A Hybrid Interaction Model for Multi-Agent
Reinforcement Learning
Douglas M. Guisi
1
, Richardson Ribeiro
1
, Marcelo Teixeira
1
, André P. Borges
2
, Eden R. Dosciatti
1
and Fabrício Enembreck
3
1
Federal University of Technology-Paraná, Pato Branco, Brazil
2
Federal University of Technology-Paraná, Ponta Grossa, Brazil
3
Pontificial Catholical University-Paraná, Curitiba, Brazil
Keywords: Multi-Agents Systems, Coordination Model, Reinforcement Learning, Hybrid Model.
Abstract: The main contribution of this paper is to implement a hybrid method of coordination from the combination
of interaction models developed previously. The interaction models are based on the sharing of rewards for
learning with multiple agents in order to discover interactively good quality policies. Exchange of rewards
among agents, when not occur properly, can cause delays in learning or even cause unexpected behavior,
making the cooperation inefficient and converging to a non-satisfactory policy. From these concepts, the
hybrid method uses the characteristics of each model, reducing possible conflicts between different policy
actions with rewards, improving the coordination of agents in reinforcement learning problems. Experi-
mental results show that the hybrid method can accelerate the convergence, rapidly gaining optimal policies
even in large spaces of states, exceeding the results of classical approaches to reinforcement learning.
1 INTRODUCTION
Multi-agent systems in general comprises of adap-
tive agents that interact with each other in order to
conduct a given task. In a multi-agent system, agents
need to interact and to coordinate themselves for
carrying out tasks (Stone and Veloso, 2000). Coor-
dination between agents can help to avoid problems
with redundant solutions, inconsistency of execution,
resources wasting and deadlock situations. In this
context, coordination models based on learning are
capable of solving complex problems involving social
and individual behaviors (Zhang and Lesser, 2013).
Besides learning how to coordinate itself, an
agent from a multi-agent system must also be able to
cooperate to other agents in the system, attempting
to solve problems that locally require unknown
knowledge or problems that compromise the agent
performance to be solved. In this way, sharing agent
expertise (usually in terms of action policies) be-
comes essential to converge to a global behavior that
satisfies a certain specification or that simply solves
a particular problem.
An alternative to share agent’s expertise among
multi-agents is using specific computational para-
digms that maximize performance based on rein-
forcement parameters (reward or punishment) ap-
plied to agents as they interact with the environment.
Such paradigms are called Reinforcement Learning
(RL) (Kaelbling et al., 1996) (Sutton and Barto,
1998).
RL algorithms, such as Q-learning (Watkins and
Dayan, 1992), can be used to discover the optimal
action policy for a single agent when it repeatedly
explores its state-space.
Formally, an action policy can be modeled by a
5-tuple b=
A, S, s°, *,
that maps states and ac-
tions in order to determine, among a set of actions A
and a set of states S, which an action a
A should
be performed at a given state s S. An action policy
model has also an initial state
S, an objective
state s*
S, and a transition relation
that defines
the range of actions possible to be generated from a
state. The relation is defined as memoryless, i.e.,
it defines actions taking into account uniquely the
current state, which qualifies the approach as a Mar-
kovian Decision Process (MDP).
A major concern that arises from this action-
policy-discovering approach is that it tends to suffer
with large state-spaces, due to state-space explosion
problems. In this case, RL involving multiple agents
has shown to be a promising strategy that modular-
54
Guisi, D., Ribeiro, R., Teixeira, M., Borges, A., Dosciatti, E. and Enembreck, F.
A Hybrid Interaction Model for Multi-Agent Reinforcement Learning.
In Proceedings of the 18th International Conference on Enterprise Information Systems (ICEIS 2016) - Volume 2, pages 54-61
ISBN: 978-989-758-187-8
Copyright
c
2016 by SCITEPRESS Science and Technology Publications, Lda. All rights reserved
izes the whole problem and locally implements ac-
tion policies (Ribeiro et al., 2008).
The whole idea behind the implementation of lo-
cal policies is discovering a global action plan gen-
erated by the proper combination of local knowledge
of agents. When this approach leads to the best global
action plan, the policy Q is said to be optimal (Q*)
and it maximizes the reward received by agents.
The approach investigated in this paper aims to
improve the way agents share information with each
other. In order to transmit and receive information,
agents are required to share a cooperative and coor-
dinated interaction model that eventually leads to
improved action policies. So, the kernel for estab-
lishing optimized information sharing strategies for
multiple agents is the interaction model.
