Privacy-preserving Data Sharing in Portable Clouds

Clemens Zeidler and Muhammad Rizwan Asghar

University of Auckland, 38 Princes Street, Auckland 1142, New Zealand

Keywords:

Portable Cloud, Privacy, Data Sharing, Data Migration, Migration Costs, Migration Agent.

Abstract:

Cloud storage is a cheap and reliable solution for users to share data with their contacts. However, the

lack of standardisation and migration tools makes it difﬁcult for users to migrate to another Cloud Service

Provider (CSP) without losing contacts, thus resulting in a vendor lock-in problem. In this work, we aim

at providing a generic framework, named PortableCloud, that is ﬂexible enough to enable users to migrate

seamlessly to a different CSP keeping all their data and contacts. To preserve privacy of users, the data in

the portable cloud is concealed from the CSP by employing encryption techniques. Moreover, we introduce a

migration agent that assists users in automatically ﬁnding a suitable CSP that can satisfy their needs.

1 INTRODUCTION

Cloud storage is a cheap and reliable alternative to a

local storage system. A Cloud Service Provider (CSP)

is considered to ensure availability of cloud services

so that users can get access to their data from any-

where at any time. Data in the cloud is stored at ge-

ographically dispersed locations, thus raising serious

privacy concerns. Assuming that the CSP is honest-

but-curious (De Capitani di Vimercati et al., 2008),

data has to be kept conﬁdential.

Many CSPs allow their users to share data with

each other, which is a great way to collaborate with

third parties. For example, Dropbox

enables users

to share ﬁles between each other. However, sharing

data with users who do not belong to the same CSP is

usually limited and less secure and requires a manual

token or key exchange with third parties. Through-

out this paper, we call third parties contacts, i.e., the

parties with whom users shares their data.

There are various reasons why a user may want to

migrate her data from one CSP to another one. For

example, if there are cheaper CSPs available, the ser-

vice condition have changed or the current service is

not reliable enough. Furthermore, there are jurisdic-

tional restrictions on the CSP (Joint et al., 2009). In

the worst case, a CSP might have to shut down its ser-

vices for ﬁnancial or legal issues. For instance, if a

CSP is used for illegal ﬁle sharing, the CSP may face

legal issues and its service may get interrupted. For

https://www.dropbox.com/

innocent users, this can lead to loss of their personal

data.

Having contacts at a certain CSP can be a hin-

drance for a user to migrate to another CSP since these

contacts would then be lost, i.e., a user and a con-

tact would not be able to access and share data with

each other anymore. Another problem that makes it

hard to migrate a cloud service is that there is often

a lack of tools for a seamless migration. For exam-

ple, there is no simple way to migrate data between

CSPs when data needs to be transformed to a differ-

ent format or encryption scheme. These problems that

could stop users from migrating to a different CSP are

also known as vendor lock-in (Armbrust et al., 2010;

De Chaves et al., 2011; Satzger et al., 2013).

In this paper, we propose PortableCloud, an ar-

chitecture that targets the problem of vendor lock-ins

and allows users to seamlessly migrate data between

CSPs that run PortableCloud. If required, data can

even be removed from the cloud and migrated to a

local service that runs PortableCloud. Data can be

shared between contacts that reside either at the same

or a different CSP (see Figure 3). To preserve pri-

vacy of users, data is stored encrypted and can only be

accessed by authorised parties. When migrating the

portable cloud to a new CSP, all contacts are kept and

automatically notiﬁed about the migration, i.e., the

migration is transparent to users and their contacts.

We provide a migration cost analysis of the portable

cloud migration. Further, we propose an agent that

informs users about CSPs with better conditions in

order to help them to migrate to a new CSP.

274

Zeidler, C. and Asghar, M.

Privacy-preserving Data Sharing in Portable Clouds.

In Proceedings of the 6th International Conference on Cloud Computing and Services Science (CLOSER 2016) - Volume 2, pages 274-281

ISBN: 978-989-758-182-3

Our contributions can be summarised as follows:

• A proposal of a novel privacy-preserving portable

cloud architecture PortableCloud that enables

seamless migration to a new CSP while maintain-

ing all existing contacts.

• A cost analysis of a portable cloud migration.

