An Improved Single Node Genetic Programming for Symbolic

Regression

ı Kubal

ık

and Robert Babu

ska

1,2

Czech Institute of Informatics, Robotics, and Cybernetics, CTU in Prague, Prague, Czech Republic

Delft Center for Systems and Control, Delft University of Technology, Delft, The Netherlands

Keywords:

Genetic Programming, Single Node Genetic Programming, Symbolic Regression.

Abstract:

This paper presents a ﬁrst step of our research on designing an effective and efﬁcient GP-based method for

solving the symbolic regression. We have proposed three extensions of the standard Single Node GP, namely

(1) a selection strategy for choosing nodes to be mutated based on the depth of the nodes, (2) operators

for placing a compact version of the best tree to the beginning and to the end of the population, and (3) a

local search strategy with multiple mutations applied in each iteration. All the proposed modiﬁcations have

been experimentally evaluated on three symbolic regression problems and compared with standard GP and

SNGP. The achieved results are promising showing the potential of the proposed modiﬁcations to signiﬁcantly

improve the performance of the SNGP algorithm.

1 INTRODUCTION

This paper presents a ﬁrst step of our research on ge-

netic programming (GP) for the symbolic regression

problem. The ultimate goal of our project is to design

an effective and efﬁcient GP-based method for solv-

ing dynamic symbolic regression problems where the

target function evolves in time. Symbolic regression

(SR) is a type of regression analysis that searches the

space of mathematical expressions to ﬁnd the model

that best ﬁts a given dataset, both in terms of accuracy

and simplicity

Genetic programming belongs to effective and ef-

ﬁcient methods for solving the SR problem. Besides

the standard Koza’s tree-based GP (Koza, 1992) there

have been many other variants proposed that proved

to perform well on the SR problem. They include, for

instance, Grammatical Evolution (GE) (Ryan et al.,

1998) which evolves programs whose syntax is de-

ﬁned by a user-speciﬁed grammar (usually a grammar

in Backus-Naur form). Gene Expression Program-

ming (GEP) (Ferreira, 2001) is another GP variant

successful in solving the SR problems. Similarly to

GE it evolves linear chromosomes that are expressed

as tree structures through a genotype-phenotype map-

ping. A graph-based Cartesian GP (CGP) (Miller and

Thomson, 2000), is a GP technique that uses a very

https://en.wikipedia.org/wiki/Symbolic regression

simple integer based genetic representation of a pro-

gram in the form of a directed graph. In its classic

form, CGP uses a variant of a simple algorithm called

(1 + λ)-Evolution Strategy with a point mutation vari-

ation operator. When searching the space of candi-

date solutions, CGP makes use of so called neutral

mutations meaning that a move to the new state is ac-

cepted if it does not worsen the quality of the current

solution. This allows an introduction of new pieces of

genetic code that can be plugged into the functional

code later on and allows for traversing plateaus of the

ﬁtness landscape.

A Single Node GP (SNGP) (Jackson, 2012a),

(Jackson, 2012b) is rather new graph-based GP sys-

tem that evolves a population of individuals, each

consisting of a single program node. Similarly to

CGP, the evolution is carried out via a hill-climbing

mechanism using a single reversible mutation opera-

tor. The ﬁrst experiments with the SNGP were very

promising as they showed that the SNGP signiﬁcantly

outperforms the standard GP on various problems in-

cluding the SR problem. In this work we take the stan-

dard SNGP as the baseline approach and propose sev-

eral modiﬁcations to further improve its performance.

The goals of this work are to verify performance

of the SNGP compared to the standard GP on vari-

ous SR benchmarks and to investigate the impact of

the following three design aspects of the SNGP algo-

rithm:

244

Kubalík, J. and Babuška, R..

An Improved Single Node Genetic Programming for Symbolic Regression.

In Proceedings of the 7th International Joint Conference on Computational Intelligence (IJCCI 2015) - Volume 1: ECTA, pages 244-251

ISBN: 978-989-758-157-1

• a strategy for selection of the nodes to be mutated,

• a strategy according to which the nodes are or-

dered in the population,

• and a type of the local search strategy used to

guide the optimization process

The paper is organized as follows. In Section 2,

the SNGP algorithm is described. In Section 3, three

modiﬁcations of the SNGP algorithm are proposed.

