Evaluating the Quality of the Documentation of

Open Source Software

Lerina Aversano, Daniela Guardabascio and Maria Tortorella

Department of Engineering, University of Sannio, p.za Roma 21, Benevento, Italy

Keywords: Open Source Software, Software Maintenance, Software Reusability, Software Measurement, Software

Metrics, Software Documentation.

Abstract: Software documentation is a basic component of the software development process: from the definition of

the functional requirements to the maintenance phase. Software documentation refers to different types of

documents that facilitates the software developer’s tasks. Then, it includes the textual documentation

required by the Software engineering standards, API documentation, Wiki pages and source code

comments. Surveys and studies indicate that the documentation is not always available and, if available,

only partially addresses the developers' needs, as it is often wrong, incomplete, out-of-date and ambiguous.

This paper focuses on the quality assessment of the documentation of open source systems with the aim of

understanding the support it can offer for adopting them and executing maintenance activities. Specifically,

a quality model is defined and a preliminary investigation of its applicability is performed.

1 INTRODUCTION

Software documentation has a significant relevance

in the software development process from the

definition of the functional requirements to the

maintenance phase (Chomas and Saini, 2015),

(Garousi et al., 2013), (Sommerville, 2005).

Actually, the software is not only documented by

the textual documentation required by the software

engineering standards (IEEE Std 830-1998), (IEEE

Std 1028-2008), (IEEE Std 1063-2001), (ISO/IEC

9126:2001), (ISO/IEC 25010:2005), (ISO/IEC

26514:2008), even if in different formats (e.g.,

Word, pdf, ppt), but it can include additional

documents describing the software artefacts, such as

all the documents produced during the software

development process, and formalized as API

documentation, Wiki pages, and source code

comments.

In the proposed study, the term "software

documentation" is used to refer the various types of

documents indicated above.

The documentation required by the standards

(IEEE Std 830-1998), (IEEE Std 1028-2008), (IEEE

Std 1063-2001), (ISO/IEC 9126:2001), (ISO/IEC

25010:2005), (ISO/IEC 26514:2008) generally

consists of documents aiming to explain the

functionalities the software performs, its

architecture, how it is structured and implemented,

and how it can be used. It includes the following

documents: software requirements specifications,

software design documents, code, quality and testing

documents. Each document is relevant for

understanding the software product. Differently, the

API documentation specifies how software

components can be used and interacts with each

other. Wiki pages allow for web-based visualization

and knowledge management. It offers semantic-

enhanced search facilities such as filtering, faceting,

and graph-like exploration of knowledge. Finally,

software documentation also includes the inline

comments of the source code. Actually, according to

de Souza at al. (Cozzetti de Souza et al., 2005), the

comments help developers to fully understand the

software product.

Several interviews with software engineers and

developers working in organizations have been

performed. The results are enclosed in surveys and

papers, and indicate that the documentation is not

always available and it only partially addresses the

developers' needs, as it is often wrong, incomplete,

out-of-date and ambiguous.

In the case of closed source software, the

requirements are generally clear and well-

documented, as well as the design and testing

308

Aversano, L., Guardabascio, D. and Tortorella, M.

Evaluating the Quality of the Documentation of Open Source Software.

DOI: 10.5220/0006369403080313

In Proceedings of the 12th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2017), pages 308-313

ISBN: 978-989-758-250-9

documents (Satzinger et al., 2000). These does not

happen for open source systems, where these

documents may not exist, or not represent any

official documentation.

This paper focuses on the assessment of the

quality of the various types of documents that may

be useful for understanding a software artefact. In

particular, it is focused on the documentation of the

Open Source Software systems, with the aim of

understanding if it can be a valuable support to

anyone who wants to adopt such a kind of systems

and/or execute maintenance activities.

With this in mind, the paper presents a quality

model and the results of a preliminary investigation

of its applicability.

This paper is organized as follows. Section 2

discusses the principal research work related to the

quality of software documentation. Section 3

describes the proposed model for evaluating the

quality of the documentation of Open Source

Software system. Section 4 presents a case study,

while conclusions are given in Section 5.

2 RELATED WORK

The literature reports several studies focusing on the

evaluation of the usefulness of the documentation of

a software product. Specifically, these studies

discuss the use that software practitioners make of

different kinds of documentations.

