CoAP Option for Capability-Based Access Control for IoT-Applications

Borting Chen

1,2

, Mesut G

unes¸

and Yu-Lun Huang

Institute of Electrical and Control Engineering, National Chiao Tung University, Hsinchu City, Taiwan

Institute of Computer Science, University of M

unster, M

unster, Germany

Keywords:

Capability-Based Access Control, Internet of Things, Network Security.

Abstract:

Access control is critical for many applications of the Internet of Things (IoT) since the owner of an IoT device

(and application) may only permit one user to access a subset of the resources of the device. To provide access

control for an IoT network, recent work adopted the capability-based access control (CBAC) model, which

allows an IoT device to decide on the authorization by itself based on a capability token. However, the existing

approaches based on CBAC directly attach the capability token at the end of CoAP when sending a request

message. For the receiver, it is not easy to retrieve the capability token from the request message if the CoAP

payload is present, because CoAP does not have a length ﬁeld to indicate the size of its payload. To counter

this problem, we propose a CoAP option, Cap-Token, to encapsulate a capability token when sending request

messages. Because a CoAP option is independent from other CoAP ﬁelds, a receiver can get the capability

token from the Cap-Token option of the request message without ambiguity. We also provide a compression

mechanism to reduce the size of the Cap-Token option. Our evaluation shows that the compression mechanism

can save the size of the option by 60%. Adding a compressed Cap-Token option to a request message increases

the IP datagram size by 45 bytes, which is only 41% of the increase when directly attaching the capability token

at the end of CoAP.

1 INTRODUCTION

The Internet of Things (IoT) is a promising archi-

tecture for the next generation Internet where ev-

ery device has the ability to communicate with each

other. Various communication protocols, such as

6LoWPAN (Montenegro et al., 2007) and RPL (Win-

ter et al., 2012) has been proposed to support realiz-

ing this concept in many ﬁelds, including home au-

tomation, smart building and industrial control (Seitz

and Gerdes, 2015). With the growing use of IoT

technologies, IoT security attracts more attention in

academia and industry. IoT security includes con-

ﬁdentiality, integrity, authentication, data freshness,

and access control (Alghamdi et al., 2013) (Granjal

et al., 2015) (Nguyen et al., 2015) (Roman et al.,

2013). Among these security requirements, access

control is critical because an IoT device can provide

multiple resources, however the device owner may

only permit a user to access a subset of them. Hence,

some research has been conducted to present different

access control solutions for an IoT network.

Recent work adopted the capability-based access

control (CBAC) model (Gusmeroli et al., 2013) for

an IoT network. CBAC allows an IoT device to han-

dle the authorization processes by itself based on a

capability token sent with the request message. A ca-

pability token contains access permissions granted to

a requester

. The requester sends a request message

with the capability token, and the receiver decides on

the authorization of the request based on the permis-

sions described in that capability token. Such a design

enables applying access control for an IoT network

where a centralized authorization server is hard to de-

ploy. It also helps to enforce the principle of least

privilege, because different requesters can be granted

with capability tokens containing different access per-

missions.

However, the existing approaches based on CBAC

still have some issues.

• When applying CBAC for an IoT network

which uses the Constrained Application Proto-

col (CoAP) (Shelby et al., 2014) as its commu-

nication protocol, every CoAP request message

should be sent with a capability token. This is be-

cause CoAP was designed according to the Rep-

We use “requester” instead of “user” in this paper, be-

cause in an IoT network the source of a request message can

be a human or a network-connected device.

266

Chen, B., Güne¸s, M. and Huang, Y-L.

CoAP Option for Capability-Based Access Control for IoT-Applications.

DOI: 10.5220/0005950902660274

In Proceedings of the International Conference on Internet of Things and Big Data (IoTBD 2016), pages 266-274

ISBN: 978-989-758-183-0

resentational State Transfer (REST) architecture,

which requires the interaction between a requester

and a receiver being stateless. Some CBAC ap-

proaches (Gusmeroli et al., 2013) (Hern

andez-

Ramos et al., 2013) realized this requirement by

directly attaching the capability token at the end

of CoAP, i.e., behind the CoAP payload. How-

ever, CoAP does not have a length ﬁeld to indi-

cate the size of its payload. If the CoAP payload

is present in a request message (e.g., “UPDTAE”

or “PUT” messages), the receiver has no means

to retrieve the capability token from the message,

because the capability token is mixed up with the

CoAP payload. We call this issue as the “payload

ambiguity problem.”

• A capability token contains not only access per-

missions but also data for identiﬁcation, validity

veriﬁcation, and integrity checking. This causes a

capability token is usually large in size. However,

in a 6 LoWPAN network, the maximum frame

size deﬁned in IEEE 802.15.4 is much smaller

than the minimum MTU for IPv6 (127 bytes vs.

