Automatic Generation and Detection of Visually Faultless Facial

Morphs

Andrey Makrushin, Tom Neubert and Jana Dittmann

Otto-von-Guericke University of Magdeburg, Universitaetsplatz 2, Magdeburg, Germany

andrey.makrushin@ovgu.de, {tom.neubert, jana.dittmann}@iti.cs.uni-magdeburg.de

Keywords: Face Morph, Morphing Attack, Automatic Face Recognition, Morph Detection, Digital Image Forensics.

Abstract: This paper introduces an approach to automatic generation of visually faultless facial morphs along with a

proposal on how such morphs can be automatically detected. It is endeavored that the created morphs

cannot be recognized as such with the naked eye and a reference automatic face recognition (AFR) system

produces high similarity scores while matching a morph against faces of persons who participated in

morphing. Automatic generation of morphs allows for creating abundant experimental data, which is

essential (i) for evaluating the performance of AFR systems to reject morphs and (ii) for training forensic

systems to detect morphs. Our first experiment shows that human performance to distinguish between

morphed and genuine face images is close to random guessing. In our second experiment, the reference

AFR system has verified 11.78% of morphs against any of genuine images at the decision threshold of 1%

false acceptance rate. These results indicate that facial morphing is a serious threat to access control systems

aided by AFR and establish the need for morph detection approaches. Our third experiment shows that the

distribution of Benford features extracted from quantized DCT coefficients of JPEG-compressed morphs is

substantially different from that of genuine images enabling the automatic detection of morphs.

1 INTRODUCTION

Face as a biometric modality is a widely accepted

means of personal identity verification. For many

years, a printed facial image has been an important

part of identification documents. Recently, printed

face images have been supplemented by digital face

images stored on a chip integrated in the document.

On the one hand, issuing machine-readable

documents with digital photographs opens up new

horizons for applying Automatic Face Recognition

(AFR) systems to identity verification which saves

expensive manpower. On the other hand, the risk of

criminal intent to overcome AFR systems arises.

One of the possible attacks is brought to the

forefront by Ferrara et al. (Ferrara, 2014). This so-

called morphing attack is based on blending digital

face images of a criminal and his accomplice

resulting in a morphed face image (morph), which is

visually similar to both faces: the accomplice’s face

and the criminal’s face. As a result, two persons can

share one document.

In order to confirm the severity of this attack,

Ferrara et al. (Ferrara, 2016) evaluated the human

performance to match faces in original and morphed

images as well as the performance of three

commercial AFR systems to reject morphs. The

conclusions raise a major concern because, in many

cases, testees said that genuine and morphed face

images depict the same person and the experts were

not better in performing this task than laymen. Even

worse results came from AFR systems. The Morph

Acceptance Rate (MAR) at the decision thresholds

of 1% and 0.1% False Acceptance Rate (FAR) is

confirmed to be very high, indicating that the tested

systems are not able to distinguish between morphed

and genuine face images.

All in all, the systematic analysis of the

morphing attack has to be performed including the

study on morphing generation approaches as well as

the development of approaches to automatic morph

detection.

The morphs in (Ferrara, 2016) include a manual

retouch, which makes morph generation very time

consuming. There have only been 80 morphs

generated resulting in 160 morph verification

attempts for computing MAR. To the best of our

knowledge, there are currently no large publicly

available datasets of facial morphs. Therefore, we

propose an algorithm for automatic generation of

morphs enabling fast creation of thousands of

Makrushin A., Neubert T. and Dittmann J.

Automatic Generation and Detection of Visually Faultless Facial Morphs.

DOI: 10.5220/0006131100390050

In Proceedings of the 12th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2017), pages 39-50

ISBN: 978-989-758-227-1

realistic morphs. Possessing a large database of

multifarious morphs allows (i) for statistically

significant estimation of MAR, thus establishing the

resistance of AFR systems against the morphing

attack and (ii) for training and evaluation of forensic

morph detection algorithms.

For our experiments, we generated 3940 halfway

facial morphs from the Utrecht ECVP face dataset

(http://pics.psych.stir.ac.uk/2D_face_sets.htm) and

500 morphs from FEI Face Database (http://fei.edu.

br/~cet/facedatabase.html).

The visual quality of our morphs is proven in the

experiment on human perception of morphs. In

contrast to (Ferrara, 2016), in our experiment, a

testee decides for each single image whether it is a

morph or not. Human failure to reveal a morph

indicates its visual faultlessness. The MAR of

humans is 44.60% while the False Rejection Rate

(FRR) is 43.64%.

Next, we tested our morphs with the Luxand

Face SDK 6.1 (https://www.luxand.com/facesdk/)

which is taken as a reference COTS AFR system. At

the thresholds of 1% and 0.1% FAR, the MAR

yields 60.59% and 53.77% correspondingly.

Nonetheless, only 11.78% of morphs have been

verified against any of genuine images at 1% FAR

and 3.21% of morphs at 0.1% FAR.

The poor performance of AFR systems to reject

morphs motivates us to work on automatic morph

detection. Our detector is based on Benford features

calculated from quantized Discrete Cosine

Transformation (DCT) coefficients of JPEG-

compressed images. Classification of feature vectors

is performed using a linear Support Vector Machine

(SVM). We state and experimentally show that the

distributions of Benford features are substantially

different for morphed and genuine images. The

MAR of our morph detector does not exceed 13%.

Our contributions can be summarized as follows:

 we introduce a splicing-based approach to

automatic generation of visually faultless facial

morphs (Section 4.1) and evaluate the quality of

the morphs experimentally in a human test

(Section 5.4) and with a COTS AFR system

(Section 5.5);

 we introduce an automatic morph detection

approach based on Benford features and linear

SVM classifier (Section 4.2) and evaluate its

classification performance (Section 5.6).

Hereafter, the paper is organized as follows.

Related work is summarized in Section 2 including

recent advances in automation of facial morphing

and standard approaches of digital image forensics.