• A migration agent that assists users in migrating

to another CSP.

2 SYSTEM MODEL

A user of a CSP stores all her data at the CSP. Data

at the CSP can be shared with contacts. Contacts are

users of the same or different CSPs. In our system

model, we assume the following entities:

• Cloud Service Provider (CSP): It is responsible

to store the data and run the PortableCloud soft-

ware. The CSP ensures that only authorised par-

ties can access the data. Furthermore, the CSP

manages the communication between users and

their contacts.

• User or Organisation: It is an entity that owns

the data managed by the CSP and regulates ac-

cess to the data by deploying access policies at

the CSP. It is a client of the CSP. In case of an or-

ganisation, there could be an administrator. How-

ever, in case of individuals, we do not distinguish

between an administrator and a user. The user is

responsible for the encryption of the data before

storing it in the cloud.

• Contact: A contact is a party that can access data

at the user’s CSP according to an access policy

deﬁned by the user. Contacts are users of the same

or of a different CSP.

Data at the CSP could be stored in any format.

It could be managed in ﬁles or there could be a

database. We assume that the CSP is honest-but-

curious (De Capitani di Vimercati et al., 2008). This

means the user cannot trust the CSP to provide conﬁ-

dentiality. For this reason, the user encrypts conﬁden-

tial data locally to prevent the CSP to gain cleartext

access to this data. The user encrypts data using a

secure symmetric key encryption algorithm, such as

AES.

To be able to securely communicate with contacts,

each user has a set of key pairs for asymmetric cryp-

tography. These are signing keys and veriﬁcation keys

for digital signatures and public keys and private keys

for public key encryption.

3 PROPOSED ARCHITECTURE

In this section, we provide an overview of the tech-

nical details of PortableCloud. We point out possi-

ble solutions and techniques to implement a portable

cloud.

Figure 1: PortableCloud: A user stores data at the CSP in

an encrypted way. Only authorised contacts get access to

the data at the CSP. The user and her contacts can exchange

commands through their CSPs.

Figure 1 depicts PortableCloud. In PortableCloud,

the core system entities include a CSP, users, their

contacts (and the CSPs of contacts).

3.1 Cloud Service Provider (CSP)

A CSP is responsible to store the data. It also reg-

ulates access to the data if a contact satisﬁes access

policy speciﬁed by the user. The user interacts with

the CSP through a client such as a desktop, a mobile

app or a web page. The CSP mainly consists of three

main components including User Data, Access Man-

ager and Command Dispatcher.

User Data. The user data is the core entity at the

CSP that holds all the data of a single user. It also

contains information the CSP needs to operate, e.g., it

includes the access policy that is deployed to regulate

access to the data. As we describe later, this simpli-

ﬁes the migration process since the user data is largely

decoupled from the CSP. All sensitive elements of the

user data are encrypted using the symmetric key en-

cryption algorithm while each element uses a separate

symmetric key. The user data contains the following

sub-components.

Data Storage. The data storage is a repository to

store the data. Typically, it could be a database, a ﬁle

system or a combination of both. Since the data in

cleartext could compromise privacy of users, data el-

ements (say ﬁles) are encrypted using different sym-

Privacy-preserving Data Sharing in Portable Clouds

275

metric keys. This increases the security since contacts

can only decrypt these entries for which they possess

the corresponding decryption keys.

Meta Data. The meta data consists of structural

information about the data, e.g., directories and ﬁle

names or table and column names of an encrypted

database (Asghar et al., 2013). Furthermore, the meta

data contains integrity and provenance information

for the data stored in the data storage. Entries in the

meta data are encrypted with encryption keys of the

associated data.

Key Store. The key store is used to manage and

store cryptographic keys at the CSP. It is important

to note that all secret cryptographic keys are stored

securely in an encrypted manner. Only the user can

access the key store and get access to the keys using

a password. This prevents the CSP accessing secret

keys (Ferretti et al., 2014). Thus, having access to the

keys in the key store enables the user to decrypt all

user data stored at the CSP.

We consider that keys in the key store are en-

crypted with a symmetric master key. This master

key, which could be realised as a role key, is stored

encrypted as well. The master key can be decrypted

by deriving a user key from the user’s password using

a Key Derivation Function (KDF) (Josefsson, 2011).

