A Comparative Study of Programming Agents in POSH and GO AL

Rien Korstanje

, Cyril Brom

, Jakub Gemrot

and Koen V. Hindriks

Delft University of Technology, EEMCS, Delft, The Netherlands

Charles University in Prague, Faculty of Mathematics and Physics, Czech Republic

Keywords:

Agent Programming, User Study, Novice Programmers, Advanced Programmers, Virtual Environment.

Abstract:

A variety of agent programming languages have been proposed but only few comparative studies have been

performed to evaluate the strengths and weaknesses of these languages. In order to gain a better understanding

of features in and their use by programmers of these languages, we perform a study which compares the

two languages GOAL and POSH. The study aims at advancing our knowledge of the beneﬁts of using agent-

oriented languages and at contributing to the evolution of these languages. The main focus of the study is on

the usability of both languages and the differences between novice and more advanced programmers that use

either language. As POSH requires Java programming experience, we expected novice POSH programmers

to perform better on the tasks than novice GOAL programmers whereas we hypothesized this difference would

not be observed between more advanced programmers. However, results suggest that there is no signiﬁcant

difference. The study does suggest that general experience and tooling support can make a difference. Analysis

of the tasks and the observations made about the use of the languages, moreover, suggests ways to improve

the experimental design in such a way that differences in usability of the frameworks could be established.

1 INTRODUCTION

A variety of agent programming languages have been

proposed in the literature, see e.g., (Bordini et al.,

2005; Bordini et al., 2009), but only few comparative

studies have been performed to evaluate the strengths

and weaknesses of these languages. In order to gain

a better understanding of the use of language fea-

tures by programmers it is important to perform stud-

ies on various programming tasks in these languages.

Such studies advance our knowledge of the beneﬁts of

agent-oriented programming and may contribute pos-

itively to the evolution of the paradigm.

In this paper we report on a study we performed in

which the agent programming languages GOAL (Hin-

driks, 2009) and POSH (Brom et al., 2006) are com-

pared empirically. Both languages take a different

approach to agent programming. GOAL is a rule-

based language for programming the decision mak-

ing of cognitive agents that uses an embedded logical

language for knowledge representation (e.g., Prolog).

POSH is based on Behaviour Oriented Design and

distinguishes between two layers: a high level rule-

This work also has been presented at the Second AA-

MAS Workshop on Cognitive Agents and Virtual Environ-

ments (2013)

based planning layer on top of a layer that provides

support for executing low level actions and senses.

The main aim of the study has been to analyse

whether the different set of language features pro-

vided impact the performance of programmers on the

same set of tasks. Moreover, we are interested in gain-

ing a better understanding of the learning curve as-

sociated with agent-oriented programming languages.

Given that the POSH framework builds directly on

top of Java whereas the GOAL language uses Pro-

log for representing knowledge, we hypothesized that

the learning curve would be less steep for POSH than

for GOAL. More in particular, we expected novice

programmers in POSH to perform better than novice

GOAL programmers. For the coding tasks that we de-

signed, we expected this difference to disappear for

more advanced programmers that received more ex-

tensive training in programming in either language.

The study consists of a comprehension task and a

number of increasingly more complex coding tasks.

The coding tasks involved programming an agent that

controls a character in a virtual environment called

Emohawk that runs on top of the Unreal engine. Emo-

hawk provides a fairly complex environment but is

not as complex as the Unreal Tournament gaming

environment. Using Emohawk enabled us to design

192

Korstanje, R., Brom, C., Gemrot, J. and Hindriks, K.

A Comparative Study of Programming Agents in POSH and GOAL.

DOI: 10.5220/0005799601920203

In Proceedings of the 8th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2016) - Volume 2, pages 192-203

ISBN: 978-989-758-172-4

challenging but not too complex tasks. A basic agent

program was provided to start with that subjects could

inspect ﬁrst and extend thereafter. By providing a

basic program not only a useful starting point was

provided but time needed to complete the tasks was

also reduced. Subjects were asked to extend the basic

agent in a number of consecutive coding tasks. Dur-

ing the experiment we collected data on the time it

took to complete each task and asked participants to

rate the usefulness of language features.

The paper is organized as follows. Section 2 dis-

cusses related work. In Section 3 we brieﬂy discuss

the virtual environment used in our study whereas

Section 4 compares the agent programming languages

used. In Section 5 we discuss the experimental design

of the study. Section 6 presents results, which are fur-

ther discussed in Section 7. Section 8 concludes.

2 RELATED WORK

In this paper we report empirical results that allow us

to compare two agent programming languages. We

can also compare agent programming languages an-

alytically and we mention two examples of work in

that area. (Hindriks et al., 1998) formally compare

the agent languages AgentSpeak(L) and 3APL and

shows that the former can be embedded into the lat-

ter. It follows that 3APL is at least as expressive as

AgentSpeak(L) and any program that can be writ-

ten in AgentSpeak(L) can also be coded in 3APL

to do the same task but not necessarily vice versa.

(Bryson, 2003) presents a theoretical comparison be-

tween POSH and other action selection mechanisms

such as Environmental Determinism, Finite State Ma-

chines and Basic Reactive Plans. POSH was found to

be more expressive than these other frameworks for

programming reactive agents.

We brieﬂy discuss some related studies that also

aim at empirically evaluating agent programming lan-

guages. (Lillis et al., 2012) evaluate a toolkit called

ACRE for conversation management between agents.

The focus of this study is on agent communication

and compares the performance of subjects that used

the toolkit with subjects that did not have access to

it. Results suggest that the toolkit can improve code

quality and reduces the code base but not necessarily

effort. The Agent Factory platform was used in the

study but use of language features was not analyzed.

(van Riemsdijk et al., 2012) present a qualitative

analysis of multi-agent programs for UNREAL TOUR-

NAMENT written in GOAL by ﬁrst year BSc computer

science students. The aim of the study was to gain in-

sight into practical aspects of agent development and

to better understand some of the problems that agent

programmers face. The method used in (van Riems-

dijk et al., 2012) has been to analyse the multi-agent

program code that was developed by the students. The

paper discusses the actual use of language features in

this code. The study did not involve an experimental

design with programmers as subjects nor a compari-

son with other languages.

