A Friend or a Foe?

Detecting Malware using Memory and CPU Features

Jelena Milosevic, Miroslaw Malek and Alberto Ferrante

ALaRI, Faculty of Informatics, Universit

a della Svizzera Italiana, Lugano, Switzerland

Keywords:

Malware Detection, Dynamic Detection, Android, Internet of Things (IoT).

Abstract:

With an ever-increasing and ever more aggressive proliferation of malware, its detection is of utmost impor-

tance. However, due to the fact that IoT devices are resource-constrained, it is difﬁcult to provide effective

solutions.

The main goal of this paper is the development of lightweight techniques for dynamic malware detection. For

this purpose, we identify an optimized set of features to be monitored at runtime on mobile devices as well as

detection algorithms that are suitable for battery-operated environments. We propose to use a minimal set of

most indicative memory and CPU features reﬂecting malicious behavior.

The performance analysis and validation of features usefulness in detecting malware have been carried out by

considering the Android operating system. The results show that memory and CPU related features contain

enough information to discriminate between execution traces belonging to malicious and benign applications

with signiﬁcant detection precision and recall. Since the proposed approach requires only a limited number of

features and algorithms of low complexity, we believe that it can be used for effective malware detection, not

only on mobile devices, but also on other smart elements of IoT.

1 INTRODUCTION

Malicious software, shortly malware, is any type of

program that is created to cause harm, ranging from

minor inconvenience to loss of data. Among others,

it has the goal of stealing sensitive information from

users, taking control over the operating system, and

damaging or even completely disabling the device.

The focus of Internet security is shifting from the

desktop and the data center to the home, the pocket,

the purse, and, ultimately, the infrastructure of the In-

ternet itself Symantec Corporation (2015). Further-

more, for the second consecutive year, mobile devices

are perceived as IT security’s weakest link Group

(2015). In fact, with increased number of mobile

devices and their widespread usage, mobile malware

is spreading as well. Threat alerts for Android con-

stantly grew year by year and, according to McAfee

Labs McAfee Labs (2015), the collection of mobile

malware continued its steady climb as it broke 6 mil-

lion samples in the fourth quarter of 2014, up 14%

over the third quarter of the same year.

Google Android is certainly one of the main oper-

ating systems for smart devices, with its 85% mar-

ket share worldwide for smartphones Gartner, Inc.

(2015). Android was ﬁrst developed for mobile de-

vices, but it has evolved into a pervasive operating

system, being also available for wearable devices,

TV sets, and vehicles. Google has also announced

Brillo, an embedded operating system based on An-

droid and aimed at being used on low-power and

memory constrained IoT devices Google Developers

(2015). In this paper, due to the availability of large

number of samples, we have chosen Android malware

for our case study, even though we aim at develop-

ing detection algorithms suitable also for resource-

constrained IoT devices. The aforementioned operat-

ing system convergence towards resource-constrained

devices will facilitate the direct porting of these re-

sults from one system to the other.

Mobile malware detection is used in the battery-

operated environment of mobile devices, where en-

ergy is the main limiting factor to run computation-

ally complex algorithms, as opposed to regular desk-

top malware detection systems. However, same as for

PCs, detection performance has to be high in order to

minimise the number of false positives that may cause

disturbance to users. Increased number of malicious

samples and malware families in recent years, make

the efﬁcient detection a challenging problem and its

Milosevic, J., Malek, M. and Ferrante, A.

A Friend or a Foe? Detecting Malware using Memory and CPU Features.

DOI: 10.5220/0005964200730084

In Proceedings of the 13th International Joint Conference on e-Business and Telecommunications (ICETE 2016) - Volume 4: SECRYPT, pages 73-84

ISBN: 978-989-758-196-0

solutions are mostly trade-offs between the mentioned

requirements. Most of the existing solutions are either

with good detection performance, but too complex to

be used at run-time and within limited energy budget,

or lightweight but with limited ability to detect the

plethora of malware ever newly generated.

Currently, there are two main approaches to de-

tect malware: static and dynamic. Static detection is

based on the investigation of the applications static

features (e.g., permissions, manifest ﬁles, API calls).

It is usually lightweight and suitable for the limited re-

sources of mobile devices. The problems with static

detection are that it cannot cope with increased num-

ber of malicious samples and their variations, it is

prone to obfuscation and alone may no longer be suf-

ﬁcient to identify malware Moser et al. (2007). What

appears as a promising candidate is dynamic mal-

ware detection that is based on observing systems at

run-time. In such a way, malware cannot easily ob-

fuscate. However, such detection can be too com-

plex for battery-operated mobile environments and

lightweight solutions are still needed.

A promising approach towards efﬁcient dynamic

mobile malware detection is the identiﬁcation of a

limited set of features that provide the ability, through

suitable algorithms, to discriminate between benign

and malicious behavior. The features in this set are the

ones that are monitored at runtime, and are indicative

for detecting presence of malware. Limiting the num-

ber of used features diminishes the requirements for

resources (memory, CPU, and energy), thus lowering

computational overhead. In this paper, we use term

feature to describe an individual measurable property

of a phenomena being observed Bishop (2006). In

the literature, also different terms, such as attributes,

variables, and parameters, can be found to describe

the same property.

We focus on the usefulness of memory and

CPU related features for efﬁcient malware detection.

Namely, our main hypothesis, conﬁrmed by the re-

sults that we have obtained, is that by observing only

memory and CPU related features, malicious execu-

tion traces can be distinguished from benign ones by

means of algorithms of low complexity. We identify

an optimized set of memory and CPU related fea-

tures and prove their effectiveness in detecting mal-

ware by applying different lightweight classiﬁcation

algorithms: Naive Bayes, Logistic Regression, and

J48 Decision Tree. The experiments we performed in

this work are with a set of malicious and benign ap-

plications running on Android mobile devices. How-

ever, due to the simplicity of monitoring and the low-

complexity of algorithms used to detect malware, we

are conﬁdent that our approach can also be used in

majority of other IoT devices.

