Conversational Scaffolding: An Analogy-based Approach to Response

Prioritization in Open-domain Dialogs

Will Myers

, Tyler Etchart

and Nancy Fulda

Perception, Control and Cognition Laboratory, Brigham Young University, 3361 TMCB, Provo, Utah, U.S.A.

DRAGN Labs, Brigham Young University, 3361 TMCB, Provo, Utah, U.S.A.

Keywords:

Response Prioritization, Utterance Retrieval, Dialog Modeling, Natural Language Processing, Vector Space

Models, Word Embeddings, Conversational AI, Sentence Representations, Analogical Reasoning.

Abstract:

We present Conversational Scaffolding, a response-prioritization technique that capitalizes on the structural

properties of existing linguistic embedding spaces. Vector offset operations within the embedding space are

used to identify an ‘ideal’ response for each set of inputs. Candidate utterances are scored based on their co-

sine distance from this ideal response, and the top-scoring candidate is selected as conversational output. We

apply our method in an open-domain dialog setting and show that the most effective analogy-based strategy

outperforms both an Approximate Nearest-Neighbor approach and a naive nearest neighbor baseline. We also

demonstrate the method’s ability to retrieve relevant dialog responses from a repository containing 19,665 ran-

dom sentences. As an additional contribution we present the Chit-Chat dataset, a high-quality conversational

dataset containing 483,112 lines of friendly, respectful chat exchanges between university students.

1 INTRODUCTION

High-quality conversational data is a scarce resource

even in the modern internet era. Unmoderated on-

line interactions, while plentiful and easy to harvest,

fail to exhibit the verbal patterns, topical continuity,

and social restraint that one would like to see in a

personal assistant or other conversational agent. The

prevalence of trolls in online chat forums and social

media platforms is particularly problematic (Buckels

et al., 2014) (Rainie and Anderson, 2017), especially

when anonymous or pseudonymous commenting is

possible (Cho and Acquisti, 2013). Even in heav-

ily moderated contexts or in datasets that have been

hand-curated to ﬁlter out derogatory posts, the length

and content of comments may differ drastically from

natural conversation (Schneider et al., 2002). Data

harvested from recordings or phone conversations is

subject to transcription errors, rambling thoughts, and

incomplete sentences, while dialogs extracted from

novels or movie scripts run the risk of being melo-

dramatic and inauthentic. (It would seem odd indeed

if a personal assistant trained using such data were to

profess undying love toward its conversation partner.)

Given this data scarcity, researchers face the ques-

tion: How shall automated systems mimic human be-

havior when so little source information is available?

We address this question by ﬁrst observing that,

while language is combinatorial in nature and thus

able to represent a nearly inﬁnite span of ideas, the

patterns of language are far more tractable. Certain

types of statements encourage certain types of re-

sponses, regardless of the speciﬁc conversation topic.

These patterns can be detected and imitated via the

use of analogical relations within a pre-trained em-

bedding space. Thus, a relatively small corpus of ex-

emplars can be used to guide the response ranking

system of a conversational agent.

The basic concept is simple: We begin by encod-

ing a reference corpus, called our scaffold, using one

of many available pre-trained embedding models. In-

coming utterances are matched against the scaffold

corpus based on the embedded concatenation of the

utterances in the dialog history, and the top n con-

textual matches are used to calculate an analogically

coherent response, or target point within the embed-

ding space. The candidate utterance with the lowest

cosine distance from the target point is selected as the

agent’s dialog response.

We examine the effectiveness of our algorithm on

a response prediction task and show that the most

effective vector offset method outperforms both an

Approximate Nearest Neighbor classiﬁer and a naive

nearest-neighbor approach. We then apply our scaf-

Myers, W., Etchart, T. and Fulda, N.

Conversational Scaffolding: An Analogy-based Approach to Response Prioritization in Open-domain Dialogs.

DOI: 10.5220/0008939900690078

In Proceedings of the 12th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2020) - Volume 2, pages 69-78

ISBN: 978-989-758-395-7; ISSN: 2184-433X

folding technique to a real-time conversational sce-

nario using a new, high-quality conversational corpus

called the Chit-Chat dataset. We show that the result-

ing automated responses, while not perfect, neverthe-

less mimic the style and ﬂow of human conversation.

2 RELATED WORK

Retrieval systems for conversational AI have his-

torically relied on statistical models such as Term

Frequency-Inverse Document Frequency (TF-IDF)

(Salton and McGill, 1986) (Gandhe and Traum, 2013)

(Charras et al., 2016) or token-level vector space

models (Banchs and Li, 2012) (Dubuisson Duplessis

et al., 2017) (Charras et al., 2016), with cosine dis-

tance used to score candidate utterances. More re-

cently, a variety of neural models for information re-

trieval have been explored, including a paraphrase

matching algorithm utilizing recursive auto-encoders

(Nio et al., 2016), models based on LSTMs and other

recurrent units (Lowe et al., 2017) (Nio et al., 2016),

and sequential matching networks that use an RNN to

accumulate vectors representing the relationship be-

tween each response and the utterances in the context

(Wu et al., 2017). The potential effectiveness of such

methods is limited, however, by the relative scarcity

of high-quality conversational training data.

