Joins vs. Links or Relational Join Considered Harmful

Alexandr Savinov

Bosch Software Innovations GmbH, Stuttgarterstr. 130, 71332 Waiblingen, Germany

Keywords: Data Processing, Data Modeling, Join Operation, Links, References, Connectivity.

Abstract: Since the introduction of the relational model of data, the join operation is part of almost all query languages

and data processing engines. Nowadays, it is not only a formal operation but rather a dominating pattern of

thought for the concept of data connectivity. In this paper, we critically analyze properties of this operation,

its role and uses by demonstrating some of its fundamental drawbacks in the context of data processing. We

also analyze an alternative approach which is based on the concept of link by showing how it can solve

these problems. Based on this analysis, we argue that link-based mechanisms should be preferred to joins as

a main operation in data model and data processing systems.

1 INTRODUCTION

A data model is a definition of data, that is, it

answers the question what is data. It defines how

data is organized and how it is manipulated by

providing structural elements and operations. For

example, the relational model (Codd, 1970)

organizes data by using tuples, domains and

relations while the functional data model (Sibley and

Kerschberg; 1977) does the same by using functions.

One of the major concerns in any data model is

describing how elements are related or connected as

well as providing means for retrieving related

elements. The mechanism of connectivity

determines such important aspects as semantic

clarity, conciseness of queries, maintainability and

performance.

Probably the most wide spread approach to

retrieving related elements in a database is based on

the operation of relational algebra called join. A join

takes two or more relations as input and produces a

new relation as output. The output relation contains

tuples composed of related tuples from the inputs.

The way they are related is specified in the join

condition which is a parameter of the operation.

Although the join operation dominates in the

area of data management, there are also alternative

approaches. One of them defines how data elements

are related and accessed by using the notion of link

or reference (we will use these terms

interchangeably because their differences are not

important for this paper). A link is a value which

identifies a data element (referent) and is used to

access it. It is a very simple and natural concept

which dominates in programming but is also used in

many data processing systems and models.

This paper is devoted to comparing joins and

links as alternative mechanisms for accessing related

data elements which are based on completely

different patterns of thought. We critically analyze

join operation and demonstrate that it has some

significant drawbacks while links on the other hand

can solve these problems. We argue that joins should

not be used in data modeling and data processing

systems or at least their role should be significantly

diminished. We also want to show that links can be

used as a basis for a new mechanism that can replace

joins and do what joins have been intended for.

The paper has the following layout. Section 2

and Section 3 are devoted to describing joins and

links, respectively. Each of these sections starts from

describing the corresponding mechanism and then

we analyze their more specific properties. Section 4

makes concluding remarks.

2 “WHO IS TO BLAME?” JOINS

2.1 What is in a Join? Common Value

Let us assume that there are two CSV files with a list

of employees and departments which might have the

followings structure and data:

362

Savinov, A.

Joins vs. Links or Relational Join Considered Harmful.

DOI: 10.5220/0005932403620368

In Proceedings of the International Conference on Internet of Things and Big Data (IoTBD 2016), pages 362-368

ISBN: 978-989-758-183-0

emp,name,dept_id

25,Smith,RD

dept,mngr,location

RD,30,Stuttgart

These two lines are stored in different files and

formally are not connected because there is no

indication of any relation between them. However,

we can easily see that both of these lines store the

same value ‘

RD’ and we also know that this value

(semantically) represents the same entity.

This fact of being characterized by the same

value is a basis for establishing relationships

between data elements. In our example, the fact that

one employee and one department are both

characterized by the value ‘

RD’ is not a coincidence

but rather a way to represent that they are connected

(Fig. 1). In other words, two data elements are

supposed to be related if they have something in

common or, more specifically, share the same value.

Therefore, this general connectivity principle could

be called a common value or shared value approach.

Importantly, in addition to the two data items being

connected, there is a third item stored in both of

them and treated as a means of connectivity. There

is no way to connect two elements without

specifying a third element they share.

Figure 1: Two elements are related if they share a third

element (data value).

Having something in common is a conceptual

definition of related elements. It allows us to

determine whether two elements are related or not.

