Learning Question Similarity in CQA from References and Query-logs

Alex Zhicharevich

, Moni Shahar

and Oren Sar Shalom

Intuit AI, Israel

Facebook, Israel

Keywords:

Community Question Answering, Text Similarity, Text Representation, Deep Learning, Weak Supervision.

Abstract:

Community question answering (CQA) sites are quickly becoming an invaluable source of information in

many domains. Since CQA forums are based on the contributions of many authors, the problem of ﬁnding

similar or even duplicate questions is essential. In the absence of supervised data for this problem, we propose

a novel approach to generate weak labels based on easily obtainable data that exist in most CQAs, e.g., query

logs and references in the answers. These labels accommodate training of auxiliary supervised text classiﬁca-

tion models. The internal states of these models serve as meaningful question representations and are used for

semantic similarity. We demonstrate that these methods are superior to state of the art text embedding methods

for the question similarity task.

1 INTRODUCTION

Community Question Answering (CQA) sites have

emerged as a popular and rich source for informa-

tion, where both domain speciﬁc sites (e.g., Stack-

Overﬂow

, TTLC

), and general purpose sites (e.g.,

Quora

), provide a platform for users to get precise

answers to their questions. Though community con-

tribution is crucial in order to keep such huge amount

of information up to date, question authors are not

necessarily aware of all the already existing questions.

It is therefore common to ﬁnd similar or even du-

plicate questions. A question to question similarity

measure is important in many applications like ques-

tion deduplication, similar question recommendation,

question routing, retrieval and more (Nakov et al.,

2017; Srba and Bielikov

a, 2016).

While each CQA site may have unique traits, all

major sites share the following three components:

structure of questions, a reference mechanism and

an internal search engine. In detail, the structure of

a question is composed of a mandatory title and an

optional details section. The title is usually one or

two sentences containing the subject of the question.

The details is a short section, few sentences long, that

elaborates on the question. An answer to a question is

termed as a reply. The reference mechanism allows to

https://stackoverﬂow.com

https://ttlc.intuit.com/

www.quora.com

link within a reply of a seed question to a referenced

question.

Most existing approaches for CQA question simi-

larity require labeled data (Nakov et al., 2017). How-

ever, in many real world applications this supervision

does not exist and it is impractical to obtain a large

corpus of labeled data. Our proposed approach lever-

ages auxiliary data to generate abundant amount of

weak supervision. Then we apply a neural network

to learn representations for questions, which in turn

would be used to calculate question similarity.

2 RELATED WORK

The huge amount of data residing in CQAs have at-

tracted a signiﬁcant amount of attention from the re-

search community. Multiple aspects of CQA systems

have been studied (Srba and Bielikov

a, 2016), such

as question and answer retrieval, automatic question

answering, question quality and more. Question to

question semantic similarity is a fundamental task and

multiple approaches have been tried to model it. One

of the subtasks in SemEval CQA task (Nakov et al.,

2017) was directly aimed at ﬁnding good question

to question similarity measures. The task was struc-

tured as a supervised retrieval problem, imposing that

the majority of the proposed solutions modeled the

similarity using unsupervised text similarity methods

which are later combined to a similarity score us-

342

Zhicharevich, A., Shahar, M. and Shalom, O.

Learning Question Similarity in CQA from References and Query-logs.

DOI: 10.5220/0008982403420352

In Proceedings of the 9th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2020), pages 342-352

ISBN: 978-989-758-397-1; ISSN: 2184-4313

ing a supervised classiﬁcation method. (Charlet and

Damnati, 2017) which were the top system at Se-

mEval17, used a supervised combination of SoftCo-

sine similarity over question tokens with cosine dis-

tance between question embeddings using word em-

bedding weighted average. (Nassif et al., 2016) used

stacked bidirectional LSTM to learn similarity classes

between questions. (Shao, 2017) proposed learning

the element wise differences of the outputs of CNN to

generate similarities. (Filice et al., 2017) trained an

SVM over engineered intra and inter pair similarity

features. Similar approaches were proposed to cap-

ture general semantic similarities between texts in Se-

mEval STS (semantic text similarity) task (Cer et al.,

2017) as well as for a more speciﬁc deduplication task

(Bogdanova et al., 2015; Zhang et al., 2017). Two

major limitations of those methods are high complex-

ity and the need for labeled datasets to train the ﬁnal

supervised component.

Question similarity can be considered as a special

case of a general text similarity problem. A popular

approach for text similarity is to encode the text in low

dimensional vector spaces which capture the text se-

mantics and later model the similarity as a geometric

proximity in the embedding space. One approach to

produce sentence level embeddings is by composing

word level embeddings (Arora et al., 2017; Pagliar-

dini et al., 2018). Alternative modern approaches use

sentence level tasks to directly encode longer texts.

(Kiros et al., 2015) proposed such an embedding by

trying to reconstruct the surrounding sentences of the

encoded sentence and (Logeswaran and Lee, 2018)

structured this idea as a classiﬁcation problem. (Con-

neau et al., 2017) train a universal sentence embed-

ding method using supervised methods on the SNLI

dataset. (Cer et al., 2018) use Transformer and DAN

networks to produce general embeddings that transfer

across various tasks. Though most of these text em-

beddings methods are trained to be successfully ap-

plied on a variety of downstream tasks they are not

optimized directly for pairwise similarity. Pretrained

language models (Devlin et al., 2019) are success-

fully improving results on many NLP tasks, but are

designed to be ﬁne-tuned with labeled data and are

not meant to serve as sentence representation extrac-

tors.

