Source and Test Code Size Prediction

A Comparison between Use Case Metrics and Objective Class Points

Mourad Badri, Linda Badri and William Flageol

Software Engineering Research Laboratory, Department of Mathematics and Computer Science, University of Quebec,

Trois-Rivières, Quebec, Canada

Keywords: Use Cases, Use Case Metrics, Class Diagrams, Objective Class Points, Source Code Size, Test Code Size,

Prediction Models, Linear Regression.

Abstract: Source code size, in terms of SLOC (Source Lines of Code), is an important parameter of many parametric

software development effort estimation methods. Moreover, test code size, in terms of TLOC (Test Lines of

Code), has been used in many studies to indicate the effort involved in testing. This paper aims at

comparing empirically the Use Case Metrics (UCM) method, a use case model based method that we

proposed in previous work, and the Objective Class Points (OCP) method in terms of early prediction of

SLOC and TLOC for object-oriented software. We used both simple and multiple linear regression methods

to build the prediction models. An empirical comparison, using data collected from four open source Java

projects, is reported in the paper. Overall, results provide evidence that the multiple linear regression model,

based on the combination of the use case metrics, is more accurate in terms of early prediction of SLOC and

TLOC than: (1) the simple linear regression models based on each use case metric, and (2) the simple linear

regression model based on the OCP method.

1 INTRODUCTION

Software development is a time and resource

consuming process. Furthermore, software testing,

which plays a crucial role in software quality

assurance, takes an important part of the software

development effort. It is, therefore, important to

estimate as soon as possible, ideally in the early

stages of the software development lifecycle, the

effort required to develop and test software. In this

way, activities can be planned and resources can be

optimally allocated in order to ensure a successful

software development (and testing) management.

Many software development effort estimation

methods have been proposed in the literature over

the years (Albrecht, 1979; Albrecht and Gaffney,

1983; Antoniol et al., 1999; Antoniol et al., 2003;

Bianco and Lavazza, 2006a; Bianco and Lavazza,

2006b; Boehm, 1981; Boehm et al., 2000a; Boehm

et al., 2000b; Bourque and Côté, 1991; Carbone and

Santucci, 2002; Carroll, 2005; Chen et al., 2004;

Hastings and Sajeev, 2001; Henderson-Sellers,

1997; Jahan and Sheibani, 2005; Janaki and Raju,

2000; Jorgensen and Boehm, 2009; Jorgensen and

Shepperd, 2007; Kemerer, 1987; Lagerstrom et al.,

2012; Kim et al., 2006; Leung and Fan, 2002;

Matson et al., 1994; McDonnel, 2003; Mishra et

al., 2010; Ochodek et al., 2011; Pfleeger et al.,

2005; Trendowicz et al., 2008; Verner and Tate,

2012; Zhao and Tan, 2003; Zhou et al., 2014).

Source code size, in terms of SLOC (Source Lines

of Code), is an important parameter of many

parametric software development effort estimation

methods. The testing effort is unfortunately often

estimated as a part of the overall software

development effort. However, test code size, in

terms of TLOC (Test Lines of Code), has been used

in many studies to indicate the effort involved in

unit testing (Badri and Toure, 2012; Bruntik and

Van Deursen, 2004; Bruntik and Van Deursen,

2006; Singh et al., 2008; Singh and Saha, 2010;

Zhou et al., 2012).

In this paper, we focus on the early prediction of

both SLOC and TLOC for object-oriented (OO)

software development, which is used extensively in

the industrial projects. The study aims basically at

comparing empirically the Use Case Metrics

(UCM) method, which is a use case model based

prediction method that we proposed in a previous

work (Badri et al., 2013), and the Objective Class

172

Badri, M., Badri, L. and Flageol, W.

Source and Test Code Size Prediction - A Comparison between Use Case Metrics and Objective Class Points.

In Proceedings of the 11th International Conference on Evaluation of Novel Software Approaches to Software Engineering (ENASE 2016), pages 172-180

ISBN: 978-989-758-189-2

Points (OCP) method (Kim et al., 2005) in terms of

early prediction of SLOC and TLOC. The UCM

method has already been compared in (Badri et al.,

2015) to the Use Case Points (UCP) method, which

is also a use case model based estimation method.

Results show that the UCM method is more

accurate, in terms of predicting test suites size, than

the UCP method. In this work, we wanted to

compare the UCM method to a class diagram based

method. We used both simple and multiple linear

regression methods to build the prediction models.

