Evaluating the Accessibility of Digital Audio Workstations for Blind or

Visually Impaired People

Gemma Pedrini, Luca Andrea Ludovico

and Giorgio Presti

Laboratorio di Informatica Musicale, Dipartimento di Informatica “Giovanni Degli Antoni”,

Universit

a degli Studi di Milano, Via G. Celoria 18, Milano, Italy

Keywords:

Accessibility, Blind or Visually Impaired (BVI), Digital Audio Workstations.

Abstract:

This paper proposes a methodology to assess the accessibility for blind or visually impaired people of mu-

sic production software known as Digital Audio Workstations. The products chosen for the tests are Cockos

REAPER, Avid Pro Tools, and Steinberg Cubase, three of the most popular solutions falling in this cate-

gory. Both Microsoft Windows and macOS versions were tested, since these two operating systems natively

integrate assistive technologies which provide a further layer to be considered. The degree of accessibility

was evaluated in relation to the possibility for blind or visually impaired people to invoke key functions and

perform basic operations. Finally, a focus group with visually impaired professional music producers was

organized in order to assess the proposed evaluation methodology.

1 INTRODUCTION

Accessibility means enabling as many people as pos-

sible to use a resource, even when those people’s abil-

ities are limited in some way. The International Clas-

siﬁcation of Functioning, Disability and Health (ICF)

denotes with the term disability the negative aspects

of the interaction between an individual and that indi-

vidual’s contextual factors. A ﬁrst assumption is that

an environment can be deﬁned as accessible when an

individual with any impairment can “function inde-

pendently”. Another assumption is that there is some

level of function that can be called minimally accept-

able (Steinfeld et al., 1999).

The UN Convention on the Rights of Persons with

Disabilities (CRPD) (United Nations, 2006) at Arti-

cle 9 – “Accessibility” encourages appropriate forms

of assistance and support to persons with disabili-

ties so as to ensure their access to information, pro-

motes their access to new information and communi-

cations technologies and systems, and fosters the de-

sign, development, production and distribution of ac-

cessible information and communications technolo-

gies and systems at an early stage, so that these tech-

nologies and systems become accessible at minimum

cost.

https://orcid.org/0000-0002-8251-2231

https://orcid.org/0000-0001-7643-9915

The theme of accessibility in the context of

Information Society, also known as e-accessibility

(Klironomos et al., 2006), concerns the integration of

all users into the Information Society, including peo-

ple with disabilities. Such a subject is tightly con-

nected to e-inclusion, which aims to prevent the risk

that people with lack of digital literacy, poor access

to technology and some form of impairment are left

behind, thus experiencing digital exclusion.

Another term often used in parallel with accessi-

bility is usability, an adjective synonymous with ﬁt to

use, functioning, operational, serviceable, valid, and

working. Usability concerns the fulﬁllment of func-

tional requirements, which makes it different from

accessibility. Nevertheless, some scholars use the

two expressions in parallel, stating that they both

are usually deﬁned in terms of observed task perfor-

mance, and together represent the concept of person-

environment ﬁt (Steinfeld and Danford, 1999). A

comprehensive review about accessibility, usability

and universal design can be found in (Iwarsson and

ahl, 2003).

In the wide context of accessibility, computer ap-

plications presents very speciﬁc requirements (Kav-

cic, 2005). As stated in (Mozilla, 2019), most soft-

ware tools assume that users can easily perform all of

the following tasks: read and react to text and images

displayed on the screen, type on a standard keyboard,

select text, pictures, and other information using a

Pedrini, G., Ludovico, L. and Presti, G.

Evaluating the Accessibility of Digital Audio Workstations for Blind or Visually Impaired People.

DOI: 10.5220/0010167002250232

In Proceedings of the 4th International Conference on Computer-Human Interaction Research and Applications (CHIRA 2020), pages 225-232

ISBN: 978-989-758-480-0

225

mouse, react to sounds being played. Conversely,

people with special needs can experience problems

in performing one or more actions, which prevents

them from using, partially or completely, even pop-

ular computer applications.

Focusing on visual impairments, this category in-

cludes the range from low vision (low-grade difﬁculty

in the use of a visual display) to full blindness (no pos-

sibility to enjoy graphical content). Please note that,

even if the hardest tasks for blind or visually impaired

(BVI) people concern the information displayed on

the screen, especially graphics and pictorial content,

also the use of a pointing device, requiring eye-hand

coordination, can pose a problem.

