FEATURE SELECTION BASED ON IMPORTANCE

AND INTERACTION INDEXES

Hierarchical Fuzzy Rule Classifier Application

Vincent Bombardier

, Laurent Wendling

and Emmanuel Schmitt

CRAN, CNRS UMR 7039, Université Henri Poincaré, BP 239, 54506 Vandoeuvre-lès-Nancy Cedex, France

LIPADE, Laboratoire Informatique Paris Descartes, 75270 Paris Cedex 06, France

Keywords: Feature Selection, Pattern Recognition, Fuzzy Rules.

Abstract: This paper proposed an extension of an iterative method to select suitable features for pattern recognition

context. The main improvement is to replace its iterative step with another criterion based on importance

and interaction indexes, providing suitable feature reduced set. This new scheme is embedded on a

hierarchical fuzzy rule classification system. At last, each node gathers a set of classes having a similar

aspect. The aim of the proposed method is to automatically extract an efficient subset of suitable features for

each node. A selection of features is given. The associated criterion is directly based on importance index

and assessment of positive and negative interaction between features. An experimental study, made in a

wood defect recognition industrial context, shows the proposed method is efficient to producing

significantly fewer rules.

1 INTRODUCTION

In many pattern recognition applications, a feature

selection scheme is fundamental to focus on most

significant data while decreasing the dimensionality

of the problem under consideration. The information

to be extracted from the images is not always trivial,

and to ensure that the maximum amount of

information is obtained, the number of extracted

features can strongly increase. The feature selection

area of interest consists in reducing the problem

dimension. It can be translated as being an

optimization problem where a subset of features is

searched in order to maximize the classification rate

of the recognition system.

Because of specific industrial context, there are

many constraints. One constraint is the necessity of

working with very small training data sets

(sometimes, there is only one or two samples for a

specific class because of its rareness). Another

difficulty is to respect the real time constraint in the

industrial production system. So, low complexity

must be kept for the recognition model. Such a

classification problem has been relatively poorly

investigated in the early years (Abdulhady, 2005),

(Yang, 2002), (Murino, 2004). Thus, this work takes

place on a “small scale” domain according to (Kudo

2000), (Zhang, 2002) definition because of the weak

number of used features.

The Fuzzy Rule Iterative Feature Selection

(FRIFS) method proposed in (Schmitt, 2008), is

based on the analysis of a training data set in three

steps. It combines an original Fuzzy Rule Classifier

(Bombardier, 2010) and feature selection associated

to capacity learning has been proposed. This

approach allows reducing the dimensionality of the

problem while keeping a high recognition rate and

improving the system interpretability by discarding

weak parameters.

First a reference set of features is set and the

associated average recognition rate is kept to check

the next training. Then an iterative global feature

selection process is performed and can be roughly

split into two steps:

 Step 1. From the previous set of features, an

interactivity process is applied to determine

the less representative features.

 Step 2. Generate the recognition model

without the first less representative features

and test it. The reached recognition rate is

stored to be compared to the previous step

one.

493

Bombardier V., Wendling L. and Schmitt E..

FEATURE SELECTION BASED ON IMPORTANCE AND INTERACTION INDEXES - Hierarchical Fuzzy Rule Classiﬁer Application.

DOI: 10.5220/0003672704930496

In Proceedings of the International Conference on Evolutionary Computation Theory and Applications (FCTA-2011), pages 493-496

ISBN: 978-989-8425-83-6

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

And so on while minimization is on the way. A

rollback step provides the remaining set of suitable

features. This model has shown its ability to

efficiently detect fibre defects in industrial

application (Schmitt, 2008).

Nonetheless in many industrial applications, it is

interesting to group together classes or products

following their specificities. A new selection scheme

based on hierarchical description is proposed. New

sets of features are assessed by a new criterion

calculated from both importance and interaction

indexes. In this paper, we propose to restrict the

iterative part of FRIFS Method (Steps 1 and 2) by

directly selecting a pertinent subset of features.