Agent programming languages have been empiri-

cally compared in only a few studies. (Gemrot et al.,

2012b; Gemrot et al., 2012a) aimed at evaluating

differences between programming agents in Java or

POSH for the virtual environment Emohawk. The

study, however, found that subjects using POSH and

those using Java performed similarly. Both studies

asked subjects to write code from scratch, i.e., no

code was provided initially. The second study also

included a comprehension task. Both studies lasted

eight hours, making fatigue a potential factor that may

have inﬂuenced the results found.

As we use a virtual environment called Emohawk

that runs on top of the Unreal gaming engine, we

brieﬂy mention related work in the area of program-

ming gaming agents. (Heckel et al., 2009) evaluated

a tool called BehaviorShop and showed that the IDE

allowed users with little to no experience in Artiﬁcial

Intelligence to create high-level behaviors that con-

trol virtual characters. Subjects that were only given

a brief lecture on the basic concepts of BehaviorShop

were able to create fairly complex interactions. In our

study we also found that, given more general experi-

ence with programming, a short tutorial was sufﬁcient

for subjects to code agents that control virtual charac-

ters. Our study is comparative, however, and different

from (Heckel et al., 2009) it also investigates which

language features are used.

3 EMOHAWK ENVIRONMENT

A challenging aspect of designing a comparative

study for agent languages concerns the choice of en-

vironment with which the agents interact. Toy ex-

amples, such as the Blocks World discussed in (van

Riemsdijk et al., 2012), for example, do not call for

the use of more advanced features of a language,

whereas the use of complex gaming environments

such as UNREAL TOURNAMENT may pose too many

challenges for a programmer to solve within the nec-

essarily limited time available during an experiment

(Gemrot et al., 2012a; Gemrot et al., 2012b).

For our study we have chosen to use the Emo-

hawk environment. Similar to UNREAL TOURNA-

MENT, Emohawk runs on top of the Unreal engine.

A Comparative Study of Programming Agents in POSH and GOAL

193

But it provides a very different environment featur-

ing a small town with several locations of interest and

several characters that can display text, emoticons and

animations (B

ıda and Brom, 2010). The size of the

Emohawk environment is small compared to maps in

UNREAL TOURNAMENT and thus presents less of a

challenge than the UNREAL TOURNAMENT game.

Like UNREAL TOURNAMENT, Emohawk is ac-

cessible through a software environment called Poga-

mut. Pogamut provides functionality to manage char-

acters in the Emohawk environment by means of

modules. These modules provide a wide range of

functionality and support various forms of locomo-

tion, displaying emotions, communication with other

bots, information, etc. They also manage information

about the world and allow an agent to query this infor-

mation. By combining modules, an agent can be pro-

grammed to do more complex tasks. For example, an

agent can request the Players module for the nearest

visible player (character) and then tell the Navigation

module to bring another character to that player.

For comparing the performance of GOAL and

POSH programmers, an environment should be used

that provides similar access to environment primitives

in both cases. This poses an additional (technical)

challenge as agents written in either language must be

able to interact with the same environment in a similar

way. Even though this concerns a mainly technical as-

pect of our study, the way access is provided to the en-

vironment thus needs to be carefully designed to make

sure that connecting to the environment does not sig-

niﬁcantly change the tasks that subjects are asked to

complete. This also rules out, for example, the use

of the UNREAL TOURNAMENT gaming environment

in our study because of the signiﬁcant differences be-

tween the interfaces that are available for connecting

GOAL and POSH to this environment.

We have used Pogamut for connecting both GOAL

and POSH to the Emohawk environment. POSH is in-

tegrated with Pogamut and can connect directly with

it. In order to connect GOAL to Emohawk, an en-

vironment interface had to be designed and created

that provides similar functionality. We used the En-

vironment Interface Standard for this (Behrens et al.,

2011). In order to make the same functionality pro-

vided by Pogamut available for GOAL and POSH

programmers, we restricted the set of Pogamut mod-

ules that were made available in POSH to those that

were present in the interface designed for GOAL or

for which similar functionality could be provided in

GOAL otherwise. Technically, this was realised for

POSH by creating a custom context that provides ac-

cess to the selected modules. For GOAL, the same

functionality was either made available through per-

cepts and actions in the interface or via Prolog code.

The Prolog code in a GOAL agent represents knowl-

edge that is provided by Pogamut modules that oper-

ate on more basic data available in the environment.

4 LANGUAGES USED: GOAL &

POSH

Before we proceed, we introduce the main features of

the agent programming languages GOAL and POSH

used in our study and provide a brief comparison

which highlights the main differences and similarities

between the languages.

4.1 The GOAL Programming Language

GOAL is a logic-based agent programming language

for programming cognitive agents (GOAL, 2015;

Hindriks, 2009). GOAL agents maintain a mental

state that consists of beliefs and goals. Agents de-

rive their choice of action from their beliefs and goals.

GOAL agents also use a knowledge base to repre-

sent conceptual and domain knowledge. The version

of GOAL used in this study uses Prolog, a declara-

tive programming language used for representing the

knowledge, beliefs, and goals of an agent. A Prolog

program consists of Horn clauses, which are logical

rules and simple facts (Shapiro and Sterling, 1994).

GOAL is a rule-based language. The design phi-

losophy of GOAL is that writing agent programs es-

sentially means writing rules that determine for each

situation that the agent ﬁnds itself in what it should do

in that situation. Rules are ordered which allows for

imposing a priority on what needs to be done ﬁrst.

GOAL agents execute a reasoning cycle that con-

sists of two phases. The purpose of the ﬁrst phase is to

process all events such as percepts and messages and

make sure that the agent’s mental state is up-to-date.

In this phase the GOAL agent retrieves and processes

all perceptual information available from the environ-

ment to update the beliefs and goals of the agent. In

the second phase of the cycle agents decide what to do

next. Typically, in this phase one environment action

is selected and sent to an environment.