This work focuses on accessibility issues of Dig-

ital Audio Workstations (DAWs) for BVI users. In

origin, a DAW was a computer equipped with a

sound card and ad-hoc software for creating, editing

and processing recording-studio quality digital sound

(Leider, 2004). A computer-based DAW presents four

basic components: a computer, either a sound card

or an audio interface, digital audio editor software,

and at least one input device for adding or modifying

data. Nowadays, DAW is a common deﬁnition for a

software system that provides the interface and func-

tionality for audio editing and uses a PC as a host for

sound generation.

There is also a business interest towards music

software accessibility. As stated in (W3C Web Ac-

cessibility Initiative (WAI), 2019), accessible design

improves overall user experience and satisfaction, es-

pecially in a variety of situations, across different de-

vices, and for impaired as well as older users. Sup-

porting accessibility can enhance a brand, drive inno-

vation, and extend the market. Among BVI people,

there are users interested in music generation, editing

and production, and they often rely on hardware aid

devices due to the poor support offered by software

tools.

This work aims to shed light on the problem of

DAWs accessibility for BVI people, focusing on pure

software aspects and leaving out proprietary or MIDI

controllers that could help solving the problem. Any-

way, the ﬁnal goal is not to provide an evaluation of

accessibility for software DAWs currently available

on the marketplace, since new versions of the ap-

plications and the operating systems are expected to

introduce novel functionalities to support visual im-

pairments; in this sense, the results of our research

would soon become obsolete. Rather, we will start

from the evaluation of existing software tools in order

to propose an objective methodology to rate the ac-

cessibility of past, current and future DAW releases.

Our proposal has been submitted to visually impaired

professional music producers for appraisal, and their

remarks will be reported and discussed.

The rest of the paper is organized as follows: Sec-

tion 2 will describe the main assistive technologies

that help BVI people in using computer devices, Sec-

tion 3 will focus on the accessibility of DAWs, de-

scribing the test protocol and showing the scores ob-

tained, Section 4 will discuss the comments made

by experts to the proposed methodology, and, ﬁnally,

Section 5 will draw conclusions.

2 ASSISTIVE TECHNOLOGIES

FOR BVI PEOPLE

According to (U.S. Government, 1998), the adjective

assistive is assigned to technology designed to be uti-

lized in an assistive-technology device or an assistive-

technology service. Concerning the former aspect,

the expression assistive-technology device identiﬁes

any item, piece of equipment, or product system,

whether acquired commercially, modiﬁed, or cus-

tomized, that is used to increase, maintain, or improve

functional capabilities of individuals with disabilities.

Regarding the latter aspect, the expression assistive-

technology service means any service that directly as-

sists an individual with a disability in the selection,

acquisition, or use of an assistive-technology device.

Assistive technologies for BVI people have been

widely discussed in literature, e.g. in (Hersh and John-

son, 2010), (Pawluk et al., 2015) and (Shinohara,

2006), to cite but a few. Alternatives to the use of

sight in computer interaction typically involve the use

of other sensory canals, mainly hearing and touch. To

this end, a number of computer-based approaches and

aiding tools have been designed and developed.

Screen readers are a category of software aid tools

for people who do not have useful vision to read text

on the screen. They can analyze, ﬁlter, and interpret

the content of a computer display and reproduce it

as audio output through text-to-speech synthesis (see

Figure 1) or pilot a refreshable Braille display (see

Figure 2). Since the beginning of the ’90s, the in-

terface of most operating systems has been no longer

exclusively textual, but it has adopted graphical com-

ponents and pictograms to convey information, thus

becoming a so-called graphical user interface (GUI).

The software running under graphical operating sys-

tems typically presents the same characteristics, sup-

porting non-textual information and relying on a num-

ber of graphical controls. For this reason, recent

screen readers must be able to convert into an alter-

native representation not only text, but also graphi-

cal elements; in this sense, associated metadata, tags,

CHIRA 2020 - 4th International Conference on Computer-Human Interaction Research and Applications

226

Duration

Linguistic

Analysis

Wave Form

Generation

Text

Analysis

Utterance

Composed

of Words

Utterance

Composed

of Phonemes

Intonation

Phasing

Text Speech

Figure 1: Block diagram of a typical text-to-speech system.

