Result Diversity for RDF Search

Hiba Arnaout and Shady Elbassuoni

Computer Science Department, American University of Beirut, Bliss Street, Beirut, Lebanon

Keywords:

Diversity, Novelty, RDF-graphs, Evaluation.

Abstract:

RDF repositories are typically searched using triple-pattern queries. Often, triple-pattern queries will return

too many results, making it difﬁcult for users to ﬁnd the most relevant ones. To remedy this, some recent

works have proposed relevance-based ranking-models for triple-pattern queries. However it is often the case

that the top-ranked results are homogeneous. In this paper, we propose a framework to diversify the results

of triple-pattern queries over RDF datasets. We ﬁrst deﬁne different notions for result diversity in the setting

of RDF. We then develop an approach for result diversity based on the Maximal Marginal Relevance. Finally,

we develop a diversity-aware evaluation metric based on the Discounted Cumulative Gain and use it on a

benchmark of 100 queries over DBPedia.

1 INTRODUCTION

The continuous growth of knowledge-sharing com-

munities like Wikipedia and the recent advances in

information extraction have made it possible to build

large knowledge-bases such as YAGO (Suchanek

et al., 2008) and DBPedia (Auer et al., 2007). These

knowledge bases consist of billions of facts repre-

sented in the W3C semantic model RDF (RDF, 2004).

Querying these RDF knowledge bases or repositories

is typically done by triple-pattern-based query lan-

guages such as SPARQL (SPARQL, 2008).

For example, consider the triple-pattern query:

”?m director ?d; ?m genre Comedy”. This query con-

sists of two triple patterns and aims to ﬁnd directors

of comedy ﬁlms. For example, running our exam-

ple query over DBPedia returns 1073 results. Table 1

shows 5 examples of these 1073 results.

Table 1: 5 example results from DBPedia for the query ”?m

director ?d; ?m genre Comedy”.

Subject Predicate Object

Model Ball director Scott Zarakin

Model Ball genre Comedy

All the Wrong Places director Martin Edwards

All the Wrong Places genre Comedy

Friends (2002 ﬁlm) director M. D. Sridhar

Friends (2002 ﬁlm) genre Comedy

Double or Nothing director Roy Mack

Double or Nothing genre Comedy

President’s Day director Chris LaMartina

President’s Day genre Comedy

Users usually prefer seeing a ranked result-list

rather than a list of unranked matches (Chaudhuri

et al., 2006). Recently, some approaches have been

proposed to rank the results of triple-pattern queries.

For example, the work in (Elbassuoni et al., 2009)

proposed a ranking approach based on language mod-

els to rank query results. In (Dali et al., 2012), the au-

thors proposed a learning-to-rank approach that uses

query-independent features. Another example is the

work in (Kasneci et al., 2008) where the authors use

several notions such as conﬁdence, informativeness

and compactness to rank query results. Table 2 shows

the top-5 ranked results for our example query when

run over DBPedia using the ranking model of (El-

bassuoni et al., 2009). As shown in Table 2, the top

ranked results are all about famous movies and direc-

tors, as compared to those in Table 1 which are about

unpopular movies and directors.

Table 2: Top-5 ranked results from DBPedia for the query

”?m director ?d; ?m genre Comedy”.

Subject Predicate Object

Annie Hall director Woody Allen

Annie Hall genre Comedy

Dumb and Dumber director Perer Farrelly

Dumb and Dumber genre Comedy

Sleeper director Woody Allen

Sleeper genre Comedy

Husbands and Wives director Woody Allen

Husbands and Wives genre Comedy

Muppets Most Wanted director James Bobin

Muppets Most Wanted genre Comedy

Arnaout, H. and Elbassuoni, S.

Result Diversity for RDF Search.

DOI: 10.5220/0006046402490256

In Proceedings of the 8th Inter national Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2016) - Volume 1: KDIR, pages 249-256

ISBN: 978-989-758-203-5

249

While result ranking goes a long way in improv-

ing the user satisfaction, it is often the case that the

top-ranked results are dominated by one aspect of the

query. This is a common problem in IR in general

(Carbonell and Goldstein, 1998). For example, con-

sider our example query. As can be seen from Table

2, a large number of the top-5 results are movies by

the same director, namely Woody Allen.

To achieve the tradeoff between the relevance and

diversity of a result, we rely on the Maximal Marginal

Relevance (MMR) approach (Carbonell and Gold-

stein, 1998) which we adapt to the RDF setting.