Forward and Lethbridge (Forward and

Lethbridge, 2002) made a survey, involving

different developers. They presented several

documentation attributes, such as document writing

style, grammar, level of upgrade, type, format,

visibility, etc. They observed that the documentation

content is an important support for communication

and should always be useful and serve a purpose. It

can be relevant even if it is not updated or

inconsistent. The same authors (Lethbridge et al.,

2003) highlighted the general attitudes regarding the

software engineering documentation. For example,

some results indicated that various types of abstract

documentation are a valid guidance for maintenance

work and that inline comments of the source code

are often a good support to assist detailed

maintenance work. The study also discussed

negative results, such as the fact that multiple types

of documents are often out of date or that the

documentation is poorly written.

de Souza et al. (Cozzetti de Souza et al., 2005)

established in their surveys the importance of each

documentation artefacts, with reference to the full

understanding of the software product and execution

of maintenance activities. The results of this study

have also shown that the documentation is often

incomplete or out-of-date, and the developers have

to use the source code and related comments for

fully understanding the software product.

Another aspect coming from the contribution of

Kipyegen and Korir (Kipyegen and Korir, 2013)

regards the little usage of the documentation, and,

consequently, the decrease of its efficiency during

the software development task.

Several other research works focused on the

documentation quality.

Arthur and Stevens (Arthur and Stevens, 1989)

identified four Document Quality Indicators (DQI)

that are attributed to an appropriate documentation:

Accuracy, Completeness, Usability and

Expandability. As quality is an intangible

characteristic, without direct measure, the authors of

the cited paper associated each quality characteristic

to some factors, and each factor to some quantifiers,

whose combination gave rise to quality indicators

(DQI) that are quantifiable.

In (Plösch et al., 2014), (Wingkvist et al., 2010),

the following additional documentation quality

attributes are proposed: Accuracy, Clarity,

Consistency, Readability, Structuring, and

Understandability. Indeed, from a conducted survey

(Wingkvist et al., 2010), it emerges that the typical

problems related to the documentation quality deals

with unreliable, incomplete or non-existent

documentation, not documented changes in the

software system and lack of integrity and coherence.

The authors developed a tool (Lethbridge et al.,

2003) for analysing the quality of software systems,

documentation included.

Problems related to the documentation quality

have also been encountered by Uddin and Robillard

(Uddin and Robillard, 2015) with reference to the

API documentation quality, and by Diaz-Pace et al.

(Diaz-Pace et al., 2014) with reference to the Wiki

pages.

This paper considers all the aspects arising from

the previous studies and proposes a quality model

for evaluating various types of documentation

associated with an Open Source Software system.

Then, unlike other proposed approaches,

focusing on just one kind of documentation, the

proposed quality model considers multiple types of

document supporting an Open Source Software

system, such as textual standard documentation, API

documentation, Wiki support and in line comments.

Evaluating the Quality of the Documentation of Open Source Software

309

3 QUALITY OF SOFTWARE

DOCUMENTATION

This section proposes an approach to assess and

evaluate the quality of software documentation. The

approach is metric-based and considers different

indicators to be evaluated on the various types of

documentation considered: technical documentation,

user documentation, API, Wiki, and source code

comments. The quality indicators have been

formalized by using a set of Questions, which entail

the evaluation of a set of Metrics. Overall, the

identified quality indicators aim to evaluate:

 to what extent the documentation reflects the

current state of the software system;

 to what extent the documentation is

understandable and well structured.

Tables 1 contains the list of the questions and

related metrics that have been considered. For each

metric the table reports the formula used for its

assessment, the range of values it can assume and its

acceptance threshold, if definable. In particular, the

acceptance thresholds are useful to identify where

the software system documentation needs to be

improved, on the basis of the values of the measured

metrics. The quality indicators considered for the

definition of the metric-based quality model and

reported in Table 1 are the following:

 Completeness: to evaluate the completeness level

of the documentation with reference to the

source code; in particular, these quality

indicators check whether the documentation

describes all of the items (packages, classes,

methods) of the source code.

 Alignment: to verify whether the documentation

is updated with reference to the project release it

refers to.

 Readability: to examine if the sentences express

clear and understandable concepts. The Flesch

readability test (Flesch Reading Ease) was used,

designed to indicate how difficult is to be

understood an English reading. The index score

ranges from 0 to 100 and a value equal to 50 is

considered adequate as it is associated with the

10th to 12th grade school level; while higher

scores indicate material that is easier to read and

lower marks indicate passages that are more

difficult to read (Flesch and Rudolf, 2016).