Figure 2: A 40-cells refreshable Braille display. Image by

Sebastien.delorme, CC BY-SA 3.0.

and automatic recognition algorithms can help. Many

operating systems integrate their own screen readers

and speech synthesizers: e.g., Orca for Linux, Narra-

tor for Microsoft Windows family, and VoiceOver for

Apple macOS.

It is worth mentioning another category of aid

tools speciﬁcally addressing visually impaired users:

screen magniﬁers, which are capable of presenting the

output on a larger scale. The enlarged portion of the

screen, called the focus, includes the content of in-

terest and an improved representation of the pointer

or cursor. The focus follows pointer movements, and

usually it can be invoked through a shortcut and ad-

justed in size depending on the user’s needs. Modern

operating systems integrate screen magniﬁers as well.

Even if designed for different purposes, assis-

tive technologies of interest in this context can also

include speciﬁc hardware controllers, provided that

they support bi-directional communication from/to

the DAW. Examples include motorized faders and

knobs. Anyway, in the analysis of DAWs accessibil-

ity presented in Section 3 we will deliberately ignore

the role played by additional hardware components,

due to their high number and variety, and, above all,

to their extraneity in relation to the original software

tools.

When designing software interfaces, developers

should take into consideration the compatibility of

their products with assistive technologies (Edyburn,

2004). Common problems of accessibility in software

include: controls identiﬁed only by images, with-

out textual tags; absence of explanatory alternative

texts; wrong tag-reading priority, with descriptors not

following a logical/functional order; the need to use

the mouse to reach controls that cannot be selected

through speech-synthesis focus; display-related infor-

mation not easily reachable or completely unreach-

able by keyboard navigation.

There is a number of good practices that can be

followed to improve software usability for BVI peo-

ple. A fundamental rule is to provide titles and la-

bels for each element of the interface. The mean-

ing of icons and other pictorial indications should

be conveyed by alternative text, too. The activa-

tion/deactivation of controls like buttons should not

be rendered only visually, but also by providing audi-

tory feedback to users of assistive technologies. Over-

lay notiﬁcations like tooltips should persist for a time

sufﬁcient to be read through the screen reader, or their

timing should be adjustable. In general, too com-

plex graphical layouts should be avoided, since they

pose serious problems of accessibility and often re-

quire mouse interaction. Even if the default layout

has not been designed for BVI people, a clear, in-

tuitive and highly-customizable interface, accompa-

nied by accessible documentation, could help. For

example, the support of high contrast color combi-

nations and the possibility of switching foreground

and background colors are useful features for BVI

users. All interface elements should be reachable

through speech-synthesis focus by using appropriate

labels. Moreover, programmers should rely on the

APIs provided by operating systems for standard con-

trols and follow the guidelines for accessibility in the

design of customized ones. Finally, software should

be tested through ad-hoc tools to ensure the accessi-

bility via keyboard or mouse of interface components

such as modules, menus, selection curtains, combo

boxes, check boxes, etc.

In conclusion, assistive technologies can be em-

ployed to provide context information, command de-

scriptions and feedback. Unfortunately, in sound-

oriented software these purposes can pose some prob-

lems: on one side, an excessive stimulation of hear-

ing can cause cognitive overload in BVI users; on the

other side, it is hard to convey some types of infor-

mation (e.g., waveforms or automation patterns) via a

Braille display.

3 ACCESSIBILITY OF DAWs

In order to evaluate the accessibility of DAWs, we

analyzed the reachability for a BVI user of a set of

common functions and operarations. To this end, we

selected and tested three very popular software solu-

tions:

Evaluating the Accessibility of Digital Audio Workstations for Blind or Visually Impaired People

227

1. Cockos REAPER,

version 5.95 for Windows and

version 5.921 for macOS;

2. Avid Pro Tools,

version 2018 7.0 for Windows

and 2018.10 for macOS;

3. Steinberg Cubase Pro,

version 9.5 for Windows

and macOS.

Tests were performed under Windows 10

version 1803 (build SO 17134.472) and

macOS Mojave 10.14.

It is worth underlining that, at the moment of ﬁ-

nalizing this paper (July 2020), such versions have

been already surpassed by more recent releases, in-

troducing new features in the graphical interface and,

more in general, presenting some differences con-

cerning accessibility. Anyway, we recall that the re-

search question we want to address in this paper is

not to determine which DAW is currently the most

accessible one for BVI people, but rather to highlight

which aspects programmers should take into account

when designing a DAW, and ultimately to propose a

general methodology for an objective evaluation of

DAWs’ accessibility. From this perspective, the re-

sults achieved by speciﬁc software versions are not

relevant.