This key chain approach is similar to the one used in

the Linux Uniﬁed Key Setup (LUKS)

or for Box-

cryptor

Contacts. This entity contains information about all

contacts known to the user. This information contains

the CSP location of the contacts as well as contacts’

public keys and veriﬁcation keys. Furthermore, each

contact entry contains information to access and de-

crypt shared data that is located at the contact’s CSP.

All the contact information is stored encrypted.

Access Policy. The access policy speciﬁes what con-

tacts are eligible to access data at the user’s CSP. In

this work, we consider that access policies are readily

available in the cleartext to allow the CSP to regu-

late access to the data. Without loss of generality, in

case of sensitive access policies, we could employ en-

crypted policy enforcement mechanisms, such as (As-

ghar, 2013).

Command Queue. The command queue holds

incoming or outgoing commands. Commands are

generic messages that can be used to communicate re-

quests between a user and her contacts. As discussed

in Section 3.3, using commands, users can communi-

cate securely with their contacts.

https://gitlab.com/groups/cryptsetup

https://www.boxcryptor.com

All commands in the incoming command queue

are fetched and handled by the user. Outgoing com-

mands are placed in the outgoing command queue to-

gether with a CSP address of the receiving contact.

The CSP address is stored in cleartext in order to al-

low the CSP to dispatch the command.

Access Manager. The access manager is a sub-

component of the CSP, which ensures that only au-

thorised entities can get access to the data stored at

the CSP. It authenticates users and contacts and pro-

vides access to the requested data, given the deployed

access policies are satisﬁed.

Command Dispatcher. The command dispatcher

is a sub-component of the CSP that dispatches com-

mands from the outgoing command queue and aims

at delivering them to the target CSP. If a command

has been delivered successfully, it is removed from

the queue. Moreover, this sub-component receives in-

coming commands and places them in the incoming

command queue.

3.2 Account Creation

Once a new user signs up, a signature key pair and an

encryption key pair are generated. Both key pairs are

securely stored in the key store. As already explained

in Section 3.1, a key chain is used, which starts from

the user’s password from which the user client derives

the user key. Using this key chain, users can get ac-

cess to the user data.

For authenticating the user to the CSP, we need

to present user credentials. As a possible solution,

we can use another password (different from one al-

ready mentioned above) but it would require the user

to manage two passwords: one for authentication and

another for decrypting the key chain, thus raising us-

ability concern. To avoid this usability issue, we pro-

pose authenticating using the same password but de-

riving an additional authentication key from it. When

signing up, the user chooses a different set of KDF

parameters, i.e., number of iterations and salt, to gen-

erate the authentication key.

3.3 Command Passing

A user needs a way to communicate with contacts at

the same or different CSPs, say to establish a new con-

tact (Section 3.4) or to share data with a contact (Sec-

tion 3.5). In general, a direct peer-to-peer connection

between the user and a contact is not possible, i.e.,

when the contact is ofﬂine. For this reason, the CSP is

used to pass commands between communicating par-

ties.

CLOSER 2016 - 6th International Conference on Cloud Computing and Services Science

276

Figure 2: The user can pass commands to the contact’s CSP.

These commands are handled by fetching them from the

incoming command queue.

To send a command to a contact, the command is

delivered to the contact’s CSP as illustrated in Fig-

ure 2. The contact’s CSP puts the command into

the contact’s incoming command queue. In case

the contact’s CSP is not available, the command is

placed into the user’s outgoing command queue and

the user’s CSP aims at delivering the command at a

later time.

Commands are always signed by the sender and

whenever possible encrypted with the public key of

the receiver, i.e., when the public key has been ex-

changed.

3.4 Contact Establishment

Data can be shared with contacts at the same or a dif-

ferent CSP. To establish a link between a user and an

unknown contact, they have to exchange their veriﬁ-

cation keys and public keys. This key exchange could

take place out-of-band, say using PGP (Garﬁnkel,

1995). Alternatively, we can rely on Public Key In-

frastructure (PKI), where a trust anchor, which is a

root Certiﬁcate Authority (CA), issues X.509 certiﬁ-

cates (Burr et al., 1996).