In contrast to general text representation ap-

proaches, some work has been done to learn repre-

sentations that directly optimize the similarity task.

Siamese networks (Chopra et al., 2005) are a popular

framework to learn similarities and have been used for

text by (Mueller and Thyagarajan, 2016) and (Necu-

loiu et al., 2016). A more general triplet architecture

(Hoffer and Ailon, 2015) was applied for text simi-

larity by (Ein Dor et al., 2018). While these meth-

ods provide a principled way of modeling similarity

directly between arbitrary texts, where the architec-

ture of the sub-network can be adapted to the texts at

hand, they do not aim to be transferred as is to other

domains and require a substantial amount of labeled

data as well as sophisticated negative sampling meth-

ods.

Unlike NLP methods, which measure similarity

between questions using the question’s content, meth-

ods from information retrieval have a long history

of inferring such similarities from the click through

data recorded by search engines. This line of work

uses user clicks on query results as an implicit rele-

vance signal (Baeza-Yates and Tiberi, 2007) and thus

queries can be represented as a function of the clicked

documents and vice versa. Popular approaches sug-

gest to construct either a bipartite graph of queries and

documents and leverage its structure to learn similar-

ities (Craswell and Szummer, 2007; Jeh and Widom,

2002), or an equivalent sparse query-document click

through matrix. Models leveraging deep learning

were also proposed (Huang et al., 2013) for this task.

A majority of the existing work focuses on query

similarity (Ma et al., 2008), but some suggestions

were made (Poblete and Baeza-Yates, 2008; Wu et al.,

2013) to apply these methods for documents as well.

While some work was done on query log analysis of

CQA (Figueroa and Neumann, 2013; Wu et al., 2014)

we are not aware of any in the context of question

similarity. A major limitation of using strictly click

through information, is the existence of questions for

which the number of recorded clicks is very limited

or even non existing. This is natural for newly posted

questions, and in our case also frequent for many ex-

isting unpopular questions

3 THE DATA - TurboTax LIVE

COMMUNITY

This work focuses on question similarity on the Tur-

boTax Live Community (TTLC) site. TurboTax, de-

veloped by Intuit, is the most widely used tax ﬁling

service in the US. TTLC is a tax related CQA oper-

ated by Intuit that provides a wide knowledge base for

US tax ﬁlers, containing over 3 million questions with

a mix of tax related and product related questions. As

described above, questions are usually posted with

question phrased titles describing the general infor-

mation the user looks for and a details section that

describes the speciﬁcs of the posting user’s question.

Like in many other CQA platforms, question are usu-

ally answered by domain experts like tax profession-

Learning Question Similarity in CQA from References and Query-logs

343

als or by the Intuit TurboTax support representatives

who are well versed in the details of the TurboTax

product. Since most posting users are looking for fac-

tual information on tax regulations or product guid-

ance, the vast majority of questions result in a single

answer providing the needed information.

Although the tax system is complex, the breadth

of topics on TTLC is much smaller compared to plat-

forms like Quora or StackOverﬂow. The vast majority

of posts relate to a relatively small set of central top-

ics either around tax regulations or the operation of

the TurboTax product with different variations depen-

dant on the posting user speciﬁc situation. To address

this need, Intuit is maintaining several thousands of

high quality expert-created guide pages (FAQs) which

provide general high quality information around those

central topics. Due to this nature, a common case is

that a reply to a question will be a reference to an-

other answer or more frequently an FAQ page, and

TTLC’s user interface allows the rendering of the ref-

erenced page within the original reply which provides

a citation-like interface to those references.

TTLC’s search engine records all queries submit-

ted to it from users, as well as all questions clicked

following those queries. Due to the varying quality

of questions on the site, the search engine is designed

to rank the higher quality questions higher, especially

Intuit generated FAQs. This results in many commu-

nity generated questions receiving very low trafﬁc. A

common scenario for a posted question is to be an-

swered after surfacing in the unanswered questions

queue, be read by the posting user after he was no-

tiﬁed it was answered, and later never be clicked by

other users as a search result (though users can be ex-

posed to questions in ways other than search). Our

modeling decisions were therefore impacted by the

high volume of questions not appearing in query logs.

4 PROPOSED MODEL

With the absence of massive amount of labels re-

quired for training modern supervised models, our so-

lution is divided into two parts: (i) learn question rep-

resentation based on weak supervision and (ii) apply

the representations to measure similarity.

We propose two methods for learning question

representation using two auxiliary sources of infor-

mation: the reference mechanism and search engine.

Both methods leverage the auxiliary information to

construct a classiﬁcation training set, where the ques-

tion is used to predict its properties - the reference in

the question reply or the query that was used to re-

trieve the question. With these training sets, a neural

network classiﬁer is trained, and the question repre-

sentation is obtained by extracting the last layer of

the network. Later, we use the fact that the two mod-

els share similar formulations to train a joint model

that leverages both the queries and references.

4.1 Reference Prediction Model

The reference prediction model uses the assumption

that similar questions have similar replies. However,

reply texts are usually of even greater complexity than

those of the questions. Two replies that reference

the same question usually resolve around the subject

of the referenced page, thus indicating that the cor-

responding question are similar as well. The large

amount of references present in the TTLC system al-

lows us to simplify and use the second assumption

to learn similarity. Table 1 shows random examples

of questions and the title of their referenced ques-

tion. As this table shows, the content of the refer-

ence is indicating the topic of interest of the original

question. We therefore treat the referenced page as a

weak signal for the topic of the referencing question.