However, the problem is not only to define related

elements but also to retrieve them by materializing

this conceptual relationship. In the relational

algebra, such a mechanism is provided by the join

operation which is applied to relations and returns a

new relation. In addition to input relations, this

operation needs a parameter which provides a

criterion of connectivity. The output relation will

contains only tuples satisfying this condition.

Although joins can specify any condition the

combinations of input tuples have to satisfy (theta-

join), the most common case is to select only input

tuples which contain equal values of some attributes

(equijoin). Fig. 2 provides an example of joining two

tables

Employees and Departments by producing a

new table

Emps_Depts. Note that every tuple of the

result table is a combination of matching tuples from

the two input tables which share the same value.

Figure 2: Output relation contains combinations of related

tuples from input relations.

The idea of using common values for matching

data elements has its formal roots in predicate

calculus and is used various technologies, for

example, deductive databases (Ullman & Zaniolo;

1990) or query languages. If two predicates in a

logical expression have the same free variables then

they have to be bound to the same value in order for

the resulting proposition to be true. For example,

given two predicates

Employees(emp,ename,city)

Departments(dept,dname,city)

we can define a logical expression Employees(emp,

ename, city) & Departments(dept, dname,

city) which will be true only if the city variable

takes the same value. In this way, we can retrieve all

employees who are located in (share) the same city

as their department.

2.2 Join is Symmetric

The underlying semantics of the join operation is

two elements are defined to be related if they have

the same property. This property makes it a

symmetric operation where all inputs have the same

roles. For example, if we look at this join condition

Employees.dept_id=Departments.dept

then it is not possible to assign a special role to one

of the input tables

Employees or Departments (Fig.

3).

Here we see one major problem of joins: in fact,

these two tables have different semantic roles and

the relationship between them is not symmetric. One

indication of asymmetricity is that it is a many-to-

one relationship where many employees belong to

one department. Another observation is that this

Employees

Departments

emp name dept_id

25 Alex RD

26 John HR

27 Anna HR

emp name dept_id

25 Alex RD

dept mngr location

RD 30 Dresden

HR 20 Berlin

dept mngr location

RD 30 Dresden

emp name dept_id dept mngr locatioin

25 Alex RD RD 30 Dresden

26 John HR HR 20 Berlin

27 Anna HR HR 20 Berlin

Emps_Depts

Employees

Departments

25 Smith RD

RD 30 Stuttgart

Sharedvalue

Joins vs. Links or Relational Join Considered Harmful

363

same semantics can be (correctly) represented as an

employee record referencing one department (but

not vice versa). Also, the shared value is a

department identifier and employee identifier. If we

change the direction of this relationship then we

change the meaning of the connection. Yet, joins are

not able to represent this semantics because all input

relations have equal rights in a join.

Figure 3: Join is symmetric.

In the relational model, a unit of connectivity

(between domains) is one relation and composition

means joining relations. In other words, join allows

to compose or chain relations. Now assume that we

have 10 relations and want to retrieve tuples from

one of them which are related to tuples in another

relation. Formally, we need to build a Cartesian

product of these relations by adding also all relevant

join conditions. This approach is highly unnatural

and very difficult to use in practice (therefore, its use

is quite rare). Why we have to include all input

relations if we want to retrieve records from only

one of them? It is also not obvious what join

conditions to use (especially if we do not have FKs

declared). It is therefore very easy to produce

formally correct but semantically wrong results. And

the reason is that the constraints are propagated

along a sequence of relations connected by common

values. It is probably one of the reasons why the

development of the conception of automatic

reasoning in the unified relation model (URM) failed

(Maier et al., 1984).

It should be noted that there exist a mechanism

of foreign keys (FK) that can solve this problem of

symmetricity of joins. Indeed, a FK declares one

input relation and one output relation which have

different roles. If two relations are used in a join

then this FK declaration can be used as a semantic

specification of our intention in the join operation.

Yet, the use of FKs for this purpose has the

following drawbacks. First, it is not an original

purpose of FKs to describe semantics of joins (FK is

a mechanism of imposing constraints). Second, the

need in an additional mechanism like FK

emphasizes that joins have some limitations. Third,

FKs are not enforced by existing models in general

and they must not be used in the context of joins in

particular. Join is an operation which is used at

query time while FK is a declaration which is used

at design time. Fourth, it can be difficult to

understand how to use FKs in the case of arbitrarily

complex join conditions. Essentially, FK is an

attempt to introduce a mechanism of links but they

have incompatible semantics and therefore their

simultaneous use is quite controversial and eclectic.