The rest of the paper is organized as follows. First,

in Section 2 the related work is discussed. Then, in

Section 3 the proposed approach is outlined. Later, in

Section 4 the performed experiments are described,

followed by detailed explanation of the obtained re-

sults in Section 5 and discussion in Section 6.

2 RELATED WORK

With increased number of mobile malware threats the

need to protect mobile devices from them is growing,

resulting in higher demands for effective detection

systems and increased research activity in this area.

Most of the existing malware is developed for mo-

bile devices. Not surprisingly, most of the available

solutions are focused on these devices as well. We re-

port related approaches where observation of different

features was used for mobile malware detection, both

static and dynamic, and compare our approach with

them.

An effective static approach to malware detection

is proposed in Arp et al. (2014) where high detection

quality is achieved by using features from the mani-

fest ﬁle and feature sets from disassembled code; de-

tection is performed by means of Support Vector Ma-

chines. Also, the mechanism presented in Wu et al.

(2012) uses static features including permissions, In-

tent messages passing and API calls to detect mali-

cious Android applications, with K-means being the

best performing clustering algorithm. However, the

main disadvantage of these approaches, since they are

based on static analysis, is the inability to detect mal-

ware at run-time and, thus, the inability to detect ma-

licious behavior after the installation of applications

and/or in between periodic system scans.

Another static approach is presented in Enck et al.

(2009) where the authors propose to identify malware

based on sets of permissions. In Felt et al. (2011a),

sending SMS messages without conﬁrmation or ac-

cessing unique phone identiﬁers like the IMEI are

identiﬁed as promising features for malware detec-

tion. Legitimate applications ask those permissions

less often Felt et al. (2011b). Still, using only asked

permissions, as it is done in Felt et al. (2011a,b) pro-

duces a high false positive rate.

In Truong et al. (2013), as a static feature for de-

tecting susceptibility of a device to malware infection,

a set of identiﬁers representing the applications on a

device is used. The assumption is that the set of ap-

plications used on a device may predict the likelihood

of the device being classiﬁed as infected in the fu-

ture. Nevertheless, observing just this feature is not

SECRYPT 2016 - International Conference on Security and Cryptography

enough to give satisfactory answer about device be-

ing attacked due to relatively low precision and recall

Truong et al. (2013).

Battery power, as a dynamic feature, is also con-

sidered for detection of malware. One of the proposed

solutions, VirusMeter Liu et al. (2009) monitors and

audits power consumption on mobile devices with a

power model that accurately characterizes power con-

sumption of normal user behaviors. Also in Kim

et al. (2008) the authors use power monitoring to de-

tect malware. They ﬁrst extract characteristic power

consumption signatures of malicious and benign ap-

plications and then, while using the system, detect if

its power consumption is more similar with benign or

malicious sample. However, althought it appears as a

promising feature, to what extent malware can be de-

tected on phones by monitoring just battery power re-

mains an open research question Becher et al. (2011).

In Shabtai et al. (2012), Andromaly, a framework

for detecting malware, is proposed. It uses a variety of

dynamic features related to: touch screen, keyboard,

scheduler, CPU load, messaging, power, memory,

calls, operating system, network, hardware, binder,

and leds. The authors of Andromaly compared False

Positive Rate, True Positive Rate, and accuracy of dif-

ferent detection algorithms and concluded that the al-

gorithms that outperformed the others were Logistic

Regression and Naive Bayes. The results were ob-

tained using 40 benign applications and four mali-

cious samples, developed by the authors, since real

malicious samples did not exist at that time.

In Ham and Choi (2013), feature selection was

performed on a set of run-time features related to net-

work, SMS, CPU, power, process information, mem-

ory, and virtual memory. Four different classiﬁca-

tion algorithms were evaluated and as a measure of

features usefulness Information Gain was used. Ran-

dom Forest was the one that provided the best perfor-

mance. Random Forest is a combination of different

tree classiﬁers Breiman (2001). Although it is a pow-

erful algorithm in achieving high quality of detection,

it also has high complexity, making it unsuitable for

mobile devices. Additionally, results have been ob-

tained by only considering 30 benign and ﬁve mali-

cious applications, with a limited coverage of the high

variety of malware available to date. This may limit

the applicability of results, both in terms of algorithm

and of selected features.

As previously mentioned, Shabtai et al. (2012)

and Ham and Choi (2013) also consider some mem-

ory and CPU features as part of a larger feature set.

While we have limited our observation to memory

and CPU related features, we have considered more

detailed features related to single applications, instead

of generic ones such as total CPU or memory usage.

In our opinion, our approach better covers CPU and

memory behavior of the observed applications. Addi-

tionally, as opposed to Shabtai et al. (2012), our ap-

proach uses real malicious samples with higher vari-

ety of malicious behavior, and less complex detection

methods rather than Random Forest, as it is done in

Ham and Choi (2013).

Another recent work, presented in Milosevic et al.

(2016), also takes into account memory and CPU fea-

tures and their usefulness in malware detection. It an-

alyzes these features and their signiﬁcance within the

malware families they belong to, and takes into ac-

count the most indicative ones for each family. It con-

cludes that some features appear as good candidates

for malware detection in general, some features ap-

pear as good candidates for detection of speciﬁc mal-

ware families, and some others are simply irrelevant.

For the analysis of usefulness of features, the authors

use Principal Component Analysis. However, in this

work further validation of features by using detection

algorithms is not performed nor benign samples are

included in the experiments.

As opposed to the approach proposed in Milosevic

et al. (2016), we validate the usefulness of the selected

features by using three different detection algorithms

and use a balanced dataset consisting of both benign

and malicious applications. Additionally, in order to

ﬁnd the most indicative features, we take into account

ﬁve different feature selection methods. Finally, we

focus on discrimination of malicious and benign ex-

ecution traces, while the paper deals with usefulness

of features within different malware families.