Note that while in TTLC the referenced pages are also

part of the same CQA, this is in general not required

for our algorithm, since the content of the referenced

page is not used by the model. In other domains the

references can point to an arbitrary content such as

Wikipedia pages.

In order to ﬁnd questions with references, a reg-

ular expression search over the replies text was per-

formed to extract the references, resulting in a dataset

of 210, 308 questions. In the case of several refer-

ences in the same reply or in the case of multiple

replies for the same question, we took the ﬁrst refer-

ence in the chronologically ﬁrst reply. We then frame

the task of reference prediction as a multi-class text

classiﬁcation, where each unique reference is repre-

sented with a class. As one may expect, the frequency

of referenced pages is highly skewed, with a small

number of highly referenced pages and a long tail of

pages referenced only once. While training can be

done with such conﬁguration, this is sub optimal both

due to the low number of training examples per class

as well as the potential duplication between the ref-

erenced pages content. To address this limitation, we

restrict the number of unique referenced pages in the

training set, requiring at least 20 referencing pages

per reference. This resulted in 893 referenced pages

in the dataset and 162, 468 question-reference pairs.

The classiﬁcation model used neural network, and

followed popular conﬁguration (

Irsoy and Cardie,

2014) for text classiﬁcation. It contained the follow-

ing four parts.

ICPRAM 2020 - 9th International Conference on Pattern Recognition Applications and Methods

344

Figure 1: Neural Network architecture of reference predic-

tion model.

• Learn a domain speciﬁc vector representations for

all words in the titles of the questions. Represen-

tations are learned with the Word2Vec SGNS em-

bedding scheme (Mikolov et al., 2013). This is

done in a separate pre-processing step.

• Embed the question titles in the training set by

representing words with the learned embeddings.

• Process the embedded question titles with two

stacked bidirectional LSTM layers (Schuster and

Paliwal, 1997; Hochreiter and Schmidhuber,

1997). The concatenation of the last hidden states

of the forward and backward parts of the second

LSTM serve as the encoding of the question title

to a ﬁxed size vector representation.

• The question representations are fed into two fully

connected layers and softmax normalization. The

output of the model is a probability distribution

of a question to reference each of the target refer-

ences.

The model architecture is presented in details in

Figure 1. The highlighted part of the network is the

representation extractor, namely we represent each

question as the output of the last hidden layer of the

MLP part. Naturally, after the network is trained rep-

resentation can be obtained for arbitrary questions,

not restricted to those appearing in the model train-

ing set.

4.2 Query Log Prediction Model

The query log is a valuable source of information for

similarity. In this approach the training data are the

query logs of the CQA, namely, the questions that

were clicked following each query. While the ref-

erence approach assumed similarity of two question

based on sharing the same reference in the reply, here

our modeling is based on the idea that questions are

similar if they are viewed by users that searched for

the same queries. The query logs of TTLC are query-

question pairs (q

, d

) which are the result of a user

entering the query q

in the CQA search engine, and

clicking question d

from the search results. As de-

scribed in Section 3, a signiﬁcant portion of questions

has very little or even no click-through data. This is

naturally the case for newly posted questions. There-

fore, though it is possible to compute similarities be-

tween documents directly on the click-through pairs,

we use the click-through data again as weak labels set

for a training set for a text based classiﬁcation model.

By grouping the click-through pairs list P, we con-

struct a set L

top

= {q

. . . q

} of the n most popular

queries, where from early experiments we set n =

2000. We then ﬁlter P to contain only pairs (q

, d

)

where q

∈ L

top

. After the ﬁltering we remained with

≈ 500K pairs where the number of unique questions

is over 25, 000. We enumerate the queries and then

train the exact same neural network as in 4.1 where

for a click pair (q

, d

) the query index of q

is pre-

dicted using the title of question d

. An important

difference from the reference model is the fact that

unlike in the reference model, where we select just

one reference per question, in this model the training

data may contain several different labels for the same

question. The click counts were used only for ﬁlter-

ing purposes, and after the ﬁltering stage no grouping

or counting is performed on the click data, i.e., each

click is a distinct training example.

4.3 Combining Reference and Query

Log Data

Sections 4.1 and 4.2 propose different ways to con-

struct weak labeling for learning question’s represen-

tations. Due to the different data which is fed to each

of the methods, each representation encodes different

properties of the questions. The semantic generaliza-

tion of the query log model is limited by the retrieval

function of the CQA search engine, while the refer-

ence model may present poorer performance on top-

ics where high quality references do not exist. There-

fore it is useful to combine the two methods to get

a representation which fuses both types of informa-

tion. One straight forward way of combination is by

vector operation like concatenation or averaging. A

more sophisticated alternative is to jointly learn both

supervised tasks from the question’s content. We ex-

periment with two approaches for such joint learning.

Multi-task learning (Ruder, 2017) is a popular ap-

proach in which a single model tries to reconstruct

two targets based on the same input. In our case, this

can be applied by trying to predict both the reference

and the query. However, this is not straight forward

Learning Question Similarity in CQA from References and Query-logs

345

Table 1: Example of questions and referenced pages.

