Web-based Fingerprinting Techniques

ıtor Bernardo and Dulce Domingos

LaSIGE, Faculdade de Ci

encias, Universidade de Lisboa, Lisboa, Portugal

Keywords:

Browser Fingerprinting, Cross-browser Fingerprinting, Device Fingerprinting, Privacy, Fingerprint.

Abstract:

The concept of device ﬁngerprinting is based in the assumption that each electronic device holds a unique set

of physical and/or logical features that others can capture and use to differentiate it from the whole. Web-based

ﬁngerprinting, a particular case of device ﬁngerprinting, allows website owners to differentiate devices based

on the set of information that browsers transmit. Depending on the techniques being used, a website can track

a device based on its browser features (browser ﬁngerprinting) or based on system settings (cross-browser

ﬁngerprinting). The latter allows identiﬁcation of the device even when more than one browser is used.

Several different works have introduced new techniques over the last years proving that ﬁngerprinting can be

done in multiple ways, but there is not a consolidated work gathering all of them. The current work identiﬁes

known web-based ﬁngerprinting techniques, categorizing them as which ones are browser and which are

cross-browser and showing real examples of the data that can be captured with each technique. The study is

synthesized in a taxonomy, which provides a clear separation between techniques, making it easier to identify

the threats to security and privacy inherent to each one.

1 INTRODUCTION

Device ﬁngerprinting is based on the assumption that

no two devices are exactly alike and that proﬁles can

be created by capturing the emanation patterns sent

or leaked from the devices, as long as these extern-

alizations

are repetitive through time. Small phys-

ical differences in the components of the devices, that

were introduced during the manufacturing process,

may result in slightly different behaviours and extern-

alizations, which could be captured and used to create

a ﬁngerprint (Jenkins et al., 2014). Other examples of

ﬁngerprinting could be the tracking of clock deviation

between the internal clock of a client’s device and the

clock of a server (Kohno et al., 2005) or the collection

of the set of fonts and browser plugins installed on a

system (Eckersley, 2010).

Web-based ﬁngerprinting, a particular case of

device ﬁngerprinting, allows a website owner to track

devices’ accesses throughout time, in an almost invis-

ible way. In fact, even if the user is aware of privacy

issues and takes precautions, whether by actively de-

leting cookies, blocking all cookies or using a browser

in “private mode”, his device will still be ﬁngerprint-

able. This makes the use of web-based ﬁngerprinting

The expression “externalization” refers to any display of

activity emanating from a certain device.

far more upsetting than simple cookies.

In most cases, web-based ﬁngerprinting is used to

track users activity in sites and bind a device ﬁnger-

print to a user proﬁle (together with its preferences,

tastes and interests). The interest of advertising com-

panies in this kind of information is foreseeable, as

it allows them to adjust the publicity to the users in-

terests.

Indeed, in 2014, the Article 29 Data Protection

Working Party, a European Union advisor on data pro-

tection, stated that: ” (...) ﬁngerprint provides the

ability to distinguish one device from another and can

be used as a covert alternative for cookies to track in-

ternet behaviour over time. As a result, an individual

may be associated, and therefore identiﬁed, or made

identiﬁable, by that device ﬁngerprint. (...) The data

protection risks of device ﬁngerprinting are increased

by the fact that the unique set of information elements

is not only available to the website publisher, but also

to many other third parties.” (Article 29 Data Protec-

tion Working Party, 2014) (p. 6).

Web-based ﬁngerprinting relies in capability to

collect information about the device’s operating sys-

tem (OS) properties, installed software, and other lo-

gical conﬁgurations to get a unique signature from the

device - rather than trying to infer patterns from the

behaviour of the equipment, such as the “hardware-

Bernardo, V. and Domingos, D.

Web-based Fingerprinting Techniques.

DOI: 10.5220/0005965602710282

In Proceedings of the 13th International Joint Conference on e-Business and Telecommunications (ICETE 2016) - Volume 4: SECRYPT, pages 271-282

ISBN: 978-989-758-196-0

271

based” device ﬁngerprinting approach would. Web-

based ﬁngerprinting does not require special equip-

ment or a speciﬁc scenario to be put into practise.

Two different approaches can be taken regarding

the type of client-side features that will be processed

to extract a signature: browser or cross-browser ﬁn-

gerprinting. Browser ﬁngerprinting relies on the dis-

tinctive features of the client browser and/or OS and

its purpose is to create a unique signature based on

the information collected from the pair (browser, OS).

Cross-browser ﬁngerprinting, on the other hand, is

based only in non-browser features, what makes it re-

silient to the use of multiple browsers by the same

device. This approach requires system settings to be

collected such as, OS version, CPU information, net-

work interfaces information, number of processors,

screen size, etc.

The next section describes how web-based ﬁnger-

printing works. Section 3 depicts the most promin-

ent works addressing web-based ﬁngerprinting tech-

niques. The bulk of the document is focused in the

analysis of the techniques (section 4), together with

the results of the tests using different browsers. The

taxonomy of web-based ﬁngerprinting techniques can

be found at the end of this section. Finally, section 5

concludes the paper, discussing the threats to security

and privacy inherent to web-based ﬁngerprinting and

possible mitigations.

2 HOW WEB-BASED

FINGERPRINTING WORKS

In a typical web-based ﬁngerprinting scenario, the cli-

ent’s browser requests the webpage code to the server

(through an HTTP request), in order to render it for

the user. Within this request, some ﬁngerprinting in-

formation from the user’s system can already be col-

lected, namely the information that is sent in the User-

Agent - the HTTP header ﬁeld that the most popular

browsers use to indicate the browser and OS versions.

In the HTTP response, the web server can include de

client-side ﬁngerprinting script. Most ﬁngerprinting

techniques are based in client-side code execution be-

cause this type of technology allows the browser to

make direct calls to the OS or other machine conﬁg-

urations and to send that data back to the webserver

asynchronously (without interfering with the display

and behaviour of the existing page).

After the browser has processed the script and

sent the result to the web server, the later computes

a unique identiﬁer based on the information received

and stores it in a database - this will be the ﬁngerprint

for this user’s device. Although this identiﬁer could

be seen as a simple hash of the device’s properties,

this would soon prove to be a simplistic approach as

it would render the ﬁngerprint useless at the slightest

change in the client’s environment. A better approach

would be to store an array of the device’s properties.

