An Exploration of the ‘It’ in ‘It Depends’:

Generative versus Interpretive Model-Driven Development

Michiel Overeem

and Slinger Jansen

Department Architecture and Innovation, AFAS Software, Leusden, The Netherlands

Department of Information and Computing Sciences, Utrecht University, Utrecht, The Netherlands

Keywords:

Model-Driven Development, Model-Driven Architecture, Software Architecture, Code Generation, Run-time

Model Interpretation, Decision Support Making.

Abstract:

Software producing organizations are increasingly using model driven development platforms to improve soft-

ware quality and developer productivity. Software architects, however, need to decide whether the platform

generates code (that might be compiled) or if the model is immediately interpreted by an interpreter embedded

in the application. Presently, there is no clear guidance that enables architects to decide for code generation,

interpretation, or a hybrid approach. Although the approaches are functionally equivalent, they have different

quality characteristics. An exploration is done on the quality characteristics of code generation versus inter-

pretation as a model execution approach. A literature study is done to gather quantitative data on the quality

characteristics of the two model execution approaches. The results of this study are matched with observa-

tions made during a case study. With the resulting support method architects of model driven development

platforms can avoid costly wrong choices in the development of a model driven development platform.

1 INTRODUCTION

Software producing organizations (SPOs) are using

model driven development (MDD) platforms to im-

prove software quality and developer productivity as

described by (D

ıaz et al., 2014). The promise of

MDD is an increase of velocity for a development

team, tooling for non-technical employees to spec-

ify functionality and intent, and provable correctness

of an application. According to (Hailpern and Tarr,

2006) this is achieved by raising the abstraction level

at which developers work. However, implementing

MDD in a SPO is not trivial. A model that is trans-

formed into running software sounds as a major step

forward, but how and when is this transformation

done? Some implementations use code generation,

others use run-time interpretation, but which one is

better? In line with (Voelter, 2009), who calls this

transformation the execution of the model, this paper

uses the term model execution approach: the model is

executed to obtain the software that conforms to the

model.

Different authors such as (Batouta et al., 2015),

(Smolik and Vitkovsky, 2012), (Tankovic, nown), and

∗

This is an AMUSE paper. See https://amuse-

project.org for more information.

(Voelter, 2009) have described possible model execu-

tion approaches and how they should be implemented.

It is clear that trade-offs have to be made. No one

should expect that the model execution approach for

one project is suitable for another project, without ex-

ploring the trade-offs ﬁrst. Developers have to ﬁnd

the balance, and the answer remains “it depends”.

One can be tempted to regard this as a mere im-

plementation detail and misuse quotes like “any good

software engineer will tell you that a compiler and

an interpreter are interchangeable”

and “interpreters

and generators are functionally equivalent” as stated

by (Stahl et al., 2006). However, that would miss the

point of this discussion: the different model execu-

tion approaches will give the same functionality, but

not with the same level of quality. Although (Stahl

et al., 2006) give a rule of thumb by saying that code

generation is more useful for structural aspects, while

interpretation is better suited for behavioral aspects,

this paper shows that there is more to say about the de-

sign of a ﬁtting model execution approach. The chal-

lenge for SPOs is to implement the model execution

approach in such a manner that their required qual-

Tim Berners-Lee in an interview with editor Brian

Runciman - http://www.bcs.org/content/ConWebDoc/3337

100

Overeem M. and Jansen S.

An Exploration of the â

AŸItâ

Z in â

AŸIt Dependsâ

Z: Generative versus Interpretive Model-Driven Development.

DOI: 10.5220/0006191201000111

In Proceedings of the 5th International Conference on Model-Driven Engineering and Software Development (MODELSWARD 2017), pages 100-111

ISBN: 978-989-758-210-3

ity attributes of the system are satisﬁed with the least

amount of effort. Although the model execution ap-

proaches are functionally equivalent and an end-user

will not see the difference the quality of the system

depends on this part as well. Interpretation for in-

stance can negatively affect the run-time performance

as explained in Section 3. Code generation on the

other hand gives ample opportunity for optimization

of the resulting application.

This paper deals with the foundational question of

whether to generate running software or interpret the

model at run-time. The context of this research is a

large scale MDD platform in development at AFAS

Software, a SPO in The Netherlands. The model ex-

ecution approach is part of this platform, and the de-

sign of this approach is the motive of this research.

The decision-making process is explored by answer-

ing two questions: How does the choice between gen-

erative and interpretive MDD inﬂuence the quality of

a MDD platform? and How can SPOs design the most

ﬁtting model execution approach based on the quality

characteristics for generative and interpretive MDD?

By answering these two questions, the trade-offs are

made explicit, resulting in decision support for the de-

sign of a model execution approach.

Section 2 gives a brief overview of different model

execution approaches, and summarizes related work.

The ﬁrst question is answered in Section 3 by per-

forming a literature study on the advantages and

disadvantages of the generative and interpretive ap-

proach, and relating them to the Software Product

Quality Model from (ISO/IEC 25010, 2011). Sec-

tion 4 answers the second question by observing the

decision-making process. The research is evaluated

and discussed in Sections 5 and 6.

2 RELATED WORK

The ﬁrst and maybe best-known approach is code

generation, a strategy in which a model is parsed, in-

terpreted, and transformed into running software by

generating source code. This approach is formalized

outside of MDD in Generative Programming and de-

ﬁned by (Czarnecki and Eisenecker, 2000): “Genera-

tive programming is a software engineering paradigm

based on modeling software system facilities such

that a highly customized and optimized intermedi-

ate or end-product can be automatically manufactured

on demand.” Generative programming is more broad

than MDD: the generation does not need to happen

based on an model, but can also be done based on a

conﬁguration of components. Combining generative

programming with MDD results in generative MDD.

Although the output could be manually changed, this

paper only regards full code generation: no manual

changes are made to the resulting source code be-

tween generation and shipping the application. As

(Kelly and Tolvanen, 2008) point out this does not

mean that all code should be generated, an approach

that combines generated code with a framework or

base library is still a full code generation approach.

The other well-known approach is model interpre-

tation or interpretive MDD. This strategy also parses

and interprets the model; however, in this approach

this is done at run-time. There is no source code or

application generated and deployed, but instead, the

model is shipped as meta-data for the application. In

the same manner as the generation approach, this pa-

per only regards interpretation without further man-

ual coding. Interpretation which needs manual coding

would not make sense, as model execution happens at

run-time there would be no time for intervention.

