Retrospective Study of Third-party Web Tracking

Tim Wambach and Katharina Br

aunlich

Institute for IS Research, University Koblenz-Landau, Universit

atsstr. 1, 56070 Koblenz, Germany

Keywords:

Web Tracking, Tracker, Privacy, Data Leakage, Data Protection, Web Archive, Security, Retrospective

Analysis, History of Web Tracking.

Abstract:

Web tracking has seen a remarkable usage increase during the last years. Unfortunately, an overview of how

web tracking evolved within the last

15 years is missing. In this paper we present a retrospective analysis

using archived data to quantify the usage and distribution of web tracking and how it changed throughout the

last decade. We identify a more than ﬁve fold increase in external requests between 2005 and 2014. About

half of the analyzed websites have a web tracking based inclusion today (2015). As web tracking is often

associated with a risk of privacy loss, we also outline the security implications of monopolized ubiquitous

tracking.

1 INTRODUCTION

Being tracked has become a part of modern life.

About half the websites we visit include some kind

of tracking mechanism ((Gelbmann, 2012)). A disad-

vantage associated with web tracking is the potential

loss of privacy for end users – (Mayer and Mitchell,

2012) illustrate possible risks for consumers. Collect-

ing data about their web surﬁng behavior can be used

for business, marketing, or other purposes. From our

point of view, the security implications for organiza-

tions and enterprises are still underestimated. For ex-

ample, let us consider an employee working in a de-

velopment department that uses the web to gain fur-

ther information about products they are working on.

The browsing history would usually be kept undis-

closed, but (Englehardt et al., 2015) shows how an ad-

versary on the web can reconstruct 62-73% of a typi-

cal user’s browsing history. Information about current

development within a company could be revealed by

their web activities. The usage of company wide web

proxies that aggregate requests do not solve the issue.

Hiding internal IP address information or removing

HTTP referrers do not prevent web tracking, because

a wide range of different technologies exists that im-

plement web tracking by other means.

Monitoring internet routers might be possible for

internet providers or intelligence services, but they

should not be able to analyze the content of TLS

(Transport Layer Security) encrypted requests. This

does not apply to web tracking mechanisms that cre-

ate a separate (encrypted or unencrypted) request to

the tracking provider and inform about activities. This

could also include very detailed usage information

about something like mouse movement.

Web tracking must also be considered if privacy

protection on the web is intended by an end user. Net-

work layer anonymization (e.g. using a TOR network

(TorProject, 2015)) is not effective if the browser as-

sists the user recognition. It is well known that cook-

ies can be used for this. However, a strong cookie

policy might not be an effective protection: (Kamkar,

2010) shows how other browser technologies can be

used as cookie replacements or circumvent cookie

deletion. How these so-called evercookies are used to

facilitate web tracking is shown in (Mcdonald et al.,

2011).

This makes web tracking a possible threat for

both, the privacy of end users and the security of com-

panies. However, web tracking as a privacy threat and

a potential data leakage seams to be underestimated in

IT security research. One reason could be that there

is a wide range of tracking and advertising providers.

Due to the variety of different tracking providers, it

is not feasible to grasp the whole picture of a speciﬁc

company or person. Another reason for this underes-

timation might be the novelty of this threat. 10 years

ago third-party web tracking was relatively rare but is

now growing into a serious problem.

Currently, no overview on how web tracking has

grown over the last 10-16 years exists (cf. Section 5).

Our goal is to analyze how third-party web tracking

138

Wambach, T. and Bräunlich, K.

Retrospective Study of Third-party Web Tracking.

DOI: 10.5220/0005741301380145

In Proceedings of the 2nd International Conference on Information Systems Security and Privacy (ICISSP 2016), pages 138-145

ISBN: 978-989-758-167-0

has changed over the last 16 years. Our methods are

explained in Section 2. The required software imple-

mentations are described in Section 3. However, the

results in Section 4 show a remarkable increase in ex-

ternal connections that can mostly be linked to web

tracking. A trend that was already partly shown in

other work.