1280 bytes). If a large size capability token is sent

with the request message, the message might be

fragmented into several data link frames. Things

get worse when the 6 LoWPAN network uses RPL

as the routing protocol. Because RPL is a hop-by-

hop routing protocol, an intermediate router needs

to collect all data link frames of a request message

to determine the next forwarding target. Losing

any data link frame fails the reassembling of the

message, which means the entire message is lost.

This decreases the success rate of delivering re-

quest messages over a 6 LoWPAN network.

To address these issues, we design a CoAP option,

called Cap-Token, to encapsulate a capability token

when sending a request message. Because a CoAP

option is independent from other CoAP ﬁelds and the

option knows its size, the capability token would not

be mixed up with the contents of other CoAP ﬁelds.

The receiver can hence retrieve the capability token

from the Cap-Token option of a request message with-

out ambiguity. Besides, to reduce the increase in the

IP datagram size after adding the Cap-Token option to

the request message, we provide a compression mech-

anism for the Cap-Token option. Since the capabil-

ity token in the Cap-Token option may have dupli-

cate contents in other CoAP ﬁelds or in the lower-

layer protocols of a request message, the compres-

sion mechanism can elide those duplicates to mini-

mize the size of the Cap-Token option. This results in

smaller IP datagrams for request messages, reducing

the chance of the occurrence of link-layer fragmenta-

tion in a 6 LoWPAN network. The main contributions

of this paper are as follows.

• The Cap-Token option solves the “payload ambi-

guity problem” for a receiver when processing a

CoAP request message containing both a capabil-

ity token and a payload. The receiver can retrieve

the Cap-Token option from any type of CoAP re-

quest message and get the capability token from

the option.

• The compression mechanism saves 60% of the

original size of the Cap-Token option. Beneﬁted

from the compression, we can reduce the increase

in the IP datagram size when applying CABC for

an IoT network. Our evaluation shows that adding

a compressed Cap-Token option only increases

the IP datagram size by 69%. In comparison to

directly attaching a capability token at the end of

CoAP, which increases the IP datagram size by

304%, our work signiﬁcantly reduces the IP data-

gram size.

• The compression mechanism also helps reduce

the chance of the occurrence of the link-layer

fragmentation when transmitting CoAP request

messages over a 6LoWPAN network. Because

of the smaller IP datagram size, using a com-

pressed Cap-Token option allows a request mes-

sage to be transmitted in 1 packet. Comparatively,

directly attaching a capability token would cause

the IP datagram being fragmented into 3 data link

frames, which downgrades the success rate of de-

livering request messages.

The paper is organized as follows. We ﬁrst brief the

design of our capability token in Section 2, and de-

scribe the design of the Cap-Token option and the

compression mechanism in Section 3. Section 4 eval-

uates the beneﬁts of the compression mechanism and

Section 5 discusses how the compression mechanism

impacts the request message transmission in a 6LoW-

PAN network. We review the related work in Sec-

tion 6. Section 7 concludes the paper.

2 CAPABILITY TOKEN

A capability token contains access permissions

granted to a requester as well as the necessary infor-

mation to verify the ownership, integrity, and validity

of the capability token.

In our design, a capability token includes the fol-

lowing data.

• Issuer Identity (II) is a 4-byte-long unsigned in-

teger, which indicates the identity of the server

that issues this capability token.

CoAP Option for Capability-Based Access Control for IoT-Applications

267

• Subject Identity (SI) makes reference to the

owner of this capability token. SI is the IPv6 ad-

dress of the owner’s device.

• Object Identity (OI) makes reference to the tar-

get device which holds resources that the owner

of this capability token is able to access. OI is the

IPv6 address of the target device.

• Issued Time (IT) indicates the time at which

the capability token was issued. IT is a 4-byte-

long integer, representing how many seconds are

elapsed since the Epoch time.

• Not Before (NB) indicates the time at which the

capability token becomes valid. NB is a 4-byte-

long integer, representing how many seconds are

elapsed since the Epoch time.

• Not After (NA) indicates the time at which the ca-

pability token becomes expired. NA is a 4-byte-

long integer, representing how many seconds are

elapsed since the Epoch time.

• Permission List (PL) stores a set of access per-

missions granted to the owner of this capability to-

ken. Each access permission is composed of three

elements, resource path, request methods, and ad-

ditional conditions:

– Resource Path (RP) is the path to a resource.

– Request Methods (RM) indicates the types of

request methods granted to the owner for ac-

cessing RP. The deﬁnition of request meth-

ods is aligned with the deﬁnition in RFC

7252 (Shelby et al., 2014).

– Additional Conditions (AC) describes a set of

conditions which should be fulﬁlled when the

receiver decides on the authorization of an ac-

cess request to RP. The contents of additional

conditions could be related to requester’s lo-

cation information or receiver’s battery sta-

tus (Seitz et al., 2013) (Hern

andez et al., 2014).

