Sampling and Evaluating the Big Data for Knowledge Discovery
Andrew H. Sung
1
, Bernardete Ribeiro
2
and Qingzhong Liu
3
1
School of Computing, The University of Southern Mississippi, Hattiesburg, MS 39406, U.S.A.
2
Department of Informatics Engineering, University of Coimbra, 3030-290 Coimbra, Portugal
3
Department of Computer Science, Sam Houston State University, Huntsville, TX 77341, U.S.A.
Keywords: Data Analytics, Knowledge Discovery, Sampling Methods, Quality of Datasets.
Abstract: The era of Internet of Things and big data has seen individuals, businesses, and organizations increasingly
rely on data for routine operations, decision making, intelligence gathering, and knowledge discovery. As the
big data is being generated by all sorts of sources at accelerated velocity, in increasing volumes, and with
unprecedented variety, it is also increasingly being traded as commodity in the new “data economy” for
utilization. With regard to data analytics for knowledge discovery, this leads to the question, among various
others, of how much data is really necessary and/or sufficient for getting the analytic results that will
reasonably satisfy the requirements of an application. In this work-in-progress paper, we address the sampling
problem in big data analytics and propose that (1) the problem of sampling the big data for analytics is
“hard”specifically, it is a theoretically intractable problem when formal measures are incorporated into
performance evaluation; therefore, (2) heuristic, rather than algorithmic, methods are necessarily needed in
data sampling, and a plausible heuristic method is proposed (3) a measure of dataset quality is proposed to
facilitate the evaluation of the worthiness of datasets with respect to model building and knowledge discovery
in big data analytics.
1 INTRODUCTION
As the Internet of Things (IoT) connects an ever
increasing variety of devices, sensors, and other
physical objects to the Internet, the big data will only
get bigger and usher in the era of the “data economy”,
where businesses and organizations generate, buy, and
sell data much like commodity (Datanami, 2016).
For many applications in data analytics, such as
business intelligence, the “value” of a dataset is
directly proportional to its volume. However, for
applications such as knowledge mining or scientific
discovery, where the results of data analytics needs to
be deeper than merely descriptive (e.g. finding
frequent items sets in shopping baskets or correlation
among features in patient datasets), the value of a
dataset may not necessarily be proportional to its
volume. This is because to extract the heretofore
unknown knowledge from the available data (say, by
first building a learning machine model, then validate
it), the available data must be of sufficiently good
quality to allow model building without resulting in
overfitting or underfitting, etc., and the quality of the
data has little to do with its quantity. Worse, there are
problems where data is plentiful and clearly provides
hope for knowledge discovery that will lead to new
insights or solutions, but the quality of the data is
insufficient. For examples: important features may
have been overlooked and not measured and collected
at all, such as in a patient dataset; or the features are
not even directly available, such as in the
cybersecurity problem of detecting steganography or
the multimedia forensics problem of detecting image
tampering (Liu et al., 2015); for another perspective,
see (Wiederhold, 2016).
This leads to two questions in dealing with the big
data analytics for knowledge discovery: 1. how to
sample a given dataset to facilitate good model
building for knowledge discovery; 2. how to evaluate
the quality of datasets with respect to their potential
for sound knowledge discovery?
The second question is interesting and very
challenging: in view of the rapidly evolving landscape
of the data economy, an effective and practicable
measure of data quality will be extremely helpful;
however, the question seems too application
dependent to allow universally applicable measures to
be developed such as the common statistics-based
formulas, e.g. sample mean vs. population mean,
confidence intervals, etc. (Hastie et al., 2009).
378
Sung, A., Ribeiro, B. and Liu, Q.
Sampling and Evaluating the Big Data for Knowledge Discovery.
DOI: 10.5220/0005932703780382
In Proceedings of the International Conference on Internet of Things and Big Data (IoTBD 2016), pages 378-382
ISBN: 978-989-758-183-0
Copyright
c
2016 by SCITEPRESS Science and Technology Publications, Lda. All rights reserved
This position paper addresses the first question,
namely how to sample a dataset for performing
analytics in knowledge discovery. It is noted that, in
addition to sampling, feature selection is also an
important task in preprocessing datasets for analytics
(and it likewise contributes to reducing the volume by
eliminating useless features), and many feature
selection methods have been proposed and studied
experimentally to evaluate their performance, e.g.
(Guyon and Elisseeff, 2003) (Liu et al., 2006). In
contrast, there are relatively fewer studies on
sampling, even though the problem is equallyif not
moreimportant, especially for data analytics tasks in
the current era of big data.
