Email Image Spam Classification based on ResNet Convolutional Neural
Network
V
´
ıt List
´
ık
1 a
, Jan
ˇ
Sediv
´
y
2 b
and V
´
aclav Hlav
´
a
ˇ
c
2 c
1
Czech Technical University in Prague Faculty of Electrical Engineering, Department of Cybernetics,
Prague 6, Technick
´
a 2, Czech Republic
2
Czech Institute of Informatics, Robotics and Cybernetics, Prague 6, Jugosl
´
avsk
´
ych partyz
´
an
˚
u 1580/3, Czech Republic
Keywords:
Spam, Email, ResNet, Image, Classification, Convolutional Neural Network.
Abstract:
The problem with email image spam classification is known from the year 2005. There are several approaches
to this task. Lately, those approaches use convolutional neural networks (CNN). We propose a novel approach
to the image spam classification task. Our approach is based on CNN and transfer learning, namely Resnet v1
used for semantic feature extraction and one layer Feedforward Neural Network for classification. We have
shown that this approach can achieve state-of-the-art performance on publicly available datasets. 99% F1-
score on two datasets (Dredze et al., 2007), Princeton and 96% F1-score on the combination of these datasets.
Due to the availability of GPUs, this approach may be used for just-in-time classification in anti-spam systems
handling huge amounts of emails. We have observed also that mentioned publicly available datasets are no
longer representative. We overcame this limitation by using a much richer dataset from a one-week long real
traffic of the freemail provider Email.cz. The training data annotation was created by user labeling of the
emails. The image spam (and image ham even more) tackles privacy issues. We overcame it by publishing
extracted feature vectors with associated classes (instead of images itself). This data does not violate privacy
issues. We have published Email.cz image spam dataset v1 via the AcademicTorrents platform and propose a
system, which achieves up to 96% F1-score with presented model architecture on this novel dataset. Providing
our dataset to the community may help others with solving similar tasks.
1 INTRODUCTION
Spam emails (unconsolidated bulk messages) costs
email providers and users a huge amount of time and
money. Anti-spam systems are trying to lower those
loses by separating the email traffic to wanted and un-
wanted (commonly called ham and spam). Anti-spam
techniques have to evolve because methods used by
spammers are evolving too. One of the examples of
a relatively recent technique is the image spam ap-
pearing in email communication (email image spam -
referred also as image spam throughout this work)
The image spam problem in emails was specified
in (Aradhye et al., 2005), (Wu et al., 2005). The
problem was defined as an email content obfuscation
method for the anti-spam filters because they did not
use information from images attached to emails. At
that time, it was hard to process information contained
a
https://orcid.org/0000-0002-1907-6334
b
https://orcid.org/0000-0003-0626-2303
c
https://orcid.org/0000-0002-8472-3147
in images mainly because of the processing power and
insufficient algorithms. The problem of image spam
in its original form is not that urgent as before because
anti-spam solutions are now able to detect it
1
, there-
fore making it less efficient for attackers.
However, it keeps being an interesting research
domain because the task is getting harder (Carpinteiro
et al., 2017), (Shang and Zhang, 2016). The reason
why it is getting harder is that emails containing im-
ages are now much more common for both legitimate
emails and unfortunately for spam emails too. An-
other reason is that the available processing power is
now much bigger. Consequently, more complex tech-
niques may be used on both sides of the barricade.
The final reason is that most of the email providers
are not classifying only to spam and ham classes any-
more. They use more classes, i.e. Newsletter or Fo-
rums. Those conditions are suggesting that image in-
formation may be helpful for those emerging tasks.
1
https://wiki.apache.org/spamassassin/FuzzyOcrPlugin
Listík, V., Šedivý, J. and Hlavá
ˇ
c, V.
Email Image Spam Classification based on ResNet Convolutional Neural Network.