• Issuer Signature (IS) stores the digital signature

signed by the issuer to provide authenticity and

integrity protection for the capability token.

• Token Sub-Identity (TI) is a 1-byte-long un-

signed integer, which stores the data to support the

issuer server in identifying this capability token.

In order to manage the issued capability tokens, an

issuer server also assigns each capability token with

an identity (ID). ID is a combination of the sub-

set of the contents of a capability token, which is

SI||OI||IT||NB||NA||TI. TI is usually assigned with 0.

Only when there exists two capability tokens having

the same SI, OI, IT, NB, and NA, one of the capability

tokens would be assigned with different value in TI

"capability_token":{

"II": 46804706,

"SI": "2002::8c71:65",

"OI": "2002::8c71:66",

"IT": 1447066800000,

"NB": 1447066800000,

"NA": 1447066800000,

"PL":[{"RP": "temperature",

"RM":["001"]}],

"IS": "jBghEa2aO8v;urVIbafsQad_d1fn",

"TI": 0

}

Figure 1: Example of a capability token.

to distinguish their identities. Besides, since ID de-

pends on other contents of the capability token, when

an issuer server generates a digital signature for the

capability token, ID would not be included in the cal-

culation. ID is also excluded when storing a capability

token on the requester’s device or sending a capabil-

ity token with a request message in order to save the

storage space and bandwidth.

Figure 1 shows an example of a capability to-

ken, which stores its contents in JSON format. The

capability token is used to obtain temperature data

from a sensor in a smart home environment. The

owner’s IPv6 address is “2002::8c71:65” and the sen-

sor’s IPv6 address is “2002::8c71:66”. “001” in RM

indicates the “GET” request method is granted to the

owner of this capability token for accessing the “tem-

perature” resource. NB equals to IT means this capa-

bility token is valid immediately after the capability

token was issued, and NA equals to NB means the va-

lidity time of this capability token is permanent. The

issuer server uses the Elliptic Curve Digital Signa-

ture Algorithm (ECDSA) with the secp112r1 curve

to generate SI, which is 28 bytes in length.

When the receiver obtains a capability token from

the request message, it ﬁrst examines NB and NA to

check whether the capability token is still valid. Then,

SI and OI are checked to insure the requester is the

owner of the capability token and the receiver is the

target device. Next, the receiver checks whether the

requested resource and request method have a match

in PL. If the matched access permission has additional

conditions, the receiver also needs to insure these con-

ditions are fulﬁlled. IS is veriﬁed at the last step,

because it costs more computational power than the

previous steps. If a request is rejected at the previous

steps, the high-cost digital signature calculation can

be avoided. Finally, if the digital signature is valid,

the receiver authorizes the request and processes the

request message.

IoTBD 2016 - International Conference on Internet of Things and Big Data

268

0123

01234567890123456789012345678901

IssuedTime

IssuerSignature

PermissionList

IssuerIdentity

SubjectIdentity

ObjectIdentity

ActivationTime

ValidityTime

bit

Opt.Delta&Len. Opt.Len.(Ext.) Dashboard

TokenSub‐Identity

Figure 2: The option ﬁelds of the Cap-Token option.

3 CAP-TOKEN OPTION

The Cap-Token option is designed for solving the

“payload ambiguity problem.” When sending a re-

quest message, the requester encapsulates a capability

token into the Cap-Token option and embeds the op-

tion into the message to be sent. The receiver extracts

the Cap-Token option from the request message and

obtains the capability token from the option.

Meanwhile, as a capability token is usually large

in size, the Cap-Token Option is proposed with a com-

pression mechanism to minimize the size of the op-

tion. The compression mechanism elides the option

ﬁelds of which the contents have a duplicate in other

CoAP ﬁelds or in the lower-layer protocols of the re-

quest message. The receiver relies on the duplicates

in the request message to restore those elided option

ﬁelds and “decompress” the Cap-Token option.

3.1 Option Fields

The Cap-Token option is composed of several option

ﬁelds which store the contents of a capability token.

It also has a length option ﬁeld to indicate the size of

the option.

Figure 2 shows the option ﬁelds of the Cap-Token

option. The ﬁrst byte indicates the difference between

the option number of the Cap-Token option and that

of the previous option. We deﬁne the option num-

ber of the Cap-Token option as 9, which implies this

option is a critical option and is safe-to-forward for

a proxy (Shelby et al., 2014). The second byte is

an extension ﬁeld indicating the size of the option.

The third byte is the “Dashboard” option ﬁeld, which

encodes the format of the option ﬁelds in the Cap-

Token option. The fourth byte stores the value of TI.

The next four ﬁelds seriatim store the value of II (4



01234567

AT VTS O PT

bit

Figure 3: The bit layout of the Dashboard ﬁeld.

bytes), SI (16 bytes), OI (16 bytes), and IT (8 bytes)

of the capability token. IP addresses are converted

to the network order before being stored. After these

four ﬁelds, the Activation Time ﬁeld stores the time

difference between IT and NB of the capability token.

