Semantic Knowledge-Based-Engineering: The Codex Framework

J. Zamboni

, A. Zamﬁr

and E. Moerland

Institute of System Architectures in Aeronautics, German Aerospace Center, Hamburg, Germany

Keywords:

Knowledge-Based Engineering, Object-Oriented Programming, Semantic Web Technologies, Collaboration,

Complex-system Development, Collaborative Engineering.

Abstract:

The development of complex systems within multi-domain environments requires an effective way of cap-

turing, sharing and integrating knowledge of the involved experts. Modern Knowledge-Based Engineering

(KBE) systems fulﬁll this function, making formalized knowledge executable by using highly specialized

environments and languages. However, the dedication of these environments to their domain of application

poses limitations on the cross-domain integration of KBE applications. The use of Semantic Web Technolo-

gies (SWT) delivers a domain-neutral way of knowledge formalization and data integration which promises

to drastically reduce the effort required to integrate knowledge of multiple domains in a single representation.

Especially within the complex ﬁeld of aeronautical vehicle design the authors are working in, characterized by

several individual disciplines having to be considered simultaneously, the combined usage of KBE and SWT

technologies seems an attractive approach for the continued digitalization of the design process. In this paper,

the COllaborative DEsign and eXploration (Codex) framework is presented which aims at merging these two

technologies into a single framework that can be used to create domain-speciﬁc knowledge-bases and inte-

grate these into a single model of the overall product. Formalizing and executing this model will lead to a

more transparent and integrated view on complex product design.

1 INTRODUCTION

Designing the next generation of aeronautical vehi-

cles requires a system of systems approach in which

a large amount of disciplinary domains need to be in-

tegrated in an overarching product development pro-

cess. Due to the current trend towards digitalization of

processes, an increasing amount of data is generated

during the design of these complex products. This

data must be aggregated and processed into compre-

hensible information before decisions can be based

upon it. These often manually executed tasks place an

increasing burden on the low number of experts avail-

able, in particular when the processes are coupled and

the tasks have to be repeated many times. The amount

of data and ever-changing landscape of requirements

and decisions can also lead to the emergence of errors

and inconsistencies among the different models.

Knowledge-Based Systems (KBS) are developed

with the aim of capturing and formalizing the ex-

perts’ knowledge so that the data processing, require-

https://orcid.org/0000-0003-3207-4138

https://orcid.org/0000-0001-7579-9628

https://orcid.org/0000-0003-4818-936X

ments analysis, and decision making can be (par-

tially) automated by using a computer for their execu-

tion (Milton, 2008). A KBS automatically propagates

user decisions to the relevant requirements, compo-

nents, and parameters, cascading these changes and

re-validating the model. In this way, true concur-

rent engineering in which several disciplinary anal-

ysis can be performed at the same time becomes pos-

sible. These approaches promise to drastically reduce

the time between each design iteration, ensure con-

sistency with the formalized experts’ knowledge and

free up resources to assess the impact of speciﬁc de-

cisions on the results.

In literature (La Rocca, 2012), Knowledge-Based

Engineering (KBE) is deﬁned as the merging of dif-

ferent disciplines such as Artiﬁcial Intelligence, Com-

puter Aided Design and Object-Oriented Program-

ming (OOP). It can be considered as an extension of

KBS with a stronger focus on tasks that have a large

impact on the engineering design process, namely

solving computational problems, dealing with geome-

tries and conﬁgurations. KBE application develop-

ment is still a fairly new discipline and it has seen a

limited use only in speciﬁc engineering sectors such

242

Zamboni, J., Zamﬁr, A. and Moerland, E.

Semantic Knowledge-Based-Engineering: The Codex Framework.

DOI: 10.5220/0010143202420249

In Proceedings of the 12th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2020) - Volume 2: KEOD, pages 242-249

ISBN: 978-989-758-474-9

as aerospace and automotive. This can be traced to

the fact that these speciﬁc sectors deal with the de-

sign of safety critical and complex systems that need

to adopt new technologies to remain competitive. All

this while under the pressure to use less resources,

to shorten the time-to-market of the products, and

to satisfy a large and continuously evolving set of

requirements. KBE proves to be a good methodol-

ogy for front-loading knowledge in the design pro-

cess, thereby creating a better foundation for design-

decisions that have to be made early in the product

life-cycle, which often have signiﬁcant inﬂuence on

the product performance (Kulkarni et al., 2017).