Although many unique hybrid approaches could

be identiﬁed, three general groups of hybrid ap-

proaches are explained. Because of the nature of the

hybrid approach, a mix of different approaches, it is

not possible to give an exhaustive overview. The ﬁrst

hybrid approach is simpliﬁcation: a model with a high

abstraction level is transformed into a model with a

lower level of abstraction. The generator simpliﬁes

the original model and the resulting model, of a lower

abstraction level, is interpreted at run-time. This is

very similar to languages that compile into an inter-

mediate language, that in return is interpreted in a

runtime environment. An example of this approach

is described by (Meijler et al., 2010). They generate

Java code, but use a customized class loader to dy-

namically load classes. The customized class loaders

acts as an interpreter while the generated Java code is

the intermediate language. The approach of a cus-

tomized class loader looks similar to the Adaptive

Object-Model Architecture described by (Yoder and

Johnson, 2002) and applied by (Hen-Tov et al., 2008).

The second group of hybrid approaches is a strat-

egy that combines different approaches to different

parts of the model and/or application. In this approach

code is generated for certain parts of the system, while

other parts of the application are built using inter-

preters. The separation could also be done from the

model perspective: generate code for the mature (and

thus more stable) parts of the model while parts that

are more dynamic can be interpreted.

The third hybrid approach is found in program-

ming language research: while (Jones et al., 1993)

and (Rohou et al., 2015) show that interpretation is

slower, partial evaluation opens up new possibilities

in implementing a model execution strategy. A com-

An Exploration of the â

AŸItâ

Z in â

AŸIt Dependsâ

Z: Generative versus Interpretive Model-Driven Development

101

Voelter and Visser, 2011

Voelter, 2009

Stahl et al., 2006

Varro et al., 2012 Batouta et al., 2015

Tankovic et al., 2012Tankovic

Meijler et al., 2010

Deursen et al., 2000

Riehle et al., 2001

Consel and Marlet, 1998

Romer et al., 1996 Jones et al., 1993Thibault and Consel, 1997

Klint, 1981

Schramm et al., 2010Ousterhout, 1998 Thibault et al., 1999

Cook et al., 2008

Mernik et al., 2005

Czarnecki and Eisenecker, 2000 Cordy, 2004

Ertl and Gregg, 2003 Gregg and Ertl, 2004

Brady and Hammond, 2010Zhu, 2014 Cleenewerck, 2007

Jorges, 2013 Guana and Stroulia, 2015

Inostroza and Van Der Storm, 2015

Gaouar et al., 2015

Fabry et al., 2015Diaz et al., 2014

Figure 1: A dependency graph of the literature found in the review. Every arrow represents a citation. The dark blue boxes

mark the start set for the literature study.

pany that started with an interpretation approach, is

able to specialize this interpreter for certain models.

The evaluator transforms the generic interpreter into

a more specialized interpreter for a certain range of

models. (Cook et al., 2009) and (Shali and Cook,

2011) demonstrate that with this approach the inter-

preter could even be translated into a specialized ap-

plication.

More research is done on model execution ap-

proaches in MDD, however, none of them answer

the questions asked in this paper. (Batouta et al.,

2015) have performed a multi-criteria analysis on

the different approaches to aid the decision-making.

However, they do make a decisive statement about

which approach is better without giving support for

decision-making in different contexts. (Fabry et al.,

2015) touch on a number of advantages regarding

the different model execution approaches, but do this

without giving any decision-making support. While

(Zhu et al., 2005) does research the decision-making,

he does this for other architectural decisions than

the speciﬁc model execution approach. (Guana and

Stroulia, 2015) research how developers interact with

code generators, but do not compare this with inter-

preters.

Applying different decision-making methods to

the design of software and their architecture is not a

new approach. Examples are (Capilla et al., 2009),

(Jansen and Bosch, 2005), and (Svahnberg et al.,

2003). All of them research how decision-making

methods can support the design of software. None of

them apply this approach to the architecture of MDD

in particular, but only look at architectural design in

general.

3 LITERATURE STUDY

How the two model execution approaches, code gen-

eration and interpretation, compare to each other

is studied by doing a literature review following

the snowballing approach as described by (Wohlin,

2014). The goal of the study is to identify advan-

tages and disadvantages of generation and interpre-

tation that are claimed in existing research. There are

two reasons for using the snowballing strategy. First

of all the research area to be covered is broad: MDD,

DSL engineering, and compiler design all cover as-

pects of this discussion. The second reason is that the

papers often do not criticize the approaches explicitly,

advantages or disadvantages are often buried in de-

scriptions of implementations. These two reasons, the

broad research area and the indirect comments, make

it hard to search for literature. The snowballing strat-

egy depends on the citations that authors add when

giving reasons for their chosen approach. Therefore,

the start set consists of papers that for instance pro-

pose a speciﬁc implementation or give a summary of

best practices.

The start set for the review was created by an

informal exploratory search using Google. Search

terms for this search were “interpretation versus code

generation” as well as a number of variations. The

results were reviewed and explored for links to scien-

tiﬁc research. The resulting literature from the differ-

ent research ﬁelds was taken as starting point: (Van

Deursen et al., 2000), (Meijler et al., 2010), (Mernik

et al., 2005), (Tankovi

c et al., 2012), and (Voelter,

2009). Both backward and forward references were

followed to expand this set. Papers were included

when advantages or disadvantages were mentioned in

relation to a model execution approach. This strategy

led to 32 papers and books that were included. The

citation graph is shown in Figure 1.

The classiﬁcation of the advantages and disadvan-

tages is done by using the characteristics for software

product quality found in (ISO/IEC 25010, 2011). The

quality attributes form the criteria of the multi-criteria

decision support method that is described in this pa-

per. The product quality model as deﬁned by ISO con-

sists of eight categories (with 31 sub-characteristics).

In the 32 papers, no evidence was found for a dif-

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

102

Table 1: The results of the literature review and basis for the ranking of the two approaches. G corresponds with a preference

for code generation over interpretation. I identiﬁes where a paper shows a preference for interpretation over generation. G I

shows where papers did not show a clear preference, but did give advantages or disadvantages.