3 METHODOLOGY

Towards enabling efﬁcient dynamic detection of mo-

bile malware, we propose the following approach to

identify the most indicative features related to mem-

ory and CPU to be monitored on mobile devices and

the most appropriate classiﬁcation algorithms to be

used afterwards:

1. Collection of malicious samples, representing dif-

ferent families, and of benign samples

2. Execution of samples and collection of the execu-

tion traces

3. Extraction of features, from the execution traces,

related to memory and CPU

4. Selection of the most indicative features

A Friend or a Foe? Detecting Malware using Memory and CPU Features

5. Selection of the most appropriate classiﬁcation al-

gorithms

6. Quantitative evaluation of the selected features

and algorithms

The ﬁrst step deﬁnes the dataset to be used in

the remaining parts of the methodology. Namely, it

is important to use malicious samples coming from

different malware families, so that the diverse behav-

ior of malware is covered to as large extent as possi-

ble. Furthermore, it is needed to set up the execu-

tion environment to run malicious samples, so that

malicious behavior can be triggered. Additionally,

such environment should provide the possibility to ex-

ecute large number of malicious samples, within rea-

sonable time, so that the obtained results have statis-

tical signiﬁcance. We have achieved these require-

ments, ﬁrst, by using a variety of malware families

with broad scope of behavior, second by triggering

different events while executing malicious applica-

tions and, third, by using an emulation environment

that enabled us to execute applications quickly. Since

our goal is to discriminate between malicious and be-

nign execution records, we have taken into account

also benign samples, and executed them in same con-

ditions used for malicious applications. While usage

of an emulator enables us to execute statistically sig-

niﬁcant number of applications on one hand, on the

other hand it is our belief that its usage instead of a

real device has a limited or no effect on results, due

to the nature of features observed. However, we are

aware of the fact that the use of an emulator may pre-

vent the activation of certain sophisticated malicious

samples.

Before identiﬁcation of the most indicative symp-

toms, feature extraction and selection needs to be per-

formed. A comprehensive survey covering the state-

of-the-art in feature selection can be found in Liu

and Yu (2005). Intuitively, a better classiﬁcation re-

sult can be achieved if we add more features to the

dataset, however this is not the case, as it can happen

that irrelevant and redundant features confuse classi-

ﬁers and decrease detection performance. Due to this

fact, we have performed feature selection as a separate

step, in which we have evaluated features usefulness

based on the following techniques: Correlation At-

tribute Evaluator, CFS Subset Evaluator, Gain Ratio

Attribute Evaluator, Information Gain Attribute Eval-

uator, and OneR Feature Evaluator Hall et al. (2009).

We have chosen feature selection techniques due to

their difference in observing usefulness of features as

they are based either on statistical importance or in-

formation gain measure. Following, the list of feature

selection algorithms that we have used:

◦ Correlation Attribute Evaluator calculates the

worth of an attribute by measuring the correlation

between it and the class.

◦ CfsSubsetEval calculates the worth of a subset of

attributes by considering the individual predictive

ability of each feature along with the degree of re-

dundancy between them. Subsets of features that

are highly correlated with the class while having

low intercorrelation are preferred Hall (1998).

◦ Gain Ratio Attribute Evaluator calculates the

worth of an attribute by measuring the gain ratio

with respect to the class.

◦ Information Gain Attribute Evaluator calculates

the worth of an attribute by measuring the infor-

mation gain with respect to the class.

◦ OneR Feature Evaluation calculates the worth of

an attribute by using the OneR classiﬁer, which

uses the minimum-error attribute for prediction

Holte (1993).

In order to validate the usefulness of selected features

we have used the following detection algorithms hav-

ing different approach to detection: Naive Bayes, Lo-

gistic Regression, and J48 Decision Tree. While most

of the steps of the proposed approach are executed of-

ﬂine (i.e., on machines equipped with extensive com-

putational resources), the classiﬁcation algorithm will

be executed on the mobile devices; thus, it needs to be

compatible with their limited resources. This is the

reason why we also take into account the complexity

of algorithms, and use the ones with low complexity.

A brief description of aforementioned classiﬁcation

algorithms follows:

• Naive Bayes is a probabilistic classiﬁer. It ap-

plies Bayes theorem making an assumption that

the features are independent. Under this naive as-

sumption it calculates probability of an unknown

instance belonging to each class and selects the

one with the highest probability as an output John

and Langley (1995).

• Logistic Regression is a linear classiﬁer that calcu-

lates the conditional probabilities of possible out-

comes and chooses the one with the maximum

likelihood. It is a technique widely used in many

ﬁelds.

• A decision tree-based J48 classiﬁer is an open

source implementation of C4.5 algorithm Hall

et al. (2009); C4.5 is a statistical classiﬁer that

for each node of the tree, chooses the attribute of

the data that the most effectively splits its samples

into subsets; the splitting criterion being maxi-

mum information gain Quinlan (1993).

SECRYPT 2016 - International Conference on Security and Cryptography

4 EVALUATION

We have executed both malicious and benign sam-

ples by using the Android SDK emulator and we have

observed their inﬂuence on 53 features representing

phone state. We have analysed collected execution

traces by applying methods to reduce the set of sig-

niﬁcant features used in the classiﬁers, based both

on statistical signiﬁcance of features and on informa-

tion gain measure. The selected features, extracted

from the training set, were afterwards employed to

train different classiﬁers for a comparative evaluation;

these classiﬁers are then used to categorize execution

records into malicious or benign. To build a balanced

set of applications, we used malicious samples com-

ing from Malware Genome Project Zhou and Jiang

(2012) and benign samples coming from Play Store

Google Inc. (2015b).