Section 3 encompasses the theoretical background of

facial morphing and tampering detection based on

JPEG compression artifacts. In Section 4, our

approaches to automatic morph generation and

detection are introduced. Our experiments are

presented in Section 5. Section 6 concludes the

paper with the results and future work.

2 RELATED WORK

2.1 Facial Morphing

Morphing or “Metamorphosis” is a well-studied

topic in computer graphics. A brief survey on

morphing approaches is given in (Wolberg, 1998).

Generally, morphing can be seen as a combination

of image warping and a cross-dissolve of image

elements. Wolberg in (Wolberg, 1990) summarizes

the fundamentals of image warping focusing on the

mesh warping technique. The most frequently

referenced morphing technique is, however, feature-

based warping introduced in (Beier, 1992). The

authors suggest locating pairs of corresponding line

segments and designing the mapping function for

each point based on the distance to each line. Further

techniques suggest locating pairs of corresponding

key points and applying the same mapping functions

to local neighborhoods around these points (Arad,

1994; Lee, 1996).

Early morphing approaches, mostly applied in

the film industry as a computer animation tool, have

always required human assistance to specify image

features. Modern morphing approaches evolve

towards automatic establishing of structural

similarity between objects in source and target

images (Liao, 2014).

A human face seems to be a favorite object for

morphing, because it is very intuitive and impressive

to visualize aging or a metamorphosis of one human

to another.

Blanz and Vetter (Blanz, 1999) introduce a

technique for face and face pose morphing

comprised of fitting the morphable 3D model to a

2D face image and modifying the resulting

individual 3D face towards another individual or

another pose exploiting principal component

analysis. However, this approach requires manual

assistance to obtain an accurate alignment between

the morphable model and a face in the image.

The efforts towards automatic generation of

facial morphs start with locating facial features in a

fully automated way. Cootes et al. (Cootes, 2000)

propose the concept of Active Shape Models to

VISAPP 2017 - International Conference on Computer Vision Theory and Applications

locate key points using local template matching

employing constraints of the shape models. This

concept is effectively used to locate facial landmarks

and to modify face appearance easily, representing

another way of face morphing. ASM is applied in

(Zanella, 2009) to face images in a frontal view to

perform morphing automatically. A comprehensive

survey on locating facial landmarks is presented in

(Celiktutan, 2013).

In spite of recent advances in facial morphing,

the automatic generation of visually faultless facial

morphs is still a very challenging task. The diversity

of facial images including different poses, skin

colors, hair styles and illumination conditions

drastically influences the appearance of automati-

cally generated morphs making them look less

realistic. One way to visually improve morphs is

retouching photographs to remove unrealistic hair

and spurious shadows caused by cross-dissolving of

images. An automatic interpolation of hair for

portrait morphing is addressed in (Weng, 2013).

Another way to achieve a realistic appearance is to

cut facial regions, warp them, blend them to a

mutual face, and seamlessly stitch it back into one of

the input images. We refer to the result of this

strategy as a splicing morph. A splicing morph is

taken as an opposite of a complete morph that could

be seen as a result of warping and blending of

complete facial images including hair, torso and

background. We focus on generation of the former,

because the visual inaccuracies created by splicing

are easier to conceal. A relatively simple and

straight-forward way to achieve seamless stitching

during generation of splicing morphs is automatic

selection of similar input images as suggested in

(Bitouk, 2008) for swapping faces or in (Vyas,

2015) for morphing.

2.2 Detection of Face Morphs

Since facial morphing can be seen as a special case

of tampering with image content, well-established

approaches to tampering detection from the field of

digital image forensics can be adopted. Indeed, a

morphing process along with a subsequent retouch,

on the one hand, creates specific artifacts in the

image and, on the other hand, destroys a camera-

specific fingerprint. Standard techniques of digital

image forensics are summarized in (Farid, 2009).

Notice that different morphing approaches create

different inconsistencies. For instance, the afore-

mentioned splicing morphs represent a special case

of image insertion or image splicing also referred to

as a cut-and-paste attack (Piva, 2013).

In (Schetinger, 2016) the “indirect arms race”

between image tampering and image forensics is

discussed. The authors assign image morphing to the

group “Image Enhancement/Tweaking” and state:

“Even though image insertion and manipulation can

create visually convincing results, they should not

pose a problem for modern forensic techniques.”

Dealing with morphed images created by an

attacker, a forensic expert is limited to so-called

“blind” approaches, implying that no other

information except for the probe image is presented

for analysis. The most complete bibliography on

blind tampering detection is gathered in (Mahdian,

2010). Image splicing detection is a substantial part

in this review.

There are three basic clues to detect splicing

independently from the image content. These are:

noise distribution (Lyu, 2014), demosaicing

inconsistencies (Dirik, 2009; Ferrara, 2012) and

compression artifacts (Lukas, 2003; Bianchi, 2012;

Milani, 2014).

Camera Noise is also referred to as Photo

Response Non-Uniformity (PRNU) of the camera

sensor and considered to be unique for each camera

(Fridrich, 2009). However, splicing detection from

PRNU is traditionally performed in the presence of

camera reference images. An alternative approach to

exposing spliced regions by means of noise

estimation is presented in (Lyu, 2014).

Demosaicing, also referred to as Color Filter

Array (CFA) interpolation, arises in color images

because standard sensors capture only a single color

value at each pixel location and the missing colors

are interpolated from the adjacent pixels. Tampering

detection (Dirik, 2009) as well as fine-grained

splicing detection (Ferrara, 2012) by analyzing

demosaicing inconsistencies has been proven an

effective technique so long as fragile CFA traces

have not been destroyed by legitimate image editing.

It is mentioned in (Schetinger, 2016) that even a

simple median or Gaussian filter is able to remove

CFA traces. Nonetheless, CFA analysis is effective

to distinguish native and non-native images, and

therefore can be applied to detection of splicing

morphs generated from raw images. Image

morphing detection by analyzing CFA traces is

addressed in (Ghatol, 2013).