Managing knowledge in multi-domain environ-

ments, such as product development, requires a col-

laborative framework that is well aligned with the

knowledge engineering process. Creating such a

framework for knowledge representation is one of

the fundamental aspects in designing a KBE applica-

tion (Sanya and Shehab, 2014). The KBE tools avail-

able on the market all adopt OOP as the core mod-

eling approach. We argue that OOP has its limita-

tions when it comes to fully capturing and integrating

experts’ knowledge as it limits possibility for meta-

modeling to frame-based structures. Our research

proposes a novel approach to knowledge formaliza-

tion in KBE applications, in which a more generic

knowledge structure using Semantic Web Technolo-

gies (SWT) (World Wide Web Consortium, 2015) is

adopted in an effort to remove these limitations.

The Codex framework is currently being devel-

oped at the German Aerospace Center (DLR), aim-

ing to overcome a large part of the aforementioned

burdens. It targets to ease the creation of knowledge-

based engineering tools, which can be easily inte-

grated in a digitally coupled overarching product de-

velopment process for aeronautical vehicle design.

Codex is a continued development of the model gen-

erator (Zamﬁr et al., 2018) and it aims to improve the

accessibility, extendability, and ease of cross-domain

knowledge reuse.

The following section will highlight the chal-

lenges of collaboration in multi-domain environments

and present possible solution to these. Section 3 fo-

cuses on human-machine interaction, the importance

of the meta-modelling environment and its impact on

knowledge formalization. Thereafter, section 4 will

present the current state of the Codex framework and

provide an example of multi-domain integration. This

paper concluded with a summary and an outlook on

future goals of this framework.

2 MULTI-DOMAIN

COLLABORATION

One reason for the aforementioned low adoption of

the KBE methodology can be be found in the large

difference between the abstract, high-level language

used in these applications compared to the highly

speciﬁc domain languages and tools generally used

within each discipline. Speciﬁc domain languages

and environments allow for a high level of expres-

siveness, since the semantics are tailored to enable

very precise modeling while using a set of vocabu-

lary and concepts that the domain-expert is already

familiar with. In contrast, to allow for integration

and high-degree linking of knowledge from all stake-

holders within a coherent knowledge base, a very ab-

stract modeling language is required, which makes no

assumptions on the domain it is used for and there-

fore features low expressiveness for speciﬁc domains.

Therefore, the choice of the modeling language for

a collaborative KBE application requires a trade-off

between applicability to different domains (abstrac-

tion/generality of the language) and expressiveness

within the domain itself.

Two examples of KBE tools used in the aerospace

sector are Pacelab APD (TXT Group, 2020) and

ParaPy (ParaPy B.V., 2019). The choice of mod-

eling languages are C# for APD and Python with

a speciﬁc ﬂavor of annotations for Parapy, which

makes knowledge-formalization straight-forward for

programmers with experience in these languages. In

both tools the meta-model is deﬁned in a frame-

like structure (Minsky, 1974), resulting from the ne-

cessity to create the model in the particular object-

oriented programming language used by the applica-

tion. Moreover, the model is deﬁned in a hierarchical

way as this structure is commonly used when mod-

eling a product and its sub-parts within the engineer-

ing domain. Describing relationships among parame-

ters from the same discipline or in the same system of

components is fairly easy thanks to the inherent con-

nections of this type of structure (e.g. parent and child

relationships).

An issue that may arise from a frame-based and

hierarchical structured knowledge capture approach

is that higher complexity, especially via cross-branch

connections, tends to increase rigidity of the knowl-

edge base and makes it more complicated to use. This

over-coupling diminishes the potential of knowledge

re-usability since the coupled knowledge is not en-

capsulated anymore and its usage introduces many

more (unwanted) dependencies. In fact, the hierarchi-

cal structure often does not even reﬂect the naturally

emerging structure of collaboration, which resembles

Semantic Knowledge-Based-Engineering: The Codex Framework

243

a graph where many cross-branch connections ex-

ist (Alexander, 1965). This unconstrained structure

yields a much higher degree of possible complexity

in designing knowledge while decreasing the friction

of cross-domain knowledge transfer.

Although this frame-like and hierarchical way of

modeling has been proven to be effective in practice,

within the Codex framework we choose a modeling

approach that focuses on avoiding the emergence of

conﬂicts that commonly arise in multi-domain envi-

ronments. This approach is based on semantically ex-

pressing the precise meaning between models of dif-

ferent domains, which we assume to be key to create

a highly collaborative KBE application.