The use of FKs in combination with joins is

analogous to introducing constructs for structural

programming along with goto operator. Their

simultaneous use will result in strange mixtures of

different patterns.

2.3 Join is a Cross-cutting Concern

Let us assume that we want to get a list of

employees working at some department. It can be

done by means of the following query:

SELECTE.emp,D.dept,D.location

FROMEmployeesE,DepartmentsD

WHEREE.dept_id=D.dept

An important observation here is that many similar

queries will include the same join condition. In other

words, this same join condition

E.dept_id=D.dept

will appear in quite many queries which involve

these two tables. It is because join conditions

describe the details of how entities are connected in

the model rather than the logic of what needs to be

retrieved.

Such fragments of the source code which scatter

throughout the whole program or query are referred

to as a cross-cutting concern (Kiczales et al., 1997).

The existence of such repeated fragments of code is

an indication of either bad design or impossibility to

modularize their logic due to limitations of the

language. The main negative consequence is that the

same fragment can appear in quite different and

unrelated contexts semantically belonging to

different levels of organization. As a result, the

program or query can become error-prone and

difficult to maintain. The solution of this problem is

to provide a mechanism for modularizing such

repeated fragments in a separate modeling construct.

Ideally, a mechanism of connectivity should

declare how different entities in the whole model are

connected independent of where these connections

will be used. Yet, in join-based queries, both the

logic of the query and the logic of the connections

between relations are described together in the same

construct. It is a typical example of mixing different

concerns. On one hand, the main purpose of the

query is to retrieve employees with the related

department information. It is application-specific

logic and we do not care how these relations are

Employee

String

Departments

dept_id

dept

domains

relations

join

IoTBD 2016 - International Conference on Internet of Things and Big Data

364

connected. On the other hand, this same query

involves a fragment which has nothing to do with

this application because it describes how the

connection between employees and departments is

implemented (independent of any queries). These

two concerns should be separated but the approach

based on joins does not support this separation.

This join-based approach to querying data leads

to exposing low-level structure of connections at the

higher level of application-specific logic. For

example, if later on we will change the way relations

(departments and employees) are connected then all

queries that use it will have to be updated. It is also

error-prone because query writers are not necessarily

experts in connectivity – they have to know only that

these two tables have a specific connection while its

implementation should be effectively hidden in a

separate module or mechanism. This task of

combining connectivity criteria with the business

logic of the query is especially difficult in the case

of complex multi-table queries. It is also a potential

security flaw because a low-level definition of

connectivity can be influenced from the higher level

of user-oriented operations. This explicit use of join

conditions can also result in lower performance

because the database engine cannot use

optimizations for pre-defined connections but rather

has to assume the possibility of any join conditions

in any new query.

2.4 Joins do Not Support Types

Let us assume that department identifiers are unique

strings and we want to retrieve tuples with the same

department:

SELECT*

FROMEmployees,Departments

WHEREdept_id=dept

If we now modify this query by changing its join

conditions as follows

WHEREdept_id=dept_name

then we get a formally valid query which however is

semantically wrong because it does not make sense

to compare department identifiers with department

names. The problem is that

dept_id is declared as a

string but semantically it is a

Department. Yet, we

are not able to declare the correct type of

dept_id:

neither as an attribute type at the level of the model

(relations cannot be used as types) nor at the query

level in the join condition. Therefore, it is not

possible to prevent the user from writing

semantically wrong conditions even if we know that

they are wrong.

It should be noted that foreign keys could help in

this situation. But it is an auxiliary mechanism

which exists independently of types (and joins).

Both FKs and types are used to constrain sets but do

it differently. In our example, if we want to

(correctly) declare the

dept_id attribute as

referencing a department then we either add a

foreign key that constrain the values by those

existing in the

Departments table or directly use

Departments as a type. It is obviously duplication of

functionality in two mechanisms with significant

negative consequences.

3 “WHAT IS TO BE DONE?”