2.1 Semantic Comparisons

The recent availability of general purpose pre-trained

linguistic embedding spaces opens new possibilities

for utterance retrieval. Sentence-level embedding

spaces such as skip-thought vectors (Kiros et al.,

2015), quick-thought vectors (Logeswaran and Lee,

2018), InferSent (Conneau et al., 2017), and Google’s

Universal Sentence Encoder (Cer et al., 2018), as well

as task-speciﬁc embeddings extracted from popular

generative models such as HRED (Serban et al., 2016)

and GPT-2 (Radford et al., ), are often used to approx-

imate the semantic distance between two sentences.

For example, Bartl et al. use conversational contexts

extracted from HRED embeddings to retrieve a set

of n candidate sentences via an Approximate Near-

est Neighbor (ANN) algorithm (Bartl and Spanakis,

2017). Each candidate is then scored based on its co-

sine similarity to each of the other candidates in the

retrieved set.

Alas, linguistic embedding models do not strictly

encode semantic structure (Thalenberg, 2016) (Dou

et al., 2018) (Kim et al., 2016), and the use of cosine

distance as an approximation of semantic similarity is

only partially successful (Fu et al., 2018) (Patro et al.,

2018). The development of embedding spaces with

improved semantic structure is an active area of re-

search (Zhu et al., 2018) (Conneau et al., 2018), how-

ever, we circumvent this limitation by relying on the

cosine distances between vector offsets, rather than

between the embeddings themselves, in order to cal-

culate our target point.

2.2 The Analogical Structure of

Embedding Spaces

Our dialog response ranking algorithm leverages the

analogical structure inherent in language, and by ex-

tension also inherent in linguistic embedding spaces,

to improve response selection. In many computer

science communities it is commonly known that

word embeddings such as word2vec (Mikolov et al.,

2013a), GLoVE (Pennington et al., 2014), and Fast-

Text (Bojanowski et al., 2016) can be used to solve

linguistic analogies of the form a:b::c:d. This is

generally accomplished using vector offsets such as

[Madrid - Spain + France ≈ Paris] or [walking -

walked + swimming ≈ swam] (Mikolov et al., 2013b)

(Gladkova et al., 2016). Query accuracy can be fur-

ther improved by averaging multiple vector offsets

(Drozd et al., 2016) (Fulda et al., 2017a) or by ex-

tending the length of the offset vector (Fulda et al.,

2017b).

Our research extends this notion of analogical re-

lationships into the realm of multi-word embeddings.

We postulate (and show via our results) that sentence-

level embedding spaces can contain similar analogi-

cal relationships, and that these relationships can be

utilized to select plausible responses in open-domain

dialogs. Thus, rather than evaluating candidate re-

sponses based on their strict distance to exemplars in

the scaffold corpus, we instead rely on the relative dis-

tance between pairs of sentences in order to locate an

idealized response vector which corresponds to point

d in the classic a:b::c:d analogical form. Candidate

responses are scored based on their cosine distance

from this target point.

3 ALGORITHM

Our conversational scaffolding algorithm, ﬁrst intro-

duced as an experimental sub-component of (Fulda

et al., 2018), is expanded and reﬁned in this work

by clarifying the localization technique and by per-

forming a structured evaluation of response accuracy

across a variety of scoring algorithms, including new

baselines. We also provide an example of the algo-

rithm in action, showing its ability to retrieve relevant

ICAART 2020 - 12th International Conference on Agents and Artiﬁcial Intelligence

Figure 1: Workﬂow diagram: The dialog context is con-

verted to an array of sentence embeddings using Google’s

Universal Sentence Encoder, then passed to an embedded

concatenation localization function to determine the best

contextual match(es). The matched utterances (orange)

along with their direct successors (red) are then passed to

the Response Scoring Algorithm, which assigns a numeri-

cal value to each candidate response.

responses from a set of ca. 20,000 randomly-selected

sentences.

Figure 1 gives an overview of our methodology.

Given a dialog context of variable length, our al-

gorithm ﬁrst locates a set of high-quality contextual

matches within the scaffold corpus. These contex-

tual matches, along with the utterance directly fol-

lowing each context match, are then passed to one

of several scoring algorithms. All utterances are en-

coded using Google’s Universal Sentence Encoder

Lite (USE Lite) (Cer et al., 2018), a lightweight

but impressively robust embedding model. We se-

lected this model based on its unusually high per-

formance as a heuristic for semantic distance. Pre-

liminary experiments in our laboratory revealed that

USE Lite was able to achieve a Pearson’s r score of

0.752 on the 2013 Semantic Textual Similarity bench-

mark, the highest score of any model we tried. Other

model scores were: InferSent (0.718), FastText bag-

of-words (0.547), BERT (0.495), GloVe bag-of-words

(0.404), skip-thought vectors (0.214), and GPT-2 (-

0.052).

3.1 Contextual Alignment

Contextual alignment refers to the process of match-

ing incoming utterances against similar utterance pat-

terns within a scaffold corpus. This can be done

naively by using an Approximate Nearest Neighbor

algorithm based on a simple Euclidean distance met-

ric

. In this paradigm, for a dialog history of length n,

the optimal contextual match can be identiﬁed using

the expression

min

∑

i=1

||v

− s

z+i

|| (1)

where {v

,...,v

} are the vector embeddings of the

n most recent utterances in the current dialog and

z+1

,...,s

z+n

} represent the vectors located within a

sliding window of length n beginning at element z of

the pre-embedded scaffold corpus. The notation ||x||

represents the Euclidean norm of vector x.

