A WEAKLY SUPERVISED APPROACH FOR LARGE-SCALE

RELATION EXTRACTION

Ludovic Jean-Louis, Romaric Besanc¸on, Olivier Ferret and Adrien Durand

CEA, LIST, Vision and Content Engineering Laboratory, Fontenay-aux-Roses, F-92265 France

Keywords:

Information extraction, Relation extraction.

Abstract:

Standard Information Extraction (IE) systems are designed for a speciﬁc domain and a limited number of re-

lations. Recent work has been undertaken to deal with large-scale IE systems. Such systems are characterized

by a large number of relations and no restriction on the domain, which makes difﬁcult the deﬁnition of manual

resources or the use of supervised techniques. In this paper, we present a large-scale IE system based on a

weakly supervised method of pattern learning. This method uses pairs of entities known to be in relation to

automatically extract example sentences from which the patterns are learned. We present the results of this

system on the data from the KBP task of the TAC 2010 evaluation campaign.

1 INTRODUCTION

In the context of information extraction, the objective

of relation extraction is to ﬁnd if two entities are se-

mantically linked and when it is possible, to deter-

mine the nature of this link. In the work we present

here, we are more speciﬁcally interested in extracting

relations between named entities for building large-

scale knowledge bases. Such building has been re-

cently achieved in the context of Semantic Web by

exploiting semi-structured data from open sources of

information. One of the most representative exam-

ples of this trend is the DBpedia project

(Bizer et al.,

2009), which built a large knowledge base from the

semi-structured part of Wikipedia. The next step in

this process is to supplement such knowledge bases

by exploiting texts, which are a larger but more difﬁ-

cult to deal with source of information, and more par-

ticularly, extracting automatically relations between

entities from them.

Work about relation extraction can be considered

according to the degree of supervision it requires. At

the lower level of supervision, which is also called

unsupervised extraction, the type of the relations to

extract is not ﬁxed a priori, neither by examples nor

a model. Only constraints about the linked entities,

as their type, are set. The type of the extracted re-

lations is deﬁned a posteriori, by gathering similar

relations. Such approach can be found in (Shinyama

http://dbpedia.org/About

and Sekine, 2006) or (Banko and Etzioni, 2008) for

instance. The opposite approach, called supervised

extraction, consists in ﬁxing both the type of the tar-

get relations and the means for extracting them from

texts. It takes the form of either a handcrafted model,

typically deﬁned as a set of rules, or a model built by

a machine learning algorithm from a set of contex-

tualized relation examples coming from a manually

annotated corpus. This second option is mostly repre-

sented by statistical machine learning models focus-

ing on taking into account various kinds of features

(lexical, syntactic, semantic ...) (Zhou et al., 2005),

for instance by ﬁnding kernel functions dealing with

complex structures such as those produced by syntac-

tic parsers (Zhou et al., 2007).

Between these two extrema, weakly supervised

approaches refer to cases where either examples or

a model are provided but are not sufﬁcient for devel-

oping a fully operational relation extraction system.

As a consequence, this initial deﬁnition must be ex-

tended in an automatic way, generally by exploiting

an unannotated corpus. Work in this area shows two

main cases, that can be eventually combined, of un-

derspeciﬁcation of this initial deﬁnition:

• underspeciﬁcation due to the extent of the deﬁni-

tion. Only a small set of relation examples or an

incomplete model are given;

• underspeciﬁcation due to the nature of the def-

inition, which occurs when the examples or the

model have to be instantiated for being used.

Jean-Louis L., Besançon R., Ferret O. and Durand A..

A WEAKLY SUPERVISED APPROACH FOR LARGE-SCALE RELATION EXTRACTION.

DOI: 10.5220/0003661200940103

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2011), pages 94-103

ISBN: 978-989-8425-79-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

The ﬁrst case is classically tackled following the

methodology of (Hearst, 1992) by the means of a

bootstrapping mechanism: starting from a model of

the target relations made of a restricted set of ini-

tial examples or extraction rules, new examples are

acquired from a corpus and used for completing the

model. This two-step process is re-applied while the

model is not developed enough for covering any new

example. (Agichtein and Gravano, 2000) is a typical

application of such methodology in the case of rela-

tions between named entities.

The second case is represented by the recent no-

tion of Distant supervision, introduced explicitly by

(Mintz et al., 2009) but already present in previous

work about bootstrapping. Examples are given in this

approach with an underspeciﬁed form as they are lim-

ited to pairs of entities: they are given both without

context and without a linguistic form. The develop-

ment of such approach is favored by the availability of

large knowledge bases extracted from resources such

as Wikipedia.

In this article, we present a large-scale informa-

tion extraction method based on a weakly supervised

learning of relation extraction patterns. Moreover,

this learning starts from relation examples reduced to

pairs of named entities. These pairs are then mapped

onto a reference corpus for building the set of con-

textualized relation examples from which the extrac-

tion patterns are learned. This process comes under

what we have called above the Distant supervision ap-

proach. We also present the results of the evaluation

of our method in the framework deﬁned by the KBP

(Knowledge Based Population) track of the TAC 2010

(Text Analysis Conference) evaluation.