Compression Artifacts arise in images after lossy

compression performed by a camera or by a

photographer after editing a raw image. After

tampering with image content, images are often re-

compressed. The vast majority of tampering

detection approaches deal with JPEG as the most

common compression standard. In order to detect

Automatic Generation and Detection of Visually Faultless Facial Morphs

double JPEG compression, most of the algorithms

rely on the analysis of the histogram of DCT

coefficients (Piva, 2013). A recent study utilizing

this idea (Bianchi, 2012) performs block-grained

localization of tampered regions in the presence of

aligned and non-aligned double JPEG compression.

Milani et al. (Milani, 2014) advocate the idea of

using first digit features also referred to as Benford

features to identify a level of compression.

Analysis of JPEG compression inconsistency is

especially promising for detection of splicing

morphs. Since the original images used for morph

generation are often JPEG-compressed, a morphed

image contains the original background blocks with

compression artifacts and synthetic face blocks with

destroyed compression artifacts due to interpolation

and cross-dissolve. Hence, the compressed splicing

morphs should contain blocks with different levels

of compression.

In (Schetinger, 2016), CFA and double JPEG

compression artifacts are asserted to be plausible

traces for morphing detection and noise to be an

identifiable trace.

The most recent effort to withstand the attack

from (Ferrara, 2014) is reported in (Ramachandra,

2016) introducing a morph detection approach based

on binarized statistical image features used in

conjunction with a linear SVM.

3 GENERAL DEFINITIONS OF

MORPHING AND BENFORD

FEATURES

3.1 Facial Morphing

Morphing is defined as a process of fluid transfor-

mation of one digital image (source) into another

(target). Generation of intermediate images is

realized by image warping supplemented by color

interpolation. Warping is a geometric transformation

applied to one or both images aiming at alignment

between important image features. We rely on the

mesh warping technique setting mesh elements to

triangles. Color interpolation can be understood as

alpha-blending of intensity values of both images for

each color layer separately. The parameter alpha

defines the proportion of pixel intensity values

obtained from source and target images.

In the case of facial morphing, the features are

defined by key points depicting eyes, nose, mouth

and face contour. The warping functions are defined

for the triangles built by the triplets of the key

points. Mapping of triangles is known to be the

standard affine transformation whose coefficients

can be easily and efficiently found. Any kind of

triangulation is theoretically possible. Practically, it

is shown that Delaunay triangulation yields

convincing results (Wu, 2011). We further use the

term facial landmarks to refer to the key points.

There are two ways to warp images: forward and

reverse mapping. Forward mapping starts with a

pixel within the source image and transfers it into

the corresponding location in the destination image.

Reverse mapping starts with a pixel within the

destination image and looks for its color in the

source image at the corresponding location. Forward

mapping might lead to unpainted pixels in the

destination image. Contrary to this, reverse mapping

ensures that every pixel in the destination image

obtains a value.

For the source (

) and target (I

) input face

images, the procedure of generation of intermediate

frames

can be formally described as follows:

1. define α from the interval [0,1]

2. find facial landmarks L

= {l

j=1..n} and L

= {l

, j=1..n}

3. create blended landmarks L

= {l

= (1-α)·l

+ α·l

, j=1..n}

4. create set of triangles T = {t

=(a,b,c), a,b,c  L

, i=1..k}

5. initialize warped images I

and I

6. for each t

denotes the set of pixels in I

enclosed in the triangle t

(e.g.

, I

and I

)

6.1 create mapping functions:

: 

→ 

and f

:

→ 

6.2 apply these:

= f

) and I

= f

)

7. I

= {I

, i=1..k} and I

= {I

i=1..k}

8. I

= (1-α)·I

+ α·I

where n is the number of landmarks and k is the

number of triangles.

3.2 Morph Detection by Analyzing

JPEG Compression Artifacts

Facing the diversity of morphing techniques, the

creation of a general morph detection algorithm is

extremely challenging. Quite to the contrary, the

algorithms for detection of particular types of facial

morphs can be developed with far less effort.

However, detection of morphs requires the thorough

understanding of the morph generation process and

possible image artifacts resulting from it.

VISAPP 2017 - International Conference on Computer Vision Theory and Applications

We believe that splicing morphs can be efficiently

detected by analyzing JPEG compression artifacts.

Our hypothesis is that a morphed image contains

blocks from the original image that have already

undergone a JPEG compression as well as synthetic

blocks generated by the morphing process. These

blocks are uncompressed. If the morphed image

undergoes JPEG compression, the original blocks

become double-compressed and the synthetic blocks

are single-compressed.

In order to comprehend the features that we use

for morph detection, let us look at the process of

JPEG compression which is comprised of three basic

steps: DCT, quantization and entropy coding.

Firstly, the color space of an image is

transformed from RGB to YCbCr. Notice that the

color levels are processed independently. Each layer

is divided into non-overlapping blocks of 8x8 pixels

and the DCT is applied to these blocks resulting in

64 DCT coefficients. Each coefficient represents the

contribution (amplitude) of a certain cosine function

to the linear combination of cosine functions

oscillating at different frequencies. This linear

combination represents the original signal. In other

words, the DCT coefficients give us an idea which

frequencies reside in an image.

Secondly, the DCT coefficients are quantized

according to a quantization table. The table, which is

not specified by the standard, describes the

correspondence between compression levels and

quantization factors. Formally, the quantized value

is calculated from the original one by dividing it by

a quantization factor and rounding to the nearest

integer. Quantization is an irreversible transforma-

tion leading to lossy data compression.

Thirdly, the quantized DCT coefficients are

coded without loss of information applying Huffman

coding.

Application of Benford features (first digits of

the quantized DCT coefficients) is suggested in (Fu,

2007; Milani, 2014) for tampering detection in

JPEG-compressed images. The hypothesis behind

applying Benford features is that the naturally

generated data follow Benford’s law and the

manipulated data violates it.

Benford’s law states that the distribution of the

first digits in a set of natural numbers is logarithmic.