In this paper we introduce a hybrid coordination
model for multi-agents using RL techniques. Our
approach collects “good” features from individual
approaches in the literature and integrates them into
a single framework, which can then be used to estab-
lish optimized information sharing strategies for
multiple agents. Preliminary results compare the
performance of the hybrid model with respect to the
each particular model that has been used to compose
our framework. In general, we have observed a con-
vergence rate among agents substantially better than
in the other cases.
The remainder of this paper is organized as fol-
lows. In the following section, the state of the art is
presented, in which: (i) describes some coordination
methods for learning in multi-agent systems; (ii)
reviews of the Q-learning algorithm; and (iii) sum-
marizes the interaction models. The details of the
proposed method, environmental assessment and
numerical results to demonstrate the performance of
the method are present in Section 3. Conclusions are
drawn in Section 4.
2 LEARNING IN MULTI-AGENT
SYSTEMS
Learning in multi-agent systems, unlike learning in
environment with a single agent, assumes that the
relevant knowledge is not locally available in a sin-
gle agent, although it is necessary to coordinate the
whole process (Chakraborty and Stone, 2014),
(Zhang and Lesser, 2010), (Xuan and Lesser, 2002).
One way for an agent to coordinate its actions is by
interacting with other agents, changing and evolving
their own coordination model.
Coordination by interaction provides the combi-
nation of efforts among a group of agents when
searching for solutions to global problems (DeLoach
and Valenzuela, 2007). A situation of interaction is a
set of behaviors resulting from a group of agents that
act to satisfy their goals and consider constraints
imposed by resources limitations and individual
skills. In the literature, learning from interactions
composes a preeminent research topic (Ribeiro et al.,
2013), (Xinhai and Lunhui, 2009), as well as collec-
tive or social learning (Ribeiro et al., 2013), (Ribeiro
and Enembreck, 2013).
Learning problems involving RL interaction
models depends basically on a structure that enables
communication among agents, so that they can share
their accumulated rewards, which immediately rein-
forces the transition system. With this propose,
Chapelle et al. (2002) propose an interaction model
that calculates rewards based on the individual satis-
faction of neighboring agents. In this learning pro-
cess, agents continuously emit a level of personal
satisfaction. Differently, Saito and Kobayashi (2016)
develop a learning strategy in which agents are able
to keep memory about information they have accu-
mulated, so they can reuse them in the future. This
method has been tested on colored mazes and re-
ports confirm that it positively impacts on jumpstarts
and reduces the total learning cost, compared to the
conventional Q-learning method.
Ribeiro and Enembreck (2013) combine theories
from different fields to build social structures for
state-space search, in terms of how interactions be-
tween states occur and how reinforcements are gen-
erated. Social measures are used as a heuristic to
guide exploration and approximation processes. Ex-
periments show that, identifying different social be-
havior within the social structure that incorporates
patterns of occurrence between explored states helps
to improve ant coordination and optimization process.
Usually, it is challenging to integrate different
methods into a single improved generic coordination
model, especially due to the diversity of the classes
of problems and the amount of knowledge necessary
from the problem domain. Furthermore, in a multi-
agent system, conflicting values for cumulative re-
wards can be generated, as each agent uses only lo-
cal learning values (DeLoach and Valenzuela,
2007). Thus, the collective learning assumes that the
relevant knowledge occurs when rewards are shared,
intensifying the relationship between agents.
2.1 Reinforcement Learning
RL tries to solve problems where an agent receives a
return from the environment (rewards or punish-
A Hybrid Interaction Model for Multi-Agent Reinforcement Learning
55
ments) for its actions. This type of learning has been
extensively investigated in the literature (Grze’s and
Hoey, 2011), (Devlin et al., 2014), (Efthymiadis and
Kudenko, 2015), (Tesauro, 1995), (Walsh et al.,
2010), (Zhang and Lesser, 2013) in order to approx-
imate solutions to NP-hard problems.
To properly formalize a RL problem, it is essen-
tial to first describe how a MDP structure is com-
posed. A MDP is a tuple
S, A, T
a
s,s’
, R
a
s,s’
such that
S is a finite set of environmental conditions, that
may be composed, for example, by a variable se-
quence of states
x
1
, x
2
, …, x
v
; A is a finite set of
actions, where an episode a
n
is a sequence of actions
a A which leads the agent from a state s
initial
to a
state s
objective
, T
a
s,s’
is a transition state relation T : S ×
A [0,1], that indicates the probability of an agent
to reach a state s’ when an action is applied at the
state s. Similarly, R
a
s,s’
is a reward function R : S × A
received whenever a transition T
a
s,s’
occurs.