DOI: 10.5220/0008956704570464
In Proceedings of the 6th International Conference on Information Systems Security and Privacy (ICISSP 2020), pages 457-464
ISBN: 978-989-758-399-5; ISSN: 2184-4356
Copyright
c
2022 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved
457
1.1 Public Datasets
As we have stated above, characteristics of the image
spam and email communication have changed signif-
icantly. However, the only commonly used publicly
available dataset is over a decade old (Dredze et al.,
2007). The biggest problem for publishing the im-
age spam dataset is the private nature of email con-
tents. Other datasets used in publications are listed in
Sec. 3.1. Those datasets are commonly not available.
It is not because they were not published, but because
the publication medium (most commonly server of
the publisher) is no longer available.
2 THE APPROACHED TASK
In this contribution, we approach the email image
spam classification. The image spam may hide ob-
fuscated text or URL in images instead of plain-text
(which is common for regular spam). Such harm-
ful images may contain inappropriate content, unso-
licited marketing campaigns, and text. The format of
HTML emails containing only embedded images and
no text is very common for newsletters
2
, which may
be either legitimate or unsolicited. When those emails
do not contain any other information other than the
images and traffic information (headers, sender IP),
we suppose that the information extracted from im-
ages may improve anti-spam solutions significantly.
Spam emails make 45% of email traffic globally.
At Email.cz, it was measured that 25% of emails are
spam. This is caused by the fact that Email.cz classi-
fies newsletter emails into a separate class. Spam and
newsletter categories combined constitute up to 75%
of the traffic. It was also measured at Email.cz that
75% of emails contain images embedded in HTML
and 13% of emails contain image attachments. This
means that 88% of emails contain at least one image.
Measurements for all the categories are shown in
Table 1. These measurements demonstrate that spam
and newsletter emails contain even more images than
personal emails.
2.1 Dataset
Due to the lack of representable dataset (problems
with datasets are described in Sec. 1.1 and available
datasets are described in Sec. 3.1) for this task we de-
cided to create a novel dataset as part of this work.
We established the following requirements for the
dataset:
2
Emails containing advertisements commonly sent in
bulks
Table 1: Statistics of emails containing images measured at
Email.cz. Image means that email contained at least one
image. HTML means images linked from HTML content
of the email. Attach means images in attachments. News
means newsletter. Categories are based on currently used
anti-spam filter at Email.cz.
All Spam News Inbox
Emails 100.00% 25.10% 52.59% 22.60%
Image 88.15% 95.81% 98.99% 54.37%
HTML 75.39% 65.46% 95.65% 39.17%
Attach 12.76% 30.35% 3.33% 15.21%
The resulting dataset should be recent and based
on a real email traffic
Images have to be labeled into following classes
{spam, ham, advertisement}
The data have to be anonymized because of their
private nature
It should contain enough samples for training
Neural Networks (NN) or other statistical models
Reliable platform for the publication
3 RELATED WORK
In this section, we describe publicly available datasets
and commonly used methods for email image spam
classification.
3.1 Publicly Available Datasets
Based on (Biggio et al., 2011), which is an overview
of used datasets and methods until 2011, the com-
monly used and still available dataset is (Dredze et al.,
2007). The other commonly used available dataset
is (Cormack and Lynam, 2005). A combination of
more public datasets is also used. A different ap-
proach is to use a custom dataset (not public).
We studied approaches that appeared after 2011.
They follow the pattern described in (Biggio et al.,
2011). Most of the approaches use custom datasets
and (Dredze et al., 2007).
Dredze 2007
(Dredze et al., 2007) is the most commonly used pub-
licly available dataset for image spam classification.
This dataset is unique because it contains both spam
and ham samples. Dredze 2007 dataset is separated
into three parts described in Table 2.
This corpus was created by image extraction from
emails. Only images attached to emails were used.
ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy
458
Table 2: Numbers based on (Dredze et al., 2007) in which
the dataset was published. Those numbers are correct, but
some of the images are damaged and cannot be used for
training.
Corpus name # of images
Personal Ham 2550
Personal Spam 3239
SpamArchive Spam 9503
Images were detected based on the file extension.
SpamArchive is still available
3
. One part (called pub-
lic) contains spam only. The authors also collected
personal emails from 10 email accounts from 10 dif-
ferent domains over one month and extracted both
spam and ham images. This part is called private or
personal.