SWT have the potential to tackle some of the

challenges just mentioned. The models created us-

ing SWT are based on the formal semantics of

RDF Schema (RDFS) and Web Ontology Language

(OWL) (World Wide Web Consortium, 2015) which

are unambiguous, precise, can be automatically val-

idated for consistency and can be understood by

experts from other domains. The increased meta-

modeling capabilities allowed by these formal se-

mantics enable the integration of common knowledge

shared by multiple domains while still persisting all

domain-speciﬁc interpretations.

Codex utilizes a hybrid modeling approach

where the internal knowledge representation is as

generic as possible (using SWT), while the mod-

eling interface used by the engineer is as close

as possible to his/her Domain-Speciﬁc Language

(DSL) (i.e. the language commonly used within

that speciﬁc domain). Examples of such DSLs

within the ﬁeld of aerospace are the Systems-

Modeling-Language (SysML) (Object Management

Group, 2020) and Common-Parametric-Aircraft-

Conﬁguration-Schema (CPACS) (Alder et al., 2020).

Codex is able to translate these (and several other)

DSLs to a generic knowledge representation, allow-

ing different disciplines to unambiguously link parts

of their knowledge – effectively creating an inter-

domain knowledge representation of the overall prod-

uct. The following section will elaborate on this as-

pect.

As depicted in Fig. 1, this mechanism enables

coupling multiple disciplines across the entire life-

cycle of an aircraft conﬁguration. Already in the

early stages of development, this coupling is automat-

ically managed by Codex and takes away the burden

of having to manually communicate inter-domain de-

pendencies. This mechanism ultimately results in the

availability of more time for creative, value-adding

design tasks to be performed by the engineers and

largely reduces the amount of mistakes made in in-

terdisciplinary communication.

Data interchange: RDF

Taxonomies: RDF-S

Syntax: XML

Ontologies: OWL Rules: RIF/SWRL

Identifiers: URI Character Set: Unicode

Querying:

SPARQL

Root Knowledge representation

CPACS

XSD

CPACS

Aero

CPACS

Structures

CPACS

[X]

SysML

UML

Custom

Language B

Custom

Language A

DSL

Custom

Language A-B

Figure 1: Coupling knowledge of different aerospace disci-

plines through language layers in Codex.

3 CHALLENGES IN MODELING

FOR KBE APPLICATIONS

The following section highlights the challenges that

arise when formalizing knowledge in KBE applica-

tions by ﬁrst focusing on the interaction between hu-

mans and machines. Thereafter, the importance of the

meta-modeling environment is discussed by compar-

ing frame-based structures with a knowledge graph

approach.

3.1 Human-machine Interaction

Effective collaboration among machines or software

that should produce deterministic results demands a

ﬁxed communication protocol. Changes to that pro-

tocol often require making changes to the machines

and software as well. When multiple tools/knowledge

bases must be integrated, the problem of language

barriers arises from the nature of having multiple

domains, each with their own DSL. Each DSL is

expressed through different software-systems, ﬁle-

formats, and ontologies. When two or more domains

have to share knowledge (collaborate), they often ex-

press the same (or at least similar) meaning of this

shared subset of knowledge in their own DSL. To then

integrate knowledge from a domain A and another

domain B a Model-to-Model Transformation (M2M)

needs to take place, which could manifest itself as a

ﬁle-based export into a common format understood

by both A and B or expressing the semantic mean-

ing between A and B via ontological statements. The

ﬁrst method of integration is most commonly used

but does not scale well with the number of domains

involved (n), since for every additional domain the

KEOD 2020 - 12th International Conference on Knowledge Engineering and Ontology Development

244

Tool A

AàSchema

Schema

Definition

Specification Documents

SchemaßB

contributes contributes

develops

Tool B

Machine

Language

Based on

Tool A Developer Tool B Developer

maintains

Schema Developer

uses

defines

(a) Human-machine protocol deﬁnition using a schema.

Codex

Tool A

develops

Tool B

Tool A Developer

Tool B Developer

maintains

Knowledge Integrator

Domain

Ontology

Domain

Ontology

I/O I/O

integrates

(b) Human-machine protocol deﬁnition using Codex.