Run-time behavior

Build-time behavior

Resource utilization

Co-existence

Interoperability

Conﬁdentiality

Modularity

Analysability

Modiﬁability

Testability

Adaptability

Installability

(Batouta et al., 2015) G I G G I G G

(Brady and Hammond, 2010) G I I I I

(Cleenewerck, 2007) G G I

(Consel and Marlet, 1998) G I I I

(Cook et al., 2008) G G I G

(Cordy, 2004) I I

(Czarnecki and Eisenecker, 2000) G I

ıaz et al., 2014) G I I G

(Ertl and Gregg, 2003) G I I I I

(Fabry et al., 2015) G G I I

(Gaouar et al., 2015) G I

(Gregg and Ertl, 2004) G G I I I I I

(Guana and Stroulia, 2015) I I I

(Inostroza and Van Der Storm, 2015) I

(Jones et al., 1993) G I I G

orges, 2013) I I I

(Klint, 1981) G I G I I G I I

(Meijler et al., 2010) G I G G G G

(Mernik et al., 2005) I I G I

(Ousterhout, 1998) G I I G

(Riehle et al., 2001) I

(Romer et al., 1996) G I

(Schramm et al., 2010) I

(Stahl et al., 2006) I G I I I

(Tankovic, nown) G I G I I

(Tankovi

c et al., 2012) G I G I I

(Thibault et al., 1999) G I

(Thibault and Consel, 1997) I I

(Varr

o et al., 2012) G I I

(Voelter, 2009) G I G G G G G

(Voelter and Visser, 2011) G I G G G

(Zhu, 2014) G I G G

% in favor generation 88 0 87.5 0 0 100 20 22.2 15 60 37.5 57.1

% in favor interpretation 12 100 12.5 100 100 0 80 77.8 85 40 62.5 42.9

ference in quality fulﬁllment in relation to three out of

eight categories. It was expected that those three cat-

egories would not have any evidence of quality differ-

ence. Categories functional suitability and usability

describe how users interact with the software and how

the software fulﬁlls their requirements, and to repeat

the quote from (Stahl et al., 2006): code generation

and model interpretation are functionally equivalent.

The last category, reliability, deals with behavior in

relation to the environment of the software system.

For the remaining categories data was found. The

category performance efﬁciency describes how to

system utilizes resources, responds to requests, and

meets the capacity requirements. The operability and

co-existence of a system are described in compatibil-

ity. Conﬁdentially, integrity, authentication, and re-

lated aspects are described in security. Maintainabil-

ity covers the effectiveness and efﬁciency of modiﬁ-

cations to the system. Last, portability describes the

transfer of the system to a new platform. Mentions

of an advantage or disadvantage were mapped onto

sub-characteristics of these categories.

Table 1 shows the results of the study: every men-

tion of an advantage or disadvantage results in either

a G (when the author prefers generation over interpre-

tation) or an I (when the author prefers the opposite)

in the corresponding cell. When the author has no

preference for generation over interpretation, but does

give advantages for both, the corresponding cell con-

tains G I. The number of papers that prefer generation

over interpretation or vice versa are used to calculate

the preference in a percentage of the two alternatives

with respect to every quality attribute. The resulting

ranks are used in Section 4 to design the most ﬁtting

approach.

The evidence found is summarized per

sub-characteristic. First the name of the sub-

characteristic, the category under which the sub-

characteristic falls between parentheses, and a short

summary of the evidence that was found.

Time Behavior (Performance efﬁciency) - This sub-

characteristic is a special one, as according to ISO

it deals with the response and processing time of the

system. Within a MDD platform there are two differ-

ent response times that are important: the run-time re-

sponse of the application and the build-time response

of the platform. Build-time response is deﬁned as

being the turnaround time of changing the model

and updating the application to correspond with the

An Exploration of the â

AŸItâ

Z in â

AŸIt Dependsâ

Z: Generative versus Interpretive Model-Driven Development

103

model. The literature shows that there is a big differ-

ence between those two kinds of response times when

comparing code generation with model interpretation.

With respect to the run-time performance of the ap-

plication a big preference for generation is observed,

while for build-time performance there is a big pref-

erence for interpretation. Because of this difference

the time behavior sub-characteristic is split out in two

separate characteristics.

The trade-off between interpretation and genera-

tion with respect to run-time performance is a fre-

quently made comment. Twenty-two papers list this

trade-off and make comments about it: three give

no preference, and the others prefer a generative ap-

proach. The general sentiment is that generators can

do upfront analysis resulting in more efﬁcient code,

while interpreters add overhead and thus are slower.

In an early paper (Klint, 1981) went against this sen-

timent and remarked that this advantage will diminish

over time because of the advent in hardware. (Ertl and

Gregg, 2003) and (Romer et al., 1996) indeed show

in their research that there are no reasons why inter-

preters are slow by deﬁnition.

Although the generative approach often results

in better run-time performance, the lower build

times are an advantage of the interpretive approach.

The turnaround time between model changes and

ready-for-use software is a huge advantage, enabling

better prototyping, according to (Consel and Marlet,

1998), and (Riehle et al., 2001) among many others.

Resource Utilization (Performance efﬁciency) -

Not only are generators producing more performant

code, they can also optimize for other resources

according to (Meijler et al., 2010). This is a much

needed advantage in for instance embedded systems

or other resource-constrained environments like

games. (Gregg and Ertl, 2004) state that interpreters

often require less memory, but they do compete with

other parts of the application for resources. Although

generators maybe use more memory, they do not have

to compete with the running application, they can run

on different hardware. (Meijler et al., 2010) point out

that with regards to data storage in the application

an interpretive approach often has to choose for a

less optimal schema. The data itself conforms to a

schema depending on the model, which can change

at run-time. The storage often can not respond to that

change and thus has to be ﬂexible enough.

Co-existence (Compatibility) - Only two papers

make comments on the inﬂuence of the different

approaches on co-existence. (J

orges, 2013) points

out that the late binding of the interpretive approach

makes it a good candidate for multi-tenant appli-

cations: the same application instance can be used

for all tenants. (Gaouar et al., 2015) share their

experiences on making dynamic user interfaces and

point out how the interpretive approach enabled them

to use the platform native elements.

Interoperability (Compatibility) - Because inter-

preters have access to the dynamic context of the

running application they can make decisions based

on that context. This advantage is claimed by (Fabry

et al., 2015), (Ousterhout, 1998), and (Varr

o et al.,

2012). The interoperability of interpreters with other

parts of the application is thus better.

Conﬁdentiality (Security) - Models can be seen as

intellectual property according to (Tankovic, nown)

and (Tankovi

c et al., 2012), and the model is exposed

to the application in an interpretive approach. With

code generation the models are never shipped, as the

modeling solution is separated from the application.

Modularity (Maintainability) - In his thesis

(Cleenewerck, 2007) argues that generators have

more room for modularization, because an interpreter

at some point produces a value which cannot be

changed anymore. He is however the only one

claiming this preference, different authors such as

(Inostroza and Van Der Storm, 2015) and (Consel and

Marlet, 1998) propose solutions for modularization

within interpreters.