Princeton Spam Image Benchmark
Princeton Spam Image Benchmark was published in
2007. It contains 1071 images in 178 groups. It is
accessible
4
.
The first issue with Dredze 2007 and Princeton
datasets is that they contain only a few thousands of
samples. Neural networks need more samples for
training. We are not training the CNN because it
comes already pre-trained on a huge dataset. Still,
neural nets perform better on more samples.
TREC
TREC dataset
5
is commonly used for benchmark-
ing. It was also created in 2007 and contains only
emails (Cormack and Lynam, 2005). Images need
to be extracted from the emails. Because this dataset
contains around 7,000 images and the extracted ver-
sion is not publicly available we decided not to use
it. It solves neither the issue with old data nor dataset
size issue.
3.2 Statistical Models
Email image spam task has been approached many
times by the community (Biggio et al., 2011). Be-
tween the years 2005 and 2015, the most common
approach to this task was to use low-level image fea-
ture extraction and SVM classifier. Lately, it has
been more common to use neural networks for this
3
The site was available at http://www.spamarchive.org/
earlier. It may be found at http://untroubled.org/spam/ now.
4
http://www.cs.princeton.edu/cass/spam/
5
Accessible at http://trec.nist.gov/data/spam.html when
this paper was written.
task (Carpinteiro et al., 2017; Shang and Zhang,
2016).
Convolutional neural networks (CNN) and trans-
fer learning have been used in computer vision and
decision-making tasks recently. In this work, we
use CNN for classifying image spam in emails based
on (Shang and Zhang, 2016). They have used a non-
public image spam dataset. Their approach is to clas-
sify images extracted from emails to seven classes us-
ing CNN and SVM. They do not mention how they
are using the result of the classification for an anti-
spam solution.
The closest work to ours is (Shang and Zhang,
2016) because of the use of CNN. The difference is
that we are using a pre-trained network and they are
training the network from scratch. The other differ-
ence is that our dataset is publicly available and our
classes may be used directly in the anti-spam system.
The second closest work to ours is (Carpinteiro
et al., 2017) which compares results on 3 publicly
available datasets and one of the models they used is
a neural network.
4 OUR APPROACH
We proposed a model architecture for this task based
on CNN and implemented it. This architecture has
shown promising results in image classification lately.
We have tested it on two above mentioned publicly
available datasets and also on Email.cz image spam
dataset v1 (described in Sec. 4.2). In the following
sections, we describe the proposed architecture and
the dataset we published as part of this work.
4.1 Model Architecture
We propose using CNN for the image spam classifica-
tion task. Namely a pre-trained ResNet v1 for seman-
tic feature extraction(He et al., 2016). We are using
the extracted features as an input to a single hidden
layer fully connected neural network. We tested this
approach on publicly available datasets. Unsatisfied
with its ability to benchmark the image spam classifi-
cation task, we decided to use the CNN model for the
creation of our dataset.
Transfer learning (sometimes called fine-tuning)
is a process of training a model trained for another
task previously. This technique is used with CNN
commonly. Sometimes this process is performed on
one model. The CNN part of the model is frozen (the
learning rate for that part is very small or zero) and the
fully connected layers are trained with new data. This
method is mostly used when the dataset size or the
Email Image Spam Classification based on ResNet Convolutional Neural Network
459
computational power is insufficient for training the
entire CNN. We split the network into two separate
parts. It made it possible to store the results of the
CNN evaluation for further evaluation and learning.
Otherwise, the process stayed the same.
We have used ResNet v1 for feature extraction (He
et al., 2016). More precisely we are using a fully con-
nected layer of the ResNet, which consists of 2048
output neurons as the output of the feature-extractor.
Consequently, the used feature vector contains 2048
float entries. The first reason to use the ResNet model
was that it achieved state-of-the-art results on the Im-
ageNet classification task (Russakovsky et al., 2015).
The second reason is that it was tested in-house in
Email.cz for a similar task and achieved the best re-
sults. That resulted in a prepared and tested imple-
mentation and acceptance at Email.cz.