From this moment on, the website owner can track

that device throughout the pages it visits, without the

use of cookies, as long as they all contain the ﬁnger-

printing script.

It is important to note that the tracking can be done

among different sites or domains, as long as all the

websites share the same ﬁngerprinting database.

In a different model of ﬁngerprinting, the agent

doing the tracking might not be the website provider

but a third-party agent. This scenario is described

in (Nikiforakis et al., 2013). A site owner can agree

with an advertisement company the deployment of a

content from the later in the webpage, which visitors

will retrieve unknowingly, containing a ﬁngerprint-

ing script. This version presents a more disturbing

scenario: the ﬁngerprinting agent can track users on

multiple third-party websites, as long as the site own-

ers agree to include the advertisement. This allows a

more intrusive proﬁling of the web users as different

kinds of websites (with different subjects) provide a

richer view of the individual.

3 RELATED WORK

As far as we are aware, (Mayer, 2009) was the ﬁrst au-

thor to present a ﬁngerprint based on browser plugins

and mime-types. (Eckersley, 2010) also discusses

these techniques and introduces other cross-browser

approaches, such as font detection and OS features.

This work paved the way for web-based ﬁngerprinting

and was the basis for the creation of Electronic Fron-

tier Foundation’s tracking awareness website, Panop-

ticlick

Fingerprinting based on HTTP Header Fields is

one of the most explored techniques and (Eckersley,

2010), as well as (Mowery et al., 2011), (Nikifora-

kis et al., 2013), and (Acar et al., 2013) discuss this

technique.

The study that (Nikiforakis et al., 2013) present is

the one that shares most resemblance with the present

work. It describes some of the practices of device

identiﬁcation through web-based ﬁngerprinting tech-

niques available by then and measures the adoption of

ﬁngerprinting on the web. The authors also present a

taxonomy for the ﬁngerprinting techniques found in

“three large, commercial companies” along with Pan-

Available at https://panopticlick.eff.org

SECRYPT 2016 - International Conference on Security and Cryptography

272

opticlick. Although very enlightening, the study is

limited to the techniques that the three software man-

ufacturers and the Panopticlick website used at the

time. Therefore, other techniques, such as HTML5

canvas ﬁngerprinting or exploitation of DNS leaks,

are not covered.

(Khademi et al., 2015) show the effectiveness of

some of the techniques depicted in the current work,

by implementing a web-based hybrid ﬁngerprinting

tool: Fybrid.

Focusing on mitigation techniques, (Nikiforakis

et al., 2015) propose a tailored browser (PriVaricator)

which makes every visit appear different to a ﬁnger-

printing site, resulting in a different ﬁngerprint for

each visit. We also discuss mitigation techniques in

section 5.

4 TECHNIQUES FOR WEB-

-BASED FINGERPRINTING

This section describes our study on web-based ﬁnger-

printing techniques. The analysed techniques were

gathered from multiple sources, ranging from pub-

lished papers to websites used with a ﬁngerprinting

purpose - mostly, websites that show how web-based

ﬁngerprinting is possible. These sources are refer-

enced along this section.

In our tests, we used different browsers: Moz-

illa Firefox 38.0.1; Microsoft Internet Explorer

10.0.9200.17357 (MS IE); Google Chrome ver.

43.0.2357.81 m; Opera/9.80 (Windows NT 6.2;

WOW64) Presto/2.12.388 Version/12.17; QtWeb In-

ternet Browser 3.8.5 (build 108); Midori 0.5.10 and

Chromium Portable version 44.0.2383.0.

After analysing the techniques, our results in a

taxonomy are synthesized in a taxonomy.

4.1 IP Address

The use of network mechanisms that changes the

user’s external IP address (e.g. NAT systems or

proxies) makes this information unreliable for track-

ing purposes. Still, while not providing enough

information to create a ﬁngerprint, the IP address

can help adjusting and completing other methods of

ﬁngerprinting. IP addresses are sent in the Internet

Layer of the TCP/IP model so, in theory, the website

always receives this information. The collection of

the IP addresses provides information to perform

cross-browser ﬁngerprinting.

Advantages: The IP address of the originator is sent

for every HTTP request without requiring any special

scripting from the website owner.

Disadvantages: With the widespread use of NAT, the

tracking of a device through its IP address became

unfeasible. Moreover, the ever-growing use of TOR

networks and IP spooﬁng methods demands caution

when associating an IP address to a device.

This technique has two variations that are de-

scribed next.

a) Local IP Address (IPv4): The website

IPLeak.net

allows checking if the client browser

uses the WebRTC API. WebRTC is a browser-to-

browser application for voice calling, video chat,

and P2P ﬁle sharing. WebRTC implements STUN

(Session Traversal Utilities for Nat)

, a network

protocol that allows an end host to discover the public

IP address even when it is located behind a NAT.

With information about the client’s local IP address,

it is possible to verify if two different signatures

with the same external IP address correspond to two

different devices behind a NAT.

Advantages: Allows to distinguish different devices

behind a NAT.

Disadvantages: Some browsers lack the native

support of WebRTC, what makes them resilient to

this technique. At the time of writing, Microsoft’s

Internet Explorer was one of them.

b) DNS Leaks: When a DNS request is made to

the default DNS servers (usually belonging to the

internet service provider), instead of the anonymous

DNS servers assigned by the anonymity network, it

is considered a “DNS leak”. In this technique, the

website generates a certain number of non-existent

second level domain names and includes them in the

code of the requested page. When the client browser

ﬁnds the references to these domains in the page

code it tries to resolve them, by querying its DNS

servers. The DNS servers, in turn, will not have any

cached registry for those domains (because they do

not exist), so they will request for addresses to the

domain authority. Once the DNS servers detect the

call to the fake domains they forward the requests to

the ﬁngerprinter, together with the names of the DNS

servers requesting them. Then, the ﬁngerprinter can

correlate the faux domains with the IP address that

requested the page, and associate an array of DNS

servers to that proﬁle.

Advantages: The data collection does not rely on any

scripting, making it more effective.

Available at https://ipleak.net

See http://www.voip-info.org/wiki/view/STUN

Web-based Fingerprinting Techniques

273

Disadvantages: Requires access to the domain au-

thority DNS servers.

