Graph Databases: Neo4j Analysis

José Guia

, Valéria Gonçalves Soares

and Jorge Bernardino

1,3

ISEC, Polytechnic of Coimbra, Rua Pedro Nunes, Coimbra, Portugal

Informatics Centre, Federal University of Paraiba, Brazil

CISUC - Centre for Informatics and Systems of the University of Coimbra, Portugal

Keywords: Graph Databases, NoSQL Databases, Neo4j.

Abstract: The volume of data is growing at an increasing rate. This growth is both in size and in connectivity, where

connectivity refers to the increasing presence of relationships between data. Social networks such as

Facebook and Twitter store and process petabytes of data each day. Graph databases have gained renewed

interest in the last years, due to their applications in areas such as the Semantic Web and Social Network

Analysis. Graph databases provide an effective and efficient solution to data storage and querying data in

these scenarios, where data is rich in relationships. In this paper, it is analyzed the fundamental points of

graph databases, showing their main characteristics and advantages. We study Neo4j, the top graph database

software in the market and evaluate its performance using the Social Network Benchmark (SNB).

1 INTRODUCTION

Relational databases are good at managing

transactional data and are still prevalent in data

storage. However, with the recent growth of

applications rich in relationships (e.g., social

networks), graphs are becoming the preferred choice

as the data model for representing and storing this

new type of data. Current platforms must deal with

huge amounts of data and the growth of

interconnected information (Lourenço et al., 2015a).

In the last years, a new database family, the NoSQL

model (Deka, 2015; Abramova et al., 2014a, 2014b),

has gained widespread popularity, especially

because of the need to deal with huge volumes of

data connected to each other, to store and to recover

them effectively (Lourenço et al., 2015b). So, a

special type of NoSQL database arises that fits this

paradigm: the graph databases (Larriba-Pey et al.,

2014).

Graph databases are a type of non-relational

databases that provide an effective and efficient

solution for the information storage in the current

context, where data are very strongly interconnected.

Graph databases can be defined as databases that use

graph structures with nodes, edges and properties to

store data (Wang et al., 2015).

The interest in graph models has been increasing

in the last few years, due to their applications in

areas like the Semantic Web and the Analysis of

Social Networks (Dietrich et al., 2014). The main

advantage is the lightning-fast access to complex

data, founded per example in social networks,

recommendations engines, data mining operations

and network systems.

This type of database is too easy to understand

because its concept is based on graph theory. This

theory is based on graphs (Rodriguez et al., 2010),

which are mathematical structures used to model

relations between objects. In this context, a graph is

a structure organized by nodes, also called vertices

(the entities), by edges (the relations) represented by

the lines that connect the various nodes and by

properties that represent the information related to

the nodes and/or with the edges. Therefore, the

graph databases can be described simply as a way to

represent and store data using their structures: nodes,

edges and properties. The simplicity of the storage

representation in their structures and quick access to

data make graph databases, a very practical database

type to use and manage. The graph databases are

optimized to store and query graph structures.

The problem of graph databases is that

sometimes they are not particularly effective in all

desired operations, for example, data representation

from the relational models. They are not a general

Guia, J., Soares, V. and Bernardino, J.

Graph Databases: Neo4j Analysis.

DOI: 10.5220/0006356003510356

In Proceedings of the 19th International Conference on Enterprise Information Systems (ICEIS 2017) - Volume 1, pages 351-356

ISBN: 978-989-758-247-9

351

replacement for relational databases, but are in fact

an efficient solution when dealing with huge

volumes of data that contain interconnected data.

The focus of this paper is the study of the

characteristics of graph databases, referring to its

advantages, and the evaluation of the most popular

graph database: Neo4j.

This paper is structured as follows: Section 2

describes the advantages and use cases of graph

databases. Section 3 describes the main

characteristics of the Neo4j database. Section 4

present Social Network Benchmark (SNB). Section

5 presents the experimental evaluation of Neo4j.

Finally, Section 6 presents the main conclusions

drawn from this study, as well as proposals for

possible future work in this topic.