In this section, we describe in detail the dataset

that we have used, and the experiments that we have

performed. Furthermore, we list the features that we

have collected, describe the settings of the techniques

used for feature analysis, so as implementation details

of the classiﬁcation algorithms used for malware de-

tection.

4.1 Dataset

The dataset consists of a mix of malicious and be-

nign applications. The Malware dataset is composed

of 1,247 malicious applications taken from the Mal-

ware Genome project Zhou and Jiang (2012) and

belonging to 41 families. These malware families

cover a broad range of malicious behaviors, including

different installation methods (repackaging, update,

drive-by download, standalone), activation mecha-

nisms (Boot Completed, Phone Events, SMS, Calls,

USB, Battery, Package, Network, System Events) and

different malicious payloads (privilege escalation, re-

mote control, ﬁnancial charges, and personal informa-

tion stealing). More details on each of these families

are provided in Zhou and Jiang (2012).

The benign dataset has been obtained by running

952 benign applications downloaded from the Google

Play Store Google Inc. (2015b). We believe that the

applications coming from Google Play Store can be

used as benign due to the detailed analysis done to

identify potentially harmful applications and the low

infection rate reported in Google Inc. (2015c). We

are aware that some of these applications could po-

tentially contain malicious behavior, but we believe

that the number of benign ones is still much higher

making the obtained dataset representative.

4.2 Execution Environment

Memory and CPU usage traces were recorded by run-

ning the applications, one at a time, on the Android

emulator; each application has been run for 10 min-

utes, even though some of the traces are shorter, due

to emulator hiccups. The considered monitoring in-

terval is equal to two seconds. Although it could be

the case that a longer execution period would provide

us more signiﬁcant results, we believe that the dura-

tion that we have chosen is a good trade-off between

time when most of the malware samples expose their

malicious intents and duration of the overall experi-

mentation.

The Android emulator of choice was the one in-

cluded in the Android Software Development Kit An-

droid Open Source project (2015b) release 20140702,

running Android 4.0. The reason why an Android em-

ulator was chosen instead of real devices is that this

solution minimizes the time necessary to set up each

application before running, thus providing the abil-

ity to run a large number of applications, making the

obtained dataset more signiﬁcant. The Android oper-

ating system was each time re-initialized before run-

ning each application, so that the interferences (e.g.,

changed settings, running processes, and modiﬁca-

tions of the operating system ﬁles) from previously

run samples are avoided.

All this process was automated by means of a shell

script that was run on a Linux PC and made use of

Android Debug Bridge (adb) Android Open Source

project (2015a), a command line tool that lets the PC

communicate with an emulator instance or with an

Android device. The Monkey application exerciser

Android Open Source project (2015c) was also used

in the script. The Monkey is a command-line tool that

can be run on any emulator instance or on a device; it

sends a pseudo-random stream of user events into the

system, which acts as a stress test on the application

software. In our script, Monkey was used to activate

different features of the applications; adb was used to

monitor application features, namely the memory us-

age of the considered sample, as well as to install the

applications. In summary, for each application, the

following actions were performed:

• A clean install of the Android operating system

• The application installation on the Android Emu-

lator by means of adb

• The memory monitoring by means of periodic

calls to the adb shell command

• Initialization and run of the application for 10

minutes by using the Monkey.

A Friend or a Foe? Detecting Malware using Memory and CPU Features

4.3 Collected Features

We have taken into account all the features related to

memory and CPU that can be accessed in Android. In

total, this makes 53 features for each running appli-

cation; these features are listed in Table 1. There are

ﬁve features related to CPU: three related to CPU us-

age, and two to virtual memory exceptions (major and

minor faults). The remaining 48 features are related

to different aspects of memory usage.

4.4 Feature Analysis Techniques

As described in Section 3, collected features are anal-

ysed by using Correlation Attribute Evaluator, CFS

Subset Evaluator, Gain Ratio Attribute Evaluator, In-

formation Gain Attribute Evaluator, and OneR Fea-

ture Evaluator. For the mentioned feature selection

methods, their implementation in Weka data mining

tool Hall et al. (2009) has been used. More in detail,

CFS subset evaluation is performed by using Greedy

forward search through the space of attribute subsets

Hall (1998). Correlation Attribute Evaluator, Gain

Ratio Attribute Evaluator, Information Gain Attribute

Evaluator, and OneR Attribute Evaluator are used to-

gether with Ranker method that ranks attributes by

their individual performance.

4.5 Detection Algorithms

As discussed in Section 3, the classiﬁers of choice

are: Naive Bayes, Logistic Regression, and J48 Deci-

sion Tree. Weka implementations of these algorithms

have been used. Naive Bayes has been set assum-

ing normality and modelling each conditional distri-

bution with a single Gaussian; Logistic Regression

has been used with ridge estimator, since it has been

shown that it can improve attribute estimation and de-

crease the error made in further predictions Le Cessie

and Van Houwelingen (1992). J48 has been used with

pruning, setting the conﬁdence factor used for prun-

ing to 0.25 and the minimum number of instances per

leaf to 5000; these values represent a trade-off be-

tween number of instances in the dataset, speed of

execution and the quality of classiﬁcation.

4.6 Evaluation of the Approach

The validation of the classiﬁcation is done by us-

ing ten-fold cross validation, that is widely used

model validation technique that can estimate how ac-

curately observed model will perform in practise Ko-

havi (1995). In case of ten-fold cross validation, the

dataset is divided into ten parts, where at each round

Table 1: List of all the considered features; totals are related

only to single applications.