The Validity Time ﬁeld indicates how long the capa-

bility token is valid, i.e., the time difference between

NA and NB. Both ﬁelds are unsigned integers and max-

imum 4 bytes in length. After the Validity Time ﬁeld,

the issuer signature is stored. The Permission List

ﬁeld is placed at the end of the Cap-Token option, be-

cause the length of the permission list varies by its

content.

3.2 Compression Mechanism

In the Cap-Token option, the compression mechanism

elides the option ﬁelds of which the contents have a

duplicate in other part of the request message. It lever-

ages the Dashboard ﬁeld to indicate whether an option

ﬁeld is compressed in the Cap-Token option. Figure 3

shows the bit layout of the Dashboard ﬁeld.

• Token Sub-Identity (T) (1 bit) indicates whether

the compression elides the Token Sub-Identity

ﬁeld in the Cap-Token option. The Token Sub-

Identity ﬁeld can be elided only when its value

equals to 0. If T = 1, the Token Sub-Identity

ﬁeld is carried in-line. Otherwise, the Token Sub-

Identity ﬁeld is elided and the receiver restores

this ﬁeld by assigning its value to 0.

• Subject Identity (S) (1 bit) indicates whether the

compression elides the Subject Identity ﬁeld in the

Cap-Token option. If S = 1, the Subject Iden-

tity ﬁeld is carried in-line. Otherwise, the Sub-

ject Identity ﬁeld is elided and the receiver uses

the source IP address of the request message to

restore this ﬁeld.

• Object Identity (O) (1 bit) indicates whether the

compression elides the Object Identity ﬁeld in the

Cap-Token option. If O = 1, the Object Iden-

tity ﬁeld is carried in-line. Otherwise, the Object

Identity ﬁeld is elided and the receiver uses the

destination IP address of the request message to

restore this ﬁeld.

• Activation Time (AT) (2 bits) indicates how

many bytes (bit value plus 1) are used to present

the Activation Time ﬁeld. For example, if AT = 1,

CoAP Option for Capability-Based Access Control for IoT-Applications

269

two bytes are used to present the Activation Time

ﬁeld.

• Validity Time (VT) (2 bits) indicates how many

bytes (bit value plus 1) are used to present the Va-

lidity Time ﬁeld.

• Permission List (P) (1 bit) indicates whether the

Permission List ﬁeld is compressed. If P = 0, the

ﬁeld is compressed; otherwise, no compression is

applied.

In the Permission List ﬁeld, when P = 0, the com-

pression mechanism elides the contents which have a

duplicate in other CoAP ﬁelds. For a valid CoAP re-

quest message, the resource path and request method

indicated by the CoAP header (more precisely, indi-

cated by the Uri-Path options and the Code ﬁeld of

CoAP) must have a duplicate in the Permission List

ﬁeld. So, the compression mechanism elides the du-

plicated resource path and request method in the Per-

mission List ﬁeld, and lets the receiver to restore the

permission list from the contents stored in the CoAP

header.

Algorithm 1 shows the pseudo code for compress-

ing a permission list. In the pseudo code, rPath and

rMethod are the resource path and request method in-

dicated by the CoAP header. pList is the permission

list of a capability token, which stores a set of ac-

cess permissions. The compression mechanism ﬁrst

searches pList to ﬁnd the access permission which has

the same resource path (RP) and request method (RM)

as rPath and rMethod. If the permission is found, the

matched resource path and request method in that per-

mission are elided. Using the permission list shown

in Figure 1 as an example, when sending a “GET” re-

quest message to obtain “temperature” data, we elide

the indicated resource path and request method as

well as elide the key part of a key-value pair in JSON

if its associated value is elided. The permission list

becomes “[{}]” after compression. The result is seri-

alized and stored in the Permission List ﬁeld.

4 EVALUATION

In this section we evaluate the performance of the

Cap-Token option and the compression mechanism.

We ﬁrst use an example to elaborate how many bytes

could be saved when compressing the Cap-Token op-

tion. Next, we study the overhead in terms of the

increase in the IP datagram size of a CoAP request

message when applying CBAC to an IoT network.

Algorithm 1: Compressing a permission list.

1: procedure COMPRESSPERMISSIONLIST

2: rPath ← path of the requested resource

3: rMethod ← the request method

4: pList ← permission list of a capability token

6: for each perm in pList do

7: if rPath matches the RP of perm then

8: if rMethod has a match in RM of perm then

9: Elide the rPath from perm

10: Elide the rMethod from perm

11: break

12: end if

13: end if

14: end for

15: end procedure

4.1 Beneﬁt of Compression

We use the capability token shown in Figure 1 as an

example to elaborate how many bytes could be saved

when compressing the Cap-Token option.