A set of numbers satisfies the generalized Benford

law if the first digit x (x=1,2,…,9) occurs with a

probability p(x):

() log 1px n











 



(1)

where n is the normalization factor and α, β are the

parameters specifying the distribution.

Fu et al. (Fu, 2007) show that the quantized DCT

coefficients of single-compressed JPEG images

follow the generalized Benford law while the

quantized DCT coefficients of double-compressed

JPEG images violate it, which is reflected in the fact

that the distribution of Benford features deviates

from the logarithmic distribution.

Moreover, it is shown in (Milani, 2014) that the

distribution of Benford features is specific for

further levels of JPEG compression making the

features a powerful instrument for revealing the

image compression history.

Let Y

denote the i-th quantized DCT coefficient,

and N the number of DCT coefficients, then the first

digits fd are computed as follows:







NiYfd

...,2,1,10

log



(2)

and the Benford features as follows:

9...,2,1,



















jfd

Benf



(3)

4 OUR APPROACH TO

GENERATION AND

DETECTION OF MORPHS

4.1 Automatic Generation of Morphs

Our approach to automatic generation of face

morphs follows the general morphing procedure

described in Section 3.1. Aiming at creating a morph

appearing similar to both persons, we generate only

halfway morphs (α=0.5) where both images

contribute equally. Hence, alpha-blending is nothing

else but averaging. The mapping of triangles is done

in the reverse way making use of bilinear

interpolation. The discontinuities between triangles

are concealed applying the 2x2 median filter.

There are 68 facial landmarks localized using the

class

shape_predictor from the dlib program-

ming library (http://dlib.net/). Three landmarks

depicting the lower contour of the upper lip are

replaced by two landmarks at the lower lip. This

adjustment is important because ID photographs

require a closed mouth. Given that, the lower

contour of the upper lip might overlap with the

upper contour of the lower lip causing the triangles

with collinear corners that are inappropriate for

warping. Moreover, the set of landmarks is extended

by two landmarks at the pupils and seven landmarks

at the forehead (see Figure 1a).

Automatic Generation and Detection of Visually Faultless Facial Morphs

(a) (b)

Figure 1: (a) Facial landmarks localized by dlib (green,

blue), removed landmarks (blue) and our additional

landmarks (red); (b) mask to apply smoothing filter.

Figure 2a depicts the generation of complete

morphs. The workflow starts with extraction of

facial landmarks which are extended by 20

landmarks on the image borders. Then the landmark

coordinates are averaged. The blended landmarks

are used for triangulation. The triangles from the

first input image are warped to the average position

resulting in the first warped image. Likewise, the

second warped image is generated from the second

input image. Finally, the warped images are

averaged. Hence, a complete morph has mutual face

geometry and texture. However, spurious shadows

and strong visual inconsistencies in the hair region

resulting from blending are the visual flaws that can

hardly be concealed automatically. Therefore, we

consider complete morphs to be inappropriate for the

morphing attack, unless they have undergone a

manual retouch.

Splicing Morphs are designed to overcome the

visual flaws encountered in complete morphs. Figure

2b visualizes the morph generation process. After

extracting facial landmarks, the convex hull

representing a face is cut from the input images. The

landmark coordinates are averaged and the blended

landmarks are used for triangulation. The triangles

from the first face are warped to the average position

resulting in the first warped face. The same is done

to obtain the second warped face. The warped faces

are averaged in the frontal position similar to how is

suggested in (Lee, 1998). This scheme allows for

morphing three and more faces. The blended frontal

face is warped back twice, namely to the face

positions in the first and in the second input images.

The result is two morphed faces. The final step is the

splicing of the morphed faces into the corresponding

original images. In order to make the transmission

between the original and blended regions appear

natural, all pixels in the mask in Figure 1b are

smoothed by applying a Gaussian filter. The width

of the mask and the parameters of the Gaussian filter

are defined as relative values in accordance with the

interpupillary distance.

The advantage of the proposed splicing approach

is that a morph looks realistic because the seams of

the blended region match the original face contour.

The disadvantage is that, after inverse warping, the

blended face has the same geometry as the face it is

warped into. Therefore, the morph has a mutual

texture, but the geometry is adopted from one of the

input faces. Consequently, the splicing morphs are

expected to match well with one subject. In order to

match with another subject, both faces should have a

similar geometry.

For perfectly frontal faces, inverse warping can

be replaced by scaling and the blended face can be

directly inserted into the one or other image. In this

case, the blended face has an average geometry and

an average texture, but the average geometry may

differ from the original face geometry making

seamless splicing extremely difficult.

Further factors impeding morphs from appearing

realistic are different skin color and occlusion of

face parts by hair e.g. abundant hair at the forehead

region in input images. A straight-forward approach

to control the quality of morphs is an automatic

selection of input face images in regard to skin and

hair. Analyzing and mitigating these factors will be a

part of our future work.

The morph generation algorithm is implemented

in Matlab.

4.2 Automatic Detection of Morphs

Based on the nine Benford features described in

Section 3.2, we train the linear SVM classifier from

two sets of images. The first one is comprised of

splicing morphs and the second one encompasses

original images as well as images after legitimate

editing usually performed by photographers. This

includes in-plane rotation, scaling and cropping.

Notice that, after in-plane rotation, images are

always cropped to get rid of blank corners.

The parameters for image editing operations are

randomly chosen from the following ranges:

 cropping: from 60 to 80 pixels at every side (left,

right, top, bottom);

 scaling factor: from 0.8 to 1.2;

 rotation angle: from -3° to 3°.

