Natural Language Processing for Risk Identification in Business
Process Repositories
Avi Wasser
1
and Maya Lincoln
2
1
University of Haifa, Mount Carmel, Haifa, Israel
2
ProcessGene Ltd, MATAM Science Park, Haifa, Israel
Keywords: Risk Management, Risk Design, Business Process Repositories, Business Process Management,
Natural Language Processing (NLP), ProcessGene.
Abstract: In recent years, researchers have become increasingly interested in developing methods and tools for
automating the design of governance, risk and compliance (GRC) models. This work suggests a method for
machine-assisted identification and design of new risks, based on business logic that is extracted from real-
life process repositories using a linguistic analysis of the operational similarity between process conducts.
The suggested method can assist process analysts, audit executives and risk managers in identifying new
organizational risks while making use of knowledge that is encoded in existing process repositories. The
suggested framework was tested on the ProcessGene process repository, showing our approach to be
effective in enabling the identification and design of new risks within real-life business process models.
1 INTRODUCTION
With the increase of regulatory requirements on one
hand, and the attempts to optimize business
outcomes on the other, organizations are required to
invest more efforts in identifying, managing and
mitigating risks. Executive officers are specifically
required to demonstrate effective risk management
practices, and to ensure corporate transparency and
visibility into the business. The risk management
process is continuous, and needs to be closely
monitored. As management is personally responsible
for monitoring risk levels, this responsibility
requires significant management attention and
allocation of time and effort.
Risk modelling is considered a manual, labour
intensive task, whose outcome depends on personal
domain expertise with errors or inconsistencies that
lead to bad risk prevention and high risk related
costs (Muller et al, 2007). Hence, automating the
identification and design of risks does not only save
design time but also supports non-expert designers
in defining new risks within business process
models.
While some works focus on the design of new
process models, mostly for a specific functional
domain, none refers to new risk definition and
identification within process repositories.
This work aims to suggest a generic method for
designing risks within business process models
related to any functional domain. The suggested
method guides business analysts and risk managers
that opt to identify and design new risks, by
suggesting new risks within a process repository.
The business logic for such suggestions is extracted
from process repositories through the analysis of
existing business process activities and their related
risks. We show through an empirical evaluation that
by utilizing operational process similarity analysis, it
is possible to effectively support the design of new
risks within process models.
The work proposes an innovative method for
assisting designers in designing brand new risks
while making use of knowledge that is encoded in
the design of existing, related process models. Our
work presents the following innovations: (a) it
provides generic support to the design of new risks
within existing process repositories; (b) it extends
the PDC model (Lincoln et al, 2007) to support the
representation of risks; and (c) it enables the design
of new risks based on extraction of business logic
from business process repositories.
The rest of the paper is organized as follows: we
present related work in Section 2, positioning our
608
Wasser, A. and Lincoln, M.
Natural Language Processing for Risk Identification in Business Process Repositories.
In Proceedings of the 18th International Conference on Enterprise Information Systems (ICEIS 2016) - Volume 2, pages 608-613
ISBN: 978-989-758-187-8
Copyright
c
2016 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved
work with respect to previous research. In Section 3
we present an extended model for representing
process risks based on the process descriptor notion,
presented first in the work of Lincoln et al (2007),
and extended in this work for the field of new risk
design. Then, we describe our method for designing
new risks in Section 4. Section 5 introduces our
empirical analysis. We conclude in Section 6.
2 RELATED WORK
Most of the efforts invested in developing methods
and tools for designing process models focus on
supporting the design of alternative process steps
within existing process models. Such a method is
presented by Schonenberg et al (2008) aiming to
provide next-activity suggestions during execution
based on historical executions and optimization
goals. Similarly, Gschwind et al (2008) suggest an
approach for helping business users in understanding
the context and consequences of applying pre-
defined patterns during a new process design.
Few works were devoted to the design of brand
new process models within specific and predefined
domains. The work presented by Muller et al (2007)
utilizes the information about a product and its
structure for modeling large process structures.
Reijers et al (2003) present a method, for designing
new manufacturing related processes based on
product specification and required design criteria.
Works in the domain of risk design also focus on
specific risk domains, such as credit risks (Giesecke,
2004; Galindo and Tamayo, 2000), inventory
management risks (Michalski, 2009), and financial
risks (Barbaro and Bagajewicz, 2004). Our work
offers a generic design method that is domain
agnostic and does not rely on product design data. In
addition our work assists in the design of risks rather
than process activities.
A requirement for the support of business
process design involves the performance of a
structured reuse of existing building blocks and pre-
defined patterns that provide context and sequences
(Gschwind et al, 2008). The identification and
choice of relevant process components are widely
based on the analysis of linguistic components -
actions and objects that describe business activities.