This Euclidean distance approach is easy to calcu-

late, but it ignores the powerful analogical structure

inherent within the embedding space. For example,

assume we have the following dialog history coupled

with two potential contextual matches in the scaffold

corpus:

dialog history

1. Did you watch the basketball game?

2. Yeah, that slam dunk at the end was really

impressive.

contextual match A

1. Did you watch the football game?

2. Yeah, that touchdown at the end was really

impressive.

contextual match B

1. Did you watch the basketball game?

2. Yeah, that was an impressive game.

Using the example text, a Euclidean distance ap-

proach using Google’s Universal Sentence Encoder

Lite and Eq. 1 above will select contextual match B

(with a summed distance of 0.884) over A (which has

a summed distance of 1.191). And yet in many ways,

contextual match A is a closer semantic parallel to the

actual dialog history. In particular, the conversational

pattern exhibited in A is an almost perfect match for

the dialog, even though the speciﬁc topic differs.

In order to capture such subtleties, we propose an

alternate method of contextual alignment: Embedded

Concatenation. Embedded Concatenation leverages

the structure of the embedding space by concatenating

the input sentences prior to encoding them via Univer-

sal Sentence Encoder Lite (Cer et al., 2018). A naive

Approximate approaches, rather than a more rigorous

K-Nearest Neighbor algorithm, are used in order to improve

computation speed.

Any valid distance metric, such as cosine distance, can

be used. We tested both cosine and Euclidean distance, but

found the latter to be empirically better.

Conversational Scaffolding: An Analogy-based Approach to Response Prioritization in Open-domain Dialogs

Figure 2: Naive Analogy, where: c (green) represents the embedded input utterance, a

(blue) represent the nearest embedded

utterances from the scaffold corpus, b

(red) represent the embedded successors to a

in the scaffold corpus, d

= c + b

− a

(yellow) represents the ‘ideal’ response, and g

(grey and black) represent embedded candidate responses with g

(black)

representing the response selected by the naive-analogy scoring algorithm. Image originally from (Fulda et al., 2018).

Figure 3: Scattershot Method, where: c (green) represents the embedded input utterance, a

(blue) represent the nearest

embedded utterances from the scaffold corpus, b

(red) represent the associated embedded successors to a

in the scaffold,

= c + (b

− a

) (yellow) represent the ‘ideal’ responses, and g

(grey and black) represent embedded candidate responses

with g

(black) representing the response selected by the scattershot scoring algorithm. Image originally from (Fulda et al.,

2018).

Euclidean distance metric is then used to match the

embedded concatenation against each element in the

pre-embedded scaffold corpus. The optimal contex-

tual match is:

min

||embed(h

+ ... + h

) − s

|| (2)

where {h

,...,h

} are the plain text (i.e. unembedded)

utterances in the dialog history, the + symbol rep-

resents string concatenation (with an extra space in-

serted between sentences), s

is an arbitrary vector lo-

cated within the pre-embedded scaffold corpus, and

embed(x) denotes the process of embedding a plain

text utterance x to obtain its corresponding vector rep-

resentation.

Note that the described localization method as-

sumes that only a single, optimal, contextual match is

desired. This was done for simplicity. In reality, it is

often beneﬁcial to take the k best matches, and in fact

many of the scoring algorithms in section 3.2 require

k > 1. The diagrams in Section 3.2 assume a value

of k = 3 for clarity. In our empirical experiments, a

value of k = 5 was used.

3.2 Candidate Response Scoring

Once the top k contextual matches for the dialog his-

tory have been identiﬁed, the candidate responses can

be scored. Candidate responses may come from a

repository of pre-selected utterances, or they may be

produced dynamically via generative models, scripted

templates, or other text generation methods. For ease

of representation, the algorithm descriptions in Fig-

ures 2-4 assume a conversation history of length 1

combined with a Euclidean distance approach to con-

versational localization. Extensions to longer conver-

sation histories and to the embedded concatenation

localization method are straightforward and easy to

implement.

In Figs 2-4, the use of the letters a

, b

, c, and d

corresponds to the classic linguistic analogy structure

a:b::c:d (‘a is to b as c is to d’), which can be solved

using vector offsets of the form c + b - a = d.

1. Naive Analogy (Fig 2). This scoring algo-

rithm represents the simplest possible use of analogi-

cal structure when scoring candidate responses, and

is an extension at the sentence level of the classic

a:b::c:d analogies used in conjunction with word em-

ICAART 2020 - 12th International Conference on Agents and Artiﬁcial Intelligence

Figure 4: Flow Vectors Method, where: c (green) represents the embedded input utterance, a

(blue) represent the nearest

embedded utterances from the scaffold corpus, b

(red) represent the associated embedded successors to a

in the scaffold

corpus, d

= c+1/n

∑

−a

) (yellow) represents the ‘ideal’ response, and g

(grey and black) represent embedded candidate

responses with g

(black) representing the response selected by the ﬂow vectors scoring algorithm. Image originally from

(Fulda et al., 2018).

beddings (Mikolov et al., 2013b) (Gladkova et al.,

2016). Using a value of k = 1, the naive analogy lo-

cates the single best context match within the scaffold

corpus, along with its (pre-embedded) successor. The

vector difference between the successor and the last

sentence in the context window is then added to the

embedded vector representation of the most recent ut-

terance in the dialog history. Candidate utterances are

scored based on their distance from the resulting point

in vector space.