3.1 Assessment Metrics

The metrics we propose takes into account both the

usability and the access speed for the analyzed func-

tions. To this end, we deﬁne an ad-hoc scale with

values ranging from 0 (minimum) to 4 (maximum).

These values correspond to the following accessibil-

ity levels:

• Level 0. The command under exam cannot be in-

voked via keyboard, and the vocal synthesis does

not recognize the presence of the control in case

of interaction through the mouse;

• Level 1. The command can be reached from the

keyboard using the cursor or via a shortcut only in

a speciﬁc context, but context information is not

clearly communicated to the user, e.g. via speech

synthesis. Moreover, there is no feedback about

the success or failure of the invoked operation,

concerning both the activation of the command

and its effects;

• Level 2. The command can be invoked through

the keyboard, using the cursor or via a shortcut.

Speech synthesis does not provide a feedback, but

https://www.reaper.fm/

https://www.avid.com/pro-tools

https://new.steinberg.net/cubase/

it is possible to check the effectiveness of the com-

mand;

• Level 3. The command can be reached from the

keyboard using the cursor or via a shortcut, and

voice synthesis produces a feedback, which lets

the user check the effectiveness of the command;

• Level 4. The command is fully accessible from

the keyboard and perfectly integrated within the

graphic environment.

3.2 Choosing the Screen Reader

The choice of the screen reader is critical for the suc-

cess or failure of many operations. For both the op-

erating systems under exam we referred to the guide-

lines suggested by the American Foundation for the

Blind.

In order to select the most suitable speech

system, this institution poses a number of questions:

What version of the operating system will be used?

Is the screen reader compatible with such a version?

Are there known system conﬁgurations with which

the screen reader does not work (color schemes, com-

mon video cards, etc.)? What synthesizers are, or are

not, supported? Considering the most common appli-

cations, are there known limits with the screen reader?

How much speech does the screen reader automati-

cally add during standard functions, such as selecting

or scrolling items? Can the amount of speech be ad-

justed to suit the user’s skill level and preferences?

How difﬁcult is to change simple standard features

(e.g., the voice rate)? Is the manual accessible and

accurate? Is there a tutorial in a usable format?

After carefully evaluating the mentioned ques-

tions, we selected NVDA as the screen reader to be

used under Windows. NVDA, standing for NonVi-

sual Desktop Access, is an open-source screen reader

that uses the eSpeak speech synthesizer and SAPI 4

and SAPI 5 synthesizers.

It is free and updated

frequently, about every 3 months, thus keeping the

pace with technological innovations. This choice has

proved to be effective especially in the program test-

ing phase, allowing an easy investigation of the screen

through the mouse. NVDA is able to read the ele-

ments currently positioned under the pointer. Speech

synthesis does not interfere with common mouse op-

erations, such as button clicking or wheel scrolling.

During our tests, we have experienced only two prob-

lems: sudden and apparently unmotivated slowdowns

in the reactivity of invoked operations and unexpected

restarts. In the latter case, speech synthesis stopped

https://www.afb.org/

https://github.com/nvaccess/nvda

CHIRA 2020 - 4th International Conference on Computer-Human Interaction Research and Applications

228

working, and the proper behavior could be resumed

only by restarting the program in use.

Concerning macOS, Apple devices em-

bed a proprietary voice synthesis called

VoiceOver. Installed by default, perfectly inte-

grated in the operating system, constantly updated

and guaranteed to be compatible with all applications,

this solution provides excellent performances with all

Apple devices.

3.3 Test Protocol

The analysis consisted in a test conducted by a visu-

ally impaired user, expert in the ﬁeld, on a signiﬁcant

set of DAW commands. The tester invoked the most

common operations of a recording studio, that can be

gouped into the following categories:

• Transport. Basic and advanced playback controls;

• Track. Operations on sequencer tracks concerning

navigation, management and controls;

• Editing. Commands to cut, copy, paste or du-

plicate events, time representations of events and

commands to change the content of each track;

• Mix. Audio stream production and post-

production processing;

• Project. File and conﬁguration management.

