Energy-efﬁcient Task Scheduling in Data Centers

Yousri Mhedheb and Achim Streit

Steinbuch Centre for Computing, Karlsruhe Institute of Technology, Karlsruhe, Germany

Keywords:

Cloud Computing, Distributed Systems, Energy Efﬁciency, Power Management, DVFS.

Abstract:

A data center is often also a Cloud center, which delivers its computational and storage capacity as services. To

enable on-demand resource provision with elasticity and high reliability, the host machines in data centers are

usually virtualized, which brings a challenging research topic, i.e., how to schedule the virtual machines (VM)

on the hosts for energy efﬁciency. The goal of this Work is to ameliorate, through scheduling, the energy-

efﬁciency of data center. To support this work a novel VM scheduling mechanism design and implementation

will be proposed. This mechanism addresses on both load-balancing and temperature-awareness with a ﬁnal

goal of reducing the energy consumption of a data centre. Our scheduling scheme selects a physical machine

to host a virtual machine based on the user requirements, the load on the hosts and the temperature of the

hosts, while maintaining the quality of the service. The proposed scheduling mechanism on CloudSim will

be ﬁnally validated, a well-known simulator that models data centers provisioning Infrastructure as a Service.

For a comparative study, we also implemented other scheduling algorithms i.e., non power control, DVFS

and power aware ThrMu. The experimental results show that the proposed scheduling scheme, combining the

power-aware with the thermal-aware scheduling strategies, signiﬁcantly reduces the energy consumption of a

given Data Center because of its thermal-aware strategy and the support of VM migration mechanisms.

1 INTRODUCTION

Cloud Computing (Mell and Grance, 2011; Wang

et al., 2010) has emerged as a novel computing

paradigm and this paradigm is so attracting that do-

ing things “in the cloud” has become a common

catch phrase these days. For that reason, increas-

ing number of Cloud infrastructures (GAE; Windows;

rackspace, ) have been established after the ﬁrst com-

puting Cloud – the Amazon Elastic Compute Cloud

(EC2) (AmazonEC2). These Cloud providers are also

data center operators, where computing and storage

facilities are now provisioned as Cloud services. With

a business model of “pay as you use”, Cloud Com-

puting offers services not only in hardware and stor-

age, but also software, applications as well as net-

work. The power of Cloud Computing is that users

can access the computing resources via Internet us-

ing a thin-client such as a Web browser. Additionally,

Cloud Computing shows the advantages in elasticity,

system management, cost-efﬁciency, customized en-

vironment and on-demand resource provision (Wang

and Khan, 2013; Menzel and Ranjan, 2012). Cur-

rently, data centers deliver mainly three kinds of

Cloud services, namely Infrastructure as a Service

(IaaS), Platform as a Service (PaaS) and Software as

a Service (IaaS) (Mell and Grance, 2011; Kahn et al.,

2013) . IaaS targets on an on-demand provision of the

computational resources, normally in the form of vir-

tual machines (VM). Customers can install software

packages on the machines to establish their own com-

puting environments. SaaS provides the customers

a feature of using the provider’s applications in the

form of Web services that run centrallyon the com-

puting infrastructure of the service provider. PaaS tar-

gets on a complete platform including the hardware

and the application development environment, which

allows the users to develop their applications using

the provider’s computing platform. Existing Clouds

are mostly IaaS-featured. Examples include the Ama-

zon EC2, SmartCloud, Flexiscale as well as the aca-

demic implementations like Eucalyptus (Nurmi et al.,

2008), OpenNebula (Sotomayor et al., 2008), Nimbus

(Keahey and Freeman, 2008) and OpenStack (Open-

stack, 2013). Independent of which services a data

center offers, data centers commonly require a virtu-

alized hardware platform for either IaaS or running

the provisioned software (SaaS) or user applications

in the case of PaaS. Therefore, virtual machines are

the base to deliver any cloud services. Since a Cloud

center is equipped with thousands of physical hosts,

where each of them is potentially the target of a re-

Mhedheb, Y. and Streit, A.

Energy-efﬁcient Task Scheduling in Data Centers.

In Proceedings of the 6th International Conference on Cloud Computing and Services Science (CLOSER 2016) - Volume 1, pages 273-282

ISBN: 978-989-758-182-3

273

quested incoming virtual machine, there arises an im-

portant issue of scheduling virtual machines on the

physical hosts. A traditional approach of scheduling

virtual machines is a kind of FIFO approaches, where

all hosts are contained in a list and the ﬁrst physical

machine that matches the requirement of the VM is

selected as the target host.

Issue with scheduling exists in various scenarios,

like task scheduling in parallel and distributed sys-

tems (Mhedheb et al., 2013; Ranjan et al., 2005)

and job scheduling in computing Grids (Ranjan

et al., 2006; Kolodziej et al., 2012; Kolodziej et al.,

2013). Various algorithms have been proposed by re-

searchers including those focusing on Energy Con-

sumption. In the ﬁeld of Cloud Computing, Cloud

providers are surely expecting a low operation over-

head. Considering the importance of energy saving

in the ﬁeld of Cloud Computing a speciﬁc algorithm

for scheduling the virtual machines on the Cloud

was here developed. This algorithm ﬁrst performs

an initial scheduling and then inspects the change

of workload and temperature on the host. In case

of over-loading or over-heating, the VM is migrated

to another host thereby to avoid hot spots with re-

spect to load and temperature. We implemented this

algorithm on CloudSim (Calheiros et al., 2011), a

well-known simulation platform for research work

in Cloud Computing. In addition to the proposed

scheduling scheme we also implemented several other

scheduling policies for a comparative study. The ex-

perimental results show that the proposed approach

performs better than others with the lowest energy

consumption while the service quality is granted in

most cases.