The concept of a module is a key programming

construct in GOAL for structuring and writing larger

agent programs. A module basically is a container for

a set of rules. A GOAL agent program then is a set

of modules. The event module corresponds to the

ﬁrst phase in the agent’s cycle and is designed to sup-

port event processing whereas the main module corre-

sponds to the second phase and is designed to support

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

194

decision making. In addition, a special init mod-

ule is available for initialising the mental state and

other components of an agent. A programmer can

also add and write its own set of modules for structur-

ing and organizing code. GOAL also provides support

for communication between agents.

The GOAL language is distributed with an Inte-

grated Development Environment for coding, testing,

and debugging in the Eclipse environment. It pro-

vides the usual program editing tools as well as tools

to analyse and debug code.

4.2 The POSH Programming Language

POSH is a reactive action selection mechanism intro-

duced in (Bryson, 2001) to simplify the construction

of action selection for modular AI; see (Gemrot et al.,

2012b) for details on the POSH language. A pro-

grammer used to thinking about conventional sequen-

tial programs is asked to ﬁrst consider a worst-case

scenario for his/her agent, then to break each step of

the plan to resolve that scenario into a part of a re-

active plan. Succeeding at a goal is the agent’s high-

est priority and attempted whenever the agent can. It

is the task of the programmer to write code that al-

lows an agent to recognize that it can meet a goal.

This needs to be done for all sub-goals: A perceptual

condition must be speciﬁed that allows the agent to

recognize if it can take an action that makes progress

towards its goal (Bryson, 2001). Actions are small

code chunks that control the agent brieﬂy, so-called

behaviour primitives.

(Bryson, 2003) provides a development method-

ology called Behaviour Oriented Design (BOD) for

developing POSH agents. BOD emphasizes the

above development process, and also the use of be-

haviour modules written in ordinary object-oriented

languages (in our case, in Java) to encode the ma-

jority of the agent’s intelligence, including its mem-

ory. These modules provide the behaviour and sen-

sory primitives; methods calls are the interface be-

tween a high-level POSH plan and the low-level code

of the behaviour modules. A POSH plan can be orga-

nized hierarchically in a tree-like structure.

Technically, a plan consists of production rules,

very similar to modules in GOAL. Rules are also or-

dered by priority. In POSH, the antecedent or condi-

tion of a rule is a method call (i.e., a sensory primi-

tive). The head of a rule is either a method call, i.e.,

a behaviour primitive, or a set of sub-rules also called

a competence. At run-time, a POSH plan is periodi-

cally evaluated in order to determine the action, i.e.,

which behaviour primitive, the agent should execute.

A graphical editor for POSH plans is available and

used in the present study.

4.3 Comparison

It is clear that GOAL and POSH share some features

for writing agent programs that are similar. Both lan-

guages, for example, are rule-based. Rules are used in

GOAL as well as in POSH for deciding which action

the agent has to perform in a particular situation. Even

though the terminology used differs, we can at least

conceptually compare language features. In order to

enable comparison, we introduce ﬁve important con-

cepts related to programming agents and discuss how

each language provides support for these concepts.

The Agent’s State. A state represents everything

that the agent knows about its environment. A

POSH agent maintains a state by means of various

Java modules which process messages received

from the Pogamut environment that enables con-

trolling characters in Emohawk (see also Sec-

tion 3). A GOAL agent maintains a mental state

by processing percepts received from the Emo-

hawk environment via an environment interface

that connects the agent to the Pogamut environ-

ment. A GOAL agent not only updates its beliefs

but may also update its goals when it receives new

percepts.

The Plan. In both languages, a plan consists of

condition-action rules that allow an agent to de-

cide on what to do next given its current state. In

GOAL such a set of rules is called a module. In

POSH such a set of rules is called a POSH plan.

Rule Conditions. Rules are condition-action rules.

Rule conditions in GOAL consist of Prolog

queries performed on the agent’s beliefs and/or

goals. Conditions of POSH rules cannot directly

query the agent’s state but use so-called ‘senses’

to evaluate rule conditions.

Rule Actions. POSH rules contain primitive and ag-

gregate actions. Through primitive actions POSH

has access to a large number of high and low

level actions provided by Pogamut (Gemrot et al.,

2009). A GOAL agent only has access to actions

that are provided by means of an environment in-

terface. In our study, that means that a GOAL

agent cannot directly access actions that are made

available by the Pogamut environment and only

has access to actions in that environment that are

made available explicitly in the environment in-

terface used by the agent.

Perception. In GOAL the event module can be used

to process percepts and store facts in the mental

A Comparative Study of Programming Agents in POSH and GOAL

195

state. POSH has no such feature and relies on

functionality provided by Pogamut to do this.

5 EXPERIMENTAL DESIGN

In our study, we compared how programmers

used two agent programming languages. Subjects

also used the Integrated Development Environments

(IDEs) that were available for both languages. Sub-

jects were provided with an initial agent and asked

to complete several tasks which measured their abil-

ity to comprehend and modify agent program code.

The coding tasks were divided into several sub-tasks

that each built on the results of the previous task.

Subjects were also asked to complete three question-

naires. Subjects were asked to program in either

GOAL or POSH, and based on their experience classi-

ﬁed as either novice or (more) advanced programmer.

We thus have four different groups: GOAL novices,

advanced GOAL programmers, POSH novices, and

advanced POSH programmers.

5.1 Aim of the Study and Hypotheses

The aim of the study is to establish whether there are

differences related to the usability of the program-

ming languages GOAL and POSH. More speciﬁcally,

we are interested in the learning curve of both lan-

guages. We therefore looked in particular at differ-

ences between novices that just started learning a lan-

guage and more advanced programmers that had re-

ceived more extensive training and practice.

The ﬁrst hypothesis we formulated relates to the

question how quickly programmers are able to famil-

iarize themselves with either GOAL or POSH and how

long it takes before they can successfully complete

a coding assignment. We speculated that because

POSH requires programming in Java, a language fa-

miliar to all participants, and GOAL requires pro-

gramming in Prolog, novices would do better when

using POSH rather than GOAL. This seems a rea-

sonable hypothesis given that Prolog is perceived as

difﬁcult to learn for novices (Pane and Myers, 1996).