Each command was tested on any version of the

DAWs under exam, and an accessibility level was

assigned according to the scale described in Section

3.1. All combinations to achieve the same result were

tested (menu, keyboard, and mouse commands), and

scores reﬂected the best option, namely the most ac-

cessible method. Final results are shown in Table 1,

which provides a detailed comparison between the 3

products in their Windows and macOS versions.

Let us brieﬂy discuss the outcome of our analy-

sis. REAPER emerges as the most accessible DAW,

scoring very well under both macOS and Windows.

Only a few operations among the commands under

exam received a low grade. In order to understand

such an impressive result, we have to mention that

Cockos REAPER 5.9 has already been analyzed and

adapted by a community of BVI people, a working

group known as Reaper Accessibility. Their activities

resulted in the design and implementation of a dedi-

cated plugin called OSARA (Open Source Accessibil-

ity for the REAPER Application),

an extension that

makes the DAW accessible to screen-reader users by

interfacing directly with the speech synthesizer. Even

if OSARA is the result of an independent community

https://osara.reaperaccessibility.com/

of users, it is worth remarking the involvement of the

BVI community in the product design.

Conversely, Cubase 9.5 received a poor score,

showing very little attention towards accessibility is-

sues for BVI people. Nevertheless, Cubase Pro 10.5

(the most recent version available on the marketplace

at the moment of writing) has substantially solved the

problems that affected the previous release.

The test phase, conducted by a low-vision user,

made some issues typically unknown to standard

users emerge. First, many operations present different

effects depending on the context in which they were

performed (e.g., editing commands), hence the impor-

tance to clearly identify the position of the focus. This

aspect can be fundamental in the evaluation of acces-

sibility, above all when the user has no residual sight.

Another problem concerns the possibility for BVI

people, like our test user, to access documentation.

Even if all the DAWs under exam have a complete

user’s guide, sometimes accessing it through assistive

technologies was a hard task. Therefore, it was essen-

tial to retrieve supplementary material, provided by

developer communities such as Github.com or shared

on platforms such as Youtube.com. Focusing on the

latter approach, video tutorials often use the voice

to explain instructions shown via desktop recording,

therefore BVI users cannot understand the context.

Furthermore, instructions are invoked via both key-

board and mouse inputs, and the sequence is not eas-

ily repeatable through assistive technologies.

Con-

cerning audiovisual material made accessible to the

blind, it is worth mentioning the Access Music Tech

channel,

a community-driven virtual place dealing

with assistive music technologies. The contents of

this channel have been fundamental in ﬁnding DAW

instructions for macOS software, while the corre-

sponding instructions under Windows were inferred

by attempts, also considering the mapping of key-

board commands under the two operating systems.

4 ASSESSING THE PROTOCOL

In order to check the validity and signiﬁcance of the

data gathered by our protocol when applied to the

mentioned DAWs, we organized a focus group involv-

ing BVI experts in the ﬁeld of music production and

asked them to provide observations and remarks about

the scores obtained by the test.

Anyway, desktop recording can help visually impaired

people with residual sight.

https://www.youtube.com/channel/UC-rL46RtrPdb

I3awd9eJow

Evaluating the Accessibility of Digital Audio Workstations for Blind or Visually Impaired People

229

Table 1: Scores in the range 0 (minimum) to 4 (maximum) obtained by the DAWs under exam for each tested task.

