(In) Security in Graph Databases

Analysis and Data Leaks

Miguel Hern

andez Boza

and Alfonso Mu

noz Mu

noz

Innovation 4 Security - BBVA , Av. Burgos 16D 28036, Madrid, Spain

Innovation 4 Security Labs - BBVA, Av. Burgos 16D 28036, Madrid, Spain

Keywords:

Graph Database, Privacy, Neo4j, OrientDB, Grafscan.

Abstract:

Graph databases are an emerging technology useful in the ﬁeld of cybersecurity, especially in the detection of

new threats based on the correlation of diverse sources of information. In our research, we had reviewed the

design of the most widespread graph databases, for example Neo4J and OrientDB, detecting several security

problems, improper default conﬁgurations and leaks, scanning the Internet during 9 months. To repeat our

proofs, we are releasing the ﬁrst hacking tool for testing and detecting (in) secure graph databases, GraFScaN.

1 INTRODUCTION

The current knowledge society has a clear dependence

on the creation of new contents, in multiple formats,

that will be consumed anywhere and at any time. This

need as a society generates that the creation of new

data increases every day. This can be observed in

any social network, blog or instant messaging appli-

cation at present: new photos, new videos, new links,

etc. In this environment, the form and the means used

for its storage and subsequent processing are critical,

especially in today’s society where free and massive

services are required, where the presence of adver-

tisements and the extraction of information through

the analytics techniques or data mining are crucial for

new business models.

In this context, the management of the temporal

component in the creation, storage or consumption

of such information, especially with the addition of

new sources of information, is not negligible. This

problem is signiﬁcant in ﬁelds such as astronomy or

genomics, and of course in information search tech-

nologies on the Internet, for example search engines

or ﬁnancial systems (Zachary, 2015).

For all these reasons, Big Data technologies have

been focusing on the collection, storage, search, anal-

ysis and visualization of large amounts of data. Such

is the interest of these technologies that in the last

decade a multitude of tools have been developed for

the treatment of large volumes of information cen-

tered on three types of data: structured data (data

well deﬁned length and format, typically stored in re-

lational databases), unstructured data (data without

speciﬁc format and is stored as it was collected) and

semi-structured data (data that is not limited to cer-

tain ﬁelds but has markers to separate information, for

example the JSON standard).

At the same time, the different types of data can

be stored considering different formats. The most

typical are: key-value storage (they are stored in

a similar way to a data dictionary where the data

is accessed from a single key), document storage

(the structure of the data stored are very similar to

key-value storage, differing in the data they keep),

column-oriented storage (it is oriented to scale hor-

izontally with what allows to save different objects

and attributes on a same key) and storage in graph.

The latter breaks with the idea of tables and are based

on graph theory, where it states that information are

nodes and relations between information are edges.

Its greater use is contemplated in cases of relating

large amounts of highly variable information, for ex-

ample in social networks.

In this point, and after a brief understanding of

the different types of data and their nature, it was op-

portune to delve into a speciﬁc type of data storage,

the graph databases. Its ability to relate information

deﬁnes it as an excellent technology in different ar-

eas of cybersecurity (fraud detection, authentication

process management, threat management, etc.) and,

therefore, it is necessary to understand its design and

analyse if they present security failures that could af-

fect other systems within an organization.

Boza, M. and Muñoz, A.

(In) Security in Graph Databases - Analysis and Data Leaks.

DOI: 10.5220/0006419003030310

In Proceedings of the 14th International Joint Conference on e-Business and Telecommunications (ICETE 2017) - Volume 4: SECRYPT, pages 303-310

ISBN: 978-989-758-259-2

303

2 GRAPH DATABASES.

ANALYSIS AND

VISUALIZATION

2.1 Introduction

The beginning of graph theory (Godsil, 2001) took

place in 1736, in an article by Leonhard Euler (Euler,

1736). The work arose from a problem known as the

onigsberg bridge problem. The problem was to go

through all the bridges once and go back to the same

starting point.

Figure 1: The bridge problem of K

onigsberg.

Euler proved that it was not possible. To do this, it

replaced each starting zone by a point and each bridge

by an arc, thus creating the ﬁrst graph, designed to

solve a problem. This case gave rise to graph theory.