4.2 HTTP Request Header Fields

The HTTP protocol speciﬁcation describes a series of

request header ﬁelds (Fielding and Reschke, 2014).

Because HTTP header ﬁelds are a well-known source

of information, many authors have mentioned them

in their works ((Eckersley, 2010), (Nikiforakis et al.,

2013), (Acar et al., 2013), (Mowery et al., 2011)).

Next, we describe four of the HTTP Header ﬁelds

that are used to gather information about the client’s

system. Advantages and disadvantages are presented

in the end of the subsection, as all of them share the

same features.

a) Accept Field: This ﬁeld allows the browser to

inform the server about the Content-Types that are

acceptable for the response - the media types that

the browser understands and how well it understands

them. This ﬁeld provides browser related informa-

tion and can contribute to the browser ﬁngerprinting.

Table 1 shows the values sent by 3 different browsers.

Table 1: Three different Accept ﬁeld values.

Browser Accept value

Mozilla

Firefox

text/html, application/xhtml+xml, applica-

tion/xml;q=0.9,*/*;q=0.8

Google

Chrome

text/html, application/xhtml+xml, applica-

tion/xml;q=0.9, image/webp, */*;q=0.8

MS IE text/html, application/xhtml+xml, */*

b) Accept-Encoding Field: Compliant browsers

should announce to the server what methods they sup-

port before downloading the correct format. This ﬁeld

provides browser related information and can contrib-

ute to the browser ﬁngerprinting. Table 2 shows 3

possible values for this ﬁeld.

Table 2: Three different Accept-Encoding ﬁeld values.

Browser Accept-Encoding value

Mozilla Firefox gzip, deﬂate

Google Chrome gzip, deﬂate, sdch

QtWeb gzip

c) Accept-Language Field: A webpage might have

the same content available in several languages. The

language can be selected automatically by the server,

based on the preference indicated in this ﬁeld. This

property also contributes to browser ﬁngerprinting.

Table 3 shows 3 different values for the Accept-

Language ﬁeld.

Table 3: Three different Accept-Language ﬁeld values.

Browser Accept-Language value

QtWeb pt-PT,en,*

Google Chrome en-US,en;q=0.8

MS IE pt-PT,pt;q=0.8,en-GB;q=0.5,en;q=0.

d) User-Agent Field: This ﬁeld can provide speciﬁc

information about the browser brand and version. It

also allows inferring the type of OS, which makes it

useful for browser ﬁngerprinting and cross-browser

ﬁngerprinting at the same time. Table 4 shows 3 dif-

ferent possible values for this ﬁeld.

Table 4: Three different User-Agent ﬁeld values.

Browser User-Agent value

Mozilla

Firefox

Mozilla/5.0 (Windows NT 6.2; WOW64;

rv:38.0) Gecko/20100101 Firefox/38.0

MS IE Mozilla/5.0 (compatible; MSIE 10.0; Win-

dows NT 6.2; WOW64; Trident/6.0)

Google

Chrome

Mozilla/5.0 (Windows NT 6.2; WOW64)

AppleWebKit/537.36 (KHTML, like Gecko)

Chrome/43.0.2357.81 Safari/537.36

Advantages: The biggest advantage of using HTTP

headers is that every incoming request contains a set

of them, making it easier for the webserver to col-

lect the information. Therefore, no client-scripting is

needed.

Disadvantages: The HTTP ﬁelds do not provide

enough diversity to create a unique signature. This

technique must always be used complementary to oth-

ers. Moreover, a user with a customized browser

could clean or modify the header ﬁles, affecting the

ﬁngerprinting.

4.3 Browser Properties

System settings such as the type of contents sup-

ported by the browser, the local clock time or the

client’s system default language can be externalized

by the browser software. We discuss advantages and

disadvantages in the end of this subsection, as they

are common for both techniques.

a) Plugin and Mime-type Enumeration: When a

website needs to query if a certain plugin exists in the

clients system, to properly display/run some type of

content, it can retrieve an array of plugins by access-

ing to JavaScript’s navigator.plugins. This tech-

nique is described in the following works: (Eckersley,

2010), (Nikiforakis et al., 2015), (Acar et al., 2013)

and (Mayer, 2009).

This information can be used for both browser ﬁn-

gerprinting and cross-browser ﬁngerprinting.

SECRYPT 2016 - International Conference on Security and Cryptography

274

An example of the information we can get with

this technique is: Plugin 0: Adobe Acrobat; Plugin 2:

Google Update; Plugin 3: Java Deployment Toolkit

7.0.450.18.

b) Do-Not-Track: The Do-Not-Track header was a

proposed HTTP header ﬁeld (DNT) with the object-

ive of increasing the privacy of the webpage users.

The header contains a ﬂag that indicates whether the

client is willing to be tracked across websites. Unfor-

tunately, the browser user has no control over whether

the request is honoured or not, so the effectiveness of

this measure is arguable.

The Do-Not-Track header can be retrieved us-

ing the JavaScript language and calling the value

navigator.doNotTrack.

(Mayer and Mitchell, 2012), (Acar et al., 2013)

and (Nikiforakis et al., 2013) mentioned the Do-Not-

Track header and agreed that its usefulness is ques-

tionable, at best. Because it produces slightly differ-

ent answers across browsers (see Table 5 below), this

technique can add diversity to the browser ﬁngerprint-

ing.

Table 5: Three different Do-Not-Track ﬁeld values.

Browser Do-Not-Track

Mozilla Firefox unspeciﬁed

MS IE undeﬁned

Google Chrome null

Advantages: The retrieval of the browser’s properties

provides an extensive list of browser related informa-

tion, including plugin versions, which adds diversity

to the proﬁling process.

Disadvantages: The browser plugins are pieces of

software that can be removed or updated (to new ver-

sions). The creation of a signature should not rely

on a simple hash of the plugin list, or else the ﬁn-

gerprint would be rendered useless right after the ﬁrst

plugin update. Also, browsers react differently to the

navigator.plugins request.

4.4 Browser Behaviour

Browser vendors are free to include their own logic

in the code that is embodied in their software. This

means that, the outcome of a certain operation

when performed by two different browsers might

be the same, although their underlying mechanisms

are different. In this section we describe different

browser behaviour techniques.

a) Browser Rounding and Fractional Pixels: The

way that different browser handle math calculations,

and rounding in particular, can be used to identify the

client’s browser and contribute to the ﬁngerprinting

process.