2 OVERVIEW

We focus in this work on a large-scale extraction of

relations with the hypothesis that a speciﬁc knowl-

edge base (KB) already exists. This KB is partially

ﬁlled with relations that are automatically acquired

from semi-structured data. We limit our study to the

relations between named entities because we want to

rely on entities that are usually well recognized but

we do not focus our work on a speciﬁc domain where

the entity recognition could be guided by a known ter-

minology. The idea of “large-scale” extraction actu-

ally covers several aspects. The ﬁrst one corresponds

to the large number of relation types that are consid-

ered, which implies that a rule-based approach based

on handcrafted rules is hardly possible. A second as-

pect is the existence of a large number of existing re-

lations (i.e. the association of two entity values with

a relation type). These relations give a good start-

ing point for machine learning techniques to learn a

model for these types of relations. Finally, a third as-

pect is the large size of the collection of documents in

which the new relations are searched, which implies

the use of information retrieval techniques to retrieve

good candidates on which a more sophisticated ex-

traction is then performed (we cannot apply patterns

for instance on all the sentences of such corpus).

This approach, as presented in Figure 1, is com-

posed of two steps: a ﬁrst step of pattern learning

from occurrences of known relations and a step of re-

lation extraction for the discovery of new relations.

The ﬁrst step starts with known instances of rela-

tions R(E1,E2) to ﬁnd occurrences of these relations

in texts for covering as many different ways of ex-

pressing them as possible; then we use these occur-

rences to learn a set of patterns associated with the

target type of relation. The second step starts with

incomplete relations R(E1,x), where the source entity

E1 is known and the target entity x has to be discov-

ered, and searches occurrences of relation R involv-

ing E1 in a collection of texts. The entity x is then

extracted using the patterns learned in the ﬁrst step.

These two steps are described in more details in the

following sections.

2.1 Relation Pattern Learning

Our procedure for learning relation patterns relies on

the induction of lexical patterns from example sen-

tences containing occurrences of the target relations.

Its objective is to model the different ways a seman-

tic relation between two entities is linguistically ex-

pressed. For instance, the two sentence excerpts be-

low contain relation occurrences for the type of rela-

tion founded by with the entity pairs (Charles Revson,

Revlon Cosmetics) and (Mayer Lehman, Lehman

Brothers investment):

The glamourous cabaret chanteuse reportedly had

had a romantic liaison with <source>Charles

Revson</source>, the founder of <target>Revlon

Cosmetics</target> ... – Lehman was a great-

grandson of <source>Mayer Lehman</source>,

a founder of the <target>Lehman Brothers

investment</target> house ...

A lot of algorithms for building and generaliz-

ing lexical patterns were already proposed (Ravichan-

dran, 2005; Ruiz-Casado et al., 2007). Our approach

is similar to (Pantel et al., 2004) and follows more

directly the method of (Embarek and Ferret, 2008).

Starting with a pair of entities and two sentences con-

taining these entities and expressing the target rela-

tion, its principle is to ﬁnd and to capture the ele-

A WEAKLY SUPERVISED APPROACH FOR LARGE-SCALE RELATION EXTRACTION

Knowledge base

rel(E1,E2)

Incomplete relations

rel(E1,?)

corpus

Retrieval of relation

occurrences

Pattern induction

Retrieval of candidate

sentences

Application of patterns

Relation extraction and

selection

Relation filtering

Learning of relation patterns Extraction of relations

Relation patterns

Expansion

corpus

Extracted relations

founded(Metawe,2005)

founded(HDNet,2001)

... network was HDNet, founded in 2001 by Dallas..

Metaweb, founded in 2005 is a spinoff company.

<E1>, founded in <E2>

country(Bernama,?)

Bernama

Malaysaian National news agency

… relations between Malaysia and Britain,

the state Bernama news agency …

News agency Bernama says Malaysian

prime minister will ...

… relations between Malaysia and Britain,

the state Bernama news agency …

Malaysia

Figure 1: Overview of the system.

ments that are shared by the two sentences in the sur-

rounding context of the two entities. More speciﬁ-

cally, we identify these shared elements among three

levels of linguistic information about words: inﬂected

form, lemma and part-of-speech category. These lev-

els of information are produced by the OpenNLP

tools, also used for named entity recognition. Having

these three levels enables the building of more expres-

sive patterns that represent an interesting compromise

in terms of generalization between the speciﬁcity of

lexicalized elements and the more general nature of

part-of-speech categories.

The induction of a pattern from two occurrences

of relations relies more precisely on the three follow-

ing steps:

• computation of the minimal edit distance between

the two example sentences, that is to say, the min-

imal number of edit operation (insertion, deletion

and substitution) that are necessary to turn one

sentence into the other one. All the operations are

given here the same weight;

• optimal alignment between the two example sen-

tences from the matrix of distances between sub-

sequences resulting from the computation of the

edit distance. The classical algorithm for achiev-

ing such alignment is enhanced for enabling a

match of two words at one of the three available

levels of information when two words are tested

for a substitution;

• building of patterns by completing alignments

with two wildcard operators when it is necessary:

(*s*) stands for 0 or 1 instance of any word while

(*g*) represents exactly 1 instance of any word.

http://opennlp.sourceforge.net/index.html

Table 1 shows the result of the induction of a pat-

tern for the type of relation founded by from the two

sentence excerpts above.

Table 1: Example of pattern induction.

Charles Revson , the founder of

Revlon Cos-

metics

Mayer Lehman , a founder of the

Lehman

Brothers

investment

<source> , DET founder of (*s*)

This example illustrates our different levels of

generalization: for a word such as of, only the in-

ﬂected form is taken. In the case of a word such

as founder, the inﬂected form is taken here but the

lemma level would be selected for an excerpt such

as X, the founders of ... At a higher level of gen-

eralization, the part-of-speech category DET (deter-

miner) covers a and the, which makes the resulting

pattern relevant for an excerpt such as ”Charles Ket-

tering, another founder of DELCO ...”. This exam-

ple also illustrates the use of wildcards as a substi-

tute for any word, that is to say the highest level of

generalization. As it is always possible to generalize

two sentences by a pattern only made of wildcards,

ﬁxing an upper limit to the number of wildcards that

can used in the generalization process is necessary for

having patterns that are speciﬁc enough to the target

type of relation. Moreover, as our work is open do-

main and based on general named entities, we prefer

to induce a large number of speciﬁc patterns rather

than a small set of very general patterns to favor on

precision. This argument also accounts for our choice

of not generalizing patterns themselves by applying

to them the generalization process described above.

