Towards Intelligent Data Analysis: The Metadata Challenge

Besim Bilalli

, Alberto Abell´o

, Tom`as Aluja-Banet

and Robert Wrembel

Universitat Polit´ecnica de Catalunya, Barcelona, Spain

Poznan University of Technology, Poznan, Poland

Keywords:

Metadata, Data Mining, Big Data Analytics.

Abstract:

Once analyzed correctly, data can yield substantial beneﬁts. The process of analyzing the data and transform-

ing it into knowledge is known as Knowledge Discovery in Databases (KDD). The plethora and subtleties of

algorithms in the different steps of KDD, render it challenging. An effective user support is of crucial impor-

tance, even more now, when the analysis is performed on Big Data. Metadata is the necessary component to

drive the user support. In this paper we study the metadata required to provide user support on every stage

of the KDD process. We show that intelligent systems addressing the problem of user assistance in KDD are

incomplete in this regard. They do not use the whole potential of metadata to enable assistance during the

whole process. We present a comprehensive classiﬁcation of all the metadata required to provide user support.

Furthermore, we present our implementation of a metadata repository for storing and managing this metadata

and explain its beneﬁts in a real Big Data analytics project.

1 INTRODUCTION

Our capability of gathering data has developed to the

highest extents, whereas the ability to analyze it, lags

far behind. Storing huge volumes of data is worth the

effort only if we are able to transform data into knowl-

edge. The process of transforming data into knowl-

edge is known as Knowledge Discovery in Databases

(KDD) and consists of the following steps: data se-

lection, data pre-processing, data mining and evalua-

tion or interpretation (Fayyad et al., 1996).

The need for knowledge discovery is rising

tremendously. This is more noticeable nowadays

thanks to the low-cost, distributed data storage and

processing platforms (e.g., Hadoop). They allow stor-

ing and processing huge datasets on large clusters of

commodity hardware. A Data Lake, for instance, is

an important component of the data analytics pipeline

in the world of Big Data. The idea is to have a single

store of all the raw data (e.g., structured and unstruc-

tured) that anyone in an organization might need to

analyze. However, the relevant data over which the

analysis is going to be performed needs to be selected

from the whole range of the available data. As the

selection of data affects the results of the analysis,

data needs to be thoroughly tracked in order to jus-

tify the results (e.g., lineage). The representation and

the quality of data also affect the analysis. Raw data

is often irrelevant, redundant, and incomplete and re-

quires pre-processing. It is commonly known that 50-

80% of data analysis time is spent on pre-processing.

Once the data is pre-processed, there comes the difﬁ-

cult task of selecting the most adequate mining algo-

rithm for a given problem. Many different algorithms

are availableand their performancecan vary consider-

ably. After data mining, the evaluation/interpretation

step follows. The generated models need to be in-

terpreted and/or evaluated to be understood by the

user. All in all, the above mentioned steps indicate

that KDD in general is an inherently challenging task.

Therefore, users need to be thoroughly supported.

A lot of research has been done in this regard

and systems that aim at providing user assistance

have been developed. These systems are referred to

as Intelligent Discovery Assistants (IDAs) (Bernstein

et al., 2005). The driving factor for the user assistance

is the metadata they consider. Yet, there is no agree-

ment on which kinds of metadata need to be gath-

ered and stored in order to provide user assistance.

In this paper we tackle the problem by studying the

types and roles of metadata. We observe that the meta

knowledge considered in IDAs is not complete (e.g.,

domain knowledge and lineage is missing). Hence,

we provide a classiﬁcation of the metadata needed to

support the whole process and discuss the implemen-

tation of our metadata repository.

Contributions. In particular, our main contributions

are as follows.

Bilalli, B., Abelló, A., Aluja-Banet, T. and Wrembel, R.

Towards Intelligent Data Analysis: The Metadata Challenge.

DOI: 10.5220/0005876203310338

In Proceedings of the International Conference on Internet of Things and Big Data (IoTBD 2016), pages 331-338

ISBN: 978-989-758-183-0

331

• We identify and extend the metadata required for

providing user support for the whole process of

KDD including the very ﬁrst step of data selection

and we provide a classiﬁcation of this metadata.