REAPER Pro Tools Cubase

Task Feature OSX Win OSX Win OSX Win

Transport

Start 4 2 4 2 0 0

Stop 4 2 4 2 0 0

Pause 4 2 4 0 0 0

Record 4 3 4 2 0 0

FFW/RW 4 1 4 2 0 0

Home/End 4 4 3 2 0 0

Loop on/off 4 4 4 3 0 0

Cursor snap/scrub 4 4 0 0 0 0

Cursor ﬁne locating 0 4 0 0 0 0

Create marker 4 3 4 3 0 0

Marker window 3 3 0 0 0 0

Move to marker 4 3 0 0 0 0

Delete marker 3 4 2 2 0 0

Grid settings 4 2 0 0 0 0

BPM 4 4 2 4 0 0

Signature 4 4 2 2 0 0

Tempo track 0 0 0 0 0 0

Metronome on/off 4 4 3 4 0 0

Metronome setup 3 4 4 0 0 0

Track

Create track 4 4 4 4 0 0

Rename track 4 4 3 4 0 0

Delete track 4 4 4 4 0 0

Track focus 4 3 3 1 0 0

Track selection 4 4 4 1 0 0

Track type 0 0 4 3 0 0

I/O Mapping 0 0 4 2 0 0

Arming track 4 3 4 4 0 0

Record mode 4 4 2 3 0 0

Editing

Import audio 3 4 4 4 0 0

Sample selection 4 4 0 0 0 0

Select all 2 4 4 4 0 0

Ripple Edit 4 4 0 0 0 0

Cut 4 4 4 1 0 0

Copy 4 4 4 1 0 0

Paste 4 4 4 1 0 0

Duplicate 4 4 4 1 0 0

Split 0 4 0 0 0 0

Undo/Redo 4 3 4 4 0 0

Mix

Show mixer 3 0 4 0 0 0

Show master track 4 4 4 3 0 0

Track fader 4 0 4 0 0 0

Master fader 3 3 4 3 0 0

Track pan 3 2 4 3 0 0

Mute/Solo 4 3 4 4 0 0

Insert FX 4 3 2 0 0 0

Project

Open project 4 4 4 2 1 1

New project 4 4 4 4 1 1

Save project 4 4 4 4 1 1

Save project as 4 4 4 4 4 4

Close project 4 4 4 4 1 1

Close all 4 4 4 4 1 1

Mixdown 4 4 3 4 0 0

We received answers from two experts who have

been working for years with DAWs at a professional

level.

A ﬁrst aspect we asked to validate was the set of

commands chosen for our tests. In order to be present

in all the tested DAWs, we limited it to the basic op-

erations typical of a recording studio, not taking into

account articulated sequences of commands, complex

sound-processing operations, nor third-party plugins

usage. From this point of view, both experts consid-

CHIRA 2020 - 4th International Conference on Computer-Human Interaction Research and Applications

230

Table 2: Comparative analysis of the three DAWs under exam.

REAPER Pro Tools Cubase

macOS Windows 10 macOS Windows 10 macOS Windows 10

Transport 4 3 3 2 0 0

Track 4 4 4 3 0 0

Editing 4 4 4 1 0 0

Mix 4 3 4 3 0 0

Project 4 4 4 4 1 1

ered the list of commands in Table 1 as exhaustive and

signiﬁcant to test software accessibility.

Moreover, they both agreed on the general out-

comes of our investigation, conﬁrming that Cockos

REAPER is more user-friendly for a BVI user than

other software tools.

As we might expect, they also gave us useful sug-

gestions to reﬁne the test protocol. First, they under-

lined how the choice of the screen reader may alter

results signiﬁcantly. For instance, one of them sug-

gested a commercial software solution that, in his/her

opinion, was essential to cope with REAPER 3

party

plugins under macOS. Consequently, it is important

to periodically evaluate the advancements in screen

readers and to choose the most suitable one, as dis-

cussed in Section 3.2.

Another aspect to consider is the inverse correla-

tion between the richness in the graphical interface

and the usability of software by BVI people. In fact,

not only ancillary pictorial content is partially or com-

pletely useless for this category of users, but it is hard

to be rendered through a different sensory canal and

can be even misleading with respect to fundamen-

tal audio-related information. Consequently, one of

the experts suggested to take into account the graphi-

cal complexity of the interface and the customization

possibilities offered by the DAWs, in order to help

some screen readers.

As a ﬁnal remark, it is worth underlining that pro-

fessional users often adopt only one operating system

and become skilled with a speciﬁc product. Thus,

their opinions can be relevant when comparing the

updates of the same DAW across major or minor re-

visions, or at least when cross-checking the function-

alities of different DAWs under the same operating

system, but they rarely have a synoptic view like the

one we provided in our analysis, involving many soft-

ware tools and their variants under different operating

systems.

5 CONCLUSIONS

The experience conducted with three popular soft-

ware DAWs underlined that accessibility for BVI peo-

ple is an aspect sometimes overlooked by designers

and developers.

For the sake of clarity, we have summarized the

results obtained by applying our protocol in Table 2,

where we have reported the median score of each

command category for each software. The table

shows that Cubase is inaccessible in almost all its

functions, probably due to the use of a proprietary

GUI environment instead of the one provided by the

operating system’s APIs; moreover, the focus of com-

mands is not clear. REAPER 5.95 and Pro Tools 2018

perform better, but the operating system in use deeply

inﬂuence the results. In particular, macOS provides a

higher level of accessibility. During our tests, Win-

dows caused also a number of system crashes un-

til the RAM of the PC was upgraded from 8 to 16

GB, as the simultaneous use of speech synthesis and

a DAW takes many resources. In general, we no-

ticed several compatibility issues between such soft-

ware tools and voice synthesis, which required set-

tings update, additional external devices (that some-

times turned to be incompatible with the software),

and program restarts. It will be interesting to apply

our protocol to more recent DAW releases, under new

versions of the operating systems and with more pow-

erful hardware conﬁgurations.