Analysability (Maintainability) - Generators

translate the model into a separate language, but the

semantics have to be translated as well. This is hard

to prove correct, according to (Guana and Stroulia,

2015). Interpreters on the other hand can play the

role of a reference implementation (according to

orges, 2013)), making the semantics of a model

clear. (Voelter, 2009) and (Voelter and Visser, 2011)

claim an advantage for generation: debugging a

generated application is easier, which beneﬁts the

analysability.

Modiﬁability (Maintainability) - (Cook et al.,

2008) and (D

ıaz et al., 2014), among others, claim

that interpreters are easier to write, and thus are

easier to modify. In the experience of (Cordy, 2004)

the heavy-weight process of the compiler made it

hard to modify. (Cleenewerck, 2007) and (Voelter

and Visser, 2011) claim that developers have more

freedom building generators and thus can make better

maintainable solutions.

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

104

Testability (Maintainability) - Interpreters can

easily be embedded in a test framework, where the

functionality can be tested. The reduced turnaround

time for interpreters also make them easier to test.

Generators are effectively a function from model to

code, which results in an indirection in the testing

framework. The easiest way to determine the correct-

ness is by running the generated code, asserting if the

correct code is generated would be cumbersome and

error prone. (Voelter, 2009) and (Voelter and Visser,

2011) give preference to generation when it comes to

debugging, because only one aspect is being looked

at.

Adaptability (Portability) - (Meijler et al., 2010),

(Batouta et al., 2015), and (Voelter, 2009) see the

advantage of code generation in adaptability: only

part of the generator needs to be adapted, which is

less work. Because of the separation between gen-

erator environment and application environment it is

possible to evolve them in different steps. (Tankovi

et al., 2012) and (Gregg and Ertl, 2004) see no

problem in porting an interpreter to a new platform

by using platform independent technologies. When

one wants to move to a different target platform,

worst case scenario is that the whole interpreter

needs be rewritten, which some regard as being easy,

while with the generative approach only part of the

generator needs to be adapted, which can be less

work.

Installability (Portability) - A clear advantage is

given to code generation by (Meijler et al., 2010),

(Cook et al., 2008), (Batouta et al., 2015), and (Voel-

ter, 2009), because the generation can target any plat-

form. By using an interpretative approach it is less

needed to re-install the application, because only the

model needs to be updated. This advantage is pointed

out by (Tankovi

c et al., 2012) and (Mernik et al.,

2005).

4 CASE STUDY

The quality characteristics and their comparisons can

be used to design the most ﬁtting approach for a spe-

ciﬁc software product or software component. In or-

der to make usage of them, teams need to prioritize

the characteristics, i.e., they have to determine which

are more important than others. This section summa-

rizes observations made at a large software company

in The Netherlands. AFAS Software, a Dutch ven-

dor of Enterprise Resource Planning (ERP) software.

The NEXT version of AFAS’ ERP software is com-

pletely model-driven, cloud-based and tailored for a

particular enterprise, based on an ontological model

of that enterprise. The ontological enterprise model

(OEM, as described (Schunselaar et al., 2016)) will

be expressive enough to fully describe the real-world

enterprise of virtually any customer.

When a priority is assigned to the quality charac-

teristics, (this is done with percentages, adding up to

a total of 100%), the total score of both code gener-

ation and model interpretation can be calculated with

the following formulas:

∑

i=1

and

∑

i=1

For every quality characteristic j the priority is ap-

plied to either the code generation or interpretation

preference. These values are summarized to end up

with the total score of code generation and model in-

terpretation.

Calculating the priorities of the different quality

characteristics can be done in different ways, and this

section describes two of them. In this case study ob-

servations are taken from two time-frames in the de-

velopment process. Although the software develop-

ment is a multi-year project and is still ongoing, these

two time-frames represent two discussions on design-

ing model execution approaches. The ﬁrst time-frame

focused on building an initial working version that

could be used for exploration and validation. It is

labeled the Architecture Design Phase as it focused

on the initial architecture of the MDD platform. The

second phase builds on top of the ﬁrst phase, mak-

ing the platform better suited for realistic deployment

scenarios. Both phases are described in terms of the

decisions that led the development, along with the re-

quirements in terms of quality characteristics. Deci-

sions that gave direction to the design are labeled with

a D, and they are summarized in Table 2.

Table 2: Summary of the decisions.

Architecture Design Phase

D1 A MDD platform based on an OEM

D2 A SaaS delivery model for the application

D3 Use multi-tenancy to gain resource sharing

Deployment Design Phase

D4 Enable customers to customize the model

D5 Run the application on the .NET runtime

D6 Deploy as a distributed application

D7 Re-design the model execution for messages

While it is observed that some of the decisions can

be seen as requirements, it are actually the decisions

following from corresponding requirements. For in-

stance decision D1 states that the decision is made to

An Exploration of the â

AŸItâ

Z in â

AŸIt Dependsâ

Z: Generative versus Interpretive Model-Driven Development

105

develop a MDD platform based on an OEM, follow-

ing from the requirement to have a model with a high

level of abstraction, not describing technology or soft-

ware but organizations.

4.1 Architecture Design Phase

Phase one focused on three key decisions, the ﬁrst

being the type of model used for the platform (D1).

The foundational vision is that the model describes

an organization, and not a software system. This re-

sults in the model being an OEM as described by

(Schunselaar et al., 2016). By deﬁnition this model

has a high abstraction level, and lacks the details that

are involved in creating software, details that are in-

stead present in the software (generator or interpreter)

transforming the model. The second decision was

that the resulting application is delivered through the

Software-as-a-Service (SaaS) model (D2). Within a

SaaS model SPOs are paid for delivering a service,

and it is important that this delivery is done in a cost

effective way. Multi-tenancy is a manner for SPOs to

be cost effective as stated in the deﬁnition of (Kabbe-

dijk et al., 2015). Therefore, the last decision fol-

lowed naturally from the second: the platform would

be multi-tenant (D3), although it was not yet decided

what form of multi-tenancy. These three decisions

gave focus for the development that was done in this

time-frame. The SaaS model, along with the multi-

tenancy resulted in a priority for the quality character-

istics resource utilization and run-time behavior. The

quality characteristic conﬁdentially has no priority,

because even if the model is distributed along with the

software it will stay conﬁdential in the SaaS model.

The resources of the platform are shared among the

customers, and to be cost effective, this sharing has to

be optimal. The platform with a different model per

customer also demanded conﬁdence, so the develop-

ment team gave priority to testability.