An empirical comparison, using data collected from

four open source Java projects, is reported in the

paper. Overall, results provide evidence that the

multiple linear regression model, based on the

combination of the use case metrics, is more

accurate in terms of early prediction of SLOC and

TLOC than: (1) the simple linear regression models

based on each use case metric, and (2) the simple

linear regression model based on the OCP metric.

The rest of this paper is organized as follows:

Section 2 presents summarily the Objective Class

Points method. The use case metrics are introduced

in Section 3. Section 4 presents the different steps

of the empirical study we conducted to evaluate

comparatively the Use Case Metrics and the

Objective Class Points approaches in terms of

SLOC and TLOC prediction accuracy. Finally,

Section 5 concludes the paper and outlines some

future work directions.

2 OBJECTIVE CLASS POINTS

METHOD

The Objective Class Points (OCP) method counts

the number of class points in a UML class diagram

(Kim et al., 2005). The OCP method, unlike other

class points based approaches such as (Costagliola

et al., 2005; Abrahao et al., 2006), does not involve

any subjective factors (Zhou et al., 2014). For a

class diagram, the OCP value is computed as

follows (Kim et al., 2005; Zhou et al., 2014):

OCP = NC + NGen + NDep + NORR + NM + NA

+ NAssoc + NAgg + NComp

where: NC: the total number of classes, NGen: the

total number of generalization relationships, NDep:

the total number of dependency relationships,

NORR: the total number of realization

relationships, NM: the total number of methods,

NA: the total number of attributes, NAssoc: the

total number of association relationships, NAgg: the

total number of aggregation relationships, and

NComp: the total number of composition

relationships.

3 USE CASE METRICS

A use case model defines the functional scope of

the system to be developed (Jacobson et al., 1993;

Larman, 2004). A use case is a collection of related

success and failure scenarios that describe actors

using a system to support a goal. Use cases describe

how external actors interact with the software

system. These interactions generate events to the

software system, known as input system events,

which are usually associated with system

operations. A scenario, also called a use case

instance, is a specific sequence of actions and

interactions between actors and the system. It is one

particular story of using the system, or one path

through the use case. We present, in what follows,

the use case metrics that we used in our study,

metrics that we introduced in previous work (Badri

et al., 2013; Badri et al., 2015)

, to quantify different

characteristics related to size and complexity of use

cases:

Number of Involved Classes (NIC): This metric

defines the total number of analysis classes

participating in a use case, which have been

identified during the analysis phase.

Number of External Operations (NEO): This metric

defines the total number of system operations

associated with the system events related to a use

case. These operations are easily identifiable from

UML system sequence diagrams.

Number of Scenarios (NS): This metric gives the

total number of the different scenarios of a use case.

One use case can, in fact, have one or more

scenarios. This metric is related to the cyclomatic

complexity of the use case.

Number of Transactions (NT): This metric gives the

total number of transactions of a use case. A

transaction is an event (a set of activities in a use

case scenario) that occurs between an actor and the

target system, the event being performed entirely or

not at all. The complexity of a use case is also

determined by the number of transactions.

Source and Test Code Size Prediction - A Comparison between Use Case Metrics and Objective Class Points

173

4 EMPIRICAL STUDY

4.1 Goals, Selected Projects and Data

Collection

The study aims at comparing empirically the Use

Case Metrics and the Objective Class Points

approaches in terms of predicting both source code

size (SLOC) and test code size (TLOC). For a use

case (noted UC

), to indicate: (1) the size of

corresponding source code, we used the SLOC

metric, and (2) the size of corresponding test code,

we used the TLOC metric. The SLOC and TLOC

metrics are defined as follows:

Source Lines Of Code (SLOC): This metric defines

the cumulative number of lines of source code

related to a use case (all of its scenarios). It is used

to indicate the total size, in terms of lines of source

code, of the parts of software corresponding to a use

case.

Test Lines Of Code (TLOC): This metric defines the

cumulative number of lines of code of the JUnit test

cases related to a use case (all of its scenarios). This

number includes only the test cases related to

classes/methods involved in the realization of the

use case.

We conducted an experimental study using data

collected from four open source Java projects. The

selected case studies are from different domains and

developed by different teams. Moreover, knowing

that the OCP method is applied on UML class

diagrams, we deliberately chose case studies that

have been developed using (strictly) the object

paradigm (in order to avoid biasing the OCP

results). The use case models have been collected

for each project by reverse engineering the source

code. The goal was, because the use case models

were not available, to produce (or reproduce) these

models (and particularly the system sequence

diagrams) as accurately as possible (without

alteration) from code analysis. In fact, we have used

the source code of the projects as well as the

available documentation (particularly the detailed

user guides).