2 MAIN ADVANTAGES AND

USES OF GRAPH DATABASES

Graph databases are effective for several industries

from telecommunications to financial services,

logistics, hospitality, and healthcare. Graph

databases are essential in main areas, such as

analysis of behavior in social networks, data

management, and census-related studies. According

to Forrester Research, graph databases is the fastest

growing category in database management systems

and will reach more than 25 percent of enterprises

by 2017. Following, we describe the main

characteristics and advantages of a graph database

(Robinson et al., 2013):

 Information search far more

optimized than compared to relational

databases, since it takes advantage of the

proximity data from one or more root (main

nodes) of the graph database.

 Quite intuitive, due to their natural

form of information representation - the

graphs.

 Support the data storage in the order

of petabytes (10

 They are very agile in development

since they can be easily adapted over time,

either in the insert or in the deletion of

information.

 Allow new types of data.

 Suitable for data connected to each

other, usually involved in real-world cases.

 Optimized for data

mining operations.

 High performance in terms

of querying very deep searches when

compared to relational databases.

For example, Walmart and eBay adopt a graph

database to understand the behavior and preferences

of online buyers with adequate speed and enough

depth to make real-time and personalized

recommendations (Retail Technology, 2016). By

using a graph database, these companies can connect

rapidly masses of complex buyer and product data to

gain insight into customer needs and product trends.

3 Neo4J ANALYSYS

Neo4j is considered the reference software in this

area (Predictive Analytics Today, 2016), and it is

one of the most used graph databases in areas such

as health, government, automotive production,

military area, among others.

Neo4j is an open-source graph database

implemented in Java. The founders of Neo4j

describe it as a fully transactional database, a

persistent Java engine where it is possible to store

structures in the form of graphs instead of tables

(Webber, 2012). The Neo4j is considered the most

popular and used graph database worldwide, the

largest reference area and this is our choice due to

this general recognition (Predictive Analytics Today,

2016).

This software was first released in 2007, and is

divided into three broad categories: Community,

Government, and Enterprise. The Community

Edition is the trial version, which is basically the

version that any user can test. The Enterprise

Edition, where there is the possibility of testing a

more complete version than the Community for 30

days. It is therefore the commercial version of this

software, and there is still the Government Edition,

which is like an upgrade to the Enterprise version.

This release is highly focused on government

services. The major differences between the two

main versions of Neo4j (Community and Enterprise)

are: the existence of online backup, high

performance level of memory cache, detailed

monitoring system, strong managing of locks on the

database, and the greater database scalability, among

other advantages of Enterprise Edition.

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

352

3.1 Neo4j Main Features

The main advantages of Neo4j are (Bruggen, 2015):

 Horizontal scalability (in the

Enterprise version) - allows easily adding

more nodes to the system. In the

Community version, the scalability is

vertical.

 Neo4j has its own language, created

by the company for its query methods -

Cypher language. It is through this

language that we can handle all the

information of graph database.

 The storage is disk- based - through

proprietary file systems.

 Its integrity is ACID guaranteed.

 It has a very intuitive and very

accessible interface.

In Neo4j interface (see Figure 1) we can see

a graph database in the central image menu – and

the graph with multiple nodes, the various

properties, and the edges that make up the graph

database. On the left side of the interface, we can

see the name of the nodes, the edges, the attributes

and the version of the program. We can also access

through an option on interface, visualize the size of

the disk graph database, follow various program

tutorials, and access the specific settings of the

program, among other options. In the center, above

the graph database, we can find a place to write

queries in Cypher language.

Figure 1: Neo4j interface (source: http://neo4j.com).

3.2 Query Methods

The query methods in Neo4j are written in Cypher

language that is the query language created by Neo

Technology (Vukotic et al., 2014).

The Cypher language allows an expressive and

efficient query execution and update of graph

database. It is a relatively simple language, but very

powerful. Very complex queries running in a

relational database can be easily executed in Cypher.

This allows users to focus on your domain instead of

getting lost in database access.

With this query language, we can delete/

insert/create, the basic elements such as nodes,

edges/relations and properties. For example, the

code to create a node with a name is:

CREATE (n: Person);

This code creates a node n, named Person,

using the CREATE command.

4 SOCIAL NETWORK

BENCHMARK (SNB)

In the experimental evaluation, it is used the Social

Network Benchmark (SNB), created by LDBC

(Erling et al., 2015). The SNB models a social

network like Facebook. The dataset consists of

people connected each other in a network

relationship, where most of the data relates to

messages that people post in various forums.