An assumption was, that a diversity of tracking

providers exist so that a single tracker might not be

able to gain the whole picture of a speciﬁc person

(as explained above). It is based on the fact that 10

years ago, third-party web tracking was relatively rare

compared to today. In this paper we show that few

providers currently track the majority of users visiting

the most popular websites. This is the ﬁrst analysis

that covers a more than 5 year range and (graphically)

demonstrates how this tracking network has grown

over the last decade.

2 METHODOLOGY

The questions this paper strives to answer are: How

many trackers have exist historically, how the number

of trackers has changed throughout the last years, how

trackers have been distributed, and how their distribu-

tion has changed over time.

Section 2.1 provides a general overview of web

tracking mechanisms. Section 2.2 explains how we

detect trackers on websites. This method differs from

privacy enhancing technologies but ﬁts our special

needs for such a retrospective analysis. For such an

analysis, we need a large amount of website snapshots

over the past years. We use website snapshots from

archive.org and perform an analysis of web tracking

on them – further explained in Section 2.3.

2.1 Tracker Mechanism

At the beginning of the world wide web, website ana-

lytics were performed by an analysis of the web server

log ﬁles. The website operator collected information

about the IP addresses of the visitors, possible loca-

tions and most requested websites. An analysis, per-

formed by the web server’s owner, can be classiﬁed

as ﬁrst-party analysis.

Embedding resources is a common technique for

web tracking. HTML allows embedding content from

local and remote servers. During the parsing and in-

terpretation process, the browser automatically loads

content from any location speciﬁed in the HTML

code. The server notices a resource request from the

visitor’s browser. A picture (so-called web bug) em-

bedded in a web site allows a third-party to track vis-

itors over different domains. Such a request contains

the user’s IP address and additional meta information

(e.g. HTTP header). Additionally, cookies can facili-

tate the recognition of visitors.

JavaScript, developed in 1995 and ﬁrst provided

in 1996 by Netscape Navigator 2.0 and Internet Ex-

plorer 3.0, introduced the possibility to execute scripts

on the client side. This technique can also be used to

perform web tracking to gain ﬁne-grained usage in-

formation. Data collected on the client-side can after-

wards be sent to the server. The Same-Origin Policy

implemented in browsers since 1996 lead to a sep-

aration of data from different websites. To achieve

cross domain tracking, a shared third party tracking

provider is required.

In active web tracking, the browser is part of the

tracking mechanism. Tracking from a third-party that

is supported by the browser in any way (e.g. creat-

ing remote connections, performing scripts, etc.) is

known as active third-party web tracking. Today, dif-

ferent techniques are used to track visitors across do-

mains. Unlike the passive type of web tracking, like

the use of browser ﬁngerprinting ((Eckersley, 2010),

(Boda et al., 2012)), the active part can be detected.

(Mayer and Mitchell, 2012) explains how modern

web tracking works.

2.2 Tracker Detection

Most currently available tracker recognition tech-

niques are focused on detecting trackers on exist-

ing and active websites. For example by blacklist-

ing known tracker patterns (e.g. Ghostery (Ghostery,

2015)) or by behavioral analysis (e.g. TrackingOb-

server (TrackingObserver, 2012)).

(Roesner et al., 2012) presents a classiﬁcation

framework and shows ﬁve different classes of typi-

cal tracker behavior. However, we cannot use exist-

ing tracking recognition tools to ﬁnd tracking mech-

anisms from archive.org websites due to the fact that

the web server of the tracker might not exist anymore

or might show different behavior as in the past. If a

visited website (A) includes an image or script that

causes the browser to open a connection to the track-

ing domain (B), (B) might set a cookie for tracking

purposes. This active part – setting a cookie – is not

preserved by archive.org. But what we can see in the

archived data of (A) is the fact that there is an active

part (e.g. image, script, etc.) that causes a request by

the browser to open a connection to (B).

Embedding content is not necessarily associated

with tracking. Examples include embedding a video

player or third-party requests caused by the server in-

frastructure (Content Delivery Network). By creat-

Retrospective Study of Third-party Web Tracking

139

ing a new connection from the browser to another do-

main, a transmission of source/location information

(IP address) is caused and may also reveal further pro-

tocol speciﬁc information like HTTP referrers. (Eck-

ersley, 2010) shows how this kind of information can

be used for passive web tracking. From our point of

view today, disclosing IP address information must be

classiﬁed as personal data transfer that can be used for

tracking purposes. In this paper, tracking is deﬁned as

a connection to an external (third party) host, that is

not part of the visited/requested website. It cannot be

proven whether the third party uses personal data for

tracking purposes or not. However, it is clear that the

data could be used to track.