We show that the sampling problem is intractable
in a formal sense, thereby necessitates heuristic
methods for solution. We then propose a practical
method for sampling as a promising method deserving
experimental study for further refinement. Finally,
based on our ongoing study of the critical sampling
problem, and in conjunction with our previous study
on the concomitant problem of feature selection, a
metric for dataset qualitywith respect to its capacity
for knowledge discovery through data miningis
proposed as a first step in developing more practically
useful metrics for dataset quality.
2 CRITICAL SAMPLING
In this section we outline a proof that the problem of
selecting an optimal sample for model building using
learning machines is intractable. To analyze the
problem in a formal setting, assume a given dataset is
represented as an n by p matrix D
n,p
with n points or
patterns, each represented as a p-dimensional vector.
In other words, the relevant datasets from the big data
have been selected and fully integrated into a uniform
format before the data analytics task commences, this
assumption may be simplistic but makes the proof
easier without losing generality.
The concept of the Critical Sampling Size of a
dataset with n points is that there may exist, with
respect to a specific learning machine M and a given
performance threshold T, a unique number
ν
n such
that the performance of M exceeds T when some
suitable sample of
ν
data points is used; further, the
performance of M is always below T when any sample
with less than
ν
data points is used. Thus,
ν
is the
critical (or absolute minimal) number of data points
required in any sample to ensure that the performance
of M meets the given performance threshold T.
Formally, for dataset D
n
with n points (the number
of features in the dataset, p, is considered fixed here
when we are concerned only with sampling, and
therefore dropped as a subscript of the data matrix
D
n,p
),
ν
(an integer between 1 and n) is called the T-
Critical Sampling Size of (D
n
, M) if the following two
conditions hold:
1. There exists D
ν
, a
ν
-point sampling of D
n
(i.e., D
ν
contains
ν
of the n vectors in D
n
) which lets M
achieve a performance of at least T, i.e.,
(D
ν
D
n
) [P
M
(D
ν
) T], where P
M
(D
ν
) denotes
the performance of M on dataset D
ν
.
2. For all j <
ν
, a j-point sampling of D
n
fails to let
M achieve performance of at least T, i.e.,
(D
j
D
n
) [j <
ν
P
M
(D
j
) < T]
In the above, the specific meaning of P
M
(D
ν
), the
performance of machine (or algorithm) M on sample
D
ν
, is left to be defined by the user to reflect a
consistent setup of the data analytic (e.g. data mining)
task and the associated performance measure. For
examples, the setup may be to train the machine M
with D
ν
and define P
M
(D
ν
) as the overall testing
accuracy of M on a fixed test set which is distinct
from D
ν
; alternatively, the setup may be to use D
ν
as
training set and use (D
n
D
ν
) or a subset of it as the
testing set. The value of threshold T, which is to be
specified by the user as well, represents a reasonable
performance requirement or expectation of the
specific learning machine that is used for the data
analytic task.
To determine whether a critical sampling size
exists, for a D
n
and M combination, is a very difficult
problem. Precisely, the problem of deciding, given
D
n
, T, k (1 < k n), and a fixed M, whether k is the T-
critical sampling size of (D
n
, M) belongs to the class
D
P
= {L
1
L
2
| L
1
NP, L
2
coNP}, where it is
assumed that the given machine M runs in polynomial
time (in n). In fact, it can be shown to be D
P
-hard, as
presented next.
2.1 Critical Sampling Problem is Hard
The problem is first restated formally: Let CSSP (the
Critical Sampling Size Problem) be the problem of
deciding if a given k is the T-critical sampling size of
a given dataset D
n
when a learning machine M is
used. Then we show that the problem belongs to the
class D
P
under the assumption that, for any D
i
D
n
,
whether P
M
(D
i
) T can be decided in polynomial (in
n) time, i.e., the machine M can “process” D
i
and has
its performance measured against T in polynomial
time. Otherwise, the problem may belong to some
possibly larger complexity class, e.g., Δ
p
2
. Note here
Sampling and Evaluating the Big Data for Knowledge Discovery
379
that NP (NP coNP) D
P
Δ
p
2
in the
polynomial hierarchy of complexity classes (Garey
and Johnson, 1979).
To prove that the CSSP is a D
P
-hard problem, we
take a known D
P
-complete problem and transform it
into the CSSP. We begin by considering the maximal
independent set problem. In graph theory, a Maximal
Independent Set (MIS) is an independent set that is
not a subset of any other independent set; so the size
of an MIS of the graph is between 1 and n, the number
of nodes; also, a graph may have multiple MIS’s.