To evaluate the effectiveness of our diversity ap-

proach and to compare different notions of diversity,

we deﬁne a new evaluation metric based on the Dis-

counted Cumulative Gain (DCG) (Jrvelin and Kekli-

nen, 2002).

Our contributions can be summarized as follows:

• We provide the ﬁrst formal deﬁnition of result di-

versity in the context of RDF Search.

• We develop the ﬁrst diversity-aware ranking

model for RDF Search.

• We design a new diversity-aware evaluation met-

ric for RDF search.

• We built the ﬁrst evaluation benchmark on DBPe-

dia that can be used to evaluate ranking models

and result diversity approaches for RDF search.

2 RELATED WORK

Result diversity for document retrieval has gained

much attention in recent years. The work in this area

deals primarily with unstructured and semi-structured

data (Agrawal et al., 2009; Carbonell and Goldstein,

1998; Chen and Karger, 2006; Clarke et al., 2008;

Gollapudi and Sharma, 2009; Zhai et al., 2003). Most

of the techniques perform diversiﬁcation by optimiz-

ing a bi-criteria objective function that takes into con-

sideration both result relevance as well as result nov-

elty with respect to other results. Gollapudi and

Sharma (Gollapudi and Sharma, 2009) presented an

axiomatic framework for this problem and studied

various objective functions that can be used to de-

ﬁne such optimization problem. They proved that in

most cases, such problem is hard to solve and pro-

posed several approximation algorithms to solve such

problem. Carbonell and Goldstein introduced the

Maximal Marginal Relevance (MMR) method (Car-

bonell and Goldstein, 1998) which is one approxi-

mation solution to such optimization problem. Zhai

et al. (Zhai et al., 2003) studied a similar approach

within the framework of language models and de-

rived an MMR-based loss function that can be used

to perform diversity-aware ranking. Aragwal et al.

(Agrawal et al., 2009) assumed that query results be-

long to different categories and they proposed an ob-

jective function that tries to trade off the relevance of

the results with the number of categories covered by

the selected results.

In an RDF setting, where results are constructed

at query time by joining triples, we do not have an ex-

plicit notion of result categories. We thus adopted the

Maximal Marginal Relevance approach (Carbonell

and Goldstein, 1998) to the setting of RDF data since

it directly utilizes the results to perform diversity

rather than explicitly taking the categories of the re-

sults into consideration.

Apart from document retrieval, there is very lit-

tle work on result diversity for queries over structured

data. In (Chen and Li, 2007) the authors propose to

navigate SQL results through categorization, which

takes into account user preferences. In (Vee et al.,

2008), the authors introduce a pre-indexing approach

for efﬁcient diversiﬁcation of query results on rela-

tional databases. However, they do not take into con-

sideration the relevance of the results to the query.

3 RDF SEARCH

In this paper, we tackle the problem of result diver-

sity for RDF search. To perform an RDF search,

we rely on the RDF Xpress search engine (Elbas-

suoni et al., 2009). RDF Xpress supports three differ-

ent modes of search, namely purely-structured triple-

pattern queries, keyword-augmented triple-pattern

queries and automatic query relaxation. For purely-

structured queries, the search engine takes as input a

triple-pattern query and returns a ranked list of RDF

subgraphs matching the given query. The results

are ranked based on a language-modeling approach

specially developed for the setting of RDF search.

For example, Table 2 shows the top-5 results for the

query: ”?m director ?d; ?m genre Comedy”. For

keyword-augmented queries, the search engine takes

as input a triple-pattern query where one or more

triple pattern is augmented with a set of keywords.

For example, to ﬁnd movies directed by Woody Allen

that have something to do with New York:”?m direc-

tor Woody

Allen [new york]”. One example result is

”Annie Hall director Woody Allen”. The story of

this ﬁlm was set in New York city.

Finally, for the case when no results are found for

a given triple-pattern query, automatic query relax-

ation is deployed.

KDIR 2016 - 8th International Conference on Knowledge Discovery and Information Retrieval

250

For example, running the query ”?m star-

ring Woody Allen; ?m musicComposer Dick Hyman”

over DBPedia will return no results. After combin-

ing the results of all relaxed queries using the result-

merging approach of RDF Xpress, one sample result

is ”Radio

Days writer Woody Allen; Radio Days mu-

sicComposer Dick

Hyman”.