• We implement a metadata repository with the aim

of storing and managing the metadata discovered

and show its beneﬁts in a real case scenario.

The rest of the paper is organized as follows. Sec-

tion 2 discusses the related work. Section 3 presents

an analysis of IDAs and brieﬂy discusses the differ-

ences between different categories of these systems.

Section 4 studies the metadata required for providing

user support and shows examples of systems using the

respective metadata. Section 5 contributes a classiﬁ-

cation of the metadata needed to support the whole

process of KDD. Section 6 shortly presents the imple-

mentation of our metadata repository and its beneﬁts

in a real Big Data analytics project. Finally, Section 7

concludes the paper.

2 RELATED WORK

In (Foshay et al., 2007), a taxonomy of the end-user

metadata with respect to data warehousing is given.

This taxonomy is further extended in (Varga et al.,

2014), where a metadata framework is provided to

support the user assistance activities in the context

of next generation BI systems. It provides a techni-

cal classiﬁcation of the metadata artifacts required to

enable user assistance in retrieving and exploring the

data. The focus is on automating certain user related

tasks with respect to queries (e.g., query recommen-

dation). Whereas, we are studying and classifying

metadata with the emphasis on how it can help the

user during the different steps of KDD.

Another work that can be seen as closely related to

us is (Serban et al., 2013). The authors provide a com-

prehensive survey of the systems that make extensive

use of metadata to make the automation of knowledge

discovery possible. The emphasis is put on explain-

ing the architectures of the systems rather than on a

comprehensive classiﬁcation of metadata.

Finally, Common Warehouse Metamodel (CWM,

2003) provides the necessary abstractions to model

generic representations of data mining models, how-

ever, the metadata considered does not cover the

whole range of KDD steps. It is mainly focused on the

metadata for the data mining step. Furthermore, the

metadata is considered from the perspective of data

interchange, which is how different systems can share

and understand metadata with regard to data mining.

3 INTELLIGENT DISCOVERY

ASSISTANTS

The KDD process is challenging for novice users. As

already stated in Section 1, the most prominent works

done in terms of providing helpful assistance to the

users are through IDAs. In order to complete our

study on the metadata needed for the user support we

have to know how and to what extent this metadata is

used by different IDAs. Depending on the core tech-

niques and metadata used, IDAs can be divided into 5

broad categories (Serban et al., 2013), namely: expert

systems, meta-learning systems, case-based reason-

ing systems, planning-based data analysis systems,

workﬂow composition environments.

Expert systems (ES) are the earliest and the simplest

systems to provide help to the user during the data

mining phase. Their main component is a knowledge

base consisting of expert rules, which determine the

mining algorithm to be used. Questions are posed to

the user about a given problem and the metadata pro-

vided as response is used by the system in order to

assess which rule is appropriate.

Meta-learning systems (MLS) are more advanced.

The rules that were statically deﬁned by the experts in

the previous category are dynamically learned here.

MLSs try to discover the relationship between mea-

surable features of the dataset and the performance

of different algorithms, which is a standard learning

problem. The learned model can then be used to pre-

dict the most suitable algorithm for a given dataset.

The idea behind case-based reasoning systems (CBR)

is to store the successfully applied workﬂows as

cases, in a case base, with the only goal of reusing

them in the future. When faced with a new problem

(i.e., dataset) provided by the user, these systems re-

turn k previous cases from the case base according to

the level of similarity with the new problem. The se-

lected workﬂow can then be adapted to properly ﬁt

and solve the new problem. Their disadvantage, as in

MLSs, is that they can provide structured help only if

a new problem is similar to the problems seen so far.

Planning-based data analysis systems (PDAS) are

able to autonomously design valid workﬂows without

relying on the similarity between different problems.