Most existing languages for business process
modeling and implementation are activity-centric,
representing processes as a set of activities
connected by control-flow elements indicating the
order of activity execution (Wahler and Kuster,
2008). In recent years, an alternative approach has
been proposed, which is based on objects (or
artifacts/entities/documents) as a central component
for business process modeling and implementation.
Our work supports this approach and focuses on
objects for the purpose of risk identification and
modeling.
Finally, the work of Lincoln et al (2007) presents
the concept of business process descriptor that
decomposes process names into objects, actions and
qualifiers. In this work we take this model a
significant step forward by extending the framework
to support also the representation of risks using a
new taxonomy - the “risk descriptor.”
3 THE DESCRIPTOR MODEL
In the Process Descriptor Catalog model (“PDC”)
(Lincoln et al, 2007) each activity is composed of
one action, one object that the action acts upon, and
possibly one or more action and object qualifiers, as
illustrated in Figure 1, using UML relationship
symbols. Qualifiers provide an additional
description to actions and objects. In particular, a
qualifier of an object is roughly related to an object
state. State-of the art Natural Language Processing
(NLP) systems, e.g., the “Stanford Parser” (Stanford
parser, 2016), can be used to automatically
decompose process and activity names into
process/activity descriptors.
Figure 1: The activity decomposition model.
For example, the activity “Manually Calibrate
the Color Machine” generates an activity descriptor
containing the action “calibrate, the action qualifier
“manually, the object “machine and the object
qualifier “color.” In short, this descriptor can be
represented as the tuple
(calibrate,manually,machine,color) - where the
action and its qualifier are followed by the object
and its qualifier. In general, such tuple can be
represented as (A,AQ,O,OQ), where A represents
the action, AQ represents the action qualifier, O
represents the object and OQ represents the object
qualifier.
Natural Language Processing for Risk Identification in Business Process Repositories
609
In this work we extend the descriptor model for
representing risk names. To do that, we have
analysed 842 real-life risk names from the
ProcessGene repository (ProcessGene, 2016), e.g.
“employee has criminal records”, “corrupt backup
tapes”, “signature forgery”. We found out that in
98.2% of the cases risks are linguistically phrased as
states (an object with 0-n qualifiers) without any
action and action qualifiers. We also found out that
it was possible to convert the other 1.8% of the risk
names into a state format (e.g. the risk “Data
Restoration will Fail” can be converted into the
state: “Data Restoration Failure”). Therefore, risk
names can be represented by a partial (degenerate)
descriptor model, with null values for the action
related constructs. For example, the risk “Backup
Restoration Failure” can be represented by a
descriptor containing a NULL action, NULL action
qualifiers, the object “backup and the object
qualifier “restoration failure. In short, the risk's name
can be represented by the tuple (NULL, NULL,
backup, restoration failure).
4 THE RISK IDENTIFIER
METHOD
The Risk Identifier method analyses an underlying
process repository and suggests the addition of
missing risks.
Figure 2: The risk identifier mechanism.
The risk identifier is illustrated in Figure 2. The
identification process starts when a user (e.g. a risk
manager or a process designer) seeks to reveal
additional risks that are not represented within a
process repository. In response, the risk identifier
searches the process repository and retrieves
operationally similar processes (phase #1, see
elaboration in Section 4.1). It then compares the
risks at each process model and identifies potentially
missing ones - meaning risks that exist in one
process model (namely “reference risks”) and are
missing at a similar process model (namely, an
“examined process model”) (phase #2). Based on the
examined process model content on one hand, and
the reference risk name on the other hand, the risk
identifier suggests a name for the new risk candidate
(phase #3, elaborated in Section 4.2).
Going back to the examined process model, and
prior to suggesting the new risk to the user, the risk
identifier verifies that the new risk candidate is not
already represented in the examined process model
(phase #4, Section 4.3). The new risk candidates are
then ranked according to their user acceptance
likelihood. This is done using a learning mechanism
that collects data regarding the user inputs in
previous risk identification procedures (phase #5,
Section 4.4). This results in an output of a ranked list
of new risk candidates that is presented to the user
(phase #6).
The user reviews the output option list and
selects the relevant risks that in her opinion should
be added to the process repository (phase #7). She
then modifies and adjusts the auto-generated risk
names (phase #8, Section 4.5). The risk identifier
analyses the user's selection and modifications and
adjusts his underlying learning mechanism for future
risk identification runs (phase #9).
4.1 Searching for Operationally
Similar Process Models
The goal of this phase is to find process models
within the process repository that are similar in
operation terms. Such processes achieve a different
business goal but are similar in the way (how) they
are conducted. Since risks refer to the modus
operandi facet of the process, it is assumed that such
similar processes will also share similar risks. This
assumption is validated and supported by
experiments in Section 5.