This approach is applied to an industrial pattern

recognition problem. The aim is to identify wood

singularities. Comparisons with well-known

selection methods like Sequential Backward Feature

Selection (SBFS) or Sequential Forward Feature

Selection (SBFS) methods, attest of the good

behaviour of our method.

2 SELECTION OF SUITABLE

SUBSET OF FEATURES

2.1 Hierarchical Description

Feature selection based on Choquet integral

(Grabisch, 1994) provided a suitable set of features

to the Fuzzy Rules Classifier (Bombardier, 2010).

As said previously, the rules are then obtained by

learning. This principle is extended here to process

with a hierarchical description associated to classes.

For each node, a set of suitable features is

extracted from an analysis of their degree of

importance combined with their level of positive and

negative interactions (see next section). The selected

subset directly depends on the recognition rates

achieved by considering independently each node

with the FRC and so on in order to process with the

whole description.

2.2 Capacity Indexes

Once the fuzzy measure is learned, it is possible to

interpret the contribution of each decision criterion

in the final decision. Several indexes can be

extracted from the fuzzy measure, helping to analyze

the behavior of DC (Grabisch, 1995). The

importance of each criterion is based on the

definition proposed by Shapley in game theory

(Shapley, 1953). Let a fuzzy measure μ and a

criterion D

be considered:

() ()()

[]

∑∑

⊆−=

−∪

⎟

⎠

⎞

⎜

⎝

⎛

−

DNT

TDT

\1,0

μμμσ

(1)

The Shapley value can be interpreted as a

weighted average value of the marginal contribution

μ(T∪D

) − μ(T) of criterion Di alone in all

combinations.

The interaction index, also called the Murofushi

and Soneda index (Murofushi, 1993), (Rendek,

2006) represents the positive or negative degree of

interaction between two Decision Criteria. If the

fuzzy measure is non-additive then some sources

interact. The marginal interaction between Di and

Dj, conditioned to the presence of elements of

combination T ⊆ X\D

is given by:

()

(

)

()

2!!

ij DD

TNDD

nt t

IDD T

μμ

⊆

−−

=Δ

−

∑

(2)

With:

(

)

(

)

(

)

(

)

(

)

(

)

jijiDD

DTDTTDDTT

−

−−−

∪

And so on, considering any pair (D

) with i ≠

j. Obviously the index are symmetric, i.e

I(μ,D

)=I(μ,D

). A positive interaction index for

two DC D

and D

means that the second one

reinforces the importance of one decision criterion.

In other words, both DC are complementary and

their combined use betters the final decision. The

behaviour is given by the value of the index. A

negative interaction index indicates that the sources

are antagonist.

2.3 Node Features

The aim is to find a suitable subset of features for all

the nodes. Each node is assumed to be a cluster of

classes having similar characteristics. Considering

the whole set of features it is obvious that the set of

suitable parameters for one node could be not the

same for another one. The processing time relies on

the cardinality of the considered hierarchical

description. A selection scheme is introduced to

decrease processing complexity while quickly

focusing suitable sets of features. The method relies

on a combination of both indexes previously

described.

A Shapley value property is Σ

i=1,n

σ(μ, D

)= 1.

Generally values are multiplied by a number of

decision criteria n=|N|. Hence, a DC with an

importance index value less that 1 can be interpreted

FCTA 2011 - International Conference on Fuzzy Computation Theory and Applications

494

as a low impact in the final decision. Otherwise an

importance index greater than 1 describes an

attribute more important than the average that is

(){}

1,/ ≥×∈=

DnNDF

, the weaker:

{

}

FNF \=

Among them, some decision criteria may impact

the recognition by having positive interactions with

selected important criteria. Then, the DCs having an

interaction of order 2 greater to the mean are

selected:

()

⎪

⎭

⎪

⎬

⎫

⎪

⎩

⎪

⎨

⎧

Δ≥Δ⊆=

∑∑

≠

⊆

jiD

FDD

vtjii

FDG

μμ

At last final set

GFN ∪='

is sent to the Fuzzy

Rule Classifier to determine if it improves or not the

recognition using the same learning samples. If the

recognition rate is better than previous epoch one,

the process is run again with N’ instead of N.