In order to do this, the workﬂow composition prob-

lem is seen as a planning problem, where a plan is

built by combining operators that transform the ini-

tial problem into accurate models or predictions. In

order to construct valid workﬂows, the input, output,

preconditions, and effects of each operator need to be

known. Once the conditions are met, operators are

composed to form valid but not necessarily optimal

workﬂows, which at a later stage are ranked.

IoTBD 2016 - International Conference on Internet of Things and Big Data

332

Workﬂow composition environments (WCE) do not

provide automatic support for data analysis, but facil-

itate the use of different data mining algorithms pro-

viding nice graphical environments for quick work-

ﬂow design and execution.

4 METADATA CHALLENGE IN

KDD

In this section, we analyze what can be achieved by

collecting metadata and what kinds of metadata can

be collected in a KDD environment.

4.1 The Role of Metadata

The generation and management of metadata can de-

termine the type of support offered. We differentiate

among the following.

Single-step Support. It is an indication of the

complexity of the advice offered. The single step for

which some kind of user support or even automation

is provided is usually the data mining step of the

KDD process.

Multi-step Support. Similarly, it indicates the

complexity of the advice offered. Metadata can be

used to extend the support to several steps of KDD.

Variable Selection Support. It indicates whether a

system provides user support in the very ﬁrst phase

of a KDD process. It is of crucial importance when

an analysis of raw data needs to be done (e.g., in

a Big Data environment). Raw data in this context

refers to data that is not offered in a form of a dataset

but, it is stored in its original format. Hence, prior to

analysis, the data of interest needs to be selected and

integrated into a unique dataset.

Explanations. It is easier for the user to design

workﬂows when explanations are present. Expla-

nations can be on operators for facilitating a design

process as well as on results to help the user interpret

them. This can be done by, for instance, giving useful

instructions about statistical concepts.

Reuse of Past Experience. Metadata can increase

reliability by enabling the reuse of workﬂows. The

reuse of successful cases speeds up the process

considerably. It allows to build on prior work and

facilitates deeper analysis. It can enable truly collab-

orative knowledge discovery.

Automatic Workﬂow Generation. Metadata can

drive the automatic composition and execution of the

pre-processing and mining steps. This is the most

advanced type of user support but at the same time

the most challenging one.

Business Understanding. Metadata can provide in-

formation about the meaning of the data, the termi-

nology and business concepts and their relationships

to the data. Metadata can provide information about

the source of the data (provenance) and the path fol-

lowed from a source to the current site (lineage).

4.2 Types of Metadata

The main objects participating in a KDD process in-

clude: (1) a dataset that needs to be analyzed, (2) op-

erators used for pre-processing, and mining, as well

as (3) workﬂows, which are combinations of operators

with data in the form of directed acyclic graphs. In or-

der to effectively support the user during the analysis,

metadata should be stored for every aforementioned

object. In addition, metadata that can boost the user

support and which were not considered in this context

are (4) domain knowledge used to store information

for the concrete domain of data and (5) lineage meta-

data, relevant to justify the results of an analysis.

Metadata on the Input Dataset. The idea of charac-

terizing a dataset has been researched from the early

inception of meta learning. A dataset that needs to be

analyzed - containing all the attributes that are rele-

vant to the problem at hand - is assumed to be selected

in advance and is generally described by the following

groups of characteristics:

• General Measures: include general information

related to the dataset at hand. To a certain extent

they are conceived to measure the complexity of

the underlying problem. Some of them are: the

number of instances, number of attributes, dataset

dimensionality, ratio of missing values, etc.

• Statistical and Information-theoretic Measures:

describe attribute statistics and class distributions

of a dataset sample. They include different sum-

mary statistics per attribute like mean, standard

deviation, etc.

However, if the problem to be solved is a prediction

problem, then, a variable (or more) is deﬁned to be a

response variable. Once the response is deﬁned, fur-

ther metadata measuring the association between the

remaining (input) variables and the response(s) (out-

put) can be used to describe the dataset. Hence, we

can additionally have the following groups of dataset

characteristics:

• Geometrical and Topological Measures: this

group tries to capture geometrical and topologi-

cal complexity of class boundaries (Ho and Basu,

2002). It includes non-linearity, volume of over-

lap region, max. Fisher’s discriminant ratio, frac-

tion of instance on class boundary, ratio of avg.

intra/inter class nearest neighbour distance, etc.