The webpage “Browser Rounding and Fractional

Pixels”

contains a test page where users can test

their browser’s behaviour. The site calculates per-

centages of decimal values for multiple graphic boxes

with fractional pixels. Being a browser benchmark-

ing technique, this approach can contribute to per-

form browser ﬁngerprinting. The different results for

browser rounding and fractional pixels of an element

(Box2) are shown in Table 6.

Table 6: Three different results for browser rounding and

fractional pixels.

Browser Calculated width for Box2

Mozilla Firefox 666.8499755859375px

MS IE 667px

Google Chrome 666.859375px

Advantages: Unlike other browser behaviour-related

approaches that are affected by the system usage

at a given time (e.g. CPU load or allocated RAM

memory), this technique is unaffected by such

constraints.

Disadvantages: This approach is not enough to

create a unique signature. At most, it can help

identifying the browser, but it requires a comparison

database to relate the measured patterns with the

browsers’ brands and models.

b) Canvas Fingerprinting: The canvas ﬁngerprint-

ing technique applies a principle similar to the previ-

ously shown: the rendering of a graphical object by

different systems (browsers) produces different out-

put, and therefore different ﬁngerprints. (Mowery

and Shacham, 2012) show that the rendering of fonts

and graphical elements have slight variations between

different browsers, what allows the extraction of an

individual signature.

In their study about canvas ﬁngerprinting and

evercookie feasibility, (Acar et al., 2014) crawled the

Top Alexa 100,000 sites and found that “more than

5.5% of crawled sites actively ran canvas ﬁngerprint-

ing scripts on their home pages.”

The website BrowserLeaks.com

provides a page

to test canvas ﬁngerprinting, but warns that the com-

parison database, used for matching the incoming sig-

natures, is not complete enough to provide a complete

coverage of the whole universe of browsers and does

not collect new signatures.

Available at http://cruft.io/posts/percentage-calculations-

in-ie

Available at https://www.browserleaks.com/

Web-based Fingerprinting Techniques

275

This technique can contribute to perform browser

ﬁngerprinting. The results of a test with 3 different

browsers can be seen in Table 7.

Table 7: Three different browser signatures built from can-

vas ﬁngerprinting.

Browser Signature Website general conclusion

Mozilla

Firefox

5525E5D4 “It is very likely that you are us-

ing [Firefox] on [Windows]”

MS IE 62939B59 “It is very likely that you are us-

ing [Internet Explorer] on [Win-

dows]”

Google

Chrome

F921F32B “Your system ﬁngerprint appears

to be unique (...)”

Advantages: Similarly to “Browser rounding and

fractional pixels”, this technique is not affected by

the computing workload at the moment of the data

collection.

Disadvantages: The technique is only reliable when

backed up by a database that maps the whole browser

signature universe and that is constantly collecting

new signatures in order to be updated.

c) Browser Performances: (Mowery et al., 2011)

presents a technique for measuring timing differences

of multiple operations in the core of the JavaScript

language, which can contribute to perform browser

ﬁngerprinting. According to the authors, it would

be possible to distinguish not only browser versions

but also micro architectural features not normally ex-

posed to JavaScript.

The results retrieved from the website V8 Bench-

mark Suite

can be seen in Table 8.

Table 8: Example of JavaScript Performance Benchmarking

for the Mozilla Firefox browser, retrieved from the website

V8 Benchmark Suite.

Benchmarking

script

Test#1

score

Test#2

score

Test#3

score

Test#4

score

Richards 5790 6023 6051 5871

DeltaBlue 10731 20556 13052 1950

Crypto 4957 4556 7585 4404

Advantages: Does not rely on information that is

communicated by the browser. It rather observes the

behaviour and registers the results. This makes the job

harder for those trying to develop anti-ﬁngerprinting

browsers, because the simple mitigation of the data

sent is not enough to protect against this technique.

Disadvantages: The performance information col-

lected from the user’s system is highly dependable on

Available at http://v8.googlecode.com/svn/data/ bench-

marks/v7/run.html

the processing being done at that moment and, there-

fore, different tests might show large discrepancies in

the time values. On other hand, the authors of this

work agree that ” [o]ne of the largest weaknesses in

[the] approach is that the ﬁngerprinting time is very

large - usually over 3 minutes ” (p. 3). In fact, while

the tests are being performed, the whole client system

is affected by a sudden degradation of performance,

mostly noticed by the browser’s lack of responsivity.

This undermines any possibility of using this tech-

nique on a stealthy way.

4.5 Operating System Features

System related settings, such as the OS version, the

amount of available RAM or the current system time

are features that can also be retrieved to create cross-

browser ﬁngerprints.

Java and Flash plugins are known to access

system settings in a fashion that is not totally privacy-

friendly, as they bypass the browser’s controls. The

TorProject team (developers of the Tor Browser),

for instance, warns their users about the threats to

anonymity associated with the use of Java and Flash

plugin.

. The collection of OS related information

using these technologies is mentioned by (Eckersley,

2010) and (Nikiforakis et al., 2013), although not

extensively debated. The universe of information

possible to retrieve from the system with the Java

technology is signiﬁcantly greater than the one

provided by Flash.

a) Using Flash Plugin: The online ActionScript 3.0

Reference for Adobe Flash Platform website

informs

that “[t]he Capabilities class provides properties that

describe the system and runtime that are hosting the

application. (...) By using the Capabilities class to

determine what capabilities the client has, you can

provide appropriate content to as many users as pos-

sible”.

The data collection through the Flash plugin al-

lows browser ﬁngerprinting and cross-browser ﬁnger-

printing, because there is plugin-related information

(browser conﬁguration) and system information be-

ing retrieved. Table 9 shows a subset of the results

retrieved from the site BrowserLeaks.com

b) Using Java: The Java plugin can provide informa-

tion about the local Java Virtual Machine (JVM). This

technique provides system-related information, there-

fore allowing to perform cross-browser ﬁngerprint-

Available at https://www.torproject.org/docs/faq.html.en

Available at http://help.adobe.com/en US/FlashPlatform/

reference/actionscript/3/index.html

Available at http://https://www.browserleaks.com

SECRYPT 2016 - International Conference on Security and Cryptography

276

Table 9: Information retrieved from the website Browser-

Leaks.com for the Mozilla Firefox and Google Chrome.