The rest of this paper is organized as follows: Sec-

tion 2 introduces the related work in energy-aware

scheduling algorithms. Section 3 describes the con-

cept of the proposed approach followed by the imple-

mentation details in Section 4. Section 5 depicts the

evaluation details and Section 6 concludes the paper

with a brief summary and future directions.

2 RELATED WORK

Task scheduling has been investigated for many years

and is currently still a hot topic in various research

domains. For example, Cluster Computing relies on

good scheduling technologies for achieving the per-

formance of parallel applications; Grid Computing re-

quires efﬁcient job scheduler to best utilize the Grid

resources and thereby reduce the job waiting time.

Over the last years, many research works have been

performed for investigating the scheduling strategies

on different systems with features like load-balancing

and energy-awareness.

As computing systems consume more and more

energy, increasing research works on task scheduling

show the feature of energy-awareness (Hsu and Feng,

2005; Wang et al., 2011). Most of these research

works adopt the technique of Dynamic Voltage and

Frequency Scaling (DVFS). DVFS has been proven

to be a feasible solution for reducing the processor en-

ergy consumption (Hsu and Feng, 2005). By lowering

the processor clock frequency and supply voltage dur-

ing some time slots (for example, idle or communica-

tion phases), energy consumption can be signiﬁcantly

reduced with a slight performance loss. Therefore,

the DVFS technique has been applied in various do-

mains, such as the high performance computing areas

and large data centers, to reduce the energy consump-

tion while gaining high reliability and availability. As

the virtualization technology is getting hot, the prob-

lem of virtual machine scheduling has also been stud-

ied. The authors of (Kim et al., 2008) implement a

guest-aware priority-based scheduling scheme, which

is speciﬁcally designed to support latency-sensitive

workloads. The proposed scheduling scheme priori-

tizes the virtual machines to be allocated by using the

information about priorities and status of guest-level

tasks in each VM. It preferentially selects the VMs

that run latency-sensitive applications to be scheduled

and in this way to reduce the response time to the I/O

events of latency-sensitive workloads.

The authors of (Wang et al., 2012) propose a

novel VM scheduling algorithm for virtualized het-

erogonous multicore architectures. The algorithm ex-

ploits the core performance heterogeneity to optimize

the overall system energy efﬁciency. It uses a met-

ric termed energy-efﬁciency factor to characterize the

power and performance behavior of the applications

hosted by VMs on different cores. The VM’s energy-

efﬁciency factors are calculated and based on the val-

ues virtual machines are mapped to heterogeneous

cores with a ﬁnal goal of maximizing the energy ef-

ﬁciency of the entire system. The authors of (Tak-

ouna et al., 2011) also address on the VM scheduling

of heterogeneous multicore machines. A scheduling

policy is designed to schedule each virtual machine

to an appropriate processing core based on the perfor-

mance sensibility to the CPU clock frequency and the

performance dependency on the host.

In addition to the research work on VM sched-

ulers of general purposes, the speciﬁc problem of VM

scheduling on the Cloud has also been addressed over

the last years.

The work presented in (Fang et al., 2010) develops

a two-layer scheduling model, where the ﬁrst layer

CLOSER 2016 - 6th International Conference on Cloud Computing and Services Science

274

creates the description of resource requirement of a

virtual machine, while the second layer takes care of

the VM scheduling on the host. By allocating the

VMs to the hosts that closely meet the resource re-

quirement this approach tries to better use the Cloud

hardware resources. The approach was evaluated on

CloudSim. The authors of (Li et al., 2011) propose a

dynamic round-robin scheduling scheme for deploy-

ing and migrating virtual machines to or across the

servers on the Cloud. The scheme uses two schedul-

ing rules, whereby the ﬁrst rule avoids allocating ad-

ditional virtual machines to a retiring physical ma-

chine that will be shut down while the second rule

speeds up the consolidation process. The main goal of

this approach is to reduce the number of used physical

machines for saving energy. The work in (Hu et al.,

2010) propose a strategy for VM scheduling on the

Cloud with load balancing. The scheduling decision

is based on the historical information and current state

of the system. Authors of (Knauth and Fetzer, 2012)

proposed a scheduler, which schedules the virtual ma-

chines based on the knowledge about the duration of

timed instances to optimize the virtual to physical

machine assignment. The main goal of this sched-

uler is to reduce the cumulative machine uptime and

thereby save the energy consumption. The work in

(Beloglazov and Buyya, 2012) is also one of the few

approaches that deal with energy-aware scheduling

of Cloud-based resources. The authors implemented

a simulation environment based on CloudSim (Cal-

heiros et al., 2011) to evaluate different power-aware

scheduling policies for VM running on a large scale

Cloud centre. Furthermore, they show how the VM

migration and VM pining techniques can optimize the

load-balancing and the total energy consumption of a

data center.

Our work is similar to the last related work. How-

ever, both power and thermal-aware scheduling poli-

cies will be combined to reduce the energy consump-

tion. More importantly, the extension of this work to

support using temperature constraints as new schedul-

ing parameters. The evaluation on CloudSim has

shown the improvement of this approach over the ex-

isting one in terms of saving energy consumption.