Nowadays, the current technology has allowed to

take these principles to new type of database, in this

case oriented to graphs. The information is stored as

nodes or entities and the relationships between them

allow to obtain an additional information of great

value. Although, it is true that this technology is rela-

tively recent, the most signiﬁcant technological mile-

stones start from 2013, however there are already cer-

tain databases that can be used in real systems with

success. The most famous graph database, by its evo-

lution and community, is Neo4j, followed by far by

OrientDB (Figure 2).

Figure 2: Ranking of graph DBMS (Db-engines, 2017).

Up to our knowledge, scientiﬁc literature did not re-

port yet any research about the speciﬁc topics cov-

ered in this paper. For that reason, in the follow-

ing sections, the security of the most important graph

databases will be deepened.

2.2 Case Studies: Neo4j and OrientDB

Neo4j (Todd, 2009) is a graph-oriented database and

free software, implemented in Java. This database

stores the information natively in nodes and relations

instead of tables. Among its features, it has the pos-

sibility of adding several tags to the nodes and an

unique one to the relations, besides being able to add

properties or indexes. The biggest feature of this

database is its query language, Cypher.

Cypher (Cypher, 2017) is a declarative language

to describe patterns in graphs visually using ASCII-

Art syntax. It allows to indicate what one wants to

consult, to insert, to update or to eliminate of the data

in the graph without the necessity to describe it with

precision. To select the nodes the parentheses are used

because of their similarity to the circles, for example,

a node p would be represented as (p). In addition, you

can add a series of tags that facilitate the search of the

nodes, as it can be (p: Person). Within each node,

a property can be accessed by using the dot, for ex-

ample p.name. All of these values are case sensitive.

Therefore, the general structure of a query can be seen

as follows:

MATCH (node:Label) RETURN node.property

MATCH (node1:Label1)-->(node2:Label2)

WHERE node1.propertyA = {value}

RETURN node2.propertyA, node2.propertyB

You can consult relations between nodes using ar-

rows, which can be directional, and additional infor-

mation can be added using brackets inside the arrow.

An example of the structure:

MATCH (n1:Label1)-[rel:TYPE]->(n2:Label2)

WHERE rel.property > {value}

RETURN rel.property, type(rel)

It is advisable to consult the technical manual of

this database to understand in detail this query lan-

guage (Cypher, 2017).

OrientDB (Orientdb, 2017) is a non-relational

open source database management system written in

Java. This system supports documents, key / value,

and object models but relationships are managed as in

graph-oriented databases with direct connections be-

tween registers.

OrientDB incorporates a key-value and object-

oriented search engine. Its query language is SQL,

SECRYPT 2017 - 14th International Conference on Security and Cryptography

304

with some extra functionality to enable functionality

with graphs. Queries are case sensitive. The SQL

engine automatically recognizes whether any of the

indexes can be used to improve execution, although

can be explicitly added.

3 SECURITY IN Neo4j.

STRENGTHS AND

LIMITATIONS

3.1 Versions

In 2013 (Neo4j, 2013) Neo4j presents the ﬁrst ver-

sion 1.9 with serious design ﬂaws, including the pos-

sibility of executing remote code (CVE-Neo4j, 2013),

using a public exploit, CVE-2013-7259. At the end

of that year appeared the ﬁrst version 2.0 (Neo4j 2.0,

2013) where the visual section began to have more

importance. It was solved the problem of remote

code execution and was added the possibility of hav-

ing HTTPS. Until 2016 it was not evolved to new ver-

sions.

In April 2016, in Graph Connect, version 3.0 was

introduced (Neo4j 3.0, 2016), adding a multitude of

functionalities, new connection protocols and the web

administration panel disappeared. This last point in-

troduces the possibility to an attacker, by using ﬁn-

gerprinting techniques, know the version of a Neo4j

database without having to be authenticated in it. If

the panel exists the version of the database will be

less than 3.0 and if not higher. At the end of 2016 ap-

peared the new version 3.1 with the great novelty of

the implementation of user management.

The conﬁguration and design of each of these ver-

sions can be used by an attacker to try to access a

database without credentials in it and to be able to in-

sert, steal, manipulate or delete information as will be

shown below.

3.2 Conﬁguration

The default conﬁguration and version management of

this graph database is vital from an attacker’s point of

view. Therefore, the conﬁguration (conﬁguration path

and ﬁles) is analysed depending on the versions:

Version 2.x: In this case the conﬁguration in-

formation is located in the following path: {path-

neo4j}/conﬁg/neo4j-server.properties, within which

the conﬁguration settings to be detailed.