Thus, the maximal number of wildcards in a pattern

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

is set to 1 in the evaluation of section 3.

In the context of distant supervision in which our

work takes place, example sentences are not directly

available but result from the mapping onto a corpus

of relations given as pairs of entities (for instance, the

pair (Ray Charles, Albany) for the type of relation

city of birth). More concretely in our case, they are

obtained by querying a search engine with pairs of

entities corresponding to relations of the target type

and by restricting its results to sentences that actually

contain a pair of entities. The nature of these restric-

tions has of course a direct impact on the quantity and

the precision of ﬁnal patterns: the more severe they

are, the less example sentences we get but the better

the induced patterns are. (Agirre et al., 2009) adds for

instance the constraint that the two entities of a rela-

tion pair must not be separated in a sentence by more

than ten words.

Another important issue concerning the induction

of patterns is its computational cost. This process is

performed by considering each pair of example sen-

tences, which can have a too high computational cost

when the number of example sentences is signiﬁcant:

for 10,000 examples, around 50 millions of distinct

pairs of sentences have to be compared (n(n − 1)/2

exactly). The most straightforward way to solve this

problem is to reduce drastically the number of exam-

ple sentences before the induction of patterns. How-

ever, such solution implies having a smaller coverage

of the different linguistic expressions of a type of re-

lation if this reduction is performed blindly. Our so-

lution to this problem exploits the fact that two sen-

tences sharing a small number of words will not lead

to an interesting pattern. The distance we use for in-

ducing patterns – the edit distance – was chosen be-

cause of its ability to take into account the order of

words but of course, it ﬁrst depends on the number of

words the two compared sentences share. As a con-

sequence, the a priori ﬁltering of example sentence

pairs can be based on the computation of a similarity

measure between sentences that only exploits a bag

of words representation of them, as the cosine mea-

sure, and the application of a minimal threshold to

these similarity values for discarding pairs that are

not likely to lead to an interesting pattern. The co-

sine measure can be computed efﬁciently, either ap-

proximately, by using methods such as Local Sensi-

tive Hashing (Gionis et al., 1999), or without any ap-

proximation but the necessity to ﬁx an a priori min-

imal similarity threshold, which corresponds to our

case. We chose more precisely the All Pairs Similarity

Search (APSS) algorithm proposed in (Bayardo et al.,

2007) which computes the cosine measure only for

the pairs of objects – example sentences in our case –

whose similarity is higher or equal to a ﬁxed thresh-

old. This algorithm relies on the incremental index-

ing of the objects whose similarity has to be evaluated

and implements a set of optimizations of this indexing

process based on both data gathered a priori about the

features of these objects and their sorting according to

these features.

More precisely, we have two levels of ﬁltering

based on APSS. Learning patterns from a large num-

ber of example sentences often leads to several oc-

currences of the same pattern, either because an ex-

ample sentence is found in several documents or be-

cause there are several occurrences of the same lin-

guistic expression of a type of relation with differ-

ent entity values (Obama’s height is 1.87m; Sarkozy’s

height is 1.65m). As a consequence, we ﬁrst apply

a high similarity threshold for identifying and dis-

carding identical sentences; second, a lower thresh-

old aims at checking that sentences are similar enough

for inducing a meaningful pattern. In order to reduce

further the number of comparisons between example

sentences, the similarity values resulting from APSS

are exploited for clustering these sentences by rely-

ing on the Markov Clustering algorithm (van Don-

gen, 2000). Finally, patterns are induced only from

sentences that are part of the same cluster.

2.2 Relation Extraction

The extraction of new relations is done from the ex-

isting types of relations and given entities: we are

searching to add knowledge to an existing knowledge

base by adding missing attributes to entities already

in the KB. The ﬁrst step of relation extraction is the

selection of candidate sentences that are likely to con-

tain the expression of a relation. It starts from a query

containing one entity associated with its type and the

type of the target entity. The retrieval of the candi-

date sentences is performed, as in the pattern learn-

ing step, using a search engine in which the target

corpus has been indexed. In our experiments, we

used Lucene

, with an indexing process taking into

account the speciﬁc needs of our task: documents

were segmented into excerpts of three sentences us-

ing a sliding window and the resulting segments were

indexed by their plain words and their named enti-

ties with their type. Moreover, we also performed a

kind of query expansion focusing on the source en-

tity. Indeed, the source entity sometimes appears in

the target base of documents under a slightly differ-

ent form than in the query: for instance, Bill Clin-

ton is often used instead of William Jefferson Blythe

http://lucene.apache.org

A WEAKLY SUPERVISED APPROACH FOR LARGE-SCALE RELATION EXTRACTION

III Clinton, which is the normalized form of the en-

tity in the KB. The expansion is based on an expan-

sion database automatically built from Wikipedia

each entity is expanded by all the formulations ex-

tracted from the redirection pages of Wikipedia for

this entity. This expansion database contains alterna-

tive forms for 2.4 million entities and, starting from

an entity such as Barack Obama, makes it possible to

retrieve documents referring to {B. Hussein Obama,

Barack H. Obama Junior, Barack Obama Jr, Barack

Hussein Obama Jr., etc.}.