Resnet is a novel architecture designed for the Im-
ageNet classification task. It consists of 152 layers.
It overcomes the problem of vanishing gradients by
using residual connections (skip connections over a
group of layers). This architecture won ILSVRC 2015
classification challenge (He et al., 2016).
Our proposed model using features extracted by
ResNet v1 consists of one fully connected hidden
layer with 2048 neurons and ReLu activations. For
the output layer, we are using Softmax activation. The
implementation of this model is described in Sec. 5.2.
4.2 Email.cz Image Spam Dataset v1
As stated in Sec. 2.1 we decided to create our own
dataset and to publish it to the scientific community.
We did it in cooperation with Email.cz, which is the
largest freemail provider in the Czech Republic. We
publish the data in an anonymized format having min-
imal information loss in mind. Our proposed format
is to publish features extracted from the pre-trained
model instead of the images itself. We named the
dataset Email.cz image spam dataset v1.
At Email.cz, each image attachment is sent for
evaluation. Embedded HTML images are identified
by the URL. Not all images may be downloaded be-
cause some images are used for tracking the open rate.
The image is identified with a composite key contain-
ing, e.g. the email and image identifiers. Then the
number of occurrences of this composite key is cal-
culated and when it hits a defined threshold the image
is sent for analysis and cache the result. The results
of the images evaluations are stored for future pro-
cessing. One part of the image evaluation is also the
extraction of a ResNet feature vector.
Email.cz provides its users a possibility to express
misclassified emails, which is a standard in this in-
dustry. User reactions are stored which allows us to
map the reactions to all images contained in the email.
Apache Spark is used to connect email reactions to
the images contained in those emails (Zaharia et al.,
2016). The result is the feature vector of the analyzed
image and all corresponding user reactions.
In our case, the anti-spam system classifies emails
into three classes.
1. Ham emails - mostly personal communication and
should end up in the user’s inbox.
2. Newsletter emails - mostly messages containing
advertisements.
3. Spam emails - unsolicited messages.
When the classification is incorrect, the user may
change the label for which results in one of the ac-
tions.
USER MARK SPAM: From anywhere to spam.
USER UNMARK SPAM: From spam to anywhere else.
The newsletters are treated analogously.
Email corporas are difficult to build and publish
due to the private nature of email communications.
The same applies to image datasets. We suggest a
new approach to this task, namely publishing only
an extracted feature vectors, which are representative
enough for the classification task (as shown in Sec. 7).
It shouldn’t be possible to reconstruct the personal
data from it (Listik, 2018).
We are following the approach of (Dredze et al.,
2007) for attaching labels to images contained in
emails. If the email is classified spam, all images in-
side are classified as spam too, same apply to all the
labels.
5 IMPLEMENTATION
We implemented the proposed algorithm and tested
the algorithm on the publicly available datasets and
our newly gathered dataset. In the following section,
we describe the process of data gathering and model
training.
5.1 Data Gathering
For feature extraction from the public datasets, we are
using the open-source implementation of ResNet v1
without any modifications. In the following sections,
we focus on the details of the creation of our pub-
lished dataset called Email.cz image spam dataset v1.
As described in Sec. 4.2 only some images are
sent for analysis. When the image is chosen to be
ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy
460
analyzed, it is put into the queue. A server (an in-
stance of a ResNet model) takes it out from the queue
and analyzes it. We use open-source implementa-
tion
6
of ResNet using Tensorflow for feature extrac-
tion (Abadi et al., 2015; He et al., 2016). The result
is stored in two locations. First, it is stored in the
key-value store as a cache for the analysis of emails
containing the same image. Second, it is stored in
the Hadoop Distributed File System (HDFS) for fu-
ture use. We also store user reactions including infor-
mation which images were contained in each email on
HDFS too. Hence we may connect user reactions to
images with a Spark job. This cannot be done without
storing the image analysis data because the user reac-
tion comes after the email delivery (after the analysis).