CPU Usage

Total CPU Usage

User CPU Usage

Kernel CPU Usage

Virtual Memory

Page Minor Faults

Page Major Faults

Native memory

Native PSS

Native Shared Dirty

Native Private Dirty

Native Heap Size

Native Heap Alloc

Native Heap Free

Dalvik memory

Dalvik PSS

Dalvik Shared Dirty

Dalvik Private Dirty

Dalvik Heap Size

Dalvik Heap Alloc

Dalvik Heap Free

Dalvik Cursor PSS

Cursor memory

Cursor Shared Dirty

Cursor Private Dirty

Android shared memory

Ashmem PSS

Ashmem Shared Dirty

Ashmem Private Dirty

Memory-mapped native code

.so mmap PSS

.so mmap Shared Dirty

.so mmap Private Dirty

Memory mapped Dalvik code

.dex mmap PSS

.dex mmap Shared Dirty

.dex mmap Private Dirty

Memory-mapped fonts

.ttf mmap PSS

.ttf mmap Shared Dirty

.ttf mmap Private Dirty

Other memory-mapped ﬁles

and devices

.jar mmap PSS

.jar mmap Shared Dirty

.jar mmap Private Dirty

.apk mmap PSS

.apk mmap Shared Dirty

.apk mmap Private Dirty

Other mmap PSS

Other mmap Shared Dirty

Other mmap Private Dirty

Non-classiﬁed memory allo-

cations

Unknown PSS

Unknown Shared Dirty

Unknown Private Dirty

Other dev PSS

Other dev Shared Dirty

Other dev Private Dirty

Memory totals

Total PSS

Total Shared Dirty

Total Private Dirty

Total Heap Size

Total Heap Alloc

Total Heap Free

one part, consisting of nine folds, is considered as a

training set and the remaining part is used as a test set.

This procedure is repeated ten times, each time using

a different training and a test set, and after ten rounds

the average detection performance is reported.

SECRYPT 2016 - International Conference on Security and Cryptography

5 RESULTS

Results show that by observing limited number of fea-

tures related to memory and CPU (only seven in case

of Naive Bayes and Logistic Regression, and six in

case of J48 Decision Tree), the execution traces be-

longing to malicious applications can be identiﬁed

with precision and recall of more than 84%. In our

opinion, this result is valuable, having in mind the

small number of features used, the lightweight clas-

siﬁcation algorithms, and the good F-measure score

obtained.

To rank the available features, we applied the ﬁve

feature selection methods introduced in Section 3; the

ﬁrst ﬁfteen highest ranked features for each method

are shown in Table 2. We may notice that different

ranking methods provide different results; however, a

number of features related to memory mapping, such

as .ttf mmap PSS and .so mmap PSS, are among the

highest ranked ones in most methods. In Table 2 for

CFS Subset Evaluator only seven features are listed,

without any ranking. This is due to the fact that CFS

does not evaluate single features but, instead, subsets

of features, calculating their usefulness with respect

to the other subsets.

As discussed in Section 4, we have used three

different classiﬁcation algorithms. In case of Naive

Bayes and Logistic Regression we have evaluated

the results of the classiﬁers both considering all the

available features and by considering only the highest

ranked ones for each feature selection method. On the

obtained dataset, we have performed ten-fold cross

validation and have taken into account precision, re-

call, and F-measure of a model as a result of the ex-

periment. We have repeated this procedure for all ﬁve

feature selection methods taken into account.

For J48 Decision Tree, we have trained the model

by changing the maximum number of instances that a

node can have and by observing its quality of detec-

tion (precision, recall, and F-measure). The number

of instances is important in order to avoid overﬁtting,

a situation in which the decision tree consists of many

nodes that are very well ﬁtted for the training set, but

do not perform well on a test set and unseen data. In

J48 Decision Tree, the maximum number of instances

in the three can be set, but meaningful features are se-

lected by the algorithms and cannot be set externally.

Table 3 summarizes the results obtained with the

different classiﬁers. The initial model includes all the

53 features available. The second model, instead, is

the one providing maximum F-measure; the last one

provides the best ratio between F-measure and the

number of features considered. We use F-measure

(sometimes also called F-score) as a quantitative de-

scription of the quality of detection models, since it

includes both precision (the fraction of detected in-

stances that are relevant) and recall (the fraction of

relevant instances that are detected).

In case of Naive Bayes, with the dataset contain-

ing all 53 features, an F-measure of 0.77 is obtained.

After taking into account rankings of the features for

all ﬁve feature selection methods, we identiﬁed an op-

timized set of features, both with respect to their num-

ber and to F-measure, as the one computed with the

CFS Subset Evaluator. As it can be seen from Table 3,

the obtained F-measure in this case is 0.83, with a set

of seven features.

In case of Logistic Regression, using all features,

we obtained F-measure of 0.83. However, decreas-

ing the number of features and observing system per-

formance, we obtained an increased F-measure of

0.86, obtained by using Correlation Attributes with

rankings higher than 0.03 (38 features). The optimal

model with respect to both number of features and

quality of detection is again obtained by using fea-

tures selected by CFS Subset Evaluator. This model

has an F-measure of 0.84.

For what concerns J48, the obtained model, that

uses six features, has an F-measure of 0.82. The deci-

sion three, with the selected features thereby used, is

shown in Figure 1.

In summary, features that are the most indicative

for the Logistic Regression and Naive Bayes classi-

ﬁers are the seven listed in the CFS Subset Evaluator

column of Table 2; for J48 Decision Tree, the six most

signiﬁcant features are listed in Figure 1. A brief de-

scription of these features is provided in Table 4. The

best detection performance with respect to F-measure,

so as with respect to the ratio between F-measure and

the number of features considered, is achieved by the

Logistic Regression algorithm. The best F-measure

is obtained by considering 38 highest ranked features

provided by the Correlation Attribute Evaluator; the

optimized set of only 7 features is obtained by con-

sidering the CFS Subset Evaluator. Also the other two

detection algorithms considered, namely Naive Bayes

and J48 Decision Tree, perform well, showing simi-

larly good detection performance.