Experimental evaluation of the modiﬁed SNGP and

its comparison to the standard SNGP and standard

Koza’s GP is presented in Section 4. Finally, Sec-

tion 5 concludes the paper and proposes directions for

the further work on this topic.

2 SINGLE NODE GENETIC

PROGRAMMING

2.1 Representation

The Single Node Genetic Programming is a GP sys-

tem that evolves a population of individuals, each

consisting of a single program node. The node can

be either terminal, i.e. a constant or a variable node,

or a function from a set of functions deﬁned for the

problem at hand. Importantly, individuals are not en-

tirely distinct, they are interlinked in a graph structure

similar to that of CGP, with population members act-

ing as operands of other members (Jackson, 2012a).

Formally, a SNGP population is a set of N in-

dividuals M = {m

, m

, .. . , m

N−1

}, each individual

being a single node represented by a tuple m

, f

, Succ

, Pred

, O

i, where

• u

∈ T ∪F is either an element chosen from a func-

tion set F or a terminal set T deﬁned for the prob-

lem,

• f

is the ﬁtness of the individual,

• Succ

is a set of successors of this node, i.e. the

nodes whose output serves as the input to the

node,

• Pred

is a set of predecessors of this node, i.e. the

nodes that use this individual as an operand,

• O

is a vector of outputs produced by this node.

Typically, the population is partitioned so that ﬁrst

term

nodes, at positions 0 to N

term

− 1, are terminals

(variables and constants in case of the SR problem),

followed by function nodes. Importantly, a function

node at position i can use as its successor (i.e. the

operand) any node that is positioned lower down in

the population relative to the node i. This means that

for each s ∈ Succ

we have 0 ≤ s < i (Jackson, 2012a).

Similarly, predecessors of individual i must occupy

higher positions in the population, i.e. for each p ∈

Pred

we have i < p < N. Note that each function

node is in fact a root of a tree that can be constructed

by recursively traversing the successors until the leaf

terminal nodes.

2.2 Evolutionary model

In (Jackson, 2012a), a single evolutionary operator

called successor mutate (smut) has been proposed.

It picks one individual of the population at random

and then one of its successors is replaced by a refer-

ence to another individual of the population making

sure that the constraint imposed on the successors is

satisﬁed. Predecessor lists of all affected individuals

are updated accordingly. Moreover, all individuals af-

fected by this action must be reevaluated as well. For

more details refer to (Jackson, 2012a).

The evolution is carried out via a hill-climbing

mechanism using a smut operator and an acceptance

rule. The acceptance rule can have various forms. In

(Jackson, 2012a), it was based on ﬁtness measure-

ments across the whole population, rather than on sin-

gle individuals. This means that once the population

has been changed by a single application of the smut

operator and all affected individuals have been reeval-

uated the new population is accepted if and only if the

sum of the ﬁtness values of all individuals in the pop-

ulation is no worse than the sum of ﬁtness values be-

fore the mutation. Otherwise, the modiﬁcations made

by the mutation are reversed. In (Jackson, 2012b) the

acceptance rule is based only on the best ﬁtness in the

population. The latter acceptance rule will be used in

this work as well. The reason for this choice is ex-

plained in Section 3.4.

3 PROPOSED MODIFICATIONS

In this section, the following three modiﬁcations of

the SNGP algorithm will be proposed:

1. A selection strategy for choosing nodes to be mu-

tated based on the depth of the nodes.

2. Operators for placing a compact version of the

tree rooted in the best performing node to the be-

ginning and to the end of the population, respec-

tively.

3. A local search strategy with multiple mutations

applied in each iteration.

In the following text, the term ”best tree” is used

to denote the tree rooted in the best performing node.

An Improved Single Node Genetic Programming for Symbolic Regression

245

3.1 Depthwise Selection Strategy

The ﬁrst modiﬁcation focuses on the strategy for se-

lecting the nodes to be mutated. In the standard

SNGP, the node to be mutated is chosen at random.

This means that all function nodes have the same

probability of selection irrespectively of (1) how well

they are performing and (2) how well the trees of

which they are a part are performing. This is not in

line with the evolutionary paradigm where the well ﬁt

individuals should have higher chance to take part in

the process of an evolution of the population.