As we only deal with intra-sentential relations, the

retrieval of document excerpts is followed by the ver-

iﬁcation that the source entity co-occurs with a pos-

sible target entity in a sentence. The detection of the

target entity is based on the presence of compatible

named entities but also on reference lists of values for

types, as in the relation per:title, that do not corre-

spond to named entities. We then apply the patterns

learned in the ﬁrst step to all candidate sentences. The

target entities extracted by these patterns are gathered

and sorted. We only keep the most frequent entities:

our hypothesis is that the more relevant the target en-

tities are the more often they appear in documents

together with the source entity. For relations with a

unique target entity (e.g. date of birth), we choose

the most frequent entity. For relations with several

possible target values (e.g. places of residence), an

arbitrary number of three values is taken since we

do not have knowledge (either prior knowledge or

learned from documents) about the correct number of

values. Finally, a ﬁlter is applied to the target enti-

ties to check the compatibility of their value with con-

straints relative to the type of information we search.

These constraints are deﬁned by lists of values or reg-

ular expression. For instance, we check that the coun-

try of birth of a person is part of a list of known coun-

tries as the named entity type for the target entity –

location – is not speciﬁc enough to guarantee the va-

lidity of the found information.

3 EVALUATION

We present in this section our system’ results on the

data of the Slot Filling task of the TAC-KBP 2010

(TAC-KBP, 2010) evaluation. Our experiments have

been carried out for English. The Slot Filling task

matches the scope of our work as deﬁned in section 2:

the task aims at extracting from a large corpus the tar-

get entity of a relation, given that its source entity is

More precisely, we used the Wikipedia dump pro-

vided by the university of New York http://nlp.cs.nyu.edu/

wikipedia-data.

part of a knowledge base that contains a large collec-

tion of examples of the target relation type. In this

context, 42 relation types are considered, 16 relations

for entity type ORGANIZATION (ORG) and 26 rela-

tions for entity type PERSON (PER). The list of these

relation types is presented in Table 2. Note that all the

experiments were conducted in parallel for all relation

types on a 24 nodes (4 processors/node) cluster.

3.1 Evaluation Framework

The evaluation material from the TAC-KBP track is

made of the following data:

• a 1.8 million documents text corpus (1,780,980

exactly) divided into 0.04% of transcripts (broad-

cast conversations, broadcast news, conversa-

tional telephone speech), 72.24% of newswire

data and 27.72% Web pages;

• a knowledge base (KB) built from an October

2008 Wikipedia snapshot: each page containing

an infobox was assigned a unique identiﬁer to-

gether with an entity type among types person, or-

ganization, geopolitical entity and unknown, de-

pending on the ﬁelds in the infobox. Typically,

pages from infobox Infobox Actor were associ-

ated with type person. Finally, 818,741 entries

were selected to populate the KB, each entry be-

ing associated with a set of properties (the ﬁelds

from the infobox) and a description text. As a

consequence, relations in the KB are represented

as tuples (identiﬁer, infobox type, name, prop-

erty, value), e.g., (E0000437; Infobox Actor; Ju-

lia Roberts; PER; birthplace; Atlanta);

• a mapping of Wikipedia properties to the

relation types of the evaluation. For in-

stance, Infobox Actor:birthplace is mapped to

per:city of birth. This mapping is a way of tak-

ing into account the heterogeneous nature of the

labels of Wikipedia properties;

• a list of 100 source entities for which target en-

tities have to be extracted for all the target rela-

tion types. Among those entities, 15 are already

present in the KB while 85 are new. Moreover, we

only focus in this study on the relations of a source

entity for which a target entity was actually found

in the corpus

, that is to say, a total of 2,069 rela-

tions. Their distribution according to their type is

presented in column Nb Ref. of Table 2.

The list of target entities that are present in the corpus

was built by the KBP organizers from the results of all par-

ticipants.

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

Table 2: Results for the different steps, by relation type.

Relation type Target type Doc. Rec (%) Rel. Rec (%) Nb Learn. Nb Test Nb Induc. Nb Patterns Pattern Cov. (%) Nb Ref.

org:alternate names ORG 89.17 33.33 20,013 10,006 214 6,007 66.10 120

org:city of headquarters LOC + list 90.12 59.26 6,847 3,423 4,553 2,010,749 65.52 81

org:country of headquarters LOC + list 91.04 55.22 18,401 9,200 2,110 185,158 69.56 67

org:dissolved DATE 100 25 532 266 87 775 0 4

org:founded by ORG/PER 95.45 31.82 1,954 977 197 4,385 77.87 28

org:founded DATE 92.86 53.57 13,688 6,844 127 22,482 77.34 22

org:member of ORG 100 100 7,951 3,976 102 103 70 2

org:members ORG 77.78 11.11 531 265 183 552 86 9

org:number of employees members regexp + list 90.48 23.81 7,173 3,586 216 3,109 100 21

org:parents ORG 96.67 43.33 22,361 11,181 3,013 485,947 69.04 30

org:political religious afﬁliation ORG 78.57 64.29 3,427 1,713 406 3,250 55.36 14

org:shareholders ORG/PER 66.67 33.33 3 2 0 0 0 3

org:stateorprovince of headquarters LOC + list 92.65 63.24 9,672 4,836 1,422 148,610 69.93 68