Moreover, as the OCP method requires metrics

that are computed from the class diagram, we also

reverse engineered the source code of the selected

systems to obtain class diagrams. In order to

compare the two methods on the same basis, and

knowing that the use case metrics are computed for

each use case, we considered for the calculation of

the OCP values all the classes (and methods)

required for the implementation of the use case. So,

for the calculation of the OCP values, we

considered for each use case the corresponding part

of the class diagram. Moreover, for the two first

case studies, we developed the corresponding JUnit

test cases. For the two other case studies, we used

the JUnit test cases that were available on their

respective web sites. For each system, we related to

each use case the corresponding source code and

JUnit test cases. For each use case, we calculated

the values of the use case metrics and the global

value of the OCP method. We also used the metric

SLOC to quantify the source code corresponding to

each use case, and the metric TLOC to quantify the

JUnit test cases corresponding to each use case. In

order to compare empirically the two methods, in

terms of predicting SLOC and TLOC, we used both

simple and multiple linear regression methods to

build the prediction models.

Table 1: Descriptive statistics.

Variables Obs Min Max Mean SD

NIC

33 1,000 15,000 4,424 3,307

NEO

33 1,000 36,000 3,333 6,352

33 1,000 32,000 3,455 5,391

33 1,000 67,000 5,818 11,359

OCP

33 2,000 134,000 21,485 23,630

SLOC

33 4,000 399,000 66,061 76,652

TLOC

33 11,000 777,000 130,818 206,393

The selected projects are: ATM, NextGen,

CommonsEmail and JODA-Time. The first case

study ATM

is a simulator system allowing

performing basic banking operations (withdrawal,

deposit, transfer, balance, etc.). We adapted the case

study for our purposes. The second case study

NextGen is an extension of the application

developed by Larman in (Larman, 2004). The

original application has been extended for our

purposes by adding features about accounts

receivable management, suppliers, and employees.

We also added features to support billing and rental

payments by debit and credit. The third case study

Commons Email

aims to provide an API for

sending email. It is built on top of the Java Mail

API, which it aims to simplify. The fourth case

study JODA-Time

is the de facto standard library

for advanced date and time in Java. It provides a

quality replacement for the Java date and time

http://www.math-cs.gordon.edu/courses/cs211/ATMExample/

https://commons.apache.org/proper/commons-email/

http://www.joda.org/joda-time/

ENASE 2016 - 11th International Conference on Evaluation of Novel Software Approaches to Software Engineering

174

classes. Because the main data set was

heterogeneous, and in order to have a significant

sample of data, we decided to perform our study on

the whole data set obtained by grouping the use

cases of the four case studies. We have then a total

of 33 use cases. Table 1 lists the descriptive

statistics for the use case metrics, the global value

of OCP and the size metrics SLOC and TLOC.

4.2 Correlation Analysis

In order to investigate the relationships between use

case metrics (noted UCM

), including the OCP

global value, and the size metrics SLOC and TLOC,

we performed statistical tests using correlation. The

null and alternative hypotheses that our study has

tested were:

H0: There is no significant correlation between a

use case metric UCM

(OCP) and SLOC (TLOC).

H1: There is a significant correlation between a use

case metric UCM

(OCP) and SLOC (TLOC).

For the analysis of the collected data, and in

order to test the correlation between a use case

metric (and OCP) and SLOC (TLOC), we used two

correlation analysis techniques: Pearson and

Spearman techniques. We used these techniques

mainly for completeness. The Pearson r correlation

is widely used in statistics to measure the degree of

the relationship between linear related variables.

The variables should be normally distributed. The

Spearman rank correlation is a non-parametric test

that is used to measure the degree of association

between two variables. Spearman rank correlation

test does not assume anything about the distribution

of the variables.

Correlation is a bivariate analysis that measures

the strengths of association between two variables.

In statistics, the value of the correlation coefficient

varies between +1 and -1. A positive correlation is

one in which the variables increase together. A

negative correlation is one in which one variable

increases as the other variable decreases. A

correlation of +1 or -1 will arise if the relationship

between the variables is exactly linear. A

correlation close to zero means that there is no

linear relationship between the variables.