Plugin info Mozilla Firefox Google Chrome

Flash

Version

Shockwave Flash

17.0 r0

Shockwave Flash

18.0 r0

Plugin

ﬁlename

NPSWF32

17 0 0 188.dll

pepﬂashplayer.dll

ing. Table 10 shows a subset of the Java plugin data

retrieved from the website BrowserLeaks.com, for the

browsers Internet Explorer and Midori.

Table 10: Information retrieved from the website Browser-

Leaks.com for the Internet Explorer and Midori browsers.

JVM info MS IE Midori

JVM Uptime 1999278 1871881

JVM Start Time 1435274207429 1435274336050

Compilation Time 334 285

Advantages: This technique provides a fair amount

of system-related information that is collected by the

plugins, via API calls to the OS. Java plugin returns

the information it reads from the JVM which, by

default, is common to all Java-dependable software

on a particular system.

Disadvantages: The approach using Java is the

one that provides the most verbose information

(i.e. actual system data, instead of Flash’s Boolean

properties), making it more suitable for creating

a system signature. However, because nowadays

most of the browsers are currently prompting users

about whether they are sure to run Java Applets, it

is difﬁcult to collect this information in a stealthy

fashion.

c) Clock Skew: (Kohno et al., 2005) suggested

the ﬁngerprinting of devices through comparison of

the clock skew between the client system and the

server clock. According to the authors, it would

be possible to exploit deviations in clock skews

“even when the measurer is thousands of miles,

multiple hops, and tens of milliseconds away from

the ﬁngerprinted device, and when the ﬁngerprinted

device is connected to the Internet from different

locations” (p. 1). The authors stressed that “one

can use [the] TCP timestamps-based method even

when the ﬁngerprintee’s system time is maintained

via NTP”. This technique allows to perform cross-

browser ﬁngerprinting.

Advantages: This technique allows the identiﬁcation

of different devices behind a NAT and even the detec-

tion of virtual honeynets (the performed test showed

that virtual machines did not have constant, or near

constant, clock skews).

Disadvantages: The measuring duration of the tests

showed in the work of (Kohno et al., 2005) range

up to 120 minutes which is a rather high expectancy

time for a user to be browsing on a certain domain.

Moreover, the authors show the limitations of this

technique when they state that the technique does “not

provide unique serial numbers for devices, but (...)

skew estimates”.

4.6 Hardware Features

Browsers can access hardware settings, such as the

screen resolution, number of CPU cores, the amount

of dedicated memory or the identiﬁcation of network

interfaces. Although the combination of the above

settings is far from being able to provide a unique

set, once combined with browser settings and other

ﬁngerprinting methods they can contribute to the

creation of a unique signature.

a) Screen Properties: The retrieval of the screen

properties is possible to achieve through JavaScript or

Flash. The use of JavaScript’s window.screen ob-

ject allows the retrieval of basic information about

the screen of the client. It is possible to gather in-

formation about screen height (in pixels), width, and

bit depth of the colour palette available for displaying

images. This type of data collection was addressed

in (Acar et al., 2013) with the use of a ﬁngerprinting

detector, the FPDetective.

An example of screen properties can be seen in

Table 11, taken from the website BrowserLeaks.com.

Table 11: Screen properties for three different browsers,

taken from the website BrowserLeaks.com.

Property Mozilla Firefox Midori QtWeb

availHeight 860 900 860

colorDepth 24 24 32

pixelDepth 24 24 32

Advantages: The collection of screen size values

allows the ﬁngerprinter to infer if the client’s device

is a smartphone, a tablet or a two-screen desktop

computer (the widths of both screens would be

added).

Disadvantages: As shown in the example, cau-

tion must be taken when processing these values.

Different browser implementations can change

the measuring rules, therefore producing different

signatures and jeopardizing any cross-browser ﬁnger-

printing attempt.

b) CPU and RAM Memory: The Java technology

Web-based Fingerprinting Techniques

277

allows to retrieve information about the number of

available processors, and the amount of free, max and

total RAM memory. Browsers showed different beha-

viour for this data retrieval: while Internet Explorer,

Mozilla Firefox and Midori provided the requested in-

formation, others returned no data at all. This tech-

nique contributes to cross-browser ﬁngerprinting, as

Java accesses OS interfaces.

Table 12 shows the different values for CPU and

RAM settings retrieved using a Java plugin with the

Internet Explorer and the Mozilla Firefox browsers.

Table 12: Examples of different results for (same) CPU and

RAM settings.

CPU and

RAM

Internet

Explorer

Mozilla

Firefox

Free Memory 8.135.728 10.363.232

Max Memory 259.522.560 259.522.560

Total Memory 16.252.928 16.384.000

Advantages: This technique provides very speciﬁc

system-related information that might help charac-

terize the type of web user (e.g. a tuned up system

might indicate a gamer or a graphics designer), which

might be interesting information for website owners

or advertisers.

Disadvantages: Properties like “Free memory” or

“Total memory” should not be relied upon, as they

are not consistent.

c) Network Interfaces Enumeration: Java enables

the retrieval of the name and status of physical and

virtual networks. Among the type of information re-

turned is the name of the interface, the status (i.e. if

the interface is enabled or not), the Maximum Trans-

mission Unit (MTU), if it is point-to-point, if it sup-

ports multicast, if it is loopback, and if the interface is

virtual.

The information retrieved with this technique

is system-related, therefore it is suitable for cross-

browser ﬁngerprinting. Table 13 presents one ex-

ample of the 106 network interfaces retrieved from

BrowserLeaks.com

Table 13: One of the 106 network interfaces retrieved from

the website BrowserLeaks.com for the Internet Explorer

browser.

VMware Virtual Ethernet Adapter for VMnet8

Interface Is Up MTU Point-To-Point Multicast

eth41 true 1500 false true

Advantages: This technique is able to quickly

identify if the device being used at the current time

is the same used before. This feature can have prac-

tical application in situations where a website wants

to make sure that the user that signs in using a differ-

ent hardware from the usual is, in fact, the real user.

In case of an incoming new signature, the website can

prompt the user with a security question or request a

multi-channel authentication.

Disadvantages: The hardware’s collectable informa-

tion is slim and there is not enough diversity in order

to build a unique signature. Therefore, ﬁngerprinting

by collection of hardware features must rely on addi-

tional techniques in order to be effective.