Figure 2: Comparison of legacy and Codex approaches.

number of potentially necessary M2M grows expo-

nentially (n ∗ (n − 1)).

A solution to this problem is to extend the com-

mon format to all the involved domains. Such an ap-

proach has been taken within the aerospace commu-

nity with CPACS, which was initiated by the German

Aerospace Center and is nowadays continually devel-

oped as an open-source format within the aerospace

community. This schema is required to include all

knowledge that must be shared by at least two in-

volved domains and forces these domains to agree on

how this shared knowledge is expressed. This makes

integration of tools within a multi-disciplinary design

optimization workﬂow easier. Some successful im-

plementations of this central data exchange format ap-

proach for multi-domain and cross-company collab-

oration have been shown in (Moerland, E., Pfeiffer,

T., B

ohnke, D. et al., 2017) and (Ciampa and Nagel,

2018). Utilizing a central schema results in a positive

network-effect – the usefulness of the schema and the

tools that utilize it increases with the number of do-

mains and people participating.

This removes the M2M scaling issues, but often

lacks reﬂection of the aforementioned graph struc-

ture of collaboration. This process demands the tool

developer to provide a mapping between the com-

mon exchange language and the internal application

model. In fact, effective collaboration among people

demands a ﬂexible communication protocol that can

capture subtle semantic differences in meaning, al-

lows for a variety of meanings about concepts to coex-

ist, and supports the distributed nature of knowledge

acquisition by enabling knowledge engineers to ad-

just their models at any time without having to know

all or any of the dependencies on their model.

Moreover, the ﬁxed structure of a schema, to-

gether with the high number of domain dependencies,

makes modiﬁcations to it a labor intensive task, es-

pecially in a collaborative environment. This often

results in a reluctance to introduce changes and there-

fore decreases development speed. These problems

intensify with the number of domains and participants

involved, which counteracts the positive network-

effect – the more domains and people make use of

the schema, the more rigid it becomes.

Figure 2a depicts the legacy approach, in which

the communications protocol between people is based

on natural language (or speciﬁcation documents writ-

ten in natural language) and the communication pro-

tocol for the machines (tools) needs to be manually

derived from these speciﬁcation documents by the

schema developer.

With Codex we aim to provide the collaborators

with a framework to add semantics to their exchange

protocol and the tools with an application program-

ming interface (API) to communicate their semantic

model to the multi-domain environment, as shown in

Figure 2b. These enhancements add formal meaning

to the protocol and remove the necessity for a central

schema while still allowing all tools to communicate.

This also removes the previously mentioned negative

network effect, since the labor intensive task of con-

tinuously keeping the schema-based inter-tool com-

munication protocols updated, has been simpliﬁed.

The task is now handled by the knowledge-integrator

that can independently deﬁne the initial shared mean-

ing between the different domain ontologies by us-

ing the formal semantics of RDFS and OWL. This

shared meaning can be updated and modiﬁed with-

out the need for the different domains to agree on

a common representation, effectively creating less

communication-overhead. Manual work is still re-

Semantic Knowledge-Based-Engineering: The Codex Framework

245

quired from the tool developer to maintain the seman-

tic model of his/her tool whenever the tool internals

are modiﬁed.

3.2 Meta-modeling Environment

In the OOP paradigm the class frame takes a central

role as other constructs such as objects, methods and

values cannot exist outside of their class. Informa-

tion in one class can be re-used in others by inheri-

tance and changes made to the classes are reﬂected in

the objects instantiated from them. If a class is modi-

ﬁed, all objects that depend on it become invalid. This

strict separation of meta-model and model is resolved

in OOP languages by ”freezing” the former while

the latter is being built and used, thus ensuring that

issues due to meta-model incongruities cannot arise

during run-time. This is usually done by compiling

the classes deﬁned in the source code.

In KBE tools based on OOP languages the strict

separation of meta-model and model is implicitly

taken and becomes part of how the knowledge en-

gineer interfaces with the knowledge base. A posi-

tive result of having the meta-model in compiled form

is that performance during the knowledge execution

phase can be improved. On the other hand, a di-

rect drawback of this choice is that it takes time to

compile the meta-model and switch to the modeling

tasks. This can negatively impact the experience of

the knowledge engineer as he/she would not be aware

of the impact of the changes on the model until the

time-intensive process needed to make such changes

available is ﬁnished; in other words, rapid iteration

of the KBE system is limited and the expert is en-

couraged to make as many changes as possible before

compiling and assessing the changes. Furthermore,

having to compile the meta-model before it can be

used makes it less practical to have a KBE applica-

tion deployed on the web, which is a major advantage

when it comes to collaboration and adoption and one

of the future goals of the Codex framework.