The set of “positive” samples contains 524

morphs that have been randomly selected from the

whole set of 2614 splicing morphs. The set of

“negative” samples contains 131 original, 131

VISAPP 2017 - International Conference on Computer Vision Theory and Applications

Blended Keypoints

Triangulation

Blend

geometry

Warping

Warped Image2

Cross

dissolve


Extract

landmarks

Keypoints2


Keypoints1

Triangles

Final Morph

Warped Image1

Blended Keypoints

Triangulation

Blend

geometry

Warping

Warped Image2

Cross

dissolve


Extract

landmarks

Keypoints2


Keypoints1

Triangles

Final Morph

Warped Image1

(a)


Extract

landmarks

Warping

Blended Face

Cross

dissolve

Face2

Keypoints2

Triangulation

Insert blended

face into image

Cut convex

hull

Triangles

Image1 Face1 Final Morph1

Blend

geometry

Keypoints1

Blended Keypoints

Inverse

warping

Warped Face2 Morphed Face2 Final Morph2

Warped Face1 Morphed Face1


Extract

landmarks

Warping

Blended Face

Cross

dissolve

Face2

Keypoints2

Triangulation

Insert blended

face into image

Cut convex

hull

Triangles

Image1 Face1 Final Morph1

Blend

geometry

Keypoints1

Blended Keypoints

Inverse

warping

Warped Face2 Morphed Face2 Final Morph2

Warped Face1 Morphed Face1

(b)

Figure 2: The workflow for the automatic generation of (a) complete morphs and (b) splicing morphs.

scaled, 131 cropped, and 131 rotated and cropped

images, 524 samples in total. The equal number of

positive and negative samples designates a balanced

training set leading to the unbiased classifier. All

training images are decompressed and then

compressed in a JPEG format with 100% quality.

For each test sample, the classifier makes a decision

on which of two classes the sample belongs to.

Before classification, all test images undergo re-

compression similar to that which is done for

training images. Training of the linear SVM

classifier as well as classification of test samples is

carried out with WEKA data mining software 3.8.0

(Hall, 2009) using default parameterization.

5 EXPERIMENTS

5.1 Evaluation Goals

The evaluation addresses the morph generation and

morph detection approaches introduced in Sections

4.1 and 4.2 correspondingly. The quality of splicing

morphs generated by the former is tested in two

experiments on how well humans can recognize

morphs as such (Exp1) and how many morphs

would be accepted by a COTS AFR (Exp2). The

classification performance of the latter is evaluated

in the experiment (Exp3) with complete and splicing

morphs from the Utrecht ECVP face dataset as well

as with the original images and splicing morphs

from the FEI Face Database.

Automatic Generation and Detection of Visually Faultless Facial Morphs

5.2 Evaluation Dataset

The morphing attack is usually performed on ID

photographs that are compliant with the ISO/IEC

19794-5 standard (ISO, 2011). In other words, a face

pose in a photograph is frontal with the face parts

located at particular regions. Facial expression is

neutral and occlusions of eyes, nose or mouth do not

occur. The interpupillary distance exceeds 120

pixels. Lighting is equally distributed on a face.

From among the publicly available face datasets,

we have selected Utrecht ECVP face dataset as the

one that best fits the ISO/IEC 19794-5 standard. It

contains 131 images of 67 different individuals (20

women, 47 men). The image resolution yields

900x1200 pixels with the average interpupillary

distance of 200 pixels. The majority of individuals

are shot with neutral and smiling facial expressions.

Morphs are generated from all possible image

pairs of 52 individuals (17 women, 35 men) utilizing

only the images with neutral expressions. For each

pair of images one complete morph and two splicing

morphs are possible. Hence, 1326 complete morphs

and 2614 splicing morphs were generated. Our

algorithm failed to generate the remaining 38

splicing morphs because some triangles had

collinear corners disabling warping. Finally, we

manually selected 183 visually pleasing splicing

morphs for evaluating human ability to distinguish

between morphs and genuine images.

5.3 Performance Measures

In order to obtain uniform performance measures in

all our experiments, we extend the standard

performance measures of biometric systems

expressed in terms of FAR/FRR by the MAR, which

is used, on the one hand, for evaluation of AFR

performance to reject morphs and, on the other hand,

for humans and our morph detector to designate the

relative number of morphs falsely classified as

genuine images.

Assuming the matching score of an AFR system

expresses the similarity between a probe and a

gallery sample, the FAR is estimated by the relative

number of impostor attempts with matching scores

exceeding or equal to a decision threshold, while the

FRR is estimated by the relative number of genuine

attempts with matching scores lower than the

threshold. Similarly, we estimate the MAR of an

AFR system by the relative number of morph

attempts with matching scores exceeding or equal to

the threshold. Since a morph attempt is a special

case of an impostor attempt, the MAR can be seen as

a substitute for the FAR and the performance of an

AFR system to reject morphs is expressed by the

combination of MAR and FRR.

For biometric systems FAR and FRR are not

equally important because the FAR is considered the

security measure and the FRR the convenience

measure. Therefore, the decision threshold is usually

defined so that the FAR does not exceed a certain

value and the FRR is then calculated at this

threshold. Typical values for the FAR are 1% and

0.1%. It is common to denote the FRR at the

decision threshold of 1% FAR as FRR

100

and at the

decision threshold of 0.1% FAR as FRR

1000

Following the same logic, MAR

100

and MAR

1000

are

defined in (Ferrara, 2016).

The estimated MAR values give a pessimistic

impression of the success of a morphing attack.

Indeed, if a face image of person A is only slightly

modified toward person B, an AFR system would

still verify the morphed image against images of

person A and would fail to verify the morphed

image against images of person B. The MAR with

such morphs would yield 50% implying that 50% of

morph attempts have been falsely accepted. In

reality, these morphs are useless because person B

cannot use them to deceive an AFR system.

We propose to count the number of successful

morphs instead of accepted morph attempts. A

morph is successful if it has been verified against all

gallery images of both persons. We call this

performance measure the realistic MAR (rMAR).

For morph detection, no matter whether it is

performed by humans or by an automated morph

detection system, the "positive" decision is that an

image is a morph and the "negative" decision is that

an image is genuine. The MAR is, therefore, equal

to the False Negative Rate (FNR) because a morph

falsely accepted by an AFR system means a morph

falsely missed by a morph detection system. The

FRR is equal to the False Positive Rate (FPR),

because a genuine image falsely rejected (as a

morph) by an AFR system means a false alarm of a

morph detection system. FNR and FPR completely

describe detection performance. We also report the

classification accuracy as the relative number of

correct decisions in the total number of decisions.