The goal of a RL agent is to learn a policy π: S ×
A which maps the current state s into a desired ac-
tion to maximize the rewards accumulated over the
time, describing the agent’s behavior (Kaelbling et
al., 1996). To achieve optimal policies, the RL algo-
rithm must iteratively explore the state space S × A,
updating the accumulated rewards and storing re-
wards in Q(s, a) (Equation 1).
A well known method that can be used to solve
RL problems is called Q-learning (Watkins and Da-
yan, 1992). The basic idea of the method is that the
learning algorithm learns an optimal evaluation
function for all pair state-action in S × A. The Q
function provides a mapping Q: S × A V, where V
is the value of expected utility when performing an
action a in state s. The function Q(s,a), of the ex-
pected reward when choosing the action, is learned
through a trial and error approach, as described by
Equation 1:
)]([),(),( VyRasQasQ ×++
α
(1)
where α [0,1] is the learning rate, R is the reward,
or cost resulting from taking action a in state s, y is
the discount factor and V is obtained by using the
function Q learned by now. A detailed discussion
about Q-learning can be found in (Watkins and Da-
yan, 1992).
In this paper, Q-learning is used to generate and
evaluate partial and global action policies. By apply-
ing Q-learning it is possible to find a policy to an
agent. However, if similar agents interact into the
same environment, each agent has its own MDP, and
optimal global behavior can not be set by local anal-
ysis. Thus, in an environment formed by several
agents, the goal is to select the actions of each MDP
at time t, so that the total expected rewards for all
agents is maximized.
2.2 Reinforcement Learning with
Multiple Shared Rewards
In RL algorithms with multiple shared rewards,
agents can produce a refined set of behaviors ob-
tained from the executed actions. Some behaviors
(e.g., a global action policy) are shared by agents
through a partial policy action (Q
i
). Usually, such
policies contain partial information (learning values)
about the environment (E), but communicate with a
central structure to share rewards in an integrated
way in order to maximize the sum of the partial re-
wards obtained during the learning process. When
policies Q
1
,…,Q
x
are integrated, it is possible to
make a new policy = {Q
1
,....,Q
x
}, where (s,a) is a
table that denotes the best rewards acquired by
agents during the learning process.
Figure 1: Learning with shared rewards (Ribeiro et al.,
2008).
Figure 1 shows how agents exchange infor-
mation during learning. When the agent A* receives
rewards from other agents Agent
i
, the following pro-
cess occurs: when Agent
i
reaches the goal state g
from a state s g with a lower-cost way, the agent
uses a model to share such rewards with other
agents. The learning values of a partial policy
i
Q
^
can be used to upgrade the overall policy (s,a), fur-
ther interfering in how other agents update their
knowledge and interact with the environment.
Figure 1 also shows the function that shares such
rewards. This task can be accomplished in three
ways (summarized in subsection 2.2.1), all internally
using Q-learning. The best rewards from each agent
are sent to (s,a), forming a new policy with the best
rewards acquired by agents Agent
i
= {i
1
,...i
x
}, which
can be socialized with other agents. A cost function
(Equation 2) is used to estimate (s,a), which calcu-
lates the cost of an episode (path from an initial state
s to the goal g) in a given policy.
ICEIS 2016 - 18th International Conference on Enterprise Information Systems
56
+=
g
Ss
g
Ss
Sst.gsstoc )(10),(
(2)
The discovery of this path is performed with the
A* algorithm which produces a generative model for
managing policies that maximize the expected
amount of reward, i.e., optimal policies, according to
the methodology presented in (Ribeiro et al., 2006).
The cooperative RL algorithm, the other algo-
rithms, and the elements formalizing the RL models
are detailed in (Ribeiro et al., 2008). Figure 2 sum-
marizes the learning process with the models in an
activity diagram that uses the algorithms proposed in
(Ribeiro et al., 2008).
Figure 2: The learning process activity diagram with the
interaction models.
2.2.1 Interaction Models
In this subsection, we summarize the models pre-
sented in (Ribeiro et al., 2008).