2. Scattershot (Fig 3). The scattershot scoring

algorithm takes the non-deterministic nature of lan-

guage into account by assuming that there are many

valid responses. It therefore searches for a candidate

response that matches any of several high-scoring

context matches. In this method, the vector differ-

ences between each context match and its respective

successor are calculated separately, and then added to

the vector embedding of the most recent utterance in

the dialog history. The result is a set of k target points,

each of which represents a possible valid conversa-

tional response. The candidate located nearest to any

one of these points receives the highest score.

3. Flow Vectors (Fig 4). Lastly, the ﬂow vec-

tors algorithm presumes that there is some manifold

of acceptable responses within the embedding space,

and seeks to calculate the centroid of that manifold

by averaging the differences between multiple context

matches and their successors. The candidate response

nearest to this averaged centroid receives the highest

score.

4 THE CHIT-CHAT DATASET

To be effective, our algorithmic approach requires a

high-quality conversational dataset to be used as a

scaffold. The scaffold dataset will deﬁne the style

and feel of the human-computer interaction, so its

contents should mimic genuine, in-person conversa-

tions as much as possible. It should also cover a wide

range of topics, be free from offensive or trollish be-

havior, include ﬂuid and natural-sounding sentences,

and not be unduly cluttered with web-links, marketing

material, or emoticons. Unsatisﬁed with the dataset

options available at the time we commenced our re-

search, we elected to construct our own.

The Chit-Chat dataset (https://github.com/BYU-

PCCL/chitchat-dataset) is a novel dataset generated

using a university-wide conversational competition

launched in 2018. Working in conjunction with a

marketing team, we created a website that would ran-

domly pair students together and let them chat via

a simple text-message interface. Participants’ chats

were scored based on the number of words used per

turn, number of turns, absence of incendiary lan-

guage, use of correct grammar, and so forth. The

highest scoring chatters received prizes.

The resulting dataset contains 482,112 dialog

turns from over 1200 users, with a vocabulary size

of 85,952. A key element of the Chit-Chat dataset is

the commitment, made by each participant when sign-

ing up for the competition, that they would abstain

from mean-spirited or offensive behaviors. While this

is difﬁcult to police algorithmically, post-competition

examinations of the chat data reveal that by and large,

the students held to their agreement. They tried to

seek common ground rather than points of discord,

and when they disagreed with each other, they did

so in a respectful and non-inﬂammatory manner. We

have found the Chit-Chat conversations highly useful,

and are releasing the dataset publicly in hopes that it

will help other researchers.

Conversational Scaffolding: An Analogy-based Approach to Response Prioritization in Open-domain Dialogs

5 EXPERIMENTS

In current state-of-the-art conversational systems,

candidate utterances may be obtained via generative

models (Sutskever et al., 2014) (Vaswani et al., 2017),

template-based algorithms (Fulda et al., 2018), or

pre-built language repositories (Wu et al., 2017) (Al-

Zubaide and Issa, 2011). Our experimental setup is

based on the latter case, although the same algorithms

could easily be used to prioritize over utterances pro-

duced by hand-coded scripts or by an ensemble of

neural generators.

We structure our empirical evaluation as a clas-

siﬁcation task with six candidate responses. One of

the responses is the actual next sentence in the dia-

log. The other ﬁve candidates are randomly-chosen

distractors drawn from the same dialog corpus as the

conversation history. The task of the agent is to lever-

age the dialog patterns in the scaffold corpus to iden-

tify the correct response. All experiments in this sec-

tion used a context length n = 2 and considered the

k = 5 best matches for each scaffolding algorithm.

5.1 Text Corpora

To simulate an open-domain dialog setting, we

needed candidate utterances with a broad spread of

conversation topics and dialog styles. To achieve this,

we merged data from four different sources:

1. Chit-Chat

2. Daily Dialog

(Li et al., 2017)

3. A 33 million word subset of Reddit

4. Ubuntu Dialogue Corpus

(Lowe et al., 2015)

The Chit-Chat dataset, collected locally via a uni-

versity competition, contains 483,112 dialog turns be-

tween university students using an informal online

chat framework. The Daily Dialog dataset simulates

common, real-life interactions such as shopping or

ordering food at a restaurant. Reddit

covers an ar-

ray of general topics, with copious instances of web

links, internet acronyms, and active debate. Finally,

the Ubuntu Dialogue Corpus contains 966,400 dialog

turns taken from the Ubuntu Chat Logs, with a heavy

emphasis on troubleshooting and technical support.

https://github.com/BYU-PCCL/chitchat-dataset

https://aclanthology.coli.uni-saarland.de/papers/I17-

1099/i17-1099

http://ﬁles.pushshift.io/reddit/

https://www.kaggle.com/rtatman/ubuntu-dialogue-

corpus

Due to the massive size of Reddit, we only used a sub-

set of the comments and posts from June 2014 to November

2014.

5.2 Evaluation Task

To evaluate our scaffolding algorithms, we began by

splitting the combined dataset into two blocks: (1) a

scaffold corpus, and (2) an evaluation corpus. The

agent’s task was to predict the correct follow-on sen-

tence for each dialog in the evaluation corpus.

Table 1: Dataset Statistics.