Moreover, POSH plans, a key feature of the language,

are represented visually which is generally considered

to facilitate novice programmers. We thus hypothe-

sized that there would be a difference in the learning

curve which would it make easier for POSH novices

to perform well on the tasks of our study.

Hypothesis I. POSH novices perform better on all

tasks than GOAL novices.

Here, performance is measured in terms of success-

fully meeting the criteria of the task (see below) and

the time-to-complete. Generally, time-to-complete is

considered a relevant measure for establishing differ-

ences in usability.

As discussed, both GOAL and POSH provide sim-

ilar though distinct language features for program-

ming an agent at a conceptual level. Both languages

provide the features needed for solving the tasks of

the study. For a programmer that has been rela-

tively well familiarized with either language, given

the quite reasonable complexity of the tasks, we ex-

pected therefore that it should be possible to perform

well on these tasks. For this reason, we did not ex-

pect advanced programmers to perform very differ-

ently. Therefore we hypothesized that more experi-

enced programmers would achieve similar results in

more or less the same time. In case we would ob-

serve different performance, we would take this as an

indicator that there would be a real and signiﬁcant dif-

ference between the languages.

Hypothesis II. Advanced POSH and GOAL pro-

grammers perform similarly on all tasks.

Finally, given that novice and more advanced pro-

grammers participated, we hypothesize that advanced

programmers outperform novices. This does not nec-

essarily have to be the case as advanced programmers

may complicate things more than novices but seems a

very reasonable assumption to make.

Hypothesis III. Advanced programmers outperform

novices on all tasks.

5.2 Tasks

In task-based evaluations, the relevance of the results

depends directly on the relevance of the tasks with

respect to the purpose of the study. Given that we

want to compare two agent programming languages,

the design of relevant tasks is a challenge. In order

to be able to perform a reasonable comparison, we

need to avoid very basic or trivial tasks but at the same

time design tasks that can be performed within a rea-

sonable amount of time. (Gemrot et al., 2012b) il-

lustrates that it is difﬁcult to strike the right balance

and report that in their comparative study of POSH

and Java subjects became fatigued during an 8 hour

session and could not successfully complete the given

task. To avoid problems like this, we decided that the

duration of the experiment should not take longer than

4 hours. Moreover, multiple tasks were designed that

aim to measure performance on different skills, in-

cluding program comprehension and code writing. A

between-subjects design was used, i.e., each subject

was asked to complete the tasks only in one language.

Due to time constraints in general and the inexpe-

rience of the novice users, for the coding tasks, we did

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

196

not consider it feasible for subjects to create a rather

complex agent from scratch. Therefore the choice

was made to ask subjects to extend a given agent, by

means of a set of incremental tasks. Each consecutive

task was designed to be more difﬁcult, starting with a

rather basic task and ending with a task that required

coding of more complex behaviour.

At the start of the experiment, subjects were pro-

vided with some time to familiarize themselves with

the development environment of the language and

were asked to run a given agent connected to the Emo-

hawk environment. This allowed subjects to try and

play with the software they were asked to use for com-

pleting the tasks. At this stage, we could provide

additional explanation where needed, address ques-

tions, or resolve potential issues and thus make sure

that very basic issues unrelated to the study would not

arise during the experiment itself.

Subjects were provided with an initial agent pro-

gram that performs a basic scenario in the Emohawk

environment. The agent controls a virtual character

and makes it do some work at home for a little while

before it then decides to get a cup of coffee. The ac-

tion of working and the need for coffee are graphi-

cally displayed in the environment by means of emoti-

cons. After deciding to get coffee, the agent walks

to the coffee shop, uses emoticons to order a dou-

ble espresso, and then returns home to make a re-

newed attempt to work again. This agent was used

in the comprehension task and provided the starting

point for the coding tasks. To ensure comparable dif-

ﬁculty of the tasks subjects needed to complete, the

agent was written in both POSH and GOAL follow-

ing a predeﬁned speciﬁcation. We also made sure that

the GOAL agent was able to provide similar function-

ality as the Pogamut framework provides (on top of

which the POSH agent runs) by means of adding sev-

eral Prolog rules as knowledge to this agent. For more

details on the tasks and the instructions that subjects

received, please see the materials we provided to sub-

jects (Materials, 2015).

Subjects were also provided with the documen-

tation that is distributed with GOAL and POSH. For

POSH, this material consists of the Pogamut source

code and documentation accessible through the IDE.

For GOAL, its programming manual and a manual

of the environment is provided. The lecture materi-

als from the tutorial that introduced the language to

novices were also provided to all subjects.

The experiment consists of two parts: the ﬁrst part

concerns a program comprehension task and the sec-

ond part involved code writing.

5.2.1 Comprehension Task

For the comprehension task, subjects were provided

with an agent that controls an entity in the Emohawk

environment as discussed above that was written in

either GOAL or POSH. They were asked to examine

the program code and to answer a number of ques-

tions about the behaviour that the agent will display,

the ﬂow of control of the agent, the structure of the

program code, and the interpreter that executes the

agent. The comprehension task was designed to mea-

sure how well subjects comprehend the agent pro-

gram provided to them. It also allowed subjects to fa-

miliarize themselves with the program code that they

needed to extend in subsequent tasks.

5.2.2 Coding Tasks

In the coding tasks subjects were asked to extend the

agent program they examined during the comprehen-

sion task in various ways. The tasks were presented

in order of increasing complexity and each task builds

on results obtained in the previous task. The main aim

of this incremental set of tasks is to create an agent

that implements the following scenario in the Emo-

hawk environment: two people (entities controlled by

agents) meet in a park, have a conversation, and there-

after visit the cinema together. The ﬁve coding tasks

asked subjects to write code that:

1. makes the agent walk to the park, a location in the

Emohawk environment,

2. makes the agent walk from that location to the cin-

ema,

3. creates a second agent that is able to do the same

(1,2 above) and makes the agents wait for each

other in the park,

4. simulates a conversation between both agents, and

5. makes the agents walk side by side to the cinema.