The results are similar to the ones generated by the

Firefox add-on Lightbeam ((Lightbeam, 2015)) that

also provides a graphical overview about third party

connections. Due to the fact that we need the ability to

block connections not directed to archive.org, further

development was necessary. In Section 3 we describe

how a development framework (PyQt) was modiﬁed

to obtain all external requests that occur during a web

request. As soon as a website is fully parsed, all net-

work requests are saved in a list and can be processed

further.

2.3 Retrospective Analysis

Founded in 1996, archive.org became well known as

an internet library by preserving the state of popu-

lar websites. If not disabled by the website owner,

archive.org stores the current state of public internet

websites several times a year (Day, 2006), (Olston and

Najork, 2010). Information about new popular web-

sites are donated by the Alexa.org database. This in-

formation will be used for a retrospective analysis of

the websites with a focus on third-party connections.

We can now obtain all requests for a given

archive.org website. We also need to restrict our

analysis to a set of websites. We decided to use

the 10,000 most popular websites according to the

Alexa.org database (as of March 2015). Unfortu-

nately, Alexa.org was not able to provide the most

visited websites for the years before 2007. Other

databases, like Netcraft or archive.org, were not able

to provide this either. Therefore, our analysis is based

on the most popular 10,000 websites today.

The archive.org JSON API

allows us to check

how many snapshots are available and where they can

be found. For each of the 10,000 websites and for

each year between the years 2000 and 2015, we re-

quest a snapshot overview from archive.org. The re-

JSON API for archive.org services and metadata,

https://archive.org/help/json.php

sult is a list of snapshots that can be processed. This

processing results in up to 16 lists of resources (for

each year) that the browser loads after visiting the

website in the archive. Finally, we perform an analy-

sis of what kind of trackers were used historically and

how tracker usage changed in the last years.

As already stated in Section 2.2, an ideal analysis

of web tracking cannot be performed due to the fact

that active parts (web servers) sometimes do not exist

anymore or do not show the same behavior. Further-

more, redirections to content on other websites cannot

be followed if they are not preserved by archive.org.

For example if an advertising spot was sold by the

website owner and ﬁlled with different content for

each request. This could generate much more exter-

nal requests if visited multiple times. Due to this, the

results of this analysis must be interpreted as a mini-

mum of tracking, but could be higher.

3 IMPLEMENTATION

For our analysis, it is necessary to identify external

connections from an archived website. A static anal-

ysis, like using regular expression to ﬁnd external re-

sources within HTML source code, has been shown to

be insufﬁcient. A reason for this is code obfuscation

that looks like this:

var src = (document.location.protocol ===

’https:’ ? ’https:/’ : ’http:/’)

+ ’/imagesrv.adition.com/js/srp.js’;

document.write(’<scr’ + ’ipt type=

"text/javascript" src="’ + src + ’"

charset="utf-8"></scr’ + ’ipt>’);

In this code, the address of the tracker (adi-

tion.com) is obfuscated in a simple form, but good

enough to defeat an automatic URL search in the

source code.

Thus, a more dynamic analysis of websites is re-

quired. PyQt is a library that connects the Qt C++

cross-platform application framework with the in-

terpreted language Python. Qt is a toolkit that in-

cludes a web browser widget that supports all mod-

ern web techniques (JavaScript, CSS, AJAX etc.)

according to their whitepaper (Riverbank, 2013).

When this browser widget is parsing a website,

there are various points where resources (images,

scripts, etc.) are requested. We identiﬁed the

PyQt4.QtNetwork.QNetworkAccessManager class

where all network-based requests come together. If a

resource must be loaded, the method createRequest

is called and contains the full address (URL) of the re-

source. We overwrote this class, so that:

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

140

• all requests on the network are stored perma-

nently, and

• requests not directed to archive.org are blocked

using an empty dummy request.