The Spark job filters out all emails without im-
ages. First, it finds all reactions to the email. Second,
it also filters out emails without any reactions, groups
them by users who reacted to them. Third, finds all
the images contained in emails. Fourth and finally, it
extracts the image vector from the image representa-
tion and separates those vectors to single records with
the corresponding reactions (Zaharia et al., 2016).
The output of this job is the dataset described and
used in this paper.
Dataset Format
The format of the data is JSON
7
structure stored sep-
arately on each line which supports efficient loading
in many programming languages.
Dataset Name
We decided to call this dataset Email.cz image spam
dataset v1.
Data Time Span
The images were gathered in the period June 12-18,
2017.
Dataset Download
URL of the dataset may be found at Github.com
8
.
6
https://github.com/tensorflow/tensorflow/blob/master/
tensorflow/contrib/slim/python/slim/nets/resnet v1.py
7
Described in RFC 7159 https://tools.ietf.org/html/
rfc7159
8
https://github.com/tivvit/image-spam-cnn-classifier/
blob/master/dataset.yaml - We chose this way because
repository may be updated but the URL in the paper
cannot. The URL also contains the actual process of how
to download the dataset.
Our dataset is published via AcademicTorrents
9
.
We chose it because of the distributed fashion of the
peer2peer network. The main reason was that we en-
countered a lot of problems with missing or moved
datasets (as described in Sec. 1.1) for this task on the
Internet.
Format Specification
[[[user rections], [user reactions], ...],
[resnet vector]], where
Resnet vector is 2048 long vector of floats.
User reactions are all reactions for one image
from one user defined in user reaction.
User reaction is one of:
USER MESSAGE MARK SPAM
USER MESSAGE UNMARK SPAM
USER MESSAGE MARK AD
USER MESSAGE MARK NONAD
5.2 Statistical Model
We are using Keras with Tensorflow backend for
the implementation of model described in Sec. 4.1
(Chollet et al., 2015; Abadi et al., 2015). This im-
plementation is open-source and may be found at
Github.com
10
. All the results in this paper may be re-
produced with that repository in favor of reproducible
research.
6 TEST DATASET PROPERTIES
Our dataset consists of 778,768 lines, where each line
represents one image with its reactions. The dataset
is distributed in gzip format and its size is 2.5 GB
(16 GB after extraction). For this number of images,
we have collected 10,623,635 reactions. That is 13.64
reactions per image on average. The reaction distribu-
tion is shown in Table 3.
The category distribution in shown in Table 4.
We have implemented filters that helps the model
to use only consistent reactions. Implementations of
those filters are also included in the repository refer-
enced in Sec. 5.2.
First, we have filtered inconsistent reactions of a
single user to one image. Those reactions are proba-
bly misclassifications. They make only 2.34% of the
data which is not significant. It simplifies the reaction
structure to a flat array. We call remaining reactions
9
http://academictorrents.com/
10
https://github.com/tivvit/image-spam-cnn-classifier
Email Image Spam Classification based on ResNet Convolutional Neural Network
461
Table 3: The reaction distribution. Correlation between
minimal number of reactions and number of sample images.
Reactions to one image #image samples
>0 778768
>1 422541
>2 318234
>3 263478
>4 228131
>5 201003
>6 182244
>7 167866
>8 155431
>9 143242
Table 4: Distribution of the classes, based on user reaction
distribution.
Category Samples
Spam 52.92%
Advertisements 13.94%
Non-spam 6.43%
Non-ad 26.71%
valid and use them in all the following tests and mea-
surements.
We have also merged unmark user re-
actions (USER MESSAGE UNMARK SPAM and
USER MESSAGE MARK NONAD) to one class because we
do not need to use the information where the email
was delivered before, but only the information where
it belongs to. We may suppose it belongs to the
inbox, which is the class name for this merged group.
This also simplifies the usage of classification result
in the anti-spam filter.
We are merging all user’s reactions to one reaction
because reactions are very noisy. When the reaction
is inconsistent the image is not used because the im-
age itself probably does not contain any information
which may be used for the classification (e.g. emoji).
