Localizing Visitors in Natural Sites Exploiting

Modality Attention on Egocentric Images and GPS Data

Giovanni Pasqualino

1,∗

, Stefano Scaﬁti

1,∗

, Antonino Furnari

and Giovanni Maria Farinella

1,2

Department of Mathematics and Computer Science, University of Catania, Catania, Italy

Cognitive Robotics and Social Sensing Laboratory, ICAR-CNR, Palermo, Italy

Keywords:

Egocentric (First Person) Vision, Localization, GPS, Multi-modal Data Fusion.

Abstract:

Localizing the visitors of an outdoor natural site can be advantageous to study their behavior as well as to

provide them information on where they are and what to visit in the site. Despite GPS can generally be used

to perform outdoor localization, we show that this kind of signal is not always accurate enough in real-case

scenarios. On the contrary, localization based on egocentric images can be more accurate but it generally

results in more expensive computation. In this paper, we investigate how fusing image- and GPS-based pre-

dictions can allow to achieve efﬁcient and accurate localization of the visitors of a natural site. Speciﬁcally, we

compare different fusion techniques, including a modality attention approach which is shown to provide the

best performances. Results point out that the proposed technique achieve promising results, allowing to obtain

the performances of very deep models (e.g., DenseNet) with a less expensive architecture (e.g., SqueezeNet)

which employ a memory footprint of about 3MB and an inference speed of about 25ms.

1 INTRODUCTION

Smart wearable and mobile devices equipped with a

camera and a display offer a convenient platform to

improve the fruition of indoor cultural sites such as

art galleries and museums (Cucchiara and Del Bimbo,

2014; Seidenari et al., 2017), outdoor urban places

such as cities (Alkhafaji et al., 2019; Alletto et al.,

2016), as well as outdoor natural environments such

as parks and gardens (Milotta et al., 2019a; Milotta

et al., 2019b). Notably, smart glasses allow to ex-

plore the cultural site and receive additional infor-

mation and services through augmented reality in a

“hands-free” fashion. At the same time, such devices

allow to effortlessly collect visual information about

the behavior of the user which, if properly analyzed,

can provide value to the site manager (Farinella et al.,

2019). In particular, the continuous localization of

the camera wearers allows to provide the visitors with

a “where am I” service, which can be useful to help

them navigate the site and provide additional informa-

tion on the current area or alternative routes to visit.

At the same time, a “where are they” service can be

provided to the site manager to help locate all visitors

to understand which areas are the most visited and

where people tend to spend more time.

∗

These authors are co-ﬁrst authors.

Figure 1: In the considered scenario, users are localized in

a natural site using both egocentric images and GPS data.

The natural site is divided into non-overlapping areas and

localization is addressed as a classiﬁcation problem.

Most previous works focused on recognizing

scene context (Battiato et al., 2008) and on localizing

the visitors in indoor scenarios (Giuliano et al., 2014;

Ragusa et al., 2019; Farinella et al., 2019), whereas

the localization of users in outdoor natural sites has

been relatively less investigated (Milotta et al., 2019a;

Milotta et al., 2019b). While GPS can be generally

exploited for localization in outdoor contexts, previ-

ous works (Milotta et al., 2019a; Milotta et al., 2019b)

have shown that this is not always the case due to

the limited accuracy of consumer GPS receivers, es-

pecially in natural scenarios in which the sky might

be covered by trees. In particular, in (Milotta et al.,

2019a) it has been shown that localizing the visitors

from egocentric images is much more accurate than

using GPS. The work of (Milotta et al., 2019b) further

Pasqualino, G., Scaﬁti, S., Furnari, A. and Farinella, G.

Localizing Visitors in Natural Sites Exploiting Modality Attention on Egocentric Images and GPS Data.

DOI: 10.5220/0009103906090617

In Proceedings of the 15th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2020) - Volume 5: VISAPP, pages

609-617

ISBN: 978-989-758-402-2; ISSN: 2184-4321

609

investigated how combining a shallow Convolutional

Neural Network (CNN) for image-based localization

with a simple decision tree to process GPS data can

allow to obtain a good localization accuracy at a low

computational cost, which is a key factor when the

system has to be deployed in the embedded settings

imposed by wearable devices.

In this paper, we consider the problem of localiz-

ing the visitors of natural sites from egocentric images

and GPS. As proposed in previous investigations (Ra-

gusa et al., 2019; Milotta et al., 2019a; Milotta et al.,

2019b), in the considered scenario, the natural site

is divided into non-overlapping areas and localiza-

tion is addressed as a classiﬁcation problem (see Fig-

ure 1). To carry out the investigation, we rely on the

dataset proposed in (Milotta et al., 2019a). Similarly

to (Milotta et al., 2019a; Milotta et al., 2019b) we

consider a multi-modal architecture which processes

images and GPS data using specialized branches.