If compression is not applied, all option ﬁelds

shown in Figure 2 are kept in the Cap-Token option.

The uncompressed option requires 32 bytes for stor-

ing source and destination IP addresses, and 8 bytes

for recording the activation time and validity time.

The value of the permission list is serialized before

being stored in the option ﬁeld and the resulting string

is 35 bytes in length. The overall size of the uncom-

pressed Cap-Token option is 115 bytes.

When the compression mechanism is applied,

both Subject Identity ﬁeld and Object Identity ﬁeld

are elided. Since TI equals to 0, the Token Sub-

Identity ﬁeld can also be elided. The sizes of the Acti-

vation Time ﬁeld and Validity Time ﬁeld are reduced

to 1 byte, because the difference between IT and NB

and the difference between NA and NB are zero. More-

over, we assume the resource path and request method

described in PL have a duplicate in other CoAP ﬁelds,

so both are elided. The compression result of the per-

mission list is “[{}]”, which is 4 bytes in length after

serialization. The ﬁnal size of the compressed Cap-

Token option is 45 bytes.

Table 1 shows the comparison in terms of the

size between an uncompressed Cap-Token option and

a compressed Cap-Token option. Our compression

mechanism reduces 70 bytes when encapsulating a

capability token into the option. 60% of the original

size of the option is saved. Among those saved data,

31 bytes are reduced from compressing the Permis-

sion List ﬁeld. The rest 39 bytes are saved from com-

pressing other ﬁelds of the Cap-Token option. Such

a result shows that our compression mechanism can

minimize the size of the Cap-Token option, resulting

in a smaller IP datagram size.

IoTBD 2016 - International Conference on Internet of Things and Big Data

270

Table 1: Comparison of the size of the Cap-Token option

before and after compression.

Option Field

Uncompressed

Option

Compressed

Option

Option Header 2 2

Token Dashboard 1 1

Token Sub-Identity 1 0

Issuer Identity 4 4

Subject Identity 16 0

Object Identity 16 0

Issued Time 4 4

Activation Time 4 1

Validity Time 4 1

Issuer Signature 28 28

Permission List 35 4

Total (bytes) 115 45

4.2 Access Control Overhead

We deﬁne the overhead of applying an access control

model for an IoT network as the increase in the IP

datagram size in percentage. Equation 1 shows how

the overhead being calculated.

overhead =

(new size − original size)

original size

× 100% (1)

Here, we compare the overheads in three different

cases, which are: (1) directly attaching a capability

token at the end of CoAP, (2) adding an uncompressed

Cap-Token option, and (3) adding a compressed Cap-

Token option. The ﬁrst and third cases are used to

compare the overhead of our Cap-Token option with

the overhead of the capability token transmission ap-

proach proposed by previous work (Gusmeroli et al.,

2013) (Hern

andez-Ramos et al., 2013). The second

and third cases are used to demonstrate how the com-

pression mechanism reduces the overhead.

We calculate the overheads based on sending a

CoAP “GET” request message to obtain data from

the “/temperature” path of a sensor device. The ca-

pability token shown in Figure 1 is used for access

control and is sent with the request message. We

also assume that the Datagram Transport Layer Se-

curity (DTLS) (Rescorla and Modadugu, 2012)) is

adopted to secure the transmission of CoAP mes-

sages. The DTLS adopts AES-GCM (Dworkin, 2007)

as the cryptography algorithm, which uses a 128-bit-

long key for encryption and generates an 8-byte-long

integrity check value (ICV).

Table 2 shows the IP datagram of the CoAP re-

quest message if no access control is applied. At

the network layer, a LOWPAN IPHC header (Hui

and Thubert, 2011) is adopted to compress the IPv6

header, which results in 7 bytes in length. An 8-byte-

long Hop-by-Hop Options extension header, which

contains a RPL option (Hui and Vasseur, 2012), is

also included to support storing-mode routing in a

RPL network (Winter et al., 2012). At the transport

layer, the UDP header is compressed to 4 bytes ac-

cording to the deﬁnition in (Montenegro et al., 2007).

The DTLS header contains a 13-byte-long record

header and an 8-byte-long initialization vector. In the

DTLS payload, the CoAP header occupies 5 bytes

The Uri-Host and Uri-Port options are set to default,

so both options are not present. The Uri-Path option

occupies 12 bytes to specify the path to the resource.

The contents of the DTLS payload are encrypted by

AES-GCM and are followed by an 8-byte-long ICV.

Summarily, the overall IP datagram size is 65 bytes

when CBAC is not applied.

Table 2: The IP datagram of the CoAP request message

without any access control protection.