4.7 Font Detection/Enumeration

Different OSs have their own font sets. On top of that,

software suites such as Microsoft Ofﬁce or Adobe

Creative Suite usually add their own set of fonts to the

system. Additionally, users can add their own fonts to

the system, as well. The resulting set of fonts can be

diverse enough to build a signature or, at least, allow

the identiﬁcation of the OS. (Boda et al., 2012) show

how the universe of fonts is affected by the installation

of Ofﬁce and Adobe suites. Fingerprinting by font

enumeration is mentioned in the works of (Eckers-

ley, 2010), (Nikiforakis et al., 2013), and (Acar et al.,

2013), making this one of the most commonly men-

tioned ﬁngerprinting techniques, together with plugin

detection. Fonts can be enumerated using JavaScript,

Flash, Silverlight or Java, with different levels of efﬁ-

ciency.

Because system fonts are managed at the OS

level, this technique allows to perform cross-browser

ﬁngerprinting. As stated in the website latit.lab

, the

font detection done through JavaScript and CSS takes

advantage of the fact that “each character appears

differently in different fonts. So different fonts will

take different width and height for the same string

of characters of same font-size”. By measuring the

output, the ﬁngerprinter is able to identify if the

rendered font is different from the fall back and, if

that case, resident in the system. Table 14 shows 3

different results for different browsers.

Table 14: Font detection performed by the website lalit.org

for three different browsers.

Browser JavaScript and CSS Flash

MS IE 276 of 512 font 276 fonts

Google Chrome 231 of 512 fonts 270 fonts

Opera 264 of 512 fonts 276 fonts

Advantages: The enumeration of fonts is, possibly,

the data collection technique that provides the biggest

Available at http://www.lalit.org/lab/javascript-css-font-

detect

SECRYPT 2016 - International Conference on Security and Cryptography

278

amount of data from the client’s system. Although

the list of font sets can change (e.g. fonts might be

actively added by the user or added because new soft-

ware was installed), the ﬁngerprinter can still ﬁnd this

risk negligible and decide to create a signature from

the list of fonts. OSs can also be inferred from the

font sets, as long as the ﬁngerprinter has a database

of speciﬁc OS featuring fonts. The same applies for

browsers.

Disadvantages: In order to perform the ﬁngerprint-

ing using JavaScript, a database of fonts is needed for

comparison. A complete identiﬁcation of the fonts

depends on having the most extensive database of

fonts possible, to encompass all fonts that might pos-

sibly appear.

4.8 Cached Objects

The technique of using stored objects on the client

side as a way to uniquely identify a device is fairly

similar across the technologies that have this ability:

ﬁrst the ﬁngerprinter checks the cached object holder

for the presence of any previous unique ID (stored

from a former visit). If no ID exists the website uses

the cached object to store a somewhat random but

unique ID that will allow further visits to be tracked

and linked to this device. Flash and HTML5 have

their own mechanisms for storing data, which are de-

scribed furthermore.

Strictly speaking, the exploitation of cached

content cannot be considered a ﬁngerprinting tech-

nique. After all, devices are not being identiﬁed by

a set of unique features but rather, by a distinctive

mark that has been previously etched in each one.

However, for the unique identiﬁer to be stored in the

system in the ﬁrst place, it was necessary to perform

a previous veriﬁcation of “non-existence” of that

device in the collected universe, which is, by itself, a

ﬁngerprinting-like processing.

a) HTTP Cache: The caching of webpage contents

allows to reduce bandwidth usage, waiting times

and server load. When requesting a resource it

has downloaded and stored previously, the client

browser indicates the version of the stored object and

asks the server if it should download a newer one.

An exploitation for this behaviour was described

in (Zalewski, 2012): if the server has the chance

to indicate the client’s browser that it should or not

replace a ﬁle already stored on its system, then it has

a certain degree of control over that ﬁle and can use

it as an ID for tracking purposes.

Advantages: Most browsers allow the storing of

objects by default, especially when used in mobile

devices, making this technique reliable for ﬁnger-

printers. Systems do this to reduce bandwidth usage

and to increase access speed, as stated before.

Disadvantages: Devices conﬁgured not to store

cache or to delete cached objects when the browser

session is over are not affected by this technique,

although those that allow the storing during session

could be tracked throughout that period.

b) Browsing History: The collection of the URLs

in the browser’s history is done by using the tech-

nique described in (Janc and Olejnik, 2010), which

allows “an attacker to determine if a particular URL

has been visited by a client’s browser through apply-

ing CSS styles distinguishing between visited and un-

visited links. (...) the attacker must supply the client

with a list of URLs to check and infer which links ex-

ist in the client’s history by examining the computed

CSS values on the client-side” (p. 4).

Because the creation of a signature of the brows-

ing history would be rather useless, the authors de-

cided to create “history proﬁles” (that act as ﬁnger-

prints), where URLs are categorized by website sub-

ject (e.g. Shopping, Entertainment, Travel, Vehicles,

etc.). In (Olejnik et al., 2012), the authors state that “a

large number of users have unique personal browsing

interests even when analysed using the more coarse-

grained category metric (...) In a real scenario of an

advertising provider, multiple repetitions of each cat-

egory in the proﬁles are likely used to enumerate the

strength of interest in the category which provides ad-

ditional information” (p. 9).

This test was performed in a universe of 368.284

web histories, and more than 69% of users had a

unique ﬁngerprint. This technique can contribute to

browser ﬁngerprinting.

Advantages: This technique is a very appealing ap-

proach for advertisers, as they get more information

with less processing on their side (i.e. if browsing

proﬁles are already categorized into website subjects,

they do not have to associate signatures with hits).

Disadvantages: (Olejnik et al., 2012) ”believe

that Web browsing preferences can be used as an

efﬁcient behavioural ﬁngerprint which is in many

cases stable over time” (p. 14). The question is how

long can it take to have a stable browsing ﬁngerprint?

The technique assumes that the user accesses the

website frequently, creating temporary proﬁles but,

for sporadic users this approach is not reliable. On

other hand, if a device is shared by multiple users

using the same account, the technique might not be

able to converge the patterns into a single proﬁle, due

to the different browsing behaviour of each user.