To accomplish the tests, we generated two large

data sets. Then we show the settings used for the

different tests in generating data on SNB. The

modified parameters were: scaleFator (which is the

scale factor of the data to be generated);

the serializer (which is the format that the generated

files out - supports the following: .csv, .ttl,

.csv_merge_foreign); the compressed (that specifies

whether the generated files must be compressed or

not); the numThreads (which is the number of

threads to use); updateStreams (option for

DATAGEN generate streams updated to use)

and outputDir (which is the location where the files

to be generated will be stored on disk). Following

we describe the two datasets that were generated

with in the SNB. Besides the datasets, we also will

describe the time to generate these files on the SNB.

In the first test, we generated one dataset with

about 1.2 GB of data (Dataset 1). This test takes 11

minutes and 54 seconds. In the second test, we

generated one dataset with about 11.6 GB of data

(Dataset 2). This test takes 1 hour, 52 minutes and

26 seconds.

The two generated datasets have eight main

entities, along with four other entities that are as

subclasses of the main entities. Relations connect

existing entities. The Tail and Head entities should

Graph Databases: Neo4j Analysis

353

be understood as the entities connected between

connection(s), and one is the end of the call and the

other is the start of the relationship, respectively.

Therefore, the relationship is oriented.

5 EXPERIMENTAL

EVALUATION

The experimental evaluation analyzes the Neo4j

behavior with different sizes of datasets, presenting

their load times and showing the performance using

SNB queries.

The experiment was executed with the following

configuration:

- Operating System: Windows 8.1 - 64bit;

- Processor: Intel (R) Core (TM) i7-3630QM

CPU @ 2.40GHz.

The tests were executed in order to load the two

datasets generated by the SNB - upload them one by

one to the Neo4j, then in each of the datasets loaded,

we run the queries test. Each dataset has 33 .csv files

- that are representative files of entities and

relationships between these entities. Two types of

tests were made with Neo4j. The first assessed the

load time of the two datasets created by the SNB, as

mentioned above. After that, we evaluate the

performance of Neo4J executing the SNB

benchmark queries.

5.1 Loading Time in Neo4j

In this step, we uploaded the files generated in the

SNB in the Dataset 1 that initially had 1.2 gigabytes

of data. At the end of loading, the original data,

which were generated by the SNB, increased from

1.2 gigabytes to 5.4 gigabytes in Neo4j when "built"

in graph database. This variation corresponds to an

overhead of 4.5 times compared to the original size,

so there was an increase of around 450%. The total

loading time of these files was 5h:12m: 24,81s.

In the second test, we load the files generated in

the Dataset 2 that has about 11.6 gigabytes of data.

The data that were generated by the SNB increased

from 11.6 gigabytes to 52.35 gigabytes in Neo4j. A

growth of about 451% compared to the size of the

files generated SNB. It is important to note that

during the loading time, the system blocked, and we

had to start it again, increasing the total final

time. The total loading time of this dataset was

160h: 28m: 4,74s.

In summary, we can say that relatively to the

Dataset 1, the Dataset 2 took much longer to load all

the files to the Neo4j. It went up for five hours in the

first dataset for approximately 160 hours in the

second dataset. This corresponds to an overhead of

about more 32 times to complete the load of all

files. This situation occurs because the volume of

data has increased considerably in the second

dataset.

5.2 Query Example

After completion of the Cypher language commands

to load the entities and relationships, we execute the

SNB queries in the two datasets, to assess the

runtimes. For example, Query 13, which will look

for people who know each other, traversing the

shortest possible route in the graph database. It

returns the length of this path taken in the search,

and the code in Cypher is:

MATCH (p1: Person), (p2: Person)

OPTIONAL MATCH shortestPath path =

((p1) - [: KNOWS] - (p2))

RETURN path CASE IS NULL

WHEN THEN true -1

ELSE length (path)

END THE pathlength

We execute the 14 queries of the SNB's

manual. It is through this type of test queries for data

query the database graph that makes assessments

such as the time it takes to query the data in the

graph database (from:

https://github.com/ldbc/ldbc_snb_docs).

Our tests were based on exactly the time that

these queries are executed to return the desired

results. In the next section we show the results in the

evaluations using Neo4j and the two datasets

generated by SNB benchmark.

5.3 SNB Queries Execution Time

In this section, we present the results of executing

the 14 queries of the SNB benchmark using the two

datasets. We execute all the queries four times and

take the average of last three runs to eliminate cold-

start.