To perform such operation-based search we
apply the search method presented by Lincoln and
Gal (2011). As an example, the following process
models were found as operationally similar:
“Background check-up of a new employee
candidate” and “supplier assessment.” Although
these process models are not semantically similar,
their activity flow is similar. Note that a semantic-
based similarity search would not have found the
two example processes since they do not share
similar terminology but are rather similar in the way
they are executed. For a more profound discussion
1. Search for
operationally
similar process
models
Risk Identifier
2. Compare risks
and locate
potentially
missing ones
Risk Identifier
3. Suggest
new risk’s
name
Risk Identifier
4. Verify the
suggested risk is not
already represented
in the process model
Risk Identifier
7. Select
relevant risks
User
6. Output: a
ranked list
of new risk
suggestions
9. Learn from
user’s
selection and
adjustments
Risk Identifier
8. Modify and
adjust selected
risks
User
5. Rank new risk
suggestion according
to their acceptance
likelihood
Risk Identifier
ICEIS 2016 - 18th International Conference on Enterprise Information Systems
610
on operational vs. semantic process search see the
work of Lincoln and Gal (2011).
4.2 Suggesting a Name for the New
Risk Candidate
The goal of this phase is to construct an appropriate
name for the new risk (“nr”) candidate. To do this
the following procedure is detailed as follows.
1. Decompose the reference risk (“rr”) name into
a risk descriptor (see Section 3), represented as
(NULL,NULL,O
rr
,OQ
rr
).
2. Decompose the reference process (“rp”) name
into a process descriptor (see Section 3), represented
as (A
rp
,AQ
rp
,O
rp
,OQ
rp
).
3. Decompose the examined process (“ep”) name
into a process descriptor (see Section 3), represented
as (A
ep
,A
ep
,O
ep
,OQ
ep
).
4. If O
rr
=O
rp
then the new risk candidate name is:
(NULL,NULL,O
ep
,OQ
rr
).
5. Else: the new risk candidate name is:
(NULL,NULL,O
rr
,OQ
rr
).
Following the above example, the risk “Missing
data about the employee candidate” was located
within the process model of “Background check-up
of a new employee candidate.” As a consequence,
according to this phase, a new risk candidate was
offered to the “Supplier assessment” process,
named: “Missing data about the supplier.”
4.3 Redundancy Check-up
This phase aims at verifying that the new risk
candidate is not already represented as part of the
examined process model. To do that, it is required to
semantically compare between each of the risks
related to the examined process and the new risk
candidate's name.
4.4 Preparing a Set of Output Options
The input for this phase is a set of several new risk
candidates. In order to assist the user in reviewing
the list options, this phase aims at ranking the new
risk candidate list according to their user acceptance
likelihood. This is done by learning and analysing
the user's inputs in previous risk identification
procedures as follows.
At the end of each risk identification procedure
the user is required to select relevant risks and also
modify and adjust selected risks (phases #7 and #8
in Figure 2). These user actions from previous runs
influence the grade each new risk candidate receives
at the current run in the following way. First, each
risk candidate is labeled with an identical grade=1.
Then, the grade of each risk candidate is adjusted as
follows:
1. Penalty Due to Risk Content. This correction
aims to add a penalty to risks that are usually
removed, by increasing the risk candidate's grade
according to the number of times a risk with the
same name was marked as irrelevant in previous
runs. Similarly, the grade increases according to the
number of times a risk with the same name was
added to the repository in previous runs. Such
additions of the same risk can also indicate that this
risk was neglected in the original process repository.
2. Penalty Due to the Nature of the Examined
Process. This correction aims to take into account
the “safety” nature of the examined process. A
“safe” process is a process that the chance of adding
risks to it are low (it may consist risks but they are
already being fully handled by the process).
Therefore, the risk's grade is increased according to
the number of times a risk within the same examined
process model was marked as irrelevant in previous
runs. Similarly, the risk's grade is decreased
according to the number of times a risk within the
same examined process model was added in
previous runs.
3. Penalty Due to Inaccuracy. This correction
aims to take into account the expected accuracy of
the risk. Therefore, the grade will increase according
to the total number of changes the user made to the
descriptor of the same risk name in previous runs. A
change is considered as any replacement of an object
or an object qualifier name.
After calculating each of the new risk list
options, the risk identifier sorts the list in an
ascending order - from the most probable to the most
improbable in terms of the chances the user will
finally accept and add the risk to the process
repository.
4.5 Adjusting the Auto-generated Risk
Names
In case the user decides that the newly suggested
risk is relevant to the examined process, she re-
examines its name and optionally modifies one or
more of its risk descriptor components (object and/or
object qualifiers).