Web-based Fingerprinting Techniques

279

c) Local Shared Objects (Flash Cookies): Using

previous versions of Flash, developers could save in-

formation between sessions by using “normal” cook-

ies, but the process was considered difﬁcult for de-

velopers to implement - creating a cookie requires

the use of a language outside Flash (like JavaScript

or ASP). In the Flash MX version, Macromedia intro-

duced the Local Shared Object (LSO), which provides

an easier way to store information (i.e. only requires

the use of ActionScript).

LSOs provide the only method by which a Flash

application can store information on a user’s com-

puter. Intended uses of the object include storing a

user’s name, a favourite colour, or the progress in a

game.

Works of (Nikiforakis et al., 2013), (Mayer and

Mitchell, 2012), and (Acar et al., 2014) show how

LSO can be used to track users, by performing a

browser ﬁngerprinting.

The Electronic Privacy Information Centre

(EPIC) warns for the risks of identiﬁcation of

individuals in an article regarding Local Shared

Objects

. According to EPIC “the Flash movie can

create a unique ID and store that ID in a Flash cookie

on a user’s computer. The Flash movie can then

communicate this information to a database, or other

applications. Subsequent visits of the same users

could be tracked by reading the ID contained in the

Flash cookie”.

Advantages: Flash cookies are a powerful way

to track users because they are still not properly

addressed by browsers and their management is not

trivial (i.e. management is not done together with

HTTP cookies). This lack of proper management

paves the way for exploiting this functionality for

tracking or ﬁngerprinting.

Disadvantages: Because it requires the storing of

information, this technique is considered intrusive.

The use of this mechanism must abide to Article 5(3)

of Directive 2002/58/EC, amended by the Directive

2009/136/EC (also known as the ePrivacy directive),

which requires prior informed consent for storage or

access to information stored on a user’s equipment.

d) Web Storage (HTML5 Cookies): HTML5 intro-

duced two related mechanisms, similar to HTTP ses-

sion cookies, for storing name-value pairs on the cli-

ent side: sessionStorage and localStorage. Ac-

cording to the HTML Living Standard

: ”Storage ob-

ject provides access to a list of key/value pairs, which

are sometimes called items”.

Available at https://epic.org/privacy/cookies/ﬂash.html

Available at https://html.spec.whatwg.org/

While sessionStorage is only stored during ses-

sion time and, therefore, has no useful application for

ﬁngerprinting, localStorage, on the other hand, is

designed for storage that spans multiple windows, and

persists after the browser is closed.

Both, (Acar et al., 2014) and (Roesner et al.,

2012) refer to the use of the localStorage mechan-

ism as a way to perform browser ﬁngerprinting.

Advantages: HTML’s localStorage might be a

concept somewhat obscure to most web users. The

functionalities of history, HTTP cookies and (normal)

cached content cleaning, available in most browsers

nowadays, might trick users into thinking that, once

used, all browsing content related data will be suc-

cessfully wiped from the system. Until browsers start

alerting the users of this data storing and provide a

simple mechanism to manage this type of data, users

will be exposed to the possibility of having a persist-

ent ID etched to their browser.

Disadvantages: In their nature, Flash’s Local Shared

Objects and HTML’s localStorage are cookies.

This means that the use of such mechanisms falls

under the Article 5(3) of Directive 2002/58/EC,

amended by the Directive 2009/136/EC, which re-

quires prior informed consent for storage or access to

information stored on a user’s terminal equipment. In

other words, websites using Flash or HTML5 cook-

ies must ask users if they agree with the storing of

data before the site starts to use them, risking penal-

ties when not abiding to these obligations.

4.9 Taxonomy

The taxonomy we present in Table 15 classiﬁes each

technique according to the type of data that is collec-

ted. Whenever possible, categories were created to

group techniques according to the source of device-

related data that they explore (leftmost column). Ad-

ditional technique-related information is shown, such

as, the type of ﬁngerprinting performed (browser,

cross-browser or both), if there is information written

to the client’s system (Active or Passive), and whether

the techniques rely on a comparison database to per-

form the ﬁngerprinting.

It should be noted that the Flash retrieval of OS

features also comprises data about the Flash plu-

gin itself, therefore, providing information about the

browser (browser and cross-browser ﬁngerprinting).

HTTP Header ﬁelds also allow both types of ﬁnger-

printing. This happens because properties, such as the

“User-Agent” ﬁeld, provide both browser and system

information.

SECRYPT 2016 - International Conference on Security and Cryptography

280

Table 15: Taxonomy of the web-based ﬁngerprinting techniques.

Technique

Browser

ﬁngerprinting

Cross-browser

ﬁngerprinting

Active/Passive

Requires

comparison

database

IP address NO YES PASSIVE NO

HTTP header ﬁelds YES YES PASSIVE NO

Browser

properties

Plugin enum. YES NO PASSIVE NO

Do-Not-Track YES NO PASSIVE NO

Browser

behaviour

Rounding pixels YES NO PASSIVE YES

Canvas YES NO PASSIVE YES

Performance YES NO PASSIVE YES

Operating

system

features

Flash plugin YES YES PASSIVE NO

Java plugin NO YES PASSIVE NO

Clock skew NO YES PASSIVE YES

Hardware

features

Screen properties NO YES PASSIVE NO

CPU and RAM NO YES PASSIVE NO

Network interfaces NO YES PASSIVE NO

Font enumeration NO YES PASSIVE YES

Cached

objects

HTTP cache YES NO ACTIVE NO

History YES NO ACTIVE NO

Flash cookie YES NO ACTIVE NO

HTML5 cookie YES NO ACTIVE NO

5 CONCLUSION

Due to its almost completely unnoticeable nature,

web-based ﬁngerprinting raises several privacy is-

sues. The obvious one is the possibility to track a

user’s online behaviour without his consent. Web-

based ﬁngerprinting also poses major risks to se-

curity: by collecting software versions (of browsers

and plugins) and operating system releases, a ﬁnger-

printer can gather enough information about a sys-

tem to perform a successful attack. This was the ba-

sic premise of the Blackhole Exploit Kit (BHEK) -

an exploit kit, created in 2010, designed to identify

software vulnerabilities in client machines commu-

nicating with it and exploiting discovered vulnerab-

ilities to upload and execute malicious code on the

client. The developer of computer security software,

Sophos, published a report (Howard, 2012) (p. 9)

about BHEK where it states that “[t]he purpose of the

landing page is straightforward: to ﬁngerprint the ma-

chine. The landing page used by Blackhole uses code

from the legitimate PluginDetect library to identify:

OS, Browser (and browser version), Adobe Flash ver-

sion, Adobe Reader version, Java version”.