We used the XLSTAT

tool to measure the two

types of correlations. We applied the typical

significance threshold (alpha = 0.05) to decide

whether the correlations where significant. For each

pair < UCM

, SLOC (TLOC)>, we analyzed the

http://www.xlstat.com/

Table 2: Pearson’s correlation values between the use

case metrics (and OCP) and SLOC (and TLOC).

Variables NIC NEO NS NT OCP SLOC TLOC

NIC 1 0,494 0,650 0,583 0,815 0,668

0,170

NEO 0,494 1 0,872 0,972 0,824 0,772 0,790

NS 0,650 0,872 1 0,962 0,907

0,850 0,528

NT 0,583 0,972 0,962 1 0,893

0,841 0,695

OCP 0,815 0,824 0,907 0,893 1

0,937 0,577

Table 3: Spearman’s correlation values between the use

case metrics (and OCP) and SLOC (and TLOC).

Variables NIC NEO NS NT OCP SLOC TLOC

NIC 1

0,324

0,512 0,402 0,794 0,673

0,190

NEO

0,324

0,243

0,759 0,477 0,582 0,365

NS 0,512

0,243

1 0,705 0,686

0,757 0,385

NT 0,402 0,759 0,705 1 0,703

0,820 0,612

OCP 0,794 0,477 0,686 0,703 1

0,923 0,497

collected data set by calculating the (Pearson’s and

Spearman’s) correlation coefficients. Table 2 and

Table 3 summarize the results (respectively

Pearson’s and Spearman’s correlation coefficients).

The correlation coefficients that are significant

(alpha = 0.05) are set in boldface in the two tables.

The first global observation that we can make

from Table 2 and Table 3 is that there is a

significant relationship (the correlation values are in

bold face) between all the use case metrics,

including the OCP global value, and the size

metrics SLOC and TLOC, except for the pair (NIC,

TLOC) in the case of the two techniques. According

to the obtained results, we can therefore reasonably

reject the null hypothesis H0. The other global

observations that we can make from these tables are

that:

- According to the Pearson technique, the use case

metrics (including OCP) that are the most

correlated to SLOC are respectively OCP (0.937),

NS (0.850) and NT (0.841), and the use case

metrics (including OCP) that are the most

correlated to TLOC are respectively NEO (0.790),

NT (0.695), which are both much better correlated

to TLOC than the OCP metric (0.577).

- According to the Spearman technique, the use case

metrics (including the OCP value) that are the

most correlated to SLOC are respectively OCP

(0.923), NT (0.820) and NS (0.757), and the use

case metric that is the most correlated to TLOC is

NT (0.612), which is much better correlated to

TLOC than the OCP metric (0.497).

We can also see from Table 2 and Table 3 that

Source and Test Code Size Prediction - A Comparison between Use Case Metrics and Objective Class Points

175

the correlation measures are positive. This means

that one variable (a use case metric (OCP))

increases as the other variable (SLOC, TLOC)

increases. Overall, results suggest that the use case

metrics (and OCP) can be used to predict SLOC

(TLOC). This must, however, be validated.

4.3 Source and Test Code Size

Prediction

We present, in this section, the different steps of the

empirical study we conducted in order to compare

the two approaches, UCM and OCP, in terms of

predicting SLOC and TLOC. The goal here is to

evaluate how accurately the two methods predict

the size metrics SLOC and TLOC. We used

different modeling techniques to build the

prediction models: (1) we used the simple linear

regression method to evaluate the individual effect

of each use case metric (and OCP) on the size

metrics SLOC and TLOC, identifying which

metrics are significantly related to SLOC and

TLOC, and (2) we used the multiple linear

regression method to explore the combined effect of

the use case metrics on SLOC and TLOC,

investigating if the combination of the use case

metrics will improve the accuracy of the prediction

of the size metrics SLOC and TLOC.

Linear regression is a commonly used statistical

technique that is widely used to model (linearly

approximate) the relationship between a dependent

variable y and one or more explanatory variables

denoted X. Linear regression analysis is of two

types: The case of one explanatory variable is called

simple linear regression (SLR). For more than one

explanatory variable, it is called multiple linear

regression (MLR). The simple linear regression

analysis is based on the equation:

Y = β

+ β

X, (1)

where Y is the dependent variable (SLOC or

TLOC) and X is the independent variable (use case

metric or OCP). The multiple linear regression

analysis is based on the equation:

Y = β

+ β

+…+ β

, (2)

where Y is the dependent variable (SLOC or

TLOC) and the X

are the independent variables

(use case metrics).

