Method of Semantic Refinement for Enterprise Search
Alexey Pismak
a
, Serge Klimenkov
b
, Eugeny Tsopa
c
, Alexandr Yarkeev
d
,
Vladimir Nikolaev
e
and Anton Gavrilov
f
ITMO University, Kronverksky pr 49, Saint-Petersburg, Russia
Keywords: Semantic Networks, Translingual Data, Apache Lucene, Semantic Queries, Semantic Search, Pertinence of
Search Results, Ontologies.
Abstract: In this paper, we propose an approach of using the semantic refinement of the input search query for the
enterprise search systems. The problem of enterprise search is actual because of the amount of processed data.
Even with a good organization of documents, the process of searching for specific documents or specific data
in these documents is very laborious. But even more significant problem is that the required content may have
the matching meaning, but expressed with different words in the different languages, which prevents it from
appearing in the search result. The proposed approach uses semantic refinement of the search query. First,
the concepts are extracted from the semantic network based on translingual lexemes of the user query string,
allowing to perform the search based on the senses rather than word forms. In addition, several rules are
applied to the query in order to include or exclude senses which can affect the relevance and the pertinence
of the search result.
1 INTRODUCTION
Search systems are the mandatory component of any
digital environment of a modern enterprise.
Generally, the search in document databases is
carried out by methods of grammatical full-text
search. This variant of work with the database of
documents has high relevance of the search results,
but at the same time, the value of the pertinence is still
quite low. In order to increase relevance, some
authors propose full-stack linguistic analysis based on
production rules (Ogarok, 2020). This approach
shows positive results in a question-based search
system, but it mainly uses the prepared subset of
search queries.
This problem is important because of the amount
of information required to be processed. It is
especially actual in enterprise search tasks which can
be characterized by the following set of features:
1. Domain homogeneity. In the most cases the
individual data elements in the enterprise system data
a
https://orcid.org/0000-0001-7459-1622
b
https://orcid.org/0000-0001-5496-6765
c
https://orcid.org/0000-0002-7473-3368
d
https://orcid.org/0000-0001-9682-7253
e
https://orcid.org/0000-0003-1889-3137
f
https://orcid.org/0000-0002-9917-6609
set are closely related to each other and they usually
belong to a common domain.
2. Large number of documents. Typical
enterprise system stores a large set (from thousands
to millions) of different documents in various
formats.
Even a relatively small enterprise has a set of
accounts, various acts, price lists, tax documents,
employee documents, and internal documentation of
the company. Even with a good organization of all
documents, the process of search of specific data in
these documents is very resource consuming.
However, the domain-specific search systems show
their effectiveness, especially when the specific
ontology is used (Formica et al., 2020).
The usage of semantic tags to guide the navigation
during the search was proposed (Solskinnsbakk and
Gulla, 2011), however, this method doesn’t solve the
problem of sense disambiguation. The problem is that
the required content may have similar meanings, but
at the same time may have different representations
(expressed in other words or in another language). All
Pismak, A., Klimenkov, S., Tsopa, E., Yarkeev, A., Nikolaev, V. and Gavrilov, A.
Method of Semantic Refinement for Enterprise Search.
DOI: 10.5220/0010159703070312
In Proceedings of the 12th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2020) - Volume 2: KEOD, pages 307-312
ISBN: 978-989-758-474-9
Copyright
c
2020 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved
307
questions concerning the semantic processing of texts
in the natural language require the formulation of a
narrow range of problems to be solved and further
research on the possibility of their resolution. An
example of such a range of problems is the semantic
search (Rashid and Nisar, 2016).
Theoretically, the semantic approach to text
processing is designed to solve the main problem of
lexical search that is huge number of errors during the
incorrect resolution of the polysemy of search query
lexemes.
The possible way of eliminating such errors is the
usage of the ontology-based semantic graph to keep
the knowledge needed to improve the search quality
(Modoni et al. 2014). In their article, the authors offer
the general architecture that has several advantages
regarding the quality of results and the usability to
formulate the queries, but their main focus is on the
data mining needed to collect and fill the knowledge
base. Another way of resolving word-sense
disambiguation is based on the usage of entity linking
in queries following by choice between supervised
and unsupervised alternatives (Hasibi et al, 2016).
As a part of this work, we propose a method for
implementing enterprise search based on the semantic
data retrieved from the ontological network. Using
the semantics of the search query we can significantly
increase the pertinence of the response, and therefore
the proposed method is based on using the semantic
relations of the ontological network, the lexical
information of semantic values and the translingual
data.