Sadly, the mitigation measures that exist today

fall short for what is needed. (Nikiforakis et al.,

2015) propose a “solution to the problem of browser-

based ﬁngerprinting”, by modifying the browser to

make every visit appear different to a ﬁngerprinting

site. However, this solution addresses only JavaScript

based techniques, like font/plugin enumeration and

screen resolution and, as shown in the current work,

there is a myriad of other techniques that PriVaric-

ator does not address, rendering it still ﬁngerprint-

able. Tor Browser, another proposal for countering

ﬁngerprinting, has several limitations and constraints.

The use of Tor networks adds speciﬁc constraints (e.g.

longer connection delays, script blocking) and risks

(e.g. conﬁdentiality at the exit node), which would

render the beneﬁts of its use pointless.

The work we present in this paper depicted a

study of the currently known web-based ﬁngerprint-

ing techniques. A special effort was put into gather-

ing the most complete universe of techniques. Tech-

niques were categorized in a taxonomy that will al-

low readers to easily identify different types of tech-

niques, their capabilities, limitations and similarities.

The categories were deﬁned bearing in mind that new

techniques might appear in the future and still have a

category where they will ﬁt in.

Finally, this study provides a working basis for fu-

ture research in the ﬁeld of web-based ﬁngerprinting

mitigations by presenting a complete and understand-

able insight of the currently known techniques.

The Web-based ﬁngerprinting concept emerged

after the realization that a device becomes unique be-

cause it is used by a unique entity-in this case, a human

being. As devices provide more customizations to

match the users preferences, the more individualized

they become, increasing the risk of ﬁngerprinting.

Web-based Fingerprinting Techniques

281

ACKNOWLEDGEMENTS

This work is partially supported by National Funding

from FCT - Fundac¸

ao para a Ci

encia e a Tecnologia,

under the project UID/CEC/00408/2013.

REFERENCES

Acar, G., Eubank, C., Englehardt, S., Juarez, M., Naray-

anan, A., and Diaz, C. (2014). The web never for-

gets: Persistent tracking mechanisms in the wild. In

Proceedings of the 2014 ACM SIGSAC Conference on

Computer and Communications Security, pages 674–

689. ACM.

Acar, G., Juarez, M., Nikiforakis, N., Diaz, C., G

urses,

S., Piessens, F., and Preneel, B. (2013). Fpdetective:

dusting the web for ﬁngerprinters. In Proceedings of

the 2013 ACM SIGSAC conference on Computer &

communications security, pages 1129–1140. ACM.

Article 29 Data Protection Working Party, A. (2014). Opin-

ion 9/2014 on the application of directive 2002/58/ec

to device ﬁngerprinting.

Boda, K., F

oldes,

A. M., Guly

as, G. G., and Imre, S. (2012).

User tracking on the web via cross-browser ﬁnger-

printing. In Information Security Technology for Ap-

plications, pages 31–46. Springer.

Eckersley, P. (2010). How unique is your web browser?

In Privacy Enhancing Technologies, pages 1–18.

Springer.

Fielding, R. and Reschke, J. (2014). Hypertext transfer pro-

tocol (http/1.1): Semantics and content.

Howard, F. (2012). Exploring the blackhole exploit kit.

Sophos Technical Paper.

Janc, A. and Olejnik, L. (2010). Web browser history de-

tection as a real-world privacy threat. In Computer

Security–ESORICS 2010, pages 215–231. Springer.

Jenkins, I. R., Shapiro, R., Bratus, S., Speers, R., and

Goodspeed, T. (2014). Fingerprinting IEEE 802.15.4

Devices with Commodity Radios. Technical Report

TR2014-746, Dartmouth College, Computer Science,

Hanover, NH.

Khademi, A. F., Zulkernine, M., and Weldemariam, K.

(2015). An empirical evaluation of web-based ﬁnger-

printing. Software, IEEE, 32(4):46–52.

Kohno, T., Broido, A., and Claffy, K. C. (2005). Remote

physical device ﬁngerprinting. Dependable and Se-

cure Computing, IEEE Transactions on, 2(2):93–108.

Mayer, J. R. (2009). Any person... a pamphleteer: Inter-

net anonymity in the age of web 2.0. Undergraduate

Senior Thesis, Princeton University.

Mayer, J. R. and Mitchell, J. C. (2012). Third-party web

tracking: Policy and technology. In Security and Pri-

vacy (SP), 2012 IEEE Symposium on, pages 413–427.

IEEE.

Mowery, K., Bogenreif, D., Yilek, S., and Shacham, H.

(2011). Fingerprinting information in javascript im-

plementations. Proceedings of W2SP, 2.

Mowery, K. and Shacham, H. (2012). Pixel perfect: Finger-

printing canvas in html5. Proceedings of W2SP.

Nikiforakis, N., Joosen, W., and Livshits, B. (2015). Privar-

icator: Deceiving ﬁngerprinters with little white lies.

In Proceedings of the 24th International Conference

on World Wide Web, pages 820–830. International

World Wide Web Conferences Steering Committee.

Nikiforakis, N., Kapravelos, A., Joosen, W., Kruegel, C.,

Piessens, F., and Vigna, G. (2013). Cookieless mon-

ster: Exploring the ecosystem of web-based device

ﬁngerprinting. In Security and privacy (SP), 2013

IEEE symposium on, pages 541–555. IEEE.

Olejnik, L., Castelluccia, C., and Janc, A. (2012). Why

johnny can’t browse in peace: On the uniqueness of

web browsing history patterns. In 5th Workshop on

Hot Topics in Privacy Enhancing Technologies (Hot-

PETs 2012).

Roesner, F., Kohno, T., and Wetherall, D. (2012). Detect-

ing and defending against third-party tracking on the

web. In Proceedings of the 9th USENIX conference

on Networked Systems Design and Implementation,

pages 12–12. USENIX Association.

Zalewski, M. (2012). The Tangled Web: A Guide to Secur-

ing Modern Web Applications. No Starch Press.

SECRYPT 2016 - International Conference on Security and Cryptography

282