After a successful contact establishment, both the

user and the new contact create a new contact entry in

their contacts databases containing the contact’s keys

and CSP location. The contact entry contains the con-

tact’s keys as well as the CSP location of the contact.

3.5 Data Access and Sharing

Data Access. The user has full access to the user

data by logging into the CSP using her user name and

password (see Section 3.2). However, the access for

contacts needs to be restricted and is managed using

access tokens. The typical frameworks for access to-

kens include OAuth

, OpenID Connect

, where to-

kens are used to provide access to a service.

Typically, an access token is an identiﬁer that is

presented to a service provider to get access to re-

http://oauth.net

http://openid.net/connect

quested services or resources. In the traditional ac-

cess token model, there is no way to identify the re-

quester. However, we consider special access tokens

that are used to allow contacts access to speciﬁed re-

sources. In the context of portable clouds, access to-

kens consist of two parts: a private signing key and a

public veriﬁcation key. The public part of the token,

i.e., the veriﬁcation key, is stored in the user’s access

policy and is mapped to access rights speciﬁed in an

Access Control List (ACL). As described later, an eli-

gible contact is in possession of the private part of the

token, i.e., the signing key.

A contact can access data by signing an access re-

quest using the private signing key. If the CSP can

verify the access request using the public veriﬁcation

key in the ACL then the requested access is granted to

the contact.

Figure 3: Data sharing between a user and her contacts who

may or may not be at the same CSP.

Data Sharing. A user can share data with contacts

located at the same or at a different CSP (see Fig-

ure 3). To access shared data, a contact needs an ac-

cess token and an encryption key to decrypt the data

(see Figure 4).

Figure 4: A contact can access or modify data at a user’s

CSP. Therefore, the contact needs an access token and an

encryption key.

To share data with a contact, the user has to send

the token as well as the encryption key to the contact.

This is done using a secure command as described in

Section 3.3. Moreover, the access rights in the access

policy have to be updated for the used token.

3.6 Data Integrity and Provenance

An important property of a cloud storage is that users

can ensure the integrity of their data stored at the

CSP (Zhao et al., 2010), i.e., detecting if potential at-

tackers have tampered with the data at the CSP. More-

over, if data is shared with a contact and the contact

writes data to the CSP, i.e., modiﬁes, adds or deletes

Privacy-preserving Data Sharing in Portable Clouds

277

data, the user may want to ensure that the changes

really originate from a certain contact (Asghar et al.,

2012). On the other hand, when the user writes data,

the user may want to certify that changes indeed origi-

nates from the user. This means not only data integrity

but also data provenance is an important property for

a cloud storage.

To be able to verify data integrity and provenance

a user or contact has to provide integrity and prove-

nance information (Hacig

us¸ et al., 2004). This in-

formation is stored in the meta data entity and can be

accessed by users or contacts who can access the as-

sociated data.

4 MIGRATION

The migration process of PortableCloud consists of

two main steps. First, the user data has to be copied to

the new CSP. Second, all contacts need to be notiﬁed

about the new CSP. It is important to ensure that the

migrations should be transparent for the contacts and

there should be a minimal downtime.

Since the user data does not need to be adapted

for the new CSP, the migration can take place through

a direct data transfer between both CSPs. However,

copying a large amount of user data can take a signif-

icant amount of time. For that reason, the data should

be copied gradually. This can be done by ﬁrst copy-

ing a snapshot of the user data and then successively

copy new changes made during the migration. With

the assumption that new changes are small, the time

to synchronise data with the new CSP during the mi-

gration is small.

One problem that can affect the migration is on-

going write or read transactions that are performed by

contacts. A conservative approach is to block new

changes at the old CSP and wait unless all the data

is migrated. Alternatively, we can imagine more so-

phisticated approaches that are able to handle ongoing

changes during and after the migration.

Once all data is copied to the new CSP, the con-

tacts need to be notiﬁed about the migration. This is

done by sending them migration commands that con-

tain the location of the new CSP. A problem that can

occur here is that a contact cannot be reached. One

reason for that could be temporary unavailability of

the contact’s CSP. However, since the migration com-

mand is in the outgoing command queue, the new

CSP will try to deliver the message at a later point.