Towards Intelligent Data Analysis: The Metadata Challenge

333

• Landmarking and Model-based Measures: this

group is related to measures asserted with fast ma-

chine learning algorithms, so called landmarkers,

and its derivative based on the learned models. It

includes error rates and pairwise 1− p values ob-

tained by landmarkers such as 1NN or Decision-

Stump as well as histogram weights learned by

Relief or Support Vector Machines (SVM).

Metadata on Operators. They are typically ex-

pressed in the form of semantic information (e.g., on-

tology). By operators we mean all the different ele-

ments that can operate on a dataset. These include:

(1) different transformation methods like normaliza-

tion, discretization, etc., which are considered to be

pre-processing operators and (2) different kinds of

learning algorithms like decision trees, support vector

machines, etc., which are considered to be data min-

ing operators. Metadata on operators can be internal

or external (Serban et al., 2013). External metadata

treat an operator as a black-box, which means they

only consider metadata with regard to the Input, Out-

put, and some other properties like Preconditions and

Effects (IOPE). Internal metadata tear up the box by

considering metadata linked to an operator’s internal

structure (e.g., parameters or model type) or perfor-

mance (e.g., speed, accuracy, model complexity).

Metadata on Workﬂows. The previously mentioned

metadata are what systems need in order to pro-

vide assistance in terms of constructing valid work-

ﬂows (e.g., all preconditions or input constraints of

algorithms are met). However, the generated work-

ﬂows may not necessarily be optimal. Moreover, the

number of generated workﬂows can reach thousands,

given the vast number of available data mining oper-

ators (e.g., Rapidminer, Weka). Thus, there needs to

be a way of ranking the workﬂows. One way to do

this is to keep track of metadata about workﬂows. In

the eIDA system for instance, in order to character-

ize workﬂows, they follow a process mining-like ap-

proach. They extract generalized, relational, frequent

patterns over the tree representations of the workﬂows

(Kalousis et al., 2014).

Domain Knowledge. The effectiveness and need for

domain knowledge in knowledge discovery has been

conﬁrmed in past research efforts. It is recognized by

(Ioannis Kopanas and Daskalaki, 2002) that there is

a role for domain knowledge in all stages of a KDD

process. They demonstrate through examples how the

domain expert is needed to (1) help deﬁne the prob-

lem by, e.g., giving business rules on what a failed

transaction is or what is considered a problematic cus-

tomer (2) assist in the creation of the target dataset

by, e.g., deﬁning the structure of the data and the se-

mantic value of the data attribute values. However, in

order to make use of it, domain knowledge should be

represented by models that computers can understand.

Ontologies are some of the successful knowledge en-

gineering advances that can be used to build and use

domain knowledge in a formal way. An ontology is

an explicit speciﬁcation of a conceptualization. Nor-

mally, it is developed to specify a particular domain

(e.g., genetics). Such an ontology, often known as a

domain ontology, formally speciﬁes the concepts and

relationships in that domain. Note that domain knowl-

edge is not used by IDAs in the literature.

Lineage Metadata. The KDD process can beneﬁt

from lineage metadata. Lineage metadata is com-

posed of steps used to derive a particular dataset. It

can be thought of as a recipe for creating data. The

quality of the data for the user’s analysis can be eval-

uated through the lineage of the dataset. Data quality

of the source is important because errors introduced

tend to inﬂate as the data propagates. This issue is

even more critical when using raw data available in

data lakes. The level of detail included in the lineage

determines the extent to which the quality of the data

can be assessed. If semantic knowledge of the pedi-

gree is available, it is possible to automatically evalu-

ate it based on quality metrics (Simmhan et al., 2005).

All in all, this metadata can be used to understand and

justify the results obtained during the analysis. This

kind of metadata is also not considered in IDAs.