The experimental results will be given after the de-

scription of the proposed scheduling algorithm and its

implementation.

3 THERMAL AWARE VM

SCHEDULING

Modern processors have a tolerance limit to the on-

chip temperature named case temperature. A higher

temperature over this limit may reaches the Junction

temperature and not only increases the energy con-

sumption but also may result in some defect in the

hardware i.e., silicon chip is going to melt the inter-

nals. The design goal of our scheduling scheme is to

be aware of the changing temperature of the process-

ing cores to avoid crossing the limit. Our thermal-

aware scheduling concept is based on several exist-

ing strategies, which are applied for the requirement

of different scheduling scenarios. These strategies

are individually integrated in our framework at the

run-time based on the current load and temperature

state. The main tasks of our scheduler, called Ther-

mal aware Scheduler (ThaS), are the following:

3.1 Power-aware Energy Management

Applying the DVFS technique for power manage-

ment. Since the power consumption depends on the

CPU usage, this metric has to be measured before

each VM scheduling step in the whole execution pro-

cess in order to calculate the current consumed energy

by the CPU.

3.2 Thermal-aware Energy

Management

The main focus of our ThaS scheme is to schedule

virtual machines with respect to the temperature of

the processors. Such a scheduling strategy needs a

temperature model to describe the property of this pa-

rameter while applications (here virtual machines) are

running. The lumped RC thermal model (Skadron

et al., 2002) will be used due to its simplicity. Accord-

ing to (Skadron et al., 2002), for an integrated circuit

at the die level, heat conduction is the dominant mech-

anism that determines the temperature. There exists a

well-known duality between heat transfer and electri-

cal phenomena. Any heat ﬂow can be described as

a current and the passing of this heat ﬂow through a

thermal resistance leads to a temperature difference

equivalent to a voltage. The RC model can be de-

scribed with T

amb

= RC

+ T − RP, where C stands

for the thermal capacitance of the processor, R for the

thermal resistance, P for the processor dynamic en-

ergy consumption, and T

amb

for the ambient tempera-

ture. This model is however limited to a single-core

processor. Therefore, ThaS supports now only single-

core machines.

3.3 Migration of Virtual Machines

Our ThaS scheme inspects the change of load and

temperature on a host machine. In case that a host

Energy-efﬁcient Task Scheduling in Data Centers

275

is about to be over-heated or over-loaded it performs

VM migration to avoid critic scenarios. Migration or

live migration refers to the process of moving a run-

ning virtual machine or application from one physical

machine to another. In addition to the machine im-

age, the data storage and network connectivity of the

virtual machines have also to be transferred from the

source host to the destination. The proposed schedul-

ing scheme implements this kind of VM migration

and runs the entire migration process transparently to

the user. The migration contains several steps, includ-

ing the Push phase, the Stop phase, the Copy phase

and the Pull phase. The VM migration can take a

long time when a VM has a large amount of memory.

In order to save the unnecessary energy consumption

during the VM migration, two strategies in ThaS are

implemented: i) the Pining strategy that allows the

allocation of multiple VMs on the same host to free

other physical hosts; ii) the energy-save-modus strat-

egy that sets the unused hosts (or CPUs) in the idle

mode.

ThaS decides during the runtime which VM shall

be allocated on which host. It works in the follow-

ing way: As a starting point a VM request coming

from the user is scheduled on a physical host based

on the traditional round-robin scheme. In order to

make a decision, ThaS calls the thermal model and

the power model to acquire all scheduling parameters

including the current CPU temperature, the CPU us-

age for each host, the data center conﬁguration and

the application (VM) requirements. In case that a

physical host approaches to the critical temperature

(Temperature threshold) or the critical CPU utiliza-

tion value (Utilization threshold), ThaS looks for an-

other host with better temperature or load criteria

and migrates the running VM from the source host

to the destination host. Therefore, our ThaS sched-

ules the virtual machines not only for minimizing

the energy consumption but also for load-balancing.

ThaS is designed to be integrated in a Cloud middle-

ware to replace its original one, usually a round-robin

scheme that allocates the VMs to each host equally in

a cyclic order. ThaS implements an interface between

the VMM (hypervisor) and the virtual machines in a

Cloud centre. It replaces the conventional scheduling

algorithm of a hypervisor to map a virtual machine

request to a physical machine with consideration of

the load and temperature on the hosts. The deploy-

ment, such as start, stop, migration, etc., of the virtual

machines on the physical host remains the task of the

hypervisor. In this way, our scheduler acts as an allo-

cation decision component for the hypervisor.

4 IMPLEMENTATION

A Java-based simulation environment, to verify the

concept and to validate the functionality of the pro-

posed scheduling strategies for ThaS was imple-

mented. The prototypical implementation is based on

a well-known simulator, CloudSim (Calheiros et al.,

2011), for research work on the Cloud. CloudSim

models large scale data centers with internal broker,

sensors, physical host, as well as virtual machines.

CloudSim also provides the functionality to conﬁg-

ure data center resources. This allows us to model

cloud providers with different system scale and hard-

ware resources.

By an incoming VM request our scheduler ThaS

starts ﬁrst with an initial task of allocating the VM to

one of the hosts that meet the requirement described

in the request. In the following, it performs the run-

time tuning with respect to load and temperature.