2 SEMANTIC NETWORKS AND
LEXICAL INFORMATION
Semantic networks are graph structures with nodes
that store semantic values (senses that represent
concepts), and the edges between nodes indicate the
relative semantic affiliation of one concept with
respect to another. Examples of such relations can be
synonymy, hyponymy, meronymy, and their reverse
relations: antonymy, hypernymy, and holonymy
(Stern D., 2015). These elementary semantic relations
between senses can be used to construct more
complex relations, such as cohyponyms, converses,
and others.
It is important to note that the semantic network
described in this paper doesn’t conform to the LMF
(Lexical Markup Framework) (Francopoulo G.,
2013) or UBY-LMF (Eckle-Kohler J. et al, 2015)
standards, because of some limitations imposed by
the object-oriented model. Instead, we used the
semantic representation based on a labeled oriented
graph structure, where nodes correspond to senses of
several types, and edges provide links between nodes
(Klimenkov et al, 2020). In addition, each node
corresponding to a sense is connected to all possible
lexemes used to represent the sense in different
languages. The ontology is formed from several semi-
structural sources (Pismak et al, 2019) and the
translingual lexemes are collected during the process
of sense-to-sense relation reconstruction (Osika et al,
2017). Such a graph structure allows us to eliminate
the needs for word-sense disambiguation due to usage
of reverse sense-to-lexeme relations while providing
the possibility for a quick search of sense nodes by
lexemes (Pokid et al, 2017). This lexico-semantic
structure contains the following types of nodes:
A semantic node is the type of node for storing
data about semantic values. In its general form it is an
abstract node that does not store specific information
about the meaning of the sense, but only positions it
with respect to other concepts in the semantic
network;
A lexical node is the type of node for storing a
certain lexeme. Lexical nodes are always associated
with a sematic node representing a sense which can
be expressed with a given lexeme. It is important that
lexical nodes also contain information about the
language. It is used for applying the translingual
functions of the semantic search.
The types of relationships are determined by the
set of permissible combinations of node types and can
take the following values:
1. Sense-to-sense-synonymy;
2. Sense-to-sense-antonymy;
3. Sense-to-sense-hyponymy;
4. Sense-to-sense-hypernymy;
5. Sense-to-sense-holonymy;
6. Sense-to-sense-meronymy;
7. Sense-to-lexeme.
One of the advantages of such a lexical-semantic
structure is the elimination of ambiguity resolving.
While working with semantic nodes we use all word
forms that express associated senses. Another benefit
is that sense-to-sense relations can be taken into
account, which makes it possible to refine the
particular concept for a given semantic meaning. And
the last but not the least advantage is the using of
sense-to-lexeme relations to provide translingual
search due to keeping word forms in different
languages.
KEOD 2020 - 12th International Conference on Knowledge Engineering and Ontology Development
308
3 SEARCH ALGORITHM
3.1 General Description
The idea of the proposed approach is that a user
formulates a search query with knowledge of required
sense. Given this fact, we can force him generate the
search query from semantic value identifiers instead
of lexemes. Taking the semantic identifiers as the
initial data, we can obtain corresponding senses from
the semantic network, and then operate with lexical
nodes that express required senses. The method of
accepting the user feedback and providing the user
the adjusted queries to choose from has been
proposed by some authors (Bi et al, 2019), but in that
case the search is performed in two stages, which is
not always the preferred way of user interaction.
In the first stage of the algorithm, we make a
selection of the necessary semantic values and
associated lexical data. Then it is necessary to form a
search query from existing lexical units and submit it
as an input data to an existing search system, such as
Apache Lucene (Apache, 2011-2020) or Sphinx
(Sphinx, 2001-2020).
In the current approach, we propose to use several
rules for the retrieval of semantic nodes and related
lexical units. The rules are used to form the sets that
encompass all user provided senses and to eliminate
documents which can reduce the pertinence of the
search result.
Figure 1: Fragment of the semantic network.
Let’s look at the application of the rules to the
fragment of the semantic network presented in Figure
1. The semantic nodes are green and the lexical nodes
are purple.
Let’s introduce several functions to operate on the
value sets in the semantic network. To obtain a set of
lexemes expressing the semantic meaning s, we
introduce the function lex(s). For example, according
to Figure 1, the function lex(s1) will evaluate to the
following result:
lex(s
1
) = { s
1
l
1
, s
1
l
2
}
(1)
To obtain the set of lexemes that can express
semantic values of the set S {s
1
, s
2
, ... s
n
}, let’s
introduce the function slex(S):
slex(S) = lex(s
1
)
lex(s
2
)
...
lex(s
n
)
(2)
The result of this function contains a set of
lexemes that includes translingual data. It is a great
advantage to use translingual data since the user can
specify abstract semantic concepts in the search
query, and the search process will use lexical units in
all languages available in the semantic network.