In SWT standards every entity is a resource with

equal importance. Classes, individuals, object- and

data-properties can be linked together but their ex-

istence is not dependent on the presence of a spe-

ciﬁc entity, as is the case for objects and classes in

OOP. Moreover, there is no strict separation between

classes and individuals as, depending on the state-

ments made, a resource can be both. For example,

an expert could see an A320 as an individual of type

Aircraft while a different (and not conﬂicting) view

of another expert is that A320 is a class for a family

of aircraft that shares a speciﬁc set of basic proper-

ties. Thus A320 can be simultaneously a class and an

individual depending on the speciﬁc point of view.

We believe that the proposed approach within

Codex can improve knowledge re-usability when

compared to OOP based KBE tools. One reason for

this is that only the resources that are actually needed

can be re-used, leaving out unnecessary information

that might actually overcomplicate the derived knowl-

edge base. Another reason for this improvement can

be found in the ability to freely mix classes and indi-

viduals; any model can become the starting point for

a new meta-model without much overhead. Friction

of implementing new knowledge is also decreased as

the engineer does not need to worry about having to

model his/her ideas in a strictly hierarchical language.

In Codex we adopt more ﬂexible modeling capa-

bilities allowed by SWT when building knowledge

bases. Doing so makes the boundary between meta-

model and model blurred, when compared to the OOP

approach, leading us to decide not to compile any of

the user-deﬁned knowledge. In this way, the expert

is allowed to modify and extend the meta-model and

model simultaneously during run-time. This choice

should allow for a faster iteration of knowledge for-

malization leading to a higher speed of innovation.

Deployment of the complete knowledge base on the

web becomes also possible allowing multiple users to

collaborate concurrently on the same project.

4 THE CODEX FRAMEWORK

With the Codex framework we provide an implemen-

tation of a KBE application where semantic knowl-

edge formalization plays a central role. The frame-

work currently consists of several modules, that allow

the different domain experts to solve many of their

knowledge-engineering tasks in a holistic way. Codex

is written in the Kotlin programming language (Kotlin

Foundation, 2020), as it has the ability to leverage the

syntax of the language to create so-called type-safe-

builders, which are a way of creating custom DSLs

within the language. This allows for the provision of

an implementation of the aforementioned hybrid ap-

proach to knowledge formalization not just to users

of our Graphical User Interface (GUI), but also to do-

main experts that like to express their knowledge in

code, as well as developers of plugins for the Codex-

framework.

Within Codex, functionalities are provided in the

form of plugins, each possibly providing its own

DSL and ontology. The core module of the frame-

work is the codex-semantic module that makes use

of existing and well-established standards for knowl-

edge representation (Resource Description Frame-

KEOD 2020 - 12th International Conference on Knowledge Engineering and Ontology Development

246

work (RDF) (World Wide Web Consortium, 2015),

OWL) and utilizes mature open-source libraries,

such as those provided by the Apache Jena Frame-

work (Apache Software Foundation, 2020). This

module takes care of the creation and manipulation

of OWL-models.

The modular plugin architecture of Codex also al-

lows for existing tools, languages, and technologies

to be connected to it. A plugin that has already been

implemented is the codex-parametric module that al-

lows users to semantically deﬁne and solve systems

of parametric constraints with a DSL that closely re-

sembles common mathematical notation. This plugin

contains an execution engine that provides informa-

tion about parameter dependency (e.g. over/under de-

termination of the system of constraints) and solving

capabilities.

Another plugin that is currently under develop-

ment provides the ability to import and export models

deﬁned using the aforementioned CPACS schema. It

also exposes this schema as an OWL ontology and ad-

ditionally provides a custom DSL that can be used by

engineers already familiar with CPACS to create and

modify models. This allows Codex to seamlessly in-

tegrate with the already existing, vast eco-system of

CPACS-enabled tools.