LINKS

3.1 What is in a Link? Inclusion

Links or references are used if it is necessary to

represent some target element within this element.

This representation can be then used to access the

target element. Links are widely used in

programming languages to represent and access

objects using some kind of a unique value. This

value, called reference, can be then stored in other

objects. As a result, a program is represented as a

graph where nodes are objects and edges are

references. Link is also a basic mechanism of the

world wide web where text documents can reference

other text documents by using their unique

identifiers. Users can traverse this graph of

documents by following links and retrieving new

documents.

Link as a mechanism of connectivity possess the

following general properties:

 Link is a value (passed by-value only) which

uniquely represents some object (referent) and is

used to access it. Primary key or similar

annotation is a design pattern that can be used to

model references but is different from true

references because references do not belong to

the represented object properties.

 Link is a mechanism of indirectly including one

object in another object. Foreign keys can be

used to declare (annotate) such an inclusion. Yet,

it is a design pattern and not a true link

declaration. In particular, foreign keys cannot be

used for access and do not have types.

 The mechanism of links assumes the existence of

three roles: represented object (referent),

reference (link), and a referencing object which

stores the reference.

Joins vs. Links or Relational Join Considered Harmful

365

 The mechanism of access provided by a

reference is hidden in its implementation and is

not exposed at the application level where links

are used.

 Link is a directed relation. In particular, this

means that one (referencing) entity knows about

the other (referenced) entity but not vice versa.

 Links on sets can be formally described by using

mathematical functions (mappings).

3.2 Link is a Directed Relationship

Links are not supported in the relational model of

data. Yet, conceptually we can think of table records

as being linked by using the following interpretation.

If a record stores one or more values which uniquely

identify and can be used to access another record

then these values are thought of as a link. For

example, if one employee record stores a unique

identifier of a department then this means that this

employee references this department (Fig. 4). Note

however that although the (physical) representation

via tables is the same for both joins and links, they

have different meanings.

One of the main distinguishing features of links

is that the ordering of the roles differs from that used

in the join-based model. Links also use three roles:

identifier (reference), referenced entity (referent)

and referencing entity. However, rather than sharing

the same value (department identifier in Fig. 4), the

Employees table includes an identifier from the

Department table while which in turn includes a

string as identifiers. It is not only a visual ordering –

it has significant semantic consequences.

Figure 4: Two tuples are connected by storing in one of

them a data value representing the other one.

In contrast to joins, links represent binary

directed relationships among data elements with

opposite roles for the two arguments. One advantage

of such an approach is that links are much easier to

compose. For example, given an employee element,

we can find the corresponding department address

by composing two references:

Addressaddr=emp.department.address;

This composition operation (syntactically encoded

as dot notation) follows a path in a directed graph of

links which is a very natural and semantically

unambiguous operation. For comparison, the same

task can be solved by applying two join operations:

SELECT*FROM

EmployeesE,DepartmentsD,AddressesA

WHEREE.dept_id=D.dept&&D.addr_id=A.addr

Here it is difficult to determine the real purpose of

this query and the role of its arguments (relations)

because the result of the operation is one relation

combining tuples from the three input relations. It is

also not obvious how to inverse this query.

The difference between link composition and

join composition is analogous to that between

function composition in mathematics and bindings

in predicate calculus. In fact, these are two quite

different ways to think about connectivity. The join-

based approach assumes that two elements are

connected if they both include a third element. The

link-based approach assumes that two elements are

connected if one of them includes (a reference to)

the other.

3.3 Links Modularize and Hide the

Access Mechanism

If we want to access related records using the

mechanism of joins then we have to provide a

specification of how the records are related.

Moreover, this specification has to be provided for

each query in the same statement with other

application specific parameters.

Links are much easier to use. In order to retrieve

related records it is necessary to provide only one

attribute name. For example, given a reference to an

employee object, we can get a related department

object by simply specifying an attribute name:

Departmetdept=emp.department;

What is important here is that we actually do not

know how departments are retrieved and what is the

definition of the relation between departments and

employees. This definition and the access

mechanism are hidden in the

department attribute.