Subjects were asked to write down the time they

ﬁnished a question or task. This provided us with a

measure of progress for all subjects throughout the

experiment. To check whether subjects successfully

completed a task we ran the agent, observed its be-

haviour, and checked whether this behaviour met a

predeﬁned list of criteria.

5.3 Questionnaire

Subjects were asked to complete three questionnaires

to collect qualitative data. One questionnaire was

given before the actual experiment, one questionnaire

was given in between the two main parts of the ex-

periment, and one questionnaire was given after com-

A Comparative Study of Programming Agents in POSH and GOAL

197

pleting the coding tasks (or when time ran out). Each

questionnaire took about 15 minutes.

5.3.1 Experience Questionnaire

The ﬁrst questionnaire we designed to obtain informa-

tion about the subject (e.g., age), about prior program-

ming experience in relevant languages, and about

their experience with popular IDEs (e.g., Eclipse).

Subjects were asked to rate their own skill in pro-

gramming with Java, Prolog, POSH, and GOAL. Java

is required for programming a POSH agent but also

gives a subjective rating of programming experience

in a common and popular language that is used exten-

sively in education at both universities where students

were recruited. Experience with Prolog is needed to

program a GOAL agent.

The results from this questionnaire also provided

us with a means to check whether the different groups

that got different treatments (based on the various ex-

perimental conditions) were balanced in the following

sense. Groups should have more or less the same ex-

perience in programming, should be familiar with at

least one popular IDE, and age should be similarly

distributed over groups.

5.3.2 Post Comprehension Questionnaire

The second questionnaire was given to subjects af-

ter they ﬁnished the comprehension task. This ques-

tionnaire asked subjects to rate on a ﬁve point Likert

scale (strongly disagree to strongly agree) how useful

they found selected language features for understand-

ing the agent program provided to them. Questions

were posed in the form “was feature X helpful”. Sub-

jects could also select a “not applicable” option for

each feature. Additionally, they were asked to explain

their rating in words.

5.3.3 Post Coding Questionnaire

After completing the second set of coding tasks, a ﬁ-

nal questionnaire was handed out to subjects. This

questionnaire asked subjects to rate the usefulness of

a language feature for completing the coding tasks.

For each feature they were asked to rate their agree-

ment with the question “was feature X helpful” on a

ﬁve point Likert scale (strongly disagree to strongly

agree). For each question there also was the option to

select “not applicable”. Additionally, subjects were

asked to explain their rating.

5.4 Treatments and Subjects

Based on the use of either GOAL or POSH and the

level of experience, we obtain four treatments: (i)

POSH novice, (ii) GOAL novice, (iii) advanced POSH

programmer, and (iv) advanced GOAL programmer.

We use ‘novice’ and ‘advanced’ here in the sense that

subjects that we label ‘novice’ had little experience

with a languages whereas ‘advanced programmers’

had received a more extensive training. Subjects as-

signed to the novice condition were only given an in-

troductory tutorial on GOAL or POSH of about two

hours well before the experiment took place. The tu-

torial consisted of a basic lecture on language features

that were needed to complete tasks and a demonstra-

tion of how to use the IDE of the language.

Subjects for the study were recruited from stu-

dents attending University Delft University of Tech-

nology with experience in GOAL and students from

University Charles University in Prague having ex-

perience with POSH.

None of the Delft Univer-

sity students were familiar with POSH and only very

limited experience with GOAL was reported by the

Prague University students. Therefore, we could as-

sign Prague University students to the GOAL novice

treatment and Delft University students to the POSH

novice treatment. GOAL novices should at least have

some experience with Prolog whereas POSH novices

should at least have some experience with Java. Re-

sults shown in Table 1, obtained from the ﬁrst ques-

tionnaire where subjects were asked to report on their

own programming experience in terms of man months

a language had been used, demonstrate that this was

indeed the case. From self-reports on the use of either

language and the skill rating we also can conclude that

the subjects assigned to the expert treatments indeed

were more advanced than the other students (e.g., skill

is rated signiﬁcantly higher; p

GOAL

< 0.005, p

POSH

0.005).

28 students from Charles University participated.

For 18 of these students participating in the experi-

ment was part of their ﬁnal exam and students were

graded on the performance of their agent. These stu-

dents were assigned to the advanced POSH program-

mers condition. The other 10 students voluntarily

signed up for the experiment and were assigned to the

GOAL novice condition. 11 students from Delft Uni-

versity of Technology participated, all of which vol-

All Delft students participated in the Multi-

Agent Systems course in which GOAL is taught, see

http://ii.tudelft.nl/trac/goal/wiki/Education. All Prague

students participated in the course Artiﬁcial Beings (Brom,

2009) in which POSH is taught. Students took part in the

study at the end of or directly after completing the course.

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

198

Table 1: Self-reports on Experience and Skill.

Novice Expert

GOAL Usage 0.2 (0.3) 0.7 (0.3)

GOAL Skill 1.5 (0.6) 2.8 (1.1)

Prolog Usage 1.8 (2.2) 0.7 (0.3)

Prolog Skill 2.2 (1.2) 3.0 (1.0)

POSH Usage 0.0 (0.0) 0.3 (0.4)

POSH Skill 1.0 (0.0) 2.5 (0.8)

Java Usage 5.5 (4.4) 2.6 (2.9)

Java Skill 3.6 (0.5) 2.5 (1.3)

unteered. These were divided equally over the POSH

novice (6 students) and advanced GOAL programmers

(5 students) condition, stratiﬁed by the results of a

Java skill test. All subjects were given an incentive

with an equivalent value of 20 Euros.

The total of 39 students that participated included

4 women and 35 men. Analysis of age shows there

is a clear difference in age distribution (one way

ANOVA, p < 0.001; F = 15.01) between groups as-

signed to different conditions. This was the case be-

cause, contrary to the expectations, a large number of

senior students enrolled in the course in Prague from

which subjects were recruited. Finally, analysis of ex-

perience with IDEs shows that almost all students ex-

cept for a few students assigned to the GOAL expert

condition had experience with either the Eclipse, Net-

beans or Visual Studio IDE.