We have defined reaction consistency as
#cr
#r
100 , (1)
where #cr is the number of reactions for most com-
mon reaction group for a given image and #r is the
number of all reactions for one image.
The average consistency of all user reactions for
one image is following 86.21% ± 20.96. When we
consider only images with more than one reaction we
get to 74.71% ± 22.69.
Table 5: Performance on publicly available datasets. Where
Dr means Dredze and PR spam means Princeton spam.
Dataset Precision Recall F1-score
Dr personal 99% 99% 99%
Dr public 95% 95% 95%
Dr combined 96% 96% 96%
Dr ham, PR spam 99% 99% 99%
All combined 96% 97% 96%
Table 6: Shows the number of samples used for testing
(15%) for 100,000 sample subset for a different number of
reactions (rows) and consistencies (columns).
0 0.5 0.6 0.75
>0 14,897 13,840 12,177 10,894
>1 8,276 7,219 5,556 4,273
>2 6,299 5,242 4,280 2,997
>3 5,204 4,216 3,275 2,424
>4 4,504 3,534 2,720 1,888
>5 3,953 3,039 2,255 1,523
>7 3,382 2,513 1,862 1,246
>10 2,663 1,877 1,387 922
>20 1,779 1,192 839 544
7 EXPERIMENTAL RESULTS
All models were trained for 80 epochs with weighted
classes. We are using a 75:25 train/test split for public
datasets and 85:15 train/test split for our dataset. For
all the models we are using Adam optimizer (Kingma
and Ba, 2014). For other details please consult Sec. 5.
7.1 Public Datasets
In Table 5, we present the performance of our solution
on public datasets.
7.2 Our Dataset
In Table 6, we present how minimal consistency and
the minimal number of reactions correspond to the
number of samples.
Table 7 shows the results of our architecture for
various consistencies and minimal reaction counts.
Classifiers were trained on a subset of our dataset
(100,000 samples). We can see that when we filter
out the reactions supported by more users and those
reactions are consistent we will get better results.
Table 8 shows the performance on our dataset for
some chosen consistencies and sample counts.
ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy
462
Table 7: Average F1-scores for test set (15%) of 100,000
sample subset for different number of reactions (rows) and
consistencies (columns). Bold records were tested further.
0 0.5 0.6 0.75
>0 0.88 0.89 0.88 0.89
>1 0.9 0.89 0.93 0.94
>2 0.91 0.91 0.91 0.94
>3 0.91 0.92 0.92 0.93
>4 0.9 0.91 0.93 0.94
>5 0.92 0.92 0.93 0.94
>7 0.92 0.93 0.93 0.95
>10 0.92 0.93 0.94 0.95
>20 0.93 0.94 0.96 0.97
Table 8: Model F1-scores for chosen consistencies and min
reaction counts.
Min reactions consistency samples F1-score
0 0 649815 87%
3 0.6 140522 93%
5 0.6 98551 93%
10 0.6 59828 95%
20 0.6 34933 96%
3 0.75 102837 93%
5 0.75 66220 95%
10 0.75 39690 95%
20 0.75 22245 96%
8 CONCLUSIONS AND FUTURE
WORK
The proposed CNN architecture for the email image
spam classification task can achieve state-of-the-art
performance on publicly available datasets. 99% F1-
score on (Dredze et al., 2007) and Princeton datasets
and 96% F1-score on combination of the datasets. It
also achieves up to 96% F1-score on the presented
Email.cz image spam v1 dataset.
Email.cz image spam v1 dataset is published as
part of this work. This dataset focuses on being re-
cent and it is based on real email traffic. Due to this
fact, the data have to be anonymized which is done by
publishing only features extracted from the images.
Those features are extracted by CNN (ResNet v1).
The dataset is published via Academic Torrents plat-
form which is distributed in its nature, that should en-
sure that the data will be available for others in the fu-
ture. We were also considering the sufficiency of the
anonymization and concluded, that it is maybe possi-
ble to partially reconstruct the image data. However,
it would be computationally very expensive and the
level of detail that is needed for recognizing personal
information is already lost in the feature vector (Lis-
tik, 2018).