4.3 Comparison of Metadata on IDAs

In Table 1, we show types of metadata used by IDAs

and types of provided support. For each cell in the

table we put sign ’+’ if the system supports the par-

ticular concept described in the column and sign ’-’

if not. From the given table, we identify that many

support limitations can be explained with the lack of

proper metadata. Moreover, note that systems do not

deal with the problem of variable selection (e.g., in

a big data environment, provide support in terms of

which variables are important to select for the analysis

and combine them into a unique dataset) and none of

the systems provides support in terms of business un-

derstanding. These limitations are due to the lack of

appropriate metadata. We believe that domain knowl-

edge and lineage metadata will improve the systems

in this regard.

- ES and MLS do not use external metadata on oper-

ators (e.g., IOPE), therefore are not able to construct

entire workﬂows.

- MLS and CBR use huge number of input meta-

data but they do not provide support for automatically

combining multiple steps.

- PDAS generate automatic workﬂows but they start

IoTBD 2016 - International Conference on Internet of Things and Big Data

334

Table 1: Type and role of metadata in IDAs.

Metadata Type Metadata Role

Category

System

Input

Operator

Workﬂow

Domain Know.

Lineage

Single step supp.

Multistep supp.

Variable selection

Explanational

Reuse

Automation

Business underst.

Int. Ext.

ES SPRINGEX (Raes, 1992) + - - - - - + - - + - - -

MLT Consultant (Sleeman et al., 1995) + + - - - - + - - + - - -

MLS DMA (Giraud-Carrier, 2005) + + - - - - + - - - - - -

NOEMON (Kalousis and Hilario, 2001) + + - - - - + - - - - - -

CBR CITRUS (Engels, 1996) + + - + - - - + - + + + -

AST (Lindner and Studer, 1999) + + - - - - + - - - + + -

MiningMart (Morik and Scholz, 2002) + + - - - - - - - - + - -

PDAS RDM (Z´akov´a et al., 2011) + + + + - - - + - - - - -

KDDVM (Diamantini et al., 2009) + + + + - - - + - - - + -

eIDA (Kietz et al., 2014) + + + + - - + + - - + + -

WCE IBM SPSS Modeler + - + - - - - - - + - - -

SAS Enterprise Miner + - + - - - - - - + - - -

RapidMiner + - + - - - - - - + - - -

Weka + - + - - - - - - + - - -

from scratch every time. They do not make use of the

experience from previous data analysis.

- WCEs allow to construct workﬂows but they do not

provide much guidance.

5 METADATA CLASSIFICATION

The analysis in Section 4 showed that IDAs rely heav-

ily on metadata in order to provide user support. In

order to classify the identiﬁed metadata, we decided

to extend the classiﬁcation provided in (Foshay et al.,

2007) and later extended in (Varga et al., 2014). Our

classiﬁcation can now capture the whole range of

metadata required for the KDD process.

The classiﬁcation tree is given in Figure 1. Note

that the shaded shapes belong to the original classi-

ﬁcation that consists of the following metadata cate-

gories: Deﬁnitional, Data quality, Navigational, Lin-

eage, and Ratings. Each category contains its respec-

tive metadata artifacts again denoted as shaded shapes

in the ﬁgure. Nevertheless, in order to attach the re-

quired metadata artifacts, change and extension of the

taxonomy was required, note the non shaded shapes.

The imposed changes are the following: Deﬁnitional

category is extended with a Domain Knowledge sub-

category which is going to cover metadata related to

the domain, Data quality is renamed to Data charac-

teristics in order to better reﬂect the meaning of the

participating artifacts. An additional category named

Activity characteristics is added to capture active ob-

jects (e.g., operators) in a knowledge discovery pro-

cess. An additional category Assessment is added

with the aim of capturing the metadata artifacts with

respect to the output of the knowledge discovery pro-

cess. Next, the Lineage category is extended with

three metadata artifacts discussed below. Moreover,

additional artifacts belonging to different categories

are further added.

For the purpose of our classiﬁcation we clearly deﬁne

all the categories and respective metadata artifacts be-

low. Note however, that metadata artifacts that belong

to (Foshay et al., 2007; Varga et al., 2014) are not dis-

cussed extensively. The interested reader is referred

to those papers for further information.

