Modeling Cyber Threat Intelligence

Siri Bromander

1,2

, Morton Swimmer

, Martin Eian

, Geir Skjotskift

and Fredrik Borg

mnemonic AS, Oslo, Norway

Department of Informatics, University of Oslo, Norway

Trend Micro Research, Germany

Keywords:

Cyber Threat Intelligence, Security, Knowledge Graph, Ontology.

Abstract:

For a strong, collective defense in the digital domain we need to produce, consume, analyze and share cyber

threat intelligence. With an increasing amount of available information, we need automation in order to be

effective. We propose a strict data model for cyber threat intelligence which enables consumption of all

relevant data, data validation and analysis of consumed content. The main contribution of this paper is the

strictness of the data model which enforces input of information and enables automation and deduction of new

knowledge.

1 INTRODUCTION

In recent years we have seen several initiatives to

structure and streamline Cyber Threat Intelligence

(CTI). Organizations share CTI, and most of the

CTI in an average organization comes from external

sources. Consuming, normalizing and analyzing CTI

from heterogeneous sources are major challenges for

CTI analysts. Successful defense against threats de-

pends on automation and to make available CTI more

useful. Big data analysis and advanced reasoning may

be applied, but these rely on consistent and structured

data. We propose the ACT data model to address

these challenges.

1.1 Research Motivation

Threat intelligence is served in several formats and

channels, and with a varying degree of structure. Hav-

ing worked with threat intelligence and incident re-

sponse we had a need for a data model that enabled

automation and analysis of our available threat intel-

ligence. Combining all available data in one place, al-

lowing for different data sources to be combined and

analyzed, will increase the analysis capability of an

analyst and remove repetitive tasks.

We ﬁnd import and export of CTI from a system

to be trivial given the data is stored in a consistent and

structured manner, covering all relevant data. How we

model our data is hence the foundation for everything

else.

A key requirement for automation and analysis is

data quality. Data quality is both content and for-

mat. We cannot enforce quality of content, but we

can enable an analyst to evaluate this. Format con-

sistency can be enforced by a strict data model. This

means that a computer knows where to ﬁnd a certain

data type in a data set, and that the data found in that

place always is the same type of data. With ﬂexibility

within the schema of a data model, this requirement

will not be met, removing the ability to automate con-

sumption and analysis across different platforms.

Threat intelligence analysis traditionally requires

a large amount of knowledge from the analyst.

Adding knowledge into the data model will make the

knowledge available to more analysts.

Threat intelligence depends on collaboration be-

tween a range of organizations and communities.

Any tool or system used by collaborators should

be openly available to the community without re-

strictions, which has been a key motivation for this

project.

2 RELATED WORK

There are several attempts at structuring cyber threat

intelligence (CTI). The motivations for the different

approaches seems to differ and these inﬂuence the re-

sults.

Barnum et al suggested the Structured Threat

Information Expression (STIX) (Barnum, 2012) in

Bromander, S., Swimmer, M., Eian, M., Skjotskift, G. and Borg, F.

Modeling Cyber Threat Intelligence.

DOI: 10.5220/0008875302730280

In Proceedings of the 6th International Conference on Information Systems Security and Privacy (ICISSP 2020), pages 273-280

ISBN: 978-989-758-399-5; ISSN: 2184-4356

273

2012. This was created with the motivation of shar-

ing CTI, preferably as more than just data. STIX was

intended as a data exchange format and not a sugges-

tion for how to store the data. STIX was published

in version 2.0 in 2017 (OASIS CTI TC, 2017) and ar-

gued to be the de facto standard for representing CTI

(Sauerwein et al., 2017). At the same time, critics of

STIX argue that the ﬂexibility of STIX makes it less

useful for automation. As there are different possibil-

ities of expressing the same data and information in

addition to a fair amount of data included in custom

ﬁelds or as comments using English prose (Polzunov

and Abraham, 2019), automating consumption and

further analysis is difﬁcult.