While (Milotta et al., 2019a; Milotta et al., 2019b)

rely on late fusion to combine the predictions of the

different branches, we show that better results can be

achieved introducing a “modality attention” (Furnari

and Farinella, 2019) module, which uses intermedi-

ate representations from the two branches to compute

fusion weights. This allows the overall architecture

to “vote” for which modality is more to be trusted on

a sample-by-sample basis. We validate the proposed

approach by comparing it with the results reported

in (Milotta et al., 2019a; Milotta et al., 2019b), as well

as with several multi-modal fusion approaches based

on weighted late fusion, and “learned” late fusion.

The reminder of the paper is organized as follow-

ing. The related works are discussed in Section 2. The

compared localization approaches are detailed in Sec-

tion 3. Experimental settings and results are given in

Section 4. Section 5 concludes the paper.

2 RELATED WORKS

Previous works have investigated the use of computer

vision in natural environments. Kumar et al. (Kumar

et al., 2012) proposed a system which allows to iden-

tify 184 species of trees from pictures acquired using

a mobile application. Wegner et al. (Wegner et al.,

2016) introduced a framework for the recognition

of trees which leverages data collected from Google

street view. Horn et al. (Horn et al., 2017) proposed

the iNat2007 dataset, which contains images of about

8, 000 different species of plants collected in natural

environments. Joly et al. (Joly et al., 2017) introduced

the LifeCLEF dataset to address the investigation of

different tasks, including identiﬁcation of birds based

on audio, recognition of plants from images, vision-

based monitoring of organisms living in seas, and rec-

ommendation of species based on location. Milotta et

al. (Milotta et al., 2019a; Milotta et al., 2019b) intro-

duced a dataset of egocentric videos paired with GPS

measurements collected by different visitors in a nat-

ural site. A subset of video frames has been labeled

to specify the area of the natural site in which the vis-

itor was located during the acquisition. In particu-

lar, labels are provided at different granularity levels,

including high-level contexts and ﬁne-grained sub-

contexts. Localization has been hence addressed as a

classiﬁcation problem. The authors also investigated

localization from images and GPS using standard late

fusion techniques, showing how accurate localization

can be obtained at a low computational budget using

a shallow CNN processing images and a decision tree

processing GPS.

Our work builds on the investigation previously

proposed by Milotta et al. (Milotta et al., 2019a;

Milotta et al., 2019b). In particular, we show that the

use of a modality attention mechanism (Furnari and

Farinella, 2019) can improve localization accuracy

based on images and GPS. The proposed approach is

compared both computationally and in terms of accu-

racy with respect to the baselines proposed in (Milotta

et al., 2019a; Milotta et al., 2019b), which are outper-

formed.

3 METHODS

In this Section, we present the methods to address

the localization problem which have been compared

in this study. All considered approaches are classi-

ﬁers over m possible classes C = 1, . . . , m which take

as input either a pair of GPS coordinates x = (x, y)

collected using a GPS receiver, an egocentric image

I, or a pair (x, I) consisting in a sensed GPS loca-

tion x and an egocentric image I collected at the same

time. It is worth noting that, as it will be clear from

the experiments, the sensed GPS location tend to be

noisy. Hence, the task of learning a classiﬁer f (x)

from GPS data is not trivial. Indeed, we will show that

different methods based on GPS have different per-

formance. We will hence consider two main classes

of methods: 1) single-modal approaches, which per-

form localization by inferring the current class from

either the GPS location ( f (x) → ˆy ∈ C) or the egocen-

tric image ( f (I) → ˆy ∈C), 2) multi-modal approaches,

which infer the area in which the visitor is currently

located by processing both GPS locations and images

( f (x,I) → ˆy ∈ C). The following sections discuss the

details of the methods considered for the two families

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

610

Figure 2: Multilayer Perceptron architecture used to local-

ize the visitors based on GPS data.

of approaches.

3.1 Single-modal Localization based on

GPS Data or Egocentric Images

GPS: We used a multilayer perceptron which takes

a pair of GPS coordinates as input to infer in which

area the user is located. Speciﬁcally, the multilayer

perceptron is composed of ﬁve fully connected lay-

ers: one input layer, three hidden layers and one out-

put layer. All layers have the same activation function

(Relu) and each layer doubles the dimensionality of

the received input. The network has been trained for

30 epochs using the cross-entropy loss fuction. Batch

size has been set to 8, momentum to 0.9 and the learn-

ing rate to 0.001. The architecture is sketched in Fig-

ure 2.