Question title Referenced page title

some how i clicked I am self employed and we are not

and now its asking for that info. Where or how can I

delete this or should I put a zero in those spots

Can I downgrade to a lower-priced version of Tur-

boTax Online?

I get a refund amount thats less than what was on Turbo-

Tax???

Why is my federal refund less than I expected?

I need to ﬁle taxes for my invalid daughter. How can I

start a new income tax without errassing min

How do I start another return in TurboTax Online?

Why wont it take my credit card for IRS payment. I have

been trying all day.

Can I pay my IRS taxes with a credit or debit card?

since in the query log training set, the same question

can appear with multiple queries as labels unlike a

single reference in the reference model. On top of

that, the intersection of questions both appearing in

the query logs and have references in the reply is rel-

atively low. Since we also want to restrict the number

of queries the model predicts, this will result in only

several thousands question with both targets. There-

fore we propose two alternatives to the straight for-

wards multi-task setting. The ﬁrst, instead of fram-

ing the query prediction as a multi-class classiﬁcation

problem and minimizing the cross entropy between

the predicted and actual classes, we will have the net-

work, on top of the reference prediction, also min-

imize the dot product between the question’s repre-

sentation and the query representation where we rep-

resent a query with the average embedding of it’s to-

kens. We do this for all query-click q

, d

pairs where

has a reference in one of it’s replies. This method is

referred in the results as the multi-task method and is

illustrated in Figure 2 with the highlighted part repre-

senting the component later used for extracting ques-

tion representations. The second method takes quite a

different approach, in which we do not change the su-

pervision framing setting. Instead, we reuse the same

weights for learning both tasks, where we train the

models in an alternating manner. We share all layers

of the network except the last fully connected layer

and the Softmax normalization (which is exactly the

question encoding part), and train the model for an

epoch with the reference target and then an epoch

with the query target. We do this alternating train-

ing for 8 iterations. We later use the shared part of the

two networks as a question encoder and refer to this

combination as the iterative method.

4.4 Modeling Question Details

Oftentimes users ask very speciﬁc question which

cannot be phrased using one or two sentence long ti-

tles. Speciﬁcally, in the tax domain the user may need

to describe the precise details of his case to get an ac-

Figure 2: Neural network architecture of the multitask

model.

curate answer. Due to this fact, the text contained in

the details section may be very important for similar-

ity estimation. However, due to its length and its com-

plex structure it is harder to process. Since the lion’s

share of information still resides in the question titles,

we compare several methods to include the details in

the similarity calculation along with the title.

4.4.1 Unsupervised Combination

The simplest way to combine the two parts of the text

is by concatenating the details and the title into one

text and apply the methods from previous sections.

Though compelling for it’s simplicity, this method ig-

nores the semantic differences between the title and

the details. To overcome this problem we combined

the representations instead of combining the text. We

separately encode the title and the details using any

of the methods previously described so as to obtain

a separate representation for each part. Once we had

this representation we combined the two representa-

tions using either averaging or concatenation.

ICPRAM 2020 - 9th International Conference on Pattern Recognition Applications and Methods

346

Figure 3: Neural network architecture of jointly predicting

references using title and details.

4.4.2 Joint Learning

In order to avoid the complication in the previous sec-

tion, we learned the problem on both the title and the

details jointly. Unlike the concatenation of the text,

separate networks are used to process each of the ti-

tle and the details, and the layer outputs of the net-

works are concatenated, and serves as an input to sev-

eral additional layers for the prediction. In theory the

same network can be used to process the two texts

with shared weights, but this will prevent the net-

work from addressing the structural differences be-

tween the two texts, for example their length. Even

without weights sharing, the simple network architec-

ture used for titles can be inadequate for the details

section which is often much longer. We experiment

with two models for joint learning: (i) symmetric in-

dependent model and (ii) hierarchical model. In the

symmetric model two identical networks which struc-

ture is described in 4.1 are learned with no weight

sharing, so the ﬁrst network encodes the title and the

second encodes the details. Each network outputs a

vector of dimension 64 and the concatenation of both

vectors enters another fully connected layer so as to ﬁt

the labeled output. The network is illustrated in Fig-

ure 3 .The second model uses hierarchical attention

networks (HAN) (Yang et al., 2016) for the encoding

of the details, and is similar to the ﬁrst model in all re-

maining components. This special conﬁguration was

designed to address the problem of the long text in the

details.

5 EXPERIMENTAL RESULTS

5.1 Evaluation Protocol

Measurement of quality of a similarity function is

somewhat hard since there are multiple traits that we

expect from a good similarity function. Possible ways

to do that are either to discretize the similarity to ﬁxed

classes (Conneau et al., 2017) or to let the similar-

ity function to retrieve the nearest neighbours of a

point and measure the resulted set in IR based mea-

sures (Nakov et al., 2017). Classiﬁcation between re-

lated vs. unrelated question may be trivial in some

cases and classiﬁcation of similarity to ﬁxed classes

may be highly subjective. In this work we measure

similarity using relative comparisons of two similar-

ity scores. We manually created a set of triplets of

questions (q, q

, q

), such that the similarity between

q and q

(positive) is higher than q and q

(negative).

Since compiling such a set is like looking for a needle

in a haystack, we assist with the TTLC tagging sys-

tem, which allows users to assign tags to questions.