Another situation when a migration command cannot

be delivered is when the user and a contact both mi-

grate to a new CSP at the same time. In this case, there

is no easy way to determine the CSP location of the

migrating contact. For this reason, the old CSP can

be conﬁgured to point to the new CSP location when

contacts try to communicate with the old CSP. One

possible approach is to introduce one or more central

name servers where users can register their CSP loca-

tion.

If a user receives a migration command from a mi-

grated contact, the new contact’s CSP location has to

be updated in the user’s contacts list. Furthermore,

the user has to verify that undelivered outgoing com-

mands to the migrated contact are updated to target

the contact’s new CSP.

4.1 Migration Costs

For enterprises as well as individuals, the costs and

services of a CSP are important. If a preferable CSP

(say based on various factors such as quality of ser-

vice or costs) is available, the user may consider mi-

grating to this CSP.

Data Sharing Systems. In the following, we discuss

the migration between two different data sharing sys-

tems. It also includes the migration to the portable

cloud architecture. We assume that the user encrypts

data on the client side to prevent the CSP accessing

the data.

One of the major costs includes set up costs, such

as initial set up fees for the new CSP. There are var-

ious sources of costs when transferring data from the

old to the new CSP. First, one or both of the involved

CSPs may have data transfer fees. Second, it might

not be possible to transfer data directly between both

CSPs and the user needs a local data storage to copy

the data. For instance, data formats or databases may

be incompatible, data requires re-encryption, or there

is a lack of APIs to transfer data directly.

Once data is transferred to the new CSP, connec-

tions to old contacts have to be re-established and ac-

cess policies have to be set up. In general, there is no

automatic way to convert the old access policy to a

new system. For this reason, the access policy has to

be veriﬁed manually, which can be an expensive and

erroneous process, e.g., due to human errors crucial

data could accidentally be leaked to wrong contacts.

Portable Clouds. For the migration of the portable

clouds, there may be set up and data transfer costs.

Even the small migration downtime for the portable

clouds could lead to further costs.

PortableCloud minimises the cost described

above. Since data can be transferred directly between

the old and the new CSP, expensive data re-encryption

and round trips to the user’s local storage could be

eliminated. Furthermore, PortableCloud ensures that

CLOSER 2016 - 6th International Conference on Cloud Computing and Services Science

278

contacts can still access the shared data and no new

encryption keys have to be exchanged. This not only

minimises the service downtime but also is fail-safe

against human errors, i.e., the old access policies are

re-used at the new CSP.

The user as well as all contacts do not need to up-

date or reconﬁgure their client software since the mi-

gration process is transparent. This eliminates support

costs and expensive software adoptions.

4.2 Migration Agent

There are various decision making and other tools

that could assist during the migration process (Satzger

et al., 2013; Ward et al., 2010; Khajeh-Hosseini et al.,

2011). Like these tools, we use a migration agent in

PortableCloud. The migration agent calculates costs

based on various parameters of interest, which in-

cludes, but are not limited to, historical growth pat-

tern, manual input or a combination of both. The mi-

gration agent assists users in providing statistics about

data usage, forecasting and listing alternative CSPs

that can offer similar or even better service. If the

agent ﬁnds a better CSP, it suggests it to the user as

a migration option. For that, the cloud agent main-

tains a knowledge base of alternative CPSs in real-

time. This knowledge base is updated regularly by

services that host the migration agent.

A core aspect when considering migration of the

portable clouds is cost. The costs identiﬁed in Sec-

tion 4.1, e.g., initial set up and data transfer costs, are

taken into account. Another interesting parameter is

the migration time. The migration agent can estimate

how long a migration will take, e.g., how much time

the account set up and the data transfer will take. This

helps the user in estimating when the new service of

the CSP is available.

The migration agent also estimates usage patterns

and notiﬁes a user about possible performance prob-

lems and issues. These problems could be a result of

lacking or surplus of data storage, transfer problems

with the users/contacts, or stability and reliability is-

sues with the CSP. For example, if for a certain pe-

riod of time the user consumes less storage space than

she pays for, the migration agent analyses if there are

more suitable (i.e., economical) options available.

The migration agent also considers factors such as

customer satisfaction, reputation or legal issues with

the CSP. However, these factors are subjective and

have to be considered carefully. Furthermore, the mi-

gration agent helps users to ﬁnd better service plans

at the current CSP, if available.