A dummy request allows the library to continue

the parsing process of the website without this re-

quested/blocked resource – so this approach can un-

fortunately not reveal requests resulting from re-

sources (e.g. scripts) that are not available any more.

Using this modiﬁed library, we obtain a list of all

connections that are created by the browser during the

parsing process. If the requested resource is available

on archive.org, it is loaded and processed. All other

requests outside the archive are blocked. It must be

clariﬁed that only the main website was initially re-

quested – the browser does not try to ”click” on hy-

perlinks if it is not forced to do so by the content.

However, we assume that most trackers will be loaded

by the main page.

In (Krishnamurthy and Wills, 2009), third-party

domains are identiﬁed by their DNS record. Due to

the fact that we do not have DNS records from the

last 16 years, this method cannot be applied here.

Therefore, we deﬁne a tracker as a loading process

from an external domain. We deﬁne an external do-

main as a host, where the second-level domain differs

from the requested. For example, if ”example.com”

is requested, ”web.example.com” and ”example.net”

count as internal resources, while ”notexample.com”

counts as external. In Table 1 we provide an overview

of request types and how they are handled. Each ex-

ternal domain is counted once. For external domains,

we also take the top level domain into account, so that

”facebook.com” and ”facebook.net” are different re-

sources.

For graphical representation, we use networkx

(Hagberg et al., 2008). All data was obtained in April

2015.

4 RESULTS

For our analysis, we determined how many years

of history of the Alexa Top 10,000 Domains (as of

April 2015) we can ﬁnd on archive.org. For 896 do-

mains, no history is available – website owners are

able to block

being archived. For 3,042 domains,

archive.org only provides a ≤ 5 year history. For the

following analysis, a history of ≥ 10 years must be

available, which includes 4,833 domains. How the

snapshots are distributed over the 10-16 years is not

Removing Documents From the Wayback Machine,

https://archive.org/about/exclude.php

relevant for our analysis. For 1,426 domains, we have

the full 16 year history. In 123 cases, we had browser

errors and removed these domains from the analysis.

In conclusion, we identiﬁed 4,710 domains with at

least a 10 year history for further analysis.

Table 2 shows an overview of the results. The sec-

ond column (column #) shows the number of analyzed

websites that were available for a particular year. The

columns x

min

and x

max

show the minimum and maxi-

mum number of external requests from a single web-

site. ¯x

med

is the median, x

Q0.25

is the ﬁrst and x

Q0.75

the third quartile. Column ¯x is the sample mean, σ is

the standard deviation, and σ

= Var(x).

During the years 2000 to 2004, the number of an-

alyzed websites is below 4,000 and therefore difﬁ-

cult to compare with the rest. As of the year 2005,

the number is between 4,000 and 4,500. Due to the

fact that the analysis was executed in the beginning

of 2015, not all websites were available at this time

for the year 2015. Therefore, the best range for a

comparison is between 2005 and 2014. Within this

range the number of web inclusions increased more

than ﬁve fold. The median in 2015 shows that half

of the websites have at least 5 different external re-

sources included and a quarter at least 2. The fact that

in the year 2005 75% have no inclusions lead us to the

question how these external resources are distributed.

4.1 Most Used Trackers

In this section, we show which domains are most

prominently included throughout our 16 years of anal-

ysis. For each year, we analyzed how often a domain

showed up in our results. The ﬁve most used domains

can be seen in Table 3. For the year 2000, the most

included domain was doubleclick.net which is still a

popular web tracking domain. But in our 2,677 ana-

lyzed websites it only occurred 177 times. In compar-

ison: the most included domain in 2014 was google-

analytics.com with 2,094 occurrences on 4,274 ana-

lyzed domains.

It needs to be noted that domains are not grouped

by company. For example, Akamai Technologies is

still in the top 20 of the year 2015 with 346 occur-

rences, but currently known under the domain aka-

maihd.net.

As explained in the previous section, the range

most suitable for comparison are the years 2005 to

2014. In 2005, doubleclick.net is the most included

domain but with 209 of 4,049 websites it is only

present in about 5% of the websites. In the year

2014, google-analytics.com is the most included do-

main with 2,094 occurrences. On nearly every sec-

ond website, the visitor is tracked by Google Analyt-

Retrospective Study of Third-party Web Tracking

141

Table 1: Overview of the request types. Protocol: http or https.