4 RESULT DIVERSITY

Our main focus in this paper is on result diversity for

RDF search. A diversity-aware ranking model should

ideally try to produce an ordering or a permutation of

the query results such that the top-k results are most

relevant to the query and at the same time as diverse

from each other as possible. This can be cast into an

optimization problem where the objective is to pro-

duce an ordering that would maximize both the rel-

evance of the top-k results and their diversity. The

objective function for such an optimization problem

is very hard to both quantify and solve and thus most

approaches try to solve a simpler closely-related prob-

lem known as the top-k set selection problem (Golla-

pudi and Sharma, 2009). The top-k set selection prob-

lem can be formulated as follows.

Deﬁnition 1 (Top-k Set Selection). Let Q be a query

and U be its result set. Furthermore, let REL be a

function that measures the relevance of a subset of re-

sults S ⊆ U with respect to Q and let DIV be a func-

tion that measures the diversity of a subset of results

S ⊆ U. Finally, let f be a function that combines both

relevance and diversity. The top-k set selection prob-

lem can be solved by ﬁnding:

∗

= argmax

S⊆U

f(Q,S,REL,DIV)

such that |S

∗

| = k

The objective function f(Q,S, REL,DIV) is

clearly underspeciﬁed and in order to the solve this

optimization problem, one must clearly specify both

the relevance function REL and diversity function

DIV, as well as how to combine them. Gollapudi and

Sharma (Gollapudi and Sharma, 2009) proposed a set

of axioms to guide the choice of the objective func-

tion f(Q,S,REL,DIV) and they showed that for most

natural choices of the relevance and diversity func-

tions, and the combination strategies between them,

the above optimization problem is NP-hard. For in-

stance, one such choice of the objective function is

the following:

f(Q,S, REL, DIV) = (k − 1)

∑

r∈S

rel(r,Q) +2λ

∑

r,r

′

∈S

d(r,r

′

)

(1)

where rel(r,Q) is a (positive) score that indicates how

relevant result r is with respect to query Q (the higher

this score is, the more relevant r is to Q) and d(r, r

′

) is

a discriminative and symmetric distance measure be-

tween two results r and r

′

, and λ is a scaling parame-

ter.

The above objective function clearly trades off

both relevance of results in the top-k set with their di-

versity (as measured by their average distance). Solv-

ing such objective function is again NP-hard, how-

ever there exists known approximation algorithms to

solve the problem that mostly rely on greedy heuris-

tics (Gollapudi and Sharma, 2009).

In the rest of this section, we follow the same ap-

proach to obtain a top-k set of relevant and diverse

results for queries over RDF knowledge bases. In

particular, we optimize the above bi-criteria objec-

tive function using a greedy algorithm that uses the

Maximal Marginal Relevance (MMR) (Carbonell and

Goldstein, 1998) to select the top-k set.

4.1 Maximal Marginal Relevance

Carbonell and Goldstein introduced the Maximal

Marginal Relevance (MMR) method (Carbonell and

Goldstein, 1998) which they use to re-rank a set of

pre-retrieved documents U given a query Q.

Deﬁnition 2 (Marginal Relevance). Given a query Q,

a set of resultsU and a subset S ⊂U, the marginal rel-

evance of a result r ∈ U \S is equal to: MR(r,Q, S) =

λrel(r,Q) + (1 − λ)min

′

∈S

d(r,r

′

) where rel(r, Q) is a

measure of how relevant r is to Q, div(r,r

′

) is a sym-

metric distance measure between r and r

′

and λ is a

weighting parameter.

The idea behind the marginal relevance metric is

very intuitive. Given a query Q and a set of already

selected results S, the marginal relevance of a result

r is a measure of how much do we gain in terms of

both relevance and diversity by adding the result r to

the selected set S. To measure how much the result

r would contribute to the relevance aspect of S, it is

straight forward and we can use the result’s relevance

to Q. On the other hand, measuring how much re-

sult r would contribute to the diversity of S is more

involved. The most natural thing to do is to compare

r with all the results r

′

∈ S and compute a similarity

(or rather dissimilarity) between r and every other re-

sult r

′

∈ S and then aggregate these similarities over

all the results in S. We do exactly this by assuming

there is a distance function that can measure how re-

sult r is different from any other result r

′

and then we

use the minimum of the distances of r from all the re-

sults r

′

∈ S as a measure of the overall contribution

Result Diversity for RDF Search

251

of result r to the diversity of set S. By maximizing

this minimum over a set of results r /∈ S, we can ﬁnd

the result that when added to S would render it most

diverse as compared to any other result.