One way to narrow this situation is to select nodes

according to their ﬁtness. However, this would pre-

fer just the root nodes of trees with high ﬁtness while

neglecting the nodes at the deeper levels of such well-

performing trees which themselves have rather poor

ﬁtness. In fact, imposing high selection pressure on

the root nodes might be counter-productive in the end

as the mutations applied on the root nodes are less

likely to bring an improvement than mutations ap-

plied on the deeper structures of the trees.

We propose a selection strategy that takes into ac-

count the quality of the mutated trees, so that better

performing trees are preferred, as well as the depth of

the mutated nodes so that deeper nodes of the trees

are preferred to the shallow ones. The selection pro-

cedure has four steps:

1. A function node n is chosen at random.

2. A tree t with the best ﬁtness out of all trees that

use the node n is chosen.

3. All nodes of the tree t are collected in a set S. Each

node is assigned a score equal to its depth in the

tree t.

4. One node is chosen from the set S using a binary

tournament selection considering the score values

in the higher the better manner.

3.2 Organization of the Population

The second modiﬁcation aims at improving the explo-

ration capabilities of the SNGP algorithm. Two oper-

ators for placing a compact version of the tree rooted

in the best performing node to the beginning or to the

end of the population are proposed.

moveLeft Operator. Let us ﬁrst describe the idea

behind and the realization of the operator that places

the compact version of the best tree to the beginning

of the population. The motivation for this operator,

denoted in this work as moveLeft operator, is that

well-performing nodes (and the whole tree structure

rooted in this node) can represent a suitable building

block for constructing even better trees when used as

a successor of other nodes in the population. Since

the chance of any node of being selected as a succes-

sor by other nodes is higher if the node is more to

the left in the population and vice versa, it might be

beneﬁcial to store the well performing nodes at lower

positions in the population. Thus, the operator takes

the best tree, T

best

, and puts its compact version to the

very beginning of the population. The operator works

as follows:

1. Start in the best performing node and traverse

its tree, T

best

, in the breadth-ﬁrst manner so that

nodes with the lowest index i are processed ﬁrst.

Put the nodes of the tree into a list of nodes, L, in

the order reversed to the order in which they were

processed.

2. Set all successor and predecessor links within L

so that the structure represents the same tree as

the original tree T

best

3. Place the tree stored in L to the beginning of the

population, i.e. the ﬁrst node of L being at the ﬁrst

function node position of the population.

4. Set the successor and predecessor links within the

original tree T

best

so that the tree retains the same

functionality as it had before the action.

5. Update the successor and predecessor links of the

other nodes in the population so that as many orig-

inal links as possible are preserved while the func-

tionality of the compact tree remains intact.

Note that after the application of the T

best

opera-

tion the population contains two versions of the best

tree, the original one and the compact one. It is made

sure that all nodes of the original tree have properly

set their successors sets. If for example some succes-

sors of a node of the original best tree gets affected

by the T

best

operation (i.e. the successor falls into the

portion of the population newly occupied by the com-

pact version of the tree), the successor of the respected

node is redirected to the new version of the successor.

Moreover, some links have to be added to the list of

predecessors of nodes of the compact tree in order to

ensure a feasibility of other nodes in the population.

moveRight Operator. Similarly, an operator that

places the compact version of the best tree to the end

of the population is proposed. The motivation for this

operator, denoted in this work as moveRight operator,

is that a performance of some well-performing tree

can be further improved by mutations applied to the

nodes on deeper levels of the tree more likely than by

mutations applied to the root node or shallow nodes of

the tree. In order to increase the number of possible

structural changes to the deeper nodes of the best tree

the compact version of the tree is placed to the end of

the population. The operator works similarly to the

ECTA 2015 - 7th International Conference on Evolutionary Computation Theory and Applications

246

moveLeft operator with the difference the successor

and predecessor links are updated. Here, the prede-

cessor links of nodes that refer to the nodes within the

area of the compact version of the best tree must be

removed. Otherwise, they would affect a functional-

ity of the best tree. Note that the application of the

moveRight operator might result in the ﬁnal popula-

tion that contains just a single occurrence of the best

tree. This might happen when the nodes of the origi-

nal best tree fall into the area of the compact version

of the tree.