Chit-Chat

Number of Words 8,433,086

Number of Turns 483,112

Average Length of Turns 88.86

Vocabulary Size 85,952

Daily Dialog

Number of Words 3,449,782

Number of Turns 243,520

Average Length of Turns 62.85

Vocabulary Size 26,116

Number of Words 33,847,503

Number of Turns 966,400

Average Length of Turns 194.73

Vocabulary Size 434,539

Ubuntu

Number of Words 15,696,635

Number of Turns 966,400

Average Length of Turns 88.33

Vocabulary Size 145,594

To set up this task, we ﬁrst needed to standardize

the formats of the datasets. Chit-Chat, Daily Dialog,

and the Ubuntu Dialogue Corpus are all two-partner

conversations. The Reddit data has a tree-like struc-

ture with an original post at the top, initial comments

responding to the original post, more comments re-

sponding to the initial comments, and so forth. These

threads of comments are not necessarily conversa-

tions between the same two users, as any user could

post a comment in any thread. In standardizing the

data, we chose to ignore distinctions between actual

users and ﬂatten the tree so that any Reddit thread was

treated as a two-partner conversation between some

speaker A and another speaker B.

Because some datasets, like Chit-Chat and the

Ubuntu Dialogue Corpus, had many turns per con-

versation, we windowed our original data to create

a sequence of shorter conversations with smaller di-

alog contexts. We chose a window size of four and a

stride of one. Hence, if our original conversation had

six turns, the windowed data would have three new

ICAART 2020 - 12th International Conference on Agents and Artiﬁcial Intelligence

conversations with four turns each. We then set aside

3,311 conversations (about 5% of the smallest corpus)

from each dataset to create the evaluation corpus, with

the rest used as scaffolding.

Finally, the evaluation corpus was used to create a

sequence of 13,244 windowed conversations. Each

dialog from this evaluation set was paired with six

candidate responses: (a) the correct follow-on sen-

tence for the given dialog history, and (b) ﬁve distrac-

tors randomly chosen from the same text corpus as the

correct answer. The scaffolding algorithms in Section

3.2, along with several baselines described in Section

5.3, were tasked with identifying the true response.

5.3 Baselines

We selected three baselines to compare against our

candidate response scoring algorithms, our objective

being to determine whether performance improves

when the analogical structure of the embedding space

is taken into consideration.

Naive Nearest

This algorithm is a non-analogical companion to the

Naive Analogy algorithm depicted in Figure 2. Rather

than calculating the ideal response as d

= c +b

−a

the naive-nearest algorithm calculates d

= b

. In

other words, the Naive Nearest algorithm ignores the

analogical nature of language by assuming that the

successor to the best context match represents an op-

timal response, even if the contexts do not match ex-

actly.

Approximate Nearest Neighbor (ANN)

This algorithm implements an Approximate Nearest

Neighbor scoring strategy. Its ideal target point is cal-

culated in the same way as the ﬂow vectors algorithm,

but with d

= 1/n

∑

. The analogical structure of

the embedding space is ignored, and the algorithm in-

stead orients itself based on the successor utterances

extracted from the scaffold corpus.

Random

This baseline randomly selects one of the candidate

responses without reference to the dialog history.

5.4 Results

Experimental results are shown in Table 2. Since no

data was available on the relative ranking of the dis-

tractor sentences, we chose to evaluate our experi-

mental results via response accuracy rather than via

mean reciprocal rank or other metrics.

With a response accuracy of 68.07%, the scat-

tershot algorithm shows a clear advantage over all

other variants, outperforming the nearest baseline by

Table 2: Algorithm accuracy on a response prioritization

task with 13,244 distinct conversations. These experiments

used a context length n = 2 and considered the k = 5 best

context matches when calculating target point locations.

scoring method accuracy

our algorithms

ﬂow vectors 62.47%

scattershot 68.07%

naive-analogy 62.29%

baselines

naive-nearest 58.97%

ANN classiﬁer 64.96%

random 16.06%

3.11%. We hypothesize that this is because scatter-

shot takes the nondeterministic nature of language

into account, allowing the scaffolding algorithm to

select a candidate that most closely matches one of

many possible valid responses.

It is also useful to compare the naive-analogy al-

gorithm with the naive-nearest baseline. These two

algorithms are identical except for their analogical

content. Our results show that leveraging the inherent

analogical properties of the embedding space results

in an overall accuracy improvement of 3.32%.

5.5 Analysis

A key insight to be taken from our results is the ob-

servation that the average of several valid responses

cannot be assumed to also represent a valid response.

This amounts to taking the centroid of a (possibly

oddly-shaped) manifold, resulting in a vector that

might easily represent a nonsense sentence.

For example, the question “Have you seen any

good movies lately?” can be appropriately answered

by statements including “Yes”, “No”, “I saw Iron Man

last night”, and “Are you crazy? You know I’m afraid

of theaters.” These disparate responses, all valid with

respect to the dialog context, nevertheless vary widely

in terms of sentence length, sentiment, vocabulary,

and dialog mode. There is no reason to assume that

a sentence which represents the average of all those

factors will have any relevance to the dialog history,

or that it will even be grammatically correct.

This observation explains the empirical success of

the scattershot algorithm over its competitors. The

naive-nearest and naive-analogy algorithms take only

a single context match into consideration, and there-

fore function on limited information. The scattershot,

ﬂow vector and ANN algorithms all take many con-

text matches into consideration, but while the ﬂow

vector and ANN algorithms operate by averaging

multiple ‘ideal’ responses, the scattershot algorithm

Conversational Scaffolding: An Analogy-based Approach to Response Prioritization in Open-domain Dialogs

> Hello.