Given all these considerations, we set the rele-

vance rel(r,Q) to the score of the result r obtained

from the RDF Xpress engine . We only assume here

that the search engine would rank the results descend-

ingly based on their scores.

We propose next three different notions of diver-

sity and then we explain how we build a subgraph rep-

resentation that allows us to achieve each such notion.

4.1.1 Resource-based Diversity

In this notion of diversity, the goal is to diversify the

different resources (i.e., entities and relations) that ap-

pear in the results. This ensures that no one resource

will dominate the result set. Recall our example query

asking for comedy movies and their directors. Table

2 shows the top-5 subgraphs retrieved for the query

using RDF Xpress.

In order to diversify the top-k results of a certain

query, we deﬁne a language model for each result as

follows.

Deﬁnition 3 (Resource-based Language Model). The

resource-based language model of result r is a proba-

bility distribution over all resources in the knowledge

base KB.

The parameters of the result language model are

estimated using a smoothed maximum likelihood es-

timator as follows:

P(w|r) = α

c(w;r)

|r|

+ (1− α)

|Col|

(2)

where w is a resource, Col is the set of all unique re-

sources in the knowledge base, c(w;r) is the number

of times resource w occurs in r, |r| is the number of

times all resources occur in r, and |Col| is the number

of unique resources in the knowledge base. Finally, α

is the smoothing parameter.

4.1.2 Term-based Diversity

In this notion of diversity, we are only interested in di-

versifying the results in terms of the variable bindings.

To be able to do this, we deﬁne a language model for

each result as follows.

Deﬁnition 4 (Term-based Language Model). The

term-based language model of result r is a probability

distribution over all terms (unigrams) in the knowl-

edge base KB.

The parameters of the result language model are

estimated using a smoothed maximum likelihood es-

timator as follows:

P(w|r) = α

c(w;r)

|r|

+ (1− α)

|Col|

(3)

such that w /∈ QTerms, where w is a term, QTerms

is the list of the terms in the query, Col is the set of

all unique terms in the knowledge base, c(w;r) is the

number of times term w occurs in r, |r| is the number

of times all terms occur in r, and |Col| is the number

of unique terms in the knowledge base. Finally, α is

the smoothing parameter.

By excluding terms that appear in the original

query when representing each result, we ensure that

when these representations are later used for diversity,

the top-ranked results still stay close to the original

user query.

4.1.3 Text-based Diversity

In RDF Xpress, each triple is also associated with a

text snippet which can be used to process keyword-

augmented queries. A text snippet can be directly uti-

lized to provide diversity among the different results

using the MMR measure.

To be able to do this, we deﬁne a language model

for each result as follows.

Deﬁnition 5 (Text-based Language Model). The text-

based language model of a result r is a probability

distribution over all the keywords in all the text snip-

pets of all the triples in the knowledge base KB.

The parameters of the text-based language model

is computed using a smoothed maximum-likelihood

estimator as follows:

P(w|r) = α

c(w;D(r))

|D(r)|

+ (1− α)

|Col|

(4)

where c(w;D(r)) is the number of times keyword w

occurs in D(r) (the text snippet of subgraph r), |D(r)|

is the number of occurrences of all keywords in D(r),

and |Col| is the number of unique keywords in the text

snippets of all triples in the knowledge base. Finally,

α is the smoothing parameter.

4.2 Diversity-aware Re-ranking

Algorithm

Finally, we explain how the marginal relevance can

be used to provide a diverse-aware ranking of results

given a query Q. Let U be the set of ranked results

using any regular ranking model (i.e., that depends

only on relevance without taking into consideration

diversity). The algorithm to re-rank the results works

as follows:

KDIR 2016 - 8th International Conference on Knowledge Discovery and Information Retrieval

252

Maximal Marginal Relevance Re-ranking Algo-

rithm

1. Initialize the top-k set S with the highest ranked

result r ∈ U

2. Iterate over all the results r ∈ U \ S, and pick the

result r

∗

with the maximum marginal relevance

MR(r

∗

,Q,S). That is,

∗

= argmax

r∈U\S

[λrel(r,Q) + (1 − λ)min

′

∈S

d(r,r

′

)]

(5)