The Malware Information Sharing Platform

(MISP) (Wagner et al., 2016) is a platform for rapid

sharing of indicators of compromise and sightings of

indicators. The MISP data model is under continu-

ous development (MISP, 2019). The data contained

within MISP platforms correspond well with the sug-

gested data model in this paper, however the popular-

ity of the platform and loose data governance has led,

in our experience, to a decrease in the consistency of

the data.

ATT&CK (MITRE, 2019) is a framework and

knowledge base for describing adversary behavior

through enumerating adversary groups, tactics, tech-

niques and tools and the relationships between them.

The knowledge base is maintained by MITRE, and it

is published online. ATT&CK uses a data model with

deﬁned relationships for structuring their knowledge

base.

The OpenCTI platform (ANSSI et al., 2019) was

published in late spring 2019 and is a platform aiming

at consuming, analyzing and sharing cyber threat in-

telligence. The OpenCTI platform is including STIX

observables and STIX relationships in its data model.

Grakn

is used to enable graph querying of the data

and includes rule-based reasoning to infer new rela-

tionships. To the best of our understanding, OpenCTI

is limited to the scope of STIX and thus limits the

possibilities of consumption and analysis within the

platform.

An ontology, in the ﬁeld of computer science, is

a formal description of concepts and how they are re-

lated to each other, often referred to as classes and

properties. In turn, ontologies provide computational

meaning to data by building relations to the logic in

the ontology and thus enables us to use reasoning

methods (such as induction or deduction) on our data

in our knowledge base. While there are many imple-

mentations of knowledge bases and ontologies, the

World Wide Web Consortium (W3C) chose a triple

https://grakn.ai/

model for facts and calls this the Resource Descrip-

tion Framework (RDF). RDF also allows us to im-

plement the RDFS schema language

and OWL

, the

ontology language which builds upon RDFS.

There are several ontologies built with the aim to

structure security relevant data. They cover a range

of data and motivations like data validation, transfor-

mation or logical reasoning. An overview of available

ontologies may be found in (Mavroeidis and Broman-

der, 2017). To the extent of our knowledge, none of

the available ontologies are suitable for solving our

problem alone, however the UTIM

ontology is being

developed in parallel with this model and it is hoped

that one day data from the ACT model will be freely

interchangeable with data modeled with UTIM.

The rest of the paper is structured as follows: First

we describe the methodology of our work in Section

3. Then we explain the details of the data model, with

argumentation for our choices in Section 4, which in-

cludes a graph representation of the data model. We

discuss our ﬁndings in Section 5, and conclude in Sec-

tion 6.

3 METHODOLOGY

We developed the model using an iterative process

basing our design on the relevant threat intelligence

data we had available and then testing and updating

as needed.

The platform we have used to implement the data

model for prototyping and testing has been developed

using agile development principles. This is a good ﬁt

for our iterative process of data model development.

3.1 Limitations

While the data model is an ontology, it is not imple-

mented in RDFS or OWL, but all content can be ex-

ported as triplets. Initial testing of implementing the

data model using Prot

has been done in order to

ﬁnd improvements, but the desired reasoning capabil-

ities lead to the need for rule based reasoning, which

can be performed on top of the proposed data model

with other tools as well.

We need a strict data model to avoid bad data

in the knowledge base. The proposed data model

requires a certain amount of work to consume new

sources of data because of this chosen strictness.

https://www.w3.org/TR/rdf-schema/

https://www.w3.org/TR/owl2-overview/

Uniﬁed Threat Intelligence Model. See: http://www.

ti-semantics.com

https://protege.stanford.edu

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

274

4 RESULTS

We have created a data model and implemented it us-

ing an Apache Cassandra

and Elasticsearch

back-

end. We have implemented an Apache TinkerPop

graph engine which enables graph querying with the

use of the graph query language Gremlin

Note that a graph view is not the same as a graph

database. You can display any kind of data, even a ﬂat

text ﬁle, as a graph, but you cannot use graph queries

unless you have a graph engine interfacing with your

data.