Natural Language Processing for Risk Identification in Business Process Repositories
611
5 EXPERIMENTS
We now present an empirical evaluation of the
proposed method effectiveness. First, we present the
experimental setup and describe the data sets that
were used. Based on this setup we present the
implemented methodology. Finally, we present the
experiment results and provide an empirical analysis
of these results.
5.1 Data
We chose a set of 43 process models from the
ProcessGene repository that have at least one
operationally similar process. The selected process
models are part of different business categories (e.g.
manufacturing, procurement, human resource
management) and have a different number of risks.
5.2 Evaluation Methodology
To evaluate the suggested method we conducted 43
experiments. At each experiment, the risks of a
single process were removed from the database and
then reconstructed using the risk identifier method.
This “machine assisted reconstruction” enables us to
objectively measure the method's effectiveness. In
addition, a risk management expert was asked to
assess risks that were offered by the risk identifier
and did not belong originally to the process
repository.
5.3 Results and Analysis
Table 1 presents a summary of the experiment
results. On average, 24% risks from the ProcessGene
repository were missing from the generated risk lists
(see column #1). This means that 76% of the risks in
the repository were reconstructed successfully by the
risk identifier mechanism, showing a high level of
usefulness to the method.
Table 1: Experiment results.
Column # 1 2 3
Column
name
% of
missing
risks in the
generated
risk list
% of
redundant
risks in
the
generated
risk list
% of
generated
risks that are
not
represented
in the
ProcessGene
repository
Avg. 24% 9% 4%
In addition, on average, 9% of the risks
candidates were redundant - meaning they were not
relevant to the examined process (see column #2),
again, highlighting the level of accuracy of the
generated risk list.
Finally, on average, the risk management expert
chose to add 4% of the risks that were not
represented in the ProcessGene repository (see
column #3). This indicates that the risk identifier
mechanism's ability to generate new risks was not
dependent on the specific given repository.
To summarize, the experiments have
demonstrated the usefulness of the machine-based
risk identification assistant in constructing risks to
process models. We have also measured and
evaluated the effectiveness of the method in the
given experimental setup, both in terms of the
amount of missing risks and in the amount of
redundant risks.
6 CONCLUSIONS
We proposed a mechanism for automating the
generation of risks within a process repository. Such
a mechanism saves design time and supports non-
expert designers in creating new risks for business
process models. The proposed method and
experiments provide a starting point that can already
be applied in real-life scenarios, yet several research
issues remain open, including: (1) an extended
empirical study to further examine the quality of the
framework; (2) extending the method to include
mitigating controls as well; and (3) extending the
learning mechanism to further predict the user's
behaviour.
REFERENCES
Barbaro, A., Bagajewicz, M., J., 2004. Managing
Financial risk in planning under uncertainty. AIChE
Journal, 50(5):963989.
Galindo, J., Tamayo, P., 2000. Credit risk assessment
using statistical and machine learning: basic
methodology and risk modelling applications.
Computational Economics, 15(1-2):107143.
Giesecke, K., 2004. Credit risk modelling and valuation:
An introduction. Available at SSRN 479323.
Gschwind, T., Koehler, J., Wong, J., 2008. Applying
patterns during business process modelling. In BPM,
volume 5240, pages 419. Springer.
Lincoln, M., Gal, A., 2011. Searching business process
repositories using operational similarity. On the Move
ICEIS 2016 - 18th International Conference on Enterprise Information Systems
612
to Meaningful Internet Systems: OTM 2011, pages
219.
Lincoln, M., Karni, R., Wasser, A., 2007. A Framework
for Ontological Standardization of Business Process
Content. International Conference on Enterprise
Information Systems, pages 257263.
Michalski, G., 2009. Inventory management optimization
as part of operational risk management. Economic
Computation and Economic Cybernetics Studies and
Research, pages 213222.
Muller, D., Reichert, M., Herbst, J., 2007. Data-driven
modelling and coordination of large process structures.
Lecture Notes in Computer Science, 4803:131.
ProcessGene website, 2016. http://processgene.com/busin
ess-process-repository/.
Reijers, H.A., Limam, S., Van Der Aalst, W.M.P., 2003.
Product-based workflow design. Journal of
Management Information Systems, 20(1):229262.
Schonenberg, H., Weber,B., van Dongen, B.F, van der
Aalst, W.M.P., 2008. Supporting flexible processes
through recommendations based on history. In
International Conference on Business Process
Management (BPM 2008), volume 5240, pages 5166.
Springer.
Stanford parser, 2016. http://nlp.stanford.edu:8080/parser/i
ndex.jsp.
Wahler, K., Kuster, J.M., 2008. Predicting Coupling of
Object-Centric Business Process Implementations. In
Proceedings of the 6th International Conference on
Business Process Management, page 163. Springer.
Natural Language Processing for Risk Identification in Business Process Repositories
613