3. Add r

∗

to S

4. If |S| = k or S = U return S otherwise repeat steps

2, 3 and 4

The distance between two results r and r

′

is com-

puted as follows:

d(r,r

′

) =

JS(r||r

′

)

where JS(r||r

′

) is the Jensen-Shannon Divergence

(Lin., 1991) between the language models of results r

and r

′

and is computed as follows:

JS(r||r

′

) =

KL(r||M) + KL(r

′

||M)

∑

terms

r(i)log

r(i)

M(i)

+ r

′

(i)log

′

(i)

M(i)

(6)

where KL(x||y) is the Kullback-Leibler Divergence

between two language models x and y, and M =

(r + r

′

) is the average of the language models of r

and r

′

We opted for using the Jensen-Shannon Diver-

gence as its square root is a symmetric distance mea-

sure which is exactly what is required in the MMR

measure.

5 DIVERSITY-AWARE

EVALUATION METRIC

To be able to evaluate the effectiveness of our re-

sult diversity approach, an evaluation metric that takes

into consideration both relevance of results as well as

their diversity must be used. There is a wealth of work

on diversity-aware evaluation metrics for IR systems

such as (Allan et al., 2003; Clarke et al., 2008; Zhai

et al., 2003). We adopt a similar strategy and propose

a novel evaluation metric that takes into consideration

both aspects we are concerned with here, namely rele-

vance and diversity, to evaluate a result set for a given

query.

We introduce an adjustment to the Discounted Cu-

mulative Gain (DCG) (Jrvelin and Keklinen, 2002)

metric by adding a component that takes into consid-

eration the novelty of a certain result, which reﬂects

result diversity in a given result set.

More formally, given a particular result set (a re-

sult ordering) of p results, the diversity-aware DCG,

which we coin DIV-DCG is computed as follows:

DCG

= rel

+ nov

∑

i=2

(

rel

log

(i)

+ nov

) (7)

where rel

is the relevance score of the result at posi-

tion i and nov

is its novelty.

5.1 Resource-based Novelty

Concerning our ﬁrst two diversity notions: the

resource-based and term-based, the novelty of a result

at position i can be computed as follows:

nov

#unseen

#variables

(8)

where #unseen

is the number of resources that are

bound to variables in result at position i that have not

yet been seen, and #variables is the total number of

variables in the query. Our goal is to diversify the

results with respect to the variable bindings.

5.2 Text-based Novelty

The computation of the text-based novelty metric is

very similar in spirit to the resource-based one. The

only difference is that in the case of text-based diver-

sity, our goal is to diversify the results with respect

to their text snippets. To be able to quantify this, we

measure for each result, the amount of new keywords

that this result contributes to the set of keywords of

the previously ranked results. More precisely, the

text-based novelty can be computed as follows:

nov

|keywords

\ (keywords

∩ (∪

i−1

j=1

keywords

))|

|keywords

(9)

where keywords

is the set of the keywords associated

with the subgraph at position i, ∪

i−1

j=1

keywords

is the

set of all the keywords seen so far (up to subgraph

i− 1), and |keywords

| is the number of keywords in

the set keywords

6 EVALUATION

6.1 Setup

In order to evaluate our greedy diversity-aware re-

ranking algorithm, we constructed a benchmark of

Result Diversity for RDF Search

253

Table 3: Average DIV − NDCG

of the training queries for different values of λ.

Notion λ = 0.1 λ = 0.2 λ = 0.3 λ = 0.4 λ = 0.5 λ = 0.6 λ = 0.7 λ = 0.8 λ = 0.9

Resouce-based 0.798 0.789 0.780 0.769 0.762 0.758 0.751 0.740 0.727

Term-based 0.798 0.785 0.770 0.759 0.752 0.747 0.741 0.731 0.724

Text-based 0.932 0.931 0.928 0.923 0.918 0.915 0.906 0.892 0.875

100 queries over DBPedia, which can be broadly

divided into 4 categories: structured, keyword-

augmented, requiring relaxation, and keyword-

augmented and requiring relaxation.

Our query benchmark was used in order to tune

the weighting parameter of MMR (λ in Equation 5),

that is used to trade-off relevance and diversity.

We needed to gather a relevance assessment for

each result to be able to compute rel

. To gather these

relevance assessments, we relied on the crowdsourc-

ing platform CrowdFlower as follows. For each one

of our three diversity notions, each query was run 10

times with λ ranging from 0.1 to 1 (i.e., no diversity)

and the top-10 results were retrieved.