#org.neo4j.server.webserver.address=0.0.0.0

This line conﬁgures which addresses can access

the service running Neo4j. The reader can observe

that by default is commented out and only the lo-

cal user can connect to it. On the contrary, remov-

ing the comment would mean that if you expose your

IP and is accessible from the Internet, that the ser-

vice (database) would be exposed and any user (legit-

imate or otherwise) would have visibility of the Neo4j

database.

Also, it is possible to disable the login password

authentication in user’s access (default enabled). It is

not recommended in any case but in some connectors

to the database is recommended because there is no

implementation of the authentication process (Neo4j

connector, 2017).

dbms.security.auth

enabled=true

The default port for remote connection is port

7474/7473. There is the possibility of changing this

port for less exposure to unsophisticated attackers.

Obviously, it is not a sophisticated protection mea-

sure.

org.neo4j.server.webserver.port=7474

org.neo4j.server.webserver.https.port=7473

In some versions for Windows operating system

is only possible to connect via HTTP, appearing the

HTTPS line commented (Neo4j conf, 2017).

Neo4j implements a remote shell on the default

port 1337. This conﬁguration is for the remote shell

to the database, to be able to query it by Cypher.

This shell presents security problems because an user

can connect without authentication. Luckily, it is not

enabled by default and it is only possible to access

through the computer itself. It is important to monitor

the change of this conﬁguration.

#remote shell enabled=true

#remote shell host=127.0.0.1

#remote shell port=1337

Version 3.x: Unlike the previous versions, the

conﬁguration of these comes enclosed within a same

ﬁle, with the same parameters as the previous version.

The conﬁguration is in the following path: {path-

neo4j}/conf/neo4j.conf.

3.3 Protection and Storage of the

Password

In all versions, the key storage is stored in a ﬁle

on the following path: $path-neo4j$/data/dbms/auth.

This ﬁle is created when Neo4j is started the ﬁrst

time and at the end of the ﬁle appears: pass-

word change required. When the user by the browser

(In) Security in Graph Databases - Analysis and Data Leaks

305

access to the portal, it asks for the initial authentica-

tion (default-user neo4j / neo4j) and asks to change

it. The limitation of the password is that it contains at

least one character, but it does not have a maximum

character and complexity limit, also it is not allow to

put the same default password neo4j. It is certainly

not the best robust password management policy.

The password is stored using the sha256 + salt al-

gorithm, that without being a bad option it is not the

best mechanism against dictionary attacks / rainbow-

tables / brute force off-line attacks. It would be advis-

able to use PBKDF2 (Burt, 2015).

3.4 User Authentication. Design

Failures

The system that implements Neo4j at the time of au-

thenticating is an HTTP Basic (Basic Auth, 2017).

The key of a user is sent to the database, encoded in

base64, in the header of each request that requires au-

thentication. This is especially sensitive when setting

up the connection via HTTP.

The authentication system has protection against

brute-force attacks that blocks by IP source. Neo4j

detects the third attempt to access with bad credentials

by entering a constant delay of 5 seconds to accept the

following request (key stretching). This protection is

simple to override by using different intermediate de-

vices or proxies to change the source IP and avoid

this restriction. In the tests performed, counting the

network delay, using 5 IPs (5 open proxies) it is pos-

sible to run a dictionary / brute force attack without

limitations.

Additionally, another attack from a design ﬂaw

was detected. Neo4J versions 2.x and 3.x allow ac-

cess to an end-point that allows changing the user’s

key if the current key is provided. This is a prob-

lem since an attacker could send requests by trying

different current keys and force the change always to

the same key (new key). By designing the database,

an attacker does not need to receive a response from

this request, which means that an intermediate system

(e.g. IoT) could be used without having to control

the response. The attacker from time to time, does

not know when a request will hit the key change, will

connect to the database, for example via Tor, with the

new key. If the brute force attack was successful you

will have full access to the database.

3.5 Licenses

Neo4j has two types of licenses (Neo4j lic, 2017),

Community (free) and Enterprise (paid). The En-

terprise license includes a twenty-four-hour support

system, high availability, backups around the mainte-

nance and a whole series of security measures (logs,

limitation of execution time, etc.). The difference be-

tween licenses is a security problem added to Neo4j.