Since, for morph detection systems, each morph is

associated with exactly one morphing attempt, the

MAR equals the rMAR.

5.4 Evaluation of Morphs by Humans

The first experiment (Exp1) on the human capability

to distinguish between morphs and genuine images

VISAPP 2017 - International Conference on Computer Vision Theory and Applications

has two goals:

 evaluating the visual quality of our splicing

morphs;

 obtaining clues on how humans recognize

anomalies in portrait images to utilize this

knowledge for developing algorithms for

automatic morph detection.

For the experiment, we take 23 out of 183 pre-

selected splicing morphs and 7 out of 15 genuine

face images that have not been used for creating

morphs. In total, there are 30 images in the test. The

images are printed with standard photo quality on

photo paper having the passport dimensions of

35x45 mm. Morphs and genuine photographs are

mixed and presented sequentially to 42 participants

under “thinking aloud test” conditions. Testees were

asked to say whatever they think about the images

and what pushes them to make one or another

decision while performing morph detection.

The results are visualized in Figure 3. The

classification accuracy of humans yields 55.62%

with the MAR of 44.6% and the FRR of 43.64%. As

can be seen in the diagram, 8 out of 23 morphs have

been falsely recognized as genuine images by 50 and

more percent of testees and only 3 morphs have been

correctly detected by 70 and more percent of testees.

Even worse is the situation with genuine images, 4

out of 7 genuine images have been falsely detected

as morphs by 50 and more percent of testees.

57,50%

58,97%

73,68%

26,83%

40,00%

46,15%

47,22%

47,62%

61,54%

51,22%

69,23%

46,15%

67,50%

54,76%

59,46%

57,14%

53,66%

57,89%

63,41%

41,46%

70,00%

82,93%

41,46%

43,59%

66,67%

77,50%

47,06%

45,00%

64,10%

48,78%

42,50%

41,03%

26,32%

73,17%

60,00%

53,85%

52,78%

52,38%

38,46%

48,78%

30,77%

53,85%

32,50%

45,24%

40,54%

42,86%

46,34%

42,11%

36,59%

58,54%

30,00%

17,07%

58,54%

56,41%

33,33%

22,50%

52,94%

55,00%

35,90%

51,22%

0% 50% 100%

M10

M11

M12

M13

M14

M15

M16

M17

M18

M19

M20

M21

M22

M23

False

Correct

Figure 3: Results of the experiment on human capability to

distinguish morphs (M1-23) from genuine images (G1-7).

Evaluating the morph detection performance of the

testees separately, we see that the performance

strongly fluctuates from one person to another. Only

9 out of 42 testees have correctly classified more

than two thirds of test images. Six of them have

mentioned blurring in the face region as a clue for

indicating morphs and five of them also pointed to

slight color differences in the face and the forehead

regions.

All in all, this detection performance can be

considered as close to random guessing enabling us

to conclude that humans are not able to distinguish

between splicing morphs and genuine images. This

justifies the visual faultlessness of our automatically

generated splicing morphs.

5.5 Evaluation of Morphs with the

Reference AFR System

The second experiment (Exp2) aims at testing how

many of our splicing morphs can deceive a COTS

AFR system. Matching of face images is done with

the Luxand FaceSDK 6.1 later referred to as “the

matcher”. The matcher produces similarity scores in

the interval [0,1]. Based on the internal experiments,

the SDK provides decision thresholds to obtain a

given level of the FAR. The thresholds, at which the

FAR yields 1% and 0.1%, are 0.99 and 0.999

correspondingly.

First, the matcher is evaluated with the complete

Utrecht ECVP face dataset to get an idea about the

distributions of genuine and impostor matching

scores. 69 genuine scores result from the comparison

of neutral and smiling faces (or two neutral faces) of

the same person. 8446 impostor scores result from

the pair-wise comparison of all images of different

persons in the database. The distributions of genuine

and impostor scores are depicted in Figure 4. All

genuine scores are located in the interval [0.999, 1].

The mean value of the impostor scores yields 0.2645

while the maximum impostor score is 0.9751. In

other words, the matcher shows the perfect result

making no mistakes at both thresholds 0.99 and

0.999.

0 0.2 0.4 0.6 0.8 1

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

Matching score

Density

Genuine Scores

Impostor Scores

Figure 4: Distributions of genuine and impostor matching

scores resulting from the cross-matching of original

images in the Utrecht ECVP face dataset using the Luxand

FaceSDK 6.1.

Second, 1326 complete and 2614 splicing morphs

are matched against all images of the persons who

participated in these particular morphs. Normally,

Automatic Generation and Detection of Visually Faultless Facial Morphs

there are four morph attempts for each morphed

image: two images with neutral faces (source images

for morph generation) and two images with smiling

faces. Notice that some persons do not have a

smiling photograph and some persons have more

than one neutral photograph. The distributions of

matching scores for complete, splicing and manually

selected splicing morphs are depicted in Figure 5.

The corresponding values of MAR and rMAR are

given in Table 1.

0.95 0.955 0.96 0.965 0.97 0.975 0.98 0.985 0.99 0.995 1

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

Matching score

Density

Complete morphs

Splicing morphs

Selected splicing morphs

Figure 5: Distributions of matching scores resulting from

matching of morphs against original images; the histogram

bin yields 0.001; the left-most column shows the relative

number of matching scores in the interval [0, 0.9501).

Despite their visual imperfection, most of the

complete morphs are able to deceive the matcher.

83.27% of complete morph attempts are accepted at

0.1% FAR and 55.20% are verified against any of

the genuine images in the test at the same threshold.

The scores with splicing morphs are substantially

lower. Only 53.77% of splicing morph attempts are

accepted at 0.1% FAR and only 3.21% are verified

against any of the genuine images. These 84 out of

2614 morphs (3.21%) can be considered perfect,

having the characteristic that these would neither be

detected by humans nor rejected by the reference

AFR system.