The inter-rater agreement reported by Crowd-

Flower was 67%. In addition, we computed the Fleiss

Kappa Coefﬁcient as another measure of agreement

which is more reliable measure than that of Crowd-

Flower as it takes into consideration agreement by

chance. We obtained a Kappa Coefﬁcient of 40%

which can interpreted as ”Fair Agreement” (Fleiss,

1971).

Table 4: Average DIV − NDCG

of the test queries.

Notion Diversiﬁed Result Set Non-diversiﬁed Result Set

Resource-based 0.79 0.74

Term-based 0.81 0.74

Text-based 0.91 0.68

To measure the efﬁciency of our algorithm, we

calculate the average execution time for each notion.

For the Resource-based and Term-based notions, the

averages are 5.7 s and 5.9 s respectively. For the Text-

based, it is 26 s.

6.2 Experiments

6.2.1 Parameter Tuning

The main parameter in our diversity-aware re-ranking

algorithm is the weighting parameter λ which trades-

off relevance and diversity. To be able to set this

parameter, we divided our query benchmark into a

training set consisting of 80 queries and computed

the normalized DIV − DCG

for each query in the

training set varying the value of λ from 0.1 to 0.9.

The normalized DIV − DCG

or DIV − NDCG

computed by dividing the DIV − DCG

by the ideal

DIV −DCG

. To be able to compute the ideal DIV−

DCG

, we re-ranked the results using a greedy ap-

proach. The new ordering pushes the results with the

best combination of diversity and relevance gain to

the top. Table 3 shows the average DIV − NDCG

for our three notions of diversity for different values

of λ. For our three notions, the best value for λ is 0.1,

which means we should give 90% importance to di-

versity over relevance in our re-ranking algorithm in

order to get the best DIV − NDCG

possible.

6.2.2 Comparison of Various Notions of

Diversity

Given the optimal values of the parameter λ that were

set based on the 80 training queries in our benchmark,

we computed the average DIV − NDCG

for the 20

test queries for each notion of diversity, as well as

for the cases when no diversity was employed. The

summary of our ﬁndings over the 20 queries is shown

in Table 4. As can be seen from the table, the av-

erage DIV − NDCG

for all notions is signiﬁcantly

larger than those where no diversiﬁcation of results

took place.

Next we show some qualitative results that high-

light the importance of result diversity for RDF search

and the difference between the various notions of di-

versity we discussed here.

Resource-based Diversity. Consider the query

”?ﬁlm1 director ?x; ?ﬁlm2 starring ?y; ?x spouse ?y”

whose corresponding information need is ”Give me

the name of a director whose partner is an actor (or

actress) and the name of a movie for each”. Table 5

shows the top-5 results with and without diversiﬁca-

tion, with λ set to 0.1. The table shows that without

diversiﬁcation, the results are dominated by two re-

sources, namely Madonna and Sean

Penn with differ-

ent combinations of movies they acted in or directed,

but when diversiﬁcation is involved, we get a set of

different director-actor pairs as shown in the second

column of Table 5.

Term-based Diversity. Consider one of the test

queries: ”?m director ?x [Disney]; ?m starring ?y”.

The information need is: ”Give me the name of a a

movie, its director, and its star, preferably a Disney

movie”. The top-5 results with the diversity param-

eter λ set to 0.1 are shown in Table 6. In the non-

KDIR 2016 - 8th International Conference on Knowledge Discovery and Information Retrieval

254

Table 5: Top-5 results for the query: ”?ﬁlm1 director ?x; ?ﬁlm2 starring ?y; ?x spouse ?y” with and without diversity.

No Diversity Resource-based Diversity

W.E. director Madonna W.E. director Madonna

Mystic River starring Sean Penn Mystic River starring Sean Penn

Madonna spouse Sean Penn Madonna spouse Sean Penn

Secretprojectrevolution director Madonna Citizen Kane director Orson Welles

Mystic River starring Sean Penn Cover Girl starring Rita Hayworth

Madonna spouse Sean Penn Orson Welles spouse Rita Hayworth

W.E. director Madonna Henry V director Laurence Olivier

The Tree of Life starring Sean Penn Ship of Fools starring Vivien Leigh

Madonna spouse Sean Penn Laurence Olivier spouse Vivien Leigh

W.E. director Madonna That Thing You Do! director Tom Hanks

Dead Man Walking starring Sean Penn Jingle All the Way starring Rita Wilson

Madonna spouse Sean Penn Tom Hanks spouse Rita Wilson

W.E. director Madonna Then She Found Me director Helen Hunt

This Must Be the Place starring Sean Penn The Simpsons Movie starring Hank Azaria

Madonna spouse Sean Penn Helen Hunt spouse Hank Azaria

Table 6: Top-5 results for the query ”?m director ?x [Disney]; ?m starring ?y” with and without diversity.