The ﬁrst task of ThaS for runtime tuning is to

detect the critical hosts with either higher tempera-

ture or workloads. The following pseudo-code illus-

trates how the scheduler performs this task. As can be

seen in the algorithm, the scheduler goes through all

the available hosts to ﬁnd the hosts, whose tempera-

ture and CPU usage exceed the speciﬁed thresholds.

The detected hosts are then marked as candidates for

VM migration and added to the list ‘Migrating From

Hosts’. This list is applied in the second step as the

input list.

Algorithm 1: Algorithm for detecting critical hosts.

Input: HotList, VmList

Output: MigratingFromHosts

1: for each host in hostlist do

2: if isHostOverThresholdTemperature (host)

then

3: overT hresholdTempHosts ← addhost

4: else

5: if isHostOverThresholdUtilization ( host )

then

6: overUtilizedHosts ← addhost

7: end if

8: end if

9: overHosts ← overT hresholdTempHosts +

overUtilizedHosts

10: MigratingFromHosts ← overHosts

11: end for

In the second step, the list of critical hosts, which

has been created by the scheduler in the ﬁrst step, is

processed again for ﬁnding the VMs running on them.

These virtual machines are the concrete candidates

for migration. The candidate VMs are then sorted by

their CPU usage. The VMs with minimal CPU us-

CLOSER 2016 - 6th International Conference on Cloud Computing and Services Science

276

age are marked with a higher priority of migration for

the reason of not to bring high workload on the target

host, thus to avoid possible further migrations. For

the same reason the scheduler must also ensure that

the temperature on the target host does not exceed the

threshold. At the end of processing, this scheduling

step creates a list ‘VMs to Migrate List’ that contains

all VMs, which are the actual migration objects.

Algorithm 2: Algorithm for detecting of migratable VMs.

Input: MigratingFromHosts

Output: VMsToMigrateList

1: for each host in MigratingFromHosts do

2: while true do

3: vm ← getV mToMigrate(host)

4: if thenvm = Null

5: break

6: end if

7: V MstoMigrateList ← addvm

8: host ← deallocatevm

9: if then!(isHostOverT hresTemp(host) &

isHostOverT hreshold Utilisation(host))

10: break

11: end if

12: end while

13: end for

The third and last step of the VM migration pro-

cedure is to ﬁnd an appropriate target host for host-

ing the migration objects in the list created in the last

step. Here, the workload requirements (e.g., needed

Algorithm 3: Algorithm for detecting of target Hosts.

Input: MigratingFromHosts, VMsToMigrateList

Output: MigrationMap

1: MigrationMap ← null

2: vmstoMigr ateList.SortDecreasingCPUUtilisation

3: for each VM in VMsToMigrateList do

4: allocatedHost ← null

5: minPower ← Max

6: for each host not in MigratingFromHost do

7: if host has enough resources for vm then

8: power ← estimatePower(host, vm)

9: end if

10: if thenpower < minPower

11: allocatedHost ← host

12: minPower ← power

13: end if

14: if thenallocatedHost! = NU LL

15: allocate vm to allocatedHost

16: end if

17: end for

18: MigrationMap ← add(vm, allocatedHost)

19: end for

resources) have to be taken into account. Our ThaS

ﬁrst observes the temperature on the destination host.

If this temperature is below the threshold value (Tem-

perature threshold) and the requirement of the VM is

fulﬁlled, the observed host is selected as the target

host. In case that several target hosts are found, the

one with the minimum energy consumption is chosen

for hosting the VM to be migrated.

To further improve the scheduling efﬁciency in

terms of energy consumption, a reallocation of VMs

is designed in the proposed scheduler. This scheme

concerns the hosts that are underutilized. In case that

the CPU usage of a physical host is below the mini-

mal value, the VMs on it are migrated to other hosts.

The underutilized hosts are then set in a sleep mode

for the purpose of saving energy. The idle hosts are

not candidates of destination host for VM migration.

5 EVALUATION RESULTS

5.1 Experimental Setup

ThaS is evaluated using a simulation environment

CloudSim, which models large data centers provi-

sioning computing infrastructures as services. Sim-

ulation is a widely applied approach for validating

novel concepts and implementations. For this work

a simulation platform is especially important because

of aiming to evaluate the thermal-aware scheduling

algorithm on a large virtualized data center infrastruc-

ture. For this purpose the status information of phys-

ical hosts on a Cloud centre is needed. In this case,

validation on a real Cloud infrastructure would be ex-

tremely difﬁcult or not possible due to the missing in-

formation, which inhibits us to perform different ex-

periments in order to examine the full functionality

of the implemented scheduler and the impact of the

scheduling strategies. In contrast, CloudSim imple-

ments a view of inﬁnite computing resources and it is

easy to extend this simulator for both monitoring and

additional functionalities.

We modeled a scenario of scheduling the virtual

machine requests of three days with a randomly gen-

erated VM request every ﬁve minutes. A VM request

contains four requirement attributes, i.e., the number

of CPU cores, the CPU frequency, the RAM size and

the bandwidth. The properties of the modelled VM

types are described in Table 1. As shown in the table,

different VMs with various values in MIPS and RAM

size to model real scenarios are used. With assuming

that all VMs run on single core machines. The band-

width and VM size for all simulated virtual machines

are set as 100 Mbit/s and 2.5 GB individually.