Table 1: Pessimistic and realistic MAR at the decision

thresholds of 1% and 0.1% of FAR.

MAR

100

MAR

1000

rMAR

100

rMAR

1000

Complete

morphs

93.34% 83.27% 80.39% 55.20%

Splicing

morphs

60.59% 53.77% 11.78% 3.21%

Selected

spl.morphs

65.43% 57.30% 16.94% 5.46%

In order to check whether the visually pleasing

splicing morphs can better deceive the reference

AFR, we have selected 183 out of 2614 and

calculated MAR

100

and MAR

1000

for them. As can be

seen in Table 1, the MAR values become slightly

higher (see also Figure 5) but the difference in MAR

values is still too low to assert that the realistic

appearance of the face in a morphed image

correlates with the performance of AFR to reject

morphs.

5.6 Evaluation of Our Morph Detector

In the third experiment (Exp3), the performance of

our morph detector is evaluated in two tests. In the

first one, the 10-fold cross-validation is performed

on the training dataset. In the second one, the morph

detector is tested with four test datasets (T):

 T

: the remaining 2090 splicing morphs from the

Utrecht ECVP face dataset;

 T

: 1326 complete morphs from the Utrecht

ECVP face dataset;

 T

: 400 original images from the FEI Face

Database;

 T

: 500 splicing morphs from the FEI Face

Database.

The confusion matrix of the first test is depicted

in Table 2. The classification accuracy yields

98.09% (1028/1048). Only 20 genuine images have

been misclassified as morphs and none of the

morphs has been misclassified as a genuine image.

Table 2: Confusion matrix of the 10-fold cross-validation

of our morph detector.

Classified as

Ground truth

Genuine Splicing

morphs

Genuine

504 (96.18%)

20 (3.82%)

Splicing morphs 0

524 (100%)

original cropped rotated scaled morphs

0.1

.15

0.2

.25

0.3

.35

Figure 6: Distribution of samples for the feature Benf

This result signifies that original and legitimately

edited images have substantially different feature

distribution compared to that of splicing morphs

which is shown in the example of feature Benf

Figure 6. The distribution of the feature values for

splicing morphs is narrow with a small variation.

The distributions of original and legitimately edited

VISAPP 2017 - International Conference on Computer Vision Theory and Applications

images are broader with means significantly

different from that of splicing morphs. Based on this

diagram, we assert that the utilized features are not

suitable to differentiate between the types of

legitimate image editing but are highly suitable for

distinguishing between splicing morphs and

remaining images.

The results of the second test are depicted in

Table 3. The MAR values of morphs created from

Utrecht ECVP face dataset (T

and T

) yield 12.11%

for splicing morphs and 12.97% for complete

morphs, indicating superior morph detection

performance regarding humans. The classification

accuracy of 98.44% (886/900) in the test with the

FEI Face Database (T

) indicates that the

proposed classifier is capable of correctly classifying

test images that are significantly different from

images used for training.

Table 3: Classification results with four test datasets.

Classified as

Ground truth

Genuine Morph

(morph) 253 (12.11%)

1837 (87.89%)

(morph) 172 (12.97%)

1154 (87.03%)

(genuine)

386 (96.50%)

14 (3.50%)

(morph) 0

500 (100%)

Nevertheless, the conducted test does not enable us

to make conclusions about the general suitability of

our proposed classifier. We realize that the

distribution of Benford features can be different if

morphs are generated from random face images

using morphing techniques which are different from

image warping with a subsequent cross-dissolve.

Moreover, it is possible to create face images with

the similar distributions of Benford features using

legitimate image processing techniques. For

instance, it is shown in (Wang, 2011) that the

application of Benford's law to image tampering

detection is vulnerable to the histogram

manipulation attack.

6 CONCLUSIONS

In this paper, we have proposed (i) the approach to

automatic generation of visually faultless facial

morphs, (ii) the approach to morph detection by

utilizing Benford features calculated from quantized

DCT coefficients of JPEG-compressed images and

(iii) evaluated both in three experiments.

The visual faultlessness of our splicing morphs is

confirmed in the experiment with humans. The

MAR of humans yields 44.60% with the FRR of

43.64% which is close to random guessing (see

Exp1).

The suitability of our splicing morphs to deceive

an AFR system has been tested in Exp2. Considering

all verification attempts, the MAR

100

is 60.59% and

the MAR

1000

is 53.77%. 11.78% of morphs have

been verified against any of the genuine images at

1% FAR and 3.21% at 0.1% FAR.

Our morph detector yields 12.11% MAR with

splicing and 12.97% MAR with complete morphs

clearly outperforming humans. The classification

accuracy of 98.44% with the alternative face

database indicates that our morph detector is capable

of correctly classifing test images that are fairly

different from images used for training (see Exp3).

In our future work, we are going to visually

improve morphs that will achieve higher matching

scores with the reference AFR system. To this end,

we plan an automatic selection of facial images with

similar skin color, hair and head geometry along

with automatic image editing including re-coloring

and a hair retouch. We also plan engaging an

alternative AFR system to the morph generation

process for morph quality control by straight-away

matching of just generated morphs against genuine

images.

Our morph detector will be improved by

considering the local features derived from blocks

located at the face contour and in the face region.

Following clues from the “thinking aloud test”, the

local analysis of skin texture will be performed to

detect excessive blurriness in the face region and

color inconsistencies.

Due to the severity of the morphing attack and

the limited capability of AFR systems to reject

morphs, we believe that much attention should be

paid to adoption of tampering detection approaches

from digital image forensics to facial morphing,

potentially making automatic morphing detection an

indispensable component of AFR systems.

ACKNOWLEDGEMENTS

The work in this paper has been funded in part by

the German Federal Ministry of Education and

Science (BMBF) through the research programme

under the contract no. FKZ: 13KIS0509K.