EXACT-MIS Problem (EMIS) – Given a graph
with n nodes, and k n, decide if there is a maximal
independent set of size exactly k in the graph. This is
a problem proved to be D
P
-complete (Papadimitriou
and Yannakakis 1984). Now we describe how to
transform the EMIS problem to the CSSP.
Given an instance of EMIS (a graph G with n
nodes, and integer k n), construct an instance of the
CSSP such that the answer to the given instance of
EMIS is Yes iff the answer to the constructed instance
of CSSP is Yes, as follows: let dataset D
n
represent
the given graph G with n nodes (e.g., D
n
is made to
contain n data points, each with n features,
representing the symmetric adjacency matrix of G);
let T be the value T from the binary range {T, F};
let
ν
= k be the value in the given instance of EMIS;
and let M, the learning machine, be simply an
algorithm that decides if the dataset represents a
graph containing an MIS of size exactly
ν
, if yes P
M
= T, otherwise P
M
= F; then a given instance of
the D
P
-complete EMIS problem is transformed into
an instance of the CSSP.
To explain the transformation in the proof, three
examples are shown for the given instance of EMIS
in Figure 1.
0 0 1 1 0 0
0 0 0 1 0 0
1 0 0 1 1 0
1 1 1 0 1 1
0 0 1 1 0 1
0 0 0 1 1 0
Figure 1: A 6-node graph with multiple MIS of 3 nodes:
{1,2,5}, {1,2,6}, {2,3,6}.
Example 1: k=3. Threshold T = T from the
binary range {T, F} to mean true,
ν
= 3, and an MIS
of size 3 exists in D
6
as highlighted in the adjacency
matrix of G above. So, algorithm M that decides if the
dataset D
6
contains an MIS of size exactly 3 (or M
verifies that some D
3
corresponds to a MIS of size
3) succeeds; i.e., P
M
(D
3
) = Tfor some D
3
. Since the
solution to the instance of EMIS problem is Yes,
solution to the constructed instance of the CSSP is
also yes, as required for a correct transformation.
Example 2: k=4. The constructed instance of
CSSP has T = T and
ν
= 4. From D
6
it can be seen
that there does not exist any independent sets of size
4, so no exact MIS of size 4 exists. Let M be an
algorithm that decides if the dataset D
6
represents a
graph containing a maximal independent set of size 4.
In this instance M fails to find an exact MIS of size 4
and thus P
M
= F, i.e., P
M
(D
4
) = F for all possible
D
4
. So the solution to the constructed instance of
CSSP is No, as is the solution to the given instance of
EMIS.
Example 3: k=2. The constructed instance of
CSSP has T = T and
ν
= 2. Independent sets of size
2 exist but they are not MIS’s, so algorithm M that
decides that some D
2
D
6
correspond to an MIS of
size exactly 2 fails. The solution to the constructed
instance of CSSP is No, as is the solution to the given
instance of EMIS, as required.
The D
P
-hardness of the Critical Sampling Size
Problem indicates that it is both NP-hard and coNP-
hard; therefore, it’s most likely to be intractable (that
is, unless P = NP).
In mining a big dataset D
n,p
the data analyst is
naturally interested in obtaining D
ν
,
μ
(a
ν
-point
sampling with
μ
selected features, and hopefully
ν
<<
n and
μ
<< p) to achieve high accuracy in model
building or knowledge extraction. From the above
analysis of the CSSP and the analysis of the Critical
Feature Dimension Problem in (Suryakumar, Sung,
and Liu, 2014), this is clearly a highly intractable
problem and therefore calls for heuristic solutions.
Discussions: the proof outlined above is rather
general and its validity depends on a loose definition
of “learning machines”. The conclusion that
determining the critical sampling size for a given
learning machine with respect to a given performance
criteria is highly intractable, however, is hardly
surprising, as many other optimality problems
pertaining to machine learning have been proved to
be intractable.
2.2 Heuristic Method for Finding
Critical Sampling
Due to the symmetry or similarity of the CSSP and
CFDP problems and the convincing examples of
using simple heuristic methods to solve the CFDP
problem (Suryakumar et al., 2013), we are naturally
led to believe that simple heuristic methods can be
developed to be sufficiently useful for practical
purposes in solving the CSSP problem. Therefore,
IoTBD 2016 - International Conference on Internet of Things and Big Data
380
proposed in the following is a heuristic method for
finding a critical sampling:
1. Apply a clustering algorithm like k-means to
partition D
n
into k clusters. (The choice of k may
be determined, for example, by the number of
classes that the learning machine is intended to be
trained for performing classification.)