We manually composed a set of ≈ 400 tags which

represent clear important concepts around the tax do-

main. We then sampled pairs of questions that have 2

common tags. Those questions act as candidates for

(q, q

), and after manually ﬁltering pairs with a low

semantic relatedness we ended up with 1, 174 pairs

with a solid connection. We have two methods to in-

troduce the negative question q

as to generate the

desired (q, q

, q

) triplets: coarse-grained that ran-

domly selects a question with no common tags with

q and ﬁne-grained, that randomly selects a question

that has a single common tag with q. The latter ap-

proach ﬁnds negative samples with some relatedness

to q, making the differences more subtle. A sample

of the ﬁne grained similarity dataset is presented in

Table 2 and from the coarse-grained dataset in Table

5.2 Experimental Settings

5.2.1 Evaluation Measures

Given a similarity function sim and a triplet t =

(q, q

, q

), we deﬁne that sim is correct on t by

sim,t

(

1 sim(q, q

) > sim(q, q

)

0 otherwise

(1)

Learning Question Similarity in CQA from References and Query-logs

347

Table 2: Example question triplets from the ﬁne-grained similarity dataset.

Seed question First reference question Second reference question

Requested the MAC software to

amend my 2016 taxes. Turbo

emailed a link with a code and

password.

need to amend 2016 but don’t re-

member my password

do I need to send a copy of my

amended federal tax return with

my Louisiana state return

what if I don’t have my 1095 how do i revise self employed

health insurance ﬁgure once en-

tered?

With the cost of medications and

healthcare, does HIV qualify as

severely disabled?

Table 3: Example question triplets from the coarse similarity dataset.

Seed question Reference question Random question

How to deal with an overfunded

401k.

If a 401K contribution includes

cents, and the tax contribution is

rounded does that have any future

tax implication?

Does being enrolled in health in

2015 qualify if it began in 2016?

how do we ﬁle jointly? Divorce not ﬁnal on Dec 31, can I

ﬁle single?

Was last years taxes ﬁled?

For a dataset D of n triplets, the ratio of correctly

classiﬁed triplets by sim is simply

∑

i=1

sim,t

We denote this ratio as similarity accuracy. For each

method we report the similarity accuracy for both the

ﬁne-grained and coarse datasets. As explained in the

previous section, in each triplet t, q and q

are the

same in both datasets and q

is random in the coarse

dataset and shares a tag with q in the ﬁne-grained

dataset

5.2.2 Baselines

We consider a variety of methods for similarity com-

putation as baselines. We mix methods that directly

address similarity, as well as text representation meth-

ods. For text representation we include both mod-

els that use unsupervised word vector combination as

well as pre-trained models trained on other domains.

All our models and baselines use the same tokeniza-

tion mechanism where all non alphanumeric charac-

ters are removed and tokens are obtained by splitting

on spaces.

Soft-Cosine. Soft-Cosine similarity was used in

the winning approach for SemEval 2017 and is a suc-

cessful technique for direct similarity computation.

We use 100 dimensional CBOW word2vec represen-

tations trained on the titles of all questions in the

database and follow (Charlet and Damnati, 2017) for

the Soft-Cosine implementation. We consider this

model as a direct similarity baseline.

SIF Embeddings. This is a popular and success-

ful baseline for constructing sentence embeddings

from individual token embeddings. For word embed-

dings we use the same vectors as described in Soft-

Cosine and follow the implementation described in

(Arora et al., 2017). We use cosine similarity over

the representations to compute question similarity.

Universal Sentence Encoder. As described in

(Cer et al., 2018) Universal Sentence Encoder (USE)

is state of the art approach for universal text repre-

sentations that can be effectively leveraged for many

downstream tasks including similarity. We used the

code released by the authors

to obtain question rep-

resentations and use inner product for similarity.

5.2.3 Model Training

All models were implemented with Keras

using Ten-

sorFlow

backend. Both the reference and query

log models, which share almost identical architec-

tures, used 100 dimensional word embeddings as in

the baselines and further tuned by each model while

training. Both bidirectional LSTMs had 128 dimen-

sional hidden states and the two fully connected layers

had 64 dimensional hidden states and a RELU activa-

tion function. Between the two fully connected layers

we applied dropout with a rate of 0.2. The question

titles were truncated to 30 tokens and padded where

needed before training. The model was trained us-

ing Adam optimization with initial learning rate of

0.001 and β1 and β2 are 0.9 and 0.999 respectively.

Both models used batch size of 256 and the reference

https://tfhub.dev/google/universal-sentence-encoder/2

https://keras.io

https://www.tensorﬂow.org

ICPRAM 2020 - 9th International Conference on Pattern Recognition Applications and Methods

348

model was trained for 12 epochs while the query log

model was trained for 70 epochs. Hyper-parameters

were tuned using 10% validation set on the original

supervised task for each model.

For the multi-task method we use the same word

embeddings described in the baselines. due to the

dot product operation we use 100 dimensional fully

connected layers instead of the regular 64 used in the

rest of the models. We minimize a weighted average

α ∗ query loss + (1 − α) ∗ cite loss, where query loss

is the mean of the squared dot products between query

and question representations and cite loss is the cross

entropy of the reference predictions. α is set to 0.2

using a validation set on the original tasks. In the it-

erative method we use the same network setting as

the individual models, with 8 iteration each, starting

with an epoch with the query log target followed by

an epoch with the reference target.

