50

and decreasing it to 10

−4

for the rest of training.

Training on all models were stopped at 100 epochs.

Stochastic gradient decent and cross-entropy were

used as learning and loss function respectively. We

use weight decay of 10

−4

and momentum of 0.9. For

training we use batch size of 8 and 4 for testing. We

implement our models using PyTorch version 1.2.0 on

a Dell Optiplex i5 48GB RAM computer with Cuda

support using NVIDIA GeForce GTX 1050 Ti 4GB

graphics card.

Distributed Information Integration in Convolutional Neural Networks

495

Table 2: Layers in the distributed information processors.

Processor Layers

Local (c)

(fc 480) → (relu) → (fc 84) →

(relu)

Local (d)

(fc 2304) → (relu) → (fc 400) →

(relu)

Central (f)

(fc 20) → (relu) → (fc 12) →

(softmax)

Figure 4: An example of scaled test image from datasets CI-

FAR10 - airplane (top) and FMNIST - ankle boot(bottom).

The numbers indicate percentage image is scaled to. 100

indicates no scaling.

4.4 Scaled Images for Testing

We establish 7 scale categories -

[150, 140, 120, 100, 80, 60, 50] to test our models.

The numbers indicate percentage an image is scaled

to. In this paper we consider both reduction and

enlargement of image size from the original. We

select at random 100 images per class from the

datasets. These images are scaled as per the scale

category percentages. In this fashion for a single

test image of a class we generate 7 scaled test

images amounting to 1000 scaled images per scale

category. We further combine images from all 7 scale

categories into an ensemble scale dataset resulting

in 7000 scaled images combined. We analyse our

models on scaled images from each of these scale

categories independently (Section 5.2) as well as on

the ensemble dataset. Figure 4 shows an example

image from each dataset and its corresponding scaled

versions for testing.

4.5 Evaluation Metrics

We use metrics accuracy to analyse results of D-Net

on scale categories. Accuracy is an intuitive perfor-

mance measure to simply evaluate the generalisation

capability D-Net by ﬁnding out the total number of

scaled images that were correctly classiﬁed in the re-

spective scale categories.

5 RESULTS AND DISCUSSION

5.1 Comparing Train and Test Statistics

on Regular Images

Table 3 compares the train losses and test accuracy

for all networks used in our experiments on regu-

lar images from the test datasets. These are evalua-

tions on images that have not been subjected to any

form of scale transformations. Our ensemble D-Net

model outperforms the traditional LeNet5 network

on all train and test metrics (indicated in bold). We

record lower train losses on D-Net networks on both

datasets. The highest test accuracy increases of 5.3%

is recorded on D-Net combining LeNet5 and FPC on

CIFAR10 dataset. Similarly, we record a 1.0% in-

crease in test accuracy on FMNIST dataset. These

baseline results provide some evidence that combin-

ing global feature information in network training is

useful in improving the overall generalisation capa-

bility of the models studied, more so on color images.

5.2 Improvements on Classiﬁcation of

Scaled Images

The classiﬁcation results of our models on differ-

ent scale categories and on different datasets can be

viewed in Table 4. The column hit-rate indicates

the number of scale categories D-Net outperformed

the benchmark. For purposes of our study hit-rate of

>= 60% is desirable, that is D-Net should at least per-

form better on 60% of the scale categories compared

to the benchmark LeNet5 only network. Since the en-

semble test dataset combines all scaled images in one

batch it is excluded from this ratio. Classiﬁcations ac-

curacies are obtained by testing the studied models on

scaled images from each scale category. Our results

show D-Net using LeNet5 with FPC performed better

on most scale categories, where hit rate achieved is

greater than 60% on both datasets. This means D-Net

was able to identify a high number of samples from

most scale bins in it correct class despite the images

being scale transformed.

We compare accuracy scores of D-Net

with LeNet5 on upscaled images (categories

150, 140, 120). For these categories on CIFAR10

dataset average D-Net accuracy score is 5.0% higher

than LeNet5. A similar performance of D-Net over

LeNet5 on FMNIST dataset is shown where average

accuracy is 1.5% higher. Comparing accuracy scores

on downscaled images (categories 80, 60, 50), we

note promising performance of D-Net over LeNet5

on both datasets. Here average accuracy score is

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

496

Table 3: Train losses and test accuracy for all models used in our experiments.

Model

train loss

CIFAR10

test acc

CIFAR10

difference

train loss

FMNIST

test acc

FMNIST

difference

LeNet5 1.734 0.568 1.535 0.899

D-Net 1.692 0.621

-0.042 (loss)

+5.3% (acc)

1.527 0.909

-0.008 (loss)

+1.0% (acc)

Table 4: Performance summarization (accuracy) of the studied models on all the scale categories.

scale categories

Model metric ensemble 150 140 120 100 80 60 50

hit rate

CIFAR10 dataset

LeNet5

acc

0.381 0.449 0.478 0.531 0.577 0.265 0.217 0.149

D-Net 0.419 0.481 0.532 0.594 0.637 0.277 0.214 0.195

0.857 (6/7)

FMNIST dataset

LeNet5

acc

0.611 0.575 0.654 0.785 0.895 0.703 0.373 0.295

D-Net 0.629 0.570 0.685 0.804 0.922 0.712 0.410 0.303

0.857 (6/7)

higher by 1.8% and 2.0% in favour of D-Net on

CIFAR10 and FMNIST datasets respectively. Scale

category 100 is where images are in their original

state (unscaled). In this category test accuracy of

D-Net surpasses benchmark LeNet5 by 6.0% on

CIFAR10 dataset and by 2.7% on FMNIST dataset.