Otherwise the previous set of features is kept

(rollback step). This process is run until all the nodes

are studied.

3 EXPERIMENTAL STUDY

The choice of a fuzzy logic-based method for our

application in the wood defect detection field could

be justified by three main reasons. Firstly, the

singularities to be recognized are intrinsically fuzzy

(gradual transition between clear wood and knots for

instance). The features extracted from the images are

thus uncertain (but precisely calculated) and the use

of fuzzy logic allows taking this into account.

Secondly, the customer expresses his needs

under a nominal form; the output classes are thus

subjective and often not separated (non strict

boundary between the classes representing a small

knot and the class representing a large knot). Finally,

the customer needs and the human operator

experience are subjective and mainly expressed in

natural language.

3.1 Wood Defect Recognition Case

The results presented in this section are based on a

real set of samples collected from a wood industrial

case. The objective of this application is to develop a

vision system for singularity identification on

wooden boards used to estimate the quality of the

final products.

During the image segmentation, a set of features

is calculated on the achieved regions to provide a

characteristic vector to the recognition step. This set

is composed with geometrical (SURF, MIN_AXIS,

MAJ_AXIS…) and topological (C1, C2, C3…)

features but we cannot make them explicit because

of confidentiality. We can note those calculated

features are rather basic and simple due to the real

time industrial constraints. So, associated values are

redundant and often contradictory bringing noise to

the final decision.

3.2 Results and Discussion

The classification is done with the features issued

from the segmentation stage performed by the

industrialist. The database is composed of 877

samples divided in nine classes of wood singularities

(called nuodo muerto, grieta, medula, resina …).

The learning database, used to compute the

learning recognition rates, is composed of 250

samples. The generalisation rates are obtained with

the generalisation database constituted by the 627

remaining samples. These databases are relatively

heterogeneous, for instance, the 250 samples of the

learning database are composed of 8, 56 7, 7, 18, 47,

5, 93, 9 samples of the nine classes. The fuzzy

inference engine consists in a single inference where

all the features are in input of the model and all the

classes to recognize in output. Let us consider the

hierarchical description provided in Figure 1.

Figure 1: Example of hierarchical description.

Tests aim to reduce the dimensionality by

removing non-efficient features per node until

reaching an interpretable model while keeping a

“good” recognition rate. Three selection methods are

used: SBFS, SFFS and EXP. Two of them are

automatic feature selection methods used as

references (Pudil, 1994). The third one is an expert

method where the feature sets have been manually

determined.

Each selected feature set is provided for input to

the FRC. This classifier is used in a hierarchical

Dx/Dy

Ln_Re

Gd_Axe

Lr_re

Node 0

Node 1

Node 2

C1 + C3

Pt_Axe

Class1 : Nudo_Firme

Class 2 : Nudo_Suelto

Class 3 : Nudo_Muerto

Class 4 … Class 9

FEATURE SELECTION BASED ON IMPORTANCE AND INTERACTION INDEXES

- Hierarchical Fuzzy Rule Classifier Application

495

version rather than a single node version. Here, the

structure is composed of three nodes as shown in

figure 1. The main advantages are to reduce the total

number of rules of the system, as the rule set of each

node is smallest and also to enhance the recognition

rate. Table 1 shows the learning rates (LR), the

generalisation rates (GR), the number of features

(#Param.) and the number of generated rules

(#Rules) obtained for five methods.

Despite the proposed method provided better

results considering separately each node, the

recognition rates obtained by SFFS, SBFS and the

proposed method (PM) are comparable. Scores

between 97% and 98% are reached for the

generalization step considering the whole database.

The expert selection (EXP) gives rise to a rate

around 96%. The difference is insignificant.