Using these functions we introduce rules for the
construction of a search query.
3.2 Hyponyms Rule
Sometimes the user performing the search specifies
more general senses in the query assuming that all
concrete senses will be included in the search query
as well. For example, if the sense car is included in
the search, the user expects that the occurrences of the
specific car brands will also match the query.
Traditional search queries require significant user
efforts to achieve the result.
For the automatic selection and use of concrete
senses in the enterprise search query let’s introduce
the function hyp(s). This function returns the set of
semantic hyponyms of argument s. Then having the
subset of all concrete sense values of the argument,
we can use the function slex to select all word forms
of this subset:
Ls = slex( hyp(a) )
(3)
The result of this function (3) is the set of lexemes
Ls used for the construction of the search query.
Query result is passed to the search engine system.
However, before we proceed to the phase of
constructing such a query, we should introduce two
new rules that will help us to refine the set of lexemes
corresponding to the required semantic senses.
Method of Semantic Refinement for Enterprise Search
309
3.3 Synonyms Rule
Having the semantic node a as an input parameter, in
the second step it is necessary to expand the set of
appropriate senses by synonyms. Let semantic nodes
s
x
(Figure 2) be synonyms with respect to the node a.
Then we introduce the function syn(s) that returns the
synset for the semantic value a. For example, for а
1
,
this function returns the following value:
syn ( а
1
) = { s
1
, s
2
, s
3
, s
4
} (4)
Given the synonymous senses, let’s introduce the
function that selects a set of lexemes for the required
semantic node with all hyponyms and associated with
them synonymous values. The resulted function will
look like:
L
s
= slex(

∈
)
(5)
As can be seen from the formulas, we select for
each hyponym its synonyms and the resulting set of
senses are passed as a parameter for the function slex.
As a result, we get the set of lexemes that can be used
to build the required search query.
3.4 Antonyms Rule
However, the search of all lexemes acquired on the
previous step yields a large number of erroneous
results that reduce the pertinence of the resulting set
of found documents. To solve this problem authors
propose to make an adjustment to the algorithm of
lexemes selection. The main idea is that while
selecting senses in the search query user does not
expect to get as result documents that contain
antonymous values to the specified argument. To
implement it we propose to truncate required
wordforms at the query level. The general form of the
query Q can be defined as the set difference:
Q = L
s
\ L
a
(6)
In this case, L
a
is a set of lexemes that can be
obtained with the function:
L
a
= slex (ant(a) ) (7)
, ant(a) is a function that extracts all antonyms of
the argument of sense a.
Thus, having the sets L
s
(5) and L
a
(7)), let’s look
at the principle of query construction using the
example with the Apache Lucene search tool.
3.5 Building and Execution of Queries
In this paper, the authors propose the implementation
of the described method for semantic search using the
Apache Lucene platform.
The general architecture of the proposed
implementation and the mapping of sets, extracted
from the semantic network to Apache Lucene, are
presented in Figure 2.
Figure 2: The general architecture for Lucene.
There are two layers of implementation:
Frontend - web interface that has the field for the
input of required senses with the autocomplete
function for possible senses;
Backend - applications integrated into a common
infrastructure: application that implements the
construction of queries in the Lucene language based
on data of the semantic query; database with
documents that are used for search; the semantic
network in the form of a graph database.
The translation into the query for Apache Lucene
is based on three simple rules:
To intersect sets of lexemes use the AND operator
To combine lexemes and their sets use the OR
operator
To calculate the difference of sets apply the NOT
operator
4 RESULTS
Mainly in the existing search engines relevance and
pertinence are used for the result evaluation (Omri,
KEOD 2020 - 12th International Conference on Knowledge Engineering and Ontology Development
310
2012). Many search systems in global networks use
their own algorithms for the evaluation of results of
the search, in particular the method based on user
actions mentioned earlier.
The evaluation of the developed approach is based
on the pertinence. This value is assumed to be within
the range from zero to one. If all found documents
correspond to the expectations of the user, we assume
that the pertinence is equal to one. In case if all results
were "useless" in terms of user expectations, we
assume that the pertinence is equal to zero.
We conducted the experiment to evaluate the
pertinence of the results for the following cases:
1. Grammatical (Lucene standard) search
without the use of semantic network.
2. Semantic search without any rules.
3. Semantic search with synset rule applied.
4. Semantic search with synset and hyponym
rules applied.
5. Semantic search with additional selection of
translingual lexemes.
The experiment was done on a prepared document
database including about 1000 files. The file set
consisted of various documentation about the
household and machine equipment, for example,
price lists, user manuals, and other documents.