Further, higher D-Net accuracy scores over

LeNet5 are recorded on all combined scaled images

in the ensemble test dataset. In this the best D-Net

performance is shown on CIFAR10 dataset where ac-

curacy is higher by 3.8% than LeNet5. This equates

to 266 more images classiﬁed correctly from the total

7000 samples in the ensemble dataset compared to

LeNet5 only network.

From the above analysis we arrive at two obser-

vations. First, distributed information processing and

integration has a positive impact on improving CNNs

ability to classify scaled images. Second, we note in

general accuracy scores of both D-Net and LeNet5

decline as images are blown-up as well as reduced

in size. In other words, the classiﬁcation accuracy

of images closer to original image dimensions are

higher. This shows CNN based architectures are task

speciﬁc where they perform well when deviations in

test images from the learnt samples are small.

6 CONCLUSION

In this paper we propose a novel model to improve

classiﬁcation of scaled images in CNNs by fusing

global and local features in a distributed information

integration neural network architecture called D-Net.

We study the effects of using global features on im-

age classiﬁcation by combining FPC and CNN fea-

tures and testing on scaled images. Our experimen-

tal results indicate using distributed information inte-

gration architecture with CNNs is an effective way to

combine information from different modalities. We

conclude adding global feature information in CNN

models are beneﬁcial in addressing scaled images.

Problems and opportunities that require further in-

vestigations are a) to evaluate other downsampling

methods in FPC such as using interpolation instead of

max pooling, b) test this technique to evaluate other

forms of transformations such as rotations and trans-

lations, c) apply FPC layer with other benchmark

network conﬁgurations using larger and more com-

plex datasets and d) experiment distributed proces-

sors with other classiﬁers such as Support Vector Ma-

chines (SVM). Finally making CNNs learn features

which are invariant to transformation remains a chal-

lenge and thus requires further investigation.

REFERENCES

Dicarlo, J., Zoccolan, D., and C Rust, N. (2012). How does

the brain solve visual object recognition? Neuron,

73:415–34.

Gong, Y., Wang, L., Guo, R., and Lazebnik, S. (2014).

Multi-scale orderless pooling of deep convolutional

activation features. In European conference on com-

puter vision, pages 392–407. Springer.

Goodfellow, I. J., Warde-Farley, D., Mirza, M., Courville,

A., and Bengio, Y. (2013). Maxout networks. arXiv

preprint arXiv:1302.4389.

Han, Y., Roig, G., Geiger, G., and Poggio, T. A. (2017).

Is the human visual system invariant to translation

and scale? In 2017 AAAI Spring Symposia, Stanford

University, Palo Alto, California, USA, March 27-29,

2017.

Heaton, J. (2008). Introduction to Neural Networks for

Distributed Information Integration in Convolutional Neural Networks

497

Java, 2Nd Edition. Heaton Research, Inc., 2nd edi-

tion.

Huang, J., Yang, Y., Zhou, K., Zhao, X., Zhou, Q., Zhu, H.,

Yang, Y., Zhang, C., Zhou, Y., and Zhou, W. (2017).

Rapid processing of a global feature in the on visual

pathways of behaving monkeys. Frontiers in Neuro-

science, 11:474.

Jaderberg, M., Simonyan, K., Zisserman, A., and

Kavukcuoglu, K. (2015). Spatial transformer net-

works. In Cortes, C., Lawrence, N. D., Lee, D. D.,

Sugiyama, M., and Garnett, R., editors, Advances

in Neural Information Processing Systems 28, pages

2017–2025. Curran Associates, Inc.

Kanazawa, A., Sharma, A., and Jacobs, D. W. (2014). Lo-

cally scale-invariant convolutional neural networks.

CoRR, abs/1412.5104.

Kauderer-Abrams, E. (2017). Quantifying translation-

invariance in convolutional neural networks. arXiv

preprint arXiv:1801.01450.

Kim, S.-W., Kook, H.-K., Sun, J.-Y., Kang, M.-C., and Ko,

S.-J. (2018). Parallel feature pyramid network for ob-

ject detection. In Proceedings of the European Con-

ference on Computer Vision (ECCV), pages 234–250.

Kong, T., Sun, F., Tan, C., Liu, H., and Huang, W. (2018).

Deep feature pyramid reconﬁguration for object de-

tection. In Proceedings of the European Conference

on Computer Vision (ECCV), pages 169–185.

Krizhevsky, A., Hinton, G., et al. (2009). Learning multiple

layers of features from tiny images. Technical report,

Citeseer.