 Dimension: to analyse if the document sentences

are too long or too short, with the aim of

verifying if text is too difficult to be understood,

or too short for exhaustively expressing a

concept, respectively. Cutts asserted that over the

whole document, average sentence length should

be 15-20 word (Cutts, 2013).

 Graphical Support: to verify the availability of

visual aids (figures and tables) facilitating the

understandability of the text. The citations of the

visual aids within the text and existence of clear

captions are verified. It may occur that figures or

tables not included in the document are indexed,

in this case the score is greater than 1.

 Consistency to Standard: to verify if the

available documentation is compliant to the

Software Engineering Standards: Software

Requirement specification, Software Design

documents, Code system documentation, Test

plans, and so on.

 Structure: regarding the textual documentation

and aiming at evaluating its actual structure in

terms of number of chapters, sections, sub-

sections nesting, document length, and density of

tables and figures. A good structure and

organization of the document helps to consult it.

 Easy to use: concerning API and Wiki and

assessing the organization from a usability point

of view. Aspects that will be investigated are the

fragmentation of the concepts within web pages,

and the size of the Java Doc and Wiki.



Appropriateness comments: estimating the

density of comments in the code. A high density

of comments helps the developer in the

comprehension of source code.

Most of the metrics included in the model can be

evaluated with reference to the API, Wiki, code

comments and documentation. While Graphical

Support and Consistency to Standard are evaluated

just with reference to Documentation. Easy to use is

evaluated with reference to Wiki and JavaDoc;

finally, the Appropriateness of the comments is

evaluated with reference to the code comments.

The evaluation of these metrics requires the

application of NLP, Information Extraction and

Information Retrieval techniques in order to make an

objective analysis and not a subjective one. Table 1

shows the metrics considered for the different types

of documentation. The index I indicates in which set

of documents refers analysis, while index E refers to

what visual aid it is evaluated (figure or table).

4 CASE STUDY

This section described the study conducted to verify

the applicability of the proposed metrics-based

approach. In particular, the approach has been used

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

310

Table 1: Metrics adopted for evaluating the quality of documentation.

QUESTION METRIC

Id Name Id Formulas Values

metrics

Acceptance

threshold

Q1 What is the

completeness level

of documentation

with reference to

the source code?

M1.I







      





WithI

∈

{API,Wiki,Comments,Documentation}

[0..1]

0.6

Q2 Is the available

documentation

updated with the

considered release?

M2.I





WithI

∈

{API,Wiki,Comments,Documentation}

{yes, not}

Yes

Q3 What is the level of

readability of the

documentation?

M3.I





WithI

∈

{API,Wiki,Comments,Documentation}

[0..100]

50.0

Q4 What is the medium

sentences

dimension?

M4.I





WithI

∈

{API,Wiki,Comments,Documentation}

Natural

number

[15..20]

If present, the

Figures and the

Tables are

appropriately

indexed? Have they

a Legend?

M5.1.E







WithE

∈

{Figure,Table}

Natural

number

M5.2.E









# 

 

WithE

∈

{Figure,Table}

[0..1]

0.6

M5.3.E





















WithE

∈

{Figure,Table}

[0..1]

0.6

Q6 Is the

documentation

organized in

accordance to the

standards?

M6.I







#

#   

[0..1]

0.6

Is the

documentation well

structured?

M7.1









Natural

number

M7.2







#

#

[0..1]

0.6

M7.3





Natural

number

M7.4.E





















WithE

∈

{Figure,Table}

[0..1]

0.6

Is the

documentation easy

to use?

M8.1















[0..1]

0.6

M8.2

 

#

 

{0,1,..}

0.8

M8.3

  # 

Natural

number

M8.4



Natural

number

Q9 Is the code

appropriately

commented?

M9.1

 

#

  

[0..1]

0.15

to measure the quality of the documentation of an

open source software system, namely, OpenNMS.

OpenNMS (www.opennms.org) is an enterprise

network management application platform

developed under the Open Source model. This

Project started in July of 1999 and was registered on

SourceForge in March of 2000. It evolved over

seventeen different releases. Currently it includes

more than 700 packages.

Table 2 reports the results of the evaluation of

the documentation of OpenNMS. A subset of these

metrics have been manually computed, such as

ChapterTreeDept or DocumentationSize, other with

Evaluating the Quality of the Documentation of Open Source Software

311

the support of Python scripts, such as Consistency of

API and Code Comments.

Table 2: Metrics evaluation of OpenNMS.