Egocentric Images: We considered different CNN

architectures: ResNet (He et al., 2016), DenseNet

(Huang et al., 2017) and SqueezeNet (Iandola et al.,

2016). We also considered a shallow variant of

SqueezeNet obtained by truncating the network to the

ﬁrst 6 layer as proposed in (Milotta et al., 2019b).

We refer to this architecture as SqueezeNet-6. In all

cases, we consider the models pre-trained on Ima-

geNet (Deng et al., 2009). Each network is ﬁne-tuned

to predict the area in which the visitor is currently

located from an input egocentric image. The hyper-

parameters were set in the same way as the multi-

layer discussed in previous paragraph, only the batch

size was changed to 3. To assess the effect of fus-

ing two networks operating on the same modality, as

compared to multi-modal fusion, we also consider an

architecture which combines the two approaches as

depicted in Figure 3. The two vectors have a size

of 32 and represent the probability distribution over

the classes of the two networks. This two vectors are

concatenated and given as input of a multilayer per-

ceptron.

Figure 3: Combined CNNs Architecture.

3.2 Multi-modal Localization

Exploiting Images and GPS

We propose to perform multi-modal localization by

processing both images and GPS using a “modal-

ity attention” approach similar to the one proposed

in (Furnari and Farinella, 2019). This approach is

compared with respect to two baseline fusion meth-

ods: “weighted late fusion” and “learned late fusion”.

All these approaches assume that two modality-

speciﬁc branches are available. The “image branch”

takes as input an egocentric image I and out-

puts the conditional probability distribution p(c|I) =

(I). The “GPS branch” f

GPS

takes as input the

GPS coordinates x and outputs the conditional prob-

ability distribution p(c|x) = f

GPS

(x). In all our ex-

periments, f

is implemented as a CNN and f

GPS

is implemented as a multilayer perceptron. The dif-

ferent fusion approaches considered for comparisons

seek ways to fuse the two probability distributions, to

obtain a multi-modal prediction p(c|I, x).

Weighted Late Fusion: This approach computes

the multi-modal prediction p(c|I, x) by computing a

weighted average between the modality speciﬁc pre-

dictions:

p(c|I, x) = λ f

(I) + (1 − λ) f

GPS

(x) (1)

where λ ∈ [0, 1] is a fusion parameter which regu-

lates the trade-off between image-based predictions

and GPS-based predictions. In our experiments, the

two branches are trained independently (we have used

the model described in previous section) on their re-

spective modalities and the λ parameter is later tuned

with a grid search on the training set. Figure 4 illus-

trates the weighted late fusion architecture. It should

be noted that this fusion technique is a very standard

approach, as investigated in (Milotta et al., 2019a;

Milotta et al., 2019b).

Learned Late Fusion: The weighted late fusion ap-

proach might be limited by the fact that modality-

specifc predictions are aggregated with a simple lin-

ear combination. To allow the model to learn better

ways to combine the predictions, we explore “learned

Localizing Visitors in Natural Sites Exploiting Modality Attention on Egocentric Images and GPS Data

611

Figure 4: Weighted Late Fusion Architecture.

Figure 5: Learned Late Fusion Architecture.

late fusion” approach in which the outputs of the two

branches are concatenated and fed to a fusion network

f usion

which directly outputs the multi-modal predic-

tion: p(c|I, x) = f

f usion

( f


(I), f

GPS

(x)). We imple-

ment the fusion network as a multilayer perceptron

with three fully connected layers. Figure 5 illustrates

the learned late fusion architecture.

Modality Attention: While the learned late fusion

approach can in principle learn how to best combine

the modality-speciﬁc predictions, we observe that it

is more exposed to over-ﬁtting, due to the highly in-

creased number of parameters. On the contrary, the

simple weighted late fusion approach keeps a very

simple late fusion scheme but imposes the fusion

weights to be ﬁxed at inference time. Inspired by

recent work (Furnari and Farinella, 2019), we con-

sider a modality attention mechanism which com-

putes the late fusion weights on a sample-by-sample

basis. This allows for more ﬂexibility as the model

can learn to assign different weights to the different

modalities depending on the input samples. To obtain

the ﬁnal prediction, we ﬁrst consider some intermedi-

ate representations computed by the modality-speciﬁc

branches f


and f

GPS

. We will refer to those as


(I) and φ

GPS

(x). These representations are con-

catenated and fed to a Modality Attention (MATT)

network f

MATT

, which outputs two scores s

and

: s

, s

= f

MATT

(φ


(I), φ

GPS

(x)). The scores are

hence normalized using the Softmax function to ob-

Figure 6: Modality Attention Architecture.

tain suitable late fusion weights which sum to 1:

+ e

, w

+ e

. (2)