The cost is a problem in the use of the Enterprise li-

cense and the Community license does not present ba-

sic security options such as a log. This will facilitate

attacks and leaks of information.

3.6 Injections

If access to Neo4j is achieved, either by not having

authentication enabled, incorrect validation in the

input of information to the database (would facilitate

injection of queries cypher) or by discovery of

the credentials, we would have full access to the

information of the database. At this point, it makes

sense to analyse how the use of Cypher language can

allow different injections with security implications.

The most classic would be those that can be done in

the most common languages, such as SQL, down-

load, delete or edit the information contained in the

database. In addition, it is proposed to analyse the

impact of different queries that would allow denial

of service or new forms of encryption of the en-

tire database as a new ransomware (Mehmood, 2016).

Disc Denial

One of the techniques investigated to deny the use of

storage (disk) would be, for example, by using a re-

quest that begins to import data to occupy all avail-

able free space, data that can be imported from exter-

nal sources, via url. This attack takes advantage of

the current conﬁguration in which the amount of disk

that the database can reserve is not limited. The ex-

ample query to import an external ﬁle would be the

following:

USING PERIODIC COMMIT 1000 LOAD CSV

FROM URL AS row CREATE (A:N1{a:row[0]})-

[:RE]->(B:N2{b:row[1]});

It is possible to accelerate this type of attacks and

get the disk to ﬁll before, using a misuse of Neo4j

(Cypher T, 2017) creating indexes in the database

without control, because the space needed for each

index is greater for each data that you have to index.

Therefore, if you create a large volume of indexes, it

is possible to do it in a single query, you can make the

data import operation more efﬁcient and ﬁll the disk

before.

SECRYPT 2017 - 14th International Conference on Security and Cryptography

306

RAM Denial

The attacks investigated to deny the use of RAM,

causing a maximum reservation of the same, take

advantage of the fact that when loading information

from Cypher accumulates all the entities and relation-

ships that are created to insert them all to the same

time. A possible attack can force, by one or more re-

quests, to store a large amount of information in mem-

ory by importing a huge number of nodes through a

loop, using the term that provides Cypher FOR EACH

for them. An example of request would be:

FOREACH (x in range(1,10000000000000) —

CREATE (:Person {name:name+x, age: x%100}));

Neo4j allows to limit the execution time of

queries of this type in the database. Although this

feature could be used as a countermeasure to this type

of attacks, it would be necessary to know very well

the queries and data in the database (data that can be

dynamic) so that this alleged countermeasure does

not impede the normal operation with the database.

Ransomware

Currently, ransomware attacks on databases are based

on the possibility of exploiting a vulnerability or con-

ﬁguration failure to export-import the database and

encrypt its contents to request a later rescue (re-

trieve the information in clear). A signiﬁcant exam-

ple of this has been the recent breach of MongoDB

databases (Pauli, D, 2017).

In addition to this possibility, which is viable

if one has access to import and export the Neo4j

database (database without authentication, query in-

jection or authentication violated), the possibility of

new attacks of ransomware was analysed, taking ad-

vantage of speciﬁc features of this database. In fact, it

was observed how the Cypher language itself and its

query engine allows not only replace values (with the

function replace), which would allow, for example, a

homophonic cipher (Hammer, 1981), if not, in addi-

tion, eliminate the relations between the nodes, with

which in practice the database would be useless (al-

though it is reversible on the part of the attacker). For

example, the following query in Cypher encrypts the

prop1 of the graph by doing concatenation of replace-

ments:

MATCH (n) where n.prop1 set n.prop1 = re-

place(replace(a,81)...) z,12)

To remove the relationships, it is necessary to keep

a copy of these to be able to reverse the process. This

can be done with the following query:

MATCH (n)-[r]->(m) RETURN ID(n), ID(m),

type(r), properties(r)

And, ﬁnally, the elimination of the relationships

that exist in the database:

MATCH ()-[r]->() DELETE r

It is noteworthy that most databases exposed on

the Internet (as will be seen later) were licensed Com-

munity (without the option of logs) so that Neo4j it-

self (without the help of external technology) could

not know the queries made by the attacker or pro-

tect itself easily even if the cryptographic attack is not

very sophisticated. In theory, from the calculations

made, when doing the research, it would have been

possible to encrypt all databases exposed on the Inter-

net without security (more than 400) in less than 10

minutes.