6 DISCUSSION

We propose and validate an approach for detection

of malicious execution traces that takes into account

limited resources of battery-operated devices. This

is the case due to the small number of features that

is used and the lightweight algorithms that are taken

into account for detection. The discussed algorithms

A Friend or a Foe? Detecting Malware using Memory and CPU Features

Table 2: Top 15 features ranked by different feature selection algorithms.

Correlation Attribute Evaluator CFS Subset Evaluator Gain Ratio Attribute Evaluator

Ranking Feature Feature Ranking Feature

0.49 .ttf mmap PSS .so mmap Shared Dirty 0.12 .jar mmap PSS

0.46 .so mmap PSS .jar mmap PSS 0.06 .dex mmap Private Dirty

0.43 .dex mmap PSS .ttf mmap PSS 0.05 Other dev Private Dirty

0.39 TOTAL PSS .dex mmap PSS 0.04 .dex mmap PSS

0.38 .so mmap Shared Dirty .dex mmap Private Dirty 0.04 .ttf mmap PSS

0.36 TOTAL Private Dirty Other mmap Private Dirty 0.04 .so mmap Shared Dirty

0.36 .jar mmap PSS CPU Total 0.03 .so mmap PSS

0.33 Unknown Private Dirty 0.03 .so mmap Private Dirty

0.33 Unknown PSS 0.03 Other mmap Private Dirty

0.31 CPU User 0.03 .dex mmap Shared Dirty

0.30 CPU Total 0.03 Unknown PSS

0.30 TOTAL Heap Size 0.03 Native Heap Size

0.29 TOTAL Heap Alloc 0.03 Unknown Private Dirty

0.27 Other mmap PSS 0.03 Other mmap Shared Dirty

0.26 Native Heap Alloc 0.02 TOTAL PSS

Information Gain Attribute Evaluator OneR Attribute Evaluator

Ranking Feature Ranking Feature

0.28 .dex mmap PSS 79.99 .ttf mmap PSS

0.27 .ttf mmap PSS 79.64 .dex mmap PSS

0.25 Unknown PSS 78.92 Unknown PSS

0.25 .so mmap PSS 78.51 .so mmap PSS

0.23 Native Heap Size 76.24 TOTAL Heap Size

0.23 TOTAL Heap Size 76.19 Native Heap Size

0.21 Unknown Private Dirty 75.87 Unknown Private Dirty

0.21 .so mmap Private Dirty 75.44 .so mmap Private Dirty

0.17 .so mmap Shared Dirty 73.25 .so mmap Shared Dirty

0.17 Ashmed PSS 71.26 Native PSS

0.15 Other mmap PSS 71.21 Other mmap PSS

0.15 TOTAL PSS 71.17 Ashmed PSS

0.14 minor faults 70.75 minor faults

0.13 Native PSS 69.78 TOTAL PSS

0.13 TOTAL Private Dirty 69.49 .apk mmap PSS

are envisioned to be part of a run-time malware de-

tection system installed on mobile devices. In such

system, identiﬁed optimized features will be period-

ically monitored, and the classiﬁcation of the execu-

tions traces will be done in the way proposed in this

work. The classiﬁed execution traces will be further

analysed at the application level and in case of a de-

tected malicious application, the user will be notiﬁed.

While in this paper we focused on the classiﬁcation

of the executions traces, the classiﬁcation of the entire

applications is envisioned as a next step of our work.

We believe that such a lightweight detection system

could be used either as a complement to other detec-

tion systems (e.g., static ones) or in two-level detec-

tion systems, such as the one presented in Milosevic

et al. (2014), to raise the ﬁrst alarm.

6.1 Highlights of the Approach

The approach adopted in developing the detection

method presented in this paper, provides the ability to

underline a number of key facts as follows.

From the results of our experiments, we can claim

that CPU and memory features contain useful in-

formation for discriminating between the execution

traces related to malicious or benign applications.

Additionally, good detection performance can be ob-

tained while using algorithms of low complexity, suit-

able for battery-operated mobile devices.

We have shown that in case of Logistic Regression

and Naive Bayes, detection performance, measured

with precision, recall, and F-measure, and presented

in Table 3 is improved even if the number of features

is decreased from 53 to 7. Reducing the number of

features without reducing performance of the system

is in line with our intention to design effective, while

at the same time efﬁcient, mobile detection system.

Out of ﬁve feature selection methods taken into

account, our analysis shows that CFS Subset Evalua-

SECRYPT 2016 - International Conference on Security and Cryptography

Table 3: Performance of the classiﬁers when different number of features are considered.

Model

Initial Max. F-

measure

Optimized

Naive Bayes

Precision 0.79 0.84 0.84

Recall 0.76 0.83 0.83

F-measure 0.77 0.83 0.83

No. of features 53 7 7

Logistic Regression

Precision 0.84 0.86 0.84

Recall 0.84 0.86 0.84

F-measure 0.83 0.86 0.84

No. of features 53 38 7

J48 Decision Tree

Precision – – 0.83

Recall – 0.83

F-measure – – 0.82

No. of features – – 6

Figure 1: Optimized J48 Decision Tree; malicious and benign traces are labelled with 0 and 1, respectively.

tor performs the best and identiﬁes the set of features

that demonstrates the highest detection performance

among all considered detection algorithms.

Out of three detection algorithms taken into ac-

count, Logistic Regression has the highest detection

performance measured by F-measure. Therefore, we

have shown that a very small number of features, cou-

pled with algorithms of linear complexity in the num-

ber of features, can be used to detect malware effec-

tively, making the approach lightweight and poten-

tially compatible with the limited resources of small

IoT nodes.

We have observed that malicious samples con-

sume less memory and CPU compared to the benign

ones. This can be seen looking into values of fea-

tures of J48 Decision Tree presented in Figure 1. A

similar behavior can also be observed by looking into

details of the obtained Naive Bayes and Logistic Re-

gression models. The reason for this could be that

malicious applications perform only a limited activ-

ity, connected to their malicious intent, rather than the

legitimate actions for which they were installed by the

user.