Id N

AME Formulas

M1.D Completeness

M1.A Completeness

0.62

M1.W Completeness

M1.C Completeness

0.29

M2.D Updating

Yes

M2.A Updating

Yes

M2.W Updating

Wiki

Yes

M2.C Updating

Yes

M3.D FleschReadabilityIndex

43.55

M3.A FleschReadabilityIndex

49.48

M3.W FleschReadabilityIndex

58.47

M3.C FleschReadabilityIndex

53.85

M4.D MediumSentenceLenght

12.72 words

M4.A MediumSentenceLenght

7.7 words

M4.W MediumSentenceLenght

16.73 words

M4.C MediumSentenceLenght

8.03 words

M5.1.F Number

D-F

56 figures

M5.1.T Number

D-T

286 Tables

M5.2.F Indexing

D-F

0.0

M5.2.T Indexing

D-F

0.0

M5.3.F Legend

D-F

0.71

M5.3.T Legend

D-T

0.33

M6.I ConsistencySt

0.20

M7.1 DocumentSize

405 pages

M7.2 AverageSizeCP

11.57 pp/cap

M7.3 ChapterTreeDept

3 sections

M7.4.F Density

D-F

0.14

M7.4.T Density

D-T

0.71

M8.1 InfoFragmention

0.20

M8.2 JavaDocDensity 0.19

M8.3 WikiSize 2825

M8.4



5 subsections

M9.1 CommentDensity 0.14

The first indication emerging from the

assessment of Question Q1 is that not all the

packages and classes in the source code are referred

in the API (M1.A), and not all the classes and

methods in Source Code are commented (M1.C),

indeed both these values are less than one. While

Wiki and Documentation have not references to the

Source Code, then their Completeness (M1.W,

M1.D) is equal to 0.

From the assessment of Question Q2, it emerges

that the documentation is updated with reference to

the source code. This means that the analysed

documentation, API, Wiki and inline comments was

aligned with the source code.

The evaluation of Question Q3 indicates that the

Documentation (M3.D) and API (M3.A) are difficult

to read, and that even the medium sentences length

is excessively long (M4.A and M 4.D). Readability

of Comments inline of source Code (M3.C) and

Readability of Wiki (M3.W) are fairly difficult to be

read. Indeed, these metrics assume a value very

closed to the thresholds.

Instead, the evaluation of Question Q5 indicates

that the documentation includes some figures with

clear captions (M5.1.F= 56 figures, M5.3.F = 0.71),

while the documentation includes a lot of Tables, but

many of them do not have an adequate caption

(M5.1.T = 286 tables, M5.3.F = 0.33), or they are

not adequately indexed (M5.2.F = 0, M5.2.T = 0).

With reference to the assessment of Question Q6,

it is possible to observe that the available

documentation is not consistent with the standards.

In fact, the documentation includes just one kind of

document foreseen in the standards (M6 = 0.20).

With reference to the assessment of Question Q7,

it is possible to observe that the number of pages of

the documentation is equal to 405 (M7.1), but the

documentation analysed includes four documents:

administrators guide (264 pages), developers guide

(79 pages), installation guide (30 pages), users guide

(32 pages). The average length of a chapter is 11.57

pages (M7.2), and the tree depth of each chapter is 3

(M7.3).

In addition, Figure density does not achieve a

high value as just 56 figures are included in 405

pages (M7.4.F = 0.13); the reverse can be observed

for the Table density as 286 tables are present in 405

pages (M7.4.T = 0.70).

With reference to the assessment of Question Q8,

it is possible to observe that the Info Fragmentation

does not achieve a high value, then each information

is distributed among few pages (M8.1 = 0.20).

Regarding JavaDocDensity, about 18 classes are

described in one JavaDoc MB indicating that even

the Java doc density (M8.2 = 0.18) assumes low

values. The size of the Wiki is fairly high (M8.4 =

2825), and has a navigation tree equal to 5 (M8.3 =

5).

Finally, density of comments in the code is fairly

low (M9.1 = 0.14), indicating that the code is few

commented.

From the obtained results, it can be deduced that

the documentation of the reporting software system

must be improved. In particular, it can be observed

that; the readability needs to be improved; more

documents requested by Software Engineering

Standards must be included; the comments should be

increased within the source code; the API should be

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

312

aligned to the source code; and Figures and Tables

should be indexed.