5 DISCUSSION

One goal of PortableCloud is to maintain privacy of

users. In this section, we discuss what information

the CSP can gain about the user and what informa-

tion is concealed from the CSP. Moreover, we discuss

requirements and solutions for an enterprise that uses

the portable clouds.

Privacy. There is some general knowledge a CSP

has about its users. For instance, when registering at

a CSP, information such as the user name and login

name, email address, phone numbers, postal address

or payment details may be revealed to the CSP.

All data the user stores at the CSP is encrypted

and can only be read by the user who has the corre-

sponding key. In PortableCloud, the meta data is also

protected. Thus, the CSP cannot learn any sensitive

user data.

Outgoing commands contain the target CSP in or-

der to deliver a command to a certain contact. This

may reveal the identity of contacts. Although all in-

formation about contacts is stored encrypted, the CSP

can derive information about the number of contacts

of a user. To address this issue, Oblivious RAM

(ORAM) (Stefanov et al., 2013; Goldreich and Ostro-

vsky, 1996) or related techniques may be necessary.

The access policy maps access tokens to an ac-

cess control map, which may reveal information to the

CSP. For example, the CSP can analyse how many ac-

cess tokens exist for a certain data entry and may de-

rive information about the number of contacts or the

importance of the data entry.

Enterprises. In PortableCloud, as described above,

users control their data and manage contacts they

share their data with. However, for commercial enter-

prises, this model might not be an ideal option. In the

following, we describe what requirements an enter-

prise may have concerning portable clouds and how

PortableCloud can be customised to fulﬁl these tai-

lored requirements.

An enterprise usually has a number of employees

and there are certain restrictions on how data can be

shared with internal and external contacts. For this

reason, the enterprise needs a way to manage their

employees. To do so, the enterprise takes the role of

an admin user who can manage a group of users at

the CSP (see Figure 5). The admin user has several

privileges, such as the administration of new users,

i.e., creation and deletion and controlling data access

between users/contacts.

In general, an enterprise can require access to all

data produced by their employees. The enterprise

can require employees to enable their admin access

Privacy-preserving Data Sharing in Portable Clouds

279

Figure 5: An enterprise can administrate and manage mul-

tiple users (e.g., its employees). The enterprise may have

special access rights to its employees’ data and key stores.

to their secret key. This would also allow the admin

to reset their secret keys. Since employees only use

their own personal password to encrypt their secret

key (see Section 3.1), the personal password is not re-

vealed to the employer. This is important in case the

employee uses this password also for other purposes.

6 RELATED WORK

The difﬁcult task of migrating a system to the cloud

has the advantage of being scalable while having a

low maintenance and ﬂexible pricing options (Zhao

and Zhou, 2014). Migrating a local service to the

cloud can reduce cost to run and maintain servers

but can also increased the dependency on external

third parties and a deterioration of the service qual-

ity because of less control over the system (Khajeh-

Hosseini et al., 2011).

For enterprises, it is not easy to decide if a mi-

gration from their IT system to the cloud is beneﬁ-

cial. Cloud Genius assists users in ﬁnding an op-

timal CSP that provides IaaS, i.e., it ﬁnds the IaaS

that is able to run a certain VM image at better ser-

vice conditions (Menzel and Ranjan, 2012). The

problem of vendor lock-in can be addressed by using

uniﬁed programming APIs and domain-speciﬁc lan-

guages to model application components and cloud

requirements (Satzger et al., 2013). In a so called

meta cloud, an agent continuously checks for alter-

native CSPs with better conditions for the speciﬁed

requirements (Satzger et al., 2013).

One way to share data is to use a distributed peer-

to-peer data sharing system such as PeerDB (Ng et al.,

2003). However, data in PeerDB is not encrypted.

Moreover, for sharing data, both peers are expected

to be online.

Various security and privacy issues in cloud com-

puting have been identiﬁed (Takabi et al., 2010). One

way of dealing with privacy issues is to keep users

anonymous while storing the user’s data in cleartext

in the cloud (Khan and Hamlen, 2012). K2C allows

users to share encrypted data with other users but

users have to manage their encryption keys in a local

key store (Zarandioon et al., 2012). A more conve-

nient approach is to store the encryption keys in an

encrypted key store in the cloud (Ferretti et al., 2014).