Layer Header or Payload

Size

(byte)

Network

Compressed IPv6 header 7

Hop-by-Hop Options 8

Transport

Compressed UDP header 4

DTLS header

Record header 13

Initialization vector 8

DTLS payload

CoAP header 5

Uri-Path option 12

DTLS ICV 8

Total size 65

When applying CBAC for an IoT network, it re-

quires every request message being transmitted with

a capability token. If we directly attache the capabil-

ity token at the end of the CoAP, the content of the

capability token is serialized and the result is attached

behind the Uri-Path option. Because the Uri-Path op-

tion has its own length ﬁeld, unlike attaching behind

CoAP payload, the receiver can still retrieve the ca-

pability token from the message. In such a case, the

serialized capability token is 198 bytes in length. The

overhead of directly attaching a capability token at the

end of CoAP is 304%.

On the other hand, encapsulating a capability to-

ken into the Cap-Token option can reduce the increase

in the IP datagram size, because most special char-

acters used by JSON (such as comma, colon, and

quotation marks) are removed during the encapsula-

tion process. After embedding an uncompressed Cap-

Token option into the CoAP request message, the in-

We assume the CoAP header uses 1 byte for Version

and Type, 1 byte for Code ﬁeld, 2 bytes for Message ID

ﬁeld, and 1 byte for Token ﬁeld. The last ﬁeld is used for

matching a response message with a request message.

CoAP Option for Capability-Based Access Control for IoT-Applications

271

Table 3: Comparison of the IP datagram sizes and over-

heads in difference cases.

IP datagram Size Overhead

Case 0 65 bytes -

Case 1 263 bytes 304 %

Case 2 180 bytes 176 %

Case 3 110 bytes 69 %

Case 0: no access control protection.

Case 1: attaching a capability token.

Case 2: uncompressed Cap-Token option.

Case 3: compressed Cap-Token option.

crease in the IP datagram size reduces to 115 bytes.

The overhead decreases to 176%. Compressing the

Cap-Token option further reduces the increase in the

IP datagram size. As shown in our previous analy-

sis, the compressed Cap-Token option is 45 bytes in

length. The overhead becomes 69% after compress-

ing the Cap-Token option.

Table 3 compares the IP datagram sizes and over-

heads in different cases. The results show that attach-

ing a capability token at the end of CoAP not only suf-

fers the payload ambiguity problem, it also generates

the largest IP datagram, which is 263 bytes. Compar-

atively, using the Cap-Token option to encapsulate a

capability token reduces the IP datagram size by 83

bytes. When the compression mechanism is applied,

the IP datagram size further reduces to 110 bytes,

which is only 41% of the IP datagram size when at-

taching a capability token at the end of CoAP. The

overhead is reduced by 235%. This demonstrates that

our Cap-Token option and the compression mecha-

nism not only solve the payload ambiguity problem,

they also reduce the IP datagram size.

5 DISCUSSION

A beneﬁt of using the compressed Cap-Token option

is that it results in fewer data link frames when trans-

mitting the CoAP request message over a 6LoWPAN

network. Because the maximum frame size deﬁned

in IEEE 802.15.4 is 127 bytes, a large IP datagram

will be fragmented into several data link frames be-

fore transmission. Since an intermediate router needs

to collect all data link frames to determine the next

forwarding target. Losing any data link frame means

the entire message is lost. Hence, generating fewer

data link frames for a request message in a 6LoW-

PAN network would result in a better success rate on

delivering request messages.

Based on our results in the previous section as an

example, directly attaching a capability token at the

end of CoAP would generates 3 data link frames. Al-

though using an uncompressed Cap-Token option re-

duces the IP datagram size, the size is still larger than

127 bytes. So, the request message is fragmented

into 2 data link frames. Only when using a com-

pressed Cap-Token option, the IP datagram can be

ﬁtted in one IEEE 802.15.4 frame. The generated

data link frames of the above three cases are shown

in Table A1, A2, and A3 in Appendix, respectively.

Thus we conclude that using the Cap-Token option

and compression mechanism can reduce the chance of

the occurrence of the link-layer fragmentation when

sending CoAP request messages. It also improves

the success rate of delivering request messages over

a 6LoWPAN network.