No Diversity Term-based Diversity

Aladdin (1992 Disney ﬁlm) director John Musker Aladdin (1992 Disney ﬁlm) director John Musker

Aladdin (1992 Disney ﬁlm) starring Robin Williams Aladdin (1992 Disney ﬁlm) starring Robin Williams

Aladdin (1992 Disney ﬁlm) director Ron Clements 102 Dalmatians director Kevin Lima

Aladdin (1992 Disney ﬁlm) starring Robin Williams 102 Dalmatians starring Glenn Close

Aladdin (1992 Disney ﬁlm) director John Musker Cars 2 director John Lasseter

Aladdin (1992 Disney ﬁlm) starring Frank Welker Cars 2 starring Michael Caine

Aladdin (1992 Disney ﬁlm) director Ron Clements Leroy & Stitch director Tony Craig

Aladdin (1992 Disney ﬁlm) starring Frank Welker Leroy & Stitch starring Tara Strong

Aladdin (1992 Disney ﬁlm) director John Musker Snow White and the Seven Dwarfs director Wilfred Jackson

Aladdin (1992 Disney ﬁlm) starring Gilbert Gottfried Snow White and the Seven Dwarfs starring Pinto Colvig

Table 7: Top-5 results for the query ”?m distributor Columbia Pictures” with and without diversity.

No Diversity Text-based Diversity

Spider-Man 2 distributor Columbia Pictures Spider-Man 2 distributor Columbia Pictures

Close Encounters distributor Columbia Pictures Sharkboy & Lavagirl distributor Columbia Pictures

A Clockwork Orange distributor Columbia Pictures Jungle Menace distributor Columbia Pictures

Spider-Man 3 distributor Columbia Pictures Quantum of Solace distributor Columbia Pictures

Lawrence of Arabia distributor Columbia Pictures The Da Vinci Code distributor Columbia Pictures

diversiﬁed set of results, we have one popular Disney

movie, Aladdin, that is repeated ﬁve times. On the

other hand, the diversiﬁed set of results contains ﬁve

different Disney movies. Note that, if we had used the

resource-based diversity notion to diversify the results

of this query, we would have ended up with 5 dif-

ferent movies which would not have been necessarily

Disney movies.

Text-based Diversity. Consider one of the test

queries: ”?m distributor Columbia

Pictures”. The

corresponding information need is: ”Give me the

name of a ﬁlm distributed by the Columbia Pictures

company”. The top-5 results for both no diversity, and

diversity notion 3 with the diversity parameter λ set

to 0.1 are shown in Table 7. While the non-diversiﬁed

set contains different movies, these movies in fact are

not very diverse. Unlike the non-diversiﬁed set, the

diversiﬁed set of results contains movies that have to-

tally different genres, locations, casts, and plots. This

indirect level of diversity cannotbe captured using our

ﬁrst two diversity notions.

7 CONCLUSION

In this paper, we proposed a framework to diversify

the results of triple-pattern queries over RDF datasets.

We provided the ﬁrst formal deﬁnition of result diver-

sity in the context of RDF search based on three dif-

ferent notions. We also developed the ﬁrst diversity-

aware ranking model for RDF search, which is based

on the Maximal Marginal Relevance. Finally, we de-

signed a new diversity-aware evaluation metric for

RDF search based on the Discounted Cummulative

Gain and used it on a benchmark of 100 queries over

Result Diversity for RDF Search

255

DBPedia. Our experimental evaluation highlights the

importance of result diversity in the context of RDF

search and the ﬂexibility of our approach and no-

tions of diversity in capturing different aspects of user

queries.

In future work, we plan to carry out more exper-

iments on other RDF datasets to further validate our

results. We also plan to explore other notions of diver-

sity such as an ontology-based diversity notion where

results can be diversiﬁed based on resource types for

instance. Finally, we plan to study other relevance

measures and to investigate other metrics for comput-

ing result diversity instead of the language modeling

approach we adopted in this paper.

ACKNOWLEDGEMENT

We would like to thank the American University of

Beirut’s research board (URB) for funding our re-

search.