Even when data is encrypted, it is possible to perform

a search query on the encrypted data while respecting

multi-user access policies (Asghar et al., 2013).

The cloud storage system DepSky (Bessani et al.,

2011) stores encrypted and signed data at multiple

CSPs. DepSky uses a secret sharing scheme (Butoi

and Tomai, 2014), which means that shares of the se-

cret key are distributed on different CSPs. While Dep-

Sky allows users to replicate data at different CSPs, it

does not offer any contact management.

There are various popular cloud sharing systems

available. The cloud software ownCloud

allows

users to setup a personal cloud server. Data sharing

platforms, such Boxcryptor

, support the client side

encryption. However, these services neither support

migration to another CSP nor do they allow private

data sharing with users of other CSPs.

Mona allows users to share data with contacts and

revoke access if necessary (Liu et al., 2013). While

the identity of contacts is concealed from the CSP,

the user knows about the provenance of the data.

To deﬁne an access policy, a simple Role-Based Ac-

cess Control (RBAC) mechanism can be used. Here,

roles can be granted and revoked if necessary (Sandhu

et al., 1996). Moreover, hierarchical attribute-based

encryption can be used to control and revoke data ac-

cess (Wang et al., 2011).

7 CONCLUSIONS AND FUTURE

WORK

In this paper, we addressed the problem of vendor

lock-in, which makes it difﬁcult for cloud users to

migrate to an alternative CSP because data cannot

easily be transferred to a new CSP and data shared

with contacts at the old CSP may become inaccessi-

ble after the migration. To ﬁll the gap, we presented

PortableCloud, an architecture that makes it possible

to migrate a data sharing system to a new CSP. In

PortableCloud, users can share data with contacts lo-

cated at the same or at different CSPs. PortableCloud

provides mechanisms to store data in an encrypted

manner.

We discussed the cost of migrating a portable

https://owncloud.com/

https://www.boxcryptor.com

CLOSER 2016 - 6th International Conference on Cloud Computing and Services Science

280

cloud and various aspects necessary for designing

PortableCloud. We described a migration agent that

assists users in automatically ﬁnding a suitable CSP

that could satisfy their needs.

As future work, we plan to complete the imple-

mentation of PortableCloud. We believe that an anal-

ysis of the migration performance will conﬁrm the

feasibility of proposed portable clouds. Furthermore,

investigating accountability aspects of portable clouds

would be an interesting research direction.

REFERENCES

Armbrust, M., Fox, A., Grifﬁth, R., Joseph, A. D., Katz,

R., Konwinski, A., Lee, G., Patterson, D., Rabkin, A.,

Stoica, I., and Zaharia, M. (2010). A view of cloud

computing. Commun. ACM, 53(4):50–58.

Asghar, M. R. (2013). Privacy Preserving Enforcement of

Sensitive Policies in Outsourced and Distributed En-

vironments. PhD thesis, University of Trento.

Asghar, M. R., Ion, M., Russello, G., and Crispo, B. (2012).

Securing data provenance in the cloud. In Open Prob-

lems in Network Security, volume 7039 of Lecture

Notes in CS, pages 145–160.

Asghar, M. R., Russello, G., Crispo, B., and Ion, M. (2013).

Supporting complex queries and access policies for

multi-user encrypted databases. CCSW ’13, pages

77–88.

Bessani, A., Correia, M., Quaresma, B., Andr

e, F., and

Sousa, P. (2011). Depsky: Dependable and secure

storage in a cloud-of-clouds. EuroSys ’11, pages 31–

46.

Burr, W. E., Nazario, N. A., and Polk, W. T. (1996). A pro-

posed federal PKI using X.509 v3 certiﬁcates. NIST.

Butoi, A. and Tomai, N. (2014). Secret sharing scheme

for data conﬁdentiality preserving in a public-private

hybrid cloud storage approach. UCC’14, pages 992–

997.

De Capitani di Vimercati, S., Foresti, S., Jajodia, S., Para-

boschi, S., Pelosi, G., and Samarati, P. (2008). Pre-

serving conﬁdentiality of security policies in data out-

sourcing. WPES ’08, pages 75–84.