In order to overcome usability issues, a user with

special needs has to choose the right combination of

products (operating system and DAW), master their

settings, run the DAW and speech synthesis on a high-

performance computer, and sometimes rely on addi-

tional technologies to gain access even to basic func-

tions. Our hope is that impaired users’ needs will be

given more attention in future software releases.

Concerning future work on the proposed evalua-

tion protocol, the ﬁrst step is to repeat the analysis

with more testers, in order to improve the validation

by assessing the statistical validity of the proposed

methodology. Then, the obtained results will be the

Evaluating the Accessibility of Digital Audio Workstations for Blind or Visually Impaired People

231

basis to provide design guidelines for developers.

We also plan to extend tested functionalities to

common combinations of operations, such as com-

plete editing tasks on waveforms (e.g., complex edit-

ing for tempo correction) or the application of stan-

dard behaviors (e.g., select and fade out multiple au-

dio events). Moreover, we need to better clarify the

goal, choosing between the evaluation of the acces-

sibility characteristics of a software per se, or its us-

ability when beneﬁting from “external” support tech-

nologies, such as suitable extensions, screen readers,

operating-system aids, etc. Another aspect to con-

sider in the overall evaluation will be the inﬂuence

of assistive technologies on the performances of the

DAW.

REFERENCES

Edyburn, D. L. (2004). Rethinking assistive technology.

Special Education Technology Practice, 5(4):16–23.

Hersh, M. and Johnson, M. A. (2010). Assistive technol-

ogy for visually impaired and blind people. Springer

Science & Business Media.

Iwarsson, S. and St

ahl, A. (2003). Accessibility, usabil-

ity and universal design—positioning and deﬁnition

of concepts describing person-environment relation-

ships. Disability and rehabilitation, 25(2):57–66.

Kavcic, A. (2005). Software accessibility: Recommenda-

tions and guidelines. In EUROCON 2005-The Inter-

national Conference on” Computer as a Tool”, vol-

ume 2, pages 1024–1027. IEEE.

Klironomos, I., Antona, M., Basdekis, I., Stephanidis, C.,

et al. (2006). White paper: promoting design for all

and e-accessibility in europe. Universal Access in the

Information Society, 5(1):105–119.

Leider, C. N. (2004). Digital audio workstation. McGraw-

Hill, Inc.

Mozilla (2019). Software accessibility: Where are we to-

day? https://developer.mozilla.org/en-US/docs/Web/

Accessibility. Accessed: 2020-01-05.

Pawluk, D. T., Adams, R. J., and Kitada, R. (2015). Design-

ing haptic assistive technology for individuals who are

blind or visually impaired. IEEE transactions on hap-

tics, 8(3):258–278.

Shinohara, K. (2006). Designing assistive technology for

blind users. In Proceedings of the 8th International

ACM SIGACCESS Conference on Computers and Ac-

cessibility, pages 293–294. ACM.

Steinfeld, E. and Danford, G. S. (1999). Theory as a basis

for research on enabling environments. In Enabling

Environments, pages 11–33. Springer.

Steinfeld, E., Danford, G. S., and Danford, G. (1999). En-

abling environments: Measuring the impact of envi-

ronment on disability and rehabilitation. Springer Sci-

ence & Business Media.

United Nations (2006). Convention on the

rights of persons with disabilities (CRPD).

https://www.un.org/development/desa/disabilities/

convention-on-the-rights-of-persons-with-disabilities.

html. Accessed: 2020-01-05.

U.S. Government (1998). S.2432 - Assistive Technology Act

of 1998, 105th Congress Public Law 394. U.S. Gov-

ernment Printing Ofﬁce.

W3C Web Accessibility Initiative (WAI) (2019). Introduc-

tion to web accessibility. https://www.w3.org/WAI/

fundamentals/accessibility-intro/. Accessed: 2020-

01-14.

CHIRA 2020 - 4th International Conference on Computer-Human Interaction Research and Applications

232