4.3.1 Hypotheses

The study tested various hypotheses, which relate

the use case metrics (including OCP) to SLOC

(TLOC). For each use case metric UCM

The null hypothesis was: A use case with a high

UCM

(OCP) value is no more likely to have a high

value of SLOC (TLOC) than a use case with a low

UCM

(OCP) value.

The hypothesis was: A use case with a high UCM

(OCP) value is more likely to have a high value of

SLOC (TLOC) than a use case with a low UCM

(OCP) value.

4.3.2 Simple Linear Regression Analysis

In the SLR analysis, and therefore in each SLR

model, we considered only one predictor variable.

The SLR models for predicting SLOC (and TLOC)

based on the value of a use case metric (or OCP)

have the form of the equation (1) presented in the

introduction of section 4.3. We used the XLSTAT

tool to perform the simple linear regression analysis

and derive the simple linear regression models.

Table 4 summarizes the results of the SLR

analysis for predicting SLOC. From Table 4, it can

be seen that all the SLR models are significant

(according to the corresponding p-value). The

performances of the models vary, however, from

one model to the other. From Table 4, we can see

that the SLR model based on the metric OCP is the

most accurate in terms of SLOC prediction (the

corresponding R

value is 87.9%), followed by the

SLR model based on the metric NS (the

corresponding R

value is 72.3%), and in a third

position the SLR model based on the metric NT (the

corresponding R

value is 70.7%).

Table 5 summarizes the results of the SLR

analysis for predicting TLOC. From Table 5, it can

be seen that all the SLR models are here also

significant (according to the corresponding p-

value), except the one based on the use case metric

NIC. The performances of the models vary here

also from one model to the other. From Table 5, we

can see that the SLR model based on the metric

NEO is the most accurate in terms of TLOC

prediction (the corresponding R

value is 62.4%),

followed by the SLR model based on the metric NT

(the corresponding R

value is 48.3%), and in a

Table 4: SLR analysis – Predicting SLOC - Results.

NIC NEO NS NT OCP

44.6% 59.7% 72.3% 70.7% 87.9%

0.668 0.772 0.850 0.841 0.937

p-value

< 0.0001 <0.0001 <0.0001 < 0.0001 < 0.0001

ENASE 2016 - 11th International Conference on Evaluation of Novel Software Approaches to Software Engineering

176

third position the SLR model based on the metric

OCP (the corresponding R

value is 33.3%)

Table 5: SLR analysis – Predicting TLOC - Results.

NIC NEO NS NT OCP

2.9% 62.4% 27.8% 48.3% 33.3%

0.170 0.790 0.528 0.695 0.577

p-value

0.343 <0.0001 0.002 < 0.0001 0.000

4.3.3 Multiple Linear Regression Analysis

The main purpose of the MLR analysis here is to

explore the potential of the combined effect of the

use case metrics (as predictor variables) on the size

metrics SLOC and TLOC (as dependent variables).

The question here is whether the combination of the

use case metrics will improve the accuracy of

SLOC (TLOC) prediction. The MLR model for

predicting SLOC (TLOC) based on the values of

the use case metrics has the form of the equation (2)

presented in the introduction of section 4.3. We

used the XLSTAT tool to perform the multiple

linear regression analysis and derive the multiple

linear regression model based on the combination of

the use case metrics.

Table 6 gives the results of the MLR analysis

for the prediction of SLOC. From Table 6, it can be

seen that the MLR model based on the use case

metrics is significant (according to the

corresponding p-value). From Table 6 and Table 4,

we can see that the MLR model is most accurate in

terms of SLOC prediction (the corresponding R

value is 93.6%) than all the SLR models based on

each use case metric, including the one based on the

OCP metric. So, it is clear that, when the use case

metrics are combined, the prediction quality visibly

increased.

Table 7 gives the results of the MLR analysis

for the prediction of TLOC. From Table 7, it can be

seen that here also the MLR model based on the use

case metrics is significant (according to the

corresponding p-value). From Table 7 and Table 5,

we can see that here also the MLR model based on

the use case metrics is most accurate in terms of

TLOC prediction (the corresponding R

value is

81.0%) than all the SLR models based on each use

case metric, including the one based on the OCP

metric. So, it is clear here also that, when the use

Table 6: MLR analysis – Predicting SLOC - Results.

NIC

NEO

93.6%

-value

< 0.0001

case metrics are combined, the prediction quality

visibly increased.

Table 7: MLR analysis – Predicting TLOC - Results.