6 RESULTS

In this Section, we report on the use of language fea-

tures by and the performance of subjects in the ex-

periment. For both language usage as well as per-

formance (time-to-complete) self-reports of subjects

were used. The data obtained from Likert scale ques-

tions is presented by the associated mean and standard

deviation which indicates the general tendency of a

group assigned to one of the four treatments. Com-

parisons between treatments are analyzed using chi-

square or Fisher’s-Exact test whenever the categorical

minimum was not reached.

6.1 Comprehension Task

The comprehension task provided little difﬁculty for

any of the subjects. Figure 1 shows that all partici-

pants ﬁnished this task in roughly the same time (one

way ANOVA, p = 0.707; F = 0.46; time reported in

minutes). Due to the low number of subjects in the

POSH novice and advanced GOAL groups, we report

the individual completion times. Most questions were

Figure 1: Comprehension task.

Figure 2: Coding tasks 1-3.

answered correctly. Only one question (out of 8 ques-

tions) about the number of execution cycles that were

needed to perform a speciﬁc part of program code

turned out to be difﬁcult for novices. This is also

reﬂected in the high self-rated satisfaction with the

completion of the task (3.9 ± 1.1) for all groups.

6.2 Coding Tasks

The coding tasks were considerably more difﬁcult and

not all participants were able to complete all tasks

in time. The difﬁculty of these tasks is also re-

ﬂected in the slightly lower satisfaction ratings (3.4 ±

1.1) for these tasks. In particular, some subjects in

the POSH novice and advanced GOAL programmers

groups were not able to complete the 4th and 5th task.

As we do not have completion times for all subjects,

these tasks are not included in the discussion below.

The 4th coding task, simulating a conversation us-

A Comparative Study of Programming Agents in POSH and GOAL

199

ing emoticons, was found to be difﬁcult for quite a

number of subjects. Most of these subjects had prob-

lems with coding the right length that the emoticons

should be displayed. The 5th task, where one agent

should be coded to follow another, was difﬁcult for

all subjects. Most subjects had problems with estab-

lishing in their code that the the ﬁrst agent should start

following the other agent (task 5). Given that all sub-

jects had trouble with completing this task, the task

may have been too challenging.

Analysing the cumulative completion times for

the ﬁrst three tasks (see Figure 2), the advanced POSH

and GOAL novice groups from Prague use signiﬁ-

cantly less time than the groups from Delft Univer-

00:00 00:14 00:28 00:43 00:57 01:12 01:26 01:40 01:55 02:09 02:24

Duration vs Age

GOAL Expert POSH Expert POSH Novice GOAL Novice

Duration (hh:mm)

Age

Figure 3: Cumulative time-to-complete versus age.

00:00 00:14 00:28 00:43 00:57 01:12 01:26 01:40 01:55 02:09 02:24

Duration vs Years Enrolled

GOAL Expert POSH Expert POSH Novice GOAL Novice

Duration (hh:mm)

Years Encrolled

Figure 4: Cumulative time-to-complete vs years enrolled.

00:00 00:14 00:28 00:43 00:57 01:12 01:26 01:40 01:55 02:09 02:24

Duration vs Years Programming Experience

GOAL Expert POSH Expert POSH Novice GOAL Novice

Duration (hh:mm)

Years of Program m ing Experience

Figure 5: Cumulative time-to-complete vs experience.

sity X (p < 0.001; F = 9.31). This may be explained

by difference in age, years of enrolment, and years

of programming experience, but separately these only

moderately correlate (R

of 0.31, 0.26, 0.17, respec-

tively).

Looking more closely at the scatter plots in Fig-

ures 3, 4, and 5 shows that there are clear outliers for

each of the three plots, including in total 5 subjects of

the POSH novice and advanced GOAL programmers

groups. While there is a difference in performance

between the groups from Delft and Prague Univer-

sity, further analysis with Tukeys HSD shows there is

little difference within these groups (p

Del f t

= 0.77;

Prague

= 0.99). The programming language thus

does not appear to inﬂuence the completion times for

the subjects from Prague University. A similar obser-

vation applies to the subjects from Delft University

but due to the low number of subjects no ﬁrm conclu-

sion can be drawn here.

6.3 POSH Language Feature Usage

Tables 2 and 3 show the average ratings given by sub-

jects of how useful they found a POSH feature for

the comprehension and coding tasks, respectively; see

Section 4 for discussion of these features. Most sub-

jects used almost all POSH language features while

completing a task. Both novices and advanced pro-

grammers rated features of the language close to a

rating of 4.0 indicating that all features were useful

with only one exception: Advanced programmers did

not ﬁnd the textual representation of POSH plans use-

ful but novices indicated that they did ﬁnd it useful.

Novices also appear to rely more on Java when they

are asked to program more complex agent behaviour.

6.4 Language Features GOAL

Tables 4 and 5 show the ratings given for the useful-

ness of GOAL features. Although all main GOAL lan-

guage features were used for completing the compre-

hension task, this is not the case for the coding tasks.

Generally speaking, advanced programmers use more

GOAL language features except maybe for Prolog (the

knowledge representation language on top of which

GOAL runs). It is not entirely clear how to explain

these ﬁndings but they suggest a difference in learn-

ing curve between POSH and GOAL. Perhaps novices

that used GOAL, which all had initial experience with

Prolog, may more quickly resort to what they already

know than more advanced programmers (a similar ef-

fect was observed for POSH). However, due to the

low number of subjects as well as the presence of out-

liers, it is difﬁcult to draw any ﬁrm conclusions. We

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

200

Table 2: POSH Feature Rating: Comprehension Task.