org:subsidiaries ORG 82.69 28.85 5,588 2,794 498 3,764 56.48 52

org:top members employees PER 91.48 37.22 40,929 20,464 108 1,010 70.57 223

org:website regexp 78.26 30.43 30,813 15,407 32 28 0 23

per:age regexp + list 85.32 32.11 157 79 3 1 0 109

per:alternate names PER 61.63 11.63 18,115 9,057 68 2,818 82.58 86

per:cause of death list 100 0 1 1 0 0 0 2

per:charges list 61.54 0 184 92 0 0 0 13

per:children PER 72 16 2,010 1,005 147 238 0 25

per:cities of residence LOC + list 77.59 34.48 3,631 1,815 722 14,297 77.88 58

per:city of birth LOC + list 69.23 15.38 4,745 2,373 2,252 62,455 63.34 13

per:city of death LOC + list 100 100 1,631 816 505 2,860 70.27 1

per:countries of residence LOC + list 73.53 20.59 8,098 4,049 2,181 205,344 80.08 34

per:country of birth LOC + list 82.35 5.88 11,085 5,542 11,192 9,145,385 65.02 17

per:country of death LOC + list 2,873 1,436 1,068 22,374 62.89 0

per:date of birth DATE 90 20 11,689 5,845 30 22 0 20

per:date of death DATE 100 0 4,692 2,346 54 63 33.33 1

per:employee of ORG 84.21 29.32 24,762 12,381 2,435 704,833 71.13 133

per:member of ORG 82.42 36.26 27,523 13,761 3,901 740,999 57.25 91

per:origin list 81.58 42.11 37,626 18,813 2,710 276,653 74.41 76

per:other family PER 86.67 33.33 4 2 0 0 0 30

per:parents PER 78.13 9.38 1,314 657 37 604 77.78 64

per:religion list 85.71 57.14 1,468 734 515 1,575 80 7

per:schools attended ORG + list 87.50 37.50 2,246 1,123 67 170 4.17 16

per:siblings PER 78.26 20.29 4 2 0 0 0 69

per:spouse PER 80 35.56 5,385 2,693 3,094 314,329 80 45

per:stateorprovince of birth LOC + list 80 50 7,047 3,523 2,097 60,782 75.42 10

per:stateorprovince of death LOC + list 100 100 1,616 808 278 911 66.67 1

per:states or provinces of residence LOC + list 84.21 50 4,980 2,490 1,166 115,418 77.90 38

per:title list 84.55 52.77 31,574 15,787 8,797 1,573,512 49.07 343

Target type: method for the ﬁnal identiﬁcation of the target entity. Doc. Rec.: recall of sentence retrieval in terms of reference documents. Rel. Rec.: recall of

candidate sentences in terms of reference documents. Nb Learn.: number of relations used for pattern learning. Nb Test: number of relations used for evaluating

patterns. Nb Induc.: number of sentences containing relation occurrences used for pattern induction. Nb Patterns: number of patterns induced from occurrences

of relations. Patterns Cov.: coverage of induced patterns. Nb Ref.: number of reference relations.

3.2 Evaluation of Pattern Learning

Patterns are used to conﬁrm/deny the existence of a

relation among two entities. As a consequence, it is

important to ensure that the induced patterns have a

high enough coverage to take into account as many

variants as possible among the occurrences of rela-

tions. To assess the quality of these patterns, we di-

vided the relations from the KB into a training set (2/3

of the relations) and a test set (1/3 of the relations) and

we measured the coverage of the patterns by comput-

ing the percentage of relation occurrences of the test

set that were found by applying the patterns learned

from the relation occurrences of the training set. We

used for this evaluation the previously described TAC-

KBP 2010 corpus. It should be noted that using this

corpus to evaluate the extraction of relations does not

invalidate its use for patterns learning since the rela-

tions are different for both tasks.

We provide in Table 2 the number of relations in

the training and test sets in columns Nb Learn. and Nb

Test respectively. The number of sentences that con-

tain occurrences of relations used for pattern general-

ization is shown in the column Nb Induc. The number

of patterns generated from these candidate sentences

is shown in the column Nb Patterns of the same table.

For instance, if we consider the relation type

org:alternate names, only 214 candidate sentences

demonstrating an evidence of the relation are selected

from the 20,013 relations of the training set. These

214 sentences are then used to generate 6,007 pat-

terns with a coverage of 66.10% (i.e. we ﬁnd 66.10%

of the sentences containing occurrences of the 10,006

test relations). The large gap between the 20,013 rela-

tions and the 214 sentences is due to two main factors:

• a constraint applied during the selection of the

candidate sentences: we only keep the sentences

in which the named entities are fully recognized,

whereas named entities can be partially (or im-

properly) recognized by linguistic processing;

• the nature of documents in the corpus: 72% of

A WEAKLY SUPERVISED APPROACH FOR LARGE-SCALE RELATION EXTRACTION

documents are news articles published between

January 2008 and August 2009, which explains

the lack of documents, if any, regarding some per-

sons or organizations existing in the KB.

Detailed results regarding the pattern coverage for

each relation type are presented in column Patterns

Cov. of Table 2. As far as efﬁciency is concerned, the

computation time for pattern generalization concern-

ing for instance the relation type per:country of birth

(11,192 sample sentences to compare) drops from

690mn and 5s without ﬁltering to 30s with ﬁltering

which illustrates the beneﬁt of this operation in terms

of computation time.

3.3 Evaluation of Relation Extraction

The relation extraction process is composed of sev-

eral steps, each of them inﬂuencing the overall result.

Consequently, we performed separate evaluations for

the retrieval of the candidate sentences and the core

relation extraction process.

3.3.1 Retrieval of Candidate Sentences

A prerequisite for extracting relevant relations is en-

suring that the search engine returns enough relevant

documents so that we can identify the target entities.