Discrete Model: The agents share learning in a
predefined cycle interactions c. Cooperation in the
discrete model occurs as follows: the agent accumu-
lates rewards obtained from its actions during the
learning cycle. At the end of the cycle, each agent
sends the values of
i
Q
^
to (s,a). The agent share its
reward if and only if it improves the efficiency of
the other agents at the same state.
Continuous Model: The agents cooperate at
every transaction T
a
s,s’
. Cooperation in the continu-
ous model occurs as follows: if s g, then every
action performed by the agent generates a reward
value, which is the sum of the accumulated rein-
forcements for all players in action a in state s. The
goal is to accumulate the greatest rewards in
i
Q
^
that
can be shared at each iteration.
Objective-driven Model: Unlike the discrete
model, cooperation occurs when the agent reaches
the goal state, i.e., s = g. In this case, the agent inter-
acts accumulating reward values. It is necessary be-
cause in this model the agent shares his rewards only
when the state goal is reached. When the agent
reaches the goal state, the rewards value is sent to
(s,a). If the state reward value improves the overall
efficiency, then the agents share such rewards. It
shows that even sharing unsatisfactory rewards (due
to of lack interaction), the agent is able to adapt his
behavior without damaging the global convergence.
3 HYBRID COOPERATION
MODEL
In RL based on shared rewards, is usual to discover
intermediate action policies that are not appropriate
to achieve a certain goal. In fact, the knowledge ex-
change among agents may lead to intermediate ac-
tion plans that do not immediately fit to the agent’s
convergence. As each agent constantly updates its
own learning, it becomes necessary that all agents
are aware of all updates happening and of the reward
from each agent.
Using the previously presented approaches for
agent’s coordination based on shared rewards, there
is no guarantees that the action plans will converge
sometime. It can happen that policies with initially
mistaken states and values are improved by rewards
informed by other intermediate policies, improving
the (s,a) function. However, the opposite is also
possible, i.e., initially interesting policies, with high
level rewards, may become less interesting to be
chosen during a given policy, as states previously
producing successful hits and errors.
A. 400 states and 5 agents
B. 400 states and 10 agents
Figure 3: Coordination models (Ribeiro et al., 2008).
In order to overcome this inconvenience (local
A Hybrid Interaction Model for Multi-Agent Reinforcement Learning
57
maximum), we develop in this paper a hybrid meth-
od for multi-agents coordination. This approach
emerges from the discrete, continuous and objective-
driven models previously presented. By analyzing
results collected from those models, we claim that
the behavior of (s,a) changes as a function of num-
ber of interactions of the algorithms, the quantity of
episodes involved in the problem and the cardinality
of the set of agents that have been used. Figure 3
supports our claim by comparing coordination mod-
els immerse in a 400-states environment.
The proposed hybrid method capture the best
features from each individual interaction model, at
every interaction of the coordination. The discovery
of new action policies is done without delaying the
learning process, reducing the probability of con-
flicts among actions from different policies.
Technically, the hybrid method can be summa-
rized as follows: at every interaction of Q-learning,
the agent’s performance is collected from each inter-
action model. This composes what we call a learn-
ing table named HM-(s,a) (Hybrid Method). When
the model update condition is reached, the agent
starts its learning process using the best performance
calculated from the learning tables in the interaction
models. The learning is then transferred to HM-
(s,a). Therefore, the function HM-(s,a) will al-
ways comprise the best rewards obtained from the
discrete, continuous and objective-driven models.
Algorithm for the Hybrid Method
M:discrete-D, continuous-C, objective-O
//models
Q
i
: Q
M
_
D
, Q
M
_
C
, Q
M
_O
//learning tables
1
For each instance of Q
i
M do
2
If Q
M
_
D
*> Q
M
_
C
and
3
Q
M
_
D
*> Q
M
_
O
then
4
HM-(s,a) Q
M
_
D
5
else if
6
Q
M
_
C
*> Q
M
_
D
and
7
Q
M
_
C
*> Q
M
_
O
then
8
HM-(s,a) Q
M
_
C
9
else
10
HM-(s,a) Q
M
_
O
11
end if
12
end for
13
Return (HM-(s,a))
Algorithm 1: Hybrid Method Algorithm.
Algorithm 1 presents the integration of discrete,
continuous and objective-driven interaction models.