An implementation of the data model can be found

on GitHub

under the ISC license. An openly avail-

able instance of the same implementation can be

found online

We have divided the results section into three: The

foundation of our data model and the discussion lead-

ing to it, the schema improvement due to additional

data, and the choice of allowing placeholder objects.

4.1 Foundation: Objects and Facts

The foundation for our work has been a data model

consisting of objects and facts. We can deﬁne dif-

ferent object types and different fact types. Thinking

of graphs, objects are the vertices and facts are the

edges. Objects can be described as nodes and facts

may be described as relationships. In the following

we use the terms objects and facts.

fqdn:www.examples.com

resolvesTo

−−−−−−→ ipv4:192.168.1.2

Figure 1: Objects and fact.

The speciﬁcations and restrictions to this model is

given in the next sections.

4.1.1 Immutable Objects - Retraction of Facts

Objects are deﬁned globally and are immutable.

There are no properties linked to an object, everything

you know about one object is stored as facts. A fact

may connect to one or two objects. A fact is directed,

and can be bidirectional.

Deleting a fact is also not possible, however a new

fact can be added that retracts the old one. In this way

we make sure nothing is deleted and we can prevent

repudiation. This way, we also preserve history and

check the history of the data set.

http://cassandra.apache.org/

https://www.elastic.co/

http://tinkerpop.apache.org/

https://tinkerpop.apache.org/gremlin.html

https://github.com/mnemonic-no/act-platform

https://act-eu1.mnemonic.no/

4.1.2 Time

Because facts cannot be deleted, we are able to tra-

verse the available data back and forth in time. Us-

ing the available threat intelligence in an incident re-

sponse setting, this is useful for two reasons:

Firstly, knowing exactly what we knew at a given

point in time. In situations where a range of decisions

are made within a time frame of months, it is useful

to be able to turn back time in order to know what

information were available at the time when the deci-

sion was made. When incorrect decisions have been

made, the ability to go back in time and see what in-

formation was available at that time will provide the

ability to learn from mistakes.

Secondly, knowing how a threat has evolved over

time. To know what infrastructure, behavior and re-

sources a given threat actor has used at different times

is useful in order to separate threat actors from each

other, to identify copycats or impersonation and in or-

der to evaluate how advanced the threat actor is. A

threat actor using novel techniques, but abandoning

them when they become normal behavior may be con-

sidered more advanced than others.

4.2 Data Model

Based on our object/fact foundation, we have deﬁned

a set of object types and fact types that are relevant

and necessary for our domain.

The initial selection of object types were done in-

ﬂuenced by STIX (Barnum, 2012), the Detection Ma-

turity Model (Stillions, 2014), the Diamond Model

(Caltagirone et al., 2013), available Open Source In-

telligence extracted with the use of Natural Language

Processing (NLP) and our own experience.

Fact types were added as we found them useful,

with an increasing attention to the semantics and the

characteristics of each of them. As our use cases for

querying the data expanded, we saw the usefulness of

differentiating between fact types.

Figure 2 shows the complete data model schema

as a graph. The diamond shapes represent the values

of fact types connected to only one object type.

We have populated the data model with a range of

sources. A list of openly available sources used so far

may be found in Table 1. The data model has been

developed and improved along with introduction of

new data.

In the following we explain the background and

reasoning for the choices we have made, and include

results from importing different data sources.

Modeling Cyber Threat Intelligence

275

Table 1: The sources inﬂuencing the data model.

Source Relevant object types

ATT&CK Tactics, Techniques, Tools, Threat Actor

VirusTotal IPv4, IPv6, FQDN, URI, Content, Hash,

Tool, ToolType, Query, Path, Scheme, Base-

name

Shadowserver ASN IPv4, IPv4Network, ASN

, Organization,

Country

Passive DNS IPv4, IPv6, FQDN

MISP Galaxies Tool, Threat Actor, Sector

STIX vocabularies Sector

Open Source Intelligence extracted with NLP All

Figure 2: The complete data model represented as a graph.