Hey!

> How are you doing today?

How are you?

> I am good. How has your day been so far?

I’ve been pretty good, I was sick earlier, but better now.

> Oh man, that stinks. What were you sick with? I am glad

you are feeling better though!

I had like ten servings of it.

> Uh oh. That sounds like a lot. Was it good food?

I had such tasty food too.

> Yum. What is your favorite food?

yum sounds so good right now haha! I love every fruit! I

like rice and pickles too haha. but like you I like just

about everything

> I love fruit too. So, have you seen any good movies

lately?

Black panther is so good!!!

> Yeah I really liked it too. I think that or, Thor

Ragnarok might be my favorite Marvel movie.

No , I haven’t . This is my first time to watch it .

> Oh yeah?

*It flips him off.*

> What are some of your favorite books?

It’s a little bit of romance and comedy.

> Cool. Well, I have to go. It has been nice talking to

you!

Okay ! Bye !

Figure 5: Conversation generated using the scattershot

scaffolding algorithm and Euclidean distance localization

method, and distance threshold τ = 0.5. Human-generated

text is preceded by the > symbol. In this example, the agent

is able to maintain several fairly coherent dialog turns, then

pivots appropriately to the topic of movies in response to

user cues. It also successfully detects and responds to an

indication that the conversation is over.

seeks a response that lies close to any one of the scaf-

fold examples. This enables it to select the correct

response candidate a higher percentage of the time.

6 RETRIEVAL FROM LARGE

DATA REPOSITORIES

To explore the types of conversations produced by our

system, we allowed a human to type the opening line

of dialog with an agent executing the scattershot algo-

rithm. The objective was to see whether a dialog agent

choosing from among ca. 10,000 candidate responses

could leverage the analogical structure of language in

order to create a plausible conversation.

Typical conversations generated using this method

are shown in Figures 5 and 6. Interestingly, although

the 19,665 randomly-selected candidate utterances

> Hey. What’s up?

Hey, whats up?

> Not much. How is your day going so far?

Hi, it’s good!

> Good to hear. What are you working on?

I’m figuring out my budget .

> Oh that sounds fun. What are you going to do after you

finish?

Well I plan to get into the accounting program

> Oh cool! Do you like accounting?

I’ve thought about going into cardiology, that seems

interesting, but also I’m considering anesthesiology.

> Oh wow. Those are both very different from accounting.

Are they hard?

semester for you and me. Is your next semester seeming to

look like its going to be a little easier?

> I think this semester will be fun but a little

challenging.

That it does! Even though you may not be getting

everything out of your classes now but oh well...;)

> Do you think you will have any time to go to see a movie

this semester?

That it does! Even though you may not be getting

everything out of your classes now but oh well...;)

> So, where are you from originally?

Haha well I’m from Arkansas

> Oh cool. I have never been there. Do you like it?

Ya actually I did enjoy the shreveport one when I lived

there last year (2012 Mardi gras) but you’re right, it’s

almost nothing Compared to most of the NO ones. Still very

enjoyable. My of my friends lives right on the route so it

was nice having somewhere to go for it lol

> haha fun. Do you like it here then?

Cool

> If you could vacation anywhere, where would it be?

well,its like 1 am here,i should get to bed, it was nice

talking to you, have a great day.

> Oh wow. Goodnight. Talk to you later.

Thanks. You too!

Figure 6: Conversation generated using the scattershot scaf-

folding algorithm, the embedded concatenation localization

method, and distance threshhold τ = 0.6. Human-generated

text is preceded by the > symbol. In this example, even

the τ threshhold is not sufﬁcient to keep the agent from get-

ting caught in a sentence repetition, however, it successfully

switches to a new topic on the next utterance.

were drawn from all four conversational datasets, al-

most all of the ones chosen by the scattershot algo-

rithm came from the Chit-Chat dataset. This suggests

that the Chit-Chat dataset was an unusually good

stylistic match for the informal conversation patterns

used by the human chatter.

We permitted one augmentation to our algorithms

for this experiment: Candidate responses that were

too similar to the most recent statement in the dialog

ICAART 2020 - 12th International Conference on Agents and Artiﬁcial Intelligence

history were excluded from consideration.

This con-

stitutes an extension at the sentence level of the tra-

ditional exclusion of source words when solving ana-

logical queries via word embeddings (Mikolov et al.,

2013b) (Gladkova et al., 2016). Without it, the scaf-

folding algorithm tends to select sentences that parrot

or reﬂect the content of the dialog history rather than

progressing to new topics.

7 CONCLUSIONS AND FUTURE

WORK

As automated personal assistants become more preva-

lent, developers will need to strike a balance between

control and spontaneity. It is important for automated

agents to behave in unexpected, even surprising ways;

otherwise they could not generalize from past experi-

ence in order to respond to unique queries from their

users. At the same time, we do not want assistants

who insult their users, make broadly offensive state-

ments, or give inaccurate information.