As it can be observed, for every learning cycle, the
agent performance is compared with respect to the
interaction models that have been used (by the oper-
ator ‘*>’ over the three learning tables). When a
given model returns a superior performance with
respect to the model that has been compared, this
learning is transferred to HM-(s,a), which repre-
sents the current action policy of the Hybrid Method.
The next section presents a simulation environment
to assess the efficiency of the proposed model.
3.1 Experimental Results
In order to assess the proposed approach, we present
a simulation environment composed by a state-space
representing a traffic structure over which agents
(drivers) try to find a route.
The structure has an initial state (s
init
), an objec-
tive state (g) and a set of actions A = { (forward),
(right), (back), (left)}. A state s is a pair
(X,Y) in which the element define the position on the
axis X and Y, respectively. A status function st : S
ST maps traffic situations (rewards) to states, such
that ST = {–0,1 (free route); –0,2 (a bit stuck); –0,3
(stuck or unknown); –0,4 (heavily stuck); –1
(blocked); 1,0 (g)}.
For this scenario, agents simulates available
routes for drivers. The global goal is elaborate an
action policy (combination that maps states and ac-
tions) that can determine the best route connecting
s
init
to g. The global action policy is defined by de-
termining step by step which action a
A should be
performed at each state s
S. After every moving of
the agent (transition/ interaction) from a state s to a
state s’, it knows whether or not its action has been
positive, as it recognizes the set of rewards shared
by the other models. The rewards for a given transi-
tion T
a
s,s’
is denoted by st(s’).
Figure 4: Simulated scenarios. The agents have a visual
field depth of 1.
ICEIS 2016 - 18th International Conference on Enterprise Information Systems
58
Figure 4 presents some scenarios that have been
used for simulations. They have been arbitrarily
generated, aiming to reproduce situations as closely
as possible to real world situations. The agents are
randomly positioned into the state-space. When an
agent reaches the goal state, this agent is randomly
positioned into others state s, until the stopping crite-
rion is satisfied (interactions numbers).
3.2 Comparative Analysis
The results illustrated in this section compares the
Hybrid Method to the individual performances ob-
tained as in the Discrete, Continuous and Objective-
driven interaction models.
The parameters that have been used in the Hy-
brid Method are the same as those used for the indi-
vidual models: discount fator (y) of 0.99 and learn-
ing rate (α) of 0.2 (Ribeiro et al., 2008).
Experiments have been conducted on environ-
ments ranging from 100 (10 × 10) to 400 (20 × 20)
states. For the sake of clarity, however, in this paper
we concentrate them on the largest state-space. The
results that follow compare the Hybrid Method to
the other methods using 3, 5 and 10 agents, in an
environment composed by 100, 250 and 400 states.
Observe that in Figures 5-11 the Hybrid Method
has shown to be more efficient with respect to the indi-
vidual performance achieved by the other models. In
general, it has shown to be superior at any interaction
phase, which substantially reduces the number of inter-
actions necessary to find out a proper action policy.
Figure 5: 100 states and 3 agents.
Figure 6: 100 states and 10 agents.
Figure 7: 250 states and 3 agents.
Figure 8: 250 states and 5 agents.
Figure 9: 250 states and 10 agents.
Figure 10: 400 states and 3 agents.
Figure 11: 400 states and 10 agents.
A Hybrid Interaction Model for Multi-Agent Reinforcement Learning
59
For experiments on environments with 100
states, the number of interactions has been reduced
in average 22.8% when using 3 agents; 26.7% with 5
agents; and 41.1% using 10 agents. For environ-
ments with 250 states, the method reduces the num-
ber of interactions in 21.1% with 3 agents; 21.9%
with 5 agents; and 32.7% for 10 agents. For envi-
ronments with 400 states, the number of interactions
has been reduced in 17,4% with 3 agents; 22,9%
with 5 agents; and 29,1% for 10 agents. Table 1
summarizes the improvements of the Hybrid Method
compared to the best method among the other mod-
els.
Table 1: Overall comparative analysis.
State-space
Number of agents
3 5 10
100
16.5% 68.7% 36.9%
250
49.4% 30.9% 32.6%
400
44.2% 41.1% 38.2%
The overall improvement achieved by the Hybrid
Method, considering all tested number of agents and
state-spaces, reaches the order of 40%.