We measured the coverage based on the document

search result, i.e. the percentage of documents re-

trieved by the index that are in the reference. We tried

several strategies by testing different values for pa-

rameters such as the number of retrieved documents

or whether to use query expansion or not. From this

evaluation, the best conﬁguration is to query the index

using the source entities and their expansions together

with considering the top 1,000 returned documents:

this conﬁguration allows retrieving 84.24% of refer-

ence documents. Detailed results by relation type are

provided in the column Doc. Rec. of Table 2.

The candidate sentences for a given relation type

are selected based on previously retrieved documents

by ensuring that each sentence contains both the

source entity and the entity type of the target en-

tity. The quality and the number of candidate sen-

tences are largely affected by the named entity recog-

nition process. Since we do not have a reference for

named entities in the corpus, we cannot evaluate the

loss caused by entity recognition errors. However, we

evaluated the proportion of reference documents in

which we found candidate sentences. This informa-

tion allows to set an upper bound for the percentage

of relations that could be extracted if the following

The version with ﬁltering being parallelized, the time

given is a sum of the time recorded for each processor.

steps performed ideally. We obtained a total cover-

age of 37.55% of sentences belonging to documents

of the reference. The breakdown by relation type is

presented in the column Rel. Rec. of Table 2.

3.3.2 Relation Extraction

To evaluate the extracted relations, we used the met-

rics and the tools provided for the TAC-KBP cam-

paign

. The judgment about the correctness of a re-

lation is only based on the entity string with no re-

striction to the documents of the reference

. Table 3

summarizes our results regarding this evaluation –

grouped for all relation types – and demonstrates the

impact of the ﬁltering of target entities in terms of re-

call (R), precision (P) and f1-measure (F1). Note that

the ﬁltering process ensures that target entities match

some regular expressions and/or belong to a list of

closed values. Column Target type in Table 2 presents

the type of ﬁltering applied for each relation type.

On one hand, results in Table 3 show that the ﬁlter-

ing of target entities improves the performance of the

system (average +2.74% f1-measure). On the other

hand, they validate the assumption that patterns in-

duced using the APSS are as relevant as those induced

by considering every pair of relation examples (in this

case, there is an improvement of +1.72% f1-measure

on average).

Table 3: Impact of target entities ﬁltering.

Before ﬁltering After ﬁltering

R. (%) P. (%) F1. (%) R. (%) P. (%) F1. (%)

All relation

pairs

16.28 11.20 13.26 18.07 13.66 15.56

APSS

16.90 12.76 14.54 18.67 16.87 17.72

Table 4 presents results from various systems on

two similar corpus, KBP 2009 and KBP 2010 corpus,

the latter adding to the ﬁrst one Web documents and

transcripts, a priori more difﬁcult to process. These

ﬁgures cover only the relations that are actually in the

corpus. Hence, they integrate a constraint that the Slot

Filling participants had to deal with and that is not

taken into account in our system since it was devel-

oped outside the campaign, namely to decide whether

the relation exists in the corpus. In this table, columns

2009 and 2010 denote the scores of the top three and

last three systems for KBP 2009 and KBP 2010. (Ji

et al., 2010) have shown that out of 492 reference re-

lations, 60.4% were within the same sentence while

the remaining 39.6% were cross-sentence: such re-

lations are handled by using coreference resolution

http://nlp.cs.qc.cuny.edu/kbp/2010/scoring.html

In fact, the reference is not complete as it was built

using only TAC-KBP participants’ outputs.

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

100

or by applying inference mechanisms. Therefore, we

have distinguished in the column 2010 (a) of Table 4

the scores of systems that are more directly compa-

rable to ours because they only deal with relation ex-

traction within the same sentence.

The top system of KBP 2010 (Chada et al., 2010)

clearly outperforms others: +36.63% compared to the

second and +4.68% compared to a human annotator.

This performance is based both on the use of a manu-

ally annotated corpus – 3 million documents (not in

the KBP corpus) – and the use of mechanisms for

cross-sentence relation extraction: pronominal coref-

erence resolution, metonymy between entities, reso-

lution of semantic dependencies between words and

entities, etc. Using an additional corpus seems to be a

crucial factor compared to the other top systems while

these ones differentiate themselves from the median

results by taking into account cross-sentence rela-

tions. The worst results, especially for 2010, mainly

come from systems under development.

Regarding our system, Table 4 situates our re-

sults in the average of those obtained by KBP 2010

participants and in the top three systems based on

within sentence relation extraction approaches. In the

latter case, the most efﬁcient approach (29.15% f1-

measure) (Byrne and Dunnion, 2010) uses a set of

manually constructed rules that achieves a precision

score (66.55%) equivalent to the best score of the

campaign (66.80%) and a recall score (18.67%) lying

in the average score (15.33%). This strong imbalance

between precision and recall is rather symptomatic of

manual approaches.

Table 4: Results on TAC-KBP data (f1-measure).

TAC KBP systems

2009 2010 2010 (a)

Nb. submissions (N)

/ participants

N=16 / 8 N=31 / 15 N=18

Human annotator

58.99% 61.10% 61.10%

score

34.35% 65.78% 29.15%

score

25.05% 29.15% 14.22%

score

18% 28.29% 14.13%

(N-2)

score

5.90% 0.55% 0.55%

(N-1)

score

2.60% 0.19% 0.19%

score

1.75% 0.08% 0.08%

Our system

– 17.72% 17.72%

Mean

13.43% 17.49% 9.71%

Median

13.93% 14.13% 12.27%

4 RELATED WORK

Large scale relation extraction, within the meaning

deﬁned in section 2, is a recent issue. Nevertheless,

by means of evaluations such as TAC-KBP, it has been

the subject of several works suggesting different ap-

proaches.