The methods outlined in this paper provide a pos-

sible middle ground, allowing a scaffold corpus to de-

ﬁne an overall personality or conversational style for

the agent without directly restricting its possible ut-

terances. In this paper, we have presented a scaffold-

ing algorithm that uses pre-trained sentence embed-

dings to (a) leverage the inherent analogical proper-

ties of the embedding space and (b) account for the

frequently non-deterministic nature of language while

scaffold corpus. Our scattershot algorithm is able to

predict the correct follow-on sentence for a given dia-

log history with nearly 70% accuracy, outperforming

both ANN and naive nearest-neighbor baselines.

Going forward, we imagine a possible future agent

which generates responses via a neural architecture,

but which has been trained to adhere as closely as

possible to a scaffold corpus in its utterance patterns.

Future work in this area should explore the possibility

of neural dialog models that utilize a scaffold corpus

during loss calculations, as well as the development

of decoders that can render the target point directly

into text. A comprehensive study of distance metrics

should also be undertaken, as it is not certain that the

de facto standards of Euclidean and cosine distance

are the best possible heuristics for semantic similar-

ity; L1 distance or correlation coefﬁcients might be

more effective.

Similarity was deﬁned as Euclidean distance < τ,

where τ is a hand-selected threshhold value.

ACKNOWLEDGEMENTS

We thank David Wingate and his students in the BYU

Perception, Control and Cognition laboratory for their

role in creating and hosting the Chit-Chat dataset.

REFERENCES

Al-Zubaide, H. and Issa, A. A. (2011). Ontbot: Ontology

based chatbot. In International Symposium on Inno-

vations in Information and Communications Technol-

ogy, pages 7–12.

Banchs, R. E. and Li, H. (2012). Iris: a chat-oriented di-

alogue system based on the vector space model. In

Proceedings of the ACL 2012 System Demonstrations,

pages 37–42. Association for Computational Linguis-

tics.

Bartl, A. and Spanakis, G. (2017). A retrieval-based dia-

logue system utilizing utterance and context embed-

dings. In 16th IEEE International Conference on Ma-

chine Learning and Applications, ICMLA 2017, Can-

cun, Mexico, December 18-21, 2017, pages 1120–

1125.

Bojanowski, P., Grave, E., Joulin, A., and Mikolov, T.

(2016). Enriching word vectors with subword infor-

mation. arXiv preprint arXiv:1607.04606.

Buckels, E. E., Trapnell, P. D., and Paulhus, D. L. (2014).

Trolls just want to have fun. Personality and individ-

ual Differences, 67:97–102.

Cer, D., Yang, Y., Kong, S., Hua, N., Limtiaco, N., John,

R. S., Constant, N., Guajardo-Cespedes, M., Yuan, S.,

Tar, C., Sung, Y., Strope, B., and Kurzweil, R. (2018).

Universal sentence encoder. CoRR, abs/1803.11175.

Charras, F., Duplessis, G. D., Letard, V., Ligozat, A.-L.,

and Rosset, S. (2016). Comparing system-response

retrieval models for open-domain and casual conver-

sational agent. In Second Workshop on Chatbots

and Conversational Agent Technologies (WOCHAT@

IVA2016).

Cho, D. and Acquisti, A. (2013). The more social cues, the

less trolling? an empirical study of online comment-

ing behavior.

Conneau, A., Kiela, D., Schwenk, H., Barrault, L., and Bor-

des, A. (2017). Supervised learning of universal sen-

tence representations from natural language inference

data. arXiv preprint arXiv:1705.02364.

Conneau, A., Kruszewski, G., Lample, G., Barrault, L., and

Baroni, M. (2018). What you can cram into a sin-

gle vector: Probing sentence embeddings for linguis-

tic properties. arXiv preprint arXiv:1805.01070.

Dou, Z., Wei, W., and Wan, X. (2018). Improving word

embeddings for antonym detection using thesauri and

sentiwordnet. In CCF International Conference on

Natural Language Processing and Chinese Comput-

ing, pages 67–79. Springer.

Drozd, A., Gladkova, A., and Matsuoka, S. (2016). Word

embeddings, analogies, and machine learning: Be-

yond king-man+ woman= queen. In Proceedings of

COLING 2016, the 26th International Conference on

Conversational Scaffolding: An Analogy-based Approach to Response Prioritization in Open-domain Dialogs

Computational Linguistics: Technical Papers, pages

3519–3530.

Dubuisson Duplessis, G., Charras, F., Letard, V., Ligozat,

A.-L., and Rosset, S. (2017). Utterance Retrieval

based on Recurrent Surface Text Patterns. In 39th

European Conference on Information Retrieval, Ab-

erdeen, United Kingdom.

Fu, P., Lin, Z., Yuan, F., Wang, W., and Meng, D.

(2018). Learning sentiment-speciﬁc word embedding

via global sentiment representation. In Thirty-Second

AAAI Conference on Artiﬁcial Intelligence.

Fulda, N., Etchart, T., Myers, W., Ricks, D., Brown, Z.,

Szendre, J., Murdoch, B., Carr, A., and Wingate, D.

(2018). Byu-eve: Mixed initiative dialog via struc-

tured knowledge graph traversal and conversational

scaffolding. In Proceedings of the 2018 Amazon Alexa

Prize.

Fulda, N., Ricks, D., Murdoch, B., and Wingate, D.

(2017a). What can you do with a rock? affordance ex-

traction via word embeddings. In Proceedings of the

Twenty-Sixth International Joint Conference on Artiﬁ-

cial Intelligence, IJCAI-17, pages 1039–1045.