4.2.1 Consistent Data

There are restrictions on which fact types can be used

to link which object types as seen in Figure 2. These

restrictions enforce data consistency by preventing

different representations of the same data, which is

a known problem with current attempts to model

CTI. If we allow ﬂexibility in how different data can

be represented and introduce a range of users, then the

data quality in terms of format is quickly reduced.

The granularity of the data model is intended to

be aligned with pivot points normally used by ana-

lysts. This has been achieved by covering all sources

in the currently available models and sources of CTI,

described in the introduction of this section.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

276

We started with differentiation between malware,

tool and utility, all instances of software. However,

we saw that the deﬁnitions of the different groups var-

ied in different sources and became difﬁcult to main-

tain. This is consistent with the known problem of

classifying malware, and we do not attempt to solve

this in our data model. When the content of the CTI

was not consistent we found that there was no value

of using it at all. Therefore in our platform these con-

cepts were all rolled up into tool, with the possibility

of tagging them as malware or utility as appropriate.

4.2.2 Enrichment and Query/Analysis Across

Sources

One of our ﬁrst observations was that our graph ended

up being a series of subgraphs, and we wanted to be

able to connect them. The simple solution was en-

richment. As we added more enrichment sources,

the graph gradually became more and more intercon-

nected, and we could ﬁnd new connections between

clusters of information that were originally separate.

Pivoting on an object is useful, as it lets you ﬁnd

related information and give you a more comprehen-

sive context. One simple example is from DNS: start

with a domain name, ﬁnd all of the IP addresses that it

has resolved to, and then ﬁnd all other domain names

that have resolved to those IP addresses.

Passive DNS (pDNS) data is a historic record of

DNS lookup resolutions and is important for an inves-

tigation. From 2013 mnemonic has collected pDNS

data. By 2017, when we had the initial version of

the platform ready for data consumption, we had a

TLP:White data set of approximately 100 GB of data.

By analyzing super nodes in the data set, we have dis-

covered new and unknown sinkholes. We tag known

sinkholes with a fact connecting to the object in order

to ﬁlter them out when traversing the graph further.

A more advanced solution was to use classiﬁers

to bridge technical, tactical, operational and strate-

gic threat intelligence. An example of this is using

VirusTotal to bridge technical indicators to tactical

information in MITRE ATT&CK. We extracted the

malware family name from anti virus signatures and

normalized it. We then normalized the Software en-

tries from MITRE ATT&CK, e.g. “TrickBot” became

“trickbot”. Automated enrichment with VirusTotal

then connects ﬁle hashes and network infrastructure

to the “trickbot” object, which is again linked to the

tactical threat intelligence in ATT&CK.

We also observed that we could create uncommon

pivot points, and our URI object type is an example of

this. A URI object is just a UUID connecting different

components to each other for a complete URI. Fig-

ure 2 shows the facts connecting to a URI in red and

blue color. Given a URL, we split it into the host (do-

main/IP) part, the path and the query parameters. Piv-

oting on query parameters proved useful when track-

ing spam campaigns with speciﬁc phishing kits, as all

of the other pivot points changed for each spam run,

but the query parameter stayed the same.

4.2.3 Aliasing

Our data model allows for aliasing different names for

the same object.

Instead of giving a threat actor a primary name,

like in MISP Galaxy, we use alias as a fact type be-

tween threat actor names that are known or suggested

to be the same. This may also be seen in Figure 2 with

green color. Adding information on any threat actor’s

name is then done by linking to the name given at the

source. In this way, if an alias turns out to be wrong,

you only need to retract that one alias, and the rest of

your information is still correct.

The problem of different names for the same ob-

ject is a common situation in CTI. Often, we ﬁnd

different providers of CTI gives a primary name for

the object, and connect all information about this ob-

ject to that name. For instance, if selecting “APT28”

as the main name for a threat actor, and receive in-

formation about “Fancy Bear” (an alias for APT28),

then such a solution will connect the information to

“APT28”. This information can be wrong. If you at

some point in the future decide that “Fancy Bear” is

not an alias for “APT28”, then you would have a large

manual task in correcting your data.