The knowledge asserted by the domain expert

can easily be enhanced by simply adding the formal-

semantics of RDFS and OWL as a set of rules that

will infer additional knowledge. Moreover, the user

can utilize this same mechanism (and the provided

Rule-DSL) to add custom rules to the knowledge-

base. While rules expressed through this mecha-

nism are sufﬁcient for semantic-inferences, they do

not cover the deﬁnition of production-rules (Russell

and Norvig, 2016), that demand additional expres-

sions to be possible, such as the deﬁnition of a pri-

ority of rule-execution. These production-rules are an

essential part of any KBE application, since they al-

low for the dynamic, rule-based creation of a large

number of interconnected individuals. To satisfy this

need, a dedicated module that allows such production-

rules to be conveniently expressed via a custom DSL

and executed using state-of-the-art algorithms and li-

braries is being developed. These user-deﬁned rules

will not be stored within the OWL model, but a more

appropriate standard such as the Rules-Interchange-

Format (World Wide Web Consortium, 2013).

4.1 Multi-domain Integration Example

In this subsection, a simpliﬁed example of how multi-

ple domains can be integrated with the help of Codex

is discussed. The following provides some exam-

ples of parameters and rules present within multiple

aerospace design domains, each represented by their

individual namespace:

a: Aircraft Sizing Domain.

(a : Wing rd f : type owl : Class)

m: Mission Analysis Domain.

R ·

g·T SFC

= −ln(

end

init

)

end

= M

init

− M

f uel

= Mission Tool(R, C

, C

, T SFC, . . . )

t: Fuel-tank Sizing Domain.

Fuel Density =

Fuel Mass

Fuel Volume

Tank Volume = Fuel Volume · Factor

r: Requirements Domain.

Range ≥ 6150km

”All fuel must be stored in the wing”

Through the use of the codex-parametric module’s

DSL and ontology, the above domains’ knowledge

can be captured; for example, an equation is mod-

elled as an expression tree where each node is ei-

ther of type operator, function (e.g. sin(x)), param-

eter, or constant. This expression tree is stored as a

RDF graph. External parametric tools, such as ”Mis-

sion Tool”, can be included in the knowledge graph as

they behave like functions having a local name within

the ontology, requiring input parameters and provid-

ing an output. During modeling, either of the deﬁni-

tions of m : M

f uel

(equation or external tool call) can

be utilized to compute its value, as the constraints in

codex-parametric are automatically reversed by use

of numerical convergers.

During the knowledge integration phase, param-

eter equivalency between different domains can be

quickly achieved with RDF statements such as:

(m : M

f uel

owl : sameAs t : Fuel Mass)

(m : R owl : sameAs r : Range) .

This ensures that the two parameters are treated as

the same entity by the execution engine, and conse-

quently their calculated values will be equivalent.

Additionally, knowledge expressed through natu-

ral language, such as the requirement that ”all fuel

must be stored in the wing”, can be integrated by RDF

statements such as:

(r : f uel r : storedIn r : wing)

(r : f uel owl : sameAs t : Fuel Volume)

(r : wing rd f : type a : Wing) .

This example is visually represented in Figure 3

where the unconnected knowledge graphs are mean-

ingfully integrated through the use of semantic state-

ments. With this example we show that a schema is

not necessary to bridge the gap between the different

Semantic Knowledge-Based-Engineering: The Codex Framework

247

Aircraft

Mission

Fuel-tank

Requirements

Knowledge Integration

Figure 3: Multi-domain knowledge integration.

domains. Maintenance is only necessary if a change

within a domain alters the meaning of the integrating

statements.

5 CONCLUSIONS

Utilizing formal knowledge deﬁnitions in the engi-

neering domain enables making the expert’s knowl-

edge reusable, modular, and machine executable.

However, the reliance of KBE on OOP introduces

limitations that might be a cause for the low adop-

tion rate of this methodology. The choice of using a

generic language (OWL) that makes no assumptions

on the domain it is being applied to, enables a way to

include other more speciﬁc approaches to system en-

gineering such as the widely adopted SysML. Codex

aims to augment these approaches by providing the

ability to apply custom rules to these models, effec-

tively making them executable. Moreover, it is one of

our goals to leverage the inference mechanism com-

bined with the model integration capability to infer

new knowledge from the models described through

these well established approaches.

The overall aim of the Codex framework is to pro-

vide a holistic knowledge-formalization and execu-

tion environment that reﬂects and supports the graph

structure of an effective collaborative environment.