However, the number of parameters extracted by

our method is the lowest assuming the better

interpretability of the model. The numbers of rules

are carried out using expert (EXP: 3775 rules) and

the Proposed Method (PM: 1375 rules). Other

methods lead to a rule number higher than 350 000.

Table 1: Recognition rates and Generated rules.

EXP SFFS SBSF PM

Node 0

LR 96.4% 96.% 96,00% 96.4%

GR 90.59% 91.38% 91.39% 90.59%

#Param 4 2 2 4

#Rules 625

25 25

625

Node 1

LR 78.771% 94.97% 90.50% 78.77%

GR 72.236% 77.64% 74.69% 72.24%

#Param

9 8

#Rules 3125 1953125 390625 3125

Node 2

LR 100.% 100.% 100.% 100.%

GR 96.818%

97.27% 97.27%

96.82%

#Param 2 3 3 2

#Rules

125 125

4 CONCLUSIONS

An enhancement of a Fuzzy Rule Iterative Feature

Selection method has been presented. It allows the

decreasing of learning time processing while

focusing on relevant samples. A suitable set of

features is obtained. Then, FRIFS method is adapted

to handle with a hierarchical fuzzy inference system.

Industrial real-data tests show the efficiency of the

proposed method. The recognition rate is similar to

other methods but the number of features

significantly decreases and thus the number of rules

too. Actually, the extension of our model to provide

selection of parameters per class is under

consideration.

REFERENCES

Abdulhady, M., Abbas, H., Nassar, S., 2005. Performance

of neural classifiers for fabric faults classification. In

proc. IEEE International Joint Conference on Neural

Networks (IJCNN '05), Montreal, Canada, 1995-2000.

Bombardier, V., Schmitt, E., 2010. Fuzzy rule classifier:

Capability for generalization in wood color

recognition. In Eng. Appli. of Artificial Intelligence,

v23, 978-988.

Grabisch, M., Nicolas, J. M., 1994. Classification by fuzzy

integral - performance and tests. In Fuzzy Sets and

Systems, v65, 255-271.

Grabisch, M., 1995. The application of fuzzy integral in

multicriteria decision making. In Europ. journal of

operational research, v89, 445-456.

Kudo, M., Sklansky, J., 2000. Comparison of algorithms

that select features for pattern classifiers. In Pattern

Recognition, v 33, 25–41.

Murino, V., Bicego, M., Rossi, I. A., 2004. Statistical

classiﬁcation of raw textile defects. In Proc. of the

17th Int. Conf. on Pattern Recognition (ICPR’04),

Cambridge, UK, 311- 314.

Murofushi, T., Soneda, S. 1993. Techniques for reading

fuzzy measures(iii): interaction index. In proc. 9th

Fuzzy System Symposium, Sapporo, Japan, 693-696.

Pudil, P., Novovicova, J., Kittler, J., 1994. Floating search

methods in feature selection. In Pattern Recognition

Letters, v15, 1119–1125.

Rendek, J., Wendling, L. 2006. Extraction of Consistent

Subsets of Descriptors using Choquet Integral. In

Proc. 18th Int. Conf. on Pattern Recognition, Hong

Kong, 208-211.

Shapley, L., 1953. A value for n-person games.

Contributions to the Theory of Games. In Annals of

Mathematics Studies. Khun, H., Tucker A., Princeton

University Press 307-317.

Schmitt, E., Bombardier, V., Wendling, L., 2008.

Improving Fuzzy Rule Classifier by Extracting

Suitable Features from Capacities with Respect to the

Choquet Integral. In IEEE trans. On System, man and

cybernetics v38-5 1195-1206.

Yang, X., Pang, G., Yung, N., 2002. Fabric defect

classiﬁcation using wavelet frames and minimum

classiﬁcation error training. In 37th IAS Industry

Application Conference, Pittsburgh, USA, 290–296.

Zhang, H., Sun, G. 2002. Feature selection using Tabu

Search method. In Pattern Recognition, v 35 701–711.

FCTA 2011 - International Conference on Fuzzy Computation Theory and Applications

496