The computed weights are hence used to perform late

fusion as follows:

p(c|I, x) = w

· f


(I) + w

· f

GPS

(x) (3)

In our experiments, we extract the internal represen-

tations of the two branches just before the ﬁnal clas-

siﬁcation layers to obtain φ


(I) and φ

GPS

(x). The

modality attention network f

MATT

is implemented as

a multilayer perceptron with three fully connected

layers which each of them halves its input. To

maximize performance, we ﬁrst train each modality-

speciﬁc branch independently. Then, we initialize

MATT

randomly and ﬁne-tune the whole architecture

by applying the cross-entropy loss to the ﬁnal output

p(c|I, x). It should be noted that this loss is differ-

entiable with respect to the parameters of both f


GPS

and f

MATT

. The network has been trained for 15

epochs, the batch size has been set to 3, momentum

to 0.9 and the learning rate to 0.001.

3.3 State of the Art Approaches

We also consider the approaches investigated

in (Milotta et al., 2019a; Milotta et al., 2019b) for

comparison. These consist in the fusion of different

CNN architectures, including SqueezeNet (Iandola

et al., 2016), AlexNet (Krizhevsky et al., 2012) and

VGG (Simonyan and Zisserman, 2015), with differ-

ent classiﬁers based on GPS, including a K-Nearest

Neighbor (KNN), a Decision Classiﬁcation Tree

(DCT) and a Support Vector Machine (SVM). All

these approaches perform fusion using a standard late

fusion approach similar in spirit to the “weighted late

fusion” method considered in this paper. We compare

with respect to these approaches by reporting the

accuracy values declared by the authors in (Milotta

et al., 2019a; Milotta et al., 2019b).

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

612

Figure 7: Topology of the natural site. The space is com-

posed by 9 context (coloured in red). For the area number

5 the botanic expert have deﬁned 9 subcontext (coloured in

blue). The 17 context area are obtained substituting the 9

subcontext to the context numbers.

4 EXPERIMENTAL RESULTS

4.1 Dataset

For our experiments, we considered the dataset intro-

duced in (Milotta et al., 2019a). This dataset com-

prises about 6 hours of egocentric videos collected

by different visitors while exploring the natural site

of the Botanical Garden of the University of Catania.

Speciﬁcally, the authors released 63, 581 images sam-

pled from the videos. To allow evaluation by cross-

validation, the set of data has been partitioned into

three folds. Each image is associated to a GPS posi-

tion retrieved with a smartphone and labeled accord-

ing to the area in which the visitor was located at the

time of acquisition. The labels are provided according

to three different levels of localization granularity:

• 9 Contexts: the area of the site has been divided

into 9 different contexts, relevant for the behav-

ioral analysis of the visitors to understand for in-

stance which plants they have seen and which ar-

eas they have spent more time into;

• 9 Subcontexts: the area of context 5, one of the

9 original contexts, has been further divided into

9 subcontexts. These provide a more ﬁne-grained

understanding of where the user has spent more

time in context 5, which is the most characteristic

part of the garden. Note that this classiﬁcation

task requires a much more accurate localization;

• 17 Contexts: this is a mixed set of classes in which

the 8 contexts (excluding context 5) are merged

with the 9 subcontexts of context 5. To address

Table 1: Accuracy of different single-modal methods based

on GPS in the 9 Contexts scenario. The performance

scores of the methods marked with the ”*” sign are reported

from (Milotta et al., 2019a).

Model Fold 0 Fold 1 Fold 2 AVG

DCT* 78.76 % 46.83 % 76.53% 67.37%

SVM* 78.89 % 52.59 % 78.50% 69.99%

KNN* 80.38 % 54.34 % 81.05% 71.92%

MLP 82.44% 63.13% 82.57% 76.04%

this classiﬁcation task, the methods needs to be

able to infer location at both a coarse (the 8 con-

texts) and a ﬁne (the 9 subcontexts) level.

Figure 7 illustrates the topology of the natural site in-

cluding the subdivision of the space into contexts and

subcontexts.

All experiments have been performed using an

NVIDIA GTX 1050 GPU with 2GB of RAM. We

compared all architectures on the 9 contexts settings

to provide ablation with respect to the different fusion

approaches. The methods achieving best performance

in these settings are further evaluated on the 9 subcon-

texts and 17 contexts scenarios.

4.2 Results on the 9 Contexts Settings

4.2.1 Methods based Only on GPS

Table 1 compares the performance of the considered

Multilayer Perceptron (MLP) with respect to the De-

cision Classiﬁcation Tree (DCT), the Support Vector

Machine (SVM) and the K-Nearest Neighbor (KNN)

classiﬁers investigated in (Milotta et al., 2019a). The

table reports the results obtained on each fold, as well

as the average performance across folds. Best results

per-column are highlighted in bold. In average, the

accuracy of MLP increases by 9% compared to DCT,

6% compared to SVM and 4% compared to KNN.