The models that exclusively use the details section

are trained with the exact same settings as those using

the titles. Since the details section is usually longer,

the texts in this case are truncated to 100 tokens which

resulted in truncation of 3% of the questions. Train-

ing a separate word embeddings for the details did not

yield performance increase, and they are initialized

with the embeddings learned from the titles and ﬁne

tuned during training. In the joint title-details mod-

els the sub-component parameters are identical to the

networks described for individual models, where the

fully connected layer after concatenation has 64 di-

mension hidden state and a dropout with 0.2 rate is

performed between the concatenated vectors and the

fully connected layer. For hierarchical attention net-

works we use a sentence tokenizer from nltk

. We

follow the paper implementation for HAN, when we

change the word embedding dimensions and the op-

timization scheme to the same as described for the

titles.

5.3 Results

5.3.1 Title Methods

Figure 4 shows the similarity accuracy of methods

based on exclusively the titles. The evaluation clearly

shows that the supervised models signiﬁcantly outper-

form all baselines. While on the ﬁne-grained dataset

the supervised models present almost equal perfor-

mance on the coarse dataset the embeddings coming

from the hidden layer of the reference model are sig-

niﬁcantly better than the rest. We explain the fact

that the unsupervised models perform poorly by the

unique semantics and vocabulary present in the tax

https://www.nltk.org/

Figure 4: Comparison of title based embeddings on similar-

ity prediction.

domain. The fact that USE, being a fully transfer

model, underperforms SIF which has the advantage of

leveraging domain speciﬁc word vectors further sup-

ports this explanation. As expected, the coarse dataset

is much easier for classiﬁcation, with the accuracy of

the best performing model on the ﬁne-grained dataset

is on par with the lower performing model on the

coarse dataset.

5.3.2 Combination Methods

Figure 5 presents the performance of the different

combination methods mentioned in 4.3. We show the

base two models and compare them to three combi-

nation methods. While not dramatic, there is signif-

icant improvement of the combined models on the

ﬁne-grained dataset. While the multi-task approach

seems not to be effective, both concatenation, averag-

ing and especially iterative training outperform each

of the stand alone models on the ﬁne-grained dataset

with no performance loss on the coarse dataset. We

address the poor performance of the multi-task ap-

proach to the low amount of questions having both

labels. The success of the iterative model conﬁrms

our assumptions on the advantage of combining both

supervised signals in one model.

5.3.3 Models with Details Section

When we combine the details section into the model,

the results are less decisive with several models show-

ing similar performance. The full results are listed

in Table 4. The attempt to jointly learn the refer-

ences from both title and details did not yield sig-

niﬁcant improvement over the title only representa-

tions (the results for the iterative and query log mod-

els are not listed but are inferior to other models as

well). The addition of a more complex model for de-

tails, in the form of HAN, yielded very marginal im-

Learning Question Similarity in CQA from References and Query-logs

349

Figure 5: Similarity accuracy of combination methods of

reference and query-log models.

provements. We address the overall disappointing re-

sults of the joint learning to the fact that the question

representations were not signiﬁcantly different from

those learned with the titles exclusively. This is sup-

ported by the similar performance of the joint model

to the models reported in Figure 4. The joint mod-

els also only marginally improved performance on the

original supervised tasks. We leave the improvement

of joint models for future work. We therefore focus

on unsupervised combinations of separately learned

representations for each section. In most cases, av-

eraging and concatenation behaved very similar for

all approaches and we report results for concatena-

tion. On the ﬁne-grained dataset, concatenation of

representation learned in a supervised way were the

best performing. Speciﬁcally the model in which both

titles and details were separately iteratively trained

on both references and query logs was the most suc-

cessful one. Despite showing quite poor performance

on titles only, Universal Sentence Encoder proved to

be very useful in encoding the details and was only

slightly inferior on the ﬁne-grained dataset and the

best performing model on the coarse dataset. We at-

tribute this to the model’s ability to model complex

textual data which is present in the details section. As

expected, SIF embedding (and moreover Soft-Cosine)

struggled to model long texts in an effective way.

6 CONCLUSIONS AND FUTURE

WORK

In this paper we presented methods for measuring

similarity in CQA sites. We showed that learning the

representation by using supervised text classiﬁcation

on proxy variables leads to a signiﬁcant improvement

over state of the art text embedding models. More-

over, when similarity was calculated from the titles

Table 4: Comparison of similarity accuracy of models

which use both titles and details.

Model ﬁne-

grained

dataset

coarse

dataset

Concatenation of references

models

.7793 .9199

Concatenation of query log

models

.7291 .8688

Concatenation of iteratively

trained models

.7964 .9131

Joint learning on references .6797 .8356

Joint learning on references

with HAN

.6797 .8390

Concatenation of USE rep-

resentations

.7640 .9293

Average of USE representa-

tions

.7606 .9386

Concatenation of SIF repre-

sentations

.7027 .8475

only the advantage of our methods was even bigger.

We also compared few methods to combine multiple

supervised models and obtained that its superior to

each model separately.

For future work we intend to explore several direc-

tions. First, the TTLC data contains relatively large

number of high quality internal question references

which made the reference prediction model very suc-

cessful. However, the replies and reference mech-

anism contain additional structure that can be used,

such as multiple references, the textual context of the

reference and more. We expect that deeper analysis of

all these would provide more training data in TTLC,

as well as make our method more applicable to other

CQAs.