Type Request Counted Blocked

I web.archive.org/web/<time>/<int domain>/<resource> no no

II web.archive.org/web/<time>/<ext domain>/<resource> yes no

III <int domain>/<resource> no yes

IV <ext domain>/<resource> yes yes

Table 2: Statistical report of external requests on websites for the years 2000 to 2015.

Year # x

min

Q0.25

¯x

med

Q0.75

max

¯x σ Var(x)

2000 2677 0 0 0 1 22 0.71 1.54 2.37

2001 3117 0 0 0 1 22 0.86 1.69 2.87

2002 3277 0 0 0 1 22 0.88 1.64 2.7

2003 3534 0 0 0 1 17 0.91 1.66 2.74

2004 3861 0 0 0 1 30 15.0 1.99 3.98

2005 4049 0 0 0 2 42 1.17 2.11 4.47

2006 4251 0 0 1 2 37 1.42 2.23 4.97

2007 4327 0 0 1 3 26 1.88 2.48 6.16

2008 4457 0 0 1 3 29 2.13 2.69 7.24

2009 4328 0 0 2 4 26 2.6 2.95 8.7

2010 4328 0 1 2 5 31 3.1 3.34 11.14

2011 4412 0 1 3 6 46 42.0 4.15 17.18

2012 4414 0 1 4 7 52 4.8 4.74 22.43

2013 4410 0 1 4 8 39 5.24 4.92 24.25

2014 4274 0 2 5 9 47 5.91 5.37 28.86

2015 4031 0 2 5 9 52 6.15 5.53 30.6

Table 3: Top 5 of the most included external domains. Legend: A: doubleclick.net, B: akamai.net, C: rambler.ru, D: bfast.com,

E: imgis.com, F: spylog.com, G: list.ru, H: imrworldwide.com, I: googlesyndication.com, K: google-analytics.com,

L: google.com, M: quantserve.com, N: scorecardresearch.com, O: facebook.com, P: googleapis.com, R: fbcdn.net, S: face-

book.net.

’00 ’01 ’02 ’03 ’04 ’05 ’06 ’07 ’08 ’09 ’10 ’11 ’12 ’13 ’14 ’15

A 177 210 205 183 190 209 224 366 454 880 787 769 614 810 1202 1050

B 46 93 91 77 68 71 71 58 43 31 38 29 26 26 23 21

C 39 51 59 67 77 71 84 93 91 96 90 90 75 60 48 44

D 31

E 31

F 49 39 36 37 30 33 25 24 22

G 42 47 53 56 57 69 67 62 48 39 31 26 18

H 47 67 75 81 83 107 99 104 213 223 199 162 134

I 118 206 322 364 356 342 326 318 290 276 280 310

K 18 563 1182 1704 2001 2175 2394 2530 2417 2094 1971

L 16 21 43 64 651 146 219 266 468 742 769 805 735

M 44 223 388 422 436 448 418 368 328

N 72 304 462 549 567 602 588

O 38 254 667 698 583 510 427

P 18 119 273 543 763 1003 1170 1179

R 35 107 542 595 463 255 36

S 65 392 701 804 797 837

ics. Due to the fact that since 2007, doubleclick.net is

part of Google Inc., 4 of these top 5 included domains

have been part of a Google Inc. service for the last

years (since 2011). It is still unclear how data from

Google services like googleapis.com are connected to

other Google services.

A further analysis of the drop in requests (Table 3)

between 2013 and 2014 of Google Analytics showed

that 209 of them changed to doubleclick.net and 92

of these domains that removed Google-Analytics in

2013 added googletagmanager.com in 2014. So this

could be part of a Google internal separation process.

Further analysis of tracker removal can be found in

Section 4.3.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

142

Figure 1: Year 2000. Figure 2: Year 2005.

Figure 3: Year 2007. Figure 4: Year 2010.

Figure 5: Year 2012. Figure 6: Year 2014.

4.2 Distribution

In this section we use a graph for a visual representa-

tion of the distribution of trackers. Figures 1 - 6 show

undirected graphs where every edge stands for at least

one load process from an external domain. The top 5

from Section 4.1 are marked with the corresponding

letter as explained in Table 3. For the sake of clarity,

nodes without any connection are not plotted. The

position of each domain (node) is consistent for all

graphs.