The alias fact type is used between threat actors

and tools and might be applied to other object types

in the future.

4.2.4 What is Content?

The concept of content is an example of where we

need to be precise in order to enable automation. In

the context of CTI, we handle not just ﬁles, but also

stream segments, text strings and parts of content that

has been found in memory. This is all “content”, but

should not all be classiﬁed as ﬁles. Furthermore, even

in the case of a ﬁle, we ﬁnd that it is seen as unique

based on more than one property. We argue that the

ﬁle name, the actual content, and the location of the

content together is what we refer to when we describe

something as a unique ﬁle.

To illustrate the above we use the example of two

ﬁles with the ﬁle system path /etc/hosts on two dif-

ferent Linux machines. In a given situation, the name

and content may be the same, but they are still not

the same ﬁle due to the fact that they reside on dif-

ferent machines. In a different scenario you can ﬁnd

Modeling Cyber Threat Intelligence

277

two ﬁles with the same name on the same machine,

but with completely different content. In both cases,

everyone agrees on the ﬁles being different from each

other.

To be able to describe these things in a precise

manner, and to identify similarities and identical ob-

jects, we saw the need for splitting them. The result

was content linked to uri with the fact types as seen in

Figure 2 with blue color. Basename (which includes

the ﬁlename) is included within the URI.

The at fact found connecting a content object to

a uri object is in the meaning of seen at and down-

loaded from. The general at was selected so as to not

exclude any of the terms. The additional connectsTo

fact represents a content which has been seen con-

necting to a uri and show the two very different sce-

narios where there is a link between the two object

types. This is an example of the importance of se-

mantics when handling CTI.

4.3 Placeholders to Preserve

Information

In the ACT data model, you cannot link objects with-

out a deﬁned fact type between the object types. From

adding new sources in various structures and formats,

we found ourselves in need of adding more fact types

based solely upon the information we wanted to con-

sume. This resulted in a vast amount of fact types, and

no consistency in representation of information. This

is one of the most commonly mentioned weaknesses

of the structure given in STIX, where there are sev-

eral ways of representing the same CTI, resulting in

problems digesting all information, especially with-

out manual work and deduplication.

Looking for solutions we found the need for de-

scribing “things we know exist, but know little about”.

Blank nodes has been a solution for this problem in

the ﬁeld of ontologies (Hogan et al., 2014) and is

part of the standardized W3C RDF Semantics (W3C,

2014). We introduced the same thought in our data

model, by using what we called “placeholders”. The

idea is that the user may ﬁnd information about the

object in the future, and then replacing the place-

holder with an actual object through a new fact. In

this way, we were able to strictly deﬁne how the data

are truly connected to each other, without worrying

about having all data in a chain in order to consume

it.

As an example, Figure 3 - 5 explains a typical sce-

nario when working with CTI.

After implementing placeholders in our data

model and restricting the fact types’ possible connec-

tions, we found that adding and searching the data

threatActor

tool

uses

Figure 3: A typical piece of information received as CTI.

incident threatActor

event content

tool

attributedTo

observedIn

classiﬁedAs

Figure 4: The information needed to give the statement in

Figure 3.

incident threatActor

event content

tool

attributedTo

observedIn

classiﬁedAs

Figure 5: The need for placeholders: the information we

know exist in gray, but is often not available for sharing.

gave us an easy overview over what data is miss-

ing. This is a very interesting beneﬁt for security an-

alysts receiving or searching data on a relevant inci-

dent, both to know what data you do not have, but also

to know what data others will need to be in possession

of when sending you data. In evaluation of different

CTI sources, this is a relevant analysis to perform.

5 DISCUSSION

The data model that we propose is strict: it restricts

which relationships may be added to connect two ob-

jects, and it enforces that objects may not be added

directly but through facts. The main beneﬁt from this

is a consistent data set which enables automation and

improves data quality. It reduces the computational

load of graph queries. It also provides for easier graph

queries as there is no need to know the data you query

so long as the user understands the data model. As an

example there is a limited amount of traversals of the

graph between threat actor and technique. Knowing

this makes it trivial to ﬁnd all connections between

known threat actors and the techniques we know it

has used without missing any available data. With

this, we argue that building the data model has trans-

ferred some of the advanced knowledge from CTI

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

278

professionals into the model itself, which enables less

skilled professionals to analyze the same data with

consistent results.