Contrary to the high-quality reference data that

we had, the query click data was relatively small and

lacked a lot of important features. For example, the

page dwell time could deﬁnitely improve our algo-

rithm. The gap in quality between data sources also

emphasizes the need for a good method to combine

different sources of information with different level

of conﬁdence. Of course pure statistical methods

like parameter tuning using cross-validation could be

used, however since cross-validation is again relying

on labeled data, it would be interesting to come with

a near-optimal solution for which it is not required.

Finally, we are aware that NLP methods for text

modeling are improving rapidly. In our experiments,

Universal Sentence Encoder was highly accurate for

representing the details section, probably because of

its ability to capture the semantics of longer and

more complicated texts. Lately, ﬁne tuning pretrained

ICPRAM 2020 - 9th International Conference on Pattern Recognition Applications and Methods

350

transformer based language models has achieved state

of the art results on many NLP tasks. Incorporating

the weak signals with those methods may further in-

crease performance.

REFERENCES

Arora, S., Liang, Y., and Ma, T. (2017). A simple but tough-

to-beat baseline for sentence embeddings. In 5th In-

ternational Conference on Learning Representations,

ICLR 2017.

Baeza-Yates, R. and Tiberi, A. (2007). Extracting semantic

relations from query logs. In Proceedings of the 13th

ACM SIGKDD International Conference on Knowl-

edge Discovery and Data Mining, KDD ’07, pages

76–85.

Bogdanova, D., dos Santos, C., Barbosa, L., and Zadrozny,

B. (2015). Detecting semantically equivalent ques-

tions in online user forums. In Proceedings of

the Nineteenth Conference on Computational Natural

Language Learning, pages 123–131. Association for

Computational Linguistics.

Cer, D., Diab, M., Agirre, E., Lopez-Gazpio, I., and Spe-

cia, L. (2017). Semeval-2017 task 1: Semantic textual

similarity multilingual and crosslingual focused eval-

uation. In Proceedings of the 11th International Work-

shop on Semantic Evaluation (SemEval-2017), pages

1–14. Association for Computational Linguistics.

Cer, D., Yang, Y., Kong, S.-y., Hua, N., Limtiaco, N.,

St. John, R., Constant, N., Guajardo-Cespedes, M.,

Yuan, S., Tar, C., Strope, B., and Kurzweil, R. (2018).

Universal sentence encoder for english. In Proceed-

ings of the 2018 Conference on Empirical Methods

in Natural Language Processing: System Demonstra-

tions, pages 169–174. Association for Computational

Linguistics.

Charlet, D. and Damnati, G. (2017). Simbow at semeval-

2017 task 3: Soft-cosine semantic similarity between

questions for community question answering. In Pro-

ceedings of the 11th International Workshop on Se-

mantic Evaluation (SemEval-2017), pages 315–319.

Association for Computational Linguistics.

Chopra, S., Hadsell, R., and LeCun, Y. (2005). Learning

a similarity metric discriminatively, with application

to face veriﬁcation. In 2005 IEEE Computer Society

Conference on Computer Vision and Pattern Recogni-

tion (CVPR’05), volume 1, pages 539–546 vol. 1.

Conneau, A., Kiela, D., Schwenk, H., Barrault, L., and

Bordes, A. (2017). Supervised learning of universal

sentence representations from natural language infer-

ence data. In Proceedings of the 2017 Conference on

Empirical Methods in Natural Language Processing,

pages 670–680, Copenhagen, Denmark. Association

for Computational Linguistics.

Craswell, N. and Szummer, M. (2007). Random walks

on the click graph. In Proceedings of the 30th An-

nual International ACM SIGIR Conference on Re-

search and Development in Information Retrieval, SI-

GIR ’07, pages 239–246.

Devlin, J., Chang, M., Lee, K., and Toutanova, K. (2019).

BERT: pre-training of deep bidirectional transform-

ers for language understanding. In Proceedings of

the 2019 Conference of the North American Chap-

ter of the Association for Computational Linguistics:

Human Language Technologies, NAACL-HLT 2019,

Minneapolis, MN, USA, June 2-7, 2019, Volume 1

(Long and Short Papers), pages 4171–4186.

Ein Dor, L., Mass, Y., Halfon, A., Venezian, E., Shnayder-

man, I., Aharonov, R., and Slonim, N. (2018). Learn-

ing thematic similarity metric from article sections us-

ing triplet networks. In Proceedings of the 56th An-

nual Meeting of the Association for Computational

Linguistics (Volume 2: Short Papers), pages 49–54.

Association for Computational Linguistics.

Figueroa, A. and Neumann, G. (2013). Learning to rank

effective paraphrases from query logs for community

question answering. In Proceedings of the Twenty-

Seventh AAAI Conference on Artiﬁcial Intelligence,

AAAI’13, pages 1099–1105.

Filice, S., Da San Martino, G., and Moschitti, A. (2017).

Kelp at semeval-2017 task 3: Learning pairwise pat-

terns in community question answering. In Proceed-

ings of the 11th International Workshop on Semantic

Evaluation (SemEval-2017), pages 326–333. Associ-

ation for Computational Linguistics.

Hochreiter, S. and Schmidhuber, J. (1997). Long short-term

memory. Neural Comput., 9(8):1735–1780.

Hoffer, E. and Ailon, N. (2015). Deep metric learning

using triplet network. In International Workshop on

Similarity-Based Pattern Recognition, pages 84–92.

Springer.

Huang, P.-S., He, X., Gao, J., Deng, L., Acero, A., and

Heck, L. (2013). Learning deep structured seman-

tic models for web search using clickthrough data.