3.3 Local Search Strategy

The last modiﬁcation of the standard SNGP algorithm

consists in allowing multiple mutation in a single it-

eration of the local search procedure. The idea be-

hind this modiﬁcation is rather straightforward. Dur-

ing the course of the optimization process the popula-

tion might converge to the local optimum state where

it is hard to ﬁnd further improvement by just one ap-

plication of the smut operator. With multiple muta-

tions applied in each iteration, the probability of get-

ting stuck in such local optimal should be reduced. In

this work, a parameter upToN specifying the maxi-

mum number of mutation applications is used. Thus,

if the parameter is set for example to 5, a randomly

chosen number from interval h1, 5i of mutations are

applied to the population in each iteration.

3.4 Outline of Tested SNGP Algorithm

This section presents an outline of the generic SNGP

algorithm with possible utilization of the proposed

modiﬁcations, see Fig. 1. In each iteration, k muta-

tions are applied to nodes of the population, see steps

8-10. In case of the standard SNGP just a single muta-

tion is applied in each iteration. After all k mutations

have been applied, the nodes affected by this action

gets reevaluated. If the best ﬁtness of the modiﬁed

population is not worse than the current best-so-far

ﬁtness than the modiﬁed population becomes the cur-

rent population for the next iteration, see step 15. In

step 16, the operators moving the best tree to the be-

ginning or to the end of the population are applied to

the population, if applicable. Then the ﬁtness evalua-

tion counter is incremented and if there are still some

ﬁtness evaluations left the next iteration is carried out.

Once the maximal number of ﬁtness evaluations is

used the best node (and its tree) of the population is

returned.

In this work, we use the acceptance criterion, step

13, working with the best ﬁtness in the population,

not the average ﬁtness of the population. The reason

is that when the moveLe f t and moveRight operators

are used, they might signiﬁcantly change the average

ﬁtness of the population while the best ﬁtness stays

intact.

1 Initialize population of nodes, P

2 evaluate P

3 bestSoFar ← best of P

4 i ← 0 // number of ﬁtness evaluations

5 do

6 P

← P // work with a copy of P

7 Choose the no. of mutations, k ∈ (1, upToN),

to be applied to nodes from P

8 for(n = 1 .. . k)

9 Choose the node to be mutated, N

10 P

← Apply mutation to node N of P

11 evaluate P

12 currBest ← best of P

13 if(currBest is not worse than bestSoFar)

14 bestSoFar ← currBest

15 P ← P

// update the population

16 If applicable, apply either moveLe f t

or moveRight operator to P

17 i ← i + 1

18 while (i ≤ maxFitnessEvaluations)

19 return bestSoFar

Figure 1: Outline of the SNGP algorithm.

4 EXPERIMENTS

This section presents experiments carried out with

standard GP, standard SNGP and SNGP with the pro-

posed modiﬁcations.

4.1 Test Cases

The algorithms have been tested on ﬁve symbolic re-

gression benchmarks

• f

(x) = 4x

− 3x

+ 2x

− x, 32 training samples

equidistantly sampled from h0, 1.0),

• f

(x) = x

− 2x

+ x

, 100 training samples

equidistantly sampled from h−1.0, 1.0)

• f

(x) = x

− 2.6x

+ 1.7x

, 100 training samples

equidistantly sampled from h−1.0, 1.0)

• f

(x) = x

− 2.6x

+ 1.7x

− x, 100 training sam-

ples equidistantly sampled from h−1.4, 1.4)

• f

, x

) =

−3)

+(x

−3)

−(x

−3)

−2)

+10

, 100 training

samples equidistantly sampled from h0.05, 6.05)