The deﬁnitional category contains metadata that

conveys the meaning of the data to the user or the

system. From the original taxonomy in this category

there are the integration schema, user characteristics

and a vocabulary of business terminology. We extend

the deﬁnitional category with the domain knowledge

subcategory which is going to contain different meta-

data with regard to the domain. The idea is to enable a

knowledge-rich data analysis. However, the goal of a

knowledge-rich data analysis is not to provide a priori

all the knowledge that might be required but to sup-

port a feedback loop by which a small amount of ini-

tial knowledge can be bootstrapped into more knowl-

edge by mining, which can in turn be complemented

by more human-supplied knowledge to allow further

mining, etc. Hence, under the domain knowledge we

Towards Intelligent Data Analysis: The Metadata Challenge

335

Metadata

Deﬁnitional

Data

characteristics

Navigational

Activity

characteristics

Ratings

Characteristics

Schema

Domain

Knowledge

Vocabulary

Expert

Rules

General

Characteristics

Statistical

Info. Theoretic

Geometrical,

Topological

Landmarking

Query

Query log

Session

Workﬂow

Operator

Data mining

Data

preprocessing

External

Internal

Lineage

Artifact

Process

Agent

Assessment

Preferences

Statistics

Speed

Accuracy

Category Artifact

User related

User and

system related

System related

Color

[Fosh y et al.]a

[Varga et al.]

added

Figure 1: Metadata classiﬁcation.

place the vocabulary artifact from the original classi-

ﬁcation, this can be replaced or can easily represent

the domain ontology discussed in Section 4.2. Fur-

thermore, we add expert rules as metadata which can

represent the expert knowledge for the domain.

Data Characteristics consists of artifacts that con-

vey information about the characteristics of data that

are of crucial importance to a knowledge discovery

process. They advice the system about the complete-

ness or even validity of data. Metadata artifacts in this

category are those detected in the analysis in Section

4.2.

The navigational category comes from the original

classiﬁcation and keeps track of how the user explores

and navigates through data. The metadata artifacts

considered under this category can be useful for en-

abling user support in a data selection phase prior

to data mining (e.g., suggesting the user relevant at-

tributes using past experience). Metadata artifacts are:

query, query log, and sessions.

The activity characteristics category consists of meta-

data artifacts whose expressiveness determines the

degree of automation that can be achieved in the pro-

cess of knowledge discovery. These are the most im-

portant metadata required in a KDD process. Note

that these kind of metadata were not considered in the

previous classiﬁcations. There are two main metadata

artifacts considered here, namely metadata on opera-

tors and metadata on workﬂows (see Section 4.2).

Lineage consists of artifacts that model resources

(e.g., data-sets) as artifacts, processes (e.g., actions

or series of actions performed in artifacts or caused

by artifacts, and resulting in new artifacts) and agents

(e.g., contextual entities acting as catalysts of a pro-

cess, enabling, facilitating, controlling, or affecting

its execution) (Moreau et al., 2011). The aim of lin-

eage metadata is to capture the causal dependencies

between the artifacts, processes, and agents.

The Ratings category comes from the original taxon-

omy and it contains metadata such as user preferences

and usage statistics. However, note that the prefer-

ences artifact is important with regard to knowledge

discovery as well. It can store different user goals,

which can be used by the system to design work-

ﬂows optimizing some performance measure associ-

ated with the user goal. Finally, statistics relates to the

data usage indicators. It can keep evidence of which

data are explored more.

The Assessment category consists of metadata arti-

facts with regard to the output of a knowledge dis-

covery process. They can be used to assess how good

are the generated DM workﬂows. This is deﬁned by

the correctness in execution and its performance with

respect to evaluation criteria, such as accuracy and

speed. These metadata can be used to list the best

performing workﬂow or rank all of the constructed

workﬂows.

6 METADATA REPOSITORY

After having identiﬁed the metadata required, we turn

on discussing how these metadata can be stored and

managed.