At the following link we published a demo

video of how an attack of this type would work:

https://youtu.be/jwXS3muRkx0.

4 SECURITY IN OrientDB.

STRENGTHS AND

LIMITATIONS

Unlike Neo4j, OrientDB is a server that facilitates the

management of different graph-oriented databases.

4.1 Versions

There are a lot of versions, which are appearing

monthly. The Table 1 describes the number of ver-

sions per year (new features are constantly added).

Versions prior to 2.0.15 and 2.1.1 have the follow-

ing CVE: CVE-2015-2918 (remote attack of click-

hacking), CVE-2015-2913 (to predict session num-

bers) and CVE-2015-2912 (CSRF attacks).

Table 1: Versions of OrientDB.

Years

Versions

2013 2014 2015 2016 2017

1.x 9 4 0 0 0

2.0 0 2 7 1 0

2.1 0 0 4 18 0

2.2 0 0 0 14 2

Total 9 6 11 33 2

(In) Security in Graph Databases - Analysis and Data Leaks

307

4.2 Conﬁguration

The conﬁguration information is stored in the instal-

lation folder, {path-OrientDB}/conﬁg, where the fol-

lowing ﬁles are located:

orientdb-server-conﬁg.xml. In this ﬁle are the

necessary parameters to establish connection and the

users of the server of OrientDB with the summaries

of their passwords. This conﬁguration is by default,

and unlike Neo4j, allowing the connection from any

source IP to the OrientDB server, exposing it to the In-

ternet. The strange thing is that the documentation in-

dicates the opposite (OrientDB expo, 2017). It is sig-

niﬁcant, in addition, how to work with the user root,

making it more vulnerable against brute-force attacks,

especially since it is possible to remotely connect to

the root account.

security.json. This ﬁle shows the security settings

of the OrientDB server, changes can be made to im-

prove security. Highlight that three default users are

created for access to any database. The users cre-

ated by default are: admin:admin, writer:writer and

reader:reader. Similarly, a default database, named

Gratefuldeadconcerts, is created.

Finally, authentication is enabled by default just

like in Neo4j and it would be necessary to disable the

credentials manually.

4.3 User Authentication. Design

Failures

Initially, when the server is started, it asks to be as-

signed a password for the user root, which will have

full access to all the databases and the management

portal. If the password is left blank, a random is cre-

ated.

The authentication is based on HTTP Basic as

in Neo4j, in this case you have credentials for each

database that is inside the server. As seen in the con-

ﬁguration, if not changed, three users are generated

to access each database, which initially have a default

credentials to try to access. It is possible to manage

from the browser the creation of more users and as-

sign them the roles that appear in the documentation

(OrientDB rol, 2017), some of them allow to cross-

wise access to all the databases of the server.

The OrientDB server does not deploy any system

against brute-force attacks, either to attack access to a

particular database or to take root credentials and ac-

cess them all. This point is signiﬁcant especially if it

joins an additional vulnerability detected. The docu-

mentation explains that from the server of OrientDB

can not list the databases that are inside the server

without authentication (AuthOrientDB, 2017), but if

a request is sent to the end-point/listdatabases, for ex-

ample http://10.0.0.1:2480/listdatabases, you can see

that it returns a list with the names of the databases,

and in the response header, the version of the Ori-

entDB server is sent, all without requiring credentials.

All this greatly simpliﬁes the ﬁngerprinting.

4.4 Licenses

As in the case of Neo4j, OrientDB has two types of

licenses, Community and Enterprise. This last one

adds different functionalities for the management of

the databases but the security characteristics are equal

in both licenses, which is a better defensive approach

than in Neo4j, at least if it thinks in global terms.

5 EXHIBITION OF PRIVATE

INFORMATION. DATA LEAKS

AND INTERNET

In order to verify the impact of some of the secu-

rity problems detected, among the most spread graph

databases, a veriﬁcation process was required. With

this purpose, a speciﬁc ﬁngerprinting tool, called

GraFScaN (Hern

andez, M; Mu

noz, A., 2017), was

designed. Using this tool, different active attacks

were implemented (brute force attacks and DoS), and

Internet (IPv4) was monitored from May 2016 until

January 2017. The tool uses IP addresses of inter-

est obtained from the search engine Shodan (Shodan,

2017) and scanning tools such as Zmap (Zmap, 2017)

or Masscan (Masscan, 2017). These scanning tools

have the capability of scanning the whole Internet

within few minutes. If further information is required,

we strongly recommend reading the user guide in-

cluded with the tool (Hern

andez, M; Mu

noz, A.,

2017).