We executed the 14 test queries in the Dataset 1,

(when coming from SNB it had 1.2GB and then

when it was built in the graph database Neo4j, it

increases to 5.4 GB) and obtained the results shown

in Table 1.

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

354

Table 1: SNB queries execution time of Dataset 1.

QueriesTest

Execution

time(s)

QUERY1 19,27

QUERY2 5,454

QUERY3 41,221

QUERY4 1,321

QUERY5 23,720

QUERY6 42,973

QUERY7 8,037

QUERY8 3,276

QUERY9 12,169

QUERY10 22,493

QUERY11 0,270

QUERY12 2,717

QUERY13 50,328

QUERY14 68,398

Total 5m1,65s

It is noticed that Queries 6, 13 and 14 are the

ones that took longer to perform, as they require

more processing. This is due to the code they

contain and calculations they have to make to the

graph database. For example, calculations of shorter

paths between certain nodes and entities. From

Table 1, the average execution time of Dataset 1 was

5 minutes and 1.65 seconds.

After that, we run the same 14 queries test in

Dataset 2 (when coming from SNB had 11.6GB and

then when it was built in graph database in Neo4j, it

increases to 52.35 GB). The results obtained are

shown in Table 2.

Table 2: SNB queries execution time of Dataset 2.

QueriesTest

Execution

time(s)

QUERY1 80,765

QUERY2 92,978

QUERY3 117,483

QUERY4 18,04

QUERY5 60,95

QUERY6 119,174

QUERY7 54,926

QUERY8 49,927

QUERY9 56,172

QUERY10 70,153

QUERY11 22,512

QUERY12 23,001

QUERY13 122,408

QUERY14 129,338

Total 16m57,83s

As previously observed with Dataset 1, the

queries 6, 13 and 14 are the ones that took longer to

run. The reason is because are the queries which

have more calculations in the graph database. It was

also found that in the Dataset 2, queries 2, 4, 7, 8, 11

and 12 were the queries that were executed in

seconds. Although they take more time to search,

comparing the times shown in the Dataset 1, but it is

normal given the size that the graph database, which

is about 52 gigabytes of data.

As we can see in Table 2, the total execution

time for the 14 queries using the Dataset 2, is 16

minutes and 57.83 seconds.

6 CONCLUSIONS AND FUTURE

WORK

The concept of non- relational databases has been

growing in popularity and usability. The NoSQL

databases bring advantages over the previously

established databases, such as the manipulation of

huge volumes of connected data. The NoSQL

databases are divided into different models, each

model with a set of features and enhancements

(Abramova et al., 2015). Our study focused on only

graph databases.

Our analysis allows to conclude that there are

three very similar databases and with very similar

characteristics, but still Neo4j stands out for its

simplicity, despite the need to have prior knowledge

of the Cypher language to create and manage any

information in graph databases of Neo4j. Its

interface also makes Neo4j one graph database

reference for its accessibility. Our assessment allows

to say that the software more robust and more

practical is the Neo4j.

The experimental evaluation considered the

performance of the data loads Neo4j to form a graph

database, as well as testing the performance in terms

of certain databases searches to those previously

created graph. Accordingly, we tested the different

times of loading the files, which were generated in

the benchmark, and the different runtimes of created

surveys conducted to graph databases. With this

analysis, we can get the knowledge of how the

Neo4j handles loading external data to the software

along with the understanding of how the software

behaves the level of performance when it has to

consult certain information in a database. The results

showed that the Neo4j, is a powerful tool, and

according to the tests performed, we concluded that

the software has a fairly acceptable behavior when

dealing with different sizes of graph databases, as in

our case, the various datasets we tested. We note that

Graph Databases: Neo4j Analysis

355

where the software loses much time is on loading the

files to the Neo4j, getting later in graph format. The

data presented the first dataset (with 1.2GB) showed

speed in loading files, since they did not have any

file with more than 800MB to be loaded. In the case

of the second dataset, which was lost over time,

since there was files being uploaded that took almost

one day to be completely loaded into the Neo4j. We

can therefore say that the software has a great

behavior in loading files, with up to a size of 700 to

800MB, because above this value, it is time

consuming this process, as we proved with the

Dataset 2. Another important aspect that also tested

it was performance-level searches.