6 RELATED WORK

Many researchers have adopted the CBAC model

for an IoT network. Mahalle et al. (Mahalle et al.,

2012a), (Mahalle et al., 2012b) treated a capability

token as a permission for setting up a connection with

an IoT device. However, their design doesn’t send

every CoAP request message with a capability token,

breaking the stateless rule of REST. Besides, no ﬁne-

grained access permission is deﬁned in the capabil-

ity token to control the access of resources hosted on

the target device. Gusmeroli et al. (Gusmeroli et al.,

2013) proposed a design for capability tokens to sup-

port the principle of least privilege. However, their

design relies on a centralized authorization server to

decide on the authorization. This makes their design

hard to be deployed in an IoT network where a cen-

tralized authorization server is hard to deploy. In the

work done by Hern

andez-Ramos et al. (Hern

andez-

Ramos et al., 2013), (Hern

andez-Ramos et al., 2014),

an IoT device can decide on the authorization by it-

self without the intervention of a centralized autho-

rization server. However, when sending a CoAP re-

quest message, their design directly attaches a capa-

bility token behind the CoAP payload. This causes

a receiver hard to retrieve the capability token from

the request message, because CoAP does not deﬁne

a length ﬁeld to indicate its payload size. To prevent

a capability token from being mixed up with the con-

tents of CoAP, both Seitz et al. (Seitz et al., 2013) and

Pereira et al. (Pereira et al., 2014) proposed to use a

CoAP option to encapsulate a capability token. But,

no detail design of the option is mentioned in their

paper. Hence, we can conclude that none of existing

work has provided a good solution for the “payload

ambiguity problem” and considered how to reduce the

IP datagram size after applying CBAC for an IoT net-

work.

IoTBD 2016 - International Conference on Internet of Things and Big Data

272

7 CONCLUSION

In this paper, we propose the Cap-Token option to

solve the payload ambiguity problem when applying

the capability-based access control model for an IoT

network. Because the Cap-Token option is indepen-

dent form other CoAP ﬁelds and the option knows

its size, we can prevent a capability token from being

mixed up with the contents of other CoAP ﬁelds. Be-

sides, we also propose a compression mechanism to

reduce the size of the Cap-Token option. Our evalua-

tion shows that the compression mechanism can save

the size of the Cap-Token option by 60%. This also

helps decrease the overhead (the increase in the IP

datagram size) after applying CBAC for an IoT net-

work. Our results show that the overhead of adding a

compressed Cap-Token option to a request message is

only 69%, while adding an uncompressed Cap-Token

option is 176% and directly attaching a capability to

the end of CoAP is 304%. The smaller IP datagram

size also helps generate fewer data link frame when

sending a CoAP request message over a 6LoWPAN

network.

Our future work focuses on solving the storage

consumption problem on the requester’s device. Be-

cause the current design only allows a capability to-

ken to be used to access a particular device, a re-

quester has to acquire at least N capability tokens if

attempting to access the resources hosted on N IoT

devices. This may consume a large amount of stor-

age space in a large IoT use case, such as smart city.

Hence, we plan to design a new type of capability to-

ken to tackle this problem.

REFERENCES

Alghamdi, T., Lasebae, A., and Aiash, M. (2013). Security

Analysis of the Constrained Application Protocol in

the Internet of Things. In Second International Con-

ference on Future Generation Communication Tech-

nology, pages 163–168.

Dworkin, M. (2007). Recommendation for Block Cipher

Modes of Operation: Galois/Counter Mode (GCM)

and GMAC. Technical report, National Institute of

Standards and Technology.

Granjal, J., Monteiro, E., and Sa Silva, J. (2015). Secu-

rity for the Internet of Things: A Survey of Existing

Protocols and Open Research Issues. IEEE Commu-

nications Surveys Tutorials, 17(3):1294–1312.

Gusmeroli, S., Piccione, S., and Rotondi, D. (2013). A

Capability-based Security Approach to Manage Ac-

cess Control in the Internet of Things. Mathematical

and Computer Modelling, 58:1189–1205.

Hern

andez, J. L., Moreno, M. V., Jara, A. J., and Skarmeta,

A. F. (2014). A Soft Computing Based Location-

aware Access Control for Smart Buildings. Soft Com-

puting, 18(9):1659–1674.

Hern

andez-Ramos, J. L., Jara, A. J., Mar

ın, L., and G

omez,

A. F. S. (2014). DCapBAC: Embedding Authorization

Logic into Smart Things through ECC Optimizations.

International Journal of Computer Mathematics, 0:1–

22.

Hern

andez-Ramos, J. L., Jara, A. J., Mar

ın, L., and

Skarmeta, A. F. (2013). Distributed Capability-based

Access Control for the Internet of Things. Journal of

Internet Services and Information Security, 3:1–16.

Hui, J. W. and Thubert, P. (2011). Compression Format for

IPv6 Datagrams over IEEE 802.15.4-Based Networks.

RFC 6282.

Hui, J. W. and Vasseur, J. (2012). The Routing Protocol

for Low-Power and Lossy Networks (RPL) Option for

Carrying RPL Information in Data-Plane Datagrams.

RFC 6553.

Mahalle, P., Anggorojati, B., Prasad, N., and Prasad, R.

(2012a). Identity Driven Capability based Access

Control (ICAC) Scheme for the Internet of Things.

In 2012 IEEE International Conference on Advanced

Networks and Telecommunications Systems, pages

49–54.

Mahalle, P., Anggorojati, B., Prasad, N., and Prasad,

R. (2012b). Identity Establishment and Capability

based Access Control (IECAC) Scheme for Internet

of Things. In 15th International Symposium on Wire-

less Personal Multimedia Communications (WPMC),

pages 187–191.