REFERENCES

Agrawal, R., Gollapudi, S., Halverson, A., and Ieong, S.

(2009). Diversifying search results. In Proceedings

of the Second ACM International Conference on Web

Search and Data Mining, WSDM ’09, pages 5–14,

New York, NY, USA. ACM.

Allan, J., Wade, C., and Bolivar, A. (2003). Retrieval and

novelty detection at the sentence level. In SIGIR,

pages 314–321.

Auer, S., Bizer, C., Cyganiak, R., Kobilarov, G., Lehmann,

J., and Ives, Z. (2007). Dbpedia: A nucleus for a web

of open data. In ISWC/ASWC.

Carbonell, J. and Goldstein, J. (1998). The use of mmr,

diversity-based reranking for reordering documents

and producing summaries. In SIGIR.

Chaudhuri, S., Das, G., Hristidis, V., and Weikum, G.

(2006). Probabilistic information retrieval approach

for ranking of database query results. SIGMOD

Record, 35(4).

Chen, H. and Karger, D. R. (2006). Less is more: prob-

abilistic models for retrieving fewer relevant docu-

ments. In Proceedings of the 29th annual interna-

tional ACM SIGIR conference on Research and de-

velopment in information retrieval, SIGIR ’06, pages

429–436, New York, NY, USA. ACM.

Chen, Z. and Li, T. (2007). Addressing diverse user prefer-

ences in SQL-query-result navigation. In Proceedings

of the 2007 ACM SIGMOD international conference

on Management of data, SIGMOD ’07, pages 641–

652, New York, NY, USA. ACM.

Clarke, C. L., Kolla, M., Cormack, G. V., Vechtomova, O.,

Ashkan, A., B¨uttcher, S., and MacKinnon, I. (2008).

Novelty and diversity in information retrieval evalua-

tion. In Proceedings of the 31st annual international

ACM SIGIR conference on Research and development

in information retrieval, SIGIR ’08, pages 659–666,

New York, NY, USA. ACM.

Dali, L., Fortuna, B., Tran Duc, T., and Mladenic, D.

(2012). Query-independent learning to rank for rdf

entity search. In ESWC, pages 484–498.

Elbassuoni, S., Ramanath, M., Schenkel, R., Sydow, M.,

and Weikum, G. (2009). Language-model-based rank-

ing for queries on RDF-graphs. In CIKM.

Fleiss, J. L. (1971). Measuring nominal scale agreement

among many raters. Psychological Bulletin, 76(5):378

– 382.

Gollapudi, S. and Sharma, A. (2009). An axiomatic ap-

proach for result diversiﬁcation. In Proceedings of

the 18th international conference on World wide web,

WWW ’09, pages 381–390, New York, NY, USA.

ACM.

Jrvelin, K. and Keklinen, J. (2002). Cumulated gain-based

evaluation of ir techniques. ACM Transactions on In-

formation Systems (TOIS), pages 422–446.

Kasneci, G., Suchanek, F. M., Ifrim, G., Ramanath, M., and

Weikum, G. (2008). Naga: Searching and ranking

knowledge. In ICDE.

Lin., J. (1991). Divergence measures based on the shannon

entropy. IEEE Transactions on Information Theory,

pages 145–151.

RDF (2004). W3c: Resource description framework (rdf).

www.w3.org/RDF/.

SPARQL (2008). W3c: Sparql query language for rdf.

www.w3.org/TR/rdf-sparql-query/.

Suchanek, F. M., Kasneci, G., and Weikum, G. (2008).

Yago: A large ontology from wikipedia and wordnet.

J. Web Sem., 6(3).

Vee, E., Srivastava, U., Shanmugasundaram, J., Bhat, P.,

and Yahia, S. A. (2008). Efﬁcient Computation of Di-

verse Query Results. In Proceedings of the 2008 IEEE

24th International Conference on Data Engineering,

pages 228–236, Washington, DC, USA. IEEE Com-

puter Society.

Zhai, C. X., Cohen, W. W., and Lafferty, J. (2003). Be-

yond independent relevance: methods and evaluation

metrics for subtopic retrieval. In Proceedings of the

26th annual international ACM SIGIR conference on

Research and development in informaion retrieval, SI-

GIR ’03, pages 10–17, New York, NY, USA. ACM.

KDIR 2016 - 8th International Conference on Knowledge Discovery and Information Retrieval

256