Ten-fold cross validation was used to evaluate per-

formance of the different classiﬁers and of the se-

lected sets of features. This approach is equivalent

to testing by applying a mix of execution traces (or

parts of them) related to both malicious samples that

have been used during training and others that have

not. This situation is still worse than what happens

in reality, where the large majority of malicious sam-

ples are known to the classiﬁers and only a fraction of

them is not.

We have performed validation by using execution

A Friend or a Foe? Detecting Malware using Memory and CPU Features

Table 4: Brief description of the most indicative features

Google Inc. (2015a).

Feature Name Feature Description

.so mmap Shared

Dirty

Shared memory, in the Dirty state, being used

for mapped native code. The Dirty state is due

to ﬁx-ups to the native code when it is loaded

into its ﬁnal address.

.so mmap PSS Memory used for native code, including plat-

form code shared across applications

.jar mmap PSS Memory usage for Java archives, including

pages shared among processes

.ttf mmap PSS Memory usage for true type fonts, including

pages shared among processes

.so mmap PSS Memory used for Dalvik or ART code, includ-

ing platform code shared across applications

.so mmap Private

Dirty

Private memory, in the Dirty state, being used

for mapped Dalvik or ART code. The Dirty

state is due to ﬁx-ups to the native code when

it is loaded into its ﬁnal address.

Other mmap Private

Dirty

Private memory used by unclassiﬁed contents

that is in the dirty state

Unknown shared

dirty

Shared memory that in the dirty state that can-

not be classiﬁed into one of the other more

speciﬁc items

CPU User Userspace CPU usage by the considered ap-

plication

CPU Total Total (User + System) CPU usage by the con-

sidered application

traces obtained when only one application was run-

ning: this situation is very likely to be the most com-

mon one in IoT nodes with limited resources.

6.2 Limitations of the Approach

Our detection system uses dynamic features that are

by their nature more difﬁcult to evade than the static

ones. The assumption for usage of dynamic features

(in our case memory and CPU) is that even when

the applications are repackaged or obfuscated, dur-

ing their execution they will still have similar behav-

ioral footprints, and a classiﬁer trained on these fea-

tures could properly discriminate malicious applica-

tions from benign ones. Our detection method can

detect effectively known malicious samples and un-

known malicious samples belonging to known mal-

ware families. However, it cannot guarantee, as any

other detection method, absolute security. If a mali-

cious attacker develops a new malicious sample that

has a behavior reﬂected in signiﬁcantly different fea-

ture proﬁles than the ones observed in our dataset, the

detection system might not be able to detect it.

Our approach is data driven and, as other meth-

ods that use a similar approach, such as Shabtai et al.

(2012)Ham and Choi (2013), it does not provide any

help in understanding how the selected features and

their relations are connected with the behavior of the

applications. Therefore, while selected features can

be described individually and the rationale beyond al-

gorithms can be explained, an explanation on why

features are important for the identiﬁcation of mal-

ware is possible only in the simplest cases, where the

number of available features is very limited and the

system is extremely simple. However, without usage

of these mathematical algorithms and models it would

be impossible to measure usefulness of features, iden-

tify their correlations, and choose only the most in-

dicative ones.

7 CONCLUSIONS

The usefulness of CPU and memory features in the

discrimination between malicious and benign exe-

cution traces has been investigated. We use differ-

ent feature selection methods based on statistics and

information theory and identify the most indicative

ones. Furthermore, in order to validate the useful-

ness of the features we use classiﬁcation algorithms

that are suitable for malware detection in the limited

battery-operated environment of mobile and other IoT

devices. Results show that memory and CPU features

contain enough information to discriminate between

benign and malicious execution behavior of applica-

tions. In particular, only six or seven features, de-

pending on the classiﬁcation algorithm, are sufﬁcient

to identify execution traces that can be associated with

malware with a precision and recall that are higher

than 84%. Since the proposed methodology is of low

complexity, it is also applicable to a wide range of

resource-constrained devices in Internet of Things.

REFERENCES

Android Open Source project (2015a).

Android Debug Bridge. Online:

http://developer.android.com/tools/help/adb.html.

Android Open Source project (2015b). An-

droid Software Development Kit. Online:

https://developer.android.com/sdk/index.html.

Android Open Source project (2015c).

UI/Application Exerciser Monkey. Online:

http://developer.android.com/tools/help/monkey.html.

Arp, D., Spreitzenbarth, M., Hubner, M., Gascon, H., and

Rieck, K. (2014). DREBIN: Effective and Explain-

able Detection of Android Malware in Your Pocket.

In NDSS.

Becher, M., Freiling, F. C., Hoffmann, J., Holz, T., Uel-

lenbeck, S., and Wolf, C. (2011). Mobile Security

Catching Up? Revealing the Nuts and Bolts of the Se-

curity of Mobile Devices. In Symposium on Security

SECRYPT 2016 - International Conference on Security and Cryptography

and Privacy, SP ’11, pages 96–111. IEEE Computer

Society.

Bishop, C. M. (2006). Pattern Recognition and Ma-

chine Learning (Information Science and Statistics).

Springer-Verlag New York, Inc., Secaucus, NJ, USA.

Breiman, L. (2001). Random forests. Mach. Learn.,

45(1):5–32.

Enck, W., Ongtang, M., and McDaniel, P. (2009). On

lightweight mobile phone application certiﬁcation. In

16th ACM conference on Computer and communica-

tions security (CCS), pages 235–245. ACM.

Felt, A. P., Finifter, M., Chin, E., Hanna, S., and Wag-

ner, D. (2011a). A Survey Of Mobile Malware in the

Wild. In 1st ACM workshop on Security and privacy

in smartphones and mobile devices (SPSM), pages 3–

14. ACM.

Felt, A. P., Greenwood, K., and Wagner, D. (2011b).