2. Select, say randomly, m points from each cluster
to form a sampling with mk points. (The value m
is set to be fairly small.)
3. Supplement the sampling with additional dk (for
some d) points, selected randomly from the whole
dataset D
n
, to form a sampling D.
4. Apply M (learning machine, analytic algorithm,
etc.) on the sample, then measure performance
P
M
(D).
5. If P
M
(D) T, then D is a critical sampling, and its
size
ν
is the critical sampling size for (D
n
, M).
Otherwise enlarge D by randomly select another
m points from each cluster, then supplement with
additional, randomly selected points from the
entire dataset, and repeat the above procedure
until a critical sampling is found, or until the
whole D
n
is exhausted and procedure fails to
find
ν
.
The values of the parameters k and m are to be
decided in consideration of the size and nature of the
dataset, the specific data analytic problem or task
being undertaken, and the amount of resource
available. As usual in all data analytic problems, prior
knowledge and domain expertise are always helpful
in designing the experimental setup. Likewise,
whether the random sampling is done with or without
replacement is a decision to be made according to the
dataset and the problem. Also, experiments may need
to be performed repeatedly and adaptively (with
regard to k and m) to obtain good results.
The authors are conducting experiments on many
large datasets that are publicly available to observe if
the “critical sampling size” indeed exists for most
datasets, and if so whether it is generally much
smaller than the size of the whole dataset.
3 DATASET QUALITY METRICS
As more and more networked physical objects
become components of the Internet of Things and
techniques of big data analytics advance (NRC,
2013), the society is experiencing the transformation
into a “data economy” where individuals, businesses,
and organizations alike are contributing to both the
generation and consumption of the big data. Further,
various types of data may be traded in the market
place much like commodity.
There are many techniques of data mining for
different purposes; an ultimate goal of data analytics,
however, is knowledge discovery for problems that
have thus far defied solutions through conventional
methods of study. Many believe that in the big data
one can find the answers to complex problems, if only
there is sufficient amount of data (that contains
sufficient amount of knowledge) and that proper
analytic techniques are applied. This belief, in fact, is
one of the driving forces of the big data phenomenon:
the exponential growth of data in nearly all areas of
human activity and interest.
In view of the above, a quantitative measure for
the quality of datasets would be very useful for all
concerned in big data analytics.
With regard to the capacity or potential for
knowledge discovery or knowledge extraction from a
dataset, we propose the following quality metrics for
a given dataset D
n,p
(the dataset is represented as a
matrix with n points, each represented as a p-
dimensional vector).
From the concept of the critical sampling size
discussed in Section 2, the Sample Quality of D
n,p
is
defined as
Q
s
=
ν
/ n
where
ν
is the critical sampling size of D
n,p
. So,
ν
n; and
ν
= 0, by definition, if the critical sample does
not exist (or, equivalently, heuristic methods for
finding
ν
fail), in which case Q
s
= 0 as well. In the
optimal case,
ν
= n and so Q
s
= 1, indicating that all
data in the dataset are essential for the data mining task
for knowledge discovery.
Likewise, the Feature Quality of D
n,p
is defined as
Q
f
=
μ
/ p
where
μ
is the critical feature dimension of D
n,p
(Suryakumar, Sung, and Liu, 2014). So,
μ
p; and
μ
= 0, by definition, if no critical feature sets exist, in
which case Q
f
= 0 as well, indicating that the dataset
is insufficient due to the lack of certain features that
are necessary. In the optimal case, Q
f
= 1 when
μ
= p,
indicating that all the features are essential for the
data mining for knowledge discovery task.
Q
D
, the Overall Quality of the dataset D
n,p
(with
respect to a specific learning machine M that is applied
in mining it for model building and knowledge
discovery), can therefore be defined as
Q
D
= Q
s
× Q
f
=
ν
×
μ
 × 
Note that 0 Q
D
1. Q
D
= 0 when either the critical
feature set or critical sample does not exist (or cannot
Sampling and Evaluating the Big Data for Knowledge Discovery
381
be found experimentally, with the respective heuristic
methods employed to find them), indicating that the
dataset is inadequate for the purpose of model
building to achieve acceptable performance. At the
other extreme, Q
D
= 1 when
ν
= n and
μ
= p,
indicating that the dataset D
n,p
is indeed optimal, in
terms of both the number of features and the number
of data points, when it is evaluated with respect to the
data mining task of model building and knowledge
discovery for the problem under study.