Montenegro, G., Kushalnagar, N., Hui, J. W., and Culler,

D. E. (2007). Transmission of IPv6 Packets over IEEE

802.15.4 Networks. RFC 4944.

Nguyen, K. T., Laurent, M., and Oualha, N. (2015). Survey

on Secure Communication Protocols for the Internet

of Things. Ad Hoc Networks, 32:17–31.

Pereira, P., Eliasson, J., and Delsing, J. (2014). An Authen-

tication and Access Control Framework for CoAP-

based Internet of Things. In 40th Annual Confer-

ence of the IEEE Industrial Electronics Society, pages

5293–5299.

Rescorla, E. and Modadugu, N. (2012). Datagram Trans-

port Layer Security Version 1.2. RFC 6347.

Roman, R., Zhou, J., and Lopez, J. (2013). On the Features

and Challenges of Security and Privacy in Distributed

Internet of Things. Computer Networks, 57(10):2266–

2279.

Seitz, L. and Gerdes, S. (2015). Use Cases for Authentica-

tion and Authorization in Constrained Environments.

IETF Draft.

Seitz, L., Selander, G., and Gehrmann, C. (2013). Autho-

rization Framework for the Internet-of-Things. In 14th

IEEE International Symposium and Workshops on a

World of Wireless, Mobile and Multimedia Networks,

pages 1–6.

Shelby, Z., Hartke, K., and Bormann, C. (2014). The Con-

strained Application Protocol (CoAP). RFC 7252.

Winter, T., Thubert, P., Brandt, A., Hui, J. W., Kelsey,

R., Levis, P., Pister, K., Struik, R., Vasseur, J., and

CoAP Option for Capability-Based Access Control for IoT-Applications

273

Alexander, R. K. (2012). RPL: IPv6 Routing Protocol

for Low-Power and Lossy Networks. RFC 6550.

APPENDIX

Here we show how many data link frames are gen-

erated when sending a CoAP request message with a

capability token and (1) directly attaching the capabil-

ity token at the end of CoAP (Table A1), (2) encapsu-

lating the capability token into the Cap-Token option

(Table A2), and (3) encapsulating the capability token

into the Cap-Token option and compressing the op-

tion (Table A3). We assume that the link-layer header

occupies 9 bytes, which includes the Frame Check Se-

quence. PAN ID is elided and short MAC addresses

are used. If the link-layer fragmentation occurs, ad-

ditional fragmentation header would be added to the

adaptation layer, which occupies 4 bytes in the ﬁrst

frame and occupies 5 bytes in the succeeding frames.

Table A1: The data link frames of the CoAP request mes-

sage when attaching a capability token at the end of CoAP.

data link frame

Layer Header or Payload

Size

(byte)

Data Link IEEE 802.15.4 header 9

Adaptation Fragmentation header 4

Network

Compressed IPv6 header 7

Hop-by-Hop Options 8

Transport

Compressed UDP header 4

DTLS header

Record header 13

Initialization vector 8

DTLS payload

Total size 127

data link frame

Layer Header or Payload

Size

(byte)

Data Link IEEE 802.15.4 header 9

Adaptation Fragmentation header 5

Transport DTLS payload

113

Total size 127

data link frame

Layer Header or Payload

Size

(byte)

Data Link IEEE 802.15.4 header 9

Adaptation Fragmentation header 5

Transport

DTLS payload

DTLS ICV 8

Total size 50

The DTLS payload is composed of the CoAP header, the Uri-Path option,

and the serialized capability token.

Table A2: The data link frames of the CoAP request mes-

sage when using an uncompressed Cap-Token option.

data link frame

Layer Header or Payload

Size

(byte)

Data Link IEEE 802.15.4 header 9

Adaptation Fragmentation header 4

Network

Compressed IPv6 header 7

Hop-by-Hop Options 8

Transport

Compressed UDP header 4

DTLS header

Record header 13

Initialization vector 8

DTLS payload

Total size 127

data link frame

Layer Header or Payload

Size

(byte)

Data Link IEEE 802.15.4 header 9

Adaptation Fragmentation header 5

Transport

DTLS payload

DTLS ICV 8

Total size 80

The DTLS payload is composed of the CoAP header, the Uri-Path option,

and the uncompressed Cap-Token option.

Table A3: The data link frame of the CoAP request message

when using a compressed Cap-Token option.

data link frame

Layer Header or Payload

Size

(byte)

Data Link IEEE 802.15.4 header 9

Network

Compressed IPv6 header 7

Hop-by-Hop Options 8

Transport

Compressed UDP header 4

DTLS header

Record header 13

Initialization vector 8

DTLS payload

CoAP header 5

Uri-Path option 12

Cap-Token option 45

DTLS ICV 8

Total size 119

IoTBD 2016 - International Conference on Internet of Things and Big Data

274