Although the data from this paper was not yet

available, the decisions and requirements are in hind-

sight translated into a prioritization of the quality at-

tributes as shown in Table 3. These weights are not

used to validate the design against the knowledge

from Table 1, because this study was done after this

phase. They serve as an illustration of how to the

data from the literature study can be used. Three

out of four requirements show a clear preference for

the code generation approach, leading to a 74% pref-

erence for code generation. Although according to

the literature study testability and analysability suf-

fer in the generation approach, the team was able to

solve those with satisfaction. In this case, the experi-

ence conﬁrmed the statements of (Voelter, 2009) and

(Voelter and Visser, 2011) that code generation is eas-

ier to implement and debug. Phase one was indeed

development by means of a full code generation ap-

proach.

Table 3: Summary of the prioritization of quality character-

istics for phase one. Columns G and I show the preferences

for code generation and model interpretation.

Priority G I

Run-time behavior 0.35 0.88 0.12

Resource utilization 0.35 0.875 0.125

Testability 0.15 0.60 0.40

Analysability 0.15 0.222 0.778

Preference 0.738 0.262

4.2 Deployment Design Phase

Phase two took place some time after the ﬁrst, and

its goal was a version of the platform that would deal

with the challenges of being a distributed SaaS so-

lution that allows customers to maintain their own

model. The decisions from phase one were not re-

jected, but new decisions were added to the list. The

ﬁrst was the possibility for customers to maintain

and customize their own model (D4). This function-

ality requires an efﬁcient upgrade mechanism, one

which is not disruptive for the users. The team also

decided on running the software on the .NET run-

time (D5), a platform that does not support dynamic

software updating, or other means of online upgrad-

ing. Dynamic software updating, or online upgrading,

is a solution for updating software processes without

stopping them ﬁrst, a solution that results in an ef-

ﬁcient upgrade mechanism. The quality characteris-

tic build-time behavior became more important, be-

cause customers maintain their own model expecting

near instant model execution, but the chosen platform

(.NET) does not support updates without restarting

the processes. The last decision was an extension of

D2, the application should have a distributed nature

to give robustness and optimal resource sharing (D6).

The attributes adaptability and modiﬁability gained

importance, because of the size of the platform and

its source code.

To set boundaries in this phase, the model ex-

ecution approach of a speciﬁc component was re-

designed. The application has a distributed nature,

and messages are used to pass information between

the different components. The re-design of the model

execution approach for these messages was the objec-

tive for this phase (D7).

In this phase, the AHP method described by

(Saaty, 1990) was used to rank the complete list of

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

106

twelve quality characteristics. (Falessi et al., 2011)

conclude that the AHP method is helpful in protect-

ing against two difﬁculties that are relevant for this

study. The ﬁrst is a too coarse grained indication of

the solution: as stated before there can be much de-

tail in the model execution approach and the decision

support method should support this. The second difﬁ-

culty is that there are many quality attributes that need

to be prioritized, and many attributes have small and

subtle differences.

Table 4 shows the result of ranking the character-

istics along with the total score for both code gener-

ation and model interpretation. The ranking is a re-

sult from the pairwise ranking of the characteristics

in Table 1: every pair was ranked on relative impor-

tance. The attributes build-time behavior, adaptabil-

ity, and modiﬁability have high priority (28%, 15.5%,

and 15% respectively), based on the decisions made.

Compared to phase one, the top three is completely

different (see Table 3), and the preference is also

ﬂipped in favor of interpretation with 69%. The re-

design was done by implementing a model simpliﬁca-

tion execution approach: the OEM is simpliﬁed into

simple message contract deﬁnitions by the generator.

Did run-time behavior, resource utilization, testabil-

ity, and analysability became less important? No, but

the decisions made in phase two favored other char-

acteristics, such as build-time behavior, and initial

tests showed that the simpliﬁcation approach would

not lead to an unacceptable decrease of the run-time

performance or an unacceptable increase of the re-

source utilization. The team was able to satisfy the

requirements for run-time behavior, resource utiliza-

tion, testability, and analysability with the simpliﬁca-

tion approach, while build-time behavior was difﬁcult

to satisfy with the generative approach combined with

the .NET runtime.

Table 4: Summary of the prioritization of quality character-

istics for phase two. Columns G and I show the preferences

for code generation and model interpretation.

Priority G I

Run-time behavior 0.059 0.88 0.12

Build-time behavior 0.278 0.00 1.00

Resource utilization 0.098 0.875 0.125

Co-existence 0.045 0.00 1.00

Interoperability 0.012 0.00 1.00

Conﬁdentiality 0.012 1.00 0.00

Modularity 0.062 0.20 0.80

Analysability 0.023 0.222 0.778

Modiﬁability 0.150 0.15 0.85

Testability 0.085 0.60 0.40

Adaptability 0.155 0.375 0.625

Installability 0.021 0.571 0.429

Preference 0.310 0.690

4.3 Evaluating the Decisions

The decisions that were observed during the design

of the model execution approach are summarized in

Table 2. As the result of the result of choices that

were made in the design of the platform, these deci-

sions set the boundaries and requirements for the on-

going design. The observed decisions are categorized

in three areas meta-model, architecture, and platform

and together form the context of the model execution

approaches within a MDD platform.

meta-model - Decisions D1: OEM and D4: Cus-

tomized model shows how the meta-model and its

features inﬂuence the design of the best ﬁtting strat-

egy for model execution. A meta-model with a high

level of abstraction, results in a more complex model

execution, because the high level of abstraction needs

to be transformed into a running application. This

complex model execution requires more resources

and takes more time, therefore code generation, or

model simpliﬁcation is preferred. By implementing

a transformation outside of the application (by either

generating code, or simplifying the model), the re-

quired resources and processing time do not add any

overhead to the application.

Decision D4:Customize, however, increases the

priority of build-time behavior. Customers that

change the model expect fast turn-around times,

a quality characteristic that is better satisﬁed with

model interpretation.

architecture - The multi-tenancy level in the ar-

chitecture as deﬁned by (Kabbedijk et al., 2015) is

also of inﬂuence to the model execution approach

(see D3: Multi-tenancy). If an application instance

level of multi-tenancy is required, code generation

would not make sense unless the platform supports

loading and unloading of source code. An applica-

tion instance level of multi-tenancy uses a single pro-

cess to serve different customers. Different customers

can have different models, and the process should

thus support loading (and unloading for efﬁcient re-

source usage) of different sets of code for different

customers. When multiple customers are served from

the same platform, resource utilization becomes im-

portant. To be cost effective the platform maximizes

resource sharing, but model interpretation adds to the

overall resource usage.