An Improved Single Node Genetic Programming for Symbolic Regression

247

Table 1: Results obtained with the compared algorithms on the function f

algorithm ﬁtness sample rate (%) solution rate (%) size

GP 0.14 82.8 49 151

SNGP 1 random noMove 0.65 37.2 5 26.8

SNGP 1 depthwise noMove 0.29 63.4 18 33.7

SNGP 1 random moveLeft 0.62 38.1 3 22.5

SNGP 1 depthwise moveLeft 0.25 68.4 24 33.9

SNGP 1 random moveRight 0.66 35.9 4 34.5

SNGP 1 depthwise moveRight 0.28 66.9 17 56.6

SNGP 5 depthwise noMove 0.16 78.8 49 32.3

SNGP 5 depthwise moveLeft 0.17 77.5 49 28.5

SNGP 5 depthwise moveRight 0.14 84.7 53 52.4

Table 2: Results obtained with the compared algorithms on the function f

algorithm ﬁtness sample rate (%) solution rate (%) size

GP 0.78 88.7 69 175.1

SNGP 1 random noMove 0.85 73.4 33 27.7

SNGP 1 depthwise noMove 0.17 94.4 78 27.6

SNGP 1 random moveLeft 0.75 78 33 30.8

SNGP 1 depthwise moveLeft 0.25 92.8 65 27.7

SNGP 1 random moveRight 0.84 72.7 17 47

SNGP 1 depthwise moveRight 0.15 94.3 82 40.9

SNGP 5 depthwise noMove 1e-6 100 100 22.6

SNGP 5 depthwise moveLeft 0.08 97.8 87 21.2

SNGP 5 depthwise moveRight 0.05 98.2 91 37.2

The ﬁrst two functions are rather simple polyno-

mials with small integer constants. We chose the

function f

since it was used in the original SNGP

paper (Jackson, 2012a). Function f

is the Koza-3

function taken from (McDermott, 2012). Functions

and f

are modiﬁcations of the Koza-3 function so

that they involve non-trivial decimal constants. Thus,

these functions should represent harder instances than

and f

. The function f

is made even harder than

while breaking the symmetry by adding the term

”−x”. The last function f

is a representative of a ra-

tional function of two variables. This function, known

as Vladislavleva-8 function (McDermott, 2012), rep-

resents the hardest SR problem used in this work.

The ﬁtness of each individual is calculated as the

sum of absolute errors in the f (x) values computed by

the individual over all training samples.

4.2 Experimental Setup

All the tested variants of the SNGP use a popula-

tion of size 400. The population starts with terminal

nodes representing the variable x

and x

and a con-

stant 1.0 followed by function nodes of types {+, -, *,

/}. SNGP was run for 25,000 iterations, in each itera-

tion just a single population reevaluation is computed

(note, just the nodes that were affected by the muta-

tion are reevaluated). The number of iterations was

chosen so as to make the comparisons of the GP and

SNGP as fair as possible. This way a balance between

processed nodes and ﬁtness evaluations is found, see

(Ryan and Azad, 2014).

The proposed modiﬁcations of the SNGP algo-

rithm are conﬁgured with the following parameters:

• upToN ∈ {1, 5},

• selection ∈ {random, depthwise}

• moveType ∈ {noMove, moveLe f t, moveRight}.

Names of the tested conﬁgurations

of the SNGP are constructed as follows

”SNGP upToN selection moveType”. The stan-

dard SNGP is denoted as SNGP 1 random noMove.

Standard GP with generational replacement strat-

egy was used with the following parameters:

ECTA 2015 - 7th International Conference on Evolutionary Computation Theory and Applications