4 CONCLUSIONS AND
DISCUSSIONS
This article designs a hybrid method to improve co-
ordination in multi-agent systems from the combina-
tion of interaction models presented in a previous
work. In sequential decision problems an agent in-
teracts repeatedly in the environment and tries to
optimize its performance based on the rewards re-
ceived. Thus, it is difficult to determine the best ac-
tions in each situation because a specific decision
may have a prolonged effect, due to the influence on
future actions. The proposed hybrid method is able
to take the agent to an acceleration in the conver-
gence of their action policy, overcoming the particu-
larities found in the interaction models presented in
(Ribeiro et al., 2008). The political of these models
may have different characteristics in environments
with different configurations, causing the agent fails
to converge at certain cycles of learning. Thus, the
hybrid method of coordination uses the best features
of interaction models (summarized in Subsection
2.3.1). The hybrid method policies outweigh the
policy of each model, assisting in the exchange of
best rewards to form a good overall action policy.
This is possible because the hybrid method can es-
timate the best rewards acquired through learning,
discovering an arrangement with the best ribs found
in partial action policies for each model.
Accumulate rewards generated by different ac-
tion policies is an alternative to support an adaptive
agent in search of good action policies. Experiments
with the hybrid method show that even with a higher
computational cost, the results are satisfactory, since
the approach improves convergence in terms of the
Q-learning algorithm standard. The complexity in-
troduced using n agents is around O(n × m), which is
equal to O(m) since n is a small constant and O(m) is
the complexity of the RL algorithm used as baseline.
Despite the satisfactory results, additional exper-
iments are needed to answer some open questions.
For example, the use of algorithms with different
paradigms could be used to explore the states with
the highest congestion regions? We observed that in
these regions the rewards of states are smaller. A
reinforcement learning algorithms system with dif-
ferent paradigms was proposed in (Ribeiro and En-
embreck, 2013), where the results seem to be en-
couraging. It is intended also use different methods
of learning to analyze situations such as: (i) explore
the most distant states the goal, where exploration is
less intense and; (ii) use a heuristic function, which a
priori could accelerate the convergence of algo-
rithms, where a heuristic policy indicate the choice
of the action taken and, therefore, limit the agent of
the search space. It is intended to further evaluate
the method in dynamic environments and with
greater variations states.
4.1 Real-world Applications
The hybrid model proposed in this paper has been
tested in scenarios in which it was possible to con-
trol all the environmental variables. In many real-
world problems, you cannot always control the fac-
tors that affect the system, such as external variables
to the environment. With the promising results of the
hybrid model presented in this article, we started to
adapt this model to a real case to support the daily
decisions of the poultry farmer. In this problem, the
agent of the system is used to generate action poli-
cies, in order to control the set of factors in the daily
activities, such as food-meat conversion, amount of
food to be consumed, time to rest, weight gain, com-
fort temperature, water and energy to be consumed,
etc. The main role of the agent is to perform a set of
actions to consider aspects such as productivity and
protability without compromising bird welfare.
Initial results show that, for the decision-taking pro-
cess in poultry farming, our model is sound, advan-
tageous and can substantially improve the agent ac-
ICEIS 2016 - 18th International Conference on Enterprise Information Systems
60
tions in comparison with equivalent decision when
taken by a human specialist. In the moment, we are
evaluating the performance of the agent when han-
dling specic management situations; checking the
performance of the algorithm to process variations
of scenario; and changing the set of attributes used
to generate the rules, which can make them less sus-
ceptible to inuence. Such statements are objects of
study for future research.
ACKNOWLEDGEMENTS
This research has been supported by Araucária
Foundation and National Council for Scientific and
Technological Development (CNPq), under grants
numbers 378/2014 and 484859/2013-7 respectively.
REFERENCES
Chakraborty, D. and Stone, P. (2014). Multiagent learning
in the presence of memory-bounded
agents. Autonomous Agents and Multi-Agent Systems,
28(2):182–213.
Chapelle, J., Simonin, O., and Ferber, J. (2002). How situ-
ated agents can learn to cooperate by monitoring their
neighbors’ satisfaction. ECAI, 2:68–78.
DeLoach, S. and Valenzuela, J. (2007). An agent envi-
ronment interaction model. In Padgham, L. and
Zambonelli, F., editors, Agent-Oriented Software En-
gineering VII, volume 4405 of Lecture Notes in Com-
puter Science, pages 1–18. Springer Berlin Heidel-
berg.
Devlin, S., Yliniemi, L., Kudenko, D., and Tumer, K.