Effectively, two concerns are principally separated:

 how links are used, and

 how links are defined

This approach provides significant advantages

especially for complex systems. We can easily

Employees

Departments

emp name dept_id

25 Alex RD

RD

dept mngr location

RD 30 Dresden

Canbemodele

byPKs

Canbemodele

byFKs

IoTBD 2016 - International Conference on Internet of Things and Big Data

366

change the definition of a link without the need to

update all its usages. One possible implementation

of user-defined links is implemented in

DataCommandr (Savinov; 2016). For example,

assume that we want to re-design our data model so

that an employee can be assigned to more than one

department. In this case, the department attribute

will have to be redefined so that it returns an

element marked as a main department. If we were

using joins then this would require modification of

all queries that access departments using an

employee. In the case of links, it is enough to change

only one link definition. References can also be

applied to sets in the form of project operation and

arrow notation as proposed in the concept-oriented

model of data (Savinov; 2014).

3.4 Links Support Types

Type is a set of elements and specifying a type

means imposing constraints on possible elements.

Any link definition involves two such types: a set of

input elements and a set of output elements. Thus

links very naturally support typing as an integral part

of this mechanism.

For example, if we want to define a link from

employees to departments then this means that it has

to work for only input elements from the

Employees

set and output elements from the

Departments set.

These constraints can be declared as a function

signature:

Departmentsdepartments(Employeesthis);

They also can be declared as a field type of a class:

classEmployees{

Departmentsdepartments;

}

Note that links allow us to impose type constraints

independent of whether the output is a relational

domain or another relation. Also, typed links make

foreign keys unnecessary.

4 CONCLUSIONS

The main result of this paper is that although join is

a powerful formal operation it has the following

major drawbacks in the context of data processing:

 Join relies on the semantics of common values

for representing connectivity which is not very

natural semantically and can be counterintuitive

when using composition.

 Join is a cross-cutting concern because the same

join condition can spread over many queries by

mixing two concerns: application specific logic

of the query and how connectivity is

implemented.

 Join does not inherently support typing because

two related (joined) sets are separated by a third

set with common values.

Therefore, the use of joins normally requires high

expertise and can lead to error prone and difficult to

maintain queries and data models.

We also analyzed an alternative mechanism of

links which provides the following benefits:

 Links rely on the semantics of inclusion of an

identifier of one element into another element

which is very natural for describing how things

are connected and allows for easily composing

and inverting the relationships.

 Links effectively modularize and hide the

underlying mechanism of access so that the main

logic of the query does not involve the

description of how the connectivity is

implemented. Primary keys can be viewed as one

possible design pattern for implementing true

references.

 Links are typed by specifying sets for their input

and output elements which is precisely what is

normally needed. Foreign keys can be viewed as

one possible design pattern for implementing

true typing.

Taking into account these properties we argue that

links should be preferred to joins as a primary

mechanism for accessing related elements in

databases. Yet, classical references miss some

properties which are of crucial importance for data

modeling. How links can be revisited in order to

overcome these drawbacks will be our focus for

future research.

REFERENCES

Codd, E., 1970. A Relational Model for Large Shared

Data Banks. Communications of the ACM, 13(6), 377-

387.

Kiczales, G., Lamping, J., Mendhekar, A., Maeda, C.,

Lopes, C., Loingtier, J.-M., Irwin, J., 1997. Aspect-

Oriented Programming. ECOOP’97, 220-242.

Maier, D., Ullman, J.D., Vardi, M.Y., 1984. On the

foundation of the universal relation model. TODS’84,

9(2), 283–308.

Savinov, A., 2014. Concept-oriented model. In J. Wang

(Ed.), Encyclopedia of Business Analytics and

Joins vs. Links or Relational Join Considered Harmful

367

Optimization. IGI Global, 502-511.

Savinov, A., 2016. DataCommandr: Column-Oriented

Data Integration, Transformation and Analysis.

Internet of Things and Big Data (IoTBD’2016).

Sibley, E.H. & Kerschberg, L., 1977. Data architecture

and data model considerations. In Proceedings of the

AFIPS Joint Computer Conferences. 85-96.

Ullman, J.D., Zaniolo, C., 1990. Deductive databases:

achievements and future directions. ACM SIGMOD

Record, 19(4), 75-82.

IoTBD 2016 - International Conference on Internet of Things and Big Data

368