248

Table 3: Results obtained with the compared algorithms on the function f

algorithm ﬁtness sample rate (%) solution rate (%) size

GP 1.19 68.4 0 155

SNGP 1 random noMove 2.7 40 0 28.9

SNGP 1 depthwise noMove 1.5 54.0 0 33.6

SNGP 1 random moveLeft 2.39 43.7 0 30.1

SNGP 1 depthwise moveLeft 1.4 59.2 0 35

SNGP 1 random moveRight 2.75 37.2 0 43.4

SNGP 1 depthwise moveRight 1.6 51.6 0 56.2

SNGP 5 depthwise noMove 1.37 59.2 0 32.6

SNGP 5 depthwise moveLeft 1.23 65.6 0 30.3

SNGP 5 depthwise moveRight 1.35 60.8 0 57.2

Table 4: Results obtained with the compared algorithms on the function f

algorithm ﬁtness sample rate (%) solution rate (%) size

GP 11.0 19.4 0 146.8

SNGP 1 random noMove 10.5 12.9 0 26.1

SNGP 1 depthwise noMove 7.8 21.7 0 34.2

SNGP 1 random moveLeft 11.2 10.8 0 26.5

SNGP 1 depthwise moveLeft 8.3 19.0 0 32.9

SNGP 1 random moveRight 8.9 19.0 0 45.8

SNGP 1 depthwise moveRight 7.4 22.4 0 53.9

SNGP 5 depthwise noMove 7.15 25.8 0 31.5

SNGP 5 depthwise moveLeft 7.4 24.0 0 28

SNGP

5 depthwise moveRight 6.7 27.2 0 50.8

Table 5: Results obtained with the compared algorithms on the function f

algorithm ﬁtness sample rate (%) solution rate (%) size

GP 71.2 4.4 0 194.3

SNGP 1 random noMove 64.1 4.0 0 26.0

SNGP 1 depthwise noMove 61.6 3.8 0 35.6

SNGP 1 random moveLeft 64.9 3.8 0 27.3

SNGP 1 depthwise moveLeft 60.0 4.1 0 34.9

SNGP 1 random moveRight 63.6 4.4 0 44.3

SNGP 1 depthwise moveRight 61.1 4.1 0 51.6

SNGP 5 depthwise noMove 60.7 3.7 0 32.8

SNGP 5 depthwise moveLeft 60.9 3.6 0 31.9

SNGP 5 depthwise moveRight 60.4 4.0 0 51.1

• Function set: {+, -, *, /}

• Terminal set: {x

, x

, 1.0}

• Population size: 500

• Initialization method: Ramped half-and-half

• Tournament selection: 5 candidates

• Number of generations: 55, i.e. 54 generations

plus initialization of the whole population

• Crossover probability: 90%

• Reproduction probability: 10%

• Probability of choosing internal node as crossover

point: 90%

An Improved Single Node Genetic Programming for Symbolic Regression

249

For the experiments with the GP we used the

Java-based Evolutionary Computation Research Sys-

tem ECJ 22

One hundred independent runs were carried out

with each tested algorithm on each benchmark and

the observed performance characteristics are

• ﬁtness – the mean best ﬁtness over 100 runs;

• sample rate – the mean number of successfully

solved samples by the best-ﬁtted individual calcu-

lated over 100 runs, where the sample is consid-

ered to be successfully solved by the individual

iff the absolute error achieved by the individual

on this sample is less then 0.01;

• solution rate – the percentage of complete solu-

tions found within 100 runs, where the runs com-

pletely solves the problem iff the best individual

generates on all training samples the absolute er-

ror less than 0.01;

• size – the mean number of nodes of the best solu-

tion found calculated over 100 runs.

4.3 Results

The results obtained with the compared algorithms

are presented in Tables 1-5. The ﬁrst observation

is that our results obtained on the benchmark f

are

quite different than the results presented in (Jackson,

2012a), as the performance of the SNGP is not as

good as the SNGP performance presented there whilst

the standard GP performs much better than presented

in (Jackson, 2012a). This might be caused by differ-

ent conﬁgurations of the SNGP and GP used in our

work and in (Jackson, 2012a). We used different ac-

ceptance criterion in SNGP and the generational in-

stead of the steady-state replacement strategy in GP.

This observation might indicate that both approaches

are quite sensitive to the proper setting of their indi-

vidual components.

The second observation is that the modiﬁed ver-

sions of SNGP systematically outperform the stan-

dard SNGP w.r.t. the ﬁtness, sample rate and solution

rate performance measures. On the other hand, the

modiﬁed SNGP is not a clear winner over the stan-

dard GP. The SNGP outperforms GP on f

, f

and f

On f

it performs equally well as the GP On f

, all

versions of SNGP get outperformed by the GP w.r.t.

the f itness. It turns out functions f

, f

and f

repre-

sent a real challenge for all tested algorithms since no

one was able to ﬁnd a single correct solution within

the 100 runs. We hypothesize the hardness of f

and

https://cs.gmu.edu/ eclab/projects/ecj/

stems from the fact these benchmarks involve non-

trivial constants that might be hard to evolve. Func-

tion f

is hard since it is a rational function.

The third observation is that there is a clear trend

showing that the depthwise node selection works sig-

niﬁcantly better than the random one. Whenever the

SNGP conﬁgurations differ just in the selection type

the one using the depthwise selection outperforms the

one with the random selection.