5 CONCLUSION

This paper proposed a metric-based quality model

for the assessment of the quality of the

documentation of Open Source Software systems. In

particular, the proposed model includes the

specification of a set of metrics to be measured. It

refers to a wide concept of documentation that

considers the various type of documentation that

facilitates the software developer’s tasks, such as

textual documentation required by the Software

engineering standards, API documentation, Wiki

pages and source code comments.

A preliminary investigation of its applicability

of the proposed quality model has been performed

by considering an Open Source Software systems,

OpenNMS.

Future work will consider a refinement of the

quality model with the introduction of additional

needed metrics considering grammatical correctness

of documentation, ambiguity of the text, duplication

of arguments and the analysis of more case studies.

Indeed, a larger base of software systems should be

measured to increase the practical relevance of the

achieved results.

REFERENCES

Arthur, J.D., Stevens, K. T., 1989, Assessing the adequacy

of documentation through document quality

indicators. Conference on Software Maintenance,

IEEE comp. soc. press, pp. 40-49.

Briand, L. C., 2003. Software documentation: how much

is enough? Software Maintenance and Reengineering,

Seventh European Conference. IEEE comp. soc.

press., pp. 13-15.

Chomas, V. S., Saini, J. R., 2015, Software Template for

Evaluating and Scoring Software Project

Documentations. Int. Journal of Computer

Applications, 116(1).

Cozzetti de Souza, S., Anquetil, N., de Oliveira, K.M.,

2005. A Study of the Documentation Essential to

Software Maintenance. 23rd Annual Int. Conference

on Design of communication: documenting &

designing for pervasive (SIGDOC '05), ACM press,

pp.68-75.

Cutts, M., 2013. Oxford guide to plain English. OUP

Oxford.

Dautovic A., Plösch, R., Saft, M., 2011. Automated

quality defect detection in software development

documents. First Int. Workshop on Model-Driven

Software Migration (MDSM 2011).

Diaz-Pace, J.A., Nicoletti, M., Schettino, S., Grisando, R.,

2014. A recommender system for technical software

documentation in Wikis. Biennial Congress of

Argentina (ARGENCON), IEEE comp. soc. press, pp.

393-398.

Garousi, G., Garousi, V., Moussavi, M., Ruhe G., Smith,

B., 2013. Evaluating usage and quality of technical

software documentation: an empirical study. 17th Int.

Conference on Evaluation and Assessment in Software

Engineering (EASE). ACM, pp. 24-35.

Flesch, R., 2016. How to Write Plain English. University

of Canterbury.

Forward, A., Lethbridge, T. C., 2002. The relevance of

software documentation, tools and technologies: a

survey. Symposium on Document engineering, ACM

press, pp. 26-33.

Kipyegen, N. J., Korir, W. P. K., 2013. Importance of

Software Documentation. IJCSI Int. Journal of

Computer Science, 10(5), pp.1694-0784

IEEE Std 830-1998. 1998. IEEE Recommended Practice

for Software Requirements Specifications.

IEEE Std 1028-2008. 2008. IEEE Standard for Software

Reviews and Audits.

IEEE Std 1063-2001. 2001. IEEE Standard for Software

User Documentation.

ISO/IEC 9126:2001. 2001. Software engineering –

Product quality. 

ISO/IEC 25010:2005. 2005. Software engineering –

Software product Quality Requirements and

Evaluation (SquaRE).

ISO/IEC 26514:2008. 2008. Systems and software

engineering - Requirements for designers and

developers of user documentation.

Lethbridge, T. C., Singer, J., Forward, A., 2003. How

software engineers use documentation: The state of the

practice. IEEE Software, 20(6), pp. 35-39.

Plösch, R., Dautovic, A., Saft, M., 2014, The Value of

Software Documentation Quality. 14th Int. Conference

on Quality Software. IEEE comp. soc. press, pp. 333-

342.

Satzinger, J. W., Jackson, R. B., Burd, S. D., 2000. System

Analysis and Design in a Changing World , Thomson

Learning.

Sommerville I, 2005. Software Documentation. Software

Engineering, Volume 2: The Supporting Process, pp.

143-154.

Uddin, G., Robillard, M. P., 2015. How API

documentation fails. IEEE Software, 32(4), pp. 68-75.

Wingkvist, A., Ericsson, M., Lucke, R., Lowe, W., 2010.

A metrics-based approach to technical documentation

quality. 7th Int. Conference on the Quality of

Information and Communications Technology

(QUATIC). IEEE comp. soc. press, pp. 476-481.

Evaluating the Quality of the Documentation of Open Source Software

313