Energy-efﬁcient Task Scheduling in Data Centers

277

Table 1: Virtual machine conﬁguration.

VM Type VM MIPS VM RAM [MB]

1 500 613

2 1000 1740

3 2000 1740

4 2500 870

VM Cores VM BW [Mbit/s] VM Size [GB]

1 100 2.5

Table 2: Thermal constants.

Thermal parameter Value Unit

Initial CPU temperatur (T

init

) 318 Kelvin

Ambiente temperatur (T

amb

) 308 Kelvin

Case temperatur (T

case

) 353 Kelvin

Thermal capacity (C

) 340 J/K

Thermal resistance (R

) 0.34 K/W

Table 3: Simulated physical machines.

Server Host Type Proliant G4 Proliant G5

Host MIPS 1860 2660

Host Cores 1 1

Host RAM [MB] 2048 4096

Host BW [Gbit/s] 1 1

Host Storage [TB] 1 1

As mentioned, a lumped RC thermal model is ap-

plied to describe the relationship between the temper-

ature of the processor and its dynamic energy con-

sumption. Table 2 depicts the used thermal constants

for the experiments. The values in the table are typical

values of a single core CPU obtained from (Hotspot, ).

CloudSim was here conﬁgured for modeling two data

centers with one equipped with 50 and the other 250

different hosts. A half of the hosts are modelled as

the HP ProLiant G4 servers. The other half is mod-

eled as the HP ProLiant G5 servers. Table 3 shows

the setup parameters of the physical machines simu-

lated for the testing. The frequency of each core on

the HP ProLiant G4 Server is 1860 MIPS and for the

HP ProLiant G5 Server the value is 2660 MIPS. Each

server is modeled with a connection of 1 GB/s band-

width. The corresponding power model used by each

server is gathered from SpecPower08 (spec08). The

simulation of less powerful CPUs is advantageous for

a better evaluation of the effect of the VM migration

because few workload is required to result in the over-

load of a server. The RAM size for both machines are

conﬁgured to 2GB and 4GB individually.

The ﬁnal goal of our ThaS approach is to reduce

the energy consumption of data centers. To evaluate

ThaS with respect to this performance metric a model

to compute the energy was needed consumption of the

host machines (i.e., servers) in a data centre. Recent

studies (Beloglazov and Buyya, 2010) show that the

energy consumption by servers can be accurately de-

scribed by a linear relationship between the energy

consumption and the CPU utilization, even when the

DVFS scheme is applied. The reason lies in the lim-

ited number of states that can be set to the frequency

and voltage of the CPU and the fact that voltage and

performance scaling are not applied to other system

components, such as the memory and the network in-

terface. Moreover, these studies show that on average

an idle server consumes approximately 70% of the en-

ergy consumed when it is fully utilized. Therefore,

the energy consumption of a server E can be modelled

as a function of the CPU utilization u using the form

E(u) = (1 − u) ∗ 0.7 ∗ E

max

+ u ∗ E

max

, where E

max

the power consumption of a server in full use. For

example, a server of a data centre is 90% used and

10% idle. In this case, the energy consumption of the

server is 0.9 ∗ E

max

in busy status and 0.1 ∗ 0.7 ∗ E

max

in idle status. The total energy consumption of the

server is the sum of the two parts.

The implemented scheduler relies on two thresh-

olds for migration decisions, one is the Tem-

perature

threshold and the other is the Utiliza-

tion threshold. In order to have a simulation-based

evaluation applicable, it is important to perform ex-

periments with workload traces of a real system.

The simulation experiments (Beloglazov and Buyya,

2010) have demonstrated that energy consumption

from a CPU utilization rate of 90% rises very quickly.

Therefore we have chosen a value of 0.9 as the Uti-

lization threshold. If the CPU utilization reaches this

threshold, the VMs running on it may be migrated

to another host with lower CPU usage. The selec-

tion of the Temperature threshold is not as easy as the

Utilization threshold. In the following subsection is

demonstrated how to achieve an optimal threshold of

343 Kelvin with a trade-off between power consump-

tion and SLA violation.

To validate ThaS several other scheduling

schemes for a comparative study were also imple-

mented. The ﬁrst one is called Non power control,

which schedules the virtual machines without consid-

ering the CPU usage. We use this scheme to study the

energy consumption of a data center with full CPU

utilization. The second scheme is DVFS. It sched-

ules tasks on the basis of the CPU voltage and fre-

quency. It relies on the information from the CPU

performance and power model to set the priorities for

the VM placement. The energy consumption is calcu-

lated as a function of the CPU usage and is regulated

automatically and dynamically based on DVFS. The

last scheme is Power

aware ThrMu (Beloglazov and

Buyya, 2012). This scheduling algorithm focuses on

minimizing the CPU usage by setting up hosts in the

CLOSER 2016 - 6th International Conference on Cloud Computing and Services Science

278

idle mode. It migrates the running VMs of a host with

CPU usage over a threshold to other hosts. An utiliza-

tion threshold of 0.9 for this scheme is used, the same

as our scheduler.