LeCun, Y., Bottou, L., Bengio, Y., Haffner, P., et al. (1998).

Gradient-based learning applied to document recogni-

tion. Proceedings of the IEEE, 86(11):2278–2324.

Lenc, K. and Vedaldi, A. (2015). Understanding image

representations by measuring their equivariance and

equivalence. CVPR.

Liao, Z. and Carneiro, G. (2015). Competitive multi-scale

convolution. arXiv preprint arXiv:1511.05635.

Lin, T.-Y., Doll

ar, P., Girshick, R., He, K., Hariharan, B.,

and Belongie, S. (2017). Feature pyramid networks

for object detection. In Proceedings of the IEEE con-

ference on computer vision and pattern recognition,

pages 2117–2125.

Ma, W. J. and Pouget, A. (2008). Linking neurons to be-

havior in multisensory perception: A computational

review. Brain research, 1242:4–12.

Park, H. and Lee, K. M. (2016). Look wider to match im-

age patches with convolutional neural networks. IEEE

Signal Processing Letters, 24(12):1788–1792.

Peng, C., Zhang, X., Yu, G., Luo, G., and Sun, J. (2017).

Large kernel matters–improve semantic segmentation

by global convolutional network. In Proceedings of

the IEEE conference on computer vision and pattern

recognition, pages 4353–4361.

Poggio, T. A., Mutch, J., and Isik, L. (2014). Computational

role of eccentricity dependent cortical magniﬁcation.

CoRR, abs/1406.1770.

Su, Y., Shan, S., Chen, X., and Gao, W. (2009). Hierar-

chical ensemble of global and local classiﬁers for face

recognition. IEEE Transactions on image processing,

18(8):1885–1896.

Szegedy, C., Ioffe, S., Vanhoucke, V., and Alemi, A. A.

(2017). Inception-v4, inception-resnet and the impact

of residual connections on learning. In Thirty-First

AAAI Conference on Artiﬁcial Intelligence.

Szegedy, C., Liu, W., Jia, Y., Sermanet, P., Reed, S.,

Anguelov, D., Erhan, D., Vanhoucke, V., and Rabi-

novich, A. (2015). Going deeper with convolutions.

In Proceedings of the IEEE conference on computer

vision and pattern recognition, pages 1–9.

Szegedy, C., Vanhoucke, V., Ioffe, S., Shlens, J., and Wo-

jna, Z. (2016). Rethinking the inception architecture

for computer vision. In Proceedings of the IEEE con-

ference on computer vision and pattern recognition,

pages 2818–2826.

Tononi, G. and Edelman, G. M. (1998). Consciousness and

complexity. science, 282(5395):1846–1851.

Wang, H., Kembhavi, A., Farhadi, A., Yuille, A. L., and

Rastegari, M. (2019). Elastic: Improving cnns with

dynamic scaling policies. In Proceedings of the IEEE

Conference on Computer Vision and Pattern Recogni-

tion, pages 2258–2267.

Xiao, H., Rasul, K., and Vollgraf, R. (2017). Fashion-

mnist: a novel image dataset for benchmarking ma-

chine learning algorithms. Technical report, arXiv.

Xu, Y., Xiao, T., Zhang, J., Yang, K., and Zhang, Z. (2014).

Scale-invariant convolutional neural networks. CoRR,

abs/1411.6369.

Yu, F., Wang, D., Shelhamer, E., and Darrell, T. (2018).

Deep layer aggregation. In Proceedings of the IEEE

Conference on Computer Vision and Pattern Recogni-

tion, pages 2403–2412.

Zagoruyko, S. and Komodakis, N. (2015). Learning to com-

pare image patches via convolutional neural networks.

In Proceedings of the IEEE conference on computer

vision and pattern recognition, pages 4353–4361.

Zhang, T., Zeng, Y., and Xu, B. (2016a). Hcnn: A neu-

ral network model for combining local and global fea-

tures towards human-like classiﬁcation. International

Journal of Pattern Recognition and Artiﬁcial Intelli-

gence, 30(01):1655004.

Zhang, W.-H., Chen, A., Rasch, M. J., and Wu, S. (2016b).

Decentralized multisensory information integration in

neural systems. Journal of Neuroscience, 36(2):532–

547.

Zhao, Q., Sheng, T., Wang, Y., Tang, Z., Chen, Y., Cai, L.,

and Ling, H. (2019). M2det: A single-shot object de-

tector based on multi-level feature pyramid network.

In Proceedings of the AAAI Conference on Artiﬁcial

Intelligence, volume 33, pages 9259–9266.

Zheng, L., Yang, Y., and Tian, Q. (2017). Sift meets cnn:

A decade survey of instance retrieval. IEEE trans-

actions on pattern analysis and machine intelligence,

40(5):1224–1244.

Zheng, Y., Huang, J., Chen, T., Ou, Y., and Zhou, W. (2018).

Processing global and local features in convolutional

neural network (cnn) and primate visual systems. In

Mobile Multimedia/Image Processing, Security, and

Applications 2018, volume 10668, page 1066809. In-

ternational Society for Optics and Photonics.

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

498