NIC

NEO

81.0%

-value

< 0.0001

4.4 Threats to Validity

The study presented in this paper should be

replicated using many other OO software systems in

order to draw more general conclusions. Indeed,

there are a number of limitations that may affect the

results of the study or limit their interpretation and

generalization.

The achieved results are based on the data set

we collected from only four open source Java

projects. To perform our study, we grouped the use

cases of the four case studies to build our data set.

Even if the collected data set is statistically

significant, we do not claim that our results can be

generalized.

The use case models and class diagrams have

been collected by reverse engineering the source

code of the applications. In fact, we have used the

source code of the projects as well as the available

documentation (particularly the detailed user

guides). By analyzing both source code and the

documentation of the projects, we were able to

reproduce the models (particularly the use case

models) needed for our study. The collection of the

models has been performed by the same person

(third author of the paper). To reduce the effect of

this threat, results were discussed, checked and

validated by all the authors.

The complexity of use cases is determined in

part by the number of transactions. The simplest

way to count the number of transactions was to

count the number of events included in the flow of

events. The number of events may be affected by

the style adopted (by developers during the analysis

phase) in the design of use cases (use case model).

So, it is important to clarify that a key prerequisite

to applying the proposed approach (this is also valid

for the other use cases based prediction methods) is

that use cases of the target system have been

identified (structured and documented) at a suitable

level of detail, where each transaction is specified.

Furthermore, the MLR analysis has been

performed using all the use case metrics. The goal

was especially to explore (in comparison to the SLR

models, particularly the one based on the OCP

metric) the combined effect of the use case metrics

Source and Test Code Size Prediction - A Comparison between Use Case Metrics and Objective Class Points

177

on the size metrics. The fact that the use case

metrics (according to the data collected) are in some

cases highly correlated (correlation analysis)

suggest that there is a redundancy in the

information captured by the use case metrics

(multicollinearity between the use case metrics as

predictor variables), which may lead to an over

fitting of the multiple regression model. The

simplest way to resolve this problem is to reduce

the number of use case metrics (collinear predictor

variables) to a subset of independent predictor

variables. In fact, the goal here was not to build the

best multiple regression model based on a subset of

independent use case metrics. So, the findings in

this paper should be viewed as exploratory and

indicative rather than conclusive. Results show at

least that use case metrics offer a potential and

simple way that can be used in early stages of the

software development lifecycle to predict the source

code and test code size. Moreover, the study has

been performed on simple case studies. It is

necessary to replicate the study on large systems.

5 CONCLUSIONS AND FUTURE

WORK

In this paper, we focused on the early prediction of

both SLOC and TLOC for OO software

development. The study aimed basically at

comparing empirically the Use Case Metrics

(UCM) method, which is a use case model based

prediction method that we proposed in previous

work, and the Objective Class Points (OCP) method

in terms of early prediction of SLOC and TLOC.

We used both simple and multiple linear regression

methods to build the prediction models. We

conducted an empirical comparison using data

collected from four open source Java projects.

In a first step, we investigated the relationships

between use case metrics (including OCP) and size

metrics SLOC and TLOC. The goal here was to

evaluate the capacity of use case metrics (and OCP)

to predict SLOC and TLOC. In a second step, we

used the simple linear regression method to evaluate

the individual effect of each use case metric

(including OCP) on SLOC (TLOC), and the

multiple linear regression method to explore the

combined effect of use case metrics on SLOC

(TLOC).

In order to assess the relationships between the

use case metrics, including the OCP global value,

and SLOC (TLOC), we performed statistical tests

using correlation. We used two correlation analysis

techniques: Pearson and Spearman techniques. We

observed a significant and (in some cases) a high

correlation between the use case metrics (and OCP)

and SLOC (TLOC). These correlations suggest that

use case metrics (and OCP) can be used to predict

the final source code (test code) size.

We also derived several simple linear regression

models to relate SLOC (TLOC) to the use case

metrics (and OCP), and a multiple linear regression

model based on the use case metrics to predict

SLOC (TLOC). Overall, results provide evidence

that the multiple linear regression model, based on

the combination of the use case metrics, is more

accurate in terms of early prediction of SLOC and

TLOC than: (1) the simple linear regression models

based on each use case metric, and (2) the simple

linear regression model based on the OCP metric.

The combination of the use case metrics highly

increased the accuracy of SLOC (TLOC)

prediction. The main limitations of the observations

made in this study are basically related to the small

size (and number) of the considered set of projects.