For future work, we want to gather a dataset in
a longer time range, which will contain also images
correctly classified by the current anti-spam solution.
Thus it will lead to a much bigger dataset. Our other
suggestion is to use a more complex model architec-
ture or a more sophisticated reaction filtering tech-
nique for higher performance.
ACKNOWLEDGEMENTS
We want to thank Seznam.cz company (Email.cz
owner) for providing us the data for the dataset
creation, computational power and the time of the
Email.cz team.
REFERENCES
Abadi, M., Agarwal, A., Barham, P., Brevdo, E., Chen, Z.,
Citro, C., Corrado, G. S., Davis, A., Dean, J., Devin,
M., Ghemawat, S., Goodfellow, I., Harp, A., Irving,
G., Isard, M., Jia, Y., Jozefowicz, R., Kaiser, L., Kud-
lur, M., Levenberg, J., Man
´
e, D., Monga, R., Moore,
S., Murray, D., Olah, C., Schuster, M., Shlens, J.,
Steiner, B., Sutskever, I., Talwar, K., Tucker, P., Van-
houcke, V., Vasudevan, V., Vi
´
egas, F., Vinyals, O.,
Warden, P., Wattenberg, M., Wicke, M., Yu, Y., and
Zheng, X. (2015). TensorFlow: Large-scale machine
learning on heterogeneous systems. Software avail-
able from tensorflow.org.
Aradhye, H. B., Myers, G. K., and Herson, J. A. (2005).
Image analysis for efficient categorization of image-
based spam e-mail. In Document Analysis and Recog-
nition, 2005. Proceedings. Eighth International Con-
ference on, pages 914–918. IEEE.
Biggio, B., Fumera, G., Pillai, I., and Roli, F. (2011). A
survey and experimental evaluation of image spam
filtering techniques. Pattern Recognition Letters,
32(10):1436–1446.
Carpinteiro, O. A., Sanches, B. C., and Moreira, E. M.
(2017). Detecting image spam with an artificial neu-
ral model. International Journal of Computer Science
and Information Security, 15(1):296.
Chollet, F. et al. (2015). Keras. https://github.com/fchol
let/keras.
Cormack, G. V. and Lynam, T. R. (2005). Trec 2005 spam
track overview. In TREC, pages 500–274.
Dredze, M., Gevaryahu, R., and Elias-Bachrach, A. (2007).
Learning fast classifiers for image spam. In CEAS.
He, K., Zhang, X., Ren, S., and Sun, J. (2016). Deep resid-
ual learning for image recognition. In Proceedings of
the IEEE conference on computer vision and pattern
recognition, pages 770–778.
Email Image Spam Classification based on ResNet Convolutional Neural Network
463
Kingma, D. and Ba, J. (2014). Adam: A method
for stochastic optimization. arXiv preprint
arXiv:1412.6980.
Listik (2018). Image reconstruction from resnet semantic
feature vector. In Poster.
Russakovsky, O., Deng, J., Su, H., Krause, J., Satheesh, S.,
Ma, S., Huang, Z., Karpathy, A., Khosla, A., Bern-
stein, M., et al. (2015). Imagenet large scale visual
recognition challenge. International Journal of Com-
puter Vision, 115(3):211–252.
Shang, E.-X. and Zhang, H.-G. (2016). Image spam clas-
sification based on convolutional neural network. In
Machine Learning and Cybernetics (ICMLC), 2016
International Conference on, pages 398–403. IEEE.
Wu, C.-T., Cheng, K.-T., Zhu, Q., and Wu, Y.-L. (2005).
Using visual features for anti-spam filtering. In Im-
age Processing, 2005. ICIP 2005. IEEE International
Conference on, volume 3, pages III–509. IEEE.
Zaharia, M., Xin, R. S., Wendell, P., Das, T., Armbrust,
M., Dave, A., Meng, X., Rosen, J., Venkataraman, S.,
Franklin, M. J., et al. (2016). Apache spark: A unified
engine for big data processing. Communications of
the ACM, 59(11):56–65.
ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy
464