These observed performance gaps suggest that GPS

coordinates are too noisy to allow for accurate local-

ization on the 9 contexts. Indeed, if they were accu-

rate enough, geometrical approaches such as decision

trees, SVM and KNN should be able to easily divide

the space into regions to perform classiﬁcation. In-

stead, the non-linearity of a properly tuned MLP al-

lows to improve performance by signiﬁcant margins.

4.2.2 Methods based Only on Images

Table 2 compares the performance of different CNNs

for image-based localization. The best performances

per-column are reported in bold numbers. As it can

be expected, the shallow SqueezeNet-6 obtains lower

performance as compared to the full SqueezeNet,

Localizing Visitors in Natural Sites Exploiting Modality Attention on Egocentric Images and GPS Data

613

Table 2: Accuracy of different CNNs for image-based localization in the 9 Contexts scenario. The performance scores of the

methods marked with the ”*” symbol are reported from (Milotta et al., 2019a).

Model Fold 0 Fold 1 Fold 2 AVG

SqueezeNet-6 82.01% 79.12% 82.70% 81.27%

AlexNet* 90.99% 90.72% 89.63% 90.45%

SqueezeNet* 91.24 % 93.23% 91.40% 91.91%

ResNet18 94.01% 94.89% 93.78% 94.25%

VGG16* 94.26% 95.59% 94.08% 94.64%

Combined ResNet18 + DenseNet121 94.43% 95.00% 94.99% 94.80%

DenseNet121 94.76% 95.29% 95.18% 95.07%

Table 3: Accuracy of the multi-modal methods processing both images and GPS on the 9 Contexts scenario. For reference,

the top part of the table also reports the performances of the single-modal branches. The performance scores of the methods

marked with the ”*” symbol are reported from (Milotta et al., 2019a). Per-fold results have not been made available by the

authors of (Milotta et al., 2019a) for these methods.

Model Fold 0 Fold 1 Fold 2 AVG

DCT* 78.76 % 46.83 % 76.53% 67.37%

MLP 82.44% 63.13% 82.57% 76.04%

SqueezeNet-6 82.01% 79.12% 82.70% 81.27%

AlexNet* 90.99% 90.72% 89.63% 90.45%

SqueezeNet* 91.24% 93.23% 91.40% 91.91%

VGG16* 94.26% 95.59% 94.08% 94.64%

DenseNet121 94.76% 95.29% 95.18% 95.07%

MLP + SqueezeNet-6 (learned late fusion) 92.65% 79.84% 91.97% 88.15%

MLP + SqueezeNet-6 (weighted late fusion) 92.13% 81.56% 91.52% 88.40%

MLP + SqueezeNet-6 (modality attention) 93.44% 79.99% 93.58% 89.00%

AlexNet + DCT (weighted late fusion)* - - - 91.33%

SqueezeNet + DCT (weighted late fusion)* - - - 92.47%

VGG16 + DCT (weighted late fusion)* - - - 94.86%

MLP + SqueezeNet (weighted late fusion) 94.15% 94.02% 94.11% 94.09%

MLP + SqueezeNet (learned late fusion) 94.49% 93.35% 94.56% 94.13%

MLP + SqueezeNet (modality attention) 95.57% 93.53% 96.06% 95.05%

MLP + DenseNet121 (modality attention) 96.15% 95.60% 96.09% 95.94%

which is probably due to the lower number of param-

eters and to the limited ﬂexibility due to the reduced

depth. In general, deeper models tend to perform bet-

ter than shallow ones (e.g., VGG16 vs AlexNet and

DenseNet121 vs VGG16 and ResNet18). To assess

whether fusing two CNNs can be beneﬁcial, we used

the “Combined CNNs” fusion architecture illustrated

in Figure 3 to combine ResNet18 and DenseNet121.

As can be noted, this results in a performance drop,

probably due to overﬁtting induced by the increased

capacity of the overall architecture and to the re-

dundancy of the visual features extracted by the two

networks. It is worth noting that even a very shal-

low CNN such as SqueezeNet-6 already outperforms

GPS-based localization obtaining a 81.27% accuracy,

versus the accuracy of the MLP for GPS-based clas-

siﬁcation which is equal to 76.04%. This highlights

how vision-based classiﬁcation can be more accurate

than classiﬁcation obtained from noisy GPS measure-

ments.