The performed study should be replicated using

many other OO software systems in order to draw

more general conclusions. The findings in this

paper should be viewed, in fact, as exploratory and

indicative rather than conclusive. As future work,

we plan to extend the present study by using other

methods (machine learning methods particularly) to

explore the individual and combined effect of the

use case metrics on the source code (test code) size

(and software development effort), compare our

approach to other development effort prediction

approaches, and finally replicate the study on

various OO software systems to be able to give

generalized results.

ACKNOWLEDGMENTS

This work was (partially) supported by NSERC

(Natural Sciences and Engineering Research

Council of Canada) grant.

REFERENCES

Abrahao, S., Poels, G., Pastor, O.: A Function Size

Measurement Method for Object-Oriented

Conceptual Schemas: Design and Evaluation Issues,

Software and System Modeling, 5(1), 2006. lokan,

c.j.: Function Points, Advances in Computers, 65,

2005.

ENASE 2016 - 11th International Conference on Evaluation of Novel Software Approaches to Software Engineering

178

Albrecht, A.: Measuring Application Development

Productivity, in IBM Application Development

Symposium, 1979.

Albrecht, A.J., Gaffney, J.E.: Software function, Source

Lines of Code and Development effort Prediction: a

Software Science Validation, IEEE Transactions on

Software Engineering, 9 (6), 1983.

Antoniol, G., Lokan, C., Caldiera, G., Fiutem, R.: A

Function Point-Like Measure for Object-Oriented

software, Empirical Software Engineering, 4 (3), 1999.

Antoniol, G., Lokan, C., Fiutem, R.: Object-Oriented

Function Points: An Empirical Validation, Empirical

Software Engineering, 8 (3), 2003.

Badri, M., Badri, L., Flageol, W.: Predicting the Size of

Test Suites from Use Cases: An Empirical

exploration, H. Yenigün, C. Yilmaz, and A. Ulrich

(Eds.): ICTSS 2013, LNCS 8254, November, 2013.

Badri, M., Badri, L., Flageol, W.: Simplifying Test Suites

Size Prediction Using Use Case Metrics: An

empirical comparison, Submitted to the International

Journal of Software Engineering and Knowledge

Engineering (IJSEKE), September 2015.

Badri, M., Toure, F.: Empirical Analysis of Object-

Oriented Design Metrics for Predicting Unit Testing

Effort of Classes, Journal of Software Engineering

and Applications, 5(7), July 2012.

Bianco, V.D, Lavazza, L.: An Assessment of Function

point-like metrics for object-oriented Open-Source

Software, International Conference on Software

Process and Product Measurement, 2006.

Bianco, V.D, Lavazza, L.: Object-Oriented Model Size

Measurement: Experiences and a Proposal for a

Process, Workshop on Model Size Metrics, ACM-

IEEE International Conference on Model Driven

Engineering Languages and Systems, 2006.

Boehm, B., Abts, C., Brown, A.W. et al.: Software Cost

Estimation with COCOMO II, Prentice-Hall,

Englewood Cliffs, NJ, 2000.

Boehm, B., Abts, C., Chulani, S.: Software Development

Cost Estimation Approaches – A survey, Annals of

Software Engineering, 10, 2000.

Boehm, W.B.: Software Engineering Economics,

Prentice-Hall, 1981.

Bourque, P., Côté, V.: An experiment in software sizing

structured analysis metrics, Journal of Systems and

Software, 15 (2), 1991.

Bruntink, M., Van Deursen, A.: Predicting Class

Testability Using Object-Oriented Metrics. In:

Proceedings of the 4th IEEE International Workshop

on Source Code Analysis and Manipulation (SCAM

2004), pp. 136–145, September 2004.

Bruntink, M., Van Deursen, A.: An Empirical Study into

class testability, Journal of Systems and Software,

79(9), 1219–1232, 2006.

Carbone, M., Santucci, G.: Fast & Serious: A UML based

Metric for Effort Estimation, 6

International

ECOOP Workshop on Quantitative Approaches in

Object-Oriented Software Engineering, 2002.

Chen, Y., Boehm, B.W., Madachy, R., Valerdi, R.: An

EMPIRICAL Study of eServices Product UML

Sizing Metrics, International Symposium on

Empirical Software Engineering, 2004.

Carroll, E.R.: Estimating Software Based on Use case

Points, OOPSLA’05, San Diego, California, USA,

October 16-20, 2005.

Costagliola, G., Ferruci, F., Tortora, G., Vitiello, G.:

Class Point: an Approach for the Size Estimation of

Object-Oriented Systems, IEEE Transactions on

Software Engineering, 31(1), 2005.