Concerning speciﬁcally the extraction of relations,

three main trends appear: using statistical learning

(Agirre et al., 2009; Chen et al., 2010b), using lexi-

cal pattern generalization (Li et al., 2009; McNamee

et al., 2009) and ﬁnally, tuning already existing sys-

tems for relation detection (Bikel et al., 2009). Com-

pared to the 2009 edition, rule-based approaches,

such as (Byrne and Dunnion, 2010), were introduced

in KBP 2010 as well as approaches based on Distant

supervision and classiﬁers (Surdeanu et al., 2010).

Our approach relies on lexical pattern generalization

and assumes, as in (Mintz et al., 2009), that the mere

presence of a pair of entities in a sentence is infor-

mative enough to indicate the effective presence of

a relation between these entities. In fact, this is not

always the case and thus we believe it is important

to ﬁlter the examples used for patterns generalization

beforehand as suggested by (Riedel et al., 2010).

Like our system, most systems developed for KBP

2009 do not exploit the dependencies among relation

types: for instance, there is an implicit link between

the age and the birth date of a person. However, in

(Chen et al., 2010a), the authors show that the results

obtained in (Li et al., 2009) (31.96% f1-measure) can

be improved (they get 34.81% f1-measure) by inte-

grating dependencies between relations using infer-

ence rules based on a ﬁrst order logic extension. In

our work, we try to avoid integrating knowledge that

is too dependent on the relation types in order to have

a more generic approach, easily adaptable to other do-

mains. Finally, (Chada et al., 2010) showed in KBP

2010 a very signiﬁcant increase in terms of perfor-

mance by integrating mechanisms for extracting rela-

tions beyond the sentence space: given the percentage

of relations that occur between sentences, such mech-

anisms seem necessary and we plan to integrate them

in our future work.

From a different angle, (Li et al., 2009) distin-

guished itself in KBP 2009 by using a two-step rela-

tion extraction process: the ﬁrst aimed at ﬁnding po-

tential target entities within the documents of the eval-

uation corpus by using patterns of relations; the sec-

ond aimed at ﬁnding additional potential target enti-

ties that had been missed by the ﬁrst step, by applying

the relation patterns on a recent Wikipedia snapshot.

The potential target entities retrieved by the process

were retained only if they can be found in a docu-

ment from the corpus. Additional entity acquisition

signiﬁcantly increases their scores (they gain +9% f1-

measure compared to (Bikel et al., 2009)) but this

process implies using an external corpus that can be

viewed as closely related to the KB. In addition, re-

A WEAKLY SUPERVISED APPROACH FOR LARGE-SCALE RELATION EXTRACTION

101

sults on KBP 2010 have shown that the overall perfor-

mance could be improved without such complemen-

tary resource and that the effect of such process on

ﬁnal results were lower compared to KBP 2009 (we

even observe a negative impact).

5 CONCLUSIONS AND

PERSPECTIVES

In this article, we present an information extraction

system designed for the large-scale extraction of at-

tribute relations between named entities. The “large-

scale” qualiﬁcation is meant for both the integration

of a large number of types of relations and the search

of these relations in a large corpus. This system is

based on a weakly supervised approach in which the

examples are limited to pairs of entities in relation.

The extraction of relations is performed by the ap-

plication of lexico-syntactic patterns that are learned

from occurrences of relations automatically selected

from the entity pairs of the examples and used to rep-

resent the relation types. We evaluate our approach

using the evaluation framework from the Slot Fill-

ing task of the KBP evaluation campaign, concentrat-

ing on the problem of relation extraction itself (we

did not consider the case where the relation is not

present in the target corpus). The results obtained in

this context are comparable to the results obtained by

the participants of 2010 campaign, which we consider

promising for our system, since it is designed to be

generic and is not tuned to deal with the speciﬁcities

of the types of relations used in this campaign. We

also show that speciﬁc techniques used to deal with

the large-scale aspect of the task, such as the ﬁlter-

ing of the examples with the APSS technique, do not

decrease the performance and can even contribute to

improve it.

We are currently working on the improvement of

our system, trying to keep the idea of a generic sys-

tem with respect to the type of relation considered. In

particular, we focus on the pattern learning step: we

are considering both the use of a more important num-

ber of examples to learn the pattens and the improve-

ment of the quality of the examples. These two points

are connected because, usually, in order to get more

examples, we need to relax a constraint on the selec-

tion of the examples, which will generally increase

the number of false examples. To avoid this draw-

back, we will explore the use of a relation ﬁltering

module which is capable of determining if a sentence

contains a relation between two entities or not with-

out any consideration on the nature of the relation (as

in (Banko and Etzioni, 2008)).

ACKNOWLEDGEMENTS

This work was partly supported by the FP7 Virtuoso

project.

REFERENCES

Agichtein, E. and Gravano, L. (2000). Snowball: Extracting

Relations from Large Plain-Text Collections. In 5

ACM International Conference on Digital Libraries,

pages 85–94, San Antonio, Texas, USA.

Agirre, E., Chang, A., Jurafsky, D., Manning, C.,

Spitkovsky, V., and Yeh, E. (2009). Stanford-UBC at

TAC-KBP. In Second Text Analysis Conference (TAC

2009), Gaithersburg, Maryland, USA.

Banko, M. and Etzioni, O. (2008). The Tradeoffs Between

Open and Traditional Relation Extraction. In ACL-08:

HLT, pages 28–36, Columbus, Ohio.

Bayardo, R., Ma, Y., and Srikant, R. (2007). Scaling Up All

Pairs Similarity Search. In 16

International Confer-

ence on World Wide Web (WWW’07), pages 131–140,

Banff, Alberta, Canada.

Bikel, D., Castelli, V., Radu, F., and jung Han, D. (2009).