(2014). Potential-based difference rewards for multia-
gent reinforcement learning. In Proceedings of
the 2014 International Conference on Autonomous
Agents and Multi-agent Systems, AAMAS ’14, pages
165–172, Richland, SC. International Foundation for
Autonomous Agents and Multiagent Systems.
Efthymiadis, K. and Kudenko, D. (2015). Knowledge
revision for reinforcement learning with abstract
mdps. In Proceedings of the 2015 International Con-
ference on Autonomous Agents and Multiagent Sys-
tems, AAMAS ’15, pages 763–770, Richland, SC. In-
ternational Foundation for Autonomous Agents and
Multiagent Systems.
Grze’s, M. and Hoey, J. (2011). Efficient planning in
rmax. In The 10th International Conference on Auton-
omous Agents and Multiagent Systems - Volume 3,
AAMAS ’11, pages 963–970, Richland, SC. Interna-
tional Foundation for Autonomous Agents and Multi-
agent Systems.
Kaelbling, L. P., Littman, M. L., and Moore, A. P. (1996).
Reinforcement learning: A survey. Journal of Artifi-
cial Intelligence Research, 4:237–285.
Ribeiro, R., Borges, A., and Enembreck, F. (2008). Inter-
action models for multiagent reinforcement learning.
In Computational Intelligence for Modelling Control
Automation, 2008 International Conference on, pages
464–469.
Ribeiro, R. and Enembreck, F. (2013). A sociologically
inspired heuristic for optimization algorithms: A case
study on ant systems. Expert Systems with Applica-
tions, 40(5):1814 – 1826.
Ribeiro, R., Enembreck, F., and Koerich, A. (2006). A
hybrid learning strategy for discovery of policies of
action. In Sichman, J., Coelho, H., and Rezende, S.,
editors, Advances in Artificial Intelligence -
IBERAMIASBIA 2006, volume 4140 of Lecture Notes
in Computer Science, pages 268–277. Springer Berlin
Heidelberg.
Ribeiro, R., Ronszcka, A. F., Barbosa, M. A. C., Favarim,
F., and Enembreck, F. (2013). Updating strategies
of policies for coordinating agent swarm in dynamic
environments. In Hammoudi, S., Maciaszek, L. A.,
Cordeiro, J., and Dietz, J. L. G., editors, ICEIS (1),
pages 345–356. SciTePress.
Saito, M. and Kobayashi, I. (2016). A study on efficient
transfer learning for reinforcement learning using
sparse coding.
Automation and Control Engineering,
4(4):324 – 330.
Stone, P. and Veloso, M. (2000). Multiagent systems: A
survey from a machine learning perspective. Autono-
mous
Robots, 8(3):345–383.
Sutton, R. S. and Barto, A. G. (1998). Reinforcement
Learning : An Introduction. MIT Press.
Tesauro, G. (1995). Temporal difference learning and
tdgammon. Commun. ACM, 38(3):58–68.
Walsh, T. J., Goschin, S., and Littman, M. L. (2010). Inte-
grating sample-based planning and model-based rein-
forcement learning. In Fox, M. and Poole, D., editors,
AAAI. AAAI Press.
Watkins, C. J. C. H. and Dayan, P. (1992). Q-learning.
Machine Learning, 8(3):272–292.
Xinhai, X. and Lunhui, X. (2009). Traffic signal control
agent interaction model based on game theory
and reinforcement learning. In Computer Science-
Technology and Applications, 2009. IFCSTA ’09. In-
ternational Forum on, volume 1, pages 164–168.
Xuan, P. and Lesser, V. (2002). Multi-Agent Policies:
From Centralized Ones to Decentralized Ones. Pro-
ceedings of the 1st International Joint Conference
on Autonomous Agents and Multiagent Systems, Part
3:1098–1105.
Zhang, C. and Lesser, V. (2010). Multi-Agent Learning
with Policy Prediction. In Proceedings of the
24th AAAI Conference on Artificial Intelligence, pages
927–934, Atlanta.
Zhang, C. and Lesser, V. (2013). Coordinating Multi-
Agent Reinforcement Learning with Limited Commu-
nication. In Ito, J. and Gini, S., editors, Proceedings of
the 12th International Conference on Autonomous
Agents and Multiagent Systems, pages 1101–1108, St.
Paul, MN. IFAAMAS.
A Hybrid Interaction Model for Multi-Agent Reinforcement Learning
61