The best way to store metadata is to store them in

a metadata repository. However, usually metadata re-

main hidden in scripts and programs, without being

further reused. This is also what we realized is hap-

pening in practice in a project we are developing with

a multinational company located in Barcelona

https://inlab.ﬁb.upc.edu/en/big-data-analytics-lab

IoTBD 2016 - International Conference on Internet of Things and Big Data

336

Passive Operator

Algorithm

AlgorithmCharacteristic

FeatureReport DataSetMiningModel

QualitativeFeature

QuantitativeFeature

TargetFeature

FeatureUsage

DataSource SourceAttribute

DomainConceptDomainOntology Evidence

PerformUser

StatisticalAttribute

TimeAttribute

OperatorCharacteristic

Preprocessing

ModelEvaluation

Modeling

ModelApplication

OperatorParameter

DMData

FeatureCharacteristic

LabeledDataSet

DataSetCharacteristic

IOObject

uses

produces

performAfter

Figure 2: Conceptual schema of the metadata repository.

Semantic Metadata

Repository

HBASE

GUI

Selection of Variables Recommended transformations

Apply selected transformations

Obtained matrix

Data Lake

HDFS

Figure 3: High level view of the proposed system.

The project aims at improving the current state of

the data analytics process in the company. The idea

is to allow data analysts to easily select relevant vari-

ables for their analysis and assist them during the data

pre-processing and mining. The company stores the

variables or the data in a raw format in a Data Lake

in a Hadoop ecosystem. In order to allow an easy

selection of variables and provide user support dur-

ing the pre-processing phase (e.g., recommend pre-

processing operations particularly suited for the do-

main) we created a semantic repository with the aim

of storing all the necessary metadata. The variables in

the Data Lake and their respective characteristics will

be mapped to corresponding concepts in the reposi-

tory. In addition, different possible transformations

(pre-processing operations; domain knowledge) will

be described in the repository and they will be linked

to corresponding concepts. The user will be able to

easily access the variables through the graphical inter-

face which is going to be fed by the repository. After

selecting the variables (e.g., their corresponding con-

cepts) of interest proper transformations will be rec-

ommended. The information of which pre-processing

will be applied to a given variable will be deduced

from the metadata repository. Hence, not everybody

in the need of analyzing the data will have to be an

expert of the domain, as happened to be the case pre-

viously in the company. Domain speciﬁc knowledge

will be added once to the repository, and will be used

automatically (repeatedly) by everyone wishing to an-

alyze the data. A high level architecture of the system

proposed for the project is shown in Figure 3.

The software components accessing the repository

will be ”bound” to the given metadata structure which

is conceptually described by a schema shown in Fig-

ure 2. The comprehensive schema proposed in this

paper proves to be useful in the project.

The schema can be logically divided into three

main parts. The ﬁrst keeps track of the domain knowl-

edge, the second manages information with regard to

passive elements, and they fall under the IOObject

class, and the third manages information with regard

to active elements and they fall under the Operator

class.

Implementation. We used Resource Description

Framework (RDF) as a data model for storing the

Towards Intelligent Data Analysis: The Metadata Challenge

337

metadata. In RDF, statements about resources can be

made in the form subject-predicate-objectexpressions

and they are called triples. Hence, our repository is

deﬁned as a triple store, where we used OpenLink

Virtuoso as a storage engine. The repository is pro-

vided as a Web Service and an application for meta-

data management is built on top of it. JavaServer

Pages (JSP), Asynchronous JavaScript (AJAX) and

XML are used to implement the application and the

graphical user interface.

7 CONCLUSION AND FUTURE

WORK

The process of knowledge discovery is challenging.

Data relevant to the analysis needs to be selected, pre-

processed, mined and ﬁnally evaluated. Beginners are

alarmed by the myriad of operators and more experi-

enced users limit their activity to several known ap-

proaches. A thorough user assistance is necessary.