5.2 Experimental Results

As described above, we use a temperature threshold

to limit the temperature of the processors. This means

that in case of higher temperature than the threshold

some workload on the host has to be moved to other

hosts in order both to avoid hardware defect and for

energy reasons. Therefore, our ﬁrst three experiments

were done for studying the impact of the Tempera-

ture threshold using a number of values ranging from

333 Kelvin to 360 Kelvin.

Figure 1 shows the results of the ﬁrst experiment,

where we measured the energy consumption of the

two simulated data centers in a single day using our

VM scheduler. The x-axis of the ﬁgure demonstrates

the thresholds, while the y-axis presents the energy

consumption in Kwh. For each temperature threshold

there are two values with one for the ﬁrst data center

(DC-1) with 50 hosts and the second for the other one

(DC-2) with 250 hosts. The data are presented in two

forms, one in bars and the other in curves. Observing

the curves in the ﬁgure, it can be seen that the energy

consumption with different temperature thresholds

can be divided into four areas. In the ﬁrst area, i.e.,

the temperature threshold between 333 and 335, the

energy consumption maintains constant with a value

of 52 Kwh for DC-1 and 102 for DC-2. In the sec-

ond region, i.e., 335 < temperaturethreshold < 340,

the energy consumption goes down as the threshold

getting larger. This behavior stops at threshold 340,

where a new phase starts with again a constant en-

ergy consumption. After this phase, a slight reduction

in energy consumption can be seen but generally the

temperature threshold does not change the energy be-

havior in phase 4.

Figure 1: Energy consumption.

The next experiment explains why such scenarios

occur with the thresholds. The results are depicted in

Figure 2, which shows the number of VM migrations

with different threshold values. Observing the ﬁgure

it can be seen that there is no any migration with the

low thresholds 333 and 335. The reason is: Our ThaS

migrates the VMs when the temperature of the source

host has reached the Temperature threshold. How-

ever, there must be a destination host with a CPU tem-

perature below the threshold. Logically, all hosts may

have a temperature above the Temperature threshold.

In this case, our scheduler cannot ﬁnd any target host

on which the VMs can be migrated. This is exactly

the case with threshold 333 and 335. Increasing the

temperature threshold, i.e., starting from 338, VM

migrations can be seen because the scheduler now

ﬁnds target hosts with temperatures below the thresh-

old Temperature threshold. It can be also observed

that the number of migrations growing up with the

threshold. This is because with a higher threshold

there must be more hosts whose temperature is be-

low the threshold. Therefore, more migrations can be

performed. However, starting from threshold 343 the

number of migrations is ﬁrst not changed and then

decreased signiﬁcantly. The former may be caused

by non more target hosts for migrations and the lat-

ter is related to the ThaS strategies. Our ThaS sets all

hosts with CPU temperature over the case tempera-

ture (T

case=353 Kelvin) in the sleep mode for cool-

ing down. Therefore, the available hosts for hosting a

migrated VM get fewer.

Figure 2: Number of Migrations.

Figure 3: Service level agreement (SLA) violation.

The last experiment with temperature threshold

was done for studying the violation to the Service

Level Agreement (SLA). that deﬁnes the quality of

the services. We deﬁne the SLA violation with the

percentage of unallocated CPU performance relative

to the total requested performance in the workloads.

Energy-efﬁcient Task Scheduling in Data Centers

279

Figure 4: Optimal trade-off for the temperature threshold

(x-axis: SLA violation, y-axis: energy consumption).

Figure 5: Comparaison of ThaS with other scheduling

schemes.

The experimental results are shown in Figure 3. Sim-

ilar to the results with energy consumption, there is

no SLA violation for the ﬁrst phase (threshold 333

and 335) again due to zero migrations. For thresh-

old 338, where VM migrations are shown in Figure

2, we see an SLA violation. The reason is that a VM

migration causes the CPU performance degradation

and hence the percentage of SLA violations increases

with the number of migrations. For thresholds be-

tween 340 and 353 the SLA violation remains con-

stant, which is resulted by nearly unchanged number

of migrations. In the last phase from threshold 354,

however, the SLA violation arises. This is again be-

cause that many hosts are set to idle and therefore not

all user requirements can be fulﬁlled with a small set

of active hosts. To summarize the results in the three

ﬁgures: The number of VM migrations signiﬁcantly

depends on the value of the Temperature threshold;

the energy consumption remains high when no mi-

gration is possible; VM migration is performed only

after a certain threshold; when the case temperature

(T case) is reached most hosts are put into the sleep

mode, which affects the CPU Utilization threshold

that in turn leads to a low number of VM migrations.

Our goal in thermal-aware scheduling is not only

to minimize the energy consumption but also not re-

sult high SLA violation. Therefore, we have to make

a trade-off in selecting the threshold value, where the

energy consumption and the SLA violation shall both

remain at a minimum. From the previous simula-

tion results we have observed that the third area of

the different waveforms is the optimum range and the

threshold value for the temperature shall be chosen

from this ﬁeld.

In order to give a clearer view about this optimal

threshold of temperature, we made a diagram with

the energy consumption and the SLA violation. Fig-

ure 4 depicts this graph, where the data are from the

tests with the second data center. The x-axis shows

the SLA violation while the y-axis presents the en-

ergy consumption. Observing the graph in the ﬁg-

ure, it can be seen that there is a point where both

the energy and the SLA violation are low. This point

(threshold 343 Kelvin) is exactly the optimal thresh-

old we are looking for. Hence, we selected 343 Kelvin

as the optimum value of the Temperature threshold

for our ThaS scheme. The last experiment studies

the feasibility of our scheduler by comparing the en-

ergy consumption with ThaS and with other three

scheduling schemes, i.e., non power control, DVFS

and power aware ThrMu. Figure 5 depicts the result

of the experiment, where the energy consumption was

measured during a single simulation run with all four

algorithms. We measured the energy consumption of

the two data centers in a single day.