Decisions D6: Distributed application and

D7: Re-design messages show how componentiza-

tion gives engineers the possibility to apply differ-

ent model execution approaches to different compo-

nents in the software system. An application that con-

sists of multiple loosely coupled services can imple-

ment a different model execution approach in every

An Exploration of the â

AŸItâ

Z in â

AŸIt Dependsâ

Z: Generative versus Interpretive Model-Driven Development

107

service. This approach can be extended to applica-

tions that run in a single process, but still consists of

several loosely coupled components. When a compo-

nent, that is tightly coupled to a generated component,

uses model interpretation it might be necessary to re-

generate the ﬁrst component too, which then reverts

any advantage of the interpretative approach. Exam-

ples for components that could beneﬁt from a gener-

ative approach are those with more business logic or

algorithms, where efﬁcient code is important.

platform - (Kelly and Tolvanen, 2008) make no

distinction between the architecture, framework, the

operating system, or the runtime environment. The

inﬂuence of the architecture and framework described

in the previous area, are different from the oper-

ating system or runtime environment. As decision

D5: .NET platform illustrates, a target platform that

does not support dynamic software updating requires

a different model execution approach to satisfy the

build-time requirements. Not only phase two of the

case study illustrates this, it is also seen in the ap-

proach taken by (Meijler et al., 2010) with their cus-

tomized Java class loader and with (Czarnecki et al.,

2002) using the extension object pattern.

Deciding for a D2: SaaS delivery model removes

the priority from the characteristics installability and

co-existence: the platform is controlled by the soft-

ware company.

The case study has an illustrative nature, obser-

vations were made during two distinct phases of the

design of an model execution approach. These phases

are characterized by the different decisions that form

the boundaries of the design. By showing two differ-

ent situations, the inﬂuences from the context on the

design of a model execution approach are shown. The

two phases are related to the quality characteristics

described in Section 3, and combined with observa-

tions on the decisions that were made in the design of

the MDD platform. The resulting Tables 3 and 4 show

how the different decisions result in different priori-

ties for the two model execution approaches. In the

ﬁrst phase the decisions led to a preference for code

generation by 74% versus 26% for model interpreta-

tion. Model interpretation received 69% preference

in the second phase, because the shifted requirements

led to different priorities for the quality characteris-

tics.

Table 1 was received with mixed reactions by

the development team. On the one hand the quality

characteristics and the contextual inﬂuences guided

the discussions and brainstorms by asking the ques-

tions that the team did not knew they needed to ask.

The percentages, however, were not unanimously ac-

cepted. Questions were asked on the validity, mostly

because the context of speciﬁc literature was doubted

to be equal to the case study context. This demon-

strates the importance of context in designing a model

execution approach. It also illustrates the problems in

transferring experience and knowledge from one con-

text to another. It was concluded that the knowledge

presented in Table 1 is informative, but the real value

is in the experience behind the knowledge that trig-

gers the “right” questions.

The case company decided to generate simpliﬁed

models that are further interpreted at run-time. This

showed a promising improvement in build-time be-

havior because there is less C# that needs to be gen-

erated and compiled. Interpreting parts of the model

that inﬂuence the distributed nature of the application

appears to be more difﬁcult than generating it. With

the results of this exploration, the team will continue

to look out for components that beneﬁt from a simpli-

ﬁcation approach, and the model execution approach

will shift more towards a hybrid form of code gener-

ation and model simpliﬁcation. A pure form of inter-

pretation is considered to add too much overhead to

the run-time performance of the application, because

of the high level of abstraction that the OEM has.

Although this paper does not present a decision-

making method, and it does not relieve SPOs from the

hard work that designing a model execution approach

is, it does make the knowledge and experience of rel-

evant research accessible. By identifying the con-

text of a model execution approach through decisions

made in earlier phases, and by prioritizing the differ-

ent quality attributes, a SPO can get insight in how

well code generation and model interpretation satisfy

the requirements. A result without a signiﬁcant pref-

erence for either code generation or model interpre-

tation steers the SPO into the design of a hybrid ap-

proach. Based on such a result, an hybrid approach

helps optimizing the software quality by means of a

better ﬁtting model execution approach.

5 THREATS TO VALIDITY

The validity of this research is threatened by several

factors. The construct validity, which is threatened by

the fact that some of the researchers where involved

in the object of the study: the observations made in

section 4 could be biased. This threat is addressed

by the fact that this paper is reviewed and commented

on by key team members involved in the design of

the execution approach, making sure that the observed

decisions are correctly described.

The internal validity is threatened because the

quality characteristics and the platform context on the

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

108

one hand and the execution approach on the other

hand are difﬁcult to correlate. However, the claims

made in the reviewed literature do converge towards

each other. Although some characteristics lack a sig-

niﬁcant number of references, the authors regard the

claims made in this paper as not being controversial,

but in line with existing research. The data found

in literature to support claims on quality lacks sig-

niﬁcance on a number of characteristics. Further,

much of the literature that was used in composing

the overview uses anecdotal argumentation, as it is

based on the experience of the authors. The claims

that were found in the cited work were frequently not

validated in other cases, and no empirical evidence

for the claims was given. To create a more trustworthy

decision support method, the data presented in Table 1

should be validated by empirical research. Experi-

ments or large case studies should provide more quan-

titative data on the fulﬁllment of the different quality

characteristics.

The case study done at a single company threat-

ens the external validity. The consequences of the de-

cisions made in the design process are in line with

literature, but additional case studies should further

strengthen the decision support method.

6 CONCLUSION AND FUTURE

WORK

This paper makes two contributions to the research on

MDD. The ﬁrst contribution is the literature study and

the resulting table with the preference for model ex-

ecution approach per quality characteristic, described

in Section 3. It makes years of experience and knowl-

edge from many different authors on designing model

execution approaches accessible. A summary is given

with advantages and disadvantages that others can use

in designing a ﬁtting model execution approach. Al-

though the knowledge was already available, it was

scattered over many papers and hidden away as side-

notes. With the overview of model execution ap-

proaches and quality criteria the paper provides SPOs

with a method for rapid decision making when it

comes to the question of interpretation versus genera-

tion.

The second contribution is presented in Section 4:

an illustration of how the quality model for MDD

platforms can be applied in a SPO designing a model

execution approach. By giving priority to the quality

characteristics, a SPO is forced to specify the require-

ments for the approach. The explicit listing of de-

cisions that inﬂuence the model execution approach

such as its architecture, platform choices, and its

meta-model show how they interplay with the model

execution approach. Some decisions, such as the ab-

straction level of the model, make a model execu-

tion approach as interpretation less preferable. Deci-

sions such as the choice for a SaaS delivery model in-

crease the need for interoperability and co-existence,

increasing the preference for interpretation. This case

study shows how the different quality characteristics

inﬂuence the design, and may even conﬂict at differ-

ent design phases of a system.