In the course of developing this model we have

discussed various solutions, implemented them and

been surprised by some of the ﬁndings. The following

discourse will look into the most relevant insights.

5.1 Data Validation

Large data sets often include some data that does not

comply to the given speciﬁcation. Adding data to our

model, data outside speciﬁcations will be identiﬁed

fast as they will fail upon consumption.

Bad CTI may lead to bad results when analyz-

ing both as they may cause incorrect conclusions but

also because they may ruin some of the other data.

Most times errors exists due to mistakes entered at the

source, because of the complexity of the subject mat-

ter or because multiple authors use different methods

or terminologies.

We have found that the model allows for data

validation. As an example, when querying the data

from ATT&CK using our data model, we found that

there actually was one technique called Shared Web-

root without a link to any threat actors or any tools,

which in threat intelligence is an interesting observa-

tion. Knowing that ATT&CK only includes data they

have a reported observation of, means that this tech-

nique has been observed, but not described by openly

available sources. This was obvious when we applied

our model.

Adding MISP Galaxy for threat actors

where

there is a range of users adding data with limited re-

strictions on data inclusion, we found that all threat

actors were listed under a main name, with all infor-

mation about them linking to this name. There are

aliases listed underneath, but with no capability of

reasoning on these aliases, the result is that a large

portion of the threat actors actually are connected and

seen as one. This meant that the value of the infor-

mation was diluted as almost all information known

about one threat actor was also stated to be valid for

a large amount of other threat actors. This is an ex-

ample of validation that may be used for evaluation

of CTI sources, and it shows the importance of the

chosen solution of aliasing as chosen in our model.

5.2 Evaluation of CTI Sources

When evaluating different sources of CTI, it is use-

ful to evaluate the quality of the offered data. Our

https://github.com/MISP/misp-galaxy/blob/master/

clusters/threat-actor.json

data model may be used for this purpose. Firstly, by

adding context and knowledge to your data, which en-

ables you to interpret the data you receive. Extensive

aliasing, wrongful classiﬁcations or attributions may

be easily found through such evaluation. Secondly, it

helps ﬁnding data with errors, inconsistencies or bad

formatting. The strictness of the data model excludes

the possibility of importing data with errors, inconsis-

tencies or bad formatting. When working to include

new data sources these shortcomings will surface.

Thirdly, to check what data is missing. When utiliz-

ing the data model with a given data set, if there is

missing data it can be identiﬁed by identifying miss-

ing data in between data points. We can also ﬁnd what

object and fact types are used in that data to evaluate

the range of CTI provided from the source.

5.3 Agreeing on Terms and

Relationships

The terms and concepts within CTI are often referred

to with different understanding. An example of this is

campaign which often is used to describe standalone

incidents and relevant threat actors in addition to the

collection of incidents by the same threat actor tar-

geting a given sector or geographical location. When

connecting each concept to other concepts in a de-

ﬁned way, the data is given context, and with this ad-

ditional meaning to a user. In this way we argue that

ambiguity in terms and deﬁnitions will be reduced.

5.4 Differences in Object Types and

Fact Types

There is a difference between objects that may be ob-

served directly, and objects that are a result of human

decision or analysis. Example of these types are inci-

dent and tool (not content or hash). The relationships

going to and from these may also imply analysis, like

classiﬁedAs and attributedTo. These facts are not a di-

rectly observable link. The trust we have in the source

of these facts is thus more signiﬁcant.

The differences in meaning of the different fact

types shows the importance of semantics. There are

object types which have multiple possible fact types

connecting them, and where the semantics of the cho-

sen fact type signiﬁcantly differentiates.

An example of this is content

connectsTo

−−−−−−→ URI and

content

−→ URI as described in Section 4.2.4.