Novice Advanced

Usage Rating Usage Rating

Senses 100% 4.2 (0.4) 94% 4.2 (0.7)

Actions 100% 4.0 (0.6) 100% 4.2 (0.8)

Plans 100% 4.8 (0.4) 100% 4.6 (0.8)

Textual 100% 3.8 (1.0) 94% 1.8 (0.8)

Java 100% 3.0 (1.2) 83% 2.4 (1.2)

Overall 4.0 (0.0) 4.0 (0.7)

Table 3: POSH Feature Rating: Coding Tasks.

Novice Advanced

Usage Rating Usage Rating

Senses 100% 3.8 (0.4) 100% 3.9 (0.9)

Actions 100% 3.6 (0.5) 100% 3.9 (0.9)

Plans 100% 3.8 (0.4) 100% 3.8 (1.1)

Textual NA NA NA NA

Java 100% 4.4 (0.5) 100% 3.9 (1.3)

Overall 3.8 (1.1) 3.7 (0.8)

Table 4: GOAL Feature Rating: Comprehension Task.

Novice Advanced

Usage Rating Usage Rating

Actions 90% 2.4 (1.2) 80% 3.0 (1.4)

Modules 90% 4.9 (0.3) 100% 4.4 (0.9)

Events 70% 2.3 (1.1) 100% 2.8 (1.1)

Knowledge 100% 2.8 (1.1) 100% 3.4 (1.5)

Prolog 100% 4.3 (0.7) 100% 3.8 (1.3)

Overall 4.6 (0.5) 5.0 (0.0)

Table 5: GOAL Feature Rating: Coding Tasks.

Novice Advanced

Usage Rating Usage Rating

Actions 22% 4.5 (0.7) 80% 3.3 (0.6)

Modules 89% 4.6 (0.5) 100% 4.4 (0.9)

Events 22% 4.0 (0.0) 40% 4.0 (1.4)

Knowledge 67% 4.2 (1.2) 20% 5.0 (N/A)

Prolog 100% 4.6 (0.7) 80% 4.0 (1.4)

Overall 4.4 (0.7) 3.2 (1.3)

are also not completely sure that all language features

were required for completing the tasks.

7 DISCUSSION

The most surprising ﬁnding has been that advanced

POSH programmers as well as GOAL novices (both

subjects from Prague University) completed tasks

much faster than advanced GOAL programmers or

POSH novices (both subjects from Delft University).

As a consequence, contrary to our initial expectations,

all three hypotheses are rejected. In our study, GOAL

novices performed better than POSH novices (and not

vice versa), advanced POSH programmers performed

better than advanced GOAL programmers (and not

similarly), and advanced GOAL programmers did not

clearly outperform GOAL novices.

Nevertheless we can draw some interesting con-

clusions based on our ﬁndings. First, the fact that

Java is used in combination with POSH did not yield a

signiﬁcant difference as we expected. It is important

to note that subjects that used POSH did not exclu-

sively use Java for programming the agent but also

used POSH rules for implementing the agent’s deci-

sion making. Second, an alternative interesting ex-

planation of the performance of subjects from Prague

University is suggested by the fact that these sub-

jects were all more experienced programmers. Our

ﬁndings here suggest that, generally speaking, hav-

ing more programming experience improves perfor-

mance more than additional training in any partic-

ular programming language. One might speculate

whether more experienced programmers have devel-

oped a mental model that is more generally applicable

to arbitrary programming language. However, a sim-

pler explanation may be that they are more experi-

enced in using tools for developing programs. In par-

ticular, we observed that the more advanced program-

mers made more use of various IDE features. Bet-

ter handling of the tooling provided with a language

may be quite beneﬁcial for programming in general,

which would point towards the importance of tool

support. As development of most agent programming

languages has focused more on the language features

than on the tooling to make these languages acces-

sible to programmers, a shift in focus may thus be

called for, although more work is needed to conﬁrm

this.

Given these results and the fact that differences

between GOAL novices and advanced POSH pro-

grammers and between advanced GOAL program-

mers and POSH novices are small, we can conclude

that it remains difﬁcult to establish relations between

language features and programming performance. In

this as well as previous studies that compared POSH

with Java (Gemrot et al., 2012a; Gemrot et al., 2012b)

no signiﬁcant effects of the programming language on

the programmer’s performance was found.

It thus remains difﬁcult to design experimental

tasks for comparative studies of (agent) programming

languages. One issue associated with the experimen-

tal design that we used is the necessarily short amount

of time that is available for completing tasks. Advan-

tages of programming languages that might not show

up in a short study may still manifest themselves in

A Comparative Study of Programming Agents in POSH and GOAL

201

much larger programming projects which take weeks

or even months. Other issues may be more speciﬁc

to the particulars of agent programming languages. It

may, for example, be the case that successfully com-

pleting tasks that involve virtual environments such

as Emohawk require that more time is spend on ob-

serving and testing the agent’s behaviour in that envi-

ronment (if only because virtual characters take more

time to perform actions). A signiﬁcant amount of time

thus may be used to this end compared to the time

that is actually spend on programming. As a conse-

quence, the use of a virtual environment may make it

more difﬁcult to measure the effect of a programming

language on completing a task. Based on observa-

tions during the experiment we do not believe there

has been a signiﬁcant difference in amount of test-

ing for either of the platforms used. For future work,

we therefore suggest to also measure the actual time

spent on various subtasks such as testing.

Finally, some language speciﬁc conclusions may

still be drawn based on the language feature usage

that we observed. An interesting ﬁnding has been

that subjects that programmed in POSH use the plan,

senses and actions language features for completing

the coding tasks. Subjects that programmed in GOAL,

however, can make due with just the modules (con-

sisting of rules) and the knowledge section. These

language features offer more or less the same expres-

sivity and therefore allow programmers to provide the

same functionality by only using these features. This

suggests that for this particular study an agent pro-

gramming language that provides an efﬁcient way to

encode and execute plans that consist of condition-

action rules may be sufﬁcient. Moreover, a likely rea-

son that explains why the event module of GOAL was

not used is that completing the tasks only required

writing of a relatively simple reactive agent that can

derive its behavior directly from the information it

perceives. It may therefore be interesting in future

work to design tasks that require more complicated

decision logic and/or persistent memory in order to

determine when speciﬁc language features are actu-

ally used. Such tasks might reveal differences be-

tween e.g., POSH and GOAL, as tasks in which an

agent is required to infer persistent beliefs from per-

cepts might be harder to write in POSH than in GOAL.