This paper is a ﬁrst exploration of the design of

a model execution approach. Although there exists

a signiﬁcant body of knowledge on MDD, including

in-depth showcases of implementations of model exe-

cution approaches, none explores the designing of the

most ﬁtting approach for a given context. The explo-

ration presented in this paper uncovers the need for

more empirical research to validate the claims made

in this paper on quality attributes. For instance the

claim of performance of a generative approach over

an interpretive approach is still widespread, but the

actual overhead in a certain context might be neg-

ligible. Experimentation and large scale case stud-

ies should be conducted to build up evidence for the

presented quality attributes. Not only the quality at-

tributes and their preferences need more evidence.

Studies on the design process should be done to im-

prove the knowledge on how the design of a model

execution approach evolves. Research should be done

to deﬁne what the most ﬁtting model execution ap-

proach entails, when is an approach ﬁtting, and when

is it better ﬁtting than another approach.

Many, maybe all, questions in software develop-

ment can be answered with “it depends”, leaving the

questioner puzzled as to what he should do. Although

this paper presents a ﬁrst exploration and does not

remove the difﬁculty from the designing and devel-

oping of a MDD platform, it does shed light on the

design process. SPOs can use this exploration to im-

prove their knowledge and steer their design process

towards the most ﬁtting model execution approach.

ACKNOWLEDGEMENTS

This research was supported by the NWO AMUSE

project (628.006.001): a collaboration between Vrije

Universiteit Amsterdam, Utrecht University, and

AFAS Software in the Netherlands. The NEXT Plat-

form is developed and maintained by AFAS Software.

Further more, the authors like to thank Jurgen Vinju,

Tijs van der Storm, and their colleagues for their feed-

back and knowledge early on in the writing of this

paper. Finally we thank the developers of AFAS Soft-

An Exploration of the â

AŸItâ

Z in â

AŸIt Dependsâ

Z: Generative versus Interpretive Model-Driven Development

109

ware for sharing their opinions and giving feedback.

REFERENCES

Batouta, Z. I., Dehbi, R., Talea, M., and Hajoui, O. (2015).

Multi-criteria Analysis and Advanced Comparative

Study Between Automatic Generation Approaches in

Software Engineering. Journal of Theoretical and Ap-

plied Information Technology, 81(3):609–620.

Brady, E. C. and Hammond, K. (2010). Scrapping your

inefﬁcient engine. ACM SIGPLAN Notices, 45(9):297.

Capilla, R., Rey, U., Carlos, J., Due

nas, J. C., and Madrid,

U. P. D. (2009). The Decision View’s Role in Software

Architecture Practice. Practice, March/April:36–43.

Cleenewerck, T. (2007). Modularizing Language Con-

structs: A Reﬂective Approach. PhD thesis, Vrije Uni-

versteit Brussel.

Consel, C. and Marlet, R. (1998). Architecturing Soft-

ware Using A Methodology For Language Devel-

opment. Principles Of Declarative Programming,

1490(October):170–194.

Cook, W. R., Delaware, B., Finsterbusch, T., Ibrahim, A.,

and Wiedermann, B. (2008). Model transformation by

partial evaluation of model interpreters. Technical re-

port, Technical Report TR-09-09, UT Austin Depart-

ment of Computer Science.

Cook, W. R., Delaware, B., Finsterbusch, T., Ibrahim, A.,

and Wiedermann, B. (2009). Strategic programming

by model interpretation and partial evaluation. unpub-

lished.

Cordy, J. R. (2004). TXLA language for programming lan-

guage tools and applications. In Proceedings of the

ACM 4th International Workshop on Language De-

scriptions, Tools and Applications, pages 1–27.

Czarnecki, K. and Eisenecker, U. W. (2000). Genera-

tive programming: Methods, Tools, and Applications.

Addison-Wesley Professional.

Czarnecki, K., Østerbye, K., and V

olter, M. (2002). Genera-

tive programming. Object-Oriented Technology, Pro-

ceedings, 2323:135–149.

ıaz, V. G., Valdez, E. R. N., Espada, J. P., Bustelo, b. C.

P. G., Lovelle, J. M. C., and Mar

ın, C. E. M. (2014).

A brief introduction to model-driven engineering. Tec-

nura, 18(40):127–142.

Ertl, M. A. and Gregg, D. (2003). The structure and perfor-

mance of efﬁcient interpreters. Journal of Instruction-

Level Parallelism, 5:1–25.

Fabry, J., Dinkelaker, T., Noye, J., and Tanter, E. (2015).

A Taxonomy of Domain-Speciﬁc Aspect Languages.

ACM Computing Surveys, 47(3):1–44.

Falessi, D., Cantone, G., Kazman, R., and Kruchten, P.

(2011). Decision-making techniques for software ar-

chitecture design. ACM Computing Surveys, 43(4):1–

28.

Gaouar, L., Benamar, A., and Bendimerad, F. T. (2015).

Model Driven Approaches to Cross Platform Mo-

bile Development. Proceedings of the International

Conference on Intelligent Information Processing, Se-

curity and Advanced Communication, pages 19:1—-

19:5.

Gregg, D. and Ertl, M. A. (2004). A Language and Tool

for Generating Efﬁcient Virtual Machine Interpreters.

In Domain-Speciﬁc Program Generation, pages 196–

215. Springer Berlin Heidelberg.

Guana, V. and Stroulia, E. (2015). How Do Developers

Solve Software-engineering Tasks on Model-based

Code Generators ? An Empirical Study Design. First

International Workshop on Human Factors in Model-

ing, (May):33–38.

Hailpern, B. and Tarr, P. (2006). Model-driven develop-

ment: The good, the bad, and the ugly. IBM Systems

Journal, 45(3):451–461.

Hen-Tov, A., Lorenz, D. H., and Schachter, L. (2008). Mod-

elTalk: A Framework for Developing Domain Spe-

ciﬁc Executable Models. The 8th OOPSLA Workshop

on Domain-Speciﬁc Modeling, (926):7.

Inostroza, P. and Van Der Storm, T. (2015). Modular in-

terpreters for the masses implicit context propagation

using object algebras. In Proceedings of the 2015

ACM SIGPLAN International Conference on Genera-

tive Programming: Concepts and Experiences, pages

171–180. ACM.

ISO/IEC 25010 (2011). Systems and software engineering

– systems and software quality requirements and eval-

uation (square) – system and software quality models.