Although Codex is at an early stage of development

and the main expected improvements have yet to be

validated, the framework can already be utilized to

deﬁne, link, and use ontologies for the creation of exe-

cutable KBE tools. A possible obstacle to its adoption

is that semantic modeling might prove to be difﬁcult

for the experts involved in the product development

process and the beneﬁts do not outweigh the required

learning curve. Another pitfall could arise when users

do not follow semantic modeling best practices or

specialize their ontologies too much, lowering their

potential for re-usage within other domains.

The Codex framework is currently being devel-

oped to create a framework for knowledge digitaliza-

tion and integration for usage within aeronautical ve-

hicle design. When the framework is fully matured

and has proved its usage within the design process,

the opportunity arises to further open-up the design

space by incorporating a larger amount of engineer-

ing and scientiﬁc domains, e.g. from other means of

transport. With this, the basis is created for the over-

all design of more efﬁcient, fully integrated mobility

solutions.

Future developments include further integration

with existing standards and tools, implementation of

a rule-based production system, and the creation of

a data-analytics and visualization environment that

leverages the data-integration and exploration capa-

bilities of SWT.

REFERENCES

Alder, M., Moerland, E., Jepsen, J., and Nagel, B. (2020).

Recent advances in establishing a common language

for aircraft design with CPACS. In Aerospace Europe

Conference, Bordeaux.

Alexander, C. (1965). A city is not a tree. Architectural

Forum, 1965, 122.

Apache Software Foundation (2020). Apache Jena. https:

//jena.apache.org/. Online; accessed Jul 27, 2020.

Ciampa, P. D. and Nagel, B. (2018). AGILE the Next

Generation of Collaborative MDO: Achievements and

KEOD 2020 - 12th International Conference on Knowledge Engineering and Ontology Development

248

Open Challenges. In 2018 Multidisciplinary Analysis

and Optimization Conference. American Institute of

Aeronautics and Astronautics.

Kotlin Foundation (2020). Kotlin Programming Language.

https://kotlinlang.org/. Online; accessed Jul 27, 2020.

Kulkarni, A., van Dijk, R., van den Berg, T., and Rocca, G.

(2017). A knowledge based engineering tool to sup-

port front-loading and multi-disciplinary design opti-

mization of the ﬁn-rudder interface. In Aerospace Eu-

rope 6th CEAS Conference, volume 680.

La Rocca, G. (2012). Knowledge based engineering: Be-

tween AI and CAD. Review of a language based tech-

nology to support engineering design. Advanced En-

gineering Informatics, 26(2):159–179.

Milton, N. (2008). Knowledge Technologies. Polimetrica,

Monza IT.

Minsky, M. (1974). A framework for representing knowl-

edge. MIT AI Memo 306.

Moerland, E., Pfeiffer, T., B

ohnke, D. et al. (2017). On the

design of a strut-braced wing conﬁguration in a col-

laborative design environment. In 17th AIAA Aviation

Technology, Integration, and Operations Conference,

page 4397.

Object Management Group (2020). OMG Systems Model-

ing Language (OMG SysML). https://www.omg.org/

spec/SysML/. Online; accessed Jul 27, 2020.

ParaPy B.V. (2019). ParaPy - Knowledge Based Engineer-

ing Platform. Online; accessed Jul 27, 2020.

Russell, S. and Norvig, P. (2016). Artiﬁcial Intelligence:

A Modern Approach, Global Edition. Pearson Educa-

tion Limited.

Sanya, I. and Shehab, E. (2014). An ontology framework

for developing platform-independent knowledge-

based engineering systems in the aerospace indus-

try. International Journal of Production Research,

52(20):6192–6215.

TXT Group (2020). Pacelab APD. https://www.txtgroup.

com/markets/solutions/pacelab-apd/. Online; ac-

cessed Jul 27, 2020.

World Wide Web Consortium (2013). RIF Production Rule

Dialect (Second Edition). https://www.w3.org/TR/rif-

prd/. Online; accessed Jul 27, 2020.

World Wide Web Consortium (2015). Semantic Web. https:

//www.w3.org/standards/semanticweb/. Online; ac-

cessed Jul 27, 2020.

Zamﬁr, A., Jepsen, J., Moerland, E., and Nagel, B. (2018).

Development of a modular knowledge-based model

generator for the preliminary aircraft design process

of the future. In 2018 Aviation Technology, Integra-

tion, and Operations Conference. American Institute

of Aeronautics and Astronautics.

Semantic Knowledge-Based-Engineering: The Codex Framework

249