Therefore, systems with the aim of assisting the user

during this process are built. We studied these sys-

tems with the goal of identifying the metadata used to

enable the assistance. Hence, we identiﬁed the meta-

data used to provide user support during the KDD

process. We found out that important metadata such

as domain knowledge and lineage which can make

the life of a data analyst easy, have not been con-

sidered. We provided a classiﬁcation of the meta-

data found. We proposed a comprehensive metadata

framework that captures the complete range of meta-

data needed to assist the user during the whole process

of KDD. We showed the importance of such metadata

in a real project by implementing a metadata reposi-

tory to store and manage the whole range of metadata.

In our future work, we are planning to extend the

domain knowledge incorporated into the repository

and we are planning to develop tools for exploiting

the metadata. We are going to test different ways of

reasoning on top of the metadata. Moreover, we will

be exploring the idea of incorporating meta learning

into the whole picture.

ACKNOWLEDGMENTS

This research has been funded by the European Com-

mission through the Erasmus Mundus Joint Doctorate

“Information Technologies for Business Intelligence -

Doctoral College” (IT4BI-DC).

REFERENCES

Bernstein, A., Provost, F. J., and Hill, S. (2005). Toward

intelligent assistance for a data mining process: An

ontology-based approach for cost-sensitive classiﬁca-

tion. IEEE TKDE, 17(4).

CWM (2003). Object Management Group: Common

warehouse metamodel speciﬁcation. Available at

http://www.omg.org/spec/CWM/1.1/PDF/.

Diamantini, C., Potena, D., and Storti, E. (2009). Ontology-

driven KDD process composition. In IDA.

Engels, R. (1996). Planning tasks for KDD; performing

task-oriented user-guidance. In KDD.

Fayyad, U. M. et al. (1996). From data mining to knowledge

discovery in databases. AI Magazine, 17(3).

Foshay, N. et al. (2007). Does data warehouse end-user

metadata add value? Commun. ACM, 50(11).

Giraud-Carrier, C. (2005). The data mining advisor: meta-

learning at the service of practitioners. In ICMLA.

Ho, T. K. and Basu, M. (2002). Complexity measures of su-

pervised classiﬁcation problems. IEEE TPAMI, 24(3).

Ioannis Kopanas, N. M. A. and Daskalaki, S. (2002). The

role of domain knowledge in a large scale data mining

project. In SETN.

Kalousis, A. et al. (2014). Using meta-mining to support

DM workﬂow planning and optimization. JAIR,51(1).

Kalousis, A. and Hilario, M. (2001). Model selection via

meta-learning: A comparative study. IJAIT, 10(4).

Kietz, J., Serban, F., Fischer, S., and Bernstein, A. (2014).

Semantics Inside! But Let’s Not Tell the Data Miners:

Intelligent Support for Data Mining. In ESWC.

Lindner, G. and Studer, R. (1999). AST: support for algo-

rithm selection with a CBR approach. In PKDD.

Moreau, L. et al. (2011). The open provenance model core

speciﬁcation (v1.1). FGCS, 27(6).

Morik, K. and Scholz, M. (2002). The miningmart ap-

proach. In Informatik bewegt: Informatik.

Raes, J. (1992). Inside two commercially available statisti-

cal expert systems. Statistics and Computing, 2(2).

Serban, F., Vanschoren, J., Kietz, J., and Bernstein, A.

(2013). A survey of intelligent assistants for data anal-

ysis. ACM Comput. Surv., 45(3).

Simmhan, Y. L., Plale, B., and Gannon, D. (2005). A survey

of data provenance in e-science. SIGMOD Rec., 34(3).

Sleeman, D. H., Rissakis, M., Craw, S., Graner, N., and

Sharma, S. (1995). Consultant-2: pre- and post-

processing of ML applications. IJHCS, 43(1).

Varga, J. et al. (2014). Towards next generation BI systems:

The analytical metadata challenge. In DaWaK.

Z´akov´a, M., Kremen, P., Zelezn´y, F., and Lavrac, N.

(2011). Automating KD workﬂow composition

through ontology-based planning. IEEE T-ASE, 8(2).

IoTBD 2016 - International Conference on Internet of Things and Big Data

338