It must be noted that for 2005, nearly the same

amount of websites were analyzed (4,049) as for 2014

(4,274). Thus, the differences between these graphs

Retrospective Study of Third-party Web Tracking

143

are mostly additional requests. In Figures 4 and 5 we

can see a monopolization: while in earlier years we

had a more equal distribution, the graph from 2010

shows few nodes with signiﬁcantly more connections

than the others. Especially google-analytics.com (K)

is in the top 5 since 2006 and its growing inﬂuence on

the web is easy to see.

4.3 Tracker Removal

As we can see in Table 3, some trackers were re-

moved. In this section, we analyze what happened

with the websites that removed a speciﬁc tracker. As

one of the most included resources since 2006, we

start this analysis with Google Analytics (GA). We

checked how many websites used GA and removed it

later. The analysis showed that 869 domains used GA

and removed it. Between the years 2006 and 2011, on

less than 50 domains per year, GA was removed. The

highest amount was in the years 2013, 2014 and 2015

with 225, 369 and 239 removals respectively. In only

a few cases (about 25 per year) the removal of GA re-

sulted in an empty list of trackers. In 258 cases where

GA was removed, doubleclick.net was added the year

after or later.

5 RELATED WORK

Using data from archive.org in connection with the

Alexa top 10,000 was also applied in (Stamm et al.,

2010) for an analysis of web application vulnerabili-

ties. Analysis of archived data in general is also per-

formed by the LAWA project (Longitudinal Analytics

of Web Archive data) (Spaniol and Weikum, 2012).

In (Krishnamurthy and Wills, 2009), a long-term

study over 5 epochs between October 2005 and

September 2008 was performed. The results showed a

steadily decreasing number of entities where a hand-

ful of companies are able to track users’ movement

across almost all of the popular websites. Our results

also show that Google-Analytics and Doubleclick are

the most widely used trackers. (Chaabane et al., 2012)

shows an analysis of the Alexa Top 10,000 regarding

tracking mechanisms and social media plugins but is

limited to October 2012.

A fully comparable overview of the history of web

tracking is missing and existing analysis cover only

a few years. Our analysis showed the trend of less

diversity found in (Krishnamurthy and Wills, 2009)

continued.

6 CONCLUSION

In our work, we showed how embedding external con-

tent has seen a usage increase in the 10,000 most

popular websites today. Within the best comparable

range between 2005 and 2014 we have shown a sig-

niﬁcant increase (ﬁve fold) of external requests. In

the year 2014 we found an average of 5.9 external re-

quests per website. This means at least 5 other hosts

were informed about the visitation of a website. The

most used external hosts could be connected with web

tracking and so the request could be used to deduce

even more information about a user, e.g. an analysis

of the user’s behavior. We presented an impression of

the distribution and diversity in our graphs.

We showed that the diversity of web tracking and

content providers, that we assumed in the beginning,

does not exist. This lead to security issues: if a glob-

ally acting company has an insight into every second

visited domain of a speciﬁc user, it is clear that keep-

ing company information secret is difﬁcult. The us-

age of further services like search, mail, calendar, or

translation services contributes to the problem. From

our point of view, information security ofﬁcers should

be more sensitive about privacy and web tracking for

two reasons: for employee privacy and for an effec-

tive protection of corporate information. The fact that

fewer companies collecting more information about

us with an upward tendency is a privacy concern for

end users. The consequences of such a centralization

of tracking, which allows the formation of an increas-

ingly complete picture about a speciﬁc person, are dif-

ﬁcult to predict.

We showed that a reason for the underestimation

of third-party web tracking consequences could be

due to the fact that it did not exist 10 years ago. From

a security point of view, considering web tracking and

the usage of PET (Privacy-Enhancing Technologies)

should be a part of every corporate security policy.

This is more important today than it was in the past.

Further research in security implications of web

tracking is required. A further study about the moti-

vation of web tracking usage to explain this increase

could be performed in future work. With respect to

the implementation, a deeper analysis of the embed-

ded content would also be beneﬁcial to increase our

understanding of modern web tracking today.