De Chaves, S., Uriarte, R., and Westphall, C. (2011). To-

ward an architecture for monitoring private clouds.

Communications Magazine, IEEE, 49(12):130–137.

Ferretti, L., Colajanni, M., and Marchetti, M. (2014). Dis-

tributed, concurrent, and independent access to en-

crypted cloud databases. Parallel and Distributed Sys-

tems, 25(2):437–446.

Garﬁnkel, S. (1995). PGP: pretty good privacy.

Goldreich, O. and Ostrovsky, R. (1996). Software pro-

tection and simulation on oblivious RAMs. J. ACM,

43(3):431–473.

Hacig

us¸, H., Iyer, B., and Mehrotra, S. (2004). Ensuring

the integrity of encrypted databases in the database-

as-a-service model. In Data and Applications Security

17, volume 142, pages 61–74.

Joint, A., Baker, E., and Eccles, E. (2009). Hey, you, get

off of that cloud? Computer Law & Security Review,

25(3):270 – 274.

Josefsson, S. (2011). PKCS# 5: Password-Based Key

Derivation Function 2 (PBKDF2) test vectors. Tech-

nical report.

Khajeh-Hosseini, A., Sommerville, I., Bogaerts, J., and

Teregowda, P. (2011). Decision support tools for

cloud migration in the enterprise. In Cloud Computing

(CLOUD), pages 541–548.

Khan, S. and Hamlen, K. (2012). Anonymouscloud: A data

ownership privacy provider framework in cloud com-

puting. In Trust, Security and Privacy in Computing

and Communications (TrustCom), pages 170–176.

Liu, X., Zhang, Y., Wang, B., and Yan, J. (2013). Mona:

Secure multi-owner data sharing for dynamic groups

in the cloud. Parallel and Distributed Systems,

24(6):1182–1191.

Menzel, M. and Ranjan, R. (2012). CloudGenius: Decision

support for web server cloud migration. WWW ’12,

pages 979–988.

Ng, W. S., Ooi, B. C., Tan, K.-L., and Zhou, A. (2003).

PeerDB: A P2P-based system for distributed data

sharing. In Data Engineering, pages 633–644.

Sandhu, R. S., Coyne, E. J., Feinstein, H. L., and Youman,

C. E. (1996). Role-based access control models. Com-

puter, 29(2):38–47.

Satzger, B., Hummer, W., Inzinger, C., Leitner, P., and

Dustdar, S. (2013). Winds of change: From vendor

lock-in to the meta cloud. IEEE Internet Computing,

17(1):69–73.

Stefanov, E., van Dijk, M., Shi, E., Fletcher, C., Ren, L.,

Yu, X., and Devadas, S. (2013). Path ORAM: An

extremely simple oblivious ram protocol. CCS ’13,

pages 299–310.

Takabi, H., Joshi, J. B., and Ahn, G.-J. (2010). Security and

privacy challenges in cloud computing environments.

Security & Privacy, 8(6):24–31.

Wang, G., Liu, Q., Wu, J., and Guo, M. (2011). Hierarchi-

cal attribute-based encryption and scalable user revo-

cation for sharing data in cloud servers. Computers &

Security, 30(5):320 – 331.

Ward, C., Aravamudan, N., Bhattacharya, K., Cheng, K.,

Filepp, R., Kearney, R., Peterson, B., Shwartz, L., and

Young, C. (2010). Workload migration into clouds

challenges, experiences, opportunities. In Cloud Com-

puting (CLOUD), pages 164–171.

Zarandioon, S., Yao, D., and Ganapathy, V. (2012). K2C:

Cryptographic cloud storage with lazy revocation and

anonymous access. In Security and Privacy in Com-

munication Networks, volume 96, pages 59–76.

Zhao, G., Rong, C., Li, J., Zhang, F., and Tang, Y. (2010).

Trusted data sharing over untrusted cloud storage

providers. In Cloud Computing Technology and Sci-

ence (CloudCom), pages 97–103.

Zhao, J.-F. and Zhou, J.-T. (2014). Strategies and methods

for cloud migration. International Journal of Automa-

tion and Computing, 11(2):143–152.

Privacy-preserving Data Sharing in Portable Clouds

281