8 CONCLUSION

In this paper, we reported the results of a comparative

study of the agent programming languages GOAL and

POSH. We discussed the design of an experiment that

required subjects to complete both comprehension as

well as coding tasks for an agent that controls a char-

acter in the virtual environment Emohawk. The tasks

were designed such that they could be completed us-

ing either GOAL or POSH. As in other studies we did

not yet ﬁnd conclusive results that suggest the agent

programming language used has a signiﬁcant inﬂu-

ence on programmer performance. We did ﬁnd that

general programming experience seems to be a rel-

atively big advantage when using a (new) program-

ming language. This may in part be due to the experi-

ence of using tooling support to develop code, which

highlights once more the importance of this aspect

when developing agent programming languages.

In addition, we believe that our study provides

several useful clues for the design of future compar-

ative studies that may actually yield concrete results

about the effectiveness of language features incorpo-

rated in a language. In our study the tasks required

programming a purely reactive agent, whereas pro-

gramming a more goal-oriented agent that needs to

use more complicated decision logic and/or persistent

memory may highlight differences between e.g., lan-

guages such as GOAL and POSH more. As GOAL and

POSH are clearly different programming languages

that are used in different ways, more work on the de-

sign of comparative studies is needed to provide in-

sights on the usability of features of these languages.

REFERENCES

Behrens, T. M., Hindriks, K. V., and Dix, J. (2011). To-

wards an environment interface standard for agent

platforms. Annals of Mathematics and Artiﬁcial In-

telligence, 61(4):261–295.

ıda, M. and Brom, C. (2010). Emohawk: learning virtual

characters by doing. Interactive Storytelling, pages

271–274.

Bordini, R., Dastani, M., Dix, J., and El Fallah Seghrouchni,

A. (2009). Multi-agent programming: Languages,

tools and applications, Vol. 15. Berlin: Springer.

Bordini, R., Dastani, M., Dix, J., and Seghrouchni, A.

E. F., editors (2005). Multi-Agent Programming: Lan-

guages, Platforms and Applications. Springer.

Brom, C. (2009). Curricula of the course on modelling be-

haviour of human and animal-like agents. In Proceed-

ings of the Frontiers in Science Education Research

Conference, volume 22, page 24.

Brom, C., Gemrot, J., Bıda, M., Burkert, O., Partington, S.,

and Bryson, J. (2006). Posh tools for game agent de-

velopment by students and non-programmers. In 9th

international conference on computer games: Ai, an-

imation, mobile, educational & serious games, pages

126–135.

Bryson, J. (2001). Intelligence by design: principles of

modularity and coordination for engineering complex

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

202

adaptive agents. PhD thesis, Massachusetts Institute

of Technology.

Bryson, J. (2003). Action selection and individuation in

agent based modelling. In Proceedings of agent, pages

317–330.

Gemrot, J., Brom, C., Bryson, J., and B

ıda, M. (2012a).

How to compare usability of techniques for the spec-

iﬁcation of virtual agents behavior? an experimental

pilot study with human subjects. Agents for Educa-

tional Games and Simulations, pages 38–62.

Gemrot, J., Hl

avka, Z., and Brom, C. (2012b). Does high-

level behavior speciﬁcation tool make production of

virtual agent behaviors better. In Proceedings of the

International Workshop on Cognitive Agents for Vir-

tual Environments (CAVE’12).

Gemrot, J., Kadlec, R., Bda, M., Burkert, O., Pbil, R.,

Havlek, J., Zemk, L., imlovi, J., Vansa, R., tolba,

M., Plch, T., and Brom, C. (2009). Pogamut 3

can assist developers in building ai (not only) for

their videogame agents. In Dignum, F., Bradshaw,

J., Silverman, B., and Doesburg, W., editors, Agents

for Games and Simulations, volume 5920 of Lec-

ture Notes in Computer Science, pages 1–15. Springer

Berlin Heidelberg.

GOAL (2015). Open source website for GOAL on github.

https://github.com/goalhub.

Heckel, F., Youngblood, G., and Hale, D. (2009). Behavior-

shop: An intuitive interface for interactive character

design. In Proceedings of the Fifth AAAI Conference

on Artiﬁcial Intelligence and Interactive Digital En-

tertainment. AAAI Press.

Hindriks, K. (2009). Programming Rational Agents in

GOAL. In Multi-Agent Programming: Languages,

Tools and Applications, pages 119–157. Springer US.

Hindriks, K. V., de Boer, F. S., van der Hoek, W., and

Meyer, J.-J. C. (1998). A Formal Embedding of

Agentspeak(L) in 3APL. In Antoniou, G. and Slaney,

J., editors, Advanced Topics in Artiﬁcial Intelligence,

volume 1502 of Lecture Notes in Computer Science,

pages 155–166. Springer Berlin Heidelberg.

Lillis, D., Jordan, H. R., and Collier, R. W. (2012). Evalua-

tion of a Conversation Management Toolkit for Multi

Agent Programming. In Proceedings of the 10th Inter-

national Workshop on Programming Multi-Agent Sys-

tems (ProMAS 2012), Valencia, Spain.

Materials (2015). Experiment materials https://ii.tudelft.

nl/trac/goal/wiki/Projects/PoshVsGoal.

Pane, J. F. and Myers, B. A. (1996). Usability issues in the

design of novice programming systems. Technical Re-

port CMU-CS-96-132, School of Computer Science,

Carnegie Mellon University.

Shapiro, L. and Sterling, E. (1994). The Art of Prolog: Ad-

vanced Programming Techniques. MIT Press.

van Riemsdijk, M. B., Hindriks, K. V., and Jonker, C. M.

(2012). An empirical study of cognitive agent

programs. Multiagent and Grid Systems (MAGS),

8(2):187–222.

A Comparative Study of Programming Agents in POSH and GOAL

203