Comparing ThaS with the other scheduling algo-

rithms, it can be observed that ThaS achieves the low-

est energy consumption with a value of 25.64 Kwh

with DC-1 and 49.4 Kwh with DC-2. The energy con-

sumption with other schemes are Non

power control

of 150.68 and 324.17, DVFS of 52.98 and 101.1, and

Power aware ThrMu of 28.9 and 63.2. For the ﬁrst

data center with 50 hosts we achieved a reduction of

83% to Non power control, 52% to DVFS and 11.3%

to power aware ThrMu. For the other data center

with 250 hosts the reduction in energy consumption

by ThaS is 85% to non power control, 52% to DVFS

and 21.8% to power aware ThrMu. It can be seen that

ThaS results a higher reduction in energy consump-

tion for larger data centers than the smaller ones, es-

pecially in comparison with the power-aware schedul-

ing scheme ThrMu.

Overall, we can conclude that the support of VM

migration mechanisms is required for efﬁciently using

Cloud resources and combining the power-aware with

the thermal-aware scheduling strategies provides the

best results for reducing the energy consumption of

data centers.

6 CONCLUSION

Today, energy-efﬁcient computing is becoming more

and more important due to the huge amount of en-

ergy consumption of the data centers. As a result,

researchers are investigating on various methods to

CLOSER 2016 - 6th International Conference on Cloud Computing and Services Science

280

reduce the energy requirement of a computer sys-

tem. This work targets on a scheduling algorithm aim-

ing at allocating virtual machines to physical hosts

of data centers in such a way that the target host

will not be overloaded or over-heated. This means

that we schedule virtual machines with respect to the

temperature and CPU utilization of processors. We

validated the novel scheduler on a simulation envi-

ronment and compared our achievement with several

other scheduling schemes. The experimental results

show a clear beneﬁt with our scheduler.

In the next step of this research work we will ad-

dress on the optimization of the proposed scheduler

with respect to its performance. We plan to use those

intelligent global optimization algorithms to speed up

the procedure of ﬁltering unqualiﬁed hosts.For the

next version of ThaS the Hotspot (Hotspot, ) tool

will adopted, that models multicore architectures with

more accuracy but not more complexity. Hotspot uses

an analogy between electrical circuit phenomena and

a heat transfer phenomena. The heat ﬂow between the

internal CPU chip blocks is modeled by connecting

thermal resistors and thermal storage in blocks. The

power consumed by each chip (which typically cor-

responds to a function unit) is modeled by a power

source. In addition, it is also our future work to

improve the models for calculating processor tem-

perature in order to support the study on many-core

servers.

REFERENCES

AmazonEC2. Amazon Elastic Compute Cloud. [Online].

http://aws.amazon.com/ec2/.

Beloglazov, A. and Buyya, R. (2010). Adaptive threshold-

based approach for energy-efﬁcient consolidation of

virtual machines in cloud data centers. In Proceedings

of the 8th International Workshop on Middleware for

Grids, Clouds and e-Science.

Beloglazov, A. and Buyya, R. (2012). Optimal Online De-

terministic Algorithms and Adaptive Heuristic for En-

ergy and Performance Efﬁcient Dynamic Consolida-

tion of Virtual Machines in Cloud Datacenters. Con-

currency and Computation: Practice and Experience,

24(3):1397–1420.

Calheiros, R. N., Ranjan, R., Beloglazov, A., e Rose, C. A.

F. D., and Buyya, R. (2011). CloudSim: A Toolkit

for Modeling and Simulation of Cloud Comp uting

Environments and Evaluation of Resource Provision-

ing Algorithms. Software: Practice and Experience,

41(1):23–50.

Fang, Y., Wang, F., and Ge, J. (2010). A task scheduling al-

gorithm based on load balancing in cloud computing.

In Proceedings of the 2010 international conference

on Web information systems and mining, pages 271–

277.

GAE. Google App Engine. [Online]. http://code.

google.com/appengine/.

Hotspot. Hotspot. [Online]. http://lava.cs.virginia.edu/

HotSpot/.

Hsu, C. and Feng, W. (2005). A Feasibility Analy-

sis of Power Awareness in Commodity-Based High-

Performance Clusters. In Proceedings of Cluster

Computing, pages 1–10.

Hu, J., Gu, J., Sun, G., and Zhao, T. (2010). A Schedul-

ing Strategy on Load Balancing of Virtual Machine

Resources in Cloud Computing Environment. In Pro-

ceedings of the International Symposium on Parallel

Architectures, Algorithms and Programming, pages

89–96.

Kahn, S., Bilal, K., Zhang, L., Li, H., Hayat, K., Madani, S.,

Min-Allah, N., Wang, L., Chen, D., Iqbal, M., Xu, C.,

and Zomaya, A. (2013). Quantitative Comparisons of

the State of the Art Data Center Architectures. Con-

currency and Computation: Practice & Experience.

DOI=10.1002/cpe.2963.

Keahey, K. and Freeman, T. (2008). Science Clouds: Early

Experiences in Cloud Computing for Scientiﬁc Ap-

plications. In Proceedings of the First Workshop on

Cloud Computing and its Applications.