4.2.3 Methods based on Images and GPS

Table 3 reports the accuracy achieved by multi-modal

approaches on the 9 Contexts scenario. To assess the

improvements due to fusion, the top part of the ta-

ble also reports the performance of the single-branch

models. The table also includes the results reported

in (Milotta et al., 2019a) for comparison. All methods

obtained by fusing the shallow SqueezeNet-6 CNN

and the MLP signiﬁcantly improve over the single-

modal branches. For instance, combining the MLP

and SqueezeNet-6 with modality attention allows to

obtain an accuracy of 89.00%, which is about 13%

higher than the one obtained using the MLP alone

(76.04%) and about 8% higher than the one obtained

using SqueezeNet-6 alone (81.27%). Improvements

are observed also for the full SqueezeNet (95.00%

with modality attention vs 76.04% with MLP and

91.91% with the CNN alone) and for DenseNet121

(95.94% with modality attention vs 95.07% with the

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

614

Table 4: Accuracy of the single-modal and multi-modal methods on the 9 Subcontexts scenario. The performance scores

of the methods marked with the ”*” symbol are reported from (Milotta et al., 2019a). Per-fold results have not been made

available by the authors of (Milotta et al., 2019a) for these methods.

Model Fold 0 Fold 1 Fold 2 AVG

MLP 59.66% 49.01% 51.72% 53.46%

AlexNet + DCT (weighted late fusion)* - - - 83.68%

SqueezeNet 83.96% 88.06% 84.21% 85.41%

SqueezeNet + DCT (weighted late fusion)* - - - 85.89%

SqueezeNet+MLP (modality attention) 86.51% 88.10% 86.28% 86.96%

VGG16 + DCT (weighted late fusion)* - - - 90.01%

DenseNet121 91.15% 92.11% 89.35% 90.87%

DenseNet121+MLP (modality attention) 92.23% 92.29% 91.40% 91.97%

Table 5: Accuracy of the single-modal and multi-modal methods on the 17 Contexts scenario. The performance scores of the

methods marked with the ”*” symbol are reported from (Milotta et al., 2019a). Per-fold results have not been made available

by the authors of (Milotta et al., 2019a) for these methods.

Model Fold 0 Fold 1 Fold 2 AVG

MLP 66.97% 48.58% 66.32% 60.62%

SqueezeNet 87.94% 91.07% 87.42% 88.81%

AlexNet + DCT (weighted late fusion)* - - - 86.59%

SqueezeNet + DCT (weighted late fusion)* - - - 89.37%

SqueezeNet+MLP (modality attention) 91.24% 91.12% 91.46% 91.27%

DenseNet121 91.42% 94.25% 91.58% 92.41%

VGG16 + DCT (weighted late fusion)* - - - 92.43%

DenseNet121+MLP (modality attention) 94.44% 94.59% 92.85% 93.96%

CNN alone). It is worth noting that for deeper

CNNs the relative improvement of the fusion with

respect to the CNN become smaller. This is due

to the fact that CNNs can already solve the prob-

lem with high accuracy without GPS. Interestingly,

even in such cases, the proposed modality atten-

tion approach always brings improvements, even if

marginal, and never leads to overﬁtting. It can also

been observed that modality attention outperforms

both weighted late fusion and learned late fusion

with both SqueezeNet-5 and SqueezeNet. Indeed,

weighted late fusion leads to minimal improvements,

whereas learned late fusion performs even worse than

weighted late fusion. Finally, even the relatively small

model fusing SqueezeNet and MLP with modality

attention outperforms all approaches previously re-

ported in (Milotta et al., 2019a), which are indicated

by a ”*” symbol in the table.

4.3 Results on the 9 Subcontexts and 17

Contexts Scenarios

Table 4 and Table 5 compare the best perform-

ing models based on the fusion of SqueezeNet and

DenseNet121 with MLP through modality attention

with the respective single-branch performances and

with previous methods proposed in (Milotta et al.,

2019a) (marked with the ’*’ symbol). In the 9 subcon-

texts scenario (Table 4) modality attention allows to

obtain large improvements over the MLP both when

SqueezeNet (86.96% vs 53.46%) and DenseNet121

(91.97% vs 53.46%) are considered. The meth-

ods also improve over the performances achieved by

the respective CNNs. As can be noted, the pro-

posed approaches outperform the methods proposed

in (Milotta et al., 2019a).

Similar trends can be observed in the case of

the 17 contexts (Table 5), where the proposed

SqueezeNet+MLP model with modality attention

outperforms the SqueezeNet+DCT model proposed

in (Milotta et al., 2019a) by +1.9% and similarly,

DenseNet121+MLP outperforms VGG16+DCT by

+1.53% and AlexNet+DCT by +7.37%. These re-

sults highlight the ﬂexibility of the proposed modality

attention approach for multi-modal fusion.