In the case of Neo4J, more than 1275 databases

were found, 298 without any authentication. In the

databases without authentication, all the privileges

could be used for the implementation of different

types of attacks. For example, a denial of service

for both Neo4j and the whole machine containing it

(Neo4J does not manage neither the RAM memory

nor the disk storage efﬁciently). This problem was

even more signiﬁcant when the machine itself offered

a web service through port 80, most of the cases cor-

porative webs.

For the cases without authentication in Neo4J (e.g.

Figure 3 and Figure 4), it was possible to obtain the

speciﬁc version used (v1.9/17, v2.x/251 and v3.0/30).

SECRYPT 2017 - 14th International Conference on Security and Cryptography

308

Figure 3: Example of information contained in Neo4j.

Figure 4: Example of a social network based on Neo4j.

This information makes much easier choosing an op-

timal type of attack. For example, in 17 cases could

be used a public exploit to obtain full control over the

machine. A relevant fact was the 5:1 ratio between the

Community and Enterprise licenses. It is important to

keep in mind that this fact does have security impli-

cations, because the Community license does not acti-

vate neither logs nor monitor of the Cypher queries.

For the OrientDB case, 214 servers were found ex-

posed, among them 553 databases. An analysis was

run with the aim of evaluating how often the default

credentials were enough, and in 187 the result was

positive. Besides, it appears the default database 104

times, that could allow the introduction of queries that

provokes DoS attacks or any other kind of misuse of

the database (hosting illegal information, cover chan-

nel, etc.).

Figure 5: Listing of databases in OrientDB associated with

a web.

Altogether, 42 servers are vulnerable to the CVEs

mentioned in the conﬁguration. There was no authen-

tication or the default authentication was activated,

the format of the existing ﬁles was accessible and in

several cases this information could be linked to spe-

ciﬁc websites in the same IP address, arising the iden-

tity of the companies. Regarding information leaks,

the implications of this fact are obvious.

During the monitor of these databases was pos-

sible to obtain information from more than 600

databases with different sensitivity levels, some of

them closely related with public institutions in Spain.

In general, sensitive corporative information was

found: information about commercial products, hun-

dreds of thousands personal dates (names, e-mails,

telephone numbers, etc.), login-passwords, etc. All

the discovered information was conveyed to the

Guardia Civil’s group of telematic crimes (gdt, 2017)

and to speciﬁc CERTs, who helped to ﬁx and mini-

mize attacks to the vulnerable devices.

6 CONCLUSION

Graph databases are an incipient technology. Never-

theless, they are having an increasing impact on com-

panies and on the management of diverse information,

especially in the context of cybersecurity. Hence,

and seeking to minimize possible attacks in the future

as a consequence of the missuse of these technolo-

gies, during this research the conﬁguration and secu-

rity components implemented within these databases

were investigated.

Regarding Neo4J, the most spread database, bad

conﬁguration habits of the database are observed,

making them vulnerable on the Internet. Measures to

prevent force brute attacks are not enough, the key

management can be improved and there is not ad-

vanced counteractions against attacks that inject bad

queries (DoS, ransomware, etc.). In this sense, the

decision of not implementing key security features,

such as logs or monitor in the Comunnity version is

not the best approach. This evidence was observed on

the exposed databases.

In the case of OrientDb there are security prob-

lems due to the default conﬁguration. When the

server initiates, the server exposes on the Internet

the databases by default. Moreover, three users are

always created by default, and they have to be re-

moved to prevent improper access. In the same

way implements deﬁcient protection measures against

brute force attacks and the detection of the version or

databases. The security problems discovered forces to

release a new version of the analysed graph databases,

Neo4j and OrientDB. This is the best recommenda-

tion to remedy the discovered security problems.