Kim, D., Kim, H., Jeon, M., Seo, E., and Lee, J. (2008).

Guest-Aware Priority-based Virtual Machine Schedul-

ing for Highly Consolidated Server. In Proceedings

of the 14th International Conference on Parallel and

Distributed Computing (Euro-Par 2008), pages 285–

294.

Knauth, T. and Fetzer, C. (2012). Energy-aware scheduling

for infrastructure clouds. In Proceedings of the IEEE

International Conference on Cloud Computing Tech-

nology and Science, pages 58–65.

Kolodziej, J., Khan, S., Wang, L., Kisiel-Dorohinicki,

M., and Madani, S. (2012). Security, Energy, and

Performance-aware Resource Allocation Mechanisms

for Computational Grids. Future Generation Com-

puter Systems. DOI: 10.1016/j.future.2012.09.009.

Kolodziej, J., Khan, S., Wang, L., and Zomaya, A. (2013).

Energy Efﬁcient Genetic-Based Schedulers in Com-

putational Grids. Concurrency and Computation:

Practice & Experience. DOI=10.1002/cpe.2839.

Li, K., Xu, G., Zhao, G., Dong, Y., and Wang, D. (2011).

Cloud Task Scheduling Based on Load Balancing Ant

Colony Optimization. In Proceedings of the Six An-

nual Chinagrid Conference, pages 3–9.

Mell, P. and Grance, T. The NIST Deﬁnition of Cloud Com-

puting. [Online]. http://csrc.nist.gov/publications/

drafts/800-145/Draft-SP-800-145 cloud-deﬁnition.pdf.

Menzel, M. and Ranjan, R. (2012). CloudGenius: Deci-

sion Support for Web Service Cloud Migration. In

Proceedings of the International ACM Conference on

World Wide Web (WWW 2012), Lyon, France.

Mhedheb, Y., Jrad, F., Tao, J., Kolodziej, J., and Streit, A.

(2013). Load and Thermal-Aware VM Scheduling on

the Cloud. In Algorithms and Architectures for Paral-

lel Processing, pages 101–114.

Nurmi, D., Wolski, R., Grzegorczyk, C., Obertelli, G., So-

man, S., Youseff, L., and Zagorodnov, D. (2008).

Energy-efﬁcient Task Scheduling in Data Centers

281

The Eucalyptus Open-source Cloud-computing Sys-

tem. In Proceedings of Cloud Computing and

Its Applications. Available: http://eucalyptus.cs.

ucsb.edu/wiki/Presentations.

Openstack (2013). OpenStack Cloud Software. [Online]

http://openstack.org/.

rackspace. The Rackspace Open Cloud. [Online]. http://

www.rackspace.com/cloud/.

Ranjan, R., Buyya, R., and Harwood, A. (2005). A Case

for Cooperative and Incentive Based Coupling of Dis-

tributed Clusters. In Proceedings of the 7th IEEE In-

ternational Conference on Cluster Computing (Clus-

ter 2005), pages 1–11, Boston, Massachusetts, USA.

Ranjan, R., Harwood, A., and Buyya, R. (2006). A SLA-

Based Coordinated Super scheduling Scheme and Per-

formance for Computational Grids. In Proceedings

of the 8th IEEE International Conference on Clus-

ter Computing (Cluster 2006), pages 1–8, Barcelona,

Spain.

Skadron, K., Abdelzaher, T., and Stan, M. R. (2002).

Control-theoretic techniques and thermal-rc modeling

for accurate and localized dynamic thermal manage-

ment. In Proceedings of the 8th International Sym-

posium on High-Performance Computer Architecture,

HPCA ’02, pages 17–, Washington, DC, USA. IEEE

Computer Society.

Sotomayor, B., Montero, R., Llorente, I., and Foster, I.

(2008). Capacity Leasing in Cloud Systems using the

OpenNebula Engine. In The First Workshop on Cloud

Computing and its Applications.

spec08. SpecPower08. [Online] http://www.spec.org.

Takouna, I., Dawoud, W., and Meinel, C. (2011). Efﬁ-

cient Virtual Machine Scheduling-policy for Virtual-

ized heterogeneous Multicore Systems. In Proceed-

ings of the International Conference on Parallel and

Distributed Processing Techniques and Applications

(PDPTA2011).

Wang, L. and Khan, S. (2013). Review of performance met-

rics for green data centers: a taxonomy study. The

Journal of Supercomputing, 63(3):639–656.

Wang, L., Laszewski, G., Younge, A., He, X., Kunze,

M., Tao, J., and Fu, C. (2010). Cloud Computing:

a Perspective Study. New Generation Computing,

28(2):137–146.

Wang, L., von Laszewski, G., Huang, F., Dayal, J., Fru-

lani, T., and Fox, G. (2011). Task scheduling with

ann-based temperature prediction in a data center: a

simulation-based study. Engineering with Computers,

27(4):381–391.

Wang, Y., Wang, X., and Chen, Y. (2012). Energy-

efﬁcient virtual machine scheduling in performance-

asymmetric multi-core architectures. In Proceedings

of the 8th international conference on Network and

service management and 2012 workshop on systems

virtualiztion management, pages 288–294.

Windows. Windows Azure Platform. [Online] http://

www.microsoft.com/windowsazure.

CLOSER 2016 - 6th International Conference on Cloud Computing and Services Science

282