Modeling Cyber Threat Intelligence

279

5.5 Sharing CTI

Newer publications suggest that still about 78% of

shared CTI is unstructured (Sauerwein et al., 2019).

Without any structure, we can only automate shar-

ing of data as no relationships are present. With the

choice of only adding information as facts (relation-

ships) in ACT, we force all CTI to be stored with/as

relationships. With this baseline we can automate

sharing of triplets which is a signiﬁcant improvement

from sharing data and allows for sharing of graphs.

6 CONCLUSIONS AND FURTHER

STUDY

We have proposed a strict data model based on objects

and relationships, with the ability to represent avail-

able CTI. We have populated it with relevant data, and

have identiﬁed new information through analysis en-

abled by the data model. The most prominent results

from the data model is data validation, seamless en-

richment, excellent analysis capabilities and ﬂexibil-

ity of CTI ingest.

Future development of the data model will include

hierarchical object types and fact types (using rela-

tionships borrowed from ontologies such as subClas-

sOf and subPropertyOf ) which will enable inheri-

tance, more precision and reasoning.

In the implemention of our data model we allow

external workers to access the content and add new

facts. In this context we are exploring the use of an

OWL-implemented version of our data model to infer

new facts based on rule based reasoning using Seman-

tic Web Rule Language (SWRL) (W3C, 2004).

ACKNOWLEDGEMENTS

This work was supported by the Research Council of

Norway and mnemonic under the ACT and TOCSA

projects.

The authors would like to thank the anonymous

reviewers for valuable input that improved the paper.

REFERENCES

ANSSI, Luatix, and CERT-EU (2019). The OpenCTI Plat-

form.

Barnum, S. (2012). Standardizing Cyber Threat Intelli-

gence Information with the Structured Threat Infor-

mation eXpression (STIX

). MITRE Corporation,

11.

Caltagirone, S., Pendergast, A., and Betz, C. (2013). The di-

amond model of intrusion analysis. Technical report,

DTIC Document.

Hogan, A., Arenas, M., Mallea, A., and Polleres, A. (2014).

Everything you always wanted to know about blank

nodes. Journal of Web Semantics, 27:42–69.

Mavroeidis, V. and Bromander, S. (2017). Cyber threat in-

telligence model: an evaluation of taxonomies, shar-

ing standards, and ontologies within cyber threat intel-

ligence. In 2017 European Intelligence and Security

Informatics Conference (EISIC), pages 91–98. IEEE.

MISP (2019). The MISP platform.

MITRE (2019). Adversarial Tactics, Techniques and Com-

mon Knowledge (ATT&CK). https://attack.mitre.

org/.

OASIS CTI TC (2017). Structured threat information ex-

pression (STIX

) 2.0. https://oasis-open.github.io/

cti-documentation/.

Polzunov, S. and Abraham, J. (2019). EVALUATE OR DIE

TRYING - A Methodology for Qualitative Evaluation

of Cyber Threat Intelligence Feeds.

Sauerwein, C., Pekaric, I., Felderer, M., and Breu, R.

(2019). An analysis and classiﬁcation of public in-

formation security data sources used in research and

practice. Computers & Security, 82:140–155.

Sauerwein, C., Sillaber, C., Mussmann, A., and Breu, R.

(2017). Threat Intelligence Sharing Platforms: An

Exploratory Study of Software Vendors and Research

Perspectives.

Stillions, R. (2014). The DML Model.

http://ryanstillions.blogspot.com/2014/04/the-dml-

model

21.html.

W3C (2004). Semantic Web Rule Language.

W3C (2014). RDF 1.1 semantics.

Wagner, C., Dulaunoy, A., Wagener, G., and Iklody, A.

(2016). Misp: The design and implementation of a

collaborative threat intelligence sharing platform. In

Proceedings of the 2016 ACM on Workshop on Infor-

mation Sharing and Collaborative Security, pages 49–

56. ACM.

ICISSP 2020 - 6th International Conference on Information Systems Security and Privacy

280