The fourth observation is that the reorganiza-

tion of the population using either the moveLe f t or

moveRight operator does not have any signiﬁcant im-

pact on the overall performance of the algorithm. It

happens only rarely that the SNGP using moveLe f t

or moveRight outperforms its counterpart conﬁgu-

ration with no move operator used. In particular,

the moveLe f t operator was signiﬁcantly better

than

noMove in four cases, the moveRight operator was

signiﬁcantly better than noMove in two cases as in-

dicated by values written in bold in Tables 1-5. On

the other hand, the noMove conﬁguration happened

to outperform both the moveLe f t and moveRight con-

ﬁguration on function f

The ﬁfth observation is that the local search strat-

egy allowing multiple mutations in one iteration out-

performs the standard local search procedure with just

a single application of the mutation operator per iter-

ation. This is with agreement with our expectations.

Last but not least, the SNGP consistently ﬁnds

much smaller trees than the GP. This is very impor-

tant since very often solutions of small size that are

interpretable by human are sought in practice.

5 CONCLUSIONS

This paper proposes three extensions of the standard

Single Node GP, namely (1) a selection strategy for

choosing nodes to be mutated based on the depth of

the nodes, (2) operators for placing a compact version

of the best tree to the beginning and to the end of the

population, and (3) a local search strategy with multi-

ple mutations applied in each iteration.

All proposed modiﬁcations have been experimen-

tally evaluated on three symbolic regression prob-

lems and compared with standard GP and SNGP. The

achieved results are promising showing the potential

of the proposed modiﬁcations to signiﬁcantly improve

the performance of the SNGP algorithm.

The next step of our research will be to carry out

a thorough experimental evaluation of the modiﬁed

SNGP algorithm and other GP paradigms such as the

Checked using the T-test at the 5% signiﬁcance level

ECTA 2015 - 7th International Conference on Evolutionary Computation Theory and Applications

250

standard GP and GE with the primary objectives be-

ing the speed of convergence and the ability to react

fast to the changes of the environment. Further ex-

tensions of the SNGP algorithm will include a utiliza-

tion of new mutation operators, for example a mu-

tation operator altering the function type of the mu-

tated node. Since the local strategy is very prone to

get stuck in a local optimum, we will also investigate

mechanisms for escaping from the local optima such

as the restarted search with perturbations.

As the experimental results suggest, the SNGP al-

gorithm might become ineffective when trying to ap-

proximate a target function that involves non-trivial

constants. Thus, we will investigate possibilities of

hybridization of the SNGP with local tuning tech-

niques such as multivariate linear regression.

ACKNOWLEDGEMENT

This research was supported by the Grant Agency of

the Czech Republic (GA

CR) with the grant no. 15-

22731S entitled ”Symbolic Regression for Reinforce-

ment Learning in Continuous Spaces”.

REFERENCES

Ferreira, C. (2001). Gene expression programming: A new

adaptive algorithm for solving problems. Complex

Systems, 13(2):87–129.

Jackson, D. (2012a). A new, node-focused model for ge-

netic programming. In EuroGP 2012, pages 49–60.

Jackson, D. (2012b). Single node genetic programming on

problems with side effects. In PPSN XII, pages 327–

336.

Koza, J. (1992). Genetic programming: On the Program-

ming of Computers by Means of Natural Selection.

MIT Press, Cambridge, 2nd edition.

McDermott, J. e. a. (2012). Genetic programming needs

better benchmarks. In Proceedings of the GECCO ’12,

pages 791–798, New York, NY, USA. ACM.

Miller, J. and Thomson, P. (2000). Cartesian genetic pro-

gramming. In Poli, R. et al. (eds.) EuroGP 2000,

LNCS, vol. 1802, pp. 121–132. Springer.

Ryan, C. and Azad, R. M. A. (2014). A simple ap-

proach to lifetime learning in genetic programming-

based symbolic regression. Evolutionary Computa-

tion, 22(2):287–317.

Ryan, C., Collins, J., Collins, J., and O’Neill, M. (1998).

Grammatical evolution: Evolving programs for an ar-

bitrary language. In LNCS 1391, Proceedings of the

First European Workshop on Genetic Programming,

pages 83–95. Springer-Verlag.

An Improved Single Node Genetic Programming for Symbolic Regression

251