4 CONCLUDING REMARKS
This position paper addresses the dataset sampling
problem in model building for knowledge discovery.
The issue of data mining and association rule
extraction, etc. from small samples of large datasets
have been studied by many authors before (Domingo
et al., 2002) (Provost et al., 1999), and sampling
techniques have been studied extensively. However,
the problem of the critical sampling size of a dataset
has not been studied thoroughly. It is shown in this
paper that the problem of searching for an optimal
sampling is, unsurprisingly, intractable, as in many
other optimality problems encountered in machine
learning and data mining. Inspired by previous
successful results of using heuristic methods to find
optimal feature set, we similarly propose a heuristic
method for finding an optimal sample of a dataset.
Finally, a quality metric for a dataset, which is
computed experimentally by finding a critical feature
set and a critical sample, is proposed. This measure
indicates the percentage of data in the dataset that is
essential for model building in knowledge discovery
to meet performance requirements. A low value (close
to 0) indicates that the dataset contains much
“unimportant” data; an exact zero (0) value indicates
that the dataset is in fact inadequate for model
building; while a high value (close to 1) indicates that
the dataset is “knowledge-intensive” and contains
very little unimportant data.
It is our position that the proposed quality
metricperhaps combined with some of the statistics
based “static” measures (i.e. those computed from the
dataset alone without having to carry out experiments
using learning machines)holds great promise to be
refined into practically useful quality measures for
datasets, which will be very helpful to the big data
industry in the emerging “data economy”.
The authors’ ongoing study includes investigating
the possible interrelation between critical feature
dimension and critical sampling, as well as conducting
experiments on different datasets for proof of concept.
REFERENCES
Datanami, 2016. Finding Your Way in the New Data
Economy (by A. Woodie).
http://www.datanami.com/2016/01/25/finding-your-way-
in-the-new-data-economy/
Liu, Q., Sung, A.H., Chen, Z. and Chen, L., 2015.
Exploring Image Tampering with the Same
Quantization Matrix, in Multimedia Data Mining and
Analytics
Disruptive Innovation (Editors: Baughman,
A.K., Gao J., Pan J-Y., and Petrushin V.) Springer,
pp.327-343.
Wiederhold, G., 2016. Unbalanced Data Leads to Obsolete
Economic Advice, Communications of the ACM, Vol.
59 No. 1, pp.45-46.
Hastie, T., Tibshirani, R. and Friedman, J., 2009. The
Elements of Statistical Learning, Data Mining,
Inference, and Prediction. 2
nd
Edition, Springer, 2009.
Guyon, I., Elisseeff, A., 2003. An Introduction to Variable
and Feature Selection, Journal of Machine Learning
Research, Vol 3, pp.1157-1182.
Liu, Q., Sung, A.H., Xu, J., Liu, J. and Chen, Z., 2006.
Microarray Gene Expression Classification based on
Supervised Learning and Similarity Measures.
Proceedings of 2006 IEEE International Conference on
Systems, Man, and Cybernetics, Vol. 6, pp.5094-5099.
Garey, M.R., Johnson, D.S., 1979. Computers and
Intractability: A Guide to the Theory of NP-
Completeness, W. H. Freeman and Compnay.
Suryakumar, D., Sung, A.H. and Liu, Q., 2014. The Critical
Dimension Problem: No Compromise Feature
Selection. Proceedings of eKNOW 2014, The Sixth
International Conference on Information, Process, and
Knowledge Management, pp.145-151.
Domingo, C., Gavaldà, R. and Watanabe, O., 2002.
Adaptive sampling methods for scaling up knowledge
discovery algorithms, Data Mining and Knowledge
Discovery, Kluwer Academic Publishers, Vol. 6 No. 2,
pp.131-152, 2002.
National Research Council, 2013. Frontiers in Massive
Data Analysis, The National Academies Press.
Papadimitriou, C.H.,Yannakakis, M., 1984. The complexity
of facets (and some facets of complexity), Journal of
Computer and System Sciences 28:244-259.
Provost, F., Jensen, D. and Oates, T., 1999. Efficient
Progressive Sampling. Proceeding of the Fifth
International Conference on Knowledge Discovery and
Data Mining, ACM KDD-99, pp.23-32.
IoTBD 2016 - International Conference on Internet of Things and Big Data
382