Standard, International Organization for Standardiza-

tion, Geneva, CH.

Jansen, A. and Bosch, J. (2005). Software Architecture as

a Set of Architectural Design Decisions. 5th Work-

ing IEEE/IFIP Conference on Software Architecture

(WICSA’05), pages 109–120.

Jones, N. D., Gomard, C. K., and Sestoft, P. (1993). Par-

tial Evaluation and Automatic Program Generation.

Prentice-Hall International.

orges, S. (2013). Construction and evolution of code

generators: A model-driven and service-oriented ap-

proach, volume 7747. Springer.

Kabbedijk, J., Bezemer, C.-P., Jansen, S., and Zaidman, A.

(2015). Deﬁning multi-tenancy: A systematic map-

ping study on the academic and the industrial perspec-

tive. Journal of Systems and Software, 100:139–148.

Kelly, S. and Tolvanen, J.-P. (2008). Domain-Speciﬁc Mod-

eling: enabling full code generation. John Wiley &

Sons.

Klint, P. (1981). Interpretation Techniques. Software: Prac-

tice and Experience, 11(June 1979):963–973.

Meijler, T. D., Nytun, J. P., Prinz, A., and Wortmann, H.

(2010). Supporting ﬁne-grained generative model-

driven evolution. Software & Systems Modeling,

9(3):403–424.

Mernik, M., Heering, J., and Sloane, A. M. (2005). When

and how to develop domain-speciﬁc languages. ACM

Computing Surveys, 37(4):316–344.

Ousterhout, J. K. (1998). Scripting: Higher-Level Program-

ming for the 21st Century. Computer, 31(3):23–30.

Riehle, D., Fraleigh, S., Bucka-Lassen, D., and Omorogbe,

N. (2001). The architecture of a UML virtual ma-

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

110

chine. International Conference on Object Oriented

Programming Systems Languages and Applications

(OOSPLA), (February):327–341.

Rohou, E., Swamy, B. N., and Seznec, A. (2015). Branch

prediction and the performance of interpreter - Don’t

trust folklore. 2015 IEEE/ACM International Sympo-

sium on Code Generation and Optimization (CGO),

pages 103–114.

Romer, T. H., Lee, D., Voelker, G. M., Wolman, A., Wong,

W. a., Baer, J.-L., Bershad, B. N., and Levy, H. M.

(1996). The structure and performance of interpreters.

ACM SIGPLAN Notices, 31(9):150–159.

Saaty, T. (1990). How to make a decision: The analytic

hierarchy process. European Journal of Operational

Research, 48(1):9–26.

Schramm, A., Preußner, A., Heinrich, M., and Vogel, L.

(2010). Rapid UI development for enterprise appli-

cations: Combining manual and model-driven tech-

niques. Models, 6394 LNCS(PART 1):271–285.

Schunselaar, D. M. M., Gulden, J., Van Der Schuur, H., and

Reijers, H. A. (2016). A Systematic Evaluation of En-

terprise Modelling Approaches on Their Applicability

to Automatically Generate Software. In 18th IEEE

Conference on Business Informatics.

Shali, A. and Cook, W. R. (2011). Hybrid Partial Eval-

uation. Proceedings of the 2011 ACM International

Conference on Object Oriented Programming Systems

Languages and Applications, pages 375–390.

Smolik, P. and Vitkovsky, P. (2012). Code Generation Nir-

vana. Modelling Foundations and Applications, pages

319–327.

Stahl, T., V

olter, M., Bettin, J., Haase, A., and Helsen, S.

(2006). Model-Driven Software Development: Tech-

nology, Engineering, Management.

Svahnberg, M., Wohlin, C., Lundberg, L., and Matts-

son, M. (2003). A Quality-Driven Decision-Support

Method for Identifying Software Architecture Candi-

dates. International Journal of Software Engineering

and Knowledge Engineering, 13(05):547–573.

Tankovic, N. (unknown). Model Driven Development Ap-

proaches: Comparison and Opportunities. Technical

report.

Tankovi

c, N., Vukoti

c, D., and

Zagar, M. (2012). Rethink-

ing Model Driven Development : Analysis and Op-

portunities. Information Technology Interfaces (ITI),

Proceedings of the ITI 2012 34th International Con-

ference, pages 505–510.

Thibault, S. and Consel, C. (1997). A framework for ap-

plication generator design. ACM SIGSOFT Software

Engineering Notes, 22(3, May 1997):131–135.

Thibault, S. A., Marlet, R., and Consel, C. (1999). Domain-

Speciﬁc Languages : From Design to Implementa-

tion Application to Video Device Drivers Genera-

tion. IEEE Transactions on Software Engineering,

25(3):363–377.

Van Deursen, A., Klint, P., and Visser, J. (2000). Domain-

speciﬁc languages: an annotated bibliography. ACM

Sigplan Notices, 35(6):26–36.

Varr

o, G., Anjorin, A., and Sch

urr, A. (2012). Uniﬁcation of

compiled and interpreter-based pattern matching tech-

niques. Lecture Notes in Computer Science (including

subseries Lecture Notes in Artiﬁcial Intelligence and

Lecture Notes in Bioinformatics), 7349 LNCS:368–

383.

Voelter, M. (2009). Best Practices for DSLs and Model-

Driven Software Development. Journal of Object

Technology, 8(6):79–102.

Voelter, M. and Visser, E. (2011). Product Line Engineer-

ing Using Domain-Speciﬁc Languages. 15th Inter-

national Software Product Line Conference, (Section

II):70–79.

Wohlin, C. (2014). Guidelines for Snowballing in System-

atic Literature Studies and a Replication in Software

Engineering. 18th International Conference on Evalu-

ation and Assessment in Software Engineering (EASE

2014), pages 1–10.

Yoder, J. W. and Johnson, R. (2002). The Adaptive Object-

Model Architectural Style. The Working IEEE/IFIP

Conference on Software Architecture 2002 (WICSA3

’02), pages 1–25.

Zhu, L., Uke, a. Y. B., Gorton, I. a. N., and Jeffery, R.

(2005). Tradeoff and Sensitivity Analysis in Soft-

ware Architecture Evaluation Using Analytic Hierar-

chy Process. pages 357–375.

Zhu, M. (2014). Model-Driven Game Development Ad-

dressing Architectural Diversity and Game Engine-

Integration. PhD thesis, Norwegian University of Sci-

ence and Technology.

An Exploration of the â

AŸItâ

Z in â

AŸIt Dependsâ

Z: Generative versus Interpretive Model-Driven Development

111