Hastings, T.E., Sajeev, A.S.M.: A vector-Based Approach

to Software Size Measurement and Effort Estimation,

IEEE Transactions on Software Engineering, 27 (4),

2001.

Henderson-Sellers, B.: Corrigenda: Software Size

Estimation of Object-Oriented Systems, IEEE

Transactions on Software Engineering, 23 (4), 1997.

Jacobson, I., Christerson, M., Jonson, P., Overgaard, G.:

Object-Oriented Software Engineering: A Use Case

Driven Approach, Addison-Wesley, 1993.

Jahan, M.V., Sheibani, R.: A new Method for Software

Size Estimation based on UML Metrics, The First

Conference on Software Engineering, Islamic Azad

University, 2005.

Janaki Ram, D., Raju, S.V.G.K.: Object-Oriented Design

Function Points, 1

Asia-Pacific Conference on

Software Quality, 2000.

Jorgensen, M., Shepperd, M.: A systematic Review of

Software Development Cost Estimation Studies,

IEEE Transactions on Software Engineering, 33 (1),

2007.

Jorgensen, M., Boehm, B.: Software Development Effort

Estimation: Formal Methods or Expert Judgment?,

IEEE Software, 2009.

Kemerer, C.F.: An empirical validation of software cost

estimation, Communications of the ACM, 30 (5),

1987.

Kim, S., Lively, W., Simmons, D.: An effort Estimation

by UML Points in the Early Stage of Software

development, International Conference on Software

Engineering Research & Practice, 2006.

Lagerstrom, R., Marcks von Wurtemberg, L., Holm, H.,

Luczak, O.: Identifying factors affecting software

development cost and productivity, Software Quality

Journal, 2012.

Larman, C.: Applying UML and Design Patterns, An

Introduction to Object-Oriented Analysis and Design

and the Unified Process, Prentice Hall, 2004.

Leung, H., Fan, Z.: Software Cost Estimation, Handbook

of Software Engineering and Knowledge

Engineering, Vol. 2, World Scientific Publishing,

2002.

Matson, J.E., Barrett, B.E., Mellichamp, J.M.: Software

Development Cost Estimation using Function Points,

IEEE Transactions on Software Engineering, 20 (4),

1994.

McDonell, S.G.: Software Source Code Sizing using

Fuzzy Logic Modeling, Information and Software

Technology, 45 (7), 2003.

Source and Test Code Size Prediction - A Comparison between Use Case Metrics and Objective Class Points

179

Mishra, S., Tripathy, K.C., Mishra, M.K.: Effort

Estimation based on Complexity and Size of

relational database system, International Journal of

Computer Science & Communication, 1 (2), 2010.

Ochodek, M., Nawrocki, J., Kwarciak, K.: Simplifying

effort estimation based on Use Case Points,

Information and Software Technology, 53, 200–213,

2011.

Pfleeger, S.L., Wu, F., Lewis, R.: Software cost

estimation and sizing methods: Issues and Guidelines,

RAND Corporation, 2005.

Singh, Y., Kaur, A., Malhota, R.: Predicting Testability

effort using Artificial Neural Network, In:

Proceedings of the World Congress on Engineering

and Computer Science, WCECS, San Francisco, USA,

2008.

Singh, Y., Saha, A.: Predicting Testability of Eclipse: a

Case Study, Journal of Software Engineering, 4(2),

2010.

Trendowicz, A., Munch, J., Jeffery, R.: State of the

Practice in Software Effort Estimation: A survey and

Literature Review, CEE-SET 2008, LNCS 4980,

2008.

Verner, J., Tate, G.: A software size model, IEEE

Transactions on Software Engineering, 38 (5), 2012.

Zhao, Y., Tan, H.B.K.: Software Cost Estimation through

Conceptual Requirement, 3

International

Conference on Software Quality, 2003.

Zhou, Y., Leung, H., Song, Q., Zhao, J., Lu, H., Chen, L.

and Xu, B.: An In-Depth Investigation into the

Relationships between Structural Metrics and Unit

Testability in OOS, Information SCIENCES, 55(12)

Science China, 2012.

Zhou, Y., Yang, Y., Xu, B., Leung, H., Zhou, X.: Souce

Code Size Estimation Approaches for Object-

Oriented systems from UML Class Diagrams: A

Comparative study, Information and Software

Technology, 56, 2014.

ENASE 2016 - 11th International Conference on Evaluation of Novel Software Approaches to Software Engineering

180