The effectiveness of application permissions. In 2nd

USENIX conference on Web application development

(WebApps), pages 7–7. USENIX Association.

Gartner, Inc. (2015). Gartner says emerging markets

drove worldwide smartphone sales to 15.5 per-

cent growth in third quarter of 2015. Online:

http://www.gartner.com/newsroom/id/3169417.

Google Developers (2015). Brillo. Online:

https://developers.google.com/brillo.

Google Inc. (2015a). Android Developers – Investigat-

ing Your RAM Usage. Online: http://developer.an

droid.com/tools/debugging/debugging-memory.html.

Google Inc. (2015b). Google Play. Online:

https://play.google.com.

Google Inc. (2015c). Google Report – Android Security

2014 Year in Review. Technical report. Online:

https://static.googleusercontent.com/media/source.an

droid.com/it//devices/tech/security/reports/Google

Android Security 2014 Report Final.pdf.

Group, C. (2015). 2015 cyberthreat defense re-

port. Technical report. Online: http://www.bright

cloud.com/pdf/cyberedge-2015-cdr-report.pdf.

Hall, M., Frank, E., Holmes, G., Pfahringer, B., Reutemann,

P., and Witten, I. H. (2009). The WEKA Data Min-

ing Software: An Update. SIGKDD Explor. Newsl.,

11(1):10–18.

Hall, M. A. (1998). Correlation-based Feature Subset Se-

lection for Machine Learning. PhD thesis, University

of Waikato, Hamilton, New Zealand.

Ham, H.-S. and Choi, M.-J. (2013). Analysis of android

malware detection performance using machine learn-

ing classiﬁers. In ICT Convergence (ICTC), 2013 In-

ternational Conference on, pages 490–495.

Holte, R. (1993). Very simple classiﬁcation rules per-

form well on most commonly used datasets. Machine

Learning, 11(1):63–90.

John, G. and Langley, P. (1995). Estimating continuous dis-

tributions in bayesian classiﬁers. In In Proceedings of

the Eleventh Conference on Uncertainty in Artiﬁcial

Intelligence, pages 338–345. Morgan Kaufmann.

Kim, H., Smith, J., and Shin, K. G. (2008). Detecting

energy-greedy anomalies and mobile malware vari-

ants. In Proceedings of the 6th International Confer-

ence on Mobile Systems, Applications, and Services,

MobiSys ’08, pages 239–252, New York, NY, USA.

ACM.

Kohavi, R. (1995). A study of cross-validation and boot-

strap for accuracy estimation and model selection.

pages 1137–1143. Morgan Kaufmann.

Le Cessie, S. and Van Houwelingen, J. C. (1992). Ridge

estimators in logistic regression. Applied statistics,

pages 191–201.

Liu, H. and Yu, L. (2005). Toward integrating feature selec-

tion algorithms for classiﬁcation and clustering. IEEE

Transactions on Knowledge and Data Engineering,

17(4):491–502.

Liu, L., Yan, G., Zhang, X., and Chen, S. (2009). VirusMe-

ter: Preventing Your Cellphone from Spies. In 12th

International Symposium on Recent Advances in In-

trusion Detection (RAID), pages 244–264. Springer.

McAfee Labs (February 2015). Threats

Report. Technical report. Online:

http://www.mcafee.com/hk/resources/reports/rp-

quarterly-threat-q4-2014.pdf.

Milosevic, J., Dittrich, A., Ferrante, A., and Malek, M.

(2014). A resource-optimized approach to efﬁcient

early detection of mobile malware. In Availability,

Reliability and Security (ARES), 2014 Ninth Interna-

tional Conference on, pages 333–340. IEEE.

Milosevic, J., Ferrante, A., and Malek, M. (2016). What

does the memory say? towards the most indicative

features for efﬁcient malware detection. In CCNC

2016, The 13th Annual IEEE Consumer Communica-

tions & Networking Conference, Las Vegas, NV, USA.

IEEE Communication Society, IEEE Communication

Society.

Moser, A., Kruegel, C., and Kirda, E. (2007). Limits of

static analysis for malware detection. In Computer Se-

curity Applications Conference, 2007. ACSAC 2007.

Twenty-Third Annual, pages 421–430.

Quinlan, J. R. (1993). C4.5: Programs for Machine Learn-

ing. Morgan Kaufmann Publishers Inc., San Fran-

cisco, CA, USA.

Shabtai, A., Kanonov, U., Elovici, Y., Glezer, C., and Weiss,

Y. (2012). ”andromaly”: A behavioral malware detec-

tion framework for android devices. J. Intell. Inf. Syst.,

38(1):161–190.

Symantec Corporation (2015). Internet security threat

report volume 20. Technical report. Online:

https://www.symantec.com/content/en/us/enterprise/

other resources/21347933 GA RPT-internet-

security-threat-report-volume-20-2015.pdf.

Truong, H. T. T., Lagerspetz, E., Nurmi, P., Oliner, A. J.,

Tarkoma, S., Asokan, N., and Bhattacharya, S. (2013).

The Company You Keep: Mobile Malware Infec-

tion Rates and Inexpensive Risk Indicators. CoRR,

abs/1312.3245.

Wu, D.-J., Mao, C.-H., Wei, T.-E., Lee, H.-M., and Wu,

K.-P. (2012). Droidmat: Android malware detection

through manifest and api calls tracing. In Information

Security (Asia JCIS), 2012 Seventh Asia Joint Confer-

ence on, pages 62–69.

A Friend or a Foe? Detecting Malware using Memory and CPU Features

Zhou, Y. and Jiang, X. (2012). Dissecting Android Mal-

ware: Characterization and Evolution. In Proceedings

of the 2012 IEEE Symposium on Security and Privacy,

SP ’12, pages 95–109, Washington, DC, USA. IEEE

Computer Society.

SECRYPT 2016 - International Conference on Security and Cryptography