4.4 Computational Resources Analysis

Table 6 reports the required time and memory of the

considered methods. Times have been computed on

CPU using a four-cores Intel

 Core

i7-7700HQ

@ 3.80GHz, averaging over 400 predictions. For ref-

erence, we also report the accuracy of such methods

on the 9 Contexts scenario. While methods based on

GPS are fast and require very little memory, their per-

formances are limited. Using even small CNNs such

Localizing Visitors in Natural Sites Exploiting Modality Attention on Egocentric Images and GPS Data

615

Table 6: Execution time, required memory and average accuracy on the 6 Contexts scenario of the different methods consid-

ered in this study.

Model Time (ms) Mem (MB) Accuracy

DCT 0.01 0.07 67.37%

MLP 0.49 0.006 76.04%

SqueezeNet-6 7.88 0.31 81.27%

SqueezeNet-6 + MLP (modality attention) 9.23 0.50 89.00%

SqueezeNet 18.30 2.78 91.91%

AlexNet 20.25 217.60 90.45%

SqueezeNet + MLP (modality attention) 24.40 3.19 95.05%

VGG16 434.86 512.32 94.64%

DenseNet121 559.09 27.685 95.07%

DenseNet121 + MLP (modality attention) 563.71 30.434 95.94%

as SqueezeNet-6 and SqueezeNet, allows to improve

performance with a small computational overhead.

In particular, the SequeezeNet-6 + MLP (modality

attention) model achieves signiﬁcantly better perfor-

mance with respect to DCT, MLP and SqueezeNet-6

still mantaining a fast inference and a small memory

footprint. Fusing a full SqueezeNet model with an

MLP using modality attention allows to achieve per-

formance comparable to the one obtained by much

larger model such as DenseNet121 still maintaining

a fast inference (about 25ms) and a very small mem-

ory footprint (about 3MB). This suggests that fusing

predictions based on images and GPS with modality

attention can bring a signiﬁcant boost in performance

with a very efﬁcient inference.

5 CONCLUSION

We have investigated the use of different fusion tech-

niques to improve the localization of visitors in a nat-

ural site from egocentric images and noisy GPS mea-

surements. The experiments have highlighted that: 1)

GPS data alone allows to achieve only limited perfor-

mance, which suggests that such data is not accurate

enough in the considered context, 2) localization from

egocentric images can achieve much more accurate

results, 3) fusing image- and GPS-based predictions

generally allows to improve results and in particular,

4) the proposed modality attention fusion mechanism

allows to achieve good localization performance at a

very low computational budget, which makes the in-

vestigated methodologies suitable for implementation

in embedded settings. Future works can investigate

the use of the considered fusion techniques to perform

a more ﬁne-grained localization based on camera pose

estimation.

ACKNOWLEDGEMENTS

This research is part of the project VALUE -

Visual Analysis for Localization and Under-

standing of Environments (N.08CT6209090207,

CUP G69J18001060007) supported by PO FESR

2014/2020 - Azione 1.1.5. - “Sostegno allavan-

zamento tecnologico delle imprese attraverso il

ﬁnanziamento di linee pilota e azioni di validazione

precoce dei prodotti e di dimostrazioni su larga scala”

del PO FESR Sicilia 2014/2020, and Piano della

Ricerca 2016-2018 linea di Intervento 2 of DMI,

University of Catania.

REFERENCES

Alkhafaji, A., Fallahkhair, S., and Cocea, M. (2019). De-

sign challenges for mobile and wearable systems to

support learning on-the-move at outdoor cultural her-

itage sites. In Lamas, D., Loizides, F., Nacke, L.,

Petrie, H., Winckler, M., and Zaphiris, P., editors,

Human-Computer Interaction – INTERACT 2019,

pages 185–207, Cham. Springer International Pub-

lishing.

Alletto, S., Abati, D., Serra, G., and Cucchiara, R. (2016).

Exploring architectural details through a wearable

egocentric vision device. Sensors, 16(2):237.

Battiato, S., Farinella, G. M., Gallo, G., and Ravi, D.

(2008). Scene categorization using bag of textons on

spatial hierarchy. In 2008 15th IEEE International

Conference on Image Processing, pages 2536–2539.

Cucchiara, R. and Del Bimbo, A. (2014). Visions for aug-

mented cultural heritage experience. IEEE MultiMe-

dia, 21(1):74–82.

Deng, J., Dong, W., Socher, R., Li, L., Kai Li, and Li Fei-

Fei (2009). Imagenet: A large-scale hierarchical im-

age database. In 2009 IEEE Conference on Computer

Vision and Pattern Recognition, pages 248–255.