As a conclusion, excluding the new issues de-

tected, it has to be enhanced how the same design mis-

takes and dangerous default conﬁgurations are sys-

(In) Security in Graph Databases - Analysis and Data Leaks

309

tematically carry out. Once again, it is necessary keep

in mind the need of audit the emergent technologies

for dismissing an eventual negative impact on our or-

ganizations. The graph databases are proof of it.

REFERENCES

AuthOrientDB (2017). List databases on orientdb. http://

orientdb.com/docs/2.1/Console-Command-List-

Databases.html.

Basic Auth (2017). Basic authentication. https://en.

wikipedia.org/wiki/Basic access authentication. last

access 05/22/2017.

Burt, K. (2015). Pkcs #5: Password-based cryptogra-

phy speciﬁcation version 2.0. https://tools.ietf.org/

html/rfc2898.

CVE-Neo4j (2013). Cve-2013-7259. https://cve.mitre.org/

cgi-bin/cvename.cgi?name=CVE-2013-7259. last ac-

cess 05/22/2017.

Cypher (2017). Intro to cypher. https://neo4j.com/

developer/cypher-query-language/. last access

05/22/2017.

Cypher T (2017). Tuning your cypher: Tips and tricks for

more effective queries. https://neo4j.com/blog/tuning-

cypher-queries/. last access 05/22/2017.

Db-engines (2017). Ranking of graph dbmd 2017. http://db-

engines.com/en/ranking/graph+dbms. last access

05/22/2017.

Euler, L. (1736). Solutio problematis ad geome-

triam situs pertinentis. http://eulerarchive.maa.org/

pages/E053.html.

gdt (2017). Gdt. https://www.gdt.guardiacivil.es/. last ac-

cess 05/22/2017.

Godsil, C; Royle, G. (2001). Algebraic graph theory.

Hammer, C. (1981). Higher-order homophonic ciphers.

http://dx.doi.org/10.1080/0161-118191856075.

Hern

andez, M; Mu

noz, A. (2017). Tool grafscan.

https://github.com/grafscan/GraFScaN.

Masscan (2017). Port scanner masscan. https://github.com/

robertdavidgraham/masscan. last access 05/22/2017.

Mehmood, S. (3 May 2016). Enterprise survival guide

for ransomware attacks. https://www.sans.org/

readingroom/whitepapers/incident/enterprise-

survival-guide-ransomwareattacks-36962.

Neo4j (2013). Neo4j 1.9. https://neo4j.com/release-

notes/neo4j-1-9/. last access 05/22/2017.

Neo4j 2.0 (2013). Neo4j 2.0. https://neo4j.com/release-

notes/neo4j-2-0/. last access 05/22/2017.

Neo4j 3.0 (2016). Neo4j 3.0. https://neo4j.com/whats-new-

in-neo4j-3-0/. last access 05/22/2017.

Neo4j conf (2017). Https conﬁguration. https://github.com/

neo4j/neo4j/commit/c9030e5a2efb2c3f43c0f69bebd

67ae67e54a286. last access 05/22/2017.

Neo4j connector (2017). Neo4j connector. https://

github.com/se38/Neo4a. last access 05/22/2017.

Neo4j lic (2017). Neo4j licenses. https://neo4j.com/

licensing/. last access 05/22/2017.

Orientdb (2017). Tutorial about graph-model. http://

orientdb.com/docs/last/Tutorial-Document-and-

graph-model.html. last access 05/22/2017.

OrientDB expo (2017). Orientdb server. http://

orientdb.com/docs/2.2/DB-Server.html.

OrientDB rol (2017). Orientdb security. http://

orientdb.com/docs/2.0/orientdb.wiki/Security.html.

Pauli, D (2017). Mongodb ransom attacks soar, body

count hits 27,000 in hours. https://www.theregister.

co.uk/2017/01/09/mongodb/.

Shodan (2017). The search engine for the web.

https://www.shodan.io/. last access 05/22/2017.

Todd, H. (13 de junio de 2009). Neo4j - a graph database

that kicks buttox. http://highscalability.com/neo4j-

graph-database-kicks-buttox.

Zachary, D. (2015). Big data: Astronomical or ge-

nomical? http://journals.plos.org/plosbiology/article/

ﬁle?id=10.1371.

Zmap (2017). Port scanner zmap. https://zmap.io/. last

access 05/22/2017.

SECRYPT 2017 - 14th International Conference on Security and Cryptography

310