Using the test queries withdrawn in SNB

benchmark, one can see that in the two datasets

where it loses more time is in the information query

in the initial execution. It happens because the graph

database leverages one of its main features that is the

storage engine, that is optimized due to the fact that

it stores adjacent registers by direct references, thus

making access to quickly plays data in the next

executions.

It is normal for the amount of information that

has to go through that in a graph database with a

huge volume of data to take longer in a given query

test that a graph database with little information

running the same query test and that this present

almost immediately the respective output. One

drawback encountered in Neo4j is their instability

when it has to deal with a large volume of data, if

the Dataset 2 (which in order to be all loaded, it

became to the size of approximately 52GB) blocking

often the system and causing the restart to load the

data.. We cannot be sure if this issue was related to

the Neo4j, or with any restrictions the hardware and

also software of the machine where the tests were

performed.

As future work, we intend to analyze the loading

of files and query times in other graph databases.

REFERENCES

A. Vukotic, N. Watt, T. Abedrabbo, D. Fox, J. Partner,

2014, “Neo4j in Action”, Book Neo4j in Action, 2014.

G. C. Deka, 2015, “Tutorial on NoSQL Databases”,

Mobile Cloud Computing, Services, and Engineering

(MobileCloud) IEEE International Conference, San

Francisco, USA, April 2015.

I. Robinson, J. Webber and E. Eifrem. Graph Databases.

O‟Reilly Media Inc., California, 2013

J. Dietrich, N. Jones and J. Wright, 2008, “Using social

networking and semantic web technology in software

engineering – Use cases, patterns and a case study”,

Massey University, Institute of Information Sciences

and Technology, Palmerston North, New Zealand,

January 2008.

J. L Larriba-Pey, N. Martínez-Bazán, D. Domínguez-Sal,

2014, “Introduction to Graph Databases”, Reasoning

Web. Reasoning on the Web in the Big Data Era

Volume 8714 of the series Lecture Notes in Computer

Science pp 171-194, 2014.

J. R. Lourenço, V. Abramova, M. Vieira, B. Cabral, J.

Bernardino, “Nosql databases: A software engineering

perspective”, New Contributions in Inform. Systems

and Technologies, Springer, pp.741-750, 2015.

J. R. Lourenço, B. Cabral, P. Carreiro, M. Vieira, J.

Bernardino, “Choosing the right NoSQL database for

the job: a quality attribute evaluation”, Journal of Big

Data, Vol 2: 18, 2015.

J. Webber, 2012, “A programmatic introduction to

Neo4j”, SPLASH’12, pages 217-218, ACM New

York, USA, 2012.

M. A. Rodriguez, Neubauer, P., 2010, “Constructions

from Dots and Lines” Bulletin of the American

Society for Information Science and Technology,

American Society for Information Science and

Technology, volume 36, number 6, pages 35-41,

August 2010.

O. Erling, A. Averbuch, J. Larriba-Pey, H. Chafi, A.

Gubichev, A. Prat, M. Pham, and P. Boncz. The

LDBC Social Network Benchmark: Interactive

Workload. In Proceedings of the 2015 ACM SIGMOD

International Conference on Management of Data

(SIGMOD '15). ACM, New York, NY, USA, 619-630.

Predictive Analytics Today, 2016, “Top 31 Graph

Databases”, http://www.predictiveanalyticstoday.com

/top-graph-databases/, accessed on 29

November,

2016

Retail Technology, “Walmart and eBay adopt graph

database “http://www.retailtechnology.co.uk/item.php

?news_id=5187, accessed on 23-11-2016

Rik Van Bruggen, 2015, Learning Neo4j, Packt

Publishing.

Shao-Ting Wang, Jennifer Jin, Pete Rivett, and Atsushi

Kitazawa, “Technical Survey Graph Databases and

Applications”, International Journal of Semantic

Computing 2015 09:04, 523-545

V. Abramova, J. Bernardino, P. Furtado, “Experimental

evaluation of NoSQL databases”, International Journal

of Database Management Systems, Vol 6 (3), 2014.

V. Abramova, J. Bernardino, P. Furtado “Testing Cloud

Benchmark Scalability with Cassandra”, 2014 IEEE

World Congress on Services, pp. 434-441.

V. Abramova, J. Bernardino, P. Furtado, “SQL or

NoSQL? Performance and scalability evaluation”,

International Journal of Business Process Integration

and Management, Vol 7 (4), pp. 314-321, 2015.

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

356