VISAPP 2020 - 15th International Conference on Computer Vision Theory and Applications

616

Farinella, G., Signorello, G., Battiato, S., Furnari, A., Ra-

gusa, F., Leonardi, R., Ragusa, E., Scuderi, E., Lopes,

A., Santo, L., et al. (2019). VEDI: Vision Exploita-

tion for Data Interpretation. In International Confer-

ence on Image Analysis and Processing, pages 753–

763. Springer.

Furnari, A. and Farinella, G. M. (2019). What would you

expect? anticipating egocentric actions with rolling-

unrolling lstms and modality attention. In Interna-

tional Conference on Computer Vision.

Giuliano, R., Marzovillo, M., Mazzenga, F., and Vari, M.

(2014). Visitors localization in cultural heritages for

experience enhancement. In 2014 Euro Med Telco

Conference (EMTC), pages 1–6. IEEE.

He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-

ual learning for image recognition. In 2016 IEEE Con-

ference on Computer Vision and Pattern Recognition

(CVPR), pages 770–778.

Horn, G. V., Mac Aodha, O., Song, Y., Shepard, A., Adam,

H., Perona, P., and Belongie, S. J. (2017). The inatu-

ralist challenge 2017 dataset. CoRR, abs/1707.06642.

Huang, G., Liu, Z., v. d. Maaten, L., and Weinberger, K. Q.

(2017). Densely connected convolutional networks. In

2017 IEEE Conference on Computer Vision and Pat-

tern Recognition (CVPR), pages 2261–2269.

Iandola, F. N., Han, S., Moskewicz, M. W., Ashraf, K.,

Dally, W. J., and Keutzer, K. (2016). Squeezenet:

Alexnet-level accuracy with 50x fewer parameters and

<0.5mb model size.

Joly, A., Go

eau, H., Glotin, H., Spampinato, C., Bon-

net, P., Vellinga, W.-P., Lombardo, J.-C., Planque,

R., Palazzo, S., and M

uller, H. (2017). LifeCLEF

2017 Lab Overview: Multimedia Species Identiﬁca-

tion Challenges. In Jones, G. J., Lawless, S., Gonzalo,

J., Kelly, L., Goeuriot, L., Mandl, T., Cappellato, L.,

and Ferro, N., editors, CLEF: Cross-Language Evalu-

ation Forum, volume LNCS of Experimental IR Meets

Multilinguality, Multimodality, and Interaction, pages

255–274, Dublin, Ireland. Springer.

Krizhevsky, A., Sutskever, I., and Hinton, G. E. (2012). Im-

agenet classiﬁcation with deep convolutional neural

networks. In Proceedings of the 25th International

Conference on Neural Information Processing Sys-

tems - Volume 1, NIPS’12, pages 1097–1105, USA.

Curran Associates Inc.

Kumar, N., Belhumeur, P. N., Biswas, A., Jacobs, D. W.,

Kress, W. J., Lopez, I. C., and Soares, J. V. B. (2012).

Leafsnap: A computer vision system for automatic

plant species identiﬁcation. In Fitzgibbon, A. W.,

Lazebnik, S., Perona, P., Sato, Y., and Schmid, C.,

editors, ECCV (2), volume 7573 of Lecture Notes in

Computer Science, pages 502–516. Springer.

Milotta, F. L., Furnari, A., Battiato, S., Signorello, G., and

Farinella, G. M. (2019a). Egocentric visitors localiza-

tion in natural sites. Journal of Visual Communication

and Image Representation, page 102664.

Milotta, F. L. M., Furnari, A., Battiato, S., Salvo, M. D.,

Signorello, G., and Farinella, G. M. (2019b). Visitors

localization in natural sites exploiting egovision and

gps. In International Conference on Computer Vision

Theory and Applications (VISAPP).

Ragusa, F., Furnari, A., Battiato, S., Signorello, G., and

Farinella, G. M. (2019). Egocentric visitors localiza-

tion in cultural sites. Journal on Computing and Cul-

tural Heritage (JOCCH), 12(2):11.

Seidenari, L., Baecchi, C., Uricchio, T., Ferracani, A.,

Bertini, M., and Bimbo, A. D. (2017). Deep artwork

detection and retrieval for automatic context-aware

audio guides. ACM Transactions on Multimedia Com-

puting, Communications, and Applications (TOMM),

13(3s):35.

Simonyan, K. and Zisserman, A. (2015). Very deep con-

volutional networks for large-scale image recognition.

In International Conference on Learning Representa-

tions.

Wegner, J. D., Branson, S., Hall, D., Schindler, K., and Per-

ona, P. (2016). Cataloging public objects using aerial

and street-level images; urban trees. In 2016 IEEE

Conference on Computer Vision and Pattern Recogni-

tion (CVPR), pages 6014–6023.

Localizing Visitors in Natural Sites Exploiting Modality Attention on Egocentric Images and GPS Data

617