Entity Linking and Slot Filling through Statistical Pro-

cessing and Inference Rules. In Second Text Analysis

Conference (TAC 2009), Gaithersburg, USA.

Bizer, C., Lehmann, J., Kobilarov, G., Auer, S., Becker, C.,

Cyganiak, R., and Hellmann, S. (2009). DBpedia - A

crystallization point for the Web of Data. Journal of

Web Semantics, 7:154–165.

Byrne, L. and Dunnion, J. (2010). UCD IIRG at TAC 2010

KBP Slot Filling Task. In Third Text Analysis Confer-

ence (TAC 2010), Gaithersburg, Maryland, USA.

Chada, D., Aranha, C., and Monte, C. (2010). An Anal-

ysis of The Cortex Method at TAC 2010 KBP Slot-

Filling. In Third Text Analysis Conference (TAC

2010), Gaithersburg, Maryland, USA.

Chen, Z., Tamang, S., Lee, A., Li, X., Passantino, M., and

Ji, H. (2010a). Top-down and Bottom-up: A Com-

bined Approach to Slot Filling. In 6

Asia Infor-

mation Retrieval Symposium on Information Retrieval

Technology, pages 300–309, Taipei, Taiwan.

Chen, Z., Tamang, S., Lee, A., Li, X., Snover, M., Pas-

santino, M., Lin, W.-P., and Ji, H. (2010b). CUNY-

BLENDER TAC-KBP2010 Slot Filling System De-

scription. In Text Analysis Conference (TAC 2010),

Gaithersburg, Maryland, USA.

Embarek, M. and Ferret, O. (2008). Learning patterns

for building resources about semantic relations in the

medical domain. In 6

Conference on Language Re-

sources and Evaluation (LREC’08), Marrakech, Mo-

rocco.

Gionis, A., Indyk, P., and Motwani, R. (1999). Simi-

larity Search in High Dimensions via Hashing. In

International Conference on Very Large Data

Bases (VLDB’99), pages 518–529, Edinburgh, Scot-

land, UK.

KDIR 2011 - International Conference on Knowledge Discovery and Information Retrieval

102

Hearst, M. (1992). Automatic Acquisition of Hyponyms

from Large Text Corpora. In 14

International Con-

ference on Computational linguistics (COLING’92),

pages 539–545, Nantes, France.

Ji, H., Grishman, R., and Trang Dang, H. (2010).

Overview of the TAC 2010 Knowledge Base Popu-

lation Track. In Third Text Analysis Conference (TAC

2010), Gaithersburg, Maryland, USA.

Li, F., Zheng, Z., Bu, F., Tang, Y., Zhu, X., and Huang,

M. (2009). THU QUANTA at TAC 2009 KBP and

RTE Track. In Second Text Analysis Conference (TAC

2009), Gaithersburg, Maryland, USA.

McNamee, P., Dredze, M., Gerber, A., Garera, N., Finin,

T., Mayﬁeld, J., Piatko, C., Rao, D., Yarowsky, D.,

and Dreyer, M. (2009). HLTCOE Approaches to

Knowledge Base Population at TAC 2009. In Second

Text Analysis Conference (TAC 2009), Gaithersburg,

Maryland, USA.

Mintz, M., Bills, S., Snow, R., and Jurafsky, D. (2009). Dis-

tant supervision for relation extraction without labeled

data. In ACL-IJCNLP’09, pages 1003–1011, Suntec,

Singapore.

Pantel, P., Ravichandran, D., and Hovy, E. (2004). To-

wards Terascale Knowledge Acquisition. In 20

In-

ternational Conference on Computational Linguistics

(COLING’04), pages 771–777, Geneva, Switzerland.

Ravichandran, D. (2005). Terascale Knowledge Acquisi-

tion. PhD thesis, University of Southern California,

Los Angeles, CA, USA.

Riedel, S., Yao, L., and McCallum, A. (2010). Modeling

Relations and Their Mentions without Labeled Text.

In Machine Learning and Knowledge Discovery in

Databases, LNCS, pages 148–163.

Ruiz-Casado, M., Alfonseca, E., and Castells, P. (2007).

Automatising the Learning of Lexical Patterns: an

Application to the Enrichment of WordNet by Extract-

ing Semantic Relationships from Wikipedia. Data

Knowledge Engineering, 61:484–499.

Shinyama, Y. and Sekine, S. (2006). Preemptive Informa-

tion Extraction using Unrestricted Relation Discovery.

In HLT-NAACL 2006, pages 304–311, New York City,

USA.

Surdeanu, M., McClosky, D., Tibshirani, J., Bauer, J.,

Chang, A., Spitkovsky, V., and Manning, C. (2010).

A Simple Distant Supervision Approach for the TAC-

KBP Slot Filling Task. In Text Analysis Conference

(TAC 2010), Gaithersburg, Maryland, USA.

TAC-KBP (2010). Preliminary Task Description for

Knowledge-Base Population at TAC 2010.

van Dongen, S. (2000). Graph Clustering by Flow Simula-

tion. PhD thesis, University of Utrecht.

Zhou, G., Su, J., Zhang, J., and Zhang, M. (2005). Ex-

ploring Various Knowledge in Relation Extraction. In

ACL 2005, pages 427–434, Ann Arbor, USA.

Zhou, G., Zhang, M., Ji, D., and Zhu, Q. (2007).

Tree Kernel-Based Relation Extraction with Context-

Sensitive Structured Parse Tree Information. In

EMNLP - CoNLL’07, pages 728–736, Prague, Czech

Republic.

A WEAKLY SUPERVISED APPROACH FOR LARGE-SCALE RELATION EXTRACTION

103