Fulda, N., Tibbetts, N., Brown, Z., and Wingate, D.

(2017b). Harvesting common-sense navigational

knowledge for robotics from uncurated text corpora.

In Proceedings of the First Conference on Robot

Learning (CoRL) - forthcoming.

Gandhe, S. and Traum, D. (2013). Surface text based dia-

logue models for virtual humans. In Proceedings of

the SIGDIAL 2013 Conference, pages 251–260.

Gladkova, A., Drozd, A., and Matsuoka, S. (2016).

Analogy-based detection of morphological and se-

mantic relations with word embeddings: what works

and what doesn’t. In Proceedings of the NAACL Stu-

dent Research Workshop, pages 8–15.

Kim, J.-K., de Marneffe, M.-C., and Fosler-Lussier, E.

(2016). Adjusting word embeddings with semantic

intensity orders. In Proceedings of the 1st Workshop

on Representation Learning for NLP, pages 62–69.

Kiros, R., Zhu, Y., Salakhutdinov, R., Zemel, R. S., Tor-

ralba, A., Urtasun, R., and Fidler, S. (2015). Skip-

thought vectors. CoRR, abs/1506.06726.

Li, Y., Su, H., Shen, X., Li, W., Cao, Z., and Niu, S. (2017).

DailyDialog: A Manually Labelled Multi-turn Dia-

logue Dataset. arXiv e-prints, page arXiv:1710.03957.

Logeswaran, L. and Lee, H. (2018). An efﬁcient framework

for learning sentence representations. In International

Conference on Learning Representations.

Lowe, R., Pow, N., Serban, I., and Pineau, J. (2015). The

Ubuntu Dialogue Corpus: A Large Dataset for Re-

search in Unstructured Multi-Turn Dialogue Systems.

arXiv e-prints, page arXiv:1506.08909.

Lowe, R. T., Pow, N., Serban, I. V., Charlin, L., Liu, C., and

Pineau, J. (2017). Training end-to-end dialogue sys-

tems with the ubuntu dialogue corpus. D&D, 8(1):31–

65.

Mikolov, T., Chen, K., Corrado, G., and Dean, J. (2013a).

Efﬁcient estimation of word representations in vector

space. CoRR, abs/1301.3781.

Mikolov, T., tau Yih, W., and Zweig, G. (2013b). Linguistic

regularities in continuous space word representations.

Association for Computational Linguistics.

Nio, L., Sakti, S., Neubig, G., Yoshino, K., and Nakamura,

S. (2016). Neural network approaches to dialog re-

sponse retrieval and generation. IEICE Transactions,

99-D(10):2508–2517.

Patro, B. N., Kurmi, V. K., Kumar, S., and Namboodiri, V. P.

(2018). Learning semantic sentence embeddings us-

ing sequential pair-wise discriminator. arXiv preprint

arXiv:1806.00807.

Pennington, J., Socher, R., and Manning, C. D. (2014).

Glove: Global vectors for word representation. In

Empirical Methods in Natural Language Processing

(EMNLP), pages 1532–1543.

Radford, A., Wu, J., Child, R., Luan, D., Amodei, D., and

Sutskever, I. Language models are unsupervised mul-

titask learners.

Rainie, H. and Anderson, J. Q. (2017). The future of free

speech, trolls, anonymity and fake news online.

Salton, G. and McGill, M. J. (1986). Introduction to Mod-

ern Information Retrieval. McGraw-Hill, Inc., New

York, NY, USA.

Schneider, S. J., Kerwin, J., Frechtling, J., and Vivari, B. A.

(2002). Characteristics of the discussion in online and

face-to-face focus groups. Social science computer

review, 20(1):31–42.

Serban, I. V., Sordoni, A., Bengio, Y., Courville, A. C.,

and Pineau, J. (2016). Building end-to-end dialogue

systems using generative hierarchical neural network

models. In AAAI.

Sutskever, I., Vinyals, O., and Le, Q. V. (2014). Sequence to

sequence learning with neural networks. In Ghahra-

mani, Z., Welling, M., Cortes, C., Lawrence, N. D.,

and Weinberger, K. Q., editors, Advances in Neu-

ral Information Processing Systems 27, pages 3104–

3112. Curran Associates, Inc.

Thalenberg, B. (2016). Distinguishing antonyms from syn-

onyms in vector space models of semantics. Technical

report.

Vaswani, A., Shazeer, N., Parmar, N., Uszkoreit, J., Jones,

L., Gomez, A. N., Kaiser, L. u., and Polosukhin, I.

(2017). Attention is all you need. In Guyon, I.,

Luxburg, U. V., Bengio, S., Wallach, H., Fergus, R.,

Vishwanathan, S., and Garnett, R., editors, Advances

in Neural Information Processing Systems 30, pages

5998–6008. Curran Associates, Inc.

Wu, Y., Wu, W., Xing, C., Zhou, M., and Li, Z. (2017).

Sequential matching network: A new architecture for

multi-turn response selection in retrieval-based chat-

bots. pages 496–505.

Zhu, X., Li, T., and De Melo, G. (2018). Exploring seman-

tic properties of sentence embeddings. In Proceed-

ings of the 56th Annual Meeting of the Association for

Computational Linguistics (Volume 2: Short Papers),

pages 632–637.

ICAART 2020 - 12th International Conference on Agents and Artiﬁcial Intelligence