In Proceedings of the 22Nd ACM International Con-

ference on Information & Knowledge Management,

CIKM ’13, pages 2333–2338, New York, NY, USA.

ACM.

Irsoy, O. and Cardie, C. (2014). Opinion mining with deep

recurrent neural networks. In EMNLP, pages 720–

728.

Jeh, G. and Widom, J. (2002). Simrank: A measure of

structural-context similarity. In Proceedings of the

Eighth ACM SIGKDD International Conference on

Knowledge Discovery and Data Mining, KDD ’02.

Kiros, R., Zhu, Y., Salakhutdinov, R., Zemel, R. S., Tor-

ralba, A., Urtasun, R., and Fidler, S. (2015). Skip-

thought vectors. arXiv preprint arXiv:1506.06726.

Logeswaran, L. and Lee, H. (2018). An efﬁcient framework

for learning sentence representations. In International

Conference on Learning Representations ICLR 2018.

Ma, H., Yang, H., King, I., and Lyu, M. R. (2008). Learn-

ing latent semantic relations from clickthrough data

for query suggestion. In Proceedings of the 17th ACM

Conference on Information and Knowledge Manage-

ment, CIKM ’08, pages 709–718, New York, NY,

USA.

Mikolov, T., Sutskever, I., Chen, K., Corrado, G. S., and

Dean, J. (2013). Distributed representations of words

Learning Question Similarity in CQA from References and Query-logs

351

and phrases and their compositionality. In Advances in

Neural Information Processing Systems, pages 3111–

3119.

Mueller, J. and Thyagarajan, A. (2016). Siamese recurrent

architectures for learning sentence similarity. In Pro-

ceedings of the Thirtieth AAAI Conference on Artiﬁ-

cial Intelligence, AAAI’16, pages 2786–2792.

Nakov, P., Hoogeveen, D., M

arquez, L., Moschitti, A.,

Mubarak, H., Baldwin, T., and Verspoor, K. (2017).

Semeval-2017 task 3: Community question answer-

ing. In Proceedings of the 11th International Work-

shop on Semantic Evaluation, SemEval@ACL 2017,

Vancouver, Canada, August 3-4, 2017, pages 27–48.

Nassif, H., Mohtarami, M., and Glass, J. (2016). Learning

semantic relatedness in community question answer-

ing using neural models. In Proceedings of the 1st

Workshop on Representation Learning for NLP, pages

137–147. Association for Computational Linguistics.

Neculoiu, P., Versteegh, M., and Rotaru, M. (2016). Learn-

ing text similarity with siamese recurrent networks.

In Proceedings of the 1st Workshop on Representa-

tion Learning for NLP, pages 148–157. Association

for Computational Linguistics.

Pagliardini, M., Gupta, P., and Jaggi, M. (2018). Unsuper-

vised Learning of Sentence Embeddings using Com-

positional n-Gram Features. In Proceedings of the

2018 Conference of the North American Chapter of

the Association for Computational Linguistics: Hu-

man Language Technologies, Volume 1 (Long Papers),

pages 528–540.

Poblete, B. and Baeza-Yates, R. (2008). Query-sets: Us-

ing implicit feedback and query patterns to organize

web documents. In Proceedings of the 17th Interna-

tional Conference on World Wide Web, WWW ’08,

pages 41–50.

Ruder, S. (2017). An overview of multi-task learning in

deep neural networks. CoRR, abs/1706.05098.

Schuster, M. and Paliwal, K. (1997). Bidirectional recur-

rent neural networks. Trans. Sig. Proc., 45(11):2673–

2681.

Shao, Y. (2017). Hcti at semeval-2017 task 1: Use convolu-

tional neural network to evaluate semantic textual sim-

ilarity. In Proceedings of the 11th International Work-

shop on Semantic Evaluation (SemEval-2017), pages

130–133. Association for Computational Linguistics.

Srba, I. and Bielikov

a, M. (2016). A comprehensive survey

and classiﬁcation of approaches for community ques-

tion answering. TWEB, 10:18:1–18:63.

Wu, H., Wu, W., Zhou, M., Chen, E., Duan, L., and Shum,

H.-Y. (2014). Improving search relevance for short

queries in community question answering. In Pro-

ceedings of the 7th ACM International Conference on

Web Search and Data Mining, WSDM ’14, pages 43–

52, New York, NY, USA.

Wu, W., Li, H., and Xu, J. (2013). Learning query and doc-

ument similarities from click-through bipartite graph

with metadata. In Proceedings of the Sixth ACM Inter-

national Conference on Web Search and Data Mining,

WSDM ’13, pages 687–696.

Yang, Z., Yang, D., Dyer, C., He, X., Smola, A., and Hovy,

E. (2016). Hierarchical attention networks for docu-

ment classiﬁcation. In Proceedings of the 2016 Con-

ference of the North American Chapter of the Asso-

ciation for Computational Linguistics: Human Lan-

guage Technologies, pages 1480–1489. Association

for Computational Linguistics.

Zhang, W. E., Sheng, Q. Z., Lau, J. H., and Abebe, E.

(2017). Detecting duplicate posts in programming

qa communities via latent semantics and association

rules. In Proceedings of the 26th International Con-

ference on World Wide Web, WWW ’17, pages 1221–

1229.

ICPRAM 2020 - 9th International Conference on Pattern Recognition Applications and Methods

352