ACKNOWLEDGEMENT

This study has been made possible by the participa-

tion of the interdisciplinary project ”Transformations

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

144

of Privacy”

funded by VolkswagenStiftung

REFERENCES

Boda, K., F

oldes, d., Guly

as, G., and Imre, S. (2012). User

tracking on the web via cross-browser ﬁngerprinting.

In Laud, P., editor, Information Security Technology

for Applications, volume 7161 of Lecture Notes in

Computer Science, pages 31–46. Springer Berlin Hei-

delberg.

Chaabane, A., Kaafar, M. A., and Boreli, R. (2012). Big

friend is watching you: Analyzing online social net-

works tracking capabilities. In Proceedings of the

2012 ACM Workshop on Workshop on Online Social

Networks, WOSN ’12, pages 7–12, New York, NY,

USA. ACM.

Day, M. (2006). The long-term preservation of web content.

In Web Archiving, pages 177–199. Springer Berlin

Heidelberg.

Eckersley, P. (2010). How unique is your web browser? In

Proceedings of the 10th International Conference on

Privacy Enhancing Technologies, PETS’10, pages 1–

18, Berlin, Heidelberg. Springer-Verlag.

Englehardt, S., Reisman, D., Eubank, C., Zimmerman, P.,

Mayer, J., Narayanan, A., and Felten, E. W. (2015).

Cookies that give you away: The surveillance impli-

cations of web tracking. In Proceedings of the 24th

International Conference on World Wide Web, WWW

2015, Florence, Italy, May 18-22, 2015, pages 289–

299.

Gelbmann, M. (2012). Google can’t track every single click

of your web surﬁng. only most of them.

Ghostery, I. (2015). Ghostery - home page.

https://www.ghostery.com/.

Hagberg, A. A., Schult, D. A., and Swart, P. J. (2008).

Exploring network structure, dynamics, and function

using NetworkX. In Proceedings of the 7th Python

in Science Conference (SciPy2008), pages 11–15,

Pasadena, CA USA.

Kamkar, S. (2010). evercookie - virtually irrevocable per-

sistent cookies.

Krishnamurthy, B. and Wills, C. E. (2009). Privacy diffu-

sion on the web: A longitudinal perspective. In In

Procs World Wide Web Conference, page 09.

Lightbeam (2015). Lightbeam addon for

ﬁrefox. https://addons.mozilla.org/en-

US/ﬁrefox/addon/lightbeam/.

Mayer, J. R. and Mitchell, J. C. (2012). Third-party web

tracking: Policy and technology. In Proceedings of

the 2012 IEEE Symposium on Security and Privacy,

SP ’12, pages 413–427, Washington, DC, USA. IEEE

Computer Society.

Mcdonald, A. M., Cranor, L. F., Mcdonald, A. M., and Cra-

nor, L. F. (2011). A survey of the use of adobe ﬂash

local shared objects to respawn http cookies.

http://www.strukturwandeldesprivaten.de/

https://www.volkswagenstiftung.de/en.html

Olston, C. and Najork, M. (2010). Web crawling. Found.

Trends Inf. Retr., 4(3):175–246.

Riverbank (2013). PyQt Whitepaper.

http://www.riverbankcomputing.com/.

Roesner, F., Kohno, T., and Wetherall, D. (2012). Detect-

ing and defending against third-party tracking on the

web. In Proceedings of the 9th USENIX Conference

on Networked Systems Design and Implementation,

NSDI’12, pages 12–12, Berkeley, CA, USA. USENIX

Association.

Spaniol, M. and Weikum, G. (2012). Tracking entities in

web archives: The lawa project.

Stamm, S., Sterne, B., and Markham, G. (2010). Reining

in the web with content security policy. In Proceed-

ings of the 19th International Conference on World

Wide Web, WWW ’10, pages 921–930, New York,

NY, USA. ACM.

TorProject (2015). Tor: An anonymous Internet communi-

cation system. http://www.torproject.org/.

TrackingObserver (2012). A browser-

based web tracking detection platform.

http://trackingobserver.cs.washington.edu/.

Retrospective Study of Third-party Web Tracking

145