The value of the pertinence was calculated based
on its average value for the set of queries to the
system with different configurations. The
configuration was used to change the algorithm in
order to reveal the value of pertinence while using
different features of the semantic network.
Figure 3: Experimental results.
For example, the maximum value of pertinence is
reached while specifying five senses. At the same
time, this category (five senses) shows maximum
results while using all features of the semantic
network, and without the usage of translingual
information. However, this property relates to
specific features of the database of documents, which
contains data mainly on the same language. The
results are shown in Figure 3.
5 CONCLUSIONS
The proposed approach is based on ideas that have
many directions for development. In particular, one
direction is to search texts for semantic constructions
that could describe whole situations.
Also, each of the drawbacks of this approach
specifies a vector for further development of this
approach as a mechanism for natural language
processing. Among the revealed disadvantages there
are the following:
1. The user spends more time to prepare the
query.
2. The performance is lower for semantic
networks with high coherence.
3. For semantic networks with low coherence,
the probability of search errors is higher.
REFERENCES
Apache Software Foundation, 2011-2020, Apache Lucene
- Welcome to Apache Lucene, lucene.apache.org/
Bi, K., Ai, Q., Croft, W. B., 2019. Iterative relevance feed-
back for answer passage retrieval with passage-level se-
mantic match. In ECIR’19. 558–572.
Eckle-Kohler, J., McCrae, J. P., Chiarcos, C., 2015, Lem-
onUby–A large, interlinked, syntactically-rich lexical
resource for ontologies. Semantic Web 6 (4), 371–378
Formica, A., Pourabbas, E., Taglino, F., 2020. Semantic
Search Enhanced with Rating Scores. Future Internet.
12. 67.
Francopoulo, G. (ed.), 2013. LMF Lexical Markup Frame-
work. ISTE Ltd and John Wiley & Sons, Inc., London,
Hoboken.
Hasibi, F., Balog, K., Bratsberg, S., 2016. Exploiting entity
linking in queries for entity retrieval. ACM SIGIR In-
ternational Conference on the Theory of Information
Retrieval (ICTIR '16). 209-
Klimenkov S. V., Nikolaev V. V., Kharitonova A. E., Gav-
rilov A. V., Pismak A. E., Pokid A. V., 2020. Using the
semantic network for storing semi-structured data. En-
gineering Journal of Don 2(62), 27-47 (in Russian)
Modoni, G., Sacco, M., Terkaj, W., 2014. A semantic
framework for graph-based enterprise search. Applied
Computer Science. 10. 66–74
Ogarok, A., 2020. Method of semantic search and analysis
of information. Informatization and communication
2020(1). 75-80 (in Russian).
Method of Semantic Refinement for Enterprise Search
311
Omri, M. N., 2012. Relevance Feedback for Goal's Extrac-
tion from Fuzzy Semantic Networks. Asian Journal of
Information Technology. 3. 434-440.
Osika, V., Klimenkov, S., Tsopa, E., Pismak, A., Nikolaev,
V., Yarkeev, A., 2017. Method of Reconstruction of Se-
mantic Relations using Translingual Information. Pro-
ceedings of 9th International Conference on
Knowledge Engineering and Ontology Development,
239-245.
Pismak, A. E., Klimenkov, S., Tsopa, E., Slobodkin, A.
Yu., Nikolaev, V. V., 2019. Merging of semantic net-
works based on equivalence of topologies. Izvestiâ
vysših učebnyh zavedenij. Priborostroenie. 62. 50-55.
(In Russian)
Pokid А. V., Klimenkov S. V., Tsopa Е. А., Zhmylev S. А.,
Tkeshelashvili N.М., 2017 Quick search method for
nodes of a semantic network by exact word forms
matching. Journal of Instrument Engineering. Vol. 60,
N 10. P. 932—939 (in Russian).
Rashid, J., Nisar, M., 2016. A study on semantic searching,
semantic search engines and technologies used for se-
mantic search engines. International Journal of Infor-
mation Technology and Computer Science (IJITCS).
10. 82-89
Solskinnsbakk, G., Gulla, J., 2011. Contextual search navi-
gation using semantic tag signatures. ACM Interna-
tional Conference Proceeding Series. 34.
Sphinx Technologies Inc. “Open Source Search Engine.”
Sphinx, 2001-2020, sphinxsearch.com/.
Stern, D., 2015. Making Search More Meaningful: Action
Values, Linked Data, and Semantic Relationships.
Online Searcher 39 (5), 55-58 (September/October
2015).
KEOD 2020 - 12th International Conference on Knowledge Engineering and Ontology Development
312