REFERENCES

Arad, N., et al., 1994. Image Warping by Radial Basis

Functions: Applications to Facial Expressions. In

Automatic Generation and Detection of Visually Faultless Facial Morphs

CVGIP:Graph Models Image Proc.56(2), pp. 161-172.

Beier, T., Neely, S., 1992. Feature-based image

metamorphosis. In Comp. Graphics. 26(2), pp. 35-42.

Bianchi, T., Piva, A., 2012. Image Forgery Localization

via Block-Grained Analysis of JPEG Artifacts. In

IEEE Trans. on Information Forensics and Security

7(3), pp. 1003-1017.

Bitouk, D., et al., 2008. Face Swapping: Automatically

Replacing Faces in Photographs, In ACM Trans. on

Graphics 27(3), 39.

Blanz V., Vetter, T., 1999. A morphable model for the

synthesis of 3D faces. In Proc. Conf. on Computer

Graphics and Interactive Techniques, pp. 187-194.

Celiktutan, O., et al., B., 2013. A comparative study of

face landmarking techniques. In EURASIP Journal on

Image and Video Processing 2013 (1), 1.

Cootes, T.F., Taylor, C.J., 2000. Statistical Models of

Appearance for Computer Vision. Technical Report,

University of Manchester.

Dirik, A.E., Memon, N., 2009. Image tamper detection

based on demosaicing artifacts. In Proc. IEEE Int.

Conf. on Image Processing, pp. 1497-1500.

Farid, H., 2009. Image forgery detection. In IEEE Signal

Processing Magazine 26(2), pp.16-25.

Ferrara, M., Franco, A., Maltoni, D., 2014. The magic

passport. In Proc. IEEE Int. Joint Conf. on Biometrics,

Clearwater, Florida, pp. 1-7.

Ferrara, M., Franco, A., Maltoni, D., 2016. On the Effects

of Image Alterations on Face Recognition Accuracy.

In Bourlai, T. (ed.) Face Recognition Across the

Electromagnetic Spectrum, Springer, pp. 195-222.

Ferrara, P., Bianchi, T., De Rosa, A., Piva, A., 2012.

Image Forgery Localization via Fine-Grained Analysis

of CFA Artifacts. In IEEE Trans. on Information

Forensics and Security 7(5), pp. 1566-1577.

Fridrich, J., 2009. Digital image forensic using sensor

noise. In IEEE Sig. Proc. Magazine 26(2), pp.26-37.

Fu, D., Shi, Y.Q., Su, W., 2007. A generalized Benford’s

law for JPEG coefficients and its applications in image

forensics. In Proc. SPIE EI 6505, San Jose, CA.

Ghatol, N., et al., 2013. Image Morphing Detection by

Locating Tampered Pixels with Demosaicing

Algorithms, In Int.J.of Computer App.66(8), pp.23-26.

Hall, M., et al., 2009. The WEKA data mining software:

An update. In SIGKDD Explorations 11(1), pp. 10-18.

ISO, 2011. ISO/IEC 19794-5:2011, Information

technology - Biometric data interchange formats, Part

5: Face image data.

Lee, S., et al., 1996. Image Metamorphosis with Scattered

Feature Constraints. In IEEE Trans. on Visualization

and Computer Graphics 2(4), pp 337-354.

Lee, S., Wolberg, G., Shin, S.Y., 1998. Polymorph:

Morphing Among Multiple Images. In IEEE

Computer Graphics and Applications 18(1)

, pp. 58-71.

Liao, J., et al., 2014. Automating Image Morphing using

Structural Similarity on a Halfway Domain. In ACM

Transactions on Graphics 33(5), 168.

Lukáš, J., Fridrich, J., 2003. Estimation of primary

quantization matrix in double compressed JPEG

images. In Proc. Digital Forensics Research

Conference (DFRWS’03).

Lyu, S., Pan, X., Zhang, X., 2014. Exposing Region

Splicing Forgeries with Blind Local Noise Estimation.

In Journal of Computer Vision 110(2), pp. 202-221.

Mahdian, B., Saic, S., 2010. A bibliography on blind

methods for identifying image forgery. In Signal

Processing: Image Communication 25, pp. 389-399.

Milani, S., et al, 2014. Discriminating multiple JPEG

compressions using first digit features. In APSIPA

Trans. on Signal and Inf. Processing 3(e19), pp. 1-10.

Piva, A., 2013. An Overview on Image Forensics., In

ISRN Signal Processing, Article ID 496701, 22 p.

Ramachandra, R., Raja, K., Busch, C., 2016.

Demystifying Magical Passport: A Robust Morphed

Face Image Detection Scheme. In Proc. IEEE Int.

Conf. on Biometrics: Theory, Appl., and Systems.

Schetinger, V., Iuliani, M., Piva, A., Oliveira, M. M.,

2016. Digital Image Forensics vs. Image Composition:

An Indirect Arms Race. In CoRR abs/1601.03239.

Vyas, J.P., Joshi, M.V., Raval., M.S., 2015. Automatic

target image detection for morphing. In Journal of

Visual Comm. and Image Represent. 27, pp. 28-43.

Wang, J., et al., 2009. Understanding Benford’s law and

its vulnerability in image forensics. In Proc. IEEE Int.

Conf. on Multimedia and Expo, pp. 1568-1571.

Weng, Y., et al., 2013. Hair interpolation for portrait

morphing, In Comp.Graph. Forum 32(7), pp. 79-84.

Wolberg, G., 1998. Image morphing: a survey, In Visual

Computer 14(8), pp. 360-372.

Wolberg, G., 1990. Digital Image Warping, IEEE

Computer Society Press, Los Alamitos CA.

Wu, J., 2011. Face Recognition Jammer using Image

Morphing. Tech.Rep. No. ECE-2011-03, Boston Uni.

Zanella, V., Ramirez, G., Vargas, H., Rosas, L.V., 2009.

Automatic Morphing of Face Images. Adaptive and

Natural Computing Alg., LNCS 5495, pp 600-608.

VISAPP 2017 - International Conference on Computer Vision Theory and Applications
